Page 1
INTEGRATED 3G/4G/WI-FI SYSTEM
To browse the Internet along the coast
USER AND INSTALLATION MANUAL
GL00159
LABEL
Page 2
weBBoat 4G
2
TECHNICAL SPECIFICATIONS
Antenna dimensions (diam.x H): 250 x 300 mm / 10x12"
Antenna weight: 1,2 kg / 2,65 lb
Automatic switch from Wi-FI registred networks to 4G.
4G backup WAN function
LTE 4G up to 100 Mbps in download and 50 Mbps in upload
DC- HSPA+ up to 42 Mbps in download and 5.76 Mbps in upload
Four Ethernet ports
2 Diversity (high) performance antennas
SMS reboot function
Android and iOS App for an easy control
Easy installation require only power supply connection 12/24V
UV waterproof resistant Dome
General Feautures
LTE FDD bands: B1/B2/B3/B5/B7/B8/B20
DC- HSPA+/HASPA+/HSPA/UMTS: 850/900/1900/2000 MHz
GSM/GPRS/EDGE: 1900/1800/900/850 MHz
Power Class 3 (23 dBm) for LTE FDD
Power Class 3 (24 dBm) for UMTS
Power Class E2 (26 dBm) for EDGE 1800/1900 MHz
Power Class E2 (27 dBm) for EDGE 850/900 MHz
Power Class 1 (30 dBm) for GSM/GPRS 1900/1800 Mhz
Power Class 4 (33 dBm) for GSM/GPRS 900/850 Mhz
Data
Mode LTE: DL 100 Mbps - 50 Mbps UL
DC-HSPA+: DL 42 Mbps - 5.76 Mbps UL
WCDMA PS: DL 384 Kbps - 384 Kbps UL
EDGE: DL 236,8 Kbps - 236,8 Kbps UL
GPRS: DL 85,6 Kbps - 85,6 Kbps UL
Complies with IEEE 802.11n, IEEE 802.11g and IEEE 802.11b wireless
Complies with IEEE 802.3 and IEEE 802.3u Ethernet standards - I Access
point for connecting Wi-FI
Page 3
weBBoat 4G
3
INDEX
1. FOREWORD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 DELIVERY LETTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 IDENTIFICATION weBBoat . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.3 WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.4 GENERAL SAFETY RULES . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.5 ENVIRONMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2. PRODUCT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . 6
3. CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.1 INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2 INSERTING THE SIM CARD . . . . . . . . . . . . . . . . . . . . . . . 13
4. HOW TO DOWNLOAD CONTROL APP FOR weBBoat . . . . . . 14
5. FIRST TIME SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Page 4
weBBoat 4G
4
1. FOREWORD
1.1 DELIVERY LETTER
Welcome: with the installation of this antenna, the world of fast Internet
comes on board your boat.
This manual has been drafted in order to help you with the correct installation and operation of the weBBoat to meet all your requirements.
1.2 IDENTIFICATION weBBoat
For any communication with GLOMEX or its service center, always have the
serial number and the model of the weBBoat shown on page one of the
manual, on the packaging and on the router inside the weBBoat.
1.3 WARRANTY
GLOMEX guarantees the weBBoat IT1004 against conformity defects for a
period of 24 (twenty-four) months from the date of shipment.
Warranty is intended as the repair or replacement of the equipment showing
conformity defects when entering the sales contract, with no charge for the
materials.
In case of conformity defects, the customer is entitled to the replacement of
the goods with no charge.
The warranty is only valid if the product comes with a valid proof of purchase
(receipt or invoice).
The non-conforming product must be sent back to a Service Centre or
authorized retailer, who, if necessary, will forward it to:
GLOMEX S.r.l.
Via Faentina 165/G
48124, Ravenna (Italy)
complete with all the accessories supplied at the time of purchase for a
refund.
The serial number must neither be erased nor made illegible, otherwise the
warranty will be voided.
S
CAUTION
Conserve the installation and user manual with care! Losing
the serial number makes the warranty null and void!
Page 5
weBBoat 4G
5
The warranty does not apply in case of damage due to carelessness, use or
installation not compliant with the instructions given, tampering, product or
serial number modification, damage due to accidental causes or to the
buyer’s negligence.
Moreover, warranty does not apply in case of damage consequent to connections of the equipment to different voltages than those indicated or to sudden voltage variations of the network the equipment is connected to, as well
as in case of damage caused by leakage, fire, inductive/electrostatic discharges or discharges due to lightning, use of cables different to those provided, overvoltages or other phenomena not related to the equipment.
Finally, the warranty does not apply to problems caused by the telephone operator and at a WI-FI hotspot.
The parts subject to wear consequent to use such as connection cables, connectors, external parts and plastic supports are covered by a one-year
period warranty.
The following are not covered by warranty: periodic monitoring, software
updates, settings of the product, maintenance.
After the expiration of the warranty period, the technical support activities
will be carried out charging the customer for the replaced parts, the labour
costs and freight charges, according to current rates.
The equipment will be replaced or repaired under warranty only and
exclusively on Glomex quality department’s approval.
Should any dispute rise, the place of jurisdiction will exclusively be Ravenna
(Italy).
The warranty is provided by:
GLOMEX S.r.l.
Via Faentina 165/G
48124 Ravenna (Italy)
1.4 GENERAL SAFETY RULES
Carefully read the instructions and follow the recommended precautions to
avoid potential hazards and safeguard your
health and safety, before carrying out any installation and maintenance.
This manual contains the following indications:
S
CAUTION
This symbol warns against potential damage to the equipment which could involve the operator’s safety.
Page 6
weBBoat 4G
6
Failure to comply with the instructions preceded by the above-mentioned
keywords (WARNING) can cause serious accidents or even the death of the
persons involved.
Moreover, in this Manual, some instructions are given with text in italics, preceded by the word NOTE.
The information and specifications given in this manual are based upon the
information available at the moment it is written.
In case of doubts, do not hesitate to contact GLOMEX S.r.l. to the following
email:
service@glomex.it
1.5 ENVIRONMENT
Do not throw the appliance away with the normal household waste at the
end of its life, but hand it in at an official point for recycling. By doing this,
you will help preserve the environment.
2. PRODUCT DESCRIPTION
weBBoat 3G/4G IT1004 is the new integrated system for surfing the internet
with 4G network and Wi-Fi both with the boat anchored in the harbor and
along the coast at more than 10 nautical miles, suitable for all types of
boats, ships and yachts where coverage of GSM networks and Wi-Fi permits.
The weBBoat 4G is also compatible with LTE, 3G systems, UMTS and GPRS
data.
NOTE The distance from the coast within which the weBBoat works
depends on the 3G/4G signal coverage from the transmitter of your
telephone operator, on the correct installation of weBBoat and on its
height.
Inside the ASA radome there is a 3G/4G antenna, a Wi-Fi antenna, a specifically constructed router with dedicated software to operate on the boat and
an access point which, protected from the elements, allow you to have a
simple and convenient high-speed internet connection on your boat in a few
Fig. 1
Page 7
weBBoat 4G
7
minutes: simply insert a SIM card (not supplied) into the external slot and
you can connect in Wi-Fi any internet devices (iPhone, smartphone, iPad,
tablet, PC...) to the Wi-Fi network of the harbor or to the 3G network.
In addition, the router inside the radome compact size (250mm/10" in diameter and 300mm/12" in height), it automatically switches from 3G/4G network to the Wi-Fi network (where you have already registered), and vice
versa to be certain of an internet connection without interruptions and costeffective. Finally, to manage in an extremely easy and convenient manner
the integrated system, weBBoat Glomex also offers an App for iOS and
Android.
GL00186
UMTS
GPRS
2G
Fig. 2
Page 8
weBBoat 4G
8
3. CONTENTS
The weBBoat is shipped packed in a cardboard box and sealed with the
strapping GLOMEX
"SEAL OF SAFETY" which acts as a seal for the WARRANTY OF CONTENTS.
Upon receipt, check that:
- the packaging is whole and the warranty hoop is present;
- the supply matches the order specifications;
- there is no damage to the antenna;
- there is the label with SSID, S/N and PASSWORD to access the weBBoat. This label is present on page 1 of this manual.
In case of damage or missing parts, immediately inform the Retailer, if possible with appropriate photos.
W
E
B
B
O
A
T
C
O
A
S
T
A
L
I
N
T
E
R
N
E
T
A
N
T
E
N
N
A
GL00152
Fig. 3
Fig. 4
SISTEMA INTEGRATO 4G/WI-FI
Per navigare in internet lungo la costa
SISTEMA INTEGRATO 4G/WI-FI
Per navigare in internet lungo la costa
SISTEMA INTEGRATO 4G/WI-FI
Per navigare in internet lungo la costa
SISTEMA INTEGRATO 4G/WI-FI
Per navigare in internet lungo la costa
SISTEMA INTEGRATO 4G/WI-FI
Per navigare in internet lungo la costa
MANUALE D’INSTALLAZIONE E D’USO
USER AND INSTALLATION MANUAL
MANUEL D’INSTALLATION ET UTILISATION
BETRIEBS- UND INSTALLATIONSHANDBUCH
MANUAL DEL USUARIO E INSTALACIÓN
USE
R AND
IN
S
TAL
L
AT
IO
M
ANUEL D’
ANUEL D’
ANUEL D’
ANUEL D’
I
NS
TAL
L
AT
I
I
IO
N E
RIEBS-
UN
D INST
D
ALL
ATI
ANU
AL
DE
L
USUARIO
E
www.glomex.it
GL00184
Page 9
weBBoat 4G
9
3.1 INSTALLATION
Installation on sailboats
It is advisable to place the weBBoat to a maximum height of 8/10 meters on
the shaft cross with the support Glomex code ITM001 (not supplied).
The weBBoat must be fixed to the support by tightening the screw on the
bottom of weBBoat with a screwdriver (Fig. 6).
IMPORTANT: Do not install the weBBoat masthead.
GL00153
NO
OK
8 - 10 m MAX
Fig. 5
WITH ITM001
(OPTIONAL)
WITH ITM001
(OPTIONAL)
GL00188
Fig. 6
Page 10
weBBoat 4G
10
Installation on motor boats in fiberglass
Installation on motor boats in metal
GL00154
OK
Fig. 7
GL00189
Fig. 8
SECOND
ACCESS
POINT
THIRD
ACCESS
POINT
Use up to 4 access points
FOURTH
ACCESS
POINT
Page 11
weBBoat 4G
11
Warning:
- The weBBoat must be fixed to a base/support by tightening the screw
in the base of the weBBoat by means of a screwdriver (
Fig. 6 ).
- The installation of the weBBoat near or above a flat metal surface
may result in significant reduction of the Wi-Fi and 3G/4G signal
strength.
- Do not mount the weBBoat near metal obstructions that may interfere with the Wi-Fi signal.
On metal crafts, the Wi-Fi signal is blocked, for this reason it is necessary to
place a second access point (up to a maximum of 4 APs) inside the boat and
connect them with a switch (optional) to the router inside of weBBoat via an
Ethernet cable (optional) (Fig. 9). The access point present inside the
radome can be used for the Wi-Fi coverage outside the boat.
Electric connections
For the proper functioning of weBBoat, simply connect the antenna to a 12/
24 Vdc power supply cable (not provided) according to the following guidelines.
Connect the red (positive) and the black wire (negative) coming out from the
base of weBBoat to the battery through a red/black power cable. The connection can be made by soldering or with a clamp. It is advisable to have this
procedure carried out by a technician.
IMPORTANT
: The polarity reversal on the power supply will burn the fuse.
The power line (not supplied) which connects the two wires coming out from
the base of weBBoat must have cables with a cross section of 1.5 mm² by a
length up to 10 m, and 2.5 mm² for longer lengths.
WARNING: in the power line, we recommend placing a switch upstream to
avoid electricity consumption when the weBBoat is not used.
GL00187
LAN1 LAN3
Fig. 9
Page 12
weBBoat 4G
12
NOTE: In order to receive the signal from the weBBoat inside metal crafts,
up to a maximum of four access points (according to your needs) must be
placed inside the boat, which must be linked with a switch to the router
inside the weBBoat via an Ethernet network cable.
GL00155
+
+
-
-
W
E
B
B
O
A
T
C
O
A
S
T
A
L
I
N
T
E
R
N
E
T
A
N
T
E
N
N
A
12/24 V dc
Fig. 10
CIRCUIT
BREAKER
1st ACCESS
POINT
2nd
ACCESS
POINT
3rd ACCESS
POINT
4th ACCESS
POINT
ROUTER
SWITCH
ETHERNET
CABLE
Page 13
weBBoat 4G
13
3.2 INSERTING THE SIM CARD
Insert the SIM CARD into the upper socket of the "EXTERNAL SLOT"
of the weBBoat, which is located at the bottom of the radome.
Insert the SIM card with the contacts facing down and the cut edge of
the SIM facing outward, as shown in Fig. 11.
NOTE Insert the SIM CARD with weBBoat off.
IMPORTANT: If the SIM card has a PIN, you must remove the PIN code
request before inserting the SIM card into weBBoat. This can be done via a
mobile phone and varies according to the individual mobile phones. Please
check the steps in the instructions of your mobile phone, or contact your
operator.
GL00156
Fig. 11
SIM CARD
SLOT
CUT EDGE OF
SIM CARD
UPPER SOCKET
BOTTOM OF RADOME
Page 14
weBBoat 4G
14
4. HOW TO DOWNLOAD CONTROL APP FOR
weBBoat
Register your weBBoat with the free downloading of the Glomex
App from the Apple Store for Apple devices or from the Play Store
for Android devices.
The App Glomex for weBBoat is essential to setup the weBBoat.
IMPORTANT: The app instructions should be used only by the
weBBoat administrator (using only one device). After following
all the steps in the following instructions, all the other internet
devices (up to 31) must simply select the wi-fi network of the
webboat and enter the password, if required.
GL00158
Fig. 12
Page 15
weBBoat 4G
15
After the download, activate the Wi-Fi connection, then connect to the
weBBoat. The weBBoat network name is “WeBBoat 4GXXX” (Fig. 13); access
to the network requires a password. The password is shown on the label on
page 1 of this manual.
Please note YOU MUST CONNECT YOUR IOS OR ANDROID DEVICE
TO THE WI-FI NETWORK OF THE WEBBOAT AND NOT TO THE
HARBOR, OFFICE NETWORK OR OTHERS.
Fig. 13
Page 16
weBBoat 4G
16
5. FIRST TIME SETUP
The weBBoat has only one administrator who needs to do the following setup
once with a single device.
Open the App and select the language clicking the flag (Fig. 14).
If the Wi-fi is connected, the page is displayed (Fig. 15). If the app does
not work, check the presence of connection. In this case, check that the
weBBoat Wi-Fi connection is enabled and try again.
Page 17
weBBoat 4G
17
After selecting the language, open the drop-down menu on the left and
select “weBBoatCoastal Internet” (Fig. 16).
When you first open the app you will be asked to record some data, fill in the
request form, then click the Registra/Salva [Record/Save] button and
wait (Fig. 17).
IMPORTANT: Fill in the WeBBoat S/N (serial number) field with the
correct code, located on the first page of this manual or on the box or on
the router inside the WeBBoat (Fig. 18).
If the WeBBoat S/N (serial number) field is not complete, we can
not guarantee immediate assistance.
When you arte prompted for a password, enter admin01
(Fig. 19)
Fig. 16
Fig. 17
Fig. 18
Fig. 19
Page 18
weBBoat 4G
18
After your registration, the page "weBBoat control App" will open. Some
information may be missing on the page, in this case you must refresh
it. Click the refresh button at the top of the page (Fig. 20) and wait until the
process is complete. This could take a while.
Once refreshed, the page will have all the necessary information. You will
also notice that the "4G in use" button is green; this means that the 4G is
active (Fig. 21).
GL00167
Fig. 20
Page 19
weBBoat 4G
19
To continue , click "APN in use" (Fig. 23), click the World icon at the top
(Fig. 22) and select your country from the list (Fig. 24); select the APN compatible with your operator (Fig. 25) and click "OK" to confirm.
Fig. 23
GL00169
GL00170
Fig. 22
Page 20
weBBoat 4G
20
NOTE If your compatible APN is not in the list, click States to go back (Fig.
26) and click APN- (Fig. 27). At this point you will see the "Manual APN set-
ting" screen; click the "arrow" at the top (Fig. 28) and fill in the information
requested on the form. Once this is done, click Salva [Save] (Fig. 29). If you
do not know the APN of your device, contact your service provider.
GL00173
GL00174
GL00175
Page 21
weBBoat 4G
21
If, by mistake, you select the wrong operator, click Cancel and select again.
In case of an error in the selection of the state, click the world icon to return
to the list and select the correct state.
Once all the information provided is correct, click "OK" (Fig. 30) and wait for
the setup.
Note: this process could take a few minutes.
Once the configuration was successful, the weBBoat is ready to surf the
internet using the 4G mode.
S
CAUTION
If the App is not correctly set, the device cannot browse the
internet through the 3G/4G. Some operators have dedicated
APN for special contracts; in this case, contact your service
provider.
Note: ensure that the App is correct and installed.
Page 22
weBBoat 4G
22
If you want to add a Wi-Fi connection external to the 4G weBBoat to share
with the devices on the boat, click "Scan Wi-Fi Network" (Fig. 32) and wait.
A list of available connections will be displayed. Click the name of the Wi-Fi
connection required (Fig. 33) and click OK to confirm. Enter the password
for the Wi-Fi network selected and click OK/CONNECT (Fig. 34), and wait a
few minutes. Now, the information of the Wi-Fi network you have chosen will
appear in the Wireless table (Fig. 35).
The "auto switch" button is green and the "4G Ready" is yellow.
This means that you are using the selected Wi-Fi network (SSID)
to surf the internet.
Fig. 33
Fig. 34
Page 23
weBBoat 4G
23
S
CAUTION
Some hotspots cannot be used by the weBBoat because the
device is recognized as a router.
Finally, to return to the 3G/4G, click the yellow button "4G Ready" (Fig. 36).
Wait a few minutes for the setup. At the end of the procedure, the "4G
Ready" button is green (Fig. 37). This means that now you are connected to
the internet in 4G mode.
NOTE The use of the external Wi-Fi network has priority over 3G/
4G to limit the service costs.
weBBoat automatically switches between the harbor or land Wi-Fi to
3G/4G when the Wi-Fi signal is no longer received.
If the Wi-Fi signal is weak, you can force the use of 3G/4G by clicking on "4G READY" (Fig. 35).
WARNING: if you change the SIM card in the weBBoat, repeat the proce-
dure from chapter 5.
Fig. 37
Page 24
weBBoat 4G
24
NOTE:
Loading...
