Gilon TLI 103N Users manual

TLi Inc.

iSOL

Smart walking sensor

Product manual

FCC ID : 2AOPXTLI-103N

Configuration of product

• 1 set of smart insole

• 2 batteries (3V CR2032)

• 2 water proof tapes

• Product manual

How to prepare

1.Install battery

Rotate battery cover to counterclockwise

and open battery slot. Face ‘+’ to

top and insert battery. Put battery

cover back and rotate to clockwise

to close.

2. Connect to mobile phone

Refer ‘connect to mobile’ chapter

3. Insert smart insole

After completion of connect to mobile

phone, apply water proof tape as

indicated in below.

Installation of mobile application

• System requirement

Android 4.4 or above

iOS9 or above

Display resolution 1280 x 720 or above

• Installation of mobile app

Download from app stores.

Connect to mobile

• Connect sensor

1. Check Bluetooth is on.

2. Keep smart insoles as close as possible
to mobile phone.

3. Run mobile app and get it paired with

smart insole both left and right.

4. Once connected successfully, app will

ask ‘shake insole to check connection’.

Shake insole to connect

For use

Major feature of product

•Dash board

• Walk information; number of walk, distance,

consumption of calories will be displayed
when insole is connected to mobile phone.

• Activity analysis; it displays activities after
certain period of duration by walking,
running, sitting, and standing.

• Walk analysis; it displays analysis after
certain period of duration by stride,
balance between right and left, foot angle,
heel to toe, and distribution of pressure.

• Mission

• Individual mission; offers to increase

amount of activity and improvement of
walk, based on individual program.

• Group mission; offer of group events by
device provider.

• Game

Funny balance; games help to improve maintain
of balance of body.

Specification

• Sensor; 3 axis (acceleration) and
pressure sensor

• Battery; replaceable (CR2032 (220mAh))

• Weight; 45g (battery included)

• Type of network; Bluetooth Low Energy

• Operating temperature; -10 ~ 50℃

Product warranty

• Warranty period; 6 month from purchase

• Out of warranty cases;

- Disassembly by user

- Damage by any type of impact

- Abnormal battery install

Customer service call

Address;
7F, TLi Building, 12 Yanghyeon-ro 405 beon-gil,
Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea
13438
Tel; [phone]

Cautions Others

• Do not renovate or disassemble.

• Do not leave product nearby fire

source.

• Pay extreme attention to children to
prevent them to swallow the battery.

• For stable operation, do not expose

product to water or humidity.

• Splash proof only.

• Wash product surface by wet rags, do

not wash product into water.

FCC STATEMENT

This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.

Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful in terference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the
following measures:

—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and

receiver.
—Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician
for help.

Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority tooperate this equipment.
