Globalsat Technology BTH-820 User Manual

BTH-820 Bluetooth Stereo Headset BTA-809 Bluetooth Stereo Audio Gateway
BTH-820 Bluetooth Stereo Headset provides you the CD quality stereo sound. If a call is coming while you are listening to the music, just press any button to receive the call. Meanwhile, the music will stop automatically, and then resume itself after you hang up the phone.
BTA-809 Bluetooth Stereo Audio Gateway enables your audio dev ice to have the ability of wireless Bluetooth transmission. It can transmit crystal clear digital sound to any compatible Bluetooth audio receiver up to 10 meters away. Just plug the BTA-809 into the iPod Docking co nnector, the audio music will be sent out from BTA-809 by the wireless Bluetooth signal. Then you can use a Bluetooth headset (receiver) to listen to the music.
Features

BTH-820 BTA-809

Light weight and handy design. Press any button to receive a call. In the headset mode, you can adjust the volume

and refuse to answer a call.
You can answer the call while listening to the
music, and the music will resume automatically after you hang up the phone.

built-in Hold key and microphone. Stand-by time up to 110 hours.

A2DP+AVRCP Profile A2DP Profile You can control the “play”,

“pause”, “stop”, “next song” and “previous song” of the Windows Media Player.
Known Supported Device:
Globalsat: BTA-806/BTA-804A

Bluetooth version 1.1/1.2/2.0 compatible. Operation range up to 10 meters.

You can control
the play/mute, volume up and down of BTH-820.

Stereo Audio Gateway Plug-and-Play Support standard A2DP profile for

consistent and clear stereo sound quality.
Compatible with iPod Photo, Video,
nano.
Divert the high quality audio from
wired to wireless.
Outstanding performance enables
you to enjoy the true digital sound with CD stereo quality.

Support A VRCP. Fast and simple one-button

operation.

Stand-by time up to 80 hours.

Embedded rechargeable Li-polymer battery LED indicator for low power and charging.

1
Specification
Model Name BTH-820 BTA-809
Product Description Bluetooth Stereo Headset Bluetooth stereo Audio Gateway
Color Blue / Orange White
Certification FCC, CE, BQB FCC, CE ,BQB ,DGT ,IC
Bluetooth Version Bluetooth v1.2 Specification Bluetooth v2.0 Specification
RF Output Power Class 2
Frequency Band 2.4GHz ~ 2.4835GHz unlicensed ISM band
Spread Spectrum FHSS (Frequency Hopping S pread Spectrum)
Operating Range 10 meters (32 feet)
Sensitivity -80dBm @0.1%BER
Bluetooth Profile Headset,Handsfree,A2DP,AVRCP A2DP,AVRCP
Stereo Audio Specification CD-Quality, 44.1, 48KHz 16-bit Stereo Audio Codec
Standby Time Up to 110 hours Up to 80 hours
Play Time Up to 6 hours Up to 7 hours
Charging Time Up to 3 hours Up to 3 hours
Talking Time Up to 6 hours --
Audio input Bluetooth signal IPOD Docking connect
Audio Output 3.5 mm stereo jack Bluetooth signal
LED 2 LEDs (blue and red)
Battery Rechargeable Li-Polymer battery
Operation Temperature
Storage Temperature
Humidity 10% ~ 90% non-condensing
Dimensions 63.5x28.5x18.5mm(L x W x T),
Weight
Microphone
-10 ~ 55
-20 ~ 60
Including back clip
19 g 21.5g
Embedded microphone,
(To avoid the noise interference,
please put the microphone within
35 cm from your mouth while
talking.)
61.8x24.5x15mm(L x W x T)
--
2
BTH-820
Button
Incoming call is ringing
Answer Transfer to cell phone Play / Pause Play / Pause Refuse the call Hang up Stop disconnect
While on the phone While playing the
Answer Volume up Volume up Volume up
Answer Volume down Volume down Volume down
Answer N/A Next Next
Answer N/A Previous Previous
Lock the buttons Lock the buttons Lock the buttons Lock the buttons
Remark 1 -- To avoid the noise
interference, please
music with BTA-806 (A VRCP, A2DP profile).
Remote control (AVRCP) is
While playing the music with BTA-809 (A VRCP, A2DP profile).
Support A VRCP remote control
Remark 2
Status
Standby Blue LED flash once Connecting Blue LED flash twice Transferring Blue LED flash four times
put the microphone within 30 cm from your mouth while talking.
If BTH-820 works with Bluetooth USB dongle which uses
,
1.6.2 or above
AVRCP, HEADSET profiles.
TOSHIBA version 3 03.10 or above
supported under “Microsoft Window Media Player”.
.
, it will support A2DP,
If BTH-820 works with Bluetooth USB dongle which uses
WIDCOMM version 4 0.1.700 or above
.
, it will support A2DP, AVRCP profiles.
LED indicator function
BTH-820, BTA-809
feature.
IVT BlueSoleil version
BROADCOM,
Pairing Blue and red LED flash quickly by turns Low battery
Red LED is on
3
Turn on
Turn off
Pairing
Charging
BTH-820, BTA-809
Press the power button for 2 seconds to turn it on. Press the power button for 4 seconds to turn it off.
While in the off mode, press the power button for 6 se condsthe blue an d red LED will flash quickly by turns and it will search other device for pairing.
Connect one end of the charging line to the USB socket of BTH-820 or BTA-809, and the other end to the USB socket of PC. The red LED will be on when charging and will be off when battery is full. You can use BTA-809 while it is in the charging mode.
Pairing procedure
To pair
Pairing password
BTH-820 with
BTA-809
Press the power button for 6 seconds, the blue and red LED will flash alternately and they will search each other for pairing. If pairing is completed, blue LED will flash four times in every 2 seconds.
-- -- 0000 0000
BTA-809 with
another Bluetooth
headset
Set the BTA-809 and your Bluetooth headset to pairing mode, these two devices will start to pair automatically. If pairing is completed, blue LED will flash four times in every 2 seconds.
BTH-820 with a Bluetooth
cell phone
Set the BTH-820 into pairing mode. In your cell phone, enter the Bluetooth menu and select “search device” option. When your cell phone finds the BTH-820, select it to pair. If pairing is completed, red LED will be off, and only blue LED will flash, then you can connect your cell phone to BTH-820.
BTH-820 with a PC
Set the BTH-820 into pairing mode. Start the Bluetooth software (for example IVT BlueSoleil 1.6.2 or Windcomm) on your PC and select “search device”. After pairing is completed, you will be able to connect BTH-820 and listen to all the music from PC.
Note:
Supports AVRCP profile, you can use BTH-820 to control iPod. The functions which can be
controlled are the following: iPod mode Function available note Music Play / Pause, Volume
up, Volume down, Next, Previous.
Photos Play / Pause, Next,
Previous.
Videos Play / Pause, Volume
up, Volume down.
Before you can use BTH-820 to control the iPod, you must select any music playlist and press the play button on your iPod. If you press the play button on BTH-820 instead of iPod, then it will play the previous playlist. Before you can use BTH-820 to control the iPod, you must select “Photos” / “Photo Library” and press play button on your iPod. Before you can use BTH-820 to control the iPod, you must select “Videos”, any video file, and then press play button on your iPod.
4
Troubleshooting
Check the battery power. Make sure the devices are turned on. Make sure the devices have been paired. Make sure the devices are within the 10 meters range. Check the volume. Check if the audio resource is correctly input. Pair the devices over again. Can not connect with cell phone: Delete the BTH-820 device in your cell phone, re-sta rt it and
do the pairing again.
Can not turn on the device: Do a Reset. Plug in the charging line to the device to enable the
electric power passing by and then unplug it. That will perform the “Reset”. For BTA-809, you need to press the Reset hole under the device.
Copyright
© 2005 Globalsat Technology Corporation. All rights reserved The trademarks mentioned in this document are legally registered to their respective companies.
FCC Notices
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation.
FCC RF Exposure requirements: This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS C OULD VOID THE USER'S AUTHORITY T O OPERATE THE EQUIPMENT.
