G.I.T POWERStart P8U-FM Owner's Manual
FEATURES AND OPERATIONS
REMOTE STARTER
ANTI-START SYSTEM – SECURITY SYSTEM
P8U-FM
P8U-FM
FEATURES AND OPERATIONS
REMOTE STARTER
ANTI-START SYSTEM – SECURITY SYSTEM
TRANSMITTER OPERATIONS
2
Arm & Lock the Doors
Disarm & Unlock the Doors
Enable / Disable audible
Start / Stop the Engine
DescriptionButton Function
AUX
Audible enable : confirmation 1 chirp / 1 or 3 flashes (dome light delay).
Audible disable : confirmation 1 or 3 flashes (dome light delay).
Audible enable : confirmation 2 chirps / 2 flashes.
Audible disable : confirmation 2 flashes.
Start and stop the remote starter.
Enable or disable the audible function. See note 1.
Enable : confirmation 1 chirp / 1 flash.
Disable : confirmation 2 flashes.
Panic Mode
Temporary Valet Mode
Enable / Disable
The Shock Sensor
Night Timer Mode
AUX
Activation of panique mode. See note 2.
Note : the engine should not be running.
The system temporary ignore the passive arming mode.
See note 3.
The engine will start every 3 hours.
See note 4.
Enable or disable the shock sensor. See note 5.
Enable : confirmation 1 chirp / 1 flash.
Disable : confirmation 2 flashes.
AUX
Auxiliary 1
Auxiliary 2
Trunk Opener
Auxiliary 3
AUX
Confirmation 1 or 6 flashes depending the programmation of the installer.
Confirmation 1 or 5 flashes depending the programmation of the installer.
Confirmation 1 or 4 flashes depending the programmation of the installer.
Allows to release the trunk.
Confirmation 1 or 3 flashes depending the programmation of the installer.
2 sec
2 sec
2 sec
2 sec
FEATURES AND OPERATIONS
Note 1 : Enable / Disable Audible
When the audible option is enabled, the system will chirp each time the system is armed or disarmed by the remote. To enable this option, the
following steps must be performed :
1. Disarm the system by pressing the unlock button .
2. Turn the ignition key to ON position (engine is not running).
3. If disabled, press once on the auxiliary button to enable this option (confirmation 1 chirp / 1 flash).
If enabled, press once again on the auxiliary button to disable this option (confirmation 2 flashes).
Note 2 : Panic Mode
The panic mode allows you to activate the horn or siren for a period of 30 seconds to scare away anyone prowling around your vehicle. In some
instances, it may also be used as a car finder. To activate this option, the following steps must be performed :
1. The engine should not be running.
2. Press 2 times (quickly) on the lock button . You will hear the horn or siren be triggered.
To deactivate the panic mode, press on any button (will deactivate the panic mode and execute the button function).
Note 3 : Temporary Valet Mode
When the temporary valet mode is activated, the system will ignore the passive arming mode (see the definition of passive arming at page 6). It
may be useful when you fill up some gaz or work on your vehicle and you don’t want the system arm by itself. To activate the temporary valet
mode, the following steps must be performed:
1. Disarm the system by pressing on the unlock button .
2. Press 2 times (quickly) on the unlock button . The parking lights will flash 5 times to confirm the entry to this mode.
By pressing on lock or unlock button, you will cancel this function.
3
