True RMS Digital Multimeter with 4 1/2
digit (LED) display.
Basic DC Voltage accuracy of 0.05 %
Basic AC Voltage accuracy of 0.75 %
Overload protection on all ranges
AC/DC Voltage measurement up to
1000V DC and 750V AC
AC/DC Current measurement up to 10A
Resistance measurement up to 20MΩ
Frequency Measurement up to 200kHz
Audible continuity test
Diode Test Voltage, 2V
110-120VAC @ 50 Hz/ 210-220VAC @ 50
Hz Input Voltage
Weighs only 4.4lbs (approx. 2.0kg)
Comes complete with User’s Manual, 1
Set Test Leads, Power cord & Spare Fuse
The Model PRO-1000A is a highly
versatile, economically-priced, portable,
bench type digital multimeter with a 4 ½
digit LED display that can measure
diodes, frequency, current, voltage,
resistance, as well as test continuity & all
for a very Low List Price of ONLY
$345.00
Designed to meet CAT II (600V) safety
standards, Engineers, Technicians,
Electricians, Educators,
Manufacturing, Quality Control can use
the PRO-1000 in confidence with its
rugged design, housed in high impact
case with convent multiple-position
handle and non-contact AC voltage
(NCV) detection feature. The PRO-1000,
fused & fully overload protected, and can
be used with either 115V AC, or 230V
AC (50-60 Hz) input voltages
Pro-1000
Features:
Innovative Training Solutions
www.globalspecialties.com
Test Equipment
Bench Digital Multimeter
Engineers, Technicians,
Electricians, Educators,
Manufacturing,
Quality Control can all
use the PRO-1000 in
confidence with its
exceptional quality,
rugged design & housed
in high impact case
with convent multipleposition handle.
=
Test Equipment
Bench Digital Multimeter
Specifications
*Important Note: All accuracies apply to 5% to 95% full scale of each range.
DC VOLTS
Range
Resolution
Accuracy
Impedance
2V
100uV
20V
1mV
±(0.05% + 10d)
10M
200V
10mV
1000V
100mV
±(0.1% + 5d)
AC VOLTS
Range
Resolution
Accuracy
Impedance
50-60Hz
60-400Hz
2V
100 V
±(1.5% + 10d)
20V
1mV
±(0.75% + 10d)
10M
200V
10mV
±(2.5% + 10d)
750V
100mV
DC CURRENT
Range
Resolution
Accuracy
Overload Protection
2mA
100nA
20mA
1 A
±(1.0% + 5d)
200mA
10 A
2A/250V
2A
100 A
±(1.0% + 10d)
*10A
1mA
±(1.0% + 10d)
10A/250V
*10A range specified for 30 seconds maximum for each 15 minute interval.
AC CURRENT
Range
Resolution
Accuracy
Overload
Protection
50-60Hz
60-400Hz
2mA
100nA
20mA
1 A
±(0.75% + 10d)
200mA
10 A
±(2.0% + 10d)
2A/250V
2A
100 A
±(1.0% + 10d)
*10A
1mA
10A/250V
*10A range specified for 30 seconds maximum for each 15 minute interval.
Innovative Training Solutions
www.globalspecialties.com
Specifications
RESISTANCE
Range
Resolution
Accuracy
Overload Protection
2k
0.1
20k
1
±(0.2% + 5d)
200
10
600V DC or Peak
2M
100
20M
1k
±(1% + 10d)
FREQUENCY
Range
Resolution
Accuracy
Overload Protection
20kHz
1 Hz
±(1.5% + 5d)
600V DC or Peak
200kHz
10 Hz
±(2.0% + 5d)
Frequencies under 500Hz requires a minimum amplitude of at least 4Vpp. Other
sensitivities are not specified.
Errors of less than 5 digits are added in the total measurement.
AUDIBLE CONTINUITY
Test Voltage
Threshold
Overload Protection
3V
Less Than 200
600V DC or Peak
DIODE TEST
Test Voltage
Max. Test Current
Overload Protection
2V
Approx. 1.0mA
600V DC or Peak
Equipment Ratings
Plug and Socket: 3 wire AC power plug and 3 wire outlet
Power & Fuse Ratings
Input Voltage
Fuse
Power Max
103 ~ 126V AC (50/60Hz)
F 0.5A / 250V
10W
206 ~ 252V AC (50/60Hz)
F 0.2A / 250V
Innovative Training Solutions
www.globalspecialties.com
Test Equipment
Bench Digital Multimeter
Specifications
Operating Environment:
Temperature: 0 °C to + 40°C (Accuracy Specified at 23 °C ±5 °C)
Humidity: Up to 85%RH to 40°C without temperature extremes which may cause
condensation within the instrument.
Storage Environment:
Temperature: -20°C to 70°C
Humidity: <85%RH
Temperature Coefficient: 1.0x (Specified Accuracy) per °C for temp. < 18°C or > 28°C
Insulation Category: II
Pollution Degree: 2
Protection to IEC 529: Ordinary
Dimensions: 9.5” x 3.5” x 11” (240 x 90 x 280 mm)
Weight: 4.4 lbs (approx. 2.0kg)
Supplied Accessories
User’s Manual----------------------------------------1
Test Leads --------------------------------------------1
Power Cord ------------------------------------------1
Spare Fuse --------------------------------------------1
Innovative Training Solutions
www.globalspecialties.com
Test Equipment
Bench Digital Multimeter
