Glooko GMB Users Manual
2.5 mm adapterMeter Connector Glooko MeterSync Blue
1) Download and open the Glooko app
Before you begin:
• Your mobile device’s Wi-Fi or cellular connection must be turned ON.
• Check that you are using the latest version of the Glooko app.
2) Pair your Glooko MeterSync Blue with your iOS
or Android device (one-time only)
If Bluetooth is not ON, on your iOS or Android device, you will be prompted to
do so in the Glooko app.
Note: You will not see the Gloo ko MeterSync Blue listed under d evices in the Bluetooth Set tings on your iOS or
Android device. To check if yo ur Glooko MeterSync Blue is con nected, refer to the Setti ngs screen of the Glooko app.
Open the Glooko app to pair with your Glooko MeterSync Blue:
• First-time user: click on Start Syncing Your Meter on the Home screen of the
Glooko app to initiate the pairing and downloading tutorial.
• Returning user: If you have previously used Glooko, but are setting up the
Glooko MeterSync Blue for the rst time, pair from the Settings screen of the
Glooko app.
Go to Settings>MeterSync Blue>Setup New Device to initiate the pairing tutorial.
3) Download your glucose meter
Please visit suppor t.glooko.com for more detail ed instructions regard ing your meter.
ACCU-CHEK® meters
You will need: Glooko MeterSync Blue
1. With your meter OFF, press and hold down the arrow (or M and S) buttons
until sync icons symbols appear on the meter’s display.
No te: Be sure to press down on the meter but tons at the exact same tim e. If your meter turns ON instead
tur n it OFF and try again.
2. Rest the meter on a at surface.
3. Point the infrared window of the Glooko MeterSync Blue so it faces the
infrared window on your meter.
4. Press and hold the blue power button on the Glooko MeterSync Blue for one
second – you will see a blinking green light.
5. Depending on if you’re a new or returning user, press Start Syncing Your
Meter or Sync on the Home Screen of the Glooko app.
Bayer® meters
You will need: Glooko MeterSync Blue and the meter connector
1. Plug one end of the meter connector into the audio port of the Glooko
MeterSync Blue.
2. Plug the other end of the meter connector into your Bayer meter.
3. Press the power button on your Bayer meter to turn it ON.
4. Press and hold the blue power button on the Glooko MeterSync Blue for one
second – you will see a blinking green light.
5. Depending on if you’re a new or returning user, press Start Syncing Your
Meter or Sync on the Home Screen of the Glooko app.
CareSens® meters
You will need: Glooko MeterSync Blue, meter connector, and 2.5 mm adapter
1. Plug one end of the meter connector into the audio port of the Glooko
MeterSync Blue.
2. Attach the 2.5 mm adapter to the other end of the meter connector and plug
it into your CareSens meter.
3. Press the S button to put your meter into data transfer mode.
4. Press and hold the blue power button on the Glooko MeterSync Blue for one
second – you will see a blinking green light.
5. Depending on if you’re a new or returning user, press Start Syncing Your
Meter or Sync on the Home Screen of the Glooko app.
FreeStyle® meters
You will need: Glooko MeterSync Blue, meter connector, and 2.5 mm adapter
1. Plug one end of the meter connector into the audio port of the Glooko
MeterSync Blue.
2. Attach the 2.5 mm adapter to the other end of the meter connector and plug
it into your FreeStyle meter.
3. Press and hold the blue power button on the Glooko MeterSync Blue for one
second – you will see a blinking green light.
4. Depending on if you’re a new or returning user, press Start Syncing Your
Meter or Sync on the Home Screen of the Glooko app.
No te: The FreeStyle meter can be turned ON o r be kept OFF.
GLUCOCARD® meters
You will need: Glooko MeterSync Blue, meter connector, and 2.5 mm adapter
1. Plug one end of the meter connector into the audio port of the Glooko
MeterSync Blue.
2. Attach the 2.5 mm adapter to the other end of the meter connector and plug
it into your GLUCOCARD meter.
3. Press and hold the blue power button on the Glooko MeterSync Blue for one
second – you will see a blinking green light.
4. Depending on if you’re a new or returning user, press Start Syncing Your
Meter or Sync on the Home Screen of the Glooko app.
Nipro® meters
You will need: Glooko MeterSync Blue and the meter connector
1. Plug one end of the meter connector into the audio port of the Glooko
MeterSync Blue.
2. Plug the other end of the meter connector into your Nipro meter.
3. Press and hold the blue power button on the Glooko MeterSync Blue for one
second – you will see a blinking green light.
4. Depending on if you’re a new or returning user, press Start Syncing Your
Meter or Sync on the Home Screen of the Glooko app.
No te: The Nipro meter can be turned ON or b e kept OFF.
TM
For the Nipro TRUEresult
directly into the meter’s docking station. Contact Nipro for more information.
OneTouch® meters
You will need: Glooko MeterSync Blue and the meter connector
1. Plug one end of the meter connector into the audio port of the Glooko
MeterSync Blue.
2. Plug the other end of the meter connector into your OneTouch meter.
3. Press and hold the blue power button on the Glooko MeterSync Blue for one
second – you will see a blinking green light.
4. Depending on if you’re a new or returning user, press Start Syncing Your
Meter or Sync on the Home Screen of the Glooko app.
ReliOn® meters
You will need: Glooko MeterSync Blue, meter connector, and 2.5 mm adapter
1. Plug one end of the meter connector into the audio port of the Glooko
MeterSync Blue.
2. Attach the 2.5 mm adapter to the other end of the meter connector and plug
it into your ReliOn meter.
3. Press and hold the blue power button on the Glooko MeterSync Blue for one
second – you will see a blinking green light.
4. Depending on if you’re a new or returning user, press Start Syncing Your
Meter or Sync on the Home Screen of the Glooko app.
meter, one end of the meter connector will plug
Troubleshooting
Problem
Unable to
PAIR the
Glooko
MeterSync
Blue
Unable to
DOWNLOAD
with the
Glooko
MeterSync
Blue
Possible Causes
Multiple Glooko
MeterSync Blue devices
are within range.
Battery has run out of power.
Bluetooth is not enabled
on your mobile device.
Too much distance between
the Glooko MeterSync Blue
and your mobile device.
Interference with other apps.
Issue with mobile device.
Solution
Move to a place where there are
no additional Glooko MeterSync
Blue devices and try to pair again.
If the LED is not ON or blinks
weakly upon pressing the power
button, replace the battery
(CR2032).
Turn ON Bluetooth in your mobile
device to allow the Glooko
MeterSync Blue to pair with your
mobile device.
Bring the Glooko MeterSync Blue
and your mobile device closer to
each other.
Other Bluetooth-capable apps
that stream audio may interfere
with downloading. Hard quit your
apps and then relaunch the
Glooko app.
Power o your mobile device
and restart it.
Specications
1. Product Name: Glooko MeterSync Blue for iOS and Android
2. Operating temperature: 50 - 100 ˚F
3. Relative humidity: 26 - 90%
FCC Certied
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits pursuant to Part 15, Subpart C of the
FCC Rules. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used
in accordance with the instructions, it may cause interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
interference to radio or television reception, which can be determined by turning the equipment on and o,
the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna of the aected radio or television.
• Increase the separation between the equipment and the aected receiver.
• Connect the equipment and the aected receiver to power outlets on separate circuits.
• Consult the dealer or an experienced radio/TV technician for help.
The FCC requires the user to be notied that any changes or modications made to this device that are not
expressly approved by Glooko, Inc. may void the user’s authority to operate the equipment.
This device has been evaluated for and shown compliant with the FCC RF Exposure limits.
Trademark
Glooko is a registered trademark of Glooko, Inc., in the USA and/or other countries. All other brand names,
product names, or trademarks belong to their respective holders. Glooko reserves the right to alter product
and service oerings and specications and pricing at any time without notice, and is not responsible for
typographical or graphical errors that may appear in this document.
©2014 Glooko, Inc., All rights reserved. All other trademarks are the property of their respective owners.
Glooko, Inc.
420 Florence Street, Suite 200
Palo Alto, CA 94301
650-720-5310
1-800-206-6601
www.glooko.com
Intended Use
The Glooko device system for the Glooko application is data management
software intended for use in home and professional settings to aid individuals
with diabetes and their healthcare professionals in review, analysis, and
evaluation of blood glucose readings to support an eective diabetes
management program. The Glooko device system for the Glooko application
connects to compatible FDA cleared meters and allows users to transfer their
blood glucose meter results to their mobile devices running on an iOS or Android
operating system.
The Glooko device system for the Glooko application is not intended to provide
treatment decisions or to be used as a substitute for professional healthcare advice.
Printed on recycled stock. IM GMB 100 REV A
Glooko MeterSync Blue for iOS and Android
™™
Part Number: GMB100
INSTRUCTION GUIDE
Need more detailed instruction?
Visit: support.glooko.com
Warning:
Unplug the Glooko MeterSync Blue from your meter after each
use. Leaving it plugged in can drain your meter’s battery.
It is important that you do not sync your meter with Glooko
app(s) while you are still testing for your blood glucose levels.
™
