GLG Creator DLX IP65 RGBWAUV User Manual

GLG Lighting products

GLG Creator DLX IP65 RGBWAUV

USER MANUAL

Please read this manual before using.

铝(6063 )

TEL：[phone]
FAX：[phone]

General Information

(1) Product statement

First of all thank you for purchasing our GLG lighting product Creator DLX IP65 18*12W 6 in 1

outdoor slim par light, for your safety and better use of this product, please read the user manual

carefully before using, and strictly in accordance with the procedures, so as to avoid personal

safety or damage caused by the misuse of lamps and lanterns.

(2) Product introduction

18*12W RGBAW+UV 6 in 1 led, excellent cooling, great brightness, lower power consumption,

special 42mm lens, flicker free & very soft linear dimmer 0-100%, extremely heavy heat sink, very

strong structure, which has very long life span. 14, 7,8,9,3 channel mode for your optional, auto

run, sound active, DMX 512 & master slave.

www.goedlichtengeluid.nl [e-mail] 1

GLG Lighting products

Safety Instructions

(1)

Safety instructions

CAUTION!

Be careful with your operations. With a dangerous voltage you can

Suffer a dangerous electric shock when touching the wires!

This device has left our premises in absolutely perfect condition. ln order to maintain this condition

and to ensure a safe operation, it is absolutely necessary for the user to follow the safety

instructions and warning notes written in this user manual.

Important:

Damages caused by the disregard of this user manual are not subject to

Warranty. The dealer will not accept liability for any resulting defects or problems.

lf the device has been exposed to drastic temperature fluctuation (e.g. after a delivery),do not

switch it on immediately. The arising condensation water might damage your device. Leave the

device switched off until it has reached room temperature.

This device is also designed for outdoor use. The fixture must be used in an area with good

ventilation. The fixture can not be used directly into water nor in an area where rain will drop

directly. Also GLG advise for long period use outdoor to protect the fixture with a water protecting

cover.

This device is allowed to be operated with an AC of 100-204V. This device falls under protection-

Class. The power plug must only be plugged into a protection-class l outlet. The Green or

Yellowish-Green conductor must be earthed! The fixture is equipped with special IP65 powercon

and XLR connectors. Connectors for cables are separately available at GLG Lighting.

Always connect the device to the mains least. Always disconnect from the mains, when the device

is not in use or before cleaning it. Never leave the device running unattended! Check the device

and the power cord from time to time. Make sure the power cord is not crimped or damaged by

sharp edges. Never let the power cord come into contact with other cables! Handle the power cord

and all connections with the mains with particular caution!

Do not shake the device. Avoid brute force when installing or operating. Operate the device only

after having familiarized with its functions. Keep away children and amateurs from the device! Do

not permit operation by person not qualified for operating the device. Most damages are the result

of unprofessional operation!

www.goedlichtengeluid.nl [e-mail] 2

GLG Lighting products

1.Product features:

* Mast slave.
* DMX 512
* Multi kinds of DMX mode.
* Auto run, master, DMX512, sound active, programming.
* Parameters download between lights.
* 16BIT Gray rate 16BIT
* Fan’s speed automatic adjustable.
* Temperature automatic protection.
* Strobe function.
* Lighting fixture’s running time.
* Positive and negative display.
* Backlight settings.
* Temperature display.
* Software version.
* Dimming liner settings.
* Dimming speed settings.
* Different white with various kinds of color temperature settings.
* Password protection settings.

1.1 DMX 512 controller settings.

1.1-1 DMX512 address choosing without ID address.

* Connect DMX512 controller with each fixture.

* Each fixture has 14 channels, therefore DMX address should gradually increase by value 14,

such as (1, 15，29，43...).

*（CH14=0） If ID address is not setting, the 14 channels cannot be active by the controller .

* Each DMX address can be used multiple times as required.

* Any DMX dress can be used from the range of 001-512.

1.1-1-1DMX location with ID address.

* Each DMX address can be set 66 separate ID address.

ID should be set to the value on each device menus, such as 1, 2, 3 …

* ID address can access via DMX512 console.

2.Operating instruction.

2.1 Key operation.

*MENU: Function key.

*ENTER: Enter key.

*UP: Plus key.

*DOWN: Minus key.

www.goedlichtengeluid.nl [e-mail] 3

GLG Lighting products

2.2 Menu

www.goedlichtengeluid.nl [e-mail] 4

GLG Lighting products

www.goedlichtengeluid.nl [e-mail] 5

GLG Lighting products

2.3 Static settings [STAT]

* Press 【ENTER】into stat setting at【STAT】 manu.

* Press 【ENTER】 key to choose 【Red】. 【Green】.【Blue】.【White】. 【Amber】. 【UV】

【

ZOOM】.

* Press 【UP】/ 【DOWN】 key to choose value.

* Press 【MENU】return back to the previous menu, the parameters that you choose can automatic

save.

Note: When entering the sub-menu to adjust, if no DMX, this fixture is automatically set to be master,

others are slave.

2.4 Auto run [AUTO]

* Choose [AUTO] and press enter is auto run function.

* Press [UP]/[DOWN] to choose auto run program and user self programing.

* Press 【MENU】return back to the previous menu, the parameters that you choose can automatic

save.

* The speed of auto run is adjustable, while user self programming should be set under [EDIT]

www.goedlichtengeluid.nl [e-mail] 6

GLG Lighting products

menu.

Note: When entering the sub-menu to adjust, if no DMX, this fixture is automatically set to be master,

others are slave.

2.5 Run mode [RUN]

* Choose [RUN] menu and press [ENTER] into [RUN] mode.

* Press [UP]/[DOWN] to choose running mode.

* Press 【MENU】return back to the previous menu, the parameters that you choose can automatic

save.

* DMX is international standard DMX 512 signal.

* SOUND mean sound function.

* SLAV is online signal .

Note: Under DMX and SLAV mode, no DMX signal connect with the master signal.

2.6 DMX 512 address settings [DMX]

* Choose [DMX] menu and press [ENTER] into address settings.

* Press [UP]/[DOWN] to increase or decrease address value.

* Press 【MENU】return back to the previous menu, the parameters that you choose can automatic

save.

2.7 DMX512 custom channel selection
[PERS].

* Choose [PERS] menu and press [ENTER] into DMX 512 custom channel selection.

* Press [UP]/[DOWN] to choose.

www.goedlichtengeluid.nl [e-mail] 7

GLG Lighting products

[STAG] [ARC.1] [AR1.d] [ARC.2] [AR2.d] [AR2.S] [HSV]

For the exact channel value, pls check the DMX channel value sheet for reference.

* Press 【MENU】return back to the previous menu, the parameters that you choose can automatic

save.

2.8 ID address settings [ID].

* Choose [ID] menu and press [ENTER] enter into ID address settings.

* Press [UP]/[DOWN] to choose [01-66] value.

*【MENU】return back to the previous menu, the parameters that you choose can automatic save.

2.9 ID scene editor [EDIT]

* Choose [EDIT] and press [ENTER] enter into scene editor, total is 10 block, each block has 30

scenes, each scene has 10 parameters.

Press [UP]/[DOWN] to choose block and scene, and press [ENTER] enter into the scene, and press

[ENTER] to choose 10 parameters.

【

Red】. 【Green】.【Blue】.【White】. 【Amber】. 【UV】

6 color’s value range [0-255].

When amend the parameters, press [UP]/[DOWN] can increase or decrease the parameters, the

parameters can be saved automatically.

[ZOOM] value range [0-255].

[Strob] value range [0-20].

[Time], value range is [0-255], the unit is second.

[Fade] transition time, value range is [0-255], the unit is second, [Fade] ‘s time setting should lower

than [Time]’s time setting.

【

* Press

save.

MENU】return back to the previous menu, the parameters that you choose can automatic

www.goedlichtengeluid.nl [e-mail] 8

GLG Lighting products

Note: when setting [Time] as 0, and not running this scene, and enter into next scene mean you

close the running of this scene.

2.10 Fixture settings [SET]

* At [SET] menu, and press [ENTER] into the fixture parameters settings, [UPLD] is automatically

send, except address code and color correction parameters.

Enter into download and you will need a password, the password is: [UP+DOWN+UP+DOWN],

then press [ENTER] to confirm, if the password is correct, it will show in yellow display, mean it is

sending, when get succeed to send the password, it will show in green display with OK, the slave

receiving the password will show yellow, once it get succeed will show green. When the master get

succeed to send the password, the slave no change or don’t show green display mean it doesn’t get

succeed, then you need to download again.

* [REST] is the factory default parameter settings, press [ENTER] and enter the password

[UP+DOWN+UP+DOWN] then press [ENTER] to confirm. When the fixture get succeed to reset, it

will show OK.

*At [CLRV] press [ENTER] to choose dimming liner mode.

Press [UP/DOWN] to choose.

Liner dimming curve.

Square nonlinear dimming curve.

Nonlinear inverse square dimmer curve.

S-linear dimming curve.

* At [DIM] menu press [ENTER] to choose dimming speed.

www.goedlichtengeluid.nl [e-mail] 9

GLG Lighting products

Press [UP/DOWN] to choose dimming speed.

[OFF] dimming speed fastest.

[DIM1] dimming speed fast.

[DIM2] dimming speed slow.

[DIM3] dimming speed slower.

[DIM4] dimming speed slowest.

* At [LED]] menu press [ENTER] to turn on/off of the display.

Press[UP/DOWN] to turn on / off the display.

[ON] :when no press for 60s, it will close the LED display automatically.

[OFF]: not close the LED display.

* At [LEDV]] menu press [ENTER] into display screen forward and reverse switch.

Press [UP/DOWN] to choose turn no or off.

[ON]: LED display screen reverse.

[OFF] : LED display screen forward.

*At [ERR] menu press [ENTER] to disconnect the DMX signal lighting’s status settings.

[SLAVE]: disconnect DMX signal, lighting status no change.

[BLACK]: disconnect DMX signal, lighting close.

[VER]: check the software version.

At [TEMP] press [ENTER] to check the fixture temperature.

* At [HOUR] menu press [ENTER] to check the fixture running time.

* At [FANS] press [ENTER] to choose the speed of the fan.

Press [UP/DOWN] to choose fan’s speed.

[OFF]：close the fan.

[LOW]: fan runs slow.

[NORM]: fan runs medium.

[AUTO]: fan runs in different speed according to different temperature.

[HIGH]：fan runs fast.

* [ID] is turn on/off the address settings, press [ENTER] to enter into.

Press [UP/DOWN] to choose turn on/off.

[ON]: Turn the ID function.

[OFF]: Turn off the ID function.

*[RGBW] is adjust color cast is working or not.

Press [UP/DOWN] to choose.

[ON]: adjust color cast is working.

[OFF]: adjust color cast is not working.

* [POWER] settings, press [ENTER] to enter into.

Press [UP/DOWN] to choose.

[HIGH]: highest power.

[NORM]: highest power times 0.9.

www.goedlichtengeluid.nl [e-mail] 10

GLG Lighting products

2.11 Color temperature balance
parameters [CAL1]

* At [CAL1] menu, press [ENTER] into color temperature balance parameters settings.

Press [UP/DOWN] to choose WT[01-11] to enter into.

WT[01-11] has 6 color’s parameter for optional.

【

Red】. 【Green】.【Blue】.【White】. 【Amber】. 【UV】

6 color’s value range [0-255].

Press [UP/DOWN] to increase or decrease.

When DMX mode is set as STAG, CH9 can find out the build in 12 color temperature. Press

【

MENU】return back to the previous menu, the parameters that you choose can automatic save.

3.1. DMX 512 channel value (STAG mode)

Channel Value

1 0-255 Master dimmer

2 0-255 red

3 0-255

4 0-255

5 0-255

6 0-255 amber

7 0-255

8 0-255

9

10

0-10

11-255

0-30

31-50

51-70

71-90

Red 100%/ Green UP/ Blue 0%

Red DOWN/ Green 100%/ Blue 0%

Control function）

（

green

blue

white

UV

No value

Strobe close

strobe speed adjustable

no value

Red 0%/ Green100%/ Blue UP

91-110

111-130

www.goedlichtengeluid.nl [e-mail] 11

Red 0%/ Green DOWN/ Blue 100%

Red UP/ Green 0%/ Blue10 0%

GLG Lighting products

131-150

151-170

171-190

191-200

201-205

206-210

211-215

216-220

221-225

226-230

231-235

236-240

241-245

246-250

251-255

Red 100%/ Green 0%/ Blue DOWN

Red 100%/ Green UP/ Blue UP

Red DOWN/ Green DOWN/ Blue 100%

Red 100%/ Green 100%/ Blue 100%

WHITE1:3200K

WHITE2:3400K

WHITE3:4200K

WHITE4:4900K

WHITE5:5600K

WHITE6:5900K

WHITE7:6500K

WHITE8:7200K

WHITE9:8000K

WHITE10:8500K

WHITE11:10000K

0-20 No value

11

21-30 AUTO1

31-40 AUTO2

41-50 AUTO3

51-60 AUTO4

61-70 AUTO5

71-80 AUTO6

81-90 AUTO7

91-100 AUTO8

101-110 AUTO9

111-120 AUTO10

121-130 CUSTOM1

131-140 CUSTOM2

141-150 CUSTOM3

161-170 CUSTOM4

171-180 CUSTOM5

181-190 CUSTOM6

191-200 CUSTOM7

201-210 CUSTOM8

211-220 CUSTOM9

221-230 CUSTOM10

231-255 Sound active

www.goedlichtengeluid.nl [e-mail] 12

GLG Lighting products

12 0-255 Auto run speed

0-9 Preset dimmer speed.

10-29 fastest dimming speed.

13

14

30-69 fast dimming speed.

70-109 faster dimming speed.

110-169 slower dimming speed

170-255 slowest dimming speed

0-9 choose or ID code at the same time

10-209 each 10 value corresponds to one ID.

210-255 ID21-66, each value corresponds to one ID.

3.2 .DMX512 channel sheet

Channel Value

1 0-255 Red

2 0-255

3 0-255

4 0-255

Control function）

（

No value

ARC.1mode

（

Green

Blue

）

3.3 .DMX512 Channel sheet

Channel Value

1 0-255 Master dimmer

2 0-255 Red

3 0-255

4 0-255

5 0-255

（

3.4 .DMX512 Channel sheet

Channel Value

1 0-255 Red

2 0-255

3 0-255

4 0-255

5 0-255

（

（

Control function）

Green

No value

（

Control function）

Green

White

Amber

AR1.Dmode

Blue

ARC.2mode

Blue

）

）

6 0-255

7 0-255

www.goedlichtengeluid.nl [e-mail] 13

UV

No value

GLG Lighting products

3.5 .DMX512 Channel sheet（AR2.d mode）

Channel Value

1 0-255 Master dimmer

2 0-255 Red

3 0-255

4 0-255

5 0-255

6 0-255

7 0-255

8 0-255

Control function）

（

Green

Blue

White

Amber

UV

No value

3.6 .DMX512 Channel sheet（AR2.S mode）

Channel Value

1 0-255 Master dimmer

2 0-255 Red

3 0-255

4 0-255

Control function）

（

Green

Blue

5 0-255

6 0-255

7 0-255

8 0-255

9 0-255

Strobe speed adjustable

White

Amber

UV

No value

3.7 .DMX512 Channel sheet（HSV mode）

Channel Value

1 0-255 H hue(0-100%)

2 0-255

3 0-255

STAG mode explanation: master dimmer is validity for 2, 3, 4, 5, 6, 7, 9.

CH9

亮度

CH9 priority 2,3, 4, 5, 6, 7, 8 channel, but master dimmer can adjust the brightness of

CH9.

CH10 strobe, this channel is validity for 2, 3, 4, 5, 6, 7.

AUTO: CH11 priority 2,3, 4, 5, 6, 7, 9 channel, CH12 can control the speed of channel 11.

Control function）

（

S saturation (0-100%)

V brightness (0-100%)

www.goedlichtengeluid.nl [e-mail] 14

GLG Lighting products

3.8 .Specifications：

GLG Creator DLX IP65 18PCS RGBWA+UV 6 in 1 LED

*Voltage: AC100/240V, 50/60Hz

*Power consumption: 270W

*Light source: 18*12W (RGBWA+UV 6IN1)

*lens angle: 25 degree, 42mm lens

*Strobe: 0-16Hz, from slow to fast, adjusting

*Electronic dimmer from 0 to 100%

*Housing material: die-cast aluminum

*Control mode: Auto, Master/Slave, DMX512 signal

*DMX channels: 5 modes, 14, 7,8,9,3 channels for optional.

*LED digital display

*Data out/in: 3 pin XLR-connection.

* IP: 65, outdoor using.

www.goedlichtengeluid.nl [e-mail] 15
