Parts Catalog
PF32E
ELECTRIC FRYERS
MODELS:
PF10E, PF16E & PF32E
08-25-201 1
IMPORT ANT!
TO EXPEDITE SHIPMENT OF PARTS, ALW AYS SPECIFY MODEL, REV,
P ART NUMBER, AND SERIAL NUMBER OF SLICER.
GLOBE FOOD EQUIPMENT COMPANY
2215 East River Road
Dayton, Ohio 45439
Parts Department
T oll Free 1-800-745-6238 · Fax (937) 290-0585
E-Mail: globeinfo@globeslicers.com
W ebsite: www.globeslicers.com
Not for resale
TABLE OF CONTENTS
PAGE
PF10E FRYER 1
PF16E FRYER 2
PF32E FRYER 3 - 4
WIRING DIAGRAM 5
PF10E COMPONENTS
1
14
7
21
8
9
10
11
2
4
3
13
5
17
6
12
15
16
18
20
19
Item Part No. QtyItem Description Part No. Qty
1 Control Box Assembly
2 Thermal Cut Out U03051220004 1 14 Element Cover U01051025555 1
3 Thermostat Knob U02101155013 1 15 Heating Element U03061225044 1
4 Thermostat U03051220008 1 16 Tube Bend Clamp U01051025128 2
5 Control Enclosure - 1 U01121063013
6 Tube Clamp U01051025402 2 *U06051471080
7 Element Hook U06051470011 1 18 Fryer Cabinet - 1
8 Cord & Plug (120V) U03021205012 1 19 Foot U01021005002 4
9 Back Cover Plate - 1 BASKET10
10 On/Off Switch U03041215027 1 *SMBASKET10
11 Indicator Light (120V) U03091240005 1 21 Cover -Optional extra FRYCOVER10 1
*Used after serial number PF10E0001497-1645.
Description
U06051470590 12 Control Assy Support Brkt - 2
*U06051471098 13 Stuffing Nut U01021005017 2
1
17 Pan 2
20 Basket 2
1
8
y
PF16E COMPONENTS
1
21
14
7
9
10
11
2
4
3
13
5
17
6
12
15
16
18
20
19
Item Part No. QtyItem Description Part No. Qt
Control Box Assembly11
2 Thermal Cut Out U03051220004 1 15 Heating Element U03061225047 1
3 Thermostat Knob U02101155013 1 16 Tube Bend Clamp U01051025128 2
4 Thermostat U03051220008 1 U01121063016
5 Control Enclosure - 1 *U06051471081
6 Tube Clamp U01051025117 2 18 Fryer Cabinet - 1
7 Element Hook U06051470010 1 19 Foot U01021005002 4
8 Cord & Plug (240V) U03021205013 1 BASKETTWIN1632
9 Back Cover Plate - 1 *TMBASKET1632
10 On/Off Switch U03041215027 1 BASKETLARGE1632
11 Indicator Light (240V) U03091240006 1 *LG BASKET1632
12 Control Assy Support Brkt - 2 21 Cover -Optional extra FRYCOVER16 1
*Used after serial number PF16E0001112-1360.
Description
U06051470593 13 Stuffing Nut U01021005017 2
*U06051471101 14 Element Cover U01051025555 1
17
Pan
20 Basket Assembly
1
2
1
2
PF32E COMPONENTS
17
20
21
7
6
3
14
15
2
9
8
1
16
5
4
11
10
12
13
18
19
8
3
PF32E P ARTS LIST
y
Item Description Part No. Qt
U06051470592
1
Control Box Assembly, Right 1
2 Thermal Cut Out U03051220004 2
3 Thermostat Knob U02101155013 2
4 Thermostat U03051220008 2
5 Control Enclosure - 2
6 Tube Clamp U01051025117 4
7 Element Hook U06051470010 2
8 Cord & Plug (240V) U03021205013 2
9 Back Cover Plate - 2
10 On/Off Switch U03041215027 2
11 Indicator Light (240V) U03091240006 2
12 Control Assy Support Bracket - 4
13 Stuffing Nut U01021005017 4
14 Element Cover U01051025555 2
15 Heating Element U03061225047 2
16 Tube Bend Clamp U01051025128 4
Pan
18 Fryer Cabinet - 1
19 Foot U01021005002 4
20 Basket
21 Cover -Optional extra FRYCOVER1032 2
*Used after serial number PF16E0001362-1495.
*U06051471100
U06051470593
*U06051471101
U01121063016
*U06051471081
BASKETLARGE1632
LGBASKET1632
1Control Box Assembly, Left
217
2
4
WIRING DIAGRAM, PF10E/PF16E/PF32E FRYERS
/ /1 (
9
0$,1
6:,7&+
7+(50$/
&877,1*'(9,&(
7+(50267$7
,1',&$725
/$03
+($7,1*
(/(0(17
5
995045 GFE PF10E/PF16E/PF32E Rev B ECN 1565 25Aug201 1
