Parts Catalog
SP62P
MIXERS
MODELS: SP62P & SPC62P
2-12-15
IMPORTANT!
TO EXPEDITE SHIPMENT OF PARTS, ALWAYS SPECIFY MODEL, REV,
PART NUMBER, AND SERIAL NUMBER OF MIXER.
GLOBE FOOD EQUIPMENT COMPANY
2215 East River Road
Dayton, Ohio 45439
Parts Department
Toll Free 1-800-745-6238 · Fax (937) 290-0585
E-Mail: info@globefoodequip.com
Website: www.globefoodequip.com
Not for resale
© Globe Food Equipment Company, 2015
TABLE OF CONTENTS
Page
Mixer Base Components 1 - 2
Head and Hub Assembly 3 - 4
Power Lift Cradle Assembly 5 - 6
Gearbox 7 - 8
Gear Shift Assembly 9
Power Lift Control Assembly 10
Planatary Motor Components 11
Motor Brake Components - Spc Models Only 12
Planetary Components 13 - 14
Electrical Schematic, 220V Mixer - 1 Phase 15
Wiring Diagram, 208/220V - 1 Phase 16
Wiring Diagram, 230/400V Power Lift Mixer - 3 Phase 17
Electrical Schematic 230/400V Power Lift Mixer - 3 Phase 18
Wiring Diagram, 230/400V Power Lift Mixer - Spc Model - 3 Phase 19
Wiring Diagram, Power Lift - Digital Control Panel, 1 Phase 20
Wiring Diagram, Power Lift - Digital Control Panel, 3 Phase 21
18
29
31
28
30
9
8
7
6
5
14
2
3
1
24
4
16
37
36
13
12
11
10
33
34
12A
11A
15
17
18
19
20
21
22
23
35
32
27
17
18
25
26
SP62P MIXER BASE COMPONENTS
1
SP62P MIXER BASE PARTS LIST
Item Description Part Number Qty Hardware
1 Screw, Flat Head X80A01 2 M8 x 85mm
2 Cover, Transmission Case
3 Gasket X62A03 1
4 Strain Relief X80A04 1
5 Screw, Truss Head X80A05 6 M5x12mm
6 Plate, Rear Column X80A06 1
7 Mixer Column - 1
8 Thumbscrew X80A08 4 M5x12mm
9 Cover, Column Front X80A09 1
10 Dowel Pin X80A10 2 Ø10x34mm
11 Mixer Base
11A Rubber Feet Set (Front/Rear) X80A11-1 1
12 Washer, Split Lock X80A12 4 M14
12A Washer, Flat - 4 M14
13 Screw, Hex Head X80A13 4 M14x50mm
14 Screw, Flat Head X80A14 1 M8x85mm
15 Dowel Pin X80A15 2 Ø10x33mm
16 Dowel Pin, Threaded X80A16 1
17 Plate, Microswitch Mounting X80A17 2
18 Screw, Truss Head X80A18 6 M5x12mm
19 Housing, Microswitch X80A19 1
20 Screw, Hex Head & Flat Washer X80A20 2 M4x45mm
Microswitch, Raise/Lower X80A21
21
Microswitch, R/L - Spc Models X80A21-1
22 Screw, Hex Head & Flat Washer X80A22 5 M12x25mm
Slide, Front Bowl (Cast Iron) X62A23 1
23
Slide, Left, Front Bowl (Metal Sheet) **X62A23-1 1
24 Dowel Pin, Threaded X80A24 1
Microswitch X62A35
25
Microswitch, Spc Models X62A35-1
26 Housing, Microswitch X80A36 1
27 Screw, Pan Head & Flat Washer X80A37 2 M4x25mm
28 Plate, Microswitch Mounting X80A40 1
Microswitch X62A38
29
Microswitch, Spc Models X62A38-1
30 Housing, Microswitch X80A41 1
31 Screw, Pan Head & Flat Washer - 2 M5x25mm
32 Washer, Shipping (Square) X80A31 4 M12
33 Washer, Split Lock - 4 M12
34 Bolt, Shipping - Grade 10.9 X80A32 4 M12x100mm
35 Plug, Plastic - 5 36 Label, Hazardous Voltage X91014 1
37 Label, Caution - 3 Phase X91011 1
* Use after S/N 7710068 (1 Phase) or S/N 7750061 (3 Phase).
** Use after S/N 7810150.
X62A02
*X62A02-DG
X62A11
*X62A11-DG
1
1
1
1
1
2
45
59
58
46
47
7
8
2
1
3
5
4
6
9
10
12
60
48
61
65
62
66
63
64
40
30
28
44
29
31
*41
42
37
*39
*38
33
11
27
34
*35
36
18
19
14
13A
17
16
22
23
*24
*25
15
21
54
57
55
50
56
53
51
52
49
32
*43
20
*26A
*26
SP62P HEAD AND HUB ASSEMBLY COMPONENTS
3
SP62P HEAD AND HUB ASSEMBLY PARTS LIST
Item Description Part Number Qty Hardware
1 Screw,Hex Head X80B01 1 M10x15mm
2 Washer, Split Lock X80B02 1 M10
3 Washer, Flat X80B03 1 M10
4 Screw, Hex Head X80B04 2 M12x40mm
5 Washer, Split Lock X80B05 2 M12
6 Washer, Flat X80B06 2 M12
7 Gauge, Oil Level X80B07 1
Transmission Case, Fixed Bowl Guard X80B08
8
Transmission Case, Removable Bowl Guard X80B08-1
9 Washer, Flat X80B09 6 M12
10 Washer, Split Lock X80B10 6 M12
11 Screw, Hex Head X80B11 6 M12x60mm
12 Oil Seal X80B12 1 TC50x80x10
13 Oil Pump Assembly (Items 13A-26) X80B13-27 1
13A Plate, Oil Pump - Bottom X80B13 1
14 Gear, Oil Pump, Right (15T) X80B14 1
15 Gear, Oil Pump, Left (15T) X80B15 1
16 Gear Set Pump X80B16 1
Housing & Tube Assy
17
Pump Shaft Bushing
18 Washer, Split Lock X80B26 4 M5
19 Screw, Socket Head X80B27 2 M5x15mm
20 Screw, Socket Head - 2 M5x25mm
21 Roll Pin X80B22 1 Ø2x10mm
22 Shaft, Oil Pump X80B21 1
23 Roll Pin X80B20 1 Ø2x18mm
*24 Conveying Gear Bushing (Ref) - 1 *25 Conveying Gear Assembly (29T) X80B23 1
26 Washer, Split Lock - M12
*26A Jam Nut - 1 M12
27 Cover, Transmission Case X80B25 1
28 Gasket, Transmission Cover X80B40 1
29 Dowel Pin, Threaded X80B39 2
30 Washer, Split Lock X30198 11 M8
31 Screw, Hex Head X30197 9 M8x24mm
32 Screw, Socket Head X30099 2 M8x28mm
33 Top Cover X80B33 1
34 Gasket, Transmission Shaft Bearing Retainer X80B28 1
*35 Bearing Retainer, Transmission Shaft X80B29 1
36 Screw, Hex Head X80B30 3 M5x15mm
37 Washer, Flat X80B31 1 M20
*38 Oil Fill Plug (Screw, Hex Head) X80B32 1 M20x40mm
Hose Assembly
*39
Hose Clamp
40 Gasket, Drive Shaft Bearing Retainer X80B36 1
*41 Bearing Retainer, Drive Shaft X80B35 1
42 Screw, Truss Head X80B34 3 M4x14mm
*43 Oil Fill Fitting X00704 1
44 Oil Tube & Gasket Assembly X80B42-43 1
45 Gasket, Lube Overow Cylinder X80B43 1
46 Lube Overow Cylinder X80B42 1
47 Screw, Flat Head X80B41 5 M6x15mm
48 Dowel Pin X80B56 2 Ø10x20mm
49 Level Drive Gear (16T) X80B44 1
50 Thrust Washer X30018-1 A/R
51 Sleeve, Square Drive X80B46 2
52 Oil Seal X10089 1
53 Gasket, Attachment Hub X80B48 1
54 Hub, Attachment
55 Screw, Socket Head X80B52 3 M6X25mm
56 Thumb Screw X10005 1 1/2-13x3/4"
57 Hole Plug, Attachment X80B51 1
58 Cover Plate, Transmission X80B53 1
59 Screw, Hex Head X80B54 4 M5x10mm
60 Dowel Pin X80B55 1
61 Screw, Socket Head X80E09 4 M8x25mm
62 Label, Globe Logo 871-3 1
63 Label, Arrow X91012 1
64 Label, Stop To Change Gears X91010 1
65 Label, Warning X91015 1
66 Label, Warning, French (Canada Only) X91007-F 1
*Part conguration may vary. **Use after S/N 7710068 (1 Phase) or S/N 7750061 (3 Phase).
X80B17-19 1Pump Outlet Bronze Pipe
X00703 1Hose Fitting
X80B50
**X80B50-DG
4
1
1
SP62P POWER LIFT CRADLE ASSEMBLY COMPONENTS
2
3
2B
2A
6A
9
8A
8B
6
7A
7
1
10B
10
10A
4A
4
5B
5A
5H
5B
5E
5F
5J
5D
5
5G
5C
15
15A
15B
15C
14
16
8B
1B
1A
2C
2C
1C
1D
9A
9B
9C
5H
5E
5F
5J
5D
5G
11
13B
13
13A
12
8
5
SP62P POWER LIFT CRADLE ASSEMBLY PARTS LIST
Item Description Part Number Qty Hardware
1 Bowl Cradle X62C12 1
1A Set Screw, Socket Head - Cup Point - 1 M12x80mm
1B Nut, Hex - 1 M12
1C Set Screw, Socket Head - Cup Point - 1 M6x40mm
1D Nut, Hex - 1 M6
2 Bowl Locating Screw X80C13 2
2A Washer, Split Lock X80C11 2 M12
2B Nut, Acorn X80C10 2 M12
2C Screw Cover - 4
3 Dowel Pin, Threaded X80C14 2
4 Screw, Bowl Clamp - Rear X80C09 2
4A Bushing, Bronze - Rear Clamp X80C07 2
5 Bowl Clamp Assembly X80C05 2
5A Screw, Bowl Clamp - Front - 2
5B Bowl Clamp X80C05-1 2
5C Bushing, Bronze - Front - 2
5D Hardware Cap - 4
5E Spring - 4
5F Washer, Flat - 4 M12
5G Washer, Split Lock - 4 M12
5H Nut, Jam - 4 M12
5J Hardware Cap - 4 -
6 Front Cover, Bowl Cradle X80C17 1
6A Screw, Hex Head X80C18 4 M5x10mm
7 Locking Bracket X80C16 1
7A Screw, Socket Head & Lock Washer X80C15 2 M8x35mm
8 Bowl Raise Screw Assembly X80C19-24 1
8A Bowl Raise Screw - 1
8B Shaft Key - 2 6x6x25mm
9 Nut Block - 1
9A Roller Ball - 1 Ø5 SS
9B Spring - 1
9C Set Screw, Socket Head - Cup Point - 1 M6x5mm
10 Nut Mounting Plate - 1
10A Washer, Split Lock - 1 M10
10B Screw, Socket Head - 1 M10x20mm
11 Ball Bearing X80C25 1
12 Retaining Ring X80C26 1 R40
13 Chain Gear (16T) X80H48 1
13A Washer, Split Lock X80H49 1 M16
13B Nut, Hex X80C30 1 M16
Motor, 1/8Hp 220V 50/60Hz 1Ph Prior To S/N 7750055 X00705
Motor, 1/8Hp 220V 50/60Hz 3Ph Prior To S/N 7750043 X80H56
Motor, Metal Plate, 220/380V/60Hz/1Ph Starting
14
S/N 7710055 XA-8038-1
Motor, Metal Plate, 220/380V/60Hz/3Ph Starting
S/N 7750043 XA-8038-3
15 Chain Gear (11T) X80H53 1
15A Washer, Flat X80H52 1 M6
15B Washer, Split Lock X80H51 1 M6
15C Screw, Hex Head X80H50 1 M6x16mm
16 Drive Chain X80H54 1
1
6
SP62P GEARBOX COMPONENTS
5
23
22
11
10
21
18
9
8
16
15
14
13A
12
13
38
31
30
29
20
17
4
2
1
27
26
25
24
7
5
37
28
11A
11B
32
32A
33
34
35
36A
36
36B
6
3
19
7
SP62P GEARBOX PARTS LIST
Item Description Part Number Qty Hardware
1 Nut, Hex Jam X80D34 1 M16
2 Washer, Split Lock X80D35 1 M16
3 Washer, Flat - 1 M16
4 Retaining Ring X80D36 1 RTW-47
5 Ball Bearing X80D37 4
6 Bronze Bushing, Upper X80D38 1
7 Bronze Bushing, Lower X62D38-1 1
Worm Gear (29T) (50Hz Mixer) *X80D39G03
8
Worm Gear (28T) (60Hz Mixer) **X00678
9 Bronze Bushing X80D40 1
10 Transmission Gear (25T) X80D41 1
11 Transmission Shaft (17T) X80D42 1
11A Shaft Key X80D43 1 6x6x18mm
11B Shaft Key X80D44 1 8x8x20mm
12 Ball Bearing X80D17 1
Shaft, Master Gear (17T) X62D67
13
Shaft, Master Gear (20T) ***X80D67-1
13A Shaft Key X62D60 1 8X8X20mm
14 Gear, Master Shaft(35T) X62D61 1
15 Bronze Bushing X62D68 1
16 Bronze Bushing (Rear) X80D27 1
17 Gear, Master Shaft (41T) X80D26 1
18 Retaining Ring X80D22 1 STW-35
19 Clutch Sleeve X80D21 1
20 Bronze Bushing X80D30 1
21 Gear, Master Shaft (49T) X80D31 1
22 Spacer X80D32 1 29x40x3mm
23 Ball Bearing X80D17 1
24 Nut, Hex Jam X80D16 1 M32
25 Washer, Flat X80D15 1 M32
26 Retaining Ring X80D14 1 RTW-72
27 Ball Bearing X30125 1
28 Bronze Bushing X62D58 1
Gear, Drive Shaft (53T) X62D69
29
Gear, Drive Shaft (52T) ***X80D69-1
30 Spacer X62D54 1
31 Oil Bushing X62D53 1
32 Gear, Drive Shaft (33T) X62D52 1
32A Screw, Socket Head - Mod X62D56 4 M8x30mm
33 Gear, Drive Shaft (41T) X62D51 1
34 Oil Bushing Sleeve X62D50 1
35 Anti-Oil Bushing X62D02-2 1
36 Drive Shaft X62D48 1
36A Shaft Key X62D49 1 10x10x45mm
36B Shaft Key X80D01 1 10x10x100mm
37 Ball Bearing X80D46 2
38 Retaining Ring X80D47 1 R-75
* Included with Worm Drive (Page 11). Worm Gear and Worm Drive must be replaced at same time.
** Included with Worm Drive (Page 11). Worm Gear and Worm Drive must be replaced at same time.
Use after S/N 7710999 (1 Phase) or 7750987 (3 Phase).
*** Use after S/N 7710999 (1 Phase) or 7750987 (3 Phase).
1Worm Gear (29T) (60Hz Mixer) *X80D39G03-1
1
1
8
SP62P GEAR SHIFT ASSEMBLY COMPONENTS
21
23
26
25
20
24
22
18
16
9
8
12
11
17
4
3
5
7
6
2
19
15
14
10
2A
5A
13
1
2
2
1
1
23
Item Description Part Number Qty Hardware
1 Gear Shift Assembly X80E01-15 1
2
Gear Shift Arm Assy (With Knob) X80E01 1
2A
Knob, Gear Shift X80E01-1 1
3
Gear Shift Arm Hub X80E02 1
4
Roll Pin X80E03 1 Ø6x38mm
5
1-2 Speed Indication Plate X62E25 1
5A
10A
10B
Screw, Round Head - SS - 4 M5x10mm
9
6
Oil Seal X80E05 1
7
O-Ring X80E06 1 P11
8
Shifter Guide Rod X80E07 1
9
Hub & Cam Assy X80E08 1
10
Screw, Socket Head X80E09 4 M8x25mm
Washer, Split Lock X08102 4 M8
Washer, Flat X08076 4 M8
11
Shaft Cover X80E10 1
12
Gear Shift Cam Assy X80E11 1
13
Roll Pin X80E12 1 Ø5x26mm
14
Steel Ball X80E13 2 Ø9mm
15
Spring X80E14 2
16
Roll Pin X80E15 1 Ø6x20mm
17 Microswitch X80E16 1
18 Microswitch Cover X80E17 1
19 Screw, Pan Head & Flat Washer X80E18 2 M4x24mm
20 Nut, Speed Shifter X80E19 4 M20
21 Spring X80E20 4
22 Speed Shifter Yoke (Top) X80E22 1
23 Touch Shaft X80E21 2
24 Speed Shifter Yoke (Rear) X80E23 1
25 Touch Shaft X80E21 2
26 Shifter Guide Rod X80E24 1
SP62P POWER LIFT CONTROL ASSEMBLY PARTS LIST
38
39
26
25
24
23
15
19
18
16
17
31
32
33
13
14
28
29/30
27
22
21
20
36
37
8
2
9
6
35
34
11
STOP
START
MAN
TIMER
TIM ER
MIN UTES
SECONDS
BOW L
12
4
5
7
1
3
10
6
Item Description Part Number Qty Hardware
1 Gasket X80J01 1
2 Control Panel X80J02 1
3 Control Panel, Digital - Upgrade Kit X80J02-1
4 Control Panel, Digital **XB754-1
5 Circuit Board **X00679 1
6 Wiring - 1
7 Screw, Circuit Board Mounting - 5 M3 x 10mm
8 Stop Button X80J03 1
9 Start Button X80J04 1
10 Timer Assembly With Knob X10137 1
11 Timer Knob X101037-1
12 Screw, Truss Head X30204 8 M4x10mm
13 Support Tube X80J07 4
14 Connecting Block X80J08 1
15 Connector X80J09 1
16 Connector X80J10 1
17 Terminal Block X80J11 1
18 Support Tube X80J12 1
19 Socket X80J13 4
20 Washer, Flat X80J14 4 M6
21 Washer, Split Lock X80J15 4 M6
22 Screw, Hex Head X80J16 4 M6x20mm
23 Contactor, 24V X80J17 1
24 Support Tube X80J18 1
Transformer, 24V (220V Mixer) X80J19 1
25
Transformer, 24V (380V Mixer) *9070T50D19
26 Electronics Mtg Plate X80J20 1
27 Contactor Mounting Plate - 1
28 Contactor Locking Caps - 2
29 Screw, Round Head - 2 M3x16mm
30 Washer, Flat - 2 M3
31 Overload Relay X80J21 1
Fuse, 250V 500Ma X80J22A 2
32
Fuse, 250V 1A X80J22B 1
33 Fuse Fixture X80J23 3
34 Connector X80J24 1
35 Connector X80J25 1
36 Bowl Raise Button X80J26 1
37 Bowl Lower Button X80J26 1
38 Bowl Raise/Lower Contactors, 24V X00680 1
39 Bowl Lift Motor Overload Relay X80J30 1
*380V Square D transformer. **Begin with S/N 7710061.
Capacitor, Start 500Mf (Not Shown) X30070-1P 1
40
Capacitor, Run 70Mf (Not Shown) X60070-2 1
10
SP62P PLANETARY MOTOR COMPONENTS
2
3
4
5
13
18
22
6
23
7
8
9
11
10
15
14
16
17
19
20
21
24
12
Item Description Part Number Qty Hardware
Motor Assembly, 3HP, 1PH, 220V, 60Hz X00560
Motor Assembly, W/Brake, 3HP, 1PH, 220V, 60Hz X00561
Motor Assembly, 3HP 3PH 220V X62G24
1
Motor Assembly W/Brake, 3HP 3PH 220V X62G24C
Motor Assembly, 3HP 3PH 380V X6261-23
Motor Assembly W/Brake, 3HP 3PH 380V X6261-23C
2 Nut, Bearing X80G01 1 M25
3 Washer, External Tooth X80G02 1 M25
Worm Drive, 50Hz *X80D39G03
4
Worm Drive (3T), 60Hz **X00678
5 Bronze Bushing (Spacer) X80G04 1
6 O-Ring X80G05 1 P73x3
7 Motor Front Cover - 1
8 Washer, Split Lock X80G07 3 M6
9 Screw, Hex Head X80G06 3 M6x30mm
10 Washer, Split Lock - 3 M12
11 Screw, Hex Head - 3 M12x40mm
12 Washer, Flat (Special) - 1 M25
13 Ball Bearing X40125 1
14 Shaft Key 1 6x6x45mm
15 Motor Shaft - 1 -
16 Motor Coil, 3 Hp - 1 -
17 Motor Body - 1 -
18 Ball Bearing X10012 1
19 Rear Cover, Motor - 1 -
20 Washer, Split Lock X80G07 3 M6
21 Screw, Hex Head X80G06 3 M6x20mm
22 Fan X62G19 1
23 Fan Cover - 1
24 Screw, Pan Head - 3 M5x12mm
* Included with Worm Gear (Page 8). Worm Drive and Worm Gear must be replaced at the same time.
** Included with Worm Gear (Page 8). Worm Drive and Worm Gear must be replaced at the same time.
Use after S/N 7710999 (1 Phase) or 7750987 (3 Phase).
11
1
1Worm Drive, 60Hz *X80D39G03-1
SPC62P MOTOR BRAKE COMPONENTS
11
10
12
2
1
3
6
4
5
7
8
9
ITEM DESCRIPTION PART NUMBER QTY HARDWARE
*1 Motor Shaft - 1
2 Shaft Key - 1 5x5x20mm
3 Motor Cover, Extended X80G18-1 1
4 Washer, Split Lock - 3 1/4"
5 Screw, Hex Head - 3 1/4-20 x 1-1/8"
6 Motor Brake, Magnetic X80G27 1
7 Washer, Split Lock - 4 M6
8 Screw, Hex Head - 4 M6x14mm
9 Fan Cover, Extended X80G20-1 1
10 Electronic Board, 220V/380V X80J11-1 1
11 Screw, Round Head - 2 M3x34mm
12 Auxiliary Contact Block - 1
*INCLUDED WITH SPC MODEL MOTOR ASSEMBLY X62G24C & X62G1-23C (PAGE 11).
12
SP62P PLANETARY COMPONENTS
25
25A
25B
11
17
11A
9
12
15
14
13
11B
10
7
6
5
2
4
16
3
1
1A
SAFETY SPRING LOCK
SEE ENLARGED VIEW
22
22A
27
28
21
20
23
18
18A
19
29
24
24A
29A
26A
26
21
SAFETY GUARD SPRING LOCK
ENLARGED VIEW
8
13
SP62P PLANETARY PARTS LIST
ITEM DESCRIPTION PART NUMBER QTY HARDWARE
1 Planetary Gear (59T) X80F01 1
1A Screw, Socket Head X80F03 6 M8x35mm
2 Nut, Jam X80F02 1 M16
3 Washer, Split Lock X80F04 1 M16
4 Washer, Flat X80F05 1 M16
5 Pinion Gear (18T) X80F06 1
6 Ball Bearing X80F07 1
7 Planetary Holder
8 Set Screw, Socket Head - Cup Point X80F08 1 M12x10mm
9 Oil Bushing X62F18 1
10 Ball Bearing X62F10 2
11 Planetary Shaft X62F13 1
11A Planetary Shaft Pin X80F14 1 M14x38mm
11B Shaft Key X80F12 1 6x6x35mm
12 Washer, Flat X80F20 2 M10
13 Washer, Split Lock X80F21 2 M10
14 Screw, Hex Head - SS X80F22 2 M10x20mm
15 Washer, Flat - D Shape X80F23-1 1 M10
16 Washer, Split Lock X80F24-1 1 M10
17 Screw, Hex Head X80F25-1 1 M10x25mm
18 Rear Guard, Fixed X62J32-33 1
18A Screw, Hex Head - SS X80F16 6 M5x12mm
19 Access Plug X80J34 2
20 Tube Wireway X80J31A1 1
21 Connector X80J31 2
Microswitch, Safety Interlock X80J35-1
22
Microswitch, Safety Interlock - Spc Models X80J35-2
22A Screw, Socket Head X80J36 2 M3x16mm
23 Slide Sheath X80J43-1 1
24 Safety Guard Spring Lock Fixture X80J42 1
24A Screw, Hex Head - SS X80J41 2 M4x12mm
25 Safety Guard Spring Lock X80J39 1
25A Washer, Flat - 2 M3
25B Screw, Round Head - SS X80J40 2 M3x8mm
26 Touch Mass (New Style) X80J43-1 1
26A Screw, Flat Head X10042 2 M4x10mm
27 Gasket X80J44 1
28 Planetary Internal Gear X80J45 1
29 Front Interlocking Guard Assy X62J48 1
29A Screw, Hex Head - SS X80J47 8 M5x12mm
*Use after S/N 7710068 (1 Phase) or S/N 7750061 (3 Phase).
X62F09
*X62F09-DG
1
1
14
SP62P ELECTRICAL SCHEMATIC, 220V MIXER - 1 PHASE
5
S1
S3
S4
3
1
2
4
K1
K2
K1
S2
7
6
13
14
96
95
S5
A2
A1
X1
K1
M1
1~
1
1
3
3
5
5
F1
M1 3HP
F2
PE
L2
L1
95
96
97
98
Item Description Qty
S1 Emergency Stop Button 1
S2 Start Button 1
S3 Microswitch, Interlock Guards 1
S4 Microswitch Speed 1
S5 Bowl Jog Button 1
K1 Contactor Coil 220V, 60Hz 1
K2 Timer 1
F1 Overload Relays 1
F2 Spark Killer (Single Phase) 1
M1 Motor: 3Hp, Single Phase, 208V 1
15
SP62P WIRING DIAGRAM, 220V MIXER - 1 PHASE
L1
L2
R
W
GR
R R
R R
R R
R R
R R
R R
R R
R R
1 2 3 4 5 6 7 71
1 2 3 4 5 6 7 71
INTERLOCK
MICROSWITCH
SPEED
MICROSWITCH
L1 L2 T1 T2 T3
L1 L2 T1 T2 T3
T1 T2 T3
M
3HP MOTOR
BL B B
B B B
L1
L2
A1
1
3
5
13
2
4
6
14
A2
T1T2T3
CONTACTOR
C-18D
11A-15A
T1
T2
600FMD
OFF SWITCH
1
1
2
2
4
3
3 4
1
2
7
NC
NCNO
NO
3 4 X1
X2
BOWL JOG
ON SWITCH & LAMP
TIMER
5
6
7
OVERLOAD
RELAY
B
B
B
WIRE COLOR:
W: WHITE
B: BLACK
GR: GREEN
R: RED
BL: BLUE
16
SP62P WIRING DIAGRAM, POWER LIFT MIXER - 230/400V, 3 PHASE
L1 L2 L3
24 VOLT TRANSFORMER
G 0V 220V 380V 0V 24V
12 11 14
15 10 11 7
6 7
9 9 10 2
5 3 16 14
V1 U1 W1
V2 U2 W2
E STOP
CYCLE
TIMER
START
UP
DOWN
.1 .2
2 3
.3 .4
X2 X1
.3
.3
.4
.4
A2 A1
L1 L2 L3
U1 V1 W1
U2 V2 W2
T1 T2 T3 NO
L1 L2 L3 NO
1 3 5 13
2 4 6 14
95 N.C. 96 97 N.O. 98
2 T1 4 T2 6 T3
95 N.C. 96 97 N.O. 98
L1 L3 1
R1 T1 2
FUSE 500mA
FUSE 1A
T1
2 4 6 22 A2
T1 T2 T3 NC
L1 L2 L3 NC
1 3 5 21 A1
L1 L2 L3 12 17
T1 T2 T3 NC
L1 L2 L3 NC
1 3 5 21 A1
L1 L2 L3 16 13 L1 L2 L3 6
10 15
2 4 6 22 A2
U V W 17 15 13 15 7
2 T1 4 T2 6 T3
4 5 3 4
6 7
15 10
6 5
14 511 5
BOWL LIFT
POWER SUPPLY
POWER SUPPLY
POWER SUPPLY
3 PHASE
(3HP) MOTOR
MOTOR
MOTOR
(1/8HP) MOTOR
MOTOR
MOTOR
GEAR
POSITION
SAFETY
LOCK
7
9
10 9
LIMIT
UPPER
11 12
LOWER
LIMIT
16
14
9
12 11 14 15 10 11 7 6 7 9 9 10 2 5 3 16 14
FUSE 500mA
CONNECT WIRE
TO APPROPRIATE
TRANSFORMER TAP
FOR 220V OR 380V
MIXER POWER RATING
1 15 R1
17
SP62P ELECTRICAL SCHEMATIC, POWER LIFT MIXER - 230/400V, 3 PH
F1 Fuse 250V/500Ma (5X20) KM1 Contactor
F2 Fuse 250V/500Ma (5X20) KM2 Contactor, Raise
F3 Fuse 250V/1A (5X20) KM3 Contactor, Lower
S1 Emergency Stop Button SQ1 Microswitch (Transmission Gear)
S2 Start Button SQ2 Microswitch (Interlock Guard)
S3 Start Button SQ3 Microswitch (Bowl Lift Safety)
S4 Start Button SQ4 Microswitch (Bowl Lift Upper Limit)
FR1 Overload Relay SQ5 Microswitch (Bowl Lift Lower Limit)
FR2 Overload Relay M1 Mixer Motor
M2 Power Lift Motor
18
SPC62P WIRING DIAGRAM, POWER LIFT MIXER - 230/400V, 3 PHASE
INTERLOCK
MICROSWITCH
M
3~
MICROSWITCH
HEIGHT ADJUSTMENT
3 HP
9 10
1
OFF SWITCH
ON SWITCH
& LAMP
TIMER
NC
L3 L2 L1
NO 13 21 A1
LC1D09
B7
CONTACTOR
50/60Hz
24V
NC NO 14 22 A2
T3 T2 T1
NC
L3
L2
L1
NO 13 21 A1
LC1D09
B7
CONTACTOR
50/60Hz
24V
NC NO 14 22 A2
T3
T2 T1
NC
L3 L2 L1
NO 13 21 A1
LC1D18
B7
CONTACTOR
50/60Hz
24V
NC
NO
14
22
A2
T3 T2 T1
24V
0V
1
380V
220V
15 (R1)
0V
G
T1
1
L3
L1
FUSE
2
T
R
GROUND
TRANSFORMER
NC
NC
POWER SUPPLY
GROUND
L
L
L
AUXILIARY
CONTACT BLOCK
POWER
BOWL LIFT
MOTOR
1/8 HP
GROUND
11 12
MICROSWITCH
HEIGHT ADJUSTMENT
COM NC
UP
COM
NO
MICROSWITCH
HEIGHT ADJUSTMENT
DOWN
NC COM
14 16
16 14 12 11 15 10 9 7 6 2 5 3
16 14 12 11 15 10 9 7 6 2 5 3
9
9
9 7
M
T1
T3
T2
OVERLOAD RELAY
0.63A~1A (BELOW 220V)
0.4A~0.63A (OVER 380V)
97 NO 98 NO 95 NC 96 NC
T1
T3
T2
OVERLOAD RELAY
12A~18A (BELOW 220V)
7A~10A (OVER 380V)
97 NO 98 NO 95 NC 96 NC
TRANSMISSION GEAR
MICROSWITCH
24V
0V
220V
110V
0V
FLANGE TYPE
ELECTROMAGNETIC
BRAKE
CONTROL CIRCUIT BOARD,
ELECTROMAGNETIC BRAKE
ON SWITCH
& LAMP
NC
2
NO
3
X1
NO
4
X2
A
9P CONNECTOR, MALE
3
NO
4
3
4
A
9P CONNECTOR, FEMALE
5 2 3
6 7 10
15 11 14
5
2
3
6
7 10
15 11 14
TRANSFORMER WIRING MAY
VARY IN COMPLIANCE WITH
MIXER POWER RATING
(220V OR 380V)
19
SP62P WIRING DIAGRAM, PWR LIFT MIXER - DIGITAL CONTROLS, 1PH
OVERLOAD RELAY SETTING:
LIFTING MOTOR BELOW 220V: SET AT 1.9A
PLANETARY MOTOR: BELOW 220V: SET AT 18A
INTERLOCK
MICROSWITCH
M
1~
MICROSWITCH
HEIGHT ADJUSTMENT
3 HP
LC1D18
B7
CONTACTOR
50/60Hz
24V
FUSE
MICROSWITCH
HEIGHT ADJUSTMENT
MICROSWITCH
HEIGHT ADJUSTMENT
DOWN
7
TRANSMISSION
GEAR
MICROSWITCH
PRINTED
CIRCUIT BOARD
GROUND
POWER SUPPLY
GROUND
L
TRANSFORMER
L
70uF
500MFD
CAPACITORS
LC1D09
B7
CONTACTOR
50/60Hz
24V
LC1D09
B7
CONTACTOR
50/60Hz
24V
9
9
9
16A~24A1.5A~2.5A
LC1D256
M7
CONTACTOR
50/60Hz
220V
1/8 HP
GROUND
UP
M
L1 L3 1
R T 2
BRN
GRN
VIO
BLU
YEL
ORG
RED
20
SP62P WIRING DIAGRAM, PWR LIFT MIXER - DIGITAL CONTROLS, 3 PH
INTERLOCK
MICROSWITCH
M
3~
MICROSWITCH
HEIGHT ADJUSTMENT
3 HP
9 10
NC
L3L2L1
NO13 21 A1
LC1D09
B7
CONTACTOR
50/60Hz
24V
NCNO14 22 A2
T3T2T1
NC
L3
L2
L1
NO13 21 A1
LC1D09
B7
CONTACTOR
50/60Hz
24V
NCNO14 22 A2
T3
T2T1
NC
L3L2L1
NO13 21 A1
LC1D18
B7
CONTACTOR
50/60Hz
24V
NC
NO1422
A2
T3T2T1
24V
0V
1
380V
220V
15 (R1)
0V
G
T1
1
L3
L1
FUSE
2
T
R
GROUND
TRANSFORMER
POWER SUPPLY
GROUND
LLL
POWER
BOWL LIFT
MOTOR
1/8 HP
GROUND
11 12
MICROSWITCH
HEIGHT ADJUSTMENT
COM NC
UP
COM
NO
MICROSWITCH
HEIGHT ADJUSTMENT
DOWN
NC COM
1416
16 14 12 11 15 10 9 7 6 25 3
16 14 12 11 15 10 9 7 6 25 3
9
9
97
M
T1
T3
T2
OVERLOAD RELAY
0.63A~1A (BELOW 220V)
0.4A~0.63A (OVER 380V)
97 NO 98 NO 95 NC 96 NC
T1
T3
T2
OVERLOAD RELAY
12A~18A (BELOW 220V)
7A~10A (OVER 380V)
97 NO 98 NO 95 NC 96 NC
TRANSMISSION
GEAR
MICROSWITCH
TRANSFORMER WIRING
MAY VARY IN COMPLIANCE
WITH MIXER POWER RATING
(220V OR 380V)
PRINTED
CIRCUIT BOARD
BRN
VIO
BLU
YEL
ORG
RED
GRN
21
995026 GFE-SP62P/SPC62P REV E ECN 1862 12Feb2015
Loading...
