EnergyPad

Wireless Charger

User Manual

Model: Moon-Fabric

For safety and proper use, please read this User Manual before using the

4.Safety Instructions

Wireless Charger

For more information, please visit:

www.teslawirelessdevice.com

1.Product Overview

5. Troubleshooting

Quick Charger

Indicator light

Wireless Charger
USB port

Wireless Charger
emission area

Product Parameter

Name：Wireless Charger

Model：B85UX

Size：74.6*146.4*6.5mm

Input：5V 2A/9V 1.67A

Output：5V 1A, 9V 1.1A

Frequency：120KHz ~ 140KHz

Induction Distance：0mm ~ 3mm

Cable Length：≈1m

Net Weight：≈75g

Scope of Application：Support wireless charging for mobiles

which has Qi certified wireless charging function, eg. Iphone,

Samsung, LG, Moto, etc.

Product List：Wireless ChargerX1，Quick ChargerX1，

User ManualX1

Certification：

*The above parameters are based on the testing result of Shenzhen Tesla
Wireless Device Co., Ltd., the actual data may have difference due to the
mobile or other factors.

6.Transportation, Storage, and Recycle

2.Wireless Charger User Guide

1. Plug USB port into the Quick Charger, and plug the Quick
Charger into stable power socket, then place the receiving area of
mobile (which support wireless charging) onto the emission area
of Wireless Charger properly (normally the receiving area is in the
middle of the mobile).

2. Remove the mobile from the Wireless Charger when it is fully
charged.

7.Warranty

3. Indicator Light

1. Indicator light will be on for about 4 seconds for
self-testing after the Wireless Charger connect with power
supply.

2. Indicator light flashes every 3 seconds at standby mode.

3. Indicator light is always on at charging mode.

4. If indicator light flashes every second when charging,
it’s because the output power is too low. We suggest you
to change the Quick Charger.

5. If indicator light flashes very fast or lights off, please
check if you placed the Wireless Charger and the mobile
properly and please make sure there is no metal placed
between the Charger and the mobile.

Warranty card

Warranty card

The mobile may heat up,if it is running APP with high power

consumption, or running APP for a long time, while charging wirelessly.
It is normal situation, will not influence the life or performance of the
mobile and the Wireless Charger.

1. Do not use the mobile with metal accessories for wireless charging.
And make sure there is no metal between Wireless Charger and mobile.

2. The applicable environment temperature range is from 0℃ to 35℃.
Using the Wireless Charger out of the suggested temperature range, may
damage the product.

3. Use the 18W QC3.0 Quick Charger in our Product List or those quick
chargers applied to international safety standards (5.2V/2A or 9V/1.67A).
Do not use quick chargers not matched with the standards.

4. Avoid children and pets chewing, swallowing or playing the Wireless
Charger.

5. Do not disassemble, modify or repair the Wireless Charger by yourself.

6. Do not place the magnetic stripe card (e.g. credit card, phone card,
bank passbook and record card) near the Wireless Charger while
charging, to avoid the magnetic field generated by the Wireless Charger
damaging the magnetic stripe card.

7. Do not use the Wireless Charger if it’s punctured or corroded. Do not
stuff any object into the slot of the Charger. Do not place weights on it or
squeeze it hardly. Do not pull the cable of the Wireless Charger.

8. Please use the Wireless Charger under stable power condition.

Please refer to below terms and conditions to solve the charging problem if
any. Contact your distributor or appointed serviceman if the problem still
exists.

1. The Wireless Charger can not work
1）Check if the USB port of the Wireless Charger is ok;
2）Check if the Quick Charger is ok. You may test with other quick charger
which applied to international safety standards 5V/2A,9V/1.67A.

3) Check if the mobile is covered with metal shell.

2. The charging is interrupted or the mobile cannot be fully charged.
1）Check if you’re using the 18W QC3.0 Quick Charger from the Product
List, or other quick chargers which applied to international safety
standards 5V/2A,9V/1.67A.
2）Check if the receiving area of the mobile is aligned with the Wireless
Charger’s emission area.

1. Keep the Wireless Charger in clean, dry and ventilated environment
during transportation. Avoid fierce vibrate, strike or extrusion. Avoid the
Wireless Charger to be exposed to the sun and rain. The Wireless Charger
can be transported by truck, train, ship, or plane.

2. The environmental temperature of storage should be from -20°C~50°C, the
ambient humidity should be less than or equal to 90%. Please avoid
touching with corrosive material. Keep away from the fire.

3. The Wireless Charger cannot be thrown away as household garbage. To
protect the environment, abandoned product should be taken to the
electronic product collection points for recycling.

Hazardous substance test result:

Part Name

PCBA
Plastic
Metal
Ferrite

O：Content of the hazardous substances in all homogenous
materials of the part is below the prescribed limits in accordance
with GB/T26572 standard.
X：Content of the hazardous substances in a certain homoge­neous material of the part is exceeding the prescribed limits in
accordance with GB/T26572 standard.

Name and Content of Hazardous Substance

Pb Hg Cd Cr6+ PBB PBDE

O O O O O O
O O O O O O
O O O O O O
O O O O O O

Shenzhen Tesla Wireless Device Company Limited
(hereinafter referred to "Company") warrants this product
(see Exclusions below) to the original purchaser against
defective material and workmanship that occurs during
normal use for one year. Company will, at Company's
option, either repair or replace same without charge (but no
cash refunds will be made).

1. Damage resulting from accident, misuse, abuse, lack of
reasonable care, subjecting the product to any but the
specified electrical service, other than normal and ordinary
use of the product, subjecting the product to abnormal
working conditions or any other failure not resulting from
defects in materials or workmanship.

2. Damage resulting from modification, tampering with or
attempted repair by anyone other than the Company or
designated repair representative by the Company.

3. Transfer of product to someone other than the original
consumer purchaser.

4. The warranty is not valid for components subject to wear
and/or to counterfeits.

* This Warranty clause is owned and intenerated by Shenzhen Tesla Wireless

Device Company Limited

Name：

Name：

Address：

Address：

Tel：

Tel：

Email：

Email：

Purchase Date：

Purchase Date：

Distributor Name：

Distributor Name：

Product Problems

Product Problems:

FCC ID: 2ALHA-MOON

Changes or modifications not expressly ap proved by t he party r esponsib le f or compliance
could void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.

This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:

-- Reorient or relocate the receiving antenna.

-- Increase the separation between t he equipment and receiver.

-- Connect the equipment into an out let on a circuit dif ferent fro m that t o which the rece iver
is connected.

-- Consult the dealer or an experienced radio/T V t echnician for help.

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance
of 20cm between the radiator & your body. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmit t er.
