Glenayre Electronics 6000 User Guide

Using Your AccessLink™ II 2-Way Pager

Congratulations on your purchase of the Glenayre
AccessLink II advanced messaging, two-way pager!

The AccessLink II is simple to use and provides

exciting new messaging capabilities.

Vi rtual Keyboard Quick Refere n c e

THE VIRTUAL KEYBOARD The AccessLink II has a virtual keyboard to allow you

to enter messages and other information. Since this keyboard is created
entirely in software, your two-way pager can be as small as a one-way pager.
You will use this keyboard often to enter messages or other information.
Refer to this page whenever you need a quick reminder about how to use
the virtual keyboard.

• To "type" letters, use the "Up/Down" and "Left/Right Scroll" buttons
to select the appropriate letter and then press the "Enter" button.

• When you enter a letter or punctuation character, the cursor returns to
the center of the keyboard, which is the space key. To type a space
simply press the "Enter" button.

• To delete a character, scroll to the bottom of the screen. When the
cursor is in the bottom row, press the down scroll button to delete the
preceding character.

• To change case, scroll to the top row of the keyboard, and select the Up
Scroll button. Each press of the Up Scroll button changes the case from
lower case, to shift, to caps lock, and back to lower case.

• To edit the message, press the "Exit/Backlight" button. The keyboard will
disappear, allowing you to scroll through the message with the "Up/Down"
and "Left/Right" Scroll buttons. Press the "Enter" button to insert the cursor
into the selected position and return the virtual keyboard.

• Once you are finished entering a message or other type of information
press the "Exit/Backlight" button which takes you to the Edit Screen.
Press the "Exit/Backlight" button again to arrive at the Message menu,
with options to address, edit, save, or delete the message.

• You may exit the editor at any time by pressing the "Exit/Backlight"
button until you have backed up to the screen you desire. Any work you
have started will be saved in the folder where it was created. Unsent
messages will be saved in the TO SEND folder.

2

AccessLink II Overv i e w

Home Screen

“Exit/Backlight” Button:
Use to Exit from
any screen

“Left/Right Scroll” Buttons
“Up/Down Scroll” Buttons
“Enter” Button

Icon Quick Reference Guide

Alarm Clock enabled
Alarm sounded and still enabled
New Messages in Information Services Folders
New Messages in RECEIVED Folder
RECEIVED message audible alert enabled
RECEIVED message vibrate alert enabled

Message Icons

Unread message
Read message
Successful send or reply
Unsuccessful send or reply
Reply Pending

3

CONGRATULATIONS To get the most out of your new advanced messaging,

two-way pager, spend a little time reading this user guide and be sure to give
your pager's number to business colleagues and friends. Family members will
also appreciate being able to reach you easily. For information on available
services, please see the service instructions provided by your paging carrier.

Table of Contents

Virtual Keyboard Quick Reference . . . . . . . . . . . . . . . . . .2

AccessLink II Overview . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Icon Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Pager Organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Quick Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-7

Inserting/Replacing the Battery . . . . . . . . . . . . . . . . . . . .8

Receiving Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Reading Messages . . . . . . . . . . . . . . . . . . . . . . . . . . .10-12

Deleting Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Creating an Address . . . . . . . . . . . . . . . . . . . . . . . . . .14-15

Creating Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Sending Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Disabling Information Services . . . . . . . . . . . . . . . . . . .18

Setting Your Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . .19-20

Getting a Good Night's Sleep . . . . . . . . . . . . . . . . . . . . .21

Waking Up (Setting Your Alarm Clock) . . . . . . . . . . . . .22

Miscellaneous Settings . . . . . . . . . . . . . . . . . . . . . . .23-27

Turning On the Backlight . . . . . . . . . . . . . . . . . . . . . . . .28

Operating in Hospitals and Planes . . . . . . . . . . . . . . . . .28

Communicating Using the IR Port . . . . . . . . . . . . . . . . .29

IR Port Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Viewing Status Information . . . . . . . . . . . . . . . . . . . . . . .31

Pager Org a n i z a t i o n

5

Quick Start

1

TURNON ACCESSLINK II PAGER

Your pager enters a "sleep" mode to conserve battery life when it is not
in use. It "wakes up" when you press any button or receive a new message.
If the unit has been turned off, turn on your pager by pressing and holding the
oval "Enter" button. (If unit does not turn on, see "Inserting/Replacing Battery"
section on page 8.)

2

SETTHE TIMEAND DATE

• From the home screen, press the “Enter” button to enter the folder list.

• Scroll down to the PREFERENCES folder by pressing the “Down Scroll”
button. Press the “Enter” button to enter the folder.

• Scroll down to DATE & TIME and press the “Enter” button.

• Adjust the date by pressing the “Up/Down Scroll” buttons to change
the month, then pressing the “Right Scroll” button to set the day and
the year.

• Press the “Right Scroll” button to set the time and AM/PM, and
then press the “Exit/Backlight” button to save your changes and
exit the screen.

3

SET ALERTS

• Within the PREFERENCES folder, scroll to PERSONAL ALERTS and
press the “Enter” button.

• Set PERSONAL ALERTS options by scrolling to the item of interest and
using the “Enter” button to select your desired setting. For TONES,
you can sample each sound by pressing the “Enter” button.

• Press the “Exit/Backlight” button to save your settings and exit the
PERSONAL ALERTS screen. For more detailed information on your alert
options, see the “Setting Your Alerts” section on page 19-20.

(Continued on next page.)

6

Quick Start Cont.

4

SET UP YOUR SENDER ID

The Sender ID is a name or other text that will be attached to the end of every
message you send to identify you to the message recipient.

To set up your Sender ID:

• Within the PREFERENCES folder, scroll down to MISCELLANEOUS and
press the "Enter" button.

• Scroll down to SENDER ID and press the "Enter" button.

• Enter your desired Sender ID using the virtual keyboard. See the "Virtual
Keyboard Quick Reference" section on page 2 for further details.

• After you have entered your Sender ID, press the "Exit/Backlight" button
twice to save your changes and exit the Editor.

Congratulations! You‘re now ready to start sending and receiving messages!

7

I n s e rting/Replacing the Battery

Your AccessLink II pager uses a single AA alkaline battery.
To insert or replace the battery:

1

Slide the lock on the back of the pager away from the symbol.

2

Slide the battery door to the left to open.

3

Insert a new battery being careful to align the + and - symbols on the
battery with the same symbols inside the battery compartment.

4

Replace the door and slide the lock towards the symbol to secure.

Note: If you have a lot of messages in your AccessLink II, you may

experience a short delay as the pager restarts itself after the
new battery has been inserted. Once it is fully operational the pager
will beep once.

CAUTION: Be careful to align the + and - symbols on the battery with those

inside the battery compartment. Inserting the battery backwards will cause
the date and time setting in your AccessLink II pager to be lost. All messages
will be preserved, however.

8

Receiving Messages

• Your AccessLink II pager helps you organize your communications by
placing messages directly into folders such as RECEIVED for personal
messages and information service folders (NEWS, SPORTS, etc.)
for news messages. Exact folder names may vary depending on
your service provider.

• When you receive a new message, your AccessLink II pager vibrates
and/or plays your selected tone.

• The icon is displayed whenever you receive a new message.
If it is solid, you have new information service messages. If it is
flashing, you have new personal messages.

• The top line of the home screen also displays the number of new
messages you have.

• Finally, your ability to receive messages varies depending on the
terrain, weather, building density, and interference around you.
Your pager home screen will report your current service level.
For a description of your service level, please see the service
instructions provided by your paging carrier.

9

Reading Messages

TO READ A MESSAGE

1

From the home screen, view the folder list by pressing the “Enter” button.

2

Select the desired folder using the “Up/Down Scroll” buttons and open it
by pressing the “Enter” button.

3

Select the desired message using the “Up/Down Scroll” buttons and read
the message by pressing the “Enter” button. You can scroll through the
message using the “Up/Down Scroll” buttons or the “Enter” button.

4

While reading a message, you can quickly move to other messages in the
same folder.

• To jump to the beginning of the next message in the folder, press the
"Right Scroll" button.

• To jump to the beginning of the previous message in the folder, press
the "Left Scroll" button.

• You can also jump to the beginning of the next or previous message by
pressing the "Right/Left Scroll" buttons when the navigational symbol
(<<•>>) at the end of the message is highlighted.

Several message options appear at the end of each message. Use the “Enter”
button to select the desired option.

Note: If a given option appears with a line through it, that option is not

available for the message you are currently reading.

SAVE

To file the message in another folder, select SAVE from the message option list
and press the “Enter” button. Use the “Up/Down Scroll” buttons to select the
folder you wish to move the message to and press the “Enter” button. The
message will be stored in the folder you have chosen. Unlike messages in
the RECEIVED, TO SEND, MESSAGE LOG, and information service folders,
messages filed in the TO DO, APPTS, BUSINESS, PERSONAL, and MISC
olders will never be deleted by the pager to make room for new messages.

(Continued on next page.)

10

Reading Messages Cont.

To remove a message once it has been saved, you must read it and select the
DEL message option. You can also delete many saved messages at the same
time. See the “Deleting Messages” section on page 13 for details.

REPLY

You can reply to a message using a pre-programmed standard reply, a reply
you have previously sent, a multiple choice response, or a fully custom reply.

To reply:

1

Select REPLY from the message option list and press the “Enter” button.

• To send a standard reply, select your desired reply from the list
and press the “Enter” button.

• To send a previously sent reply, scroll down the list of replies until you
find the reply you want. Press the “Enter” button to select the reply.

• When someone sends you a message he/she can create multiple
choice responses from which you can chose. These custom
responses appear at the top of the list of replies when you select
REPLY. For information on sending multiple choice responses with a
message see "Attaching Multiple Choice Replies" section on page

• To create a custom reply, select "Custom Reply" from the list. Create
your reply using the virtual keyboard. See the "Virtual Keyboard Quick
Reference" section on page 2 for details regarding how to use the
virtual keyboard. When you have finished entering your reply press the
"Exit/Backlight" button twice.

2

The SEND option will now be highlighted. To send the reply, press the
"Enter" button. To edit the reply, select EDIT by first pressing the "Right
Scroll" button and then pressing the "Enter" button. For details on editing
a message, see the "Editing" section on page 17.

After you send your reply, the display will change to REPLYING as your reply is
transmitted. If other messages are currently being sent, your display will show
PENDING indicating your reply will be sent as soon as possible.

(Continued on next page.)

11
