KPC-HLN(D)D45
1/3 2.1Mega pixel SONY CMOS
HD-SDI DOME Camera
- High Resolution
”
- Support various digital video output
1080p 30fps / 1080p 25fps,
720p 60fps / 720p 50fps
- Video Output
HD-SDI
CVBS
-15 units LED & TDN (OPTION)
-S/N Ratio : More than 50dB
,
4/12
-Support OSD menu
- Input Voltage : Dual / DC12V
CONTENTS
PAGE
1. SPECIFICATIONS-------------------------------------------------------------- 5
2. ENVIRONMENT CONDITION AND TEST------------------------------- 6
3. OSD MENU STRUCTURE -------------------------------------------------- 7
4. FUNCTION SWITCH----------------------------------------------------------- 9
5. APPEARANCE------------------------------------------------------------------- 10
6. CONNECTION------------------------------------------------------------------- 11
7. PACKING SPECIFICATION ------------------------------------------------- 12
1. SPECIFICATIONS
1) Details
KPC-HLN(D)D45
5/12
KPC-HLN(D)D45
2) HD
SDI SIGNAL
Timing Jitter
< 1.0UI
Humidity
Less than 90%
N
-
Item Specification
SDI OUT LEVEL 800mV±10%
Rising Time < 270ps
Falling Time < 270ps
Aligment Jitter < 0.2UI
Overshoot Rising < Amplitude * 10%
OverShoot Falling < Amplitude * 10%
2. ENVIRONMENT CONDITION AND TEST
6/12
1) Operating Condition Temperature -10 ° C ~ 50 ° C
Humidity Less than 80%
2) Storage Condition Temperature -20 ° C ~ 60 ° C
3) High T emperature storage Test
Leaving the packed at Temperature of 60 ° C for 72 Hours, and after leaving it at
Normal Temperature for 8 Hours, there should be no Problem in Performance.
4) Low Temperature storage Test
Leaving the packed at Temperature of -20 ° C for 72 Hours, and after leaving it at
ormal Temperature for 8 Hours, there should be no Problem in Performance.
KPC-HLN(D)D45
INITIAL
C
0~20
CS00
S
SS
1
10
DNR
OFF, LOW, MIDDLE, HIGH
3. OSD MENU STRUCTURE
Main Menu Sub Menu Sub Menu
SETUP
EXPOSURE BRIGHTNESS 1~20
SHUTTER
MODE
SHUTTER SPEED
DSS OFF, X2, X3, X4, X5, X6, X7, X8
AGC MAX 0dB ~ 23dB
INITIAL
RETURN
WHITEBALANCE WB MODE AUTO, PUSH LOCK, MANUAL, AUTO EXT
CHROMA 0~20
KELVIN LOW, MIDDLE, HIGH
RED CONTROL 0~20
BLUE CONTROL 0~20
PUSH AUTO -
RETURN
WDR/BLC MODE OFF, WDR, BLC
WDR LEVEL 0~20
BLC ZONE OFF, ON
BLC XPOSITION
BLC YPOSITION
X-SIZE
BL
BLC Y-SIZE 0~20
INITIAL
RETURN
DAY&NIGHT D&N MODE AUTO, COLOR, BW
(IR-LED OPTION) DWELL TIME 1sec ~ 10 sec
DAY->NIGHT 0~15
NIGHT->DAY 0~15
IR OPTIMIZER OFF, ON
IR OPT.LEVEL 0~15
INITIAL
RETURN
DAY&NIGHT D&N MODE AUTO, COLOR, BW
(NO LED
OPTION)
DWELL TIME 1sec ~ 10 sec
AGC THRS 0~20
AGC MARGIN 0~20
INITIAL
RETURN
HARPNE
FLIP OFF, H-FLIP, V-FLIP, HV-FLIP
DZOOM 1X~20X
HLMASK OFF, ON HLMASK LEVEL 0~20
D-WDR ON, OFF
AUTO, MANUAL
1/30(25), 1/60(50), 1/120(100), 1/250, 1/700, 1/1K, 1/1.6K, 1/2.5K, 1/5K, 1/7K, 1/10K,
1/30K,
0~20
0~20
~
HLMASK
COLOR
INITIAL
RETURN
WHITE, YELLOW, CYAN, GREEN, MAGENTA, RED, BLUE,
BLACK
7/12
DEFOG ON, OFF DEFOG MODE AUTO, MANUAL
DEFOG LEVEL LOW, MIDDLE, HIGH
INITIAL
RETURN
INITIAL
RETURN
KPC-HLN(D)D45
MASK MODE
OFF, ON
OW US
OFF, O
OUS
O,O
RETURN
RETURN
SPECIAL CAM TITLE CAM TITLE
0 1 2 3 4 5 6 7 8 9 A B C D E F G H I J K
L M N O P Q R S T U V W X Y Z ! - () <>
SPA>> <<BAK
LOCATION
RETURN
LANGUAGE ENGLISH, RUSSIAN, SPANISH, GERMAN, FRENCH, PORTUGUESE, JAPANESE
PRIVACY OFF, ON ZONE NO 0~15
X-POSITION 0~60
Y-POSITION 0~40
X-SIZE 0~40
Y-SIZE 0~40
COLOR
TRANSPARENCY 100%, 75%, 50%, 25%, 0%
INITIAL
RETURN
BLACK, WHITE, YELLOW, CYAN, GREEN, MAGENTA,
RED, BLUE
8/12
MOTION DETECT OFF, ON RESOLUTION 0~4
SENSITIVITY 0~20
WIND
WINDOW TONE 1~4
X-POSITION 0~60
Y-POSITION 0~40
X-SIZE 0~40
Y-SIZE 0~40
INITIAL
RETURN
DISPLAY CAM TITLE OFF, ON
MOTION OFF, ON
DZOOM OFF, ON
INITIAL
SYSTEM DEFECT DET OFF, ON
DOUT FORMAT 720P, 1080P
DOUT FPS 50, 60 / 25, 30
FREQ 60Hz, 50Hz
CVBS NTSC, PAL
APPLY
E
N
INITIAL
RETURN
FACTORY
DEFAULT
EXIT
KPC-HLN(D)D45
4. FUNCTION SWITCH
9/12
KPC-HLN(D)D45
5. APPEARANCE
Unit(mm)
10/12
KPC-HLN(D)D45
6. CONNECTION
11/12
KPC-HLN(D)D45
7. PACKING SPECIFICATION
12/12
