G.I.T PL-6000-TW-FM Series Owner's Manual

1

FEATURES AND OPERATIONS

TWO WAY FM COMMUNICATION

REMOTE STARTER & SECURITY SYSTEM

PL-6000-TW-FM Series

OWNER'S MANUEL

2

TRANSMITTER OPERATIONS

ONE WAY

FM TRANSMITTERS FOR

PL-6000 SERIES

TWO WAY LCD

FM TRANSMITTER FOR

PL-6000 SERIES

SLIDE

2

1

1 WAY FM

TRANSMITTER

2 WAY LCD FM
TRANSMITTER

FONCTIONS

:

Bt 1

ARM & LOCK THE DOORS (Silent mode)

, :

Bt 1, Bt 1

ARM & LOCK THE DOORS (Audible mode)

(2 sec):

Bt 1 (2 sec.)

PANIC MODE

:

Bt 2

DISARM & UNLOCK THE DOORS (Silent mode)

, :

Bt 2, Bt 2

DISARM & UNLOCK THE DOORS (Audible mode)

(2 sec) ou Option

Bt 2 (2 sec.)

TRUNK OPENER

:

Bt 3

ENGINE START / ENGINE STOP

, :

Bt 3, Bt 3

TEMPORARY VALET MODE

(2 sec):

Bt 3 (2 sec.)

EXTENDED RUNNING TIMER / COLD START

3

TRANSMITTER OPERATIONS

2 WAY LCD FM TRANSMITTER

F THEN Bt 2:

TEMPERATURE CHECK (optional)

F THEN Bt 3:

ENGINE START TIMER ACTIVATION

M THEN Bt 2:

OUTPUT # 3 ACTIVATION (pink)

M THEN Bt 1:

OUTPUT # 5 ACTIVATION (orange)

Bt 1 et Bt 3 (2 sec AT THE SAME TIME)

1

ST

OR 2ND VEHICLE SELECTION

Bt 1 et Bt 2 (2 sec AT THE SAME TIME)

TRANSMITTER ON / OFF

1 WAY FM TRANSMITTER

Option:

TRUNK OPENER

Option, Option:

OUTPUT # 5 ACTIVATION (orange)

Option (2 sec) :

OUTPUT # 3 ACTIVATION (pink)

SLIDE :

OUTPUT # 5 ACTIVATION (orange)

SLIDE, SLIDE :

OUTPUT # 3 ACTIVATION (rose)

, (2 sec AT THE SAME TIME)

1

ST

OR 2ND VEHICLE SELECTION

4

TWO WAY LCD TRANSMITTER OPERATIONS
