Oscillo-Saw GOLD II
EN
HB 8894-A
HB 8894-B
HB 8894-G
HB 8894-S
HB 8894-V
Oscillating cast cutting saw
HEBU Oscillo-Saw GOLD II
Content
1 Scope of delivery ..................................................................................................................................... 17
2 Safety remarks ......................................................................................................................................... 17
3 Scope ....................................................................................................................................................... 18
3.1 Inteded Use ..................................................................................................................................... 18
3.2 Contraindication .............................................................................................................................. 18
4 Mounting / exchanging the saw blade ..................................................................................................... 18
4.1 Releasing the retaining screw / removing the old saw blade .......................................................... 18
4.2 Inserting the new saw blade............................................................................................................ 19
5 Operation ................................................................................................................................................. 19
5.1 Opening plaster casts ..................................................................................................................... 20
6 Cleaning and maintenance ...................................................................................................................... 21
7 Accessories .............................................................................................................................................. 21
8 Spare Parts .............................................................................................................................................. 22
9 Servicing .................................................................................................................................................. 22
9.1 Saw head ........................................................................................................................................ 22
9.2 Saw motor ....................................................................................................................................... 23
10 Warranty .................................................................................................................................................. 25
11 Environmental protection ......................................................................................................................... 25
12 Specifications ........................................................................................................................................... 25
13 Manufacturer and aftersales service address .......................................................................................... 25
15
Oscillo-Saw GOLD II
EN
HEBU
Oscillo-Saw
GOLD II
16
Oscillo-Saw GOLD II
EN
HB 8894
HEBU oscillating cast cutting saw GOLD II
HB 8895-02
Circular saw blade, dia. 50 mm, x-bite
HB 8896-02
Circular saw blade, dia. 65 mm, x-bite
E 8894-01
2x fork wrenches
Operating instructions
!
Before using the saw, carefully read through these operating instructions and the
valid national occupational safety regulations and act accordingly.
Please keep these operating instructions for later reference and always include them if
the device is sold or passed on to third parties.
!
Application in accordance with the intended application:
This device is intended for sawing open plaster casts.
!
Never rivet or screw signs or symbols onto the device, as this can render the
protective insulation ineffective. We recommend using adhesive signs.
!
Only ever use undamaged plugs and cables.
Check cables and plugs regularly.
!
The mains voltage and specified voltage rating shown at the device must be in
agreement.
!
Only ever use original accessories.
!
Wear personal protective gear such as protective goggles,
ear protectors and gloves.
!
The device must not be operated in areas at risk from explosion.
!
Any serious incident that has occurred in relation to the device should be
reported to the manufacturer and the competent authority of the Member State in
which the user and/or patient is established.
1 Scope of delivery
2 Safety remarks
Our products are exclusively intended for professional use by appropriately trained and qualified
personnel and may only be acquired by them.
All safety remarks in these operating instructions are marked with the symbol !.
17
Oscillo-Saw GOLD II
EN
!
Danger of injury due to unintentional activation. Pull out the plug before
changing the saw blade. If applicable use thick gloves to prevent injury
when handling the saw blade. Only ever connect the HEBU oscillating cast
cutting saw to the mains when it is switched off.
3 Scope
The use of oscillating plaster saws mainly takes place in orthopaedics for plaster removal.
3.1 Inteded Use
A hand-held, current-driven (AC) product for cutting gypsum or synthetic material usually during the
removal of a plaster cast. The proximal end (the handle) is usually cylindrical, while the distal end
terminates in a round, crescent-shaped, or circular blade suitable for cutting plaster casting material. The
leaves cut as an electric motor in the handle drives them (swinging). The cut is done by vibration rather
than by sawing.
3.2 Contraindication
There are no known contraindications.
4 Mounting / exchanging the saw blade
4.1 Releasing the retaining screw / removing the old saw blade
1. Place the cast cutting saw on a stable underlay (table).
2. Apply one fork wrench at the drive shaft behind the saw blade,
and the other one at the front at the retaining screw (see fig. 1).
3. Hold the rear wrench firmly and use it to fix the cast cutting saw.
4. Release the retaining screw using the front wrench.
5. Remove the retaining screw and the fixing ring.
Ensure that you do not lose any components.
6. If applicable, remove the old saw blade.
18
Releasing the retaining screw
Fig. 1:
Oscillo-Saw GOLD II
EN
Fig. 3
Fig. 4
I
O
4.2 Inserting the new saw blade
1. Check that the female thread and saw blade support of the drive shaft are clean.
2. Position the new saw blade.
It makes no difference which side of the saw blade is facing inwards or outwards.
Important!
The notches in the saw blade must be positioned precisely flush on the spigots of the
drive shaft.
3. Position the fixing ring. The notches in the fixing ring must always be pointing towards
the saw (see fig. 2). These must also be positioned precisely on the spigots.
4. Screw the retaining screw in manually until hand tight.
5. Then tighten firmly using the fork wrench, as described above.
The tightening torque is 6 - 7 Nm. Caution! Do not overtighten.
Fig. 2:
Inserting the saw blade
5 Operation
Switching on and off (see fig. 3)
Switching on: Push the switch forwards ( I )
Switching off: Push the switch back ( 0 )
Setting the oscillating frequency (see fig. 4)
Select the oscillating frequency when the motor is running.
The optimum oscillating frequency can be selected at the s
peed gauge depending on the properties of the plaster cast.
Oscillating frequency preselection using the electronic
speed gauge.
Lowest oscillating frequency ( 1 )
Highest oscillating frequency ( 8 )
19
Oscillo-Saw GOLD II
20
EN
5.1 Opening plaster casts
First select a suitable saw blade.
Apply the HEBU oscillating saw with the saw blade mounted to the cast you wish to open and
press in lightly. Your guiding hand can be used as a support and for depth control, and to
prevent sudden penetration of the blade when the cast has been cut through.
As long as the saw blade is cutting through the plaster, you will be able to feel a resistance.
Once the plaster cast has been cut through, this resistance disappears. Once the breakthrough
point is tangible, lift the saw blade off lightly without removing it from the cutting groove and
move it forwards appr. 15 mm in the direction of cutting.
Then apply the blade again and proceed as described above until the next piece has been cut
through.
In this way, the plaster cast is more safely opened through a series of cuts and linear
movements along the cutting line than would be the case if executing a continuous linear cut.
After you have used the saw only a few times, you will become accustomed to guiding the saw
through the plaster cast and you will also develop an instinctive feel for the moment where no
further resistance is tangible and no further pressure should be applied to the saw blade.
If the saw blade oscillates for too long on the wadding, high-speed oscillation can bring about a
burning sensation on the skin under the wadding.
Additional remarks:
◼ Because different materials are used, every plaster or plastic cast has different properties.
While working, try to determine the optimum speed for the respective material.
◼ A lower speed is advantages when cutting through plastic casts. This prevents the plastic from
starting to melt due to friction heat generated during cutting.
◼ Where possible, avoid cutting through plaster casts without wadding when using the HEBU
oscillating cast cutting saw.
Injuries can result if the skin has become stuck to the plaster, and so does not oscillate with
the saw blade.
Where a plaster cast close to the skin is preferred, we recommend laying a knitted or felt strip
along one side of the arm or leg and drawing a line precisely above this strip on the surface of
the plaster cast using indelible ink.
When sawing open the cast, this line can be used as guiding mark.
◼ When applying a plaster cast following surgery, the position of the operation wound should be
marked on the surface of the plaster cast. This will allow a window to be cut subsequently in
the plaster for removing stitches and observation of the wound.
◼ Cutting a window in the plaster also simplifies the extraction of bone nails and also facilitates
any necessary punctures or incisions.
◼ Metal rails inserted in the plaster cast should not be cut.
◼ While serving, check the retaining screw for a firm fit and if necessary tighten.
◼ If the motor is overloaded, the device is automatically switched off. The fuse (see fig. 9 on
page 24, item 110) is located on the electronic circuit board (see fig. 7 on page 24,
item 110) and can be quickly and easily exchanged after unscrewing the housing.
◼ Used and blunt saw blades place excessive stress on the motor and should consequently be
continuously checked and exchanged in good time.
◼ To ensure even wear of the saw blade, open the retaining screw and turn the saw blade
by 90°.
Oscillo-Saw GOLD II
EN
!
Danger of injury through unintentional
activation. Pull out the plug before any
cleaning or main-tenance work.
HB 8899-01
Transportation case with insert
HB 8889-01
Retrofit kit (vacuum cleaner, hose, suction unit, tool), 220-240V
HB 8889-01V
Retrofit kit (vacuum cleaner, hose, suction unit, tool), 100-120V
HB 8878-01
Patent Screw
HB 8877
Special grease, 8 g tube
HB 8895-03
Round saw blade TITANIUM, 50 mm
HB 8896-03
Round saw blade, TITANIUM, 65 mm
HB 8895-04
Round saw blade “non-stick”, 50 mm
HB 8896-04
Round saw blade, “non-stick”, 65 mm
HB 8897-01
Round saw blade, 44 mm, for plaster
HB 8897-02
Round saw blade, 44 mm, x-bite
HB 8895-01
Round saw blade, 50 mm, for plaster
HB 8895-02
Round saw blade, 50 mm, x-bite
HB 8896-01
Round saw blade, 65 mm, for plaster
HB 8896-02
Round saw blade, 65 mm, x-bite
HB 8898-01
Round saw blade, 80 mm, for plaster
HB 8898-02
Round saw blade, 80 mm, x-bite
HB 8893-01
Deep saw blade, 70 mm, for plaster
HB 8893-02
Deep saw blade, 70 mm, x-bite
HB 8892-01
Segmental saw blade, 65 mm, for plaster
HB 8892-02
Segmental saw blade, 65 mm, x-bite
HB 8890-01
Waisted saw blade, 65 mm, for plaster
HB 8890-02
Waisted saw blade, 65 mm, x-bite
Fig. 5
6 Cleaning and maintenance
The following measures should be performed once a week
or more often if the saw is used frequently: Clean the
cooling slots (see fig. 5) to ensure sufficient ventilation for
cooling the motor. Clean the motor compartment from the
outside with a jet of dry compressed air.
Wipe disinfection is suitable for motor housing, cable, power plug and all accessories, such as saw
blades and an open-end wrench. For this purpose, we recommend products with a pH-value within 9-10,
e.g. MediClean forte from Dr. Weigert.
It is important to ensure that the device is disconnected from the power supply and the disinfecting liquid
does not enter the interior of the motor.
7 Accessories
21
EN
8 Spare Parts
E 8894-01
Fork wrench
E 8894-02
Retaining screw
E 8894-03
Fixing ring
Pos.
Pc.
Description
GOLD II
50-60Hz / 220-240 V
50-60Hz / 110-120 V
HB 8894
HB 8894V
10 1 Saw head housing
E 8810-00GO
20 1 main shaft / Fork
E 8810-20/1
30 1 Front floating bearing
E 8810-12
40 2 Head Screw with washer
E 8810-13
50 1 Back floating bearing
E 8810-15/1
60
1
retaining ring
E 8810-20/2
70 2 Bearing screw
E 8810-19
9 Servicing
9.1 Saw head
(Drawing items refer to fig. 6)
Oscillo-Saw GOLD II
Fig. 6:
Explosion view of the saw head
22
Oscillo-Saw GOLD II
EN
Pos.
Pc.
Description
GOLD II
50-60Hz / 220-240 V
50-60Hz / 110-120 V
HB 8894
HB 8894V
10
1
Motor housing
E 8820-00SW
E 8820-00SW
20
1
Switching rod
E 8820-01
E 8820-01
30
1
Switching slide
E 8820-02
E 8820-02
40 1 Pole housing with winding
E 8820-03
E 8820-04
50 2 Ejot Delta PT screw
E 8820-05
E 8820-05
60
1
Air guiding ring
E 8820-06
E 8820-06
70
2
Brush holder
E 8820-07
E 8820-07
75
2
Plug connector
E 8820-08
E 8820-08
80
2
Carbon brush
E 8820-09
E 8820-09
90
1
Contact spring
E 8820-10
E 8820-10
110
1
Electronic circuit
E 8820-11
E 8820-12
115
1
Fuse
E 8820-13
E 8820-14
116 1 Pressure pad for fuse
E 8820-15
E 8820-15
130 1 Cable clamping bridge
E 8820-16
E 8820-16
150
1
Lid
E 8820-17SW
E 8820-17SW
155 1 Pressure pad for lid
E 8820-18
E 8820-18
160 1 Ejot Delta PT screw
E 8820-19
E 8820-19
170 5 Ejot Delta PT screw
E 8820-20
E 8820-20
190
1
Protective hose
E 8820-21
E 8820-21
250
1
Anchor
E 8820-22
E 8820-23
260 1 Deep groove ball bearing
E 8820-26
E 8820-26
270 1 Deep groove ball bearing
E 8820-27
E 8820-27
300 1 Intermediate bearing
E 8820-28
E 8820-28
310
1
Bearing bush
E 8820-29
E 8820-29
320 1 Deep groove ball bearing
E 8820-32
E 8820-32
330 4 Ejot Delta PT screw
E 8820-34
E 8820-34
340
1
Parallel pin
E 8820-36
E 8820-36
180 1 Cable standard “Europe”, 3-pin
E 8825-01
-
180 1 Cable "USA", 2-pin
-
E 8825-02-V
180 1 Cable "Australia", 3-pin
E 8825-03-A
-
180 1 Cable "USA", 3-pin
-
E 8825-04-W
180 1 Cable "UK", 3-pin
E 8825-05-G
-
180 1 Cable "Switzerland", 2-pin
E 8825-06-S
-
180 1 Cable „Aspiration“, 2 pin
E 8825-07-C
-
180 1 Cable „Aspiration“, 2 pin
-
E 8825-07-CV
9.2 Saw motor
The drawing items refer to fig. 7 to 9, next page.
23
Oscillo-Saw GOLD II
EN
Fig 8:
Motor terminal plan
Fig 9:
Electronic circuit
without lid
electronics
supply
motor
24
Fig 7:
Motor drawing
Oscillo-Saw GOLD II
EN
Model
HB 8894 (A / G / S)
HB 8894 (B / V)
Mains connection
220-240 Volt, 50/60 Hz.
110-120 Volt, 50/60 Hz.
Rated current consumption
250 Watt
250 Watt
Current type
1 ~
1 ~
Oscillations
ca. 12000 - 21000 min -1
ca. 12000 - 21000 min -1
Weight
1,2 kg
1,2 kg
Protection class
II
II
IP Code
IP2X
Noise level (A-graded)
Typically 75 dB (A).
The noise level during sawing can exceed 85 dB (A).
From 85 dB (A), wear ear protectors!
Hand-arm vibration
Typically lower than 2.5 m/s2.
Measured values determined in accordance with EN 50 144.
10 Warranty
We provide a guarantee for HEBU cast cutting saws in accordance with statutory and countryspecific legislation (proof of purchase by invoice or delivery note). The minimum warranty period
is 18 month. In the event of material or production defects, we provide free repair of the device.
Any attempt to carry out unauthorized repairs will result in forfeiture of your warranty cover.
Damage caused by incorrect handling, overloading or normal wear and tear is not covered by
the warranty. Please contact our aftersales service department.
In case of warranty claims and repairs, please enclose a copy of the invoice or delivery note
with the device.
11 Environmental protection
Any packaging materials, disused devices and accessories must be sent for
environmentally friendly recycling or disposal. Electrical devices may not be
disposed of with the household waste but taken to the local disposal and
recycling facility for electrical devices.
For more information on this subject, consult your specialist dealer.
12 Specifications
13 Manufacturer and aftersales service address
HEBU medical GmbH
Badstraße 8
78532 Tuttlingen
Germany
Tel: +49 74 61 / 94 71 - 0
Fax: +49 74 61 / 94 71 - 22
eMail: service@HEBUmedical.de
Web: www.HEBUmedical.de
25
Notizen / Notes / Note / Noticias / Notizie
_______________________________________________________________________________________
_______________________________________________________________________________________
_______________________________________________________________________________________
_______________________________________________________________________________________
_______________________________________________________________________________________
_______________________________________________________________________________________
_______________________________________________________________________________________
_______________________________________________________________________________________
_______________________________________________________________________________________
_______________________________________________________________________________________
_______________________________________________________________________________________
_______________________________________________________________________________________
_______________________________________________________________________________________
_______________________________________________________________________________________
_______________________________________________________________________________________
_______________________________________________________________________________________
_______________________________________________________________________________________
_______________________________________________________________________________________
_______________________________________________________________________________________
_______________________________________________________________________________________
_______________________________________________________________________________________
63
HEBUmedical GmbH
Badstraße 8 • 78532 Tuttlingen / Germany
Tel. +49 (0) 7461 94 71 - 0 • Fax +49 (0) 7461 94 71 - 22
info@HEBUmedical.de • www.HEBUmedical.de
Unser umfangreiches Sortiment umfasst
über 10 000 verschiedene Instrumente.
Besuchen Sie uns im Internet oder fordern Sie unseren Katalog an.
Our vast range of products covers over 10 000 various instruments.
They can be found in Internet or request our catalog.
Notre assortiment complet comprend
plus de 10 000 instruments differents.
Vous le trouverez sur Internet. Ou bien demandez notre catalogue.
Nuestro amplio instrumental consta de más de 10 000 artículos
diferentes. Usted puede consultarlo en Internet
o solicitor nuestro catálogo.
Il nostro assortimento comprende più di 10 000 strumenti differente.
Lei ci può vistare in Internet
o chieda il nostro catalogo.
GAOS008V009 / 27.07.2021
Loading...
