Glem GL965EI, GL53EI, GL53GI User Manual

COOKERS

INSTALLATION AND OPERATING INSTRUCTIONS

All Glem and Emilia cooker models

Gl

em Gas Australasia P/L 48 Percy

Street Auburn NSW 2144

tel [phone]

fax [phone]

[e-mail]
www.glemgas.com.au

IMPORTANT:

This cooker is for domestic applications. It is NOT suitable for commercial applications of any kind.
Do not install the cooker if there is any doubt. Contact Glem Gas Australasia if you require
clarification.
This cooker must be installed by a qualified & licensed installer in accordance with these
instructions. If you do not retain proof of correct installation your warranty will be voided. If your
cooker is found to be incorrectly installed you will be liable for all service costs. If a warranty call is
made and the cooker is found to be incor-rectly installed you will be charged for the service call
even if the cooker is not repaired. We will not service an incorrectly installed cooker.
IF THE APPLIANCE IS DAMAGED DO NOT INSTALL. CALL 1300 307 91

REV190320

7

Dear Customer,

Thank you for purchasing our product.

This manual has been written to assist you and instruct you in the operation of this
appliance. It will help you get the best performance and make full use of the
appliance's features.

The safety precautions and warnings are listed for your safety and the safety of others when
operating this appliance.

Please keep this manual in a safe place for future reference.

This appliance has been designed for use in cooking of domestic (household) food. Any
form of usage other than cooking food is considered dangerous and inappropriate. The
manufacturer accepts no responsibility in the event of problems caused by improper use,
incorrect use or faulty installation. A signed installation certificate indicating the installer's
licence number and details is required for warranty service.

IMPORTANT

This appliance is designed and intended for use in a domestic household application.
It is not suitable for any non domestic application. IT SHOULD NOT BE USED IN A
COMMERCIAL ENVIRONMENT.

Th

e appliance guarantee will be void if the appliance is used within a
non domestic environment. This includes semi commercial, commercial
or communal applications such as clubs and schools.

MODEL NUMBER DETAILS ARE ON THE INSIDE OF THE WARMING DOOR PANEL
UNDERNEATH THE OVEN OR ON A LABEL NEXT TO THE OVEN CAVITY ABOVE THE

DOOR SEAL.

Emilia & Glem cookers are manufactured in the Glem Gas factory in Modena, Italy.
They have been designed and constructed to meet the following standards:

AS/NZ 5623 Australian safety standard - Requirements for Domestic Gas cooking appliances
AS/NZS 60335-1 General Requirements for Domestic electrical appliances
AS/NZS 60335-2-6 Particular Requirements for Domestic electrical cooking appliances
AS/NSZ 1044 Electromagnetic Compatibility Requirements.

Surface temperatures for all components comply with the standards. Even so certain parts of
a stainless steel cooker become very hot during and after use. On some models a cooling fan
operates during the cooking cycle and afterwards until the cooker cools.

NOTE: If there is a concern regarding the surrounding surfaces you must install an
insulating material such as fibre sheet between the cupboards and the cooker.

The cooker is not intended for use by young children or infirmed persons unless they have
been properly trained in the use of the cooker.

FIRST TIME USE

IMPORTANT

Remove all packing material and literature from the upright cooker before connecting the
gas and electrical supply.

A protective plastic film is coated on the stainless steel inside and on the outside of the
cooker. It must be removed before use.

Make sure all plastic has been removed before use. Some models have trays with a
protective coating; make sure the plastic coating has been removed. To make the plastic
film easier to remove we suggest using a Stanley knife to trim along joints and edges
before peeling back the film.

Clean the interior of the oven with soap and water.

Switch on the empty oven on maximum to eliminate grease residues from
manufacturing. There may be a slight odour at this time. Run the oven on maximum for a
period of 2 hours. Open the kitchen windows at this time. If this odour lingers use the
oven and the odour will dissipate within a short period of time.

IMPORTANT

• DO NOT spray aerosols in the vicinity of this upright cooker while it is in operation.

• DO NOT allow young children to use the cooker

• DO NOT touch surfaces when they are hot

• DO NOT store flammable materials in or under the cooker

•

DO keep the cooker clean to avoid fires

WARNING

THIS COOKER IS NOT TO BE USED AS A SPACE HEATER.

If the upright cooker fails to operate correctly, call Glem Gas Australasia Pty Ltd or their
appointed agent for service. DO NOT ATTEMPT REPAIRS YOURSELF.

Glem Gas Australasia Pty. Ltd. does not accept any responsibility for any damage
coming from inappropriate, incorrect and irrational use. For more detailed information,
refer to the Warranty Card. Contact Glem Gas Australasia Pty. Ltd. on 1300 307 917
for all service enquiries.

DO NOT MODIFY THIS APPLIANCE

DO NOT INSTALL IF THE COOKER IS DAMAGED

DO NOT USE THIS APPLIANCE AS A SPACE HEATER

THIS APPLIANCE IS NOT FOR USE IN MARINE CRAFT, CARAVANS OR MOBILE
HOMES.

2

3

MOVING THE COOKER

When moving the cooker always use two people.

When installed this cooker complies with all safety requirements however care must
be taken when moving the cooker as some sharp edges and corners that are not
intended to be touched could cause injury.

DO NOT LIFT USING THE HANDLE –
open the oven door and hold inside
the top of the oven cavity.

DO NOT DRAG OR SLIDE THE COOKER

ADJUSTABLE FEET (SOME MODELS) – before installing

the cooker level the appliance using the adjustable feet or
legs.

Location of model number

SAFETY CHAIN AND ANTI TILT BRACKETS

The upright cookers have a safety chain to prevent damage to the gas pipes if the
upright cooker is moved and anti tilt brackets to prevent accidental tipping of the cooker.

Safety chain

The chain must be secured to the wall
behind the upright cooker by fitting an
expansion plug with hook to the wall at
the same height as the safety chain.
The chain may then be attached to the hook.

4 5

INSTALLATION OF ANTI TILT BRACKET

Install the legs to the cooker and adjust the height to the desired level. Make sure that
this height is absolutely correct to what you require.

On the rear of the cooker there is a covering panel. Accurately measure the distance
from the top of this panel to the floor Height H.

Mark the same height on the wall against which the cooker is to be installed.

Mark the centre of the cooker at the same height on the wall.

At a distance of 150mm either side of the centre at the measured height mount the
2 anti tilt brackets supplied onto the wall.

Slide the cooker into position after connecting the chain. The brackets prevent any
chance of the cooker tilting forward.

Brackets mounted
onto wall and cooker
slides underneath

H

300mm

Connect safety
chain onto wall
with hook

Rear cover

IMPORTANT INFORMATION AND WARNINGS BEFORE USING
THE COOKER

After the cooker is unpacked make sure that it is not damaged. If unsure please contact
Glem Gas Australasia on 1 300 307 917. All packaging materials should be disposed of
appropriately.

Cookers are hot. This cooker meets Australia Standards on external surface
temperatures but the surfaces are still hot and children should not be allowed to play
with the cooker at any time.

FOR SAFE USE OF THE COOKER PLEASE CONSIDER:

Oven door: Keep children away from the glass oven door while cooking is in progress.

Drop down doors: Don’t let children sit down or play with the oven door.

Do not use the drop down door as a stool to reach above cabinets. Do not put any
weight on an open oven door.

Grill: Grilling must always be done with the oven door closed.

Pots and pan handles: Always turn pan handles to the side or to the back of the hob

where they can’t be knocked or reached by children.

Storage compartment: Some models have a storage compartment located under the
oven. Do not place inflammable materials or plastic utensils in the storage compartment.

Using the right sized pan: Using the right sized pan makes sense: saves energy and
avoids burnt handles or damage to pots and the hob.

Use of pot holder gloves: Make sure that burners and oven trays are cool before
touching them unless you are wearing oven gloves.

Rear view showing brackets attached to wall

Slide cooker
under brackets

Side view showing brackets attached to wall

6

Precautions: Never wear loose fitting garments while burners are on, since the fabric
could ignite and cause injuries. Caution should also be taken with potholders & tea
towels.

DO NOT line the oven walls or floor with aluminium foil. Do not place baking trays or
anything onto the floor of the oven.

This cooker is stainless steel. Harsh detergents and acids can cause rust spots.
This is not covered under warranty. Please use an approved stainless steel
cleaner. Call 1300 307 917 if you are unsure.

H

NOTE: This cooker is supplied with a duplicate data plate. Attach it to an
adjacent cupboard for easy access. Record model and serial number here:

MODEL: ________________________________________

Serial No: _______________________________________

7

REMOVING THE DOOR ON THE AL, EM AND EB SERIES

1. Open the door completely

2. Using a small screwdriver ick up the hinge lock A on each hinge
and swing it into the slot.

REMOVING THE DOOR ON THE AL, EM AND EB SERIES

1. Open the door completely

2. Using a small screwdriver ick up the hinge lock A on each hinge
and swing it into the slot.

A

3. Take the weight of the door and partially close it until there is a
certain resistance. At this point the hinge lock should lock in and
allow the door to be lifted up and away from the cooker.

4. Take care not to damage the hinges - DO NOT force them.

5. When replacing the door repeat the process in reverse order.
Be careful to seat the hinges properly. If the door is crooked and the
hinges seem tight try again.

6. Check that the door is operating properly.

REMOVING THE DOOR ON THE AL, EM AND EB SERIES

1. Open the door completely

2. Using a small screwdriver ick up the hinge lock A on each hinge
and swing it into the slot.

A

3. Take the weight of the door and partially close it until there is a
certain resistance. At this point the hinge lock should lock in and
allow the door to be lifted up and away from the cooker.

4. Take care not to damage the hinges - DO NOT force them.

5. When replacing the door repeat the process in reverse order.
Be careful to seat the hinges properly. If the door is crooked and the

DI/ML SERIES DOOR REMOVAL AND RE INSTALLATION

The DI and ML series of Glem and Emilia cookers have the latest oven door hinge design technology

from Glem Gas. For the removal and re-installation of the oven door with the new hinges please follow

these procedures.

CLICK AND SLIDE INNER GLASS REMOVAL - SOME MODELS

The models with the click and slide inner glass removal can be identified by the two
circular press points located towards the top of the inner door. This allows for easy glass
removal to clean the inside of the door.

12

3

5

DOOR REMOVAL AND RE INSTALLATION

Glem and Emilia cookers have the latest oven door hinge design technology from Glem
Gas. For the removal and re-installation of the oven door with the new hinges please

follow these procedures:

4

6

1. Open the door fully.

OPEN

150 mm

PULL

2. Rotate the hinge locking tab
usingyour finger or a small
screw driver.

LIFT UP

3. Tab in locked position. Repeat
the procedure on each hinge.

4. Hold the door as shown.
Close the door until there is a gap
of about 150mm at the top and pull

in the direction of the arrows. The
most pull should be at the lower
part of the door. Do not force it.

IMPORTANT:

Ensure that the bottom right corner of the inner glass reads VIT.

8 9

TO RE-INSTALL THE DOOR

IMPORTANT Hold the door at an angle so there is a 150mm gap at the top.

Hook the hinges in first with the groove in the bottom of the hinge sitting on the

roller housing

Once the hinges are located properly fully open the door again to allow unlocking of the
hinges and then you will be able to close the door.

OTE - ONCE YOU HAVE INSTALLED THE DOOR IF IT DOES NOT OPEN PROPERLY

N
REPEAT THE PROCEDURE. DO NOT FORCE THE DOOR AT ANY TIME.
