Global are a company specialising in
temperature measurement solutions,
one being the manufacture of
miniature and standard
thermocouple connectors.
Our range of miniature and standard
connectors are uniquely shaped
allowing ease of use, manufactured
as a one pressed body giving
superior strength and quality, and
are available in most common
thermocouple combinations, using
thermocouple grade alloys for error
free connections.
Our connector range is available with
maximum temperature ratings of
220°C and 560°C. The 220°C
connectors are colour coded to
international colour standard
IEC584.3 :1989 (other colour
standards available upon request).
The 560°C ceramic connectors are
supplied in white and are marked
with identifying international colour
code.
Pins are polarised by size and are
marked for negative and positive
polarity. All connectors are
compatible with other miniature and
standard connectors. To order, please
use the part code shown against the
product and type.
A range of accessories and fascia
mounting systems are also available.
All miniature in-line connectors have
a 3mm cable entry, and all standard
in-line connectors have a 6mm cable
entry.
.
Miniature
connectors
Mini Plug - In line. Rated 220°C
PART NO. TYPE
04-3510-00 J
04-1510-00 K
04-6510-00 N
04-2510-00 T
04-8510-00 Copper
Ceramic Mini Plug - In line. Rated 560°C
PART NO. TYPE
04-3710-00 J
04-1710-00 K
04-6710-00 N
04-2710-00 T
04-8710-00 Copper
Mini Socket - In line. Rated 220°C
PART NO. TYPE
04-3560-00 J
04-1560-00 K
04-6560-00 N
04-2560-00 T
04-8560-00 Copper
Ceramic Mini Socket - In line. Rated 560°C
PART NO. TYPE
04-3760-00 J
04-1760-00 K
04-6760-00 N
04-2760-00 T
04-8760-00 Copper
Page 3
Mini Quickwire Socket - Rated 220°C
PART NO. TYPE
04-3560-04 J
04-1560-04 K
04-6560-04 N
04-2560-04 T
04-8560-04 Copper
Mini PCB Socket - Rated 220°C
PART NO. TYPE
04-3760-02 J
04-1760-02 K
04-6760-02 N
04-2760-02 T
04-8760-02 Copper
Cable Caddie - Mini plug with wire carrier
Other thermocouple calibrations
are available on request
PART NO. TYPE
??-????-?? ?
Standard
connectors
Standard Plug - In line. Rated 220°C
Using solid pin construction.
PART NO. TYPE
04-3010-00 J
04-1010-00 K
04-6010-00 N
04-2010-00 T
04-8010-00 Copper
Standard Socket - In line. Rated 220°C
PART NO. TYPE
04-3060-00 J
04-1060-00 K
04-6060-00 N
04-2060-00 T
04-8060-00 Copper
Standard Fascia - Rated 220°C
PART NO. TYPE
04-3060-01 J
04-1060-01 K
04-6060-01 N
04-2060-01 T
04-8060-01 Copper
Ceramic Standard Plug - In line. Rated 560°C
PART NO. TYPE
04-3310-00 J
04-1310-00 K
04-6310-00 N
04-2310-00 T
04-8310-00 Copper
Mini Fascia Socket - Rated 220°C
PART NO. TYPE
04-3560-01 J
04-1560-01 K
04-6560-01 N
04-2560-01 T
04-8560-01 Copper
Mini Socket Panel- With S/S Bracket. Rated 220°C
PART NO. TYPE
04-3560-06 J
04-1560-06 K
04-6560-06 N
04-2560-06 T
04-8560-06 Copper
Page 4
Accessories
for miniature connectors
Ceramic Standard Socket - In line. Rated 560°C
PART NO. TYPE
04-3360-00 J
04-1360-00 K
04-6360-00 N
04-2360-00 T
04-8360-00 Copper
Standard Socket - With S/S Bracket. Rated 220°C
PART NO. TYPE
04-3060-00 J
04-1060-00 K
04-6060-00 N
04-2060-00 T
04-8060-00 Copper
Cable Clamp - Miniature and Standard
PART NO. TYPE
??-????-?? Miniature
??-????-?? Standard
Neoprene Grommet - Miniature and Standard
PART NO. TYPE
??-????-?? Miniature
??-????-?? Standard
Panels - Miniature and Standard
PART NO. TYPE
??-????-?? Miniature
??-????-?? Standard
PART NO. SIZE
??-????-?? 0.5mm, 1.0mm or 1.5mm
??-????-?? 1.5mm, 3.0mm or 4.5mm
Other thermocouple calibrations
are available on request
Standard Crimp Inserts - Standard inserts can be drilled out to the following sizes
PART NO. WAYS SIZE
??-????-?? 2 Way L-40mm
??-????-?? 4 Way L-72mm
??-????-?? 6 Way L-104mm
??-????-?? 8 Way L-136mm
??-????-?? 10 Way L-168mm
??-????-?? 12 Way L-200mm
Standard and Mini Panels - Aluminium panel for use with fascia sockets
Mini Panel
PART NO. WAYS SIZE
??-????-?? 2 Way L-62mm
??-????-?? 4 Way L-112mm
??-????-?? 6 Way L-162mm
??-????-?? 8 Way L-212mm
??-????-?? 10 Way L-262mm
??-????-?? 12 Way L-312mm
Standard Panel
