80W (16V/5A) Power Supply
with USB Output
User
Manual
1325
V A
OUTPUT
ON/OFF
USB
CHARGER
GND
OUTPUT 5 A MAX.
C.V.
Volt. Am p.
C.C.
Model: 1325- 110 V Power Supply
INPUT: 110 VAC, 60 Hz ~, 1.6 A
OUTPUT: 1-16 VDC, 0.5A
USB: 5 VDC, 1.2 A
1325
1
Safety Summary
The following safety precautions apply to both operating and
maintenance personnel and must be observed during all
phases of operation, service, and repair of this instrument.
Before applying power, follow the installation instructions
and become familiar with the operating instructions for this
instrument.
GROUND THE INSTRUMENT
To minimize shock hazard, the instrument chassis and cabinet
must be connected to an electrical ground. This instrument
is grounded through the ground conductor of the supplied,
three-conductor ac power cable. The power cable must be
plugged into an approved three-conductor electrical outlet. Do
not alter the ground connection. Without the protective ground
connection, all accessible conductive parts (including control
knobs) can render an electric shock. The power cable meets
IEC safety standards.
DO NOT OPERATE IN AN EXPLOSIVE ATMOSPHERE
Do not operate the instrument in the presence of ammable
gases or fumes. Operation of any electrical instrument in such
an environment constitutes a denite safety hazard.
KEEP AWAY FROM LIVE CIRCUITS
Instrument covers must not be removed by operating
personnel. Component replacement and internal adjustments
must be made by qualied maintenance personnel. Disconnect
the power cord before removing the instrument covers and
replacing components. Under certain conditions, even with
the power cable removed, dangerous voltages may exist. To
avoid injuries, always disconnect power and discharge circuits
before touching them.
2
DO NOT SUBSTITUTE PARTS OR MODIFY THE INSTRUMENT
Do not install substitute parts or perform any unauthorized
modications to this instrument. Return the instrument to
Global Specialties (Cal Test Electronics) for service and repair
to ensure that safety features are maintained.
WARNINGS AND CAUTIONS
WARNING and CAUTION statements, such as the following
examples, denote a hazard and appear throughout this
manual. Follow all instructions contained in these statements.
A
WARNING statement calls attention to an operating
procedure, practice, or condition, which, if not followed
correctly, could result in injury or death to personnel.
A
CAUTION statement calls attention to an operating
procedure, practice, or condition, which, if not followed
correctly, could result in damage to or destruction of parts or
the entire product.
WARNING
Do not alter the ground connection. Without the protective
ground connection, all accessible conductive parts (including
control knobs) can render an electric shock. The power
jack and mating plug of the power cable meet IEC safety
standards.
WARNING
To avoid electrical shock hazard, disconnect power cord before
removing covers. Refer servicing to qualied personnel.
CAUTION
Before connecting the line cord to the AC mains, check the
rear panel AC line voltage indicator. Applying a line voltage
other than the indicated voltage can destroy the AC line fuses.
For continued re protection, replace fuses only with those of
3
the specied voltage and current ratings.
CAUTION
This product uses components which can be damaged by
electro-static discharge (ESD). To avoid
damage, be sure to follow proper procedures
for handling, storing and transporting parts
and sub-assemblies which contain ESDsensitive components.
Compliance Statements
Disposal of Old Electrical & Electronic
Equipment (Applicable in the European Union and other
European countries with separate collection systems). This
product is subject to Directive 2012/19/EU of the European
Parliament and the Council of the European Union on
waste electrical and electronic equipment (WEEE), and in
jurisdictions adopting that Directive, is marked as being put on
the market after August 13, 2005, and should not be disposed
of as unsorted municipal waste. Please utilize your local
WEEE collection facilities in the disposition of this product and
otherwise observe all applicable requirements.
