Key Features & Benefits
9Super Fast Charging In just 45 seconds this cordless driver is fully
charged from dead flat and ready to go
9 500,000 Charge Cycles Provides many years of service compared to
Ni-Cads which offer 500-100 cycle/charges
9High Torque With 4.5Nm of torque, this tool is ideal for a
wide range of applications in and around the
workshop and home
9No Memory Effect It will accept partial charges between full
charges with out detriment to the cell
9Charge Indicator Shows at a glance the charge and charging
condition of the cells
PFC46V – Cordless Driver
Page 3
¼” Bit Insert
Tip
Rubber Over-Moulded
Grips
Key Features
Forward / Reverse
Switch
6pce Bit Set
LED Charge
Indicators
Charging Base
PFC46V – Cordless Driver
Page 4
Key Feature Information
Worlds Fastest Charging. Ready to go in just 45 SECONDS!
Thanks to new technology utilizing capacitor cells rather than traditional rechargeable
batteries that allow for such incredible charging speeds without any detriment to the
cell.
So what is a capacitor? For starters, capacitors have
been around for decades and are found in almost
every electronic circuitry. Basically they store and
discharge electrical energy similar to a re-chargeable
battery, but different in how they do it. If you want to
learn more about capacitors, follow this link
http://electronics.howstuffworks.com/capacitor.htm
Because of how capacitors work, they can be
charged/discharged at any time and can even be left
on the charger permanently, though this is not normally
recommended since the tool is full charged from dead
flat in just 90 seconds
PFC46V – Cordless Driver
Page 5
Key Feature Information
Quick and Simple
The process of charging the screwdriver is a Quick and simple 3 step process.
1. Place the tool in the charger and switch it on
2. Wait 45 seconds (if dead flat). LED’s will
indicate when charge is complete
3. Remove the tool from the charger and your
ready to work
See this tool in action at
http://www.youtube.com/watch?v=V58OMVUSacE
PFC46V – Cordless Driver
Page 6
Typical Applications vs. Performance
4 x Cabinet Hinges
1 x Saucepan
Handle
2 x Bench Top Joins
Into Hardwood
These are typical applications in and around a domestic home. The tasks were carried out on a
single charge until flattened enough that it could not do the required operation.
A total of 23 tasks were performed.
6 x Light Switches
2 x Door Latches
Into hardwood
8 x Hinge Latch
Adjustments
PFC46V – Cordless Driver
Page 7
Specification Sheet
Technical Specifications Supplied Accessories
6 x mixed driver bits
Voltage 4.2 volts
Cell Type Capacitor
Recharges Approximately 500,000
No Load Speed 170rpm
Max Torque 4.5Nm
Charge Time 45 seconds
Driver Net Weight .36kgs
Accessories 6
Warranty 2 Year Repair or
Replacement for Domestic
Home Use only
PFC46V – Cordless Driver
Page 8
Frequently Asked Questions
Q: Are there any memory effect issues with this battery type?
A: No as the power cell is not actually a battery, but a capacitor which is an electronic
component that stores and discharged electrical energy
Q: How long will the tool last per charge?
A: This is like asking “how long is a piece of string?” This can’t be determined exactly as there are
to many variables such as charge capacity, material being screwed into and the screw itself. It will
not run for as long as traditional rechargeable battery types, but can be re-charged in a fraction
of the time
Q: Is there auto spindle lock with this model
A: Not at this time which means that when the cell is exhausted you should not try and use the tool
as a tradition screwdriver as this will damage the mechanism
Q: Does the cell need to be discharged fully before re-charging?
A: No it can be charged at anytime
Q: Can I leave the driver in the charger all the time?
A: Utilizing new LED charge indicators and auto cut off system means that you can leave the tool
on the charger when the mains is off and not experience any discharge of the cells
.
PFC46V – Cordless Driver
