Product Manual
NO. : JG16-1589
REV ： R1.0
DATE：2016-8-1
SECTION Ⅰ/Ⅱ
Security rating：□Top secret□ Confidential □Secret□ Ordinary
Lithium-ion Rechargeable Battery
Product Manual
Product Name： LiFePO4 Battery Pack
Product Specification： 9.6V1.5Ah
Designed
Checked
Approved
Lei Chen
Peng Ren
Shijie Ren
Product Manual
NO. : JG16-1589
REV ： R1.0
DATE：2016-8-1
SECTION Ⅰ/Ⅱ
Security rating：□Top secret□ Confidential □Secret□ Ordinary
1. Preface
This manual describes the type and size, performance, technical characteristics, warning and caution.
2. Product and Model
2.1 Product: Lithium-ion Battery Pack
2.2 Model: 3IFR9.6-1.5-N （18650-3.2V-3S1P）
2.3 Picture And Output Wire （In order to prevail in kind）
B3
24AWG
Length:200±10mm
JST-XH-5P
B2
24AWG
Length:200±10mm
B1
24AWG
Length:200±10mm
B+
24AWG
Length:200±10mm
B-
24AWG
Length:200±10mm
Product Manual
NO. : JG16-1589
REV ： R1.0
DATE：2016-8-1
SECTION Ⅰ/Ⅱ
Security rating：□Top secret□ Confidential □Secret□ Ordinary
3. Battery Pack Specifications
Items
Parameters
Nominal voltage
9.6V
Typical capacity
1.5±0.1Ah( At 0.2C discharge rate)
Discharge
Normal current
≤ 0.5A
Max continuous
current
≤ 1A (≤ 5min)
Cut-off voltage
About 7.5V
Charge
Voltage
10.8±0.1V
Current
≤ 0.5A
Charge mode
CC/CV，please use special lithium charger
Inner resistance
Discharging Inner
resistance
≤ 200mΩ
Operation
temperature/
humidity range
Charge
0℃～+45℃
Discharge
-20℃～+60℃
When the environment temperature is higher than
45℃，please pay attention to ventilation and heat
rejection.
Humidity
RH≤ 85%, When the environment humidity is
higher than 85%，please pay attention to protect
Operation
temperature/
humidity range
Temperature
0℃～40℃（Capacity 80%）Recommended
long-term storage temperature is 15~25℃
Humidity
RH≤ 50%，Easily oxidized components note sealed
Shell material
PVC
Weight
135±10g
Size（L*W*H）
（19±1）mm *（69±1）mm *（55±1）mm
Cycle
Standard charge at 0.2C（A）, rest 0.5~1 h，discharge at 0.2C to cut off
voltage，rest 0.5~1h,repeat the above steps until 1500 cycles.( capacity
retention rate≥ 80%)
Product Manual
NO. : JG16-1589
REV ： R1.0
DATE：2016-8-1
SECTION Ⅰ/Ⅱ
Security rating：□Top secret□ Confidential □Secret□ Ordinary
4.Characteristic curve
0.0 0.5 1.0 1.5
7.5
8.0
8.5
9.0
9.5
10.0
10.5
11.0
Discharge
Charge
HT9.6V1.5Ah Charge-Discharge Curve 0.2C,250C
Capacity(Ah)
Voltage(V)
5. Product Liability
It is not responsible for the incident caused by not obeying the Manual. Before using the battery, you should
read the specifications( The manual is divided into two parts), usage instruction and some attentions carefully to
learn its application method and areas. If the phenomenon such as error using method or wrong circuit
connection, or input power data, working index are inconsistent with the Manual , cause damage to product,
load and its accessories, we are not responsible for it.
Our company have the right to change the content of specification without prior notice；
The final explanation of specification belongs to our company.
