1. Labdisc Hardware Overview
1.1 What’s in the Pack
① Labdisc data logger
② Labdisc AC charger
③ USB cable
④ Quick start guide
⑤ Warranty page
1
4
⑥ Software CD
⑦ Temperature probe
⑧ Colorimeter 5 cuvettes set
⑨ pH electrode
⑩ Dissolved oxygen electrode
(Must be ordered separately)
2
5
6
⑪ Plastic stand + screw
⑯
Universal sensor adaptor
3
7
9
12
11
1
Page 3
Pullman Academic
1
Better Learning Outcomes
1.2 Ports and Controls
The picture below reviews the Labdisc ports, sensors, keypad and display:
① On/Off and Escape key
② Scroll key
③ Select key
④ Sensor selection keys
⑤ Graphical display 128 x 64 pixels
⑥ Rotating ring
⑦ USB port
⑧ Plastic leg
⑨ M5 screw insert
⑩ Colorimeter and turbidity sensor
⑪ External temperature input
⑫ Relative humidity
⑬ IR temperature
⑭ Sound level
3
1
4
5
2
7
6
8
9
18
⑮ pH input and dissolved oxygen
⑯ Barometric pressure
⑰ GPS sensor
⑱ UV and universal input
10
11
12
13
17
16
15
14
16
Pullman Academic
Measuring
Better Learning Outcomes
1.3 Built-in Sensors
Icon Type Range Description
Ambient
temp.
Barometric
pressure
-10 °C to 50 °C
300 to 1100 mB
Measuring
ambient
temperature
Measuring
barometric air
pressure
Max.
Sample
Rate
1/s Not required
1/s
External
Accessories
(supplied
with Labdisc)
Not required
Colorimeter
Dissolved
oxygen
External
temp.
GPS N/A
Infra-red
temperature
pH 0 to 14 pH
10 - 90 %
transmittance
(3 colors)
0 to 14 mg/l
-25 °C to 125 °C
-70°C to 380°C
solution
transmittance in
3-light
wavelength: Red,
Green, Blue
Measuring
distance
General purpose
stainless steel
temperature
probe
Measuring 6
different
parameters:
Longitude,
latitude, course,
speed, date and
time
Contactless
temperature
measurement. No
need to touch the
measured body
Measuring pH
level
1/s
10/s
10/s
1/s Not required
1/s Not required
10/s
Cuvette set
Dissolved
oxygen
electrode
Temp. probe
pH electrode
Pullman Academic
Better Learning Outcomes
Icon Type Range Description
Relative
humidity
Sound level 58 to 93 dB
0 to 100% RH
Turbidity 0 to 1000 NTU
Ultra Violet
(UV)
Radiation
Universal
input
0 to 400 W/m2
0 to 5 V
Measuring
relative humidity
Measuring sound
level
Measuring water
turbidity level
Measuring sun UV
radiation
Connecting
Fourier or Vernier
analog sensors
Max.
Sample
Rate
100/s Not required
10/s Not required
1/s
10/s
24,000/s
External
Accessories
(supplied
with Labdisc)
Cuvette set
Not required
Universal input
adapter cable
Pullman Academic
Better Learning Outcomes
1.4 Using the Labdisc
CHARGE THE LABDISC BATTERY BEFORE STARTING
Before working with the Labdisc for the first time, the unit should be charged for
six hours with the supplied 12 V charger. The Labdisc charging input is located to
the left of the On/Off key. Simply rotate the orange ring until the charging input on
the Labdisc is exposed and then connect the
charger plug to the charging input.
The Labdisc charger will accept any input voltage ranging from 100 to
240 VAC 50/60 Hz, making it functional worldwide.
Labdisc
charging
input
Pullman Academic
1
2 3 4 5
6
7
Better Learning Outcomes
1.4.1 Labdisc display
The Labdisc LCD display allows users to see the different sensor readings and to
setup or re-configure the Labdisc parameters.
①
Run/Stop icon – shows when the Labdisc is logging data, or when
the Labdisc is not logging sensor data.
Sound Status – shows active sound beep when the key is pressed and
②
when the sound beep is disabled.
Communication Status – shows when Bluetooth communication is
③
enabled, or when the USB cable is connected from the host computer to the
Labdisc.
④
GPS Status – shows when the GPS is enabled, when locked to GPS
satellites and provides valid positioning parameters.
Pullman Academic
Select key
Scroll key
On/Off and ESC key
3 con trol keys
7 se nsor keys
Better Learning Outcomes
⑤ Battery Level – shows battery capacity at 3 levels , or
when the Labdisc is connected to the external charger.
Sensor Value – shows the selected sensor value.
⑥
Sensor Name and Unit - shows the selected sensor name and unit.
⑦
1.4.2 Labdisc keys
The Labdisc 10 keys are divided into 7 sensor keys and 3 control keys. Using the
sensor keys users can select and view different sensor readings. The control keys
are used to turn on/off the Labdisc, setup the device for the next logging session
and configure all its parameters. The 3 control keys are:
1.4.3 Labdisc menu
Press the scroll key to enter the Labdisc menu. Then use the scroll key to scan the
menu options, the select key to choose a menu option and the ESC key to go one
level up in the menu.
Pullman Academic
Better Learning Outcomes
1.4.3.1 Setup the Labdisc for the next logging session
1.4.3.2 Labdisc information
Pullman Academic
Better Learning Outcomes
1.4.3.3 Configuration of the Labdisc
Pullman Academic
Better Learning Outcomes
2. GlobiLab Analysis Software
2.1 Software Installation
To install the software, users should run the following installers:
For PC: GlobiLab-en-1.0-setup.exe
For Mac: GlobiLab-en-1.0-setup
Then follow the simple installation instructions. These instructions take the user
through the installation of the GlobiLab software and the USB driver needed for
USB communication with the Labdisc.
2.2 Software Functionality
Page 12
Pullman Academic
Better Learning Outcomes
2.3 Software Popular Icons and their Functions
Selecting the Open-project icon opens the stored activity
*.XML files and displays all its graphs and graphical
attributes.
Selecting the Workbook icon opens the activities folder,
where users can choose from a variety of PDF activities.
Clicking the Display-options small triangle icon allows the
user to select one of the following six display options:
1. Meter view
2. Table view
3. Graph view
4. Map view
5. Mixed Meter and Graph view
6. Mixed Table and Graph view
Selecting the Sensor legend:
1. A left click on the sensor name will set it as the
active sensor and will change the y-axis to
reflect this sensor’s units and scale
2. First right click on the sensor name will change
the line graphs to symbols
3. Second right click on the sensor name will
remove this sensor graph from the display
4. Third right click on the sensor name will return
to the default view for this sensor and will
show it as a line graph on the display
Page 13
Pullman Academic
Better Learning Outcomes
The graphic window includes a graph title. The default title
is New Experiment. Changing this title is done with a
double left mouse click over the title. A small text dialog
box will open where the user can type in the new title.
When displaying two or more sensors – a right click on the
graph x-axis title will open a dialog box for assigning a
sensors or time as the x-axis.
Selecting the Meter view:
A left mouse click on the four bottom blue dot icons will
change the number of meters on the screen to: 1, 2, 4 or 6
meters.
A left click on any of the meters will open a dialog box for
meter type selection and assigning a sensor for this meter.
Selecting the Marker icon enters into Marker mode. Left
mouse click, near any of the graphs, will place a marker on
the graph. Hovering over any of the markers, while
pressing and holding the left mouse button and dragging
the mouse, will move the marker over the graph. Selecting
the Marker icon again, exits the Marker mode.
Selecting the Annotation icon activates the Annotation
mode. Left mouse click opens a dialog box where users
can enter text and images. Pressing the Annotation icon
again exits the Annotation mode.
Page 14
Pullman Academic
Better Learning Outcomes
Pressing the Function-options small triangle icon allows
the user to apply the mathematical functions listed below
between the graph markers:
1. Selecting the Linear regression icon will
display the best linear line that fits the graph
between the locations of two markers. Next to the
line the software will open a small text box
displaying the linear line equation: Y= aX+b.
2. Selecting the Quadric regression icon will
display the best parabolic line (2
the graph between the locations of two markers.
Next to the line the software will open a small text
box displaying the parabolic line equation: Y=
aX²+bX+c.
3.
Selecting the Run icon launches a new data collection
session.
Selecting the Stop icon ends the current data collection
session.
Selecting the FFT icon will split the graphic
display and show the original measurement on a
time scale in the top graphic window, and its
harmonics, on a frequency scale in the bottom
graphic window.
nd
degree) that fits
Selecting the Selective download icon opens a table listing
all stored recordings. Selecting one of the lines on the
table and pressing download will download this specific
recording to the computer.
Page 15
Pullman Academic
Better Learning Outcomes
Setting up the Labdisc is done by selecting the Setup icon.
The software will open a dialog box, where users can
select/remove sensors, set the sampling rate and the
amount of samples for the next data recording.
Selecting the EXCEL icon saves the file in a *.CSV format,
prompts the user for a file name and then automatically
opens EXCEL and exports the experiment data into the
spreadsheet.
GlobiLab status bar, is located at the bottom right corner
of the software. It includes 3 icons:
1. USB indicator – where blue indicates a USB
communication between the computer and the
Labdisc.
2. Bluetooth indicator – where blue indicates a
Bluetooth wireless communication between the
computer and the Labdisc. A right mouse click on
this icon will open a list of recognized Labdiscs, click
on one to connect.
1. Memory info – shows how many experiments are
stored in the Labdisc memory, out of a maximum of
127. In the example above there are 7 stored
experiments out of 127. A right mouse click on this
section will allow users to erase all stored data or
just the last recording.
Page 16
Pullman Academic
Better Learning Outcomes
2.4 GlobiLab Software for iPad
The GlobiLab software for iPad (iPad, iPad 2 and 3rd generation iPad models) is
available in the App Store and makes K-12 science experiments mobile, convenient
and immediate. GlobiLab wirelessly integrates between the Labdisc data logger and
the iPad. Allowing full Labdisc management (setup of all data logging parameters,
online display of current measurements and download of the Labdisc sample
memory), together with graph manipulations (markers, zoom, crop, text and image
annotation) and data analysis (statistics and curve fitting etc.).
GlobiLab software for iPad was specifically designed to engage students and help
visualize complex science concepts by harnessing the iPad built-in accelerometer
sensor, data display, multimedia and multi-touch features. The following steps
provide a guide on the installation and implementation of the GlobiLab App for iPad.
Download and install of the GlobiLab application
Tap the iPad App Store icon
Search for “GlobiLab”
Press the FREE green key to install the application
Set wireless communication between the Labdisc and
the iPad
Go to iPad Setting - Bluetooth and select your
Labdisc from the Devices list
The iPad should immediately connect to your
Labdisc and change its status to “connected”
Close the setting and open the GlobiLab software
Meter view
Tap Meter view
current values of the Labdisc sensors
Tap one of the Meters and scroll the sensor wheel
to select a different sensor type for an existing
Meter
Select a different Meter type from the
horizontal line of icons
to see the
Page 17
Pullman Academic
Better Learning Outcomes
Data collection
Tap the SETUP icon and enter the SETUP
screen. This dialog box allows you to select the
Sensors, Sampling rate and amount of samples for
the next data recording.
Tap the RUN icon to start recording and
observe the graph build up on the screen
You may switch the display to a Bar Graph view by
tapping the Bar Graph key
You may switch the display to a Table view by
tapping the Table key
To stop recording tap the STOP icon
Download Labdisc stored measurements to the iPad
The Labdisc can store up to 127 different experiments.
This is very useful when conducting outdoor data
collection or long measurements.
Tap the Download icon
The iPad will list all Labdisc stored experiments
Each line on this list shows what sensors were
recorded, at what sampling rates and for how
many samples. In addition it indicates the date
and time of the recording.
Click on one of the lines in the list. The Labdisc
transfers the data to the iPad.
After all data is transferred, the iPad will show a
graph of the collected measurement
Data analysis (markers, curve fitting)
Tap the open icon and select “Free fall”.
This graph describes a real recording of a pingpong ball bouncing on a table, as recorded by the
Labdisc distance sensor. For more details see the
Free Fall movie at:
http://www.globisens.com/resources/experiment
-videos
Page 18
Pullman Academic
Better Learning Outcomes
Long touch on the graph to add a Marker
Touch the Marker to cross and drag it with your
finger. View the Marker text box data changing
while the marker follows the graph line.
Tap the graph twice to view the actual sampling
points
Long touch the graph to add a 2
Place both the Markers on the beginning and end
of a single ball jump
Tap the Curve Fitting icon and select a
Quadric Regression to get the mathematical
equation representing the ping-pong ball jump.
From this equation we can calculate earth
gravitation.
Graph Annotation
Use a long touch anywhere on the background
(not on a graph), create an empty annotation. The
edit annotation box opens automatically. From
here:
Use of Map view in field trip (Environment)
Recording GPS together with other Labdisc sensors,
enables the GlobiLab software to plot these sensors
over the Apple maps.
nd
Marker
o Edit or write an annotation
o Add an image using the camera or the
image gallery
o Remove the annotation
Make sure the iPad is connected to the Internet
Tap the Open icon and select the “Walk in
the park”. In this experiment we measured the
different climate in a city park compared to a
nearby cross road. For more details check the
Microclimates movie at:
http://www.globisens.com/resources/experiment
-videos.
Tap the color scale on the left and select Amb.
Temperature. Observe the dramatic temperature
change while walking from the city cross-road to
Page 19
Pullman Academic
Better Learning Outcomes
the park.
Tap the colored samples on the map to get a
marker with the temperature value.
Pinch to zoom in/out the map
See the experiment data in a table, by tapping the
Table View
longitude and latitude values.
You may show other experiments under this
category like” Trip to the Dead Sea” or “Flight
from Tel-Aviv to Istanbul”
Online help
GlobiLab offers an online help for each of the 5 views:
Line, Bar, Table, Meter and Map.
Open the relevant View
and observe the GPS
Tap on the HELP icon
functions and controls
and observe a list of
Page 20
Pullman Academic
Better Learning Outcomes
3 Labdisc – GlobiLab Communication
3.1 USB Communication
Upon USB cable connection between the computer and the Labdisc, the GlobiLab
software automatically detects the USB connection and begins communicating with
the Labdisc.
3.2 Bluetooth Wireless Communication
Before wireless communication with a Labdisc for the first time, the Labdisc should
be added as a device to the computer in a process called pairing. Pairing need be
done only once for each Labdisc, after which the computer stores the connection
information, including a unique name for each Labdisc. When no Labdisc is
connected via USB, the computer will automatically try to wirelessly connect to the
last connected Labdisc. To connect to a different or a new Labdisc, right click on
the Bluetooth icon in the GlobiLab status bar, located at the
bottom right corner of the screen, then click on the Labdisc you want to connect
to.
3.2.1 Set the Labdisc to “pairing mode”
1. Turn on the Labdisc.
2. Press the Scroll key to launch the Labdisc menu.
3. Scroll and select the Configuration menu.
4. In the configuration menu scroll and select the Bluetooth icon.
5. In the Bluetooth menu select “BT pairing”. The Labdisc will produce a
long “beep” sound and switch to “BT enabled”.
Page 21
Pullman Academic
Better Learning Outcomes
3.2.2 Pairing with a PC running Windows OS
1. Start the GlobiLab software.
2. Right click the Bluetooth icon, located on the
status bar at bottom right corner of the GlobiLab.
3. This action opens a pop-up menu. From the menu select “find more
Labdiscs”. The computer opens the “add a device” dialog box and starts
searching for the Bluetooth device.
4. Your Labdisc will be displayed as “Labdisc-xxxx” where “xxxx” are the 4
last digits of the Labdisc serial number sticker. Select this device and
press Next.
nd
5. Select the 2
6. In the next dialog box enter “1234” as the pairing code and click Next.
Wait for the computer to finish the process and announce that the
Labdisc and computer were paired successfully.
option: “Enter the device pairing code” and press Next.
7. Right click the Bluetooth icon on the status bar. Choose the Labdisc
you’ve just paired and click on it. The computer will connect to the
Labdisc and will turn the Bluetooth icon blue.
3.2.3 Pairing with a Mac OS
1. Open the Bluetooth menu from the Mac menu bar and select "Set Up
Bluetooth Device...".
2. A dialog box opens. Your Labdisc will be displayed as “Labdisc-xxxx”
where “xxxx” are the 4 last digits of the Labdisc serial number sticker.
Select this device and press Continue.
3. Put your Labdisc in pairing mode again (see 3.2.1)
Page 22
Pullman Academic
Better Learning Outcomes
4. In the next dialog box press the “Passcode Options…” button and select
5. When the wizard action is complete wait for the computer to confirm
6. Open the GlobiLab software.
7. Right click the Bluetooth icon located at the
8. Choose the Labdisc you’ve just paired and click on it. The computer will
rd
option: “Use a specific passcode”. Enter the passcode “1234”,
the 3
press “OK” and “Continue”.
that the Labdisc was added successfully. The Labdisc is now paired, and
the software can connect to it.
bottom right corner of the software.
connect to the Labdisc and turn the Bluetooth icon blue.
3.2.4 Pairing with an iPad
1. Launch the iPad Setting
2. Open Bluetooth. Make sure the iPad Bluetooth is on.
3. From the devices list click the “Labdisc-xxxx”, where the xxxx digits
match the last 4 digits of your Labdisc S/N sticker on the Labdisc back
cover.
4. The iPad will ask for a PIN code. Enter “1234” and click Pair.
5. The iPad will show Labdisc-xxxx connected.
Page 23
Pullman Academic
Walk in the Park
Better Learning Outcomes
4. Experiment Samples
The GlobiLab software includes experiment samples, for teachers and students to
view, analyze, modify or repeat. In this section some interesting GlobiLab recorded
experiments are reviewed. To open a recorded experiment, simply press the Open
icon in the GlobiLab software and select the files below:
Micro climate activity. Comparing temperature
and relative humidity at a city cross-road and
park
Sensors selected: External temperature,
relative humidity, GPS
Sampling rate: 1/sec
Amount of samples: 1000
Experiment duration: 15 minutes
Communication: Offline, data down-
loaded at recording’s end
Data Analysis: Show temperature and
humidity changes on GlobiLab map view
pH level of Soft Drinks
A fun and interesting activity, comparing the
acidity of water, lemon juice and Coca-Cola.
Sensors selected: pH
Sampling rate: 10/sec
Amount of samples: 1000
Experiment duration: 2 minutes approx.
Communication: Online, preferably with
Bluetooth wireless communication
Data Analysis: Using Markers to measure
the acidity level of the different liquids
Page 24
Pullman Academic
Better Learning Outcomes
The FCC Wants You to Know:
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
a) Reorient or relocate the receiving antenna.
b) Increase the separation between the equipment and receiver.
c) Connect the equipment to an outlet on a circuit different from
that to which the receiver is connected.
d) Consult the dealer or an experienced radio/TV technician.
FCC Warning
Modifications not expressly approved by the manufacturer could void the user
authority to operate the equipment under FCC Rules.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT.
SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE
EQUIPMENT.
INSTRUCTIONS CONCERNING HUMAN EXPOSURE TO RADIO FREQUENCY
ELECTROMAGNETIC FIELDS
A distance of at least 20cm. between the equipment and all persons should be
maintained during the operation of the equipment.
Page 25
Pullman Academic
Better Learning Outcomes
Copyright ©2011 Globisens. All rights reserved. Globisens Ltd. logos and
product names are registered trademarks of Globisens Ltd. No part of this
document may be reproduced by any means, nor translated to any
electronic medium without the written consent of Globisens. Information
contained in this document is believed to be accurate and reliable,
however, Globisens assumes no responsibility for its use. Specifications
are subject to change without notice. www.GLOBISENS.com
Made for
iPad (3rd generation)
iPad 2
iPad
iPad is a trademark of Apple Inc., registered in the U.S. and other countries.
“Made for iPad” means that an electronic accessory has been designed to connect specifically
to iPod, iPhone, or iPad, respectively, and has been certified by the developer to meet Apple
performance standards. Apple is not responsible for the operation of this device or its
compliance with safety and regulatory standards. Please note that the use of this accessory
with iPod, iPhone, or iPad may affect wireless performance.
REV: 09.06.13
Page 26
Loading...
