SP-10 POCKET SPIROMETER
User manual
ATTENTION: The operators must carefully read and completely
understand the present manual before using the product.
33536
CONTEC MEDICAL SYSTEMS CO., LTD
ADD: No 112 Qinhuang West Street,
Economic & Technical Development Zone,
Qinhuangdao, Hebei Province, 066004,
PEOPLE’S REPUBLIC OF CHINA
Made in China
Shanghai International Holding Corp. GmbH (Europe)
Eiffestrasse 80, 20537 Hamburg, Germany
Importato e distribuito da:
Gima S.p.A. - Via Marconi, 1 - 20060 Gessate (MI) Italy
M33536-GB-Rev.1-12.19
-40°C
55°C
50kPa
106kPa
0%
0123
95%
%
Dear users, thank you very much for purchasing the SPIROMETER.
Please read the User Manual carefully before using this product. The User Manual which describes the operating
procedures should be followed strictly. Failure to follow the User Manual may cause measuring abnormality,
equipment damage and human injury. The manufacturer is NOT responsible for the safety, reliability and performance issues and any monitoring abnormality, human injury and equipment damage due to users’ negligence of
the operation instructions. The manufacturer’s warranty service does not cover such faults.
Owing to the forthcoming renovation, the specic products you received may not be totally in accordance with the
description of this User Manual. We would sincerely regret for that.
This product is medical device, which can be used repeatedly.
WARNING:
For accuracy,it is recommended that the SPIROMETER should not be tested on the same testee for more than
5 times.
The testee should breathe out all air during testing, don’t exchange air or cough.
Don’t use the device in environment with lower temperature.
Automatic power off when there is no operation in one minute.
Please refer to the correlative literature about the clinical restrictions and caution.
This device is not intended for treatment.
Our company reserves the nal elucidative right.
2
3
Contents
Chapter 1 Safety ..................................................................................................................................................... 5
1.1 Instructions for Safe Operations ....................................................................................................... 5
1.2 Warning .............................................................................................................................................5
1.3 Attention ............................................................................................................................................6
1.4 Contraindication ................................................................................................................................6
1.5 EMC declaration ...............................................................................................................................7
Chapter 2 Overview ................................................................................................................................................ 8
2.1 Features ............................................................................................................................................8
2.2 Major Applications and Scope .......................................................................................................... 8
2.3 Environment Requirements ...............................................................................................................9
Chapter 3 Principle ................................................................................................................................................. 9
Chapter 4 Technical Specications.......................................................................................................................9
4.1 Main Performance .............................................................................................................................9
4.2 Main Parameters ............................................................................................................................. 10
Chapter 5 Installation ........................................................................................................................................... 11
5.1 View of the Front Panel ...................................................................................................................11
5.2 Assembly and disassembly ............................................................................................................11
5.3 Accessories .....................................................................................................................................12
Chapter 6 Operating Guide ..................................................................................................................................12
6.1 How to use ...................................................................................................................................... 12
6.1.1 Power on/off ..........................................................................................................................12
6.1.2 Measurement .........................................................................................................................12
6.1.3 Main Interface ........................................................................................................................ 13
6.1.4 Menu ...................................................................................................................................... 15
6.1.5 Repeated measure.................................................................................................................25
6.1.6 Charge ...................................................................................................................................26
6.1.7 Upload Data ........................................................................................................................... 26
6.2 Attention ..........................................................................................................................................27
Chapter 7 Maintenance,Transportation and Storage ........................................................................................27
7.1 Cleaning and Disinfection ............................................................................................................... 27
7.2 Maintenance ...................................................................................................................................27
7.3 Transportation and Storage ............................................................................................................28
Chapter 8 Troubleshooting ..................................................................................................................................28
Chapter 9 Key of Symbols ...................................................................................................................................30
Chapter 10 Parameter Introduction ....................................................................................................................31
Appendix I .............................................................................................................................................................32
4
5
Chapter 1
SAFETY
1.1 Instructions for Safe Operations
• Check the main unit and all accessories periodically to make sure that there is no visible damage that may
affect patient’s safety and monitoring performance. It is recommended that the device should be inspected
weekly at least. When there is obvious damage, stop using the device.
• All maintenance must be performed by qualied service engineers ONLY. Users are not permitted to maintain it
by themselves.
• The SPIROMETER cannot be used together with devices not specied in User Manual. Only the accessory that
is appointed or recommendatory by manufacture can be used with this device.
• This product has been calibrated before leaving factory.
1.2 Warning
Explosive hazard—DO NOT use the SPIROMETER in the environment with tinder such as anesthetic.
Please check the packing before use to make sure the device and accessories are totally in accordance with
the packing list, or else the device may have the possibility of working abnormally.
Don’t use the device in environment with strong electromagnetic interference, direct breeze source, cold source
and hot source.
Portable or mobile RF equipment with strong electromagnetic interference may inuence the accuracy of this
device.
Improper disposal of device and its accessories and packing (include mouthpiece, plastic bags, foams and
paper boxes) may cause environment pollution, please follow the local laws and regulations.
Please choose the accessories which are appointed or recommended by the manufacturer for avoiding device
damage.
Don’t use the device with the turbine of the same kind product.
DO NOT use the device when it is under charging state.
The red and green indicators are all highlight in charging state, the red indicator goes out when the charge has
nished.
1.3 Attention
Keep the SPIROMETER away from dust, vibration, corrosive substances, tinder, high temperature and mois-
ture.
If the SPIROMETER gets wet, please stop operation.
When it is carried from cold environment to warm or humid environment, please do not use it immediately.
DO NOT operate button on front panel with sharp things.
High temperature or high pressure steam disinfection to the device is not permitted. Refer to User Manual in
the relative chapter (7.1) for cleaning and disinfection.
Do not have the SPIROMETER immerged in liquid. When it needs cleaning, please wipe its surface with medical
alcohol by soft material. Do not spray any liquid on the device directly.
When cleaning the device with water, the temperature should be lower than 60°C.
The display period of data is less than 5 seconds, which is changeable according to the end rate.
When data can’t be displayed at all times or other cases happened during testing, press “repeated measure”
key to remeasure, or power off to restart.
The device has normal life for three years since the rst electried use.
When the data goes beyond the limits, the main screen shows “Error!”.
The device doesn’t suit all users, if you can’t get good measurement data, please stop using it.
The device needs to be calibrated once per year or less.
The device is forced SPIROMETER, according to the User Manual to use right to gain best result.
1.4 Contraindication
1.4.1 Absolute contraindication
The one with MI or shock in recent 3 months;
The one with serious cardiac function unstable or angina pectoris in recent 4 weeks;
6
7
The one with massive hemoptysis in recent 4 weeks;
The one who needs medication in epileptic seizure;
The one with uncontrolled hypertensive disease (SYS>200mmHg, DIA>100mmHg);
The one with aortic aneurysm;
The one with serious hyperthyroidism.
1.4.2 Relative contraindication
Heart rate >120 beats/min;
The one with pneumothorax or giant pulmonary bulla and not plan for surgical treatment;
The one with pregnancy;
The one with tympanic membrane perforation (need to block the ear canal of affected side before taking meas-
urement);
The one with RTI recently (less than 4 weeks);
The one with hypoimmunity.
Patients of respiratory communicable disease or infectious disease shall not take lung function examination in the
acute stage. The one with low immunity is not appropriate to take the examination also. If it is necessary, disease
control and protection shall be strictly followed.
1.5 EMC declaration
When this device is installed or putted into service, EMC should be paid more attention, as the portable and
mobile RF communications equipment with higher EM interference can affect this device.
The internal components and cables should not be changed, as this may decreased IMMUNITY of the device.
The SPIROMETER should not be used adjacent to or stacked with other equipments.
Chapter 2
OVERVIEW
Forced Vital Capacity is the maximum expiration after taking a full breath, it’s an important examination content in
chest-lung disease and respiratory health, and it is indispensable testing project in modern Pulmonary inspection.
At the same time, it has great signicance in respiratory diseases, differential diagnosis, treatment evaluation and
selection of surgical indications. Thus, with the rapid development of clinical respiratory physiology, clinical applications of lung capacity inspection are also gaining popularity.
The SPIROMETER is small in volume, low in power consumption, convenient in operation and portable. With
high-denition display screen, the device is concise and fashion. It is only necessary for patient to breath in fully
and seal the lips around the mouthpiece and blast the air out in best times for measure, then the display screen
will directly show the Forced Vital Capacity (FVC), Forced Expired Volume in one second (FEV1), Peak Expiratory
Flow (PEF) with the high veracity and repetition.
2.1 Features
1) Ultra-thin design, concise and fashion.
2) Small in volume, light in weight and convenient in carrying.
3) Low power consumption.
4) TFT display.
5) Reect lung function by measuring FVC, FEV1, PEF etc.
2.2 Major Applications and Scope
The SPIROMETER is a hand-held equipment for examining lung function. The product is t for hospital, clinique,
family for ordinary test. It’s only required that the user operates it according to user manual, no need for specialized training,so the operation of the device would be as simple and easy as possible.
8
9
2.3 Environment Requirements
Storage Environment:
Temperature: -40°C~+55°C
Relative humidity: ≤95%
Atmospheric pressure: 500hPa~1060hPa
Operating Environment:
Temperature: +10°C~+40°C
Relative Humidity: ≤80%
Atmospheric pressure: 700hPa~1060hPa
Chapter 3
PRINCIPLE
Firstly, testee deep inspires, then seals the lips around the mouthpiece and blasts all air out as forcefully as possible, the exhalant gas transforms to rotary airow by turbine, then makes the blade rotate. The reception part of the
infrared pair diodes (one is for infrared emission, the other is reception) towards to the blade is used for receiving
the infrared ray, when the blade rotates, the received ray strength of the reception diode will be different as the
difference of the blade angle, so form the various signal of same proportion in reception diode, which forms acquisition signal by SCM after processing. At last, various parameters to be measured formed from the information
which were processed by the microprocessor, and displayed from the screen.
Chapter 4
TECHNICAL SPECIFICATIONS
4.1 Main Performance
• Forced Vital Capacity (FVC), Forced Expired Volume in one second (FEV1), the ratio of FEV1 and FVC (FEV1%),
Peak expiratory ow (PEF), 25% ow of the FVC (FEF25), 75% ow of the FVC (FEF75) and average ow between 25% and 75% of the FVC (FEF2575) can be measured. Besides, the testee condition can be shown by
the ratio of the measured value and the predicted value.
• Flow rate-volume chart, volume-time chart display.
• Data memory, delete, upload and review.
• Trend chart display.
• Calibration.
• Information prompts when volume or ow goes beyond the limits.
• Automatic power off when there is no operation in one minute.
• Rechargeable lithium battery and with charging tips.
• Battery power display.
4.2 Main Parameters
Volume Range: 10L
Flow range: 0 L/s~16 L/s
Volume accuracy: ±3% or 0.05L (whichever is greater)
Flow accuracy: ±5% or 0.2L/s (whichever is greater)
Working current: 60mA
Power supply: DC3.7V 820mAh rechargeable lithium battery
Classication:
EMC: Group I Class B.
According to the MDD 93/42, the classication of this medical device: IIa.
The type of protection against electroshock: Internally powered equipment.
The degree of protection against electroshock: Type BF applied part .
International Protection: IPX0.
10
11
Chapter 5
INSTALLATION
5.1 View of the Front Panel
Turbine
Charging indicator
Power on/off;
conrm key
Figure 1 Front panel view
Up key
Down key
Repeated measure
5.2 Assembly and disassembly
1) Turbine assembly: Hold the turbine, align the arrowhead of the turbine with the triangular shape on the shell,
gently insert it to the bottom, counterclockwise rotate to lock it
2) Turbine disassembly: clockwise rotate the turbine, gently pull it out
3) Mouthpiece assembly: insert the mouthpiece into the turbine port directly
12
5.3 Accessories
1) A User Manual
2) A USB data line
3) A mouthpiece
4) A power adapter
5) A CD (PC software)
6) A nose clip (optional)
Other type adapter should meet the following conditions: output voltage: DC 5V; output current≥500mA, the
power adapter must meet the requirements of EN60601 related standards and have the CE mark.
Chapter 6
OPERATING GUIDE
6.1 How to use
6.1.1 Power on/off
1. After assembly, long press “power on” key to turn on the device.
2. When device is powered on, long press “power off” key to turn it off.
6.1.2 Measurement
1. The device is in [Selective interface] after turn on as shown in Fig.2, press “up” or “down” key to select “No”,
then press “conrm” key to enter [Testing] interface as shown in Fig.3. (Note: If select “Yes”, it will enter [Personal information] interface to edit personal information, after exit, it will return to [Testing] interface.)
2. In [Testing] interface, breath in fully, seal the lips around the mouthpiece and blast all air out as forcefully as
possible in a minimal amount of time, wait for a few seconds, the device will enter [Main parameter] interface
as shown in Fig.4.
13
Figura 2 Interfaccia “Selective” Figura 3 Interfaccia “Testing”
6.1.3 Main Interface
Case No.
Predicted value is a reference under
the situation that values (gender,
age, height, etc.) have been set.
It is a popularize value.
Ratio of measured
Health status
indicator
Figura 4 Interfaccia “Main parameter”
value and predicted
value
14
a. Main parameter interface: display the ratio of predicted value and measured value of three main parameters.
Ratio reects health status, correct settings of personal information is the key to obtain accuracy ratio. Besides,
this interface can also display battery status, time, case number and health status indicator, as shown in Fig.4.
b. Health status indicator: indicate the ratio of measured value and the predicted value, display the testee health
condition in image. I.e. Compare the measured value with the reference value in same situation. When the value
is lower than 50%, only red indicator is displayed, which means testee should pay attention and go to hospital
in time. When the value is in range from 50%-80%, red and yellow indicator are displayed, which means it
should be noticed. When the value is higher than 80%, all red, yellow and green indicator are displayed, which
means healthy. The determinate item of health status indicator is optional, it can be set in “Denote value” under
“Date management”.
c. Other parameter interface: display four parameters except the main parameter, as shown in Fig.5.
d. Under [Main parameter] interface, press “Up” or “Down” key will enter [Other parameter] [Flow rate-volume
chart] [Volume-time chart] in turn, as shown in Fig.5, 6, 7. The four interfaces above are [Main interface].
Figure 5 Other parameter interface Figure 6 Flow rate-volume chart Figure 7 Volume-time chart
15
6.1.4 Menu
Under [Testing] or [Main interface], press conrm key to enter [Menu] interface as shown in Fig.8. Under the interface, functions such as modify personal information, data management, device setting, power off can be realized.
Press “Up” or “Down” key to move the selection toolbar to the item that need to modied, then press “Conrm”
key to enter the sub-menu. See the following steps for details:
Figure 8 Menu interface Figure 9 Personal information interface
a. PERSONAL INFORMATION
Under [Menu] interface, select “Personal information” to enter its interface as shown in Fig.9, in which user can
edit patient information (Note: Under [Selective interface] as shown in Fig.2, if selected”Yes”, you can enter [Personal information]interface also.).
1. Case number
“Number” is the case number displayed at present. For example, if you are the 36th testee, the “Number” will
be 36. Case number can increase automatically, no need to set manually.
16
2. Gender setting
Under [Personal information] interface, press “Up” or “Down” key to move the selection toolbar to “Gender”,
then press “Conrm” key to select “female” or “male”.
3. Setting of age, height, weight
Under [Personal information], select “Age” to enter [Age edit] interface, as show in Fig.10. Press “Up” or “Down”
key to change the value. At each pressing of “Up” or “Down” key, the value will plus or minus 1. When long
press the“Up” or “Down” key, the value will increase or decrease continuously. Press “Conrm” key to back to
[Personal information] interface.
The modication of “Height” and “Weight” is similar to the “Age”. In which, range of “Age” is 6~100 years old,
range of “Height” is 80~240 cm, range of “Weight” is 15~250 kg.
Figure 10 Age edit interface
4. Nation setting
The modication of “Nation” is similar to the “Gender”. The standard of predicted value can be set under “Na-
tion” interface, which including ERS, KNUDSON and USA. ERS is the European standard, KNUDSON is the
Asian standard, USA is the American standard.
17
5. Setting of smoker and drug
The modication of “Smoker” and “Drug” is similar to the “Gender”, in which patient information of smoker and
drug can be modied.
For the display of screen is limited, the device won’t display all items at the same time. When selection toolbar
moved to “Smoker”, press “Down” key, the item of “Drug” and “Exit” will appear, as shown in Fig. 11, 12.
6. Exit
Under [Personal information] interface, select “Exit” to return to [Menu] interface.
Figure 11 Figure 12
b. DATA MANAGEMENT
Under [Menu] interface, select “Data management” to enter [Data management] interface, as shown in Fig.13.
Under the interface, functions such as review, view trend curve, delete data, denote value setting can be realized.
18
Figure 13 Data management interface Figure 14 Case selection interface
1. Review function
Under [Data management] interface, select “Review function” to enter [Case selection] interface as shown in
Fig.14, press “Up” or “Down” key (long press is available) to change case number, then press “Conrm” key,
the device will enter [Main interface] and display history data on it. Under [Main interface], press “Up” or “Down”
key continuously can review data in adjacent case number, press “Conrm” key to return to [Menu] interface.
2. Trend curve
Under [Data management] interface, select “Trend Curve” to enter [Trend curve selection] interface as shown in
Fig.15. Select the determinant parameter, then press “Conrm” key to enter [Trend curve display] as shown in
Fig.15. The curve is a summary of stored data for selected parameter. It displays the change trend in form of visual
image, which is convenient for comparison. If the data is too much, press “Up” or “Down” key to browse all data
trend curves orderly. Press “Conrm” key to return to [Data management] interface.
19
Figure 15 Trend curve selection interface Figure 16 Trend curve display interface
3. Delete data
Under [Data management] interface, select “Delete data” to en-
ter [Delete data] interface as shown in Fig.17. If choose “Yes”, the
screen displays “waiting...”, all data will be deleted, then return to
[Data management] interface. If choose “No”, it will return to [Data
management] interface directly.
Figure 17 Delete data interface
20
4. Denote value
Under [Data management] interface, select “Denote value” to enter [Denote value setting] interface as shown
in Fig.18. Select one parameter to decide the denote value, after that, it will automatically return to [Data management] interface.
Figure 18 Denote value setting interface
5. Exit
Under [Data management], select “Exit” to return to [Menu] interface.
c. SETTINGS
Under [Menu] interface, select “Settings” to enter [Settings] interface as shown in Fig.19. Under this interface,
settings of language, Bluetooth on/off, time and calibration, and view device information can be realized.
21
Figure 19 Setting interface Figure 20 Language setting interface
1. Language setting
Under [Settings] interface, select “Language” to enter [Language setting] interface as shown in Fig.20. Select
“English”, the device language will be English, select “中文”, the device language will be Chinese, after selected, it will automatically return to [Settings] interface
2. Bluetooth
Move selection toolbar to “Bluetooth”, press “Conrm” key to select “ON” or “OFF” that can turn on or off the
Bluetooth module (If there is no Bluetooth module in the device, the operation is invalid).
3. Time setting
Under [Settings] interface, select “Time” to enter [Time setting] interface as shown in Fig.21. Select “Minute”
to enter [Minute setting] interface, as shown in Fig.22. Press “Up” or “Down” key to change the value (long
pressing is available), then press “Conrm” key to return to [Time setting] interface.
The operation of “Hour”, “Day”, “Month”, “Year” is similar to the “Minute”. The “Week” will be calculated
according to “Year”, “Month” and “Day”, which does not need to set manually. Then select “Exit” to return to
[Settings] interface.
22
Figure 21 Time setting interface Figure 22 Minute setting interface
4. Calibration
Under [Settings] interface, select “Calibration” to enter [Calibration setting] interface as shown in Fig.23. Select
2L or 3L based on the volume of syringe, then enter to [Calibrate] interface as shown in Fig.24.
23
Figure 23 Calibration setting interface Figure 24 Calibrate interface
Under [Calibrate] interface, push the syringe once, the device will display “REPEAT”, then push the syringe once
again. After twice correct continuous operation, the calibrating will be succeed, and the device will display “OK!”.
Finally the interface will jump to the former interface before calibration (The former interface: If the device is
calibrated after measurement completed, it will return to [Settings] interface; if calibrated before measurement
completed, it will return to [Testing] interface.).
If the device displays “Error! Please repeat”, it indicates something wrong with the operation, please repeat the
calibrating until succeeded. If the device displays “Select right volume”, please conrm whether the volume of
syringe and calibration selection is accordant, then repeat the calibrating until succeeded. If you need to stop
calibrating, just press the“Conrm” key to exit to the former interface before calibration.
Under [Calibration setting] interface, select “Adjust” to enter [Adjusting] interface, as shown in Fig.25. Press “Up”
or “Down” key to change the value (long pressing is available), then press “Conrm” key to return to [Adjusting
conrm] interface, as shown in Fig.26. Selecting “Yes” will save adjusted value, selecting “No” will cancel the
setting, then the device will return to [Calibration setting] interface.
24
Note: The value determines the accuracy of measurement, please do NOT change it randomly. After
the turbine has been replaced, calibration shall be applied for inputting parameters of new turbine, which
guarantees the accuracy of measurement after turbine replaced.
Figure 25 Adjusting interface Figure 26 Adjusting conrm interface
Under [Calibration setting] interface, select “Exit” to return to [Settings] interface.
5. About device
Under [Settings] interface, select “About” to enter [About] interface. User can view device name and software
version. Press “Conrm” key to return to [Settings] interface.
6. Exit
Under [Settings] interface, select “Exit” to return to [Menu] interface.
25
d. POWER OFF
Under [Menu] interface, select “Power off”, the device will shut down.
Note: If there is no operation within 1 minute, the device will power off automatically.
e. EXIT
Under [Menu] interface, select “Exit” to return to [Main interface]. If the measurement is not completed before
enter [Main interface], it will return to [Testing] interface.
6.1.5 Repeated measure
Measurement of the device is repeatable. Long press “Repeated measure” key to enter [Testing] interface. When
the memory is full, it will display [Memory full] interface as shown in Fig.27. If you select “Yes”, it will enter [Delete
data] interface; if you select “No”, it will enter [Menu] interface.
Figure 27
6.1.6 Charge
There are two kinds of charging methods
1) Connect the device with computer by data line― then the device should be under charging state.
2) Connect the device with power supply by power adapter, then the device should be under charging state.
For device charging, connect it with the power where easy to be cut off, after charging completed, unplug
the power adapter to cut off from power.
6.1.7 Upload Data
Install the PC software in the computer, then the following gure will appear after completing.
Figure 28
1) Connect the device with computer by data line,double press the icon to open the PC software procedure.
2) Press the corresponding key to achieve upload data, delete case, print information, background, select language, switch PDF format, set the testee information etc.
3) Press “Exit” to exit the software, unplug the data line from the computer to achieve uploading.
26
27
6.2 Attention
Please check the device before using, and conrm that it can work normally.
Rechargeable lithium battery.
It is recommended that the device should be measured in room.
Excessive ambient light may affect measurement accuracy. It includes uorescent lamp, dual ruby light, infra-
red heater, direct sunlight and etc.
Intense activity of the subject or extreme electrosurgical interference may also affect the accuracy.
Please clean and disinfect the device after using according to the User Manual (7.1).
Chapter 7
MAINTENANCE,TRANSPORTATION AND STORAGE
7.1 Cleaning and Disinfection
Using medical alcohol to wipe the device for disinfecting, nature dry or clean it with clean soft cloth. It’s necessary
to clean the turbine periodically for accuracy, keep the diaphaneity of the lucency part, and keep it away sundries
(such as hair or lesser sediment). Immerse the turbine in disinfectant after use, clean it with clean water and dry
standing vertically after soaked a few minutes (but don’t make the turbine rinsed with water directly), this type
doesn’t bring pollution to environment. (Note: The disinfectant is 75% alcohol).
7.2 Maintenance
1) Please clean and disinfect the device before using according to the User Manual (7.1).
2) Please recharge the battery when the screen shows low-power (the battery power is ).
3) Recharge the battery soon after the over-discharge. The device should be recharged every six months when it
is not regular used. It can extend the battery life following this guidance. If the battery is broken, DO NOT try to
maintain it by yourself, please contact us or the local service center.
4) The device needs to be calibrated once a year (or according to the calibrating program of hospital). It also can
be performed at the state-appointed agent or just contact us for calibration.
28
7.3 Transportation and Storage
1) The packed device can be transported by ordinary conveyance or according to transport contract. The device
can not be transported mixed with toxic, harmful, corrosive material.
2) The packed device should be stored in room with no corrosive gases and good ventilation. Temperature:
-40°C~+55°C; Relative Humidity: ≤95%.
Chapter 8
TROUBLESHOOTING
Trouble Possible Reason Solution
The device can't nish
measurement for a long
time, and the data can't be
displayed.
The start speed is too low, the device does not measure.
The malfunction of the device. Press "Repeated Measure" key to remeas-
Remeasure according to the user manual.
ure, or power off to restart.
The gure is wrong and unorderly.
The device can not be powered on.
The power turned off abnormally. Delete the current case and remeasure.
Operation is wrong. Operate normally according to the user
manual.
The malfunction of the device. Please contact the local service center.
Low battery or no power. Please charge the battery.
The malfunction of the device. Please contact the local service center.
29
The display disappears
suddenly.
The device can not be used
for full time after charge.
The battery can not be full
charged even after 10 hours
charging time.
The device is set to automatic
power off when there is no operation in one minute.
The battery is drained away or almost drained away.
The battery is not full charged. Please recharge the battery.
The battery is broken. Please contact the local service center.
The battery is broken. Please contact the local service center.
Normal.
Please charge the battery.
30
Chapter 9
KEY OF SYMBOLS
Symbol Meanings
0123
Error
50kPa
%
0%
Follow instructions for use
Medical Device complies
with Directive 93/42/EEC
WEEE disposal
Type BF applied part
Full-power
Low-power
Measured value goes beyond
the limits
Status indicator bar
106kPa
Atmospheric pressure
limitation
95%
Humidity limitation
Symbol Meanings
55%
-40%
Store between -40 and 55°C
Fragile, handle with care
Keep in a cool, dry place
This way up
Date of manufacture
Product code
Lot number
SN
Serial number
Caution: read instructions (warnings)
carefully
Manufacturer
Authorized representative in the
European community
31
Chapter 10
PARAMETER INTRODUCTION
Measured parameters
Parameter Description Unit
FVC Forced vital capacity L
FEV1 Forced Expired Volume in one second L
PEF Peak expiratory ow L/s
FEV1 FEV1/FVC×100 %
FEF25 25% ow of the FVC L/s
FEF2575 Average ow between 25% and 75% of the FVC L/s
FEF75 75% ow of the FVC L/s
32
Appendix I
Guidance and manufacturer’s declaration – electromagnetic emissions- for spirometer
Guidance and manufacturer’s declaration – electromagnetic emission
The spirometer (SP10) is intended for use in the electromagnetic environment specied below. The customer of
the user of the spirometer (SP10) should assure that it is used in such an environment.
Emission test Compliance Electromagnetic environment – guidance
RF emissions CISPR 11 Group 1 The spirometer (SP10) uses RF energy only for its internal
RF emission CISPR 11 Class B The spirometer (SP10) is suitable for use in all establishments,
function. Therefore, its RF emissions are very low and are not
likely to cause any interference in nearby electronic equipment.
other than domestic establishments and those directly connected to the public low-voltage power supply network that
supplies buildings used for domestic purposes.
33
Guidance and manufacture’s declaration – electromagnetic immunity – for spirometer
Guidance and manufacture’s declaration – electromagnetic immunity
The spirometer (SP10) is intended for use in the electromagnetic environment specied below. The customer or
the user of SP10 should assure that it is used in such an environment.
Immunity test IEC 60601
Electrostatic
discharge (ESD)
IEC 61000-4-2
Power frequency
(50/60Hz) magnetic
eld IEC61000-4-8
test level
±6 kV contact
±8 kV air
3A/m 3A/m Power frequency magnetic elds Should be at lev-
Compliance
level
±6 kV contact
±8 kV air
Electromagnetic environment - guidance
Floors should be wood, concrete or ceramic tile. If
oor are covered with synthetic material, the relative humidity should be at least 30%.
els characteristic of a typical location in a typical
commercial or hospital environment.
34
Guidance and manufacturer’s declaration – electromagnetic immunity – for spirometer (SP10) that are not
LIFE-SUPPORTING
Guidance and manufacturer’s declaration – electromagnetic immunity
The spirometer (SP10) is intended for use in the electromagnetic environment specied below. The customer or
the user of spirometer (SP10) should assure that it is used in such an environment.
Immunity test IEC 60601
Radiated RF
IEC 61000-4-3
test level
3 V/m
80 MHz
to 2.5 GHz
Compliance
level
3 V/m Portable and mobile RF communications equipment
Electromagnetic environment - guidance
should be used no closer to any part of the spirometer
(SP10), including cables, than the recommended separation distance calculated from the equation applicable
to the frequency of the transmitter.
Recommended separation distance
d= 1.17 √P
d= 2.33 √P
Where P is the maximum output power rating of the
transmitter in watts (W) according to the transmitter
manufacturer and d is the recommended separation distance in metres (m).
80 MHz to 800 MHz
800 MHz to 2.5 GHz
35
Field strengths from xed RF transmitters, as determined
by an electromagnetic site survey,a should be less than
the compliance level in each frequency range.
b
Interference may occur in the vicinity of equipment
marked with the following symbol:
NOTE 1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption
and reection from structures, objects and people.
a. Field strengths from xed transmitters, such as base stations for radio (cellular/cordless) telephones and land
mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically
with accuracy. To assess the electromagnetic environment due to xed RF transmitters, an electromagnetic site
survey should be considered. If the measured eld strength in the location in which the SP10 is used exceeds
the applicable RF compliance level above, the SP10 should be observed to verify normal operation. If abnormal
performance is observed, additional measures may be necessary, such as reorienting or relocating the SP10.
b. Over the frequency range 150 kHz to 80 MHz, eld strengths should be less than 3 V/m.
36
Recommended separation distances between portable and mobile RF communications equipment and
the spirometer (SP10)
Recommended separation distances between portable and mobile RF communications equipment and
the spirometer (SP10)
The spirometer (SP10) is intended for use in an electromagnetic environment in which radiated RF disturbances
are controlled. The customer or the user of the spirometer (SP10) can help prevent electromagnetic interference by
maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and
the spirometer (SP10) as recommended below, according to the maximum output power of the communications
equipment.
Rated maximum output
power of transmitter
(W)
0,01 0,12 0,12 0,23
0,1 0,37 0,37 0,74
1 1,17 1,17 2,33
10 3,70 3,70 7,37
100 11,70 11,70 23,30
For transmitters rated at a maximum output power not listed above, the recommended separation distance d
in metres (m) can be estimated using the equation applicable to the frequency of the transmitter, where P is the
maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer.
NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption
and reection from structures, objects and people.
Separation distance according to frequency of transmitter (m)
150 kHz to 80 MHz 80 MHz to 800 MHz 800 MHz to 2.5 GHz
d= 1.17 √P d= 2.33 √Pd= 1.17 √P
37
Disposal: The product must not be disposed of along with other domestic waste. The users must dispose
of this equipment by bringing it to a specic recycling point for electric and electronic equipment. For
further information on recycling points contact the local authorities, the local recycling center or the shop
where the product was purchased. If the equipment is not disposed of correctly, nes or penalties may be
applied in accordance with the national legislation and regulations.
GIMA WARRANTY CONDITIONS
Congratulations for purchasing a GIMA product. This product meets high qualitative standards both as regards
the material and the production.
The warranty is valid for 12 months from the date of supply of GIMA.
During the period of validity of the warranty, GIMA will repair and/or replace free of charge all the defected parts
due to production reasons.
Labor costs and personnel traveling expenses and packaging not included.
All components subject to wear are not included in the warranty.
The repair or replacement performed during the warranty period shall not extend the warranty. The warranty is
void in the following cases: repairs performed by unauthorized personnel or with non-original spare parts, defects
caused by negligence or incorrect use. GIMA cannot be held responsible for malfunctioning on electronic devices
or software due to outside agents such as: voltage changes, electro-magnetic elds, radio interferences, etc.
The warranty is void if the above regulations are not observed and if the serial code (if available) has been removed, cancelled or changed.
The defected products must be returned only to the dealer the product was purchased from. Products sent to
GIMA will be rejected.
38
39
Loading...
