Gima GIMA GD-301 EVO SEALING MACHINE User guide

Instructions manual v .1.0

GD 301 Evo

Constant heat sealer

Translation from original instructions

GD 301 Evo rev.1.0

FOREWORD

This machine is part of the Gandus Saldatrici product range. Thanks to our modern
production, assembly and testing methods and many years of experience Gandus
Saldatrici machines satisfy the highest quality requirements.

This user manual includes:

 Safety instructions
 Instructions for installation and use
 Instructions for maintenance and repair
 Troubleshooting
 Technical data
 Declaration(s)

Using this manual will:

 Make it easier to get used to working with the machine
 Prevent malfunctions caused by non-professional use

Please observe the maintenance instructions, as they will:

 Enhance the machine’s reliability
 Extend the machine’s service life
 Reduce the costs of repair and shutdown of operations

Gandus Saldatrici will not accept liability for damage to this machine if:
 The machine is not operated in accordance with the instructions presented in this

user manual.

 The machine is used for any purpose other than that specified in this user manual.

(see safety instructions).

The guarantee expires in the event of:

 Faulty operation
 Failure in the scheduled maintenance
 Deviating dimensions

CAUTION!
The user manual should always be kept in the direct vicinity of the machine.

Only operate the machine after careful study of the user manual.
Please observe the safety instructions and instructions for preventing accidents under

all circumstances.

If you need to use spare parts, use only original Gandus Saldatrici parts for your
own safety.

This Gandus Saldatrici machine was built in accordance with current technical
rules and regulations.

1

CAUTION: danger

CAUTION: specific warning

CAUTION: maintenance advice

Symbols in the user manual:

GD 301 Evo rev.1.0

2

GD 301 Evo rev.1.0

Operation of the machine by untrained personnel could lead to
serious personal injury and considerable damage.

Gandus Saldatrici cannot be held liable for damage caused by
individuals not authorised to operate the machine.

If in doubt about the correct operation of the machine, consult
maintenance personnel immediately.

When working on the machine, all maintenance personnel are
obligated to work in accordance with the manual.

All specialist work is to be performed exclusively by persons
authorised to perform these tasks as specified in the relevant
sections of the manual.

The user

This manual is meant to be used by different users. However, all operators must
observe the following restrictions.

Operating personnel

Operating personnel must be trained, through a training programme or by the operator,
to perform the designated tasks and be aware of the consequences that can arise from
use by untrained individuals. The machine may not be operated by persons under the
influence of alcohol, medicines and/or drugs.

Installation, maintenance and repairs require specialist training and may only be carried
out by maintenance personnel.

Maintenance personnel

Based on professional training, knowledge and experience and the applicable
regulations set down by the manufacturer, maintenance personnel has been trained to
carry out the designated tasks and identify potentially dangerous situations
independently.

3

GD 301 Evo rev.1.0

All rights reserved. Nothing from this edition is allowed to be copied and/or made public
by means of print, photo copy or any other way without previous written permission of
Gandus Saldatrici .

Gandus Saldatrici reserves the right to change spare parts and/or specifications without
previous notice. Contents of this manual can also be changed without previous warning.

Gandus Saldatrici cannot be hold responsible for eventual damage caused by
specifications deviating from the standard model.

Although extreme care has been exercised during writing this manual, Gandus
Saldatrici will not accept any liability for eventual errors in this manual and/or for the
consequences of (mis)interpretation of the contents.

Gandus Saldatrici is not responsible for damage or problems which result from the use
of other than the original spare parts. If this manual has not been supplied with
instructions for certain repairs, adjustments and maintenance, you should contact your
dealer of Gandus Saldatrici .

4

GD 301 Evo rev.1.0

Table of contents

1 UNPACKING ............................................................................................................. 7

2 SAFETY INSTRUCTIONS AND PRECAUTIONS ..................................................... 7

3 GENERAL DESCRIPTION ...................................................................................... 12

4 DIMENSIONAL SKETCH ........................................................................................ 13

5 SPECIFICATIONS ................................................................................................... 13

5.1 OPERATING SPECIFICATIONS ................................................................................. 13

5.2 NON-PERMITTED APPLICATIONS ............................................................................. 13

6 INSTALLATION ...................................................................................................... 14

6.1 INSTALLATION ...................................................................................................... 14

6.1.1 Installation with a spindle ............................................................................. 15

6.1.2 Installation without a spindle ........................................................................ 15

6.1.3 Installing the work table ............................................................................... 16

6.1.4 Installing the cutter ....................................................................................... 16

6.2 CONNECTING THE MACHINE TO THE MAIN POWER SUPPLY ........................................ 16

7 OPERATING PARTS .............................................................................................. 17

7.1 SAFETY APPLICATIONS .......................................................................................... 17

8 OPERATION ........................................................................................................... 18

8.1 SWITCHING THE MACHINE ON ................................................................................. 18

8.2 SWITCHING THE MACHINE OFF ............................................................................... 18

8.3 SEALING .............................................................................................................. 19

8.3.1 Sealing prefabricated bags .......................................................................... 20

8.3.2 Making bags from a roll of foil ...................................................................... 20

9 MAINTENANCE ...................................................................................................... 21

9.1 GENERAL MAINTENANCE INSTRUCTIONS ................................................................. 21

9.2 MAINTENANCE SCHEDULE ..................................................................................... 22

9.3 REPLACING THE BLADE ......................................................................................... 23

10 TROUBLESHOOTING ......................................................................................... 24

10.1 CODES AND FAULT CODES FOR THE ON/OFF SWITCH ................................................ 25

10.2 DEACTIVATING THE BUZZER: .................................................................................. 25

11 RECOMMENDED SPARE PARTS ...................................................................... 26

12 TAKING OUT OF OPERATION, TRANSPORTATION AND STORAGE ............ 26

12.1 TAKING OUT OF OPERATION ................................................................................... 26

12.1.1 Switching off the main power supply ............................................................ 27

12.2 TRANSPORTATION AND STORAGE ........................................................................... 27

12.2.1 Transport ..................................................................................................... 27

12.2.2 Storage ........................................................................................................ 27

13 TECHNICAL DETAILS ......................................................................................... 28

5

GD 301 Evo rev.1.0

14 TO DISCARD ....................................................................................................... 29

15 CONDITIONS OF GUARANTEE .......................................................................... 29

15.1 LIABILITY .......................................................................................................... 29

15.2 GUARANTEE ..................................................................................................... 29

16 ELECTRICAL DIAGRAM....................................................................................30

6

GD 301 Evo rev.1.0

fig. 1 Identification plate

Please read the user manual carefully before operating the machine!

A

1 Unpacking

While unpacking the machine, use the following list to check if everything is present.

 The machine
 User manual
 Power supply cable
 Left and right foil roll holder
 Foil roll
 Foil guides (4x)
 Work table
 Bag containing:

 Hex key
 Phillips screwdriver
 Fasteners
 Covers (2x)

Check the data on the identification plate. (see fig. 1) near the power port and copy
them to the following figure.

The packaging materials used for this machine are environmentally friendly and can be
disposed of as regular household waste. We recommend keeping the packaging, so
that the machine can be transported safely if required in the future.

2 Safety instructions and precautions

Explanation of the warning icons:
A. Caution: hot parts on the inside of

the machine

Safety markings on the machine:

The safety markings are complete and have been applied to the machine in such a way
that they are easy to read. Please replace any damaged and illegible safety markings.

The machine can be dangerous for persons and objects if:

 The machine was not installed in accordance with the instructions;

7

GD 301 Evo rev.1.0

If the machine is used in a medically sterile environment and/or clean
room, the operator is responsible for compliance with the
regulations that apply specifically to that environment.

If the machine is used for the packaging of medical instruments, the
operator is responsible for compliance with the regulations that
apply specifically to the packaging of medical instruments.

 The machine has been placed in an unsuitable environment;
 The machine is not used properly;
 The machine has been modified or adapted in any way;
 The users do not meet the requirements;
 The safety instructions are not observed.

Remaining risks that cannot be avoided through technical adjustments:

 When feeding the foil into the machine fingers can get trapped under the seal bar.

Be certain to remove your fingers from underneath before closing the seal bar with
the operating lever.

 When feeding the foil into the machine your fingers may come into contact with the

seal bar. Do not touch the seal bar, as this may cause serious burns.

 Be careful not to touch the cutter blade during maintenance operations, as this may

cause serious injury.

 Beware of the danger of an electric shock. Your fingers may come into contact with

electrically charged parts during maintenance operations. Always switch off the
machine and disconnect it from the main power supply before carrying out
maintenance operations.

Of course, the following apply as well:

 The relevant safety regulations to prevent accidents;
 The general safety instructions;
 Any applicable local or regional regulations.

Making alterations and adjustments to the machine:

 If any alterations or adjustments are made to the machine by unauthorised

personnel, Gandus Saldatrici will no longer be able to guarantee the operational
safety of the machine.

 Gandus Saldatrici does not accept liability for any parts or special components not

supplied by Gandus Saldatrici (or any other goods not manufactured by Gandus
Saldatrici ).

 The assembly and/or installation of these articles could have a detrimental effect on

the passive safety of the machine.

 Gandus Saldatrici is not liable for damage caused by any components other than

the original components supplied by Gandus Saldatrici .

Using the machine for any special applications:

8

GD 301 Evo rev.1.0

The user must be thoroughly familiar with the equipment, working
method and operating elements of the machine.

All operators are required to use personal protective equipment.

If the above points are not in order, the machine may NOT be
switched on.

SWITCHING ON THE MACHINE
Before switching on the machine:

Please ensure the following points are in order before switching on the machine:
 The data on the identification plate corresponds with the voltage (V), frequency (Hz)

and the power rating (W) of the local power supply.

 The machine does not have any notable defects.
 The operating elements all function properly.
 No foreign objects have been placed in or on the machine.

9

GD 301 Evo rev.1.0

When working with the machine, the seal bars will be hot and can
cause serious burns if they come into contact with the skin.

The machine is equipped with a sharp blade. This can cause serious
injury.

Working with the machine:
 Use only sealable materials that are suitable for the machine. (See capitel Errore.

L'origine riferimento non è stata trovata.)

 Never open the cover of the machine while it is still connected to the power supply.
 If there is any doubt about the proper functioning of the machine, immediately

disconnect the machine from the main power supply and consult maintenance
personnel.

 Both the operator and the machine must be supervised throughout the operating

process.

 In the event of a malfunction, do not operate the machine until the fault has been

completely repaired.

 If any liquid is spilled onto the machine or an object falls into the machine, switch off

the machine and immediately disconnect the machine from the main power supply.
Have the machine checked by maintenance personnel before using it again.

 In the event of an unusual alarm, such as smoke emanating from the machine,

switch off the machine and immediately disconnect the machine from the main
power supply. Have the machine checked by maintenance personnel before using it
again.

In case of fire:

Never douse the machine with water if it catches fire. The machine is connected to the
power mains, so this could cause a life-threatening situation. A fire extinguisher must be
kept within reach of the machine at all times. The following types of fire extinguisher can
be used to extinguish the machine:

 Powder extinguisher
 Foam extinguisher

Switching off the machine:

 Switch off the machine when it is not in use.
 If the machine will not be used for a long period of time, disconnect the machine

from the main power supply.

Maintenance and repairs:

 Maintenance and repairs to the machine require specialist training and may only be

carried out by authorised maintenance personnel.

 Unauthorised persons may not perform maintenance tasks.
 Switch off the machine and disconnect it from the main power supply before carrying

out maintenance operations.

 Do not clean the machine with water, abrasives, chemical solvents or other fluids.

10

GD 301 Evo rev.1.0

The machine contains high voltage parts, which may cause electric
shock or serious personal injury.

The machine contains hazardous moving parts, which may cause
serious personal injury.

When performing maintenance tasks or repairs, remember that the
seal bars are still hot immediately after use. Touching these can
cause serious burn injuries.

Maintenance work on the electrical wiring:

Switch off the machine and disconnect it from the main power supply before carrying
out maintenance operations to the electrical wiring. Be absolutely certain that there is no
power supply to the machine. Place a warning sign on the machine to ensure that no
one switches it on.

11

GD 301 Evo rev.1.0

The GD 301 Evo can only seal laminated foil and/or plastic bags that
can withstand steam sterilisation.

3 General description

The GD 301 Evo is a heat sealer for the packaging of medical instruments in laminated
foil. After the instruments have been placed in a bag, the bag is sealed. The bag is
placed under the seal bar, which is closed by manually pulling down the operating lever.
This causes the seal bar to shut, sealing the bag in just a few seconds. Once the bag
has been sealed, the instruments in the sealed bags can be sterilised in a steam
autoclave.

The GD 301 Evo is easy to operate. After the machine has been switched on, the seal
bar will start heating to the standard sealing temperature. This takes only a few minutes.
The machine will start sealing immediately after the seal bar has been lowered by
means of the operating lever. After 4 seconds the on/off switch will start to blink and the
sealer will emit a sound signal. The MHS switches off automatically if it is not used for
30 minutes.

The GD 301 Evo uses prefabricated plastic bags as well as rolls of laminated foil.
Plastic bags can be made to measure from this foil, which can be cut to the dimensions

of your choice with the machine’s integrated cutter. The machine seals bags in all foil

widths, up to the maximum width of the seal bar.
The machine can seal laminated foil and/or plastic bags that are suitable for steam

sterilisation.

Sealing cycle

The complete sealing cycle of the machine comprises the following steps:

 Insert the laminated foil bag into the machine under the seal.
 Pull the operating lever to close the seal bar.
 Cut off the excess foil above the seal by sliding the cutter back and forth.
 After 4 seconds the on/off switch will start to blink and the machine will emit a sound

signal. The seal is ready.

 Open the seal bar and take the bag out of the machine. Your packaged instruments

can now be sterilised in a steam autoclave.

12

fig. 2 Dimensional sketch

4 Dimensional sketch

GD 301 Evo rev.1.0

5 Specifications

5.1 Operating specifications

- Operating speed: Max. 12 runs per minute

- Ambient temperature: +5 . . .+40 Celsius

- Relative humidity: 30% . . .95% rel. (without condensation)

- Attachment, base : Rubber legs

- Extraction, ventilation: Use in a ventilated room

5.2 Non-permitted applications

- Use in an explosive environment

- Use in a freezer/walk-in refrigerator

- Packaging of toxic, corrosive or irritating substances

- Packaging of explosive materials

- Packaging of toxic, suffocating or irritating gases

- Packaging of hazardous dustlike products

13

The machine may only be installed by authorised maintenance
personnel. (see foreword).

Installing the machine under unauthorised circumstances may cause
lasting damage to some of its components.

All operators are required to use personal protective equipment.

Make sure that there is enough space around the machine to ensure
its safe operation, maintenance and repairs.

6 Installation

GD 301 Evo rev.1.0

6.1 Installation

Place the machine in a ventilated, well-lit room. Make sure that the machine is not
exposed to direct sunlight, extreme temperatures, moisture, dust or sand. The machine
must not be exposed to mechanical shocks or vibrations.

Place the machine on a sturdy, flat surface to ensure optimum stability.

14

fig. 3 Mounting the spindle to the work table

fig. 4 Installation without a spindle

6.1.1 Installation with a spindle

GD 301 Evo rev.1.0

Insert the nut (6) into the groove at the bottom of the spindle holders (3 and 7).
Next, slot the spindle holders (3 and 7) into the grooves in the machine.
Screw both spindle holders onto the machine with the washer (4) and the bolt (5).
Insert the spindle (with a roll of foil) (2) into the spindle holders (3 and 7).
Mount the four foil roll guides (1) onto the spindle (2).

6.1.2 Installation without a spindle

15

GD 301 Evo rev.1.0

Caution: do not cut yourself! The blade is extremely sharp.

fig. 5 Connection point

1

Power port

Connect the machine only to a power supply with earth connection
and overvoltage protection that has been secured with max. 16A.

Insert the guards (1) into the grooves on the machine and attach them to the machine
with the screws (2).

6.1.3 Installing the work table

Slit the work table (8) in the grooves of the machine (see fig. 3).

6.1.4 Installing the cutter

Insert the cutter (with the blade) into the cutter guide groove at the top of the machine.
(see fig. 3).

6.2 Connecting the machine to the main power supply

Insert the female plug of the power cord into the power port (1) of the machine (see fig.

5).
Next, plug the power cord into the wall socket.

16

fig. 6 Operating parts

No.

Name

Function

1

On/off switch

To switch the machine on and off

2

Cutter

To cut the excess foil from above the seal
To cut foil to the desired size

3

Work table

To measure the foil on the roll

4

Operating lever

To close the seal bar and start the sealing process

5

Spindle

Spindle on which to place 1 or 2 rolls of foil

6

Foil guides

Keep the roll(s) of foil in place

fig. 7 Safety applications

7 Operating parts

GD 301 Evo rev.1.0

7.1 Safety applications

17

No.

Name

Function

1

Safety fuses

In the event of a short circuit, the machine will be
switched off by the two safety fuses (2 AT) on the print

2

Cutter

The cutter has been designed to ensure safe operation
of the blade

3

Heating
elements

Will not heat to temperatures above 190ºC

The machine may only be used by authorised personnel. (see
foreword).

Before switching on the machine, make sure that all the safety
features are present and functioning properly.

All operators are required to use personal protective equipment.

Operators must stand in front of the machine, within easy reach of
the on/off switch and the operating lever.

After an unexpected power failure, the machine will need to be
restarted manually by setting the on/off switch to ‘on’.

The MHS switches off automatically if it is not used for 30 minutes.

8 Operation

GD 301 Evo rev.1.0

8.1 Switching the machine on

To switch the machine on:
 Press on the on/off switch until the MHS emits a sound signal. The LED in the on/off

switch will now light up red, showing that the machine is warming up. See also
section 10.1 for troubleshooting steps for the on/off switch.

8.2 Switching the machine off

To switch the machine off:
 Press on the on/off switch until the MHS emits a sound signal. The LED in the on/off

switch will now extinguish, showing that the machine has been switched off.

18

Failure to carefully follow the seal cycle instructions below can
result in serious personal injury and/or material damage.

For the best possible result and ease of operation, the bag must be
filled by three quarters lengthwise and there must be at least 30 mm
of free space between the product and the inside of the seal.

Never place bags containing labels or adhesive tape between the
seal bars.

8.3 Sealing

GD 301 Evo rev.1.0

19

GD 301 Evo rev.1.0

fig. 8 Guiding the foil

8.3.1 Sealing prefabricated bags

1. Slide the cutter to the left.

2. Place the bag on the work table and insert the foil entirely under the seal bar.
Make sure that the transparent part is facing upwards during the sealing process.

3. Lower the seal bar by pushing the operating lever forwards.
The bag will now be sealed. After 4 seconds the machine will emit a sound signal
indicating that the sealing process has been completed.

4. Raise the seal bar by pulling back the operating lever.

5. Remove the bag from the work table.
The machine is now ready to seal the next bag.

8.3.2 Making bags from a roll of foil

1. Place a roll of foil on the spindle and clamp this between two foil guides so that
the roll will stay in place.
Make sure that the transparent side will be facing up during the sealing process.

2. Slide the cutter to the left.

3. Guide the foil from the rear of the machine underneath the seal bar.

4. Pull on the foil until it has reached the desired length.
The length can be measured on the work table.

5. Lower the seal bar by pushing the operating lever forwards.
The foil will now be sealed. After 4 seconds the machine will emit a sound signal
showing that the sealing process has been completed.

6. Cut the foil by sliding the cutter to the other side of the machine.

7. Raise the seal bar by pulling back the operating lever.

8. Remove the bag from the work table.
The bag can now be filled and subsequently sealed.

9. If no bags are made, remove the film between the seal bar.

20

Only authorised maintenance personnel are allowed to perform
repair work on the machine. (see foreword).

Always follow safety instructions carefully during maintenance
operations.

All operators are required to use personal protective equipment.

If you need to perform maintenance operations that are not
specified in this manual, please contact your dealer or Gandus
Saldatrici .

Before carrying out maintenance operations ensure that the
machine has been completely switched off. (see section 12.1).

When performing maintenance tasks or repairs, remember that the
seal bars are still hot immediately after use. Touching these can
cause serious burn injuries.

Do not clean the machine with water, abrasives, chemical solvents
or other fluids.

Note: please also follow the safety instructions for the cleaning
agents.

Make sure there is a repair kit near the machine with the
recommended spare parts. (see section 11) so that defective parts
can be replaced quickly and the production process will not be
interrupted longer than necessary.

9 Maintenance

9.1 General maintenance instructions

GD 301 Evo rev.1.0

21

GD 301 Evo rev.1.0

Component

Description

Machine

Clean the exterior of the machine with a damp cloth and soft
soap

Machine

Disinfect the machine with Isopropyl alcohol

Component

Description

Cutter

Check to see if the cutter is working properly. If necessary,
replace the blade. (See section 0)

9.2 Maintenance schedule

The following maintenance schedule is based on regular use of the machine. If the
machine is used intensively or in extreme conditions, maintenance should be performed
at shorter intervals.

Weekly maintenance:

Weekly maintenance may be performed by operating personnel. (see foreword). Always
switch off the machine and disconnect it from the main power supply before carrying out
maintenance operations.

Monthly maintenance:

Monthly maintenance may only be performed by authorised maintenance personnel.
(see foreword). Always switch off the machine and disconnect it from the main power
supply before carrying out maintenance operations.

22

fig. 9 Replacing the blade

Caution: do not cut yourself! The blade is extremely sharp.

9.3 Replacing the blade

GD 301 Evo rev.1.0

A blunt blade can easily be replaced as follows:

 Remove the cutter (1) from the machine.
 Remove the blade (2) from the cutter with a pair of pliers (3).
 Insert a fresh blade into the cutter using the pliers.
 Slot the cutter back into the guides.

23

GD 301 Evo rev.1.0

Problems to the machine may only be resolved by authorised
maintenance personnel. (see foreword).

In the event of a malfunction, always switch off the machine first.
Then consult the manual.

Problem

Cause

Solution

The machine will
not start.

The machine is not plugged in
properly.

Insert the plug into the wall
socket properly.

The plug has not been connected
properly to the machine.

Insert the plug into the
machine properly.

Internal malfunction.

Contact your dealer or
Gandus Saldatrici .

10 Troubleshooting

Below you will find a table specifying the most common malfunctions. If you encounter a
problem not listed in this table, contact your dealer or Gandus Saldatrici . (see the
reverse of this manual for contact details).

24

LED Colour

Buzzer

Meaning

Off

Off

The machine has been switched
off.

Green, continuous

Off

The machine has been switched
on; the seal bar has reached the
desired temperature.

Green, flashing
(slowly)

Off

The machine is busy sealing.

Green, flashing
(fast)

Continuous

The sealing process is complete.
Use the operating lever to open the
seal bar.

Red, continuous

Off

The machine has been switched
on, but the temperature of the seal
bar is too high or too low. Wait until
the machine has reached the
desired temperature.

Red, flashing
(slowly)

On/off

The seal bar is closed and the
temperature is too low. Raise the
seal bar by pulling back the
operating lever. Wait until the
machine has reached the desired
temperature.

Red, flashing
(slowly)

On/off

The seal bar has remained closed
for too long and the temperature is
too high or too low. Use the
operating lever to open the seal
bar.

10.1 Codes and fault codes for the on/off switch

GD 301 Evo rev.1.0

10.2 Deactivating the buzzer:

The buzzer can easily be switched off as follows:

1. Switch off the machine.

2. Press the on/off switch for about 10 seconds until you hear two short bleeps.
The buzzer has now been deactivated. This will remain so until it has been

reactivated.

3. To reactivate the buzzer, simply repeat the above steps.

25

GD 301 Evo rev.1.0

Article number

Name

Number per
machine

82010

Blade (set 5 pcs)

1

82011

Self adhesive seal rubber

1

The machine may only be put out of operation by authorised
maintenance personnel. (see foreword).

While the machine is being put out of operation all safety
regulations must be observed.

All operators are required to use personal protective equipment.

The machine must be switched off properly before it can be taken
out of operation. (see section 8.2).

No special tools or equipment are required to put the machine out
of operation.

11 Recommended spare parts

Gandus Saldatrici recommends always having the following spare parts on hand so
that defective parts can be replaced quickly and the production process will not be
interrupted longer than necessary.

12 Taking out of operation, transportation and storage

12.1 Taking out of operation

26

GD 301 Evo rev.1.0

Always observe the applicable safety precautions when transporting
or storing the machine.

Gandus Saldatrici cannot be held liable for damage incurred during
transportation and/or storage.

Never transport or store the machine upside down.

To prevent irreparable damage to the machine, also observe
specifications applicable to the storage and transportation
environment. (see Chapter 5).

12.1.1 Switching off the main power supply

Switch the machine off.
Disconnect the power cord from the power supply.
Disconnect the female plug of the power cord from the machine power port.

12.2 Transportation and storage

12.2.1 Transport

Before transporting the machine it must be put out of operation in the correct manner.
We recommend transporting the machine in its original packaging.

The machine’s centre of gravity is at the bottom. As such, it will remain stable during

transport in normal circumstances. For safe transport of the machine, please take the
weight of the machine into consideration before starting all transport operations. (see
section 13).

The relative light weight of the machine allows it to be transported manually. The
machine must be lifted from the underside.

12.2.2 Storage

Before putting the machine in storage it must be put out of operation in the correct
manner. We recommend storing the machine in its original packaging.

27

General

Dimensions H x W x D:

307 mm(H) x 452 mm (W) x 412 mm (D)

Weight:

± 3 kg

Seal length:

300 mm

Seal width:

12 mm

Seal temperature:

180 °C

Electrical wiring

Max. capacity:

300 W

Stand-by capacity:

< 0,5 W

Voltage:

230 V

Main power supply deviation:

<10%

Frequency:

50 Hz

Fuses:

2 AT

Connector cable length:

± 1.8 m

Emission

Sound:

< 80 dB(A)

Hand/arm vibration:

< 2.5 m/s²

13 Technical details

GD 301 Evo rev.1.0

28

GD 301 Evo rev.1.0

14 To discard

In accordance with the directive 2002/96/CE, the logo below indicates that the
equipment concerned is not to be disposed of as ordinary waste at the end of its
useable life. The equipment is to be delivered to a suitable depot that will dispose of the
equipment in a proper way in accordance with the legislation on this subject, or to the
supplier of new equipment in case of replacement.
The owner of the equipment is responsible for proper disposal of the equipment.
For further information we advise you to contact your local waste facility.

Appropriate disposal of Waste of Electric and Electronic Equipment prevents
unnecessary pollution of the environment and negative influence on general
health.

15 Conditions of guarantee

15.1 Liability

 We exclude any liability as far as it has not been arranged by law.
 Our liability will never exceed the amount of order.
 Subject to the general valid regulations of the law, we are not obliged to any

compensation of damage of which kind ever, directly or indirectly, under which
company damage, to movable' and immovable or to persons, both to the
opposite party as to third persons.

- In no way we are liable for damage arisen from or caused by the supplied or by
the unsuitability of this for the purpose for which the opposite party has
purchased the Sealer.

15.2 Guarantee

 With due observance of the restrictions stated hereafter, we allow 12 months of

guarantee to the products supplied by us. This guarantee is restricted to the
occurring manufacture errors and does not imply interruptions caused by any
form of wear spare parts subject to use.

 To spare parts or enclosures obtained from third persons we do not give longer

guarantee than this third supplier does.

 Guarantee expires if the opposite party and/or third parties associated make

improper use of the supplied.

 Guarantee also expires if the opposite party and/or third parties associated

execute activities and/or modifications to the supplied.

29

GD 301 Evo rev.1.0

 In case we replace spare parts to fulfill our guarantee engagement, the spare

parts replaced become property of GANDUS SALDATRICI packaging
machines.

- In case the opposite party does not come up completely, partially or does not
come up in time to the obligations arisen from the engagement closed between
the parties, we are not obliged to guarantee as long as the situation continues.

30

GD 301 Evo rev.1.0

16 Electrical diagram

2

Gandus Saldatrici s.r.l socio unico

Via Milano, 5 – 20010 CORNAREDO - ITALY

Tel [phone] – Fax [phone]

[e-mail] – www.gandus.it
