Glen Dimplex UIM600 User Manual

UIM600

Built-In Microwave

User Manual

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY

Specifications

Model:

Rated Voltage:

Rated Input Power(Microwave):

Rated Output Power(Microwave):

Rated Input Power(Grill):

Oven Capacity:

Turntable Diameter:

External Dimensions(LxWxH):

Net Weight:

25L

315mm

If the apparatus is not maintained in a good state of cleanliness, its surface could

be degraded and affect the lifespan of the apparatus and lead to a dangerous

situation.

ADDENDUM

(a) Do not attempt to operate this oven with the door open since this can result in harmful exposure to microwave energy. It is important not to break or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. (c) WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person.

595x412x460mm

Approx. 17.3 kg

UIM600

2

230-240V~50Hz

1400-1450W

850-900W

950-1000W

IMPORTANT SAFETY INSTRUCTIONS

WARNING

To reduce the risk of fire, electric shock, injury to persons or exposure to excessive microwave oven energy when using your appliance, follow basic precautions, including the following:

1. Warning: Liquids and other foods must not be heated in sealed containers since they are liable to explode.

2. Warning: It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy.

3. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and

4. Keep the appliance and its cord out of

5. Only use utensils suitable for use in microwave ovens.

6. The oven should be cleaned regularly and

7. Read and follow the specific:"PRECAU TIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY".

8. When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition.

9. If smoke is emitted, switch off or unplug the appliance and keep the door closed in order to stifle any flames.

10. Do not overcook food.

11. Do not use the oven cavity for storage purposes. Do not store items, such as bread, cookies, etc. inside the oven.

12. Remove wire twist-ties and metal handles from paper or plastic containers/bags before placing them in the oven.

13. Install or locate this oven only in accordance with the installation instructions provided.

14. Eggs in the shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode, even after microwave heating has ended.

15.This appliance is intended to be used in household and similar applications such as:

-staff kitchen areas in shops, offices and other working environments;

-by clients in hotels, motels and other residential type environments;

-farm houses;

-bed and breakfast type environments.

16. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

17. Do not store or use this appliance outdoors.

18. Do not use this oven near water, in a wet basement or near a swimming pool.

19. The temperature of accessible surfaces

operating.

The surfaces are liable to get

hot during use.

Keep cord away from

heated surface, and do not cover any

20. Do not let cord hang over edge of table or counter.

21. Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation.

22. The contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature checked before consumption, in order to avoid burns.

knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised.

reach of children less than 8 years.

vents on the oven.

may be high when the appliance is

any food deposits should be removed.

3

READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

23. Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling the container.

24.The appliance is not intended for use by persons (including children) with reduced physical , sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

25.Children should be supervised to ensure that they do not play with the appliance.

26.The appliances are not intended to be operated by means of an external timer or separate remote-control system.

27. Accessible parts may become hot during use. Young children should be kept away.

28.Steam cleaner is not to be used. 29 During use the appliance becomes hot. Care should be taken to avoid touching heating elements inside the oven.

30. Only use the temperature probe recommended for this oven.(for ovens provided with a facility to use a temperature-sensing probe.)

31. WARNING: The appliance and its accessible parts become hot during use.Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised.

32. Only use the temperature probe recommended for this oven.(for ovens provided with a facility to use a temperature-sensing probe.)

33. The microwave oven must be operated with the decorative door open.(for ovens with a decorative door.)

34.surface of a storage cabinet can get hot.

4

DANGER

Electric Shock Hazard Touching some of the interna components can cause serious personal injury or death. Do not disassemble this appliance.

WARNING

Electric Shock Hazard Improper use of the grounding can result in electric shock. Do not plug into an outlet until appliance is properly installed and grounded.

To Reduce the Risk of Injury to Persons Grounding Installation

CLEANING

Be sure to unplug the appliance from the power supply.

1. Clean the cavity of the oven after using with a slightly damp cloth.

2. Clean the accessories in the usual way in soapy water.

3. The door frame and seal and neighbouring parts must be cleaned carefully with a damp cloth when they are dirty.

1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord.

2. If a long cord set or extension cord is used:

1)The marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance.

This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.

Consult a qualified electrician or serviceman if the grounding instructions are not completely understood or if doubt exists as to whether the appliance is properly grounded. If it is necessary to use an extension cord , use only a 3-wire extension cord.

2)The extension cord must be a groundingtype 3-wire cord.

3)The long cord should be arranged so that it will not drape over the counter top or tabletop where it can be pulled on by children or tripped over unintentionally.

4. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass.

5. Cleaning Tip---For easier cleaning of the cavity walls that the food cooked can touch: Place half a lemon in a bowl, add 300ml (1/2 pint) water and heat on 100% microwave power for 10 minutes. Wipe the oven clean using a soft, dry cloth.

5

CAUTION

Personal Injury Hazard

It is hazardous for anyone other than a compentent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy.

Utensil Test:

1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil in question.

2. Cook on maximum power for 1 minute.

3. Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.

4. Do not exceed 1 minute cooking time.

Materials you can use in microwave oven

Utensils Remarks

Aluminum foil Shielding only. Small smooth pieces can be used to cover thin parts of

meat or poultry to prevent overcooking. Arcing can occur if foil is too close to oven walls. The foil should be at least 1 inch (2.5cm) away from oven walls.

Follow manufacturer’s instructions. The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause the turntable to break.

Microwave-safe only. Follow manufacturer's instructions. Do not use cracked or chipped dishes.

Always remove lid. Use only to heat food until just warm. Most glass jars are not heat resistant and may break.

Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use cracked or chipped dishes.

Follow manufacturer’s instructions. Do not close with metal tie. Make slits to allow steam to escape.

Use for short–term cooking/warming only. Do not leave oven unattended while cooking.

Use to cover food for reheating and absorbing fat. Use with supervision for a short-term cooking only.

Use as a cover to prevent splattering or a wrap for steaming.

Microwave-safe only. Follow the manufacturer’s instructions. Should be labeled "Microwave Safe". Some plastic containers soften, as the food inside gets hot. "Boiling bags" and tightly closed plastic bags should be slit, pierced or vented as directed by package.

Microwave-safe only. Use to cover food during cooking to retain

moisture. Do not allow plastic wrap to touch food. Thermometers Microwave-safe only (meat and candy thermometers). Wax paper Use as a cover to prevent splattering and retain moisture.

Browning dish

Glass jars

Glassware

UTENSILS

See the instructions on "Materials you can use in

microwave oven or to be avoided in microwave oven."

There may be certain non-metallic utensils that are not

safe to use for microwaving. If in doubt, you can test the

utensil in question following the procedure below.

Oven cooking bags

Paper plates and cups

Paper towels

Parchment paper

Plastic

Plastic wrap

Dinnerware

6

A) Control panel B) Turntable shaft C) Turntable ring assembly D) Glass tray E) Observation window F) Door assembly G) Safety interlock system

Materials to be avoided in microwave oven

Utensils Remarks

Aluminum tray Food carton with

metal handle Metal or metal-

trimmed utensils Metal twist ties

Paper bags Plastic foam

Wood

F

G

A

CB

E

D

SETTING UP YOUR OVEN

Names of Oven Parts and Accessories

Remove the oven and all materials from the carton and oven cavity. Your oven comes with the following accessories: Glass tray 1 Turntable ring assembly 1 Instruction Manual 1

Metal shields the food from microwave energy. Metal trim may cause arcing.

May cause a fire in the oven. Plastic foam may melt or contaminate the liquid inside when exposed

to high temperature. Wood will dry out when used in the microwave oven and may split

or crack.

May cause arcing. Transfer food into microwave-safe dish. May cause arcing. Transfer food into microwave-safe dish.

May cause arcing and could cause a fire in the oven.

Grill Rack( Only be used in grill function and be placed on the glass tray )

7

Hub (underside)

Glass tray

Turntable ring assembly

a. Never place the

glass tray

upside down. The glass

tray should never be restricted.

b. Both

glass tray

and

turntable ring assembly

must

always be used during cooking.

c. All food and containers of food are always placed

on the

glass tray

for cooking.

d. If

glass tray

or

turntable ring assembly

cracks or

breaks, contact your nearest authorized service

center.

Turntable Installation

Turntable shaft

The accessible surface may be hot during operation.

Installation and connection

1.This appliance is only intended for domestic use.

2.This oven is intended for built-in use only.It is not intended for counter-top use or for use inside a cupboard.

3. Please observe the special installation instructions.

4.The appliance can be installed in a 60cm wide wall-mounted cupboard(at lease 55cm deep and 85cm off the floor).

5.The appliance is fitted with a plug and must only be connected to a properly installed earthed socket.

6.The mains voltage must correspond to the voltage specified on the rating plate.

7.The socket must be installed and connecting cable must only be replaced by a qualified electrician.If the plug is no longer to accessible following installation,an all-pole disconnecting device must be present on the installation side with a contact gap of at lease 3mm.

8.Adapters,multi-way strips and extension leads must not be used. Overloading can result in a risk of fire.

8

Installation Instruction

9

Please Read the Manual Carefully Before Installation

SCREW A

ADJUST SCREW B

SCREW C

TRIM-KIT PLASTIC COVER

BOTTOM BRACKETS

Please Note Electrical connection

The oven is fitted with a plug and must be only connected to a properly installed earthed socket. In accordance with the appropriate regulations, the socket must only be installed and the connecting cable must only be replaced by a qualified electrician.

If the plug is no longer accessible following installation and all-pole isolating switch must be present on the installation side with a contact gap at least 3mm.

A. Built-in furniture

The built-in cabinet shall not have a rear wall behind the appliance.

Minimum installation height is 85cm.

Do not cover ventilation slots and air intake points.

600

+8

560

(45)

min

550

450

+2

(45)

10

B. Prepare the Cabinet.

1

1. Read the instruction on the BOTTOM CABINET TEMPLATE, put the

template on the bottom plane of cabinet.

2

SCREW A

BOTTOM BRACKETS

2. Make marks on the bottom plane of cabinet according to marks “a” of the

template.

11

3

SCREW A

3. Remove the BOTTOM CABINET TEMPLATE, and fix the BOTTOM BRACKETS with SCREW A.

C. Prepare the oven.

4

ADJUST SCREW B

UPPER AIR TUNNEL

4. Fix SCREW B on the UPPER AIR TUNNEL of the oven.

TRIM-KIT

D. Install the oven.

12

5

ADJUST SCREW B

ADJUST HEIGHT

OVEN FOOT

5. Install the oven into the cabinet. z Adjust the height of SCREW B to keep 1mm gap between the SCREW B

and the top plane of cabinet.

z Make sure that the OVEN FEET are aligned with the grooves of brackets

when install the oven into the cabinet.

z Do not trap or kink the power cord.

6

SCREW C

INSTALLATION HOLE

TRIM-KIT PLASTIC COVER

INSTALLATION HOLE

6. Open the door; fix the oven to the cabinet with SCREW C at the INSTALLATION HOLE of TRIM KIT.

Then fix the TRIM-KIT PLASTIC COVER

to the INSTALLATION HOLE.

Operation Instructions

1) Press " " once, the screen display "P100".

2) Turn " " to adjust the hour figures, the input time should be within 0--23.

3) Press " ", the minute figures will flash.

3) Press " " to confirm, and the screen displays "P 80".

4) Turn " " to adjust the cooking time until the oven displays "20:00".

5) Press " " to start cooking .

1. Clock Setting

When the microwave oven is electrified, the LED will display "0:00", buzzer will ring once.

1) Press " ", the hour figures will flash.

4) Turn " " to adjust the minute figures, the input time should be within 0--59.

5) Press " " to finish clock setting. ":" will flash, and the time will light.

Note: the step quantities for the adjustment time of the coding switch are as follow:

0---1 min : 5 seconds

1---5 min : 10 seconds

5---10 min : 30 seconds

10---30 min : 1 minute

30---95 min : 5 minutes

2) Press " " once again or turn" " to choose 80% microwave power.

Note: 1) If the clock is not set, it would not function when powered.

2) During the process of clock setting, if you press " ", the oven will go back to the previous status automatically.

2. Microwave Cooking

Press " " the LED will display "P100.Press " " for times

or turn " "to choose the power you want, and "P100", "P80" "P50", "P30" or

"P10" will display for each added press. Then press" " to

confirm, and turn " " to set cooking time from 0:05to 95:00. Press

" " again to start cooking. Example: If you want to use 80% microwave power to cook for 20 minutes, you can

operate the oven as the following steps.

Microwave

Start/+30Sec./Confirm

Microwave

Clock/ Pre-Set

Start/+30Sec./Confirm

Stop/Clear

Start/+30Sec./Confirm

Microwave

13

Order

Microwave

Power

Grill

Power

Display

1

2

3

4

5

100%

80%

50%

30%

10%

100%

45%

64%

0%

55%

36%

1

2

3

Microwave

Power

Order

Display

1) Press " " once, the screen display "G".

3) Press " " to confirm, and the screen displays "C-1".

4) Turn " " to adjust the cooking time until the oven displays "10:00".

5) Press " " to start cooking .

2) Press " " once again or turn " " to choose combi. 1 mode.

"Microwave" Pad instructions

"Grill/Combi." Pad instructions

Note:If half the grill time passes, the oven sounds twice, and this is normal.

In order to have a better effect of grilling food, you should turn the food over,

close the door, and then press " " to cintinue cooking.

If no operation the oven will continue cooking.

P100

P80

P50

P30

P10

G

C-1

C-2

3. Grill or Combi. Cooking

Press " " the LED will display"G",and press " "for times or

turn the " " to choose the power you want, and "G","C-1" or "C-2" will display

for each added press. Then press " "to confirm, and turn " "

to set cooking time from 0:05 to 95:00. Press " " again to

start cooking.

Grill/Combi.

Example: If you want to use 55% microwave power and 45% grill power(C-1) to cook for

10 minutes, you can operate the oven as the following steps.

Grill/Combi.

Start/+30Sec./Confirm

Grill/Combi.

Start/+30Sec./Confirm

14

1) Press " " twice, and the oven will display "dEF2".

2) Turn " " to select the defrost time.

3) Press " " to start defrosting.

1) Turn " " clockwise till "A-5" display.

Example: If you want to use "Auto Menu" to cook fish for 350g.

2) Press " " to confirm.

1) Press " " once, and the LED will display "200".

2) Press " " more times or turn " " to choose the weight of food, and "400" or "600" g will be selected.

3) Press " " to start cooking.

1) Turn " " right to choose the menu, and "A-1" to "A-8" will display, which means pizza, potato, meat, vegetable, fish, pasta, soup and porridge.

2) Press " " to confirm.

3) Turn " " to choose the default weight as the menu chart.

4) Press " " to start cooking.

1) Press " " once, and the oven will display "dEF1".

2) Turn " " to select the weight of food from 100 to 2000 g.

3) Press " " to start defrosting.

1) In waiting state, Press " " to start cooking with 100% power,

each added press will increase 30 seconds cooking time up to 95 minutes.

2) In microwave, grill, combi. cooking or time defrost state, each press of

" " can increase 30 seconds of cooking time.

3) In waiting state, turn " " anti-clockwise to set cooking time with 100%

microwave power, then press " " to start cooking.

4. Quick Start

6. Defrost By Time

8. Auto Menu

7. Auto Reheat

Auto Reheat

5. Defrost By Weight

W.T/Time Defrost

Start/+30Sec./Confirm

W.T/Time Defrost

Start/+30Sec./Confirm

15

3) Turn " " to select the weight of fish till "350" display.

4) Press " " to start cooking.

The menu chart:

Menu

Weight

Display

A-2

Potato

A-3

Meat

A-4

Vegetable

A-5

Fish

A-6

Pasta

A-7

Soup

A-8

Porridge

200 g

400 g

200 g

400 g

600 g

250 g

350 g

450 g

200 g

300 g

400 g

250 g

350g

450 g

50g(with 450 cold water)

100g(with 800 cold water)

200ml

400ml

550g

1100g

A-1

Pizza

200 g

400 g

200 g

400 g

600 g

250 g

350 g

450 g

200 g

300 g

400 g

250 g

350g

450 g

50g

100g

200ml

400ml

550g

1100g

a. Press " " once, the screen display "P100".

b. Press " " once again or turn " " to choose 80% microwave power.

9. Program set in Advance

1) Set the clock first. (Consult the instruction of clock setting.)

2) Input the cooking program. Two stages can be set at most.

Defrost should not be set as the cooking program.

Start/+30Sec./Confirm

Example: If you want to cook with 80% microwave power for 7 minutes, operate it as the

following:

Microwave

16

7) Press " " to start cooking, and buzzer will sound once for the

first section, defrosting time counts down; buzzer will sound once again entering

the second cooking. when cooking finish, buzzer sounds five times.

1) Press " " twice, and the oven will display "dEF2".

2) Turn " " to select the defrost time till "5:00" display.

3) Press " " once, the screen display "P100".

5) Press " " to confirm, and the screen displays "P 80".

6) Turn " " to adjust the cooking time till the oven displays "7:00".

4) Press " " once again or turn " " to choose 80% microwave power.

4) Turn " " to adjust the hour figures, the input time should be within 0--23.

5) Press " ", the minute figures will flash.

3) Press " ", the hour figures will flash.

c. Press " " to confirm, and the screen displays "P 80".

d. Turn " " to adjust the cooking time till the oven displays "7:00".

10. Multi-section cooking

At most 2 sections can be set for cooking. In multi-section cooking, if one section is

defrosting, then defrosting shall be placed in the first section.

After the aboved steps, be careful not to press " " to start

cooking.

Example: If you want to defrost food for 5 minutes and then cook with 80% microwave

power for 7 minutes, operate it as the following:

Clock/ Pre-Set

Microwave

6) Turn " " to adjust the minute figures, the input time should be within 0--59.

7) Press " " to finish setting. If the door is closed, buzzer will ring

twice when the time arrives, then cooking will start automatically.

Start/+30Sec./Confirm

W.T/Time Defrost

Start/+30Sec./Confirm

17

11. Inquiring Function

(1) In states of microwave,grill and combination cooking, press " ", the

current power will be displayed for 3 seconds. After 3 seconds, the oven will turn back

to the former state;

(2) In cooking state, press " " to inquire the time and the time will display

for 3 seconds.

(3) In preset state, press " " to inquire the preset time, and the preset time

will display for 3 seconds.

12. Lock-out Function for Children

Lock: In waiting state, press " " for 3 seconds, there will be a long beep denoting entering the children-lock state and the locked indicator will display if the time has been set, otherwise, the LED will display " ". Lock quitting: In locked state, press " " for 3 seconds, there will be a long "beep" denoting that the lock is released.

Clock/ Pre-set

Microwave

Clock/ Pre-set

Stop/Clear

18

Trouble shooting

According to Waste of Electrical and Electronic Equipment (WEEE) directive, WEEE should be separately collected and treated. If at any time in future you need to dispose of this product please do NOT dispose of this product with household waste. Please send this product to WEEE collecting points where available.

It is forbidden to run the unit without any food inside.

It is very dangerous.

19

Contact US

Should you need to get in touch with us (UK and Northern Ireland only),

please call the Customer Care Helpline on:

0844 815 3747

For customers outside the UK and Northern Ireland, please contact your local supplier.

Please keep this handbook in a safe place.

Please fill in the model number and serial number in the spaces provided below as they will

assist us should you need to call

Your 1

st

Year Guarantee

To fulfil the conditions of your guarantee, this appliance must be correctly installed and

operated, in accordance with these instructions, and only be used for normal domestic

purposes.

Please note that the guarantee, and Service availability, only apply to the UK and

Republic of Ireland.

Model No

Serial No

20

Stoney Lane, Prescot, Merseyside, L35 2XW

PN:2618003124 4

29th Sep,2012

7

Glen Dimplex UIM600 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
