The handset at a glance
Ä e
INT 1
01/31 9:45
1
2
3
4
5
6
7
8
911
13
14
15
10
12
§§§§Menu§§§§
The handset at a glance
Note:
Pictures in this user manual may differ from the
actual product.
1 Display in idle status
2 Charge status of the batteries (page 2)
3 Display keys
4 Control key
t Access to base station’s Calls list.
s Access to base station’s directory.
5 Line keys
Answer an incoming call for Line 1/Line 2.
Make a call from Line 1/Line 2.
Start a second call from Line 2 while telephoning from Line 1 and vice versa.
6 End Call key, On/Off key
End call, cancel function, return to idle status,
activate/deactivate handset (press and hold in
idle status).
7 2.5-mm socket (mono) for headset
8 Pound (#) key
Enter # symbol.
Keypad lock on/off (press and hold in idle sta-
tus).
Switch between uppercase and lowercase let-
ters for text entry.
9 Redial/Pause key
Open redial list (in idle status) or insert a dial-
ing pause (when editing a number).
10 Microphone
11 Intercom/Hold/Conference key
Set up an internal call.
Switch between an external call and internal
party (handset/base station), or transfer a call
during an external call.
Set up a conference call between an external
line and an internal party (handset/base sta-
tion). Press and hold the key in hold-intercom
mode.
12 Star (*) key
Ring tone on/off (press and hold).
Switch temporarily to tone dialing (DTMF).
Switch between AM and PM during time set-
ting.
Switch number format in the Calls list.
13 Handsfree key
Answer or place a call in speaker mode.
Switch between speaker on and speaker off (in
off-the-hook mode).
14 Talk/Flash key
Answer or start a call.
Key flashes: incoming call.
Add a flash (in the directory).
Send FLASH (when off the hook).
15 Reception indicator (page 2)
1
The handset at a glance
Ê
Ë
Ê
Ë
Overview of handset’s display icons
Reception indicator
Ä
Handset is linked with the base station.
Flashes: the handset is out of range or not
registered
Charge status of the batteries
e
= e U (empty to full)
= flashes: batteries almost empty
= U flashes: batteries charging
Ê ËIs shown when the respective line is off the
hook, in external talk mode, in use mode or
on hold.
Is displayed in the Calls lists to show the
line on which the call came in.
Off-Hook
Æ
Outgoing call initiated or during a call.
Flashes: indicates incoming call,
L2CALL in the display heade r shows the line
of the incoming call
L1CALL /
Calls list icon
Ó
Entries stored in the base station‘s Calls list.
Flashes: New missed calls in the Calls list
Voic e m ai l e nvelo pe
î
At least one new message on voice
mailbox
Handsfree icon
Ç
Handsfree mode activated
Ringer off icon
Å
Ring tone volume of handset is turned off
Õ
Answering machine icon
Answering machine at the base station is
Õ
switched on for Line 1 / Line 2 / Line 1 and
Line 2.
Õ
Flashes: answering machine is recording or
is being operated by another handset or
there are new messages on the answering
machine
2
Contents
Contents
The handset at a glance . . . . . . . . . . . . 1
Overview of handset’s display icons . . . . . 2
Safety precautions . . . . . . . . . . . . . . . . 4
Notes on the operating instructions 5
Symbols used . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Example: menu input . . . . . . . . . . . . . . . . . . . 5
Gigaset C28H – First Steps . . . . . . . . . . 6
Package contents . . . . . . . . . . . . . . . . . . . . . . . 6
Setting up the handset for use . . . . . . . . . . 6
Registering and de-registering handsets . 7
Changing the base station . . . . . . . . . . . . . . 7
Making calls . . . . . . . . . . . . . . . . . . . . . . . 9
Making an external call . . . . . . . . . . . . . . . . . . 9
Ending a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Answering a call . . . . . . . . . . . . . . . . . . . . . . . . 9
Last number redial list . . . . . . . . . . . . . . . . . . 10
Operating the handset . . . . . . . . . . . 10
Control key . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Display keys . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Returning to idle status . . . . . . . . . . . . . . . . 11
Menu guidance . . . . . . . . . . . . . . . . . . . . . . . . 11
Correcting incorrect entries . . . . . . . . . . . . 12
Using several handsets . . . . . . . . . . . 12
Making internal calls . . . . . . . . . . . . . . . . . . . 12
Handset settings . . . . . . . . . . . . . . . . . 12
Changing the name of a handset . . . . . . . 12
Changing the display language . . . . . . . . 12
Setting the display contrast . . . . . . . . . . . . 12
Activating/deactivating auto answer . . . 13
Adjusting the loudspeaker and
earpiece volume . . . . . . . . . . . . . . . . . . . . . . . 13
Changing ring tones . . . . . . . . . . . . . . . . . . . 13
Activating/deactivating the
key-touch tone . . . . . . . . . . . . . . . . . . . . . . . . 13
Appendix . . . . . . . . . . . . . . . . . . . . . . . . 14
Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Contact with liquid . . . . . . . . . . . . . . . . . . . . 14
Questions and answers . . . . . . . . . . . . . . . . . 14
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Industry Canada Certification . . . . . . . . . . . 16
FCC / ACTA Information . . . . . . . . . . . 16
Safety precautions . . . . . . . . . . . . . . . . . . . . . 17
End-user limited warranty . . . . . . . . . . . . . . 19
Menu of the handset . . . . . . . . . . . . . 22
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3
Safety precautions
!
$
‹
Œ
ƒ
Safety precautions*
Only use the power supply unit supplied as indicated on the bottom of the device.
Only insert approved rechargeable batteries of the same type.
Never use ordinary (non-rechargeable) batteries, as they may pose a health hazard
or cause injury.
Do not charge the handset in the charging unit or base station while the headset is
connected.
Make sure the rechargeable battery is inserted in the correct direction.
Use the battery specified in these operating instructions.
The phone may affect medical equipment, so always turn your phone off before
entering a hospital or doctor's office.
Notice to Hearing Aid Wearers:
This phone system is compatible with inductively coupled hearing aids.
Do not operate the phone in places where there is a risk of explosion
(such as paint workshops).
Do not install the base station in the bathroom. The handset and base station are not
splash-proof (see page 14).
Drivers must not use the phone while driving.
The phone must be turned off at all times in aircraft. Make sure the phone cannot be
switched on accidentally.
If you give your telephone to someone else, you should also provide the operating
instructions.
Dispose of batteries and the phone carefully. Do not pollute the environment.
Emergency numbers cannot be dialed if the keypad lock is activated!
*also see page17
4
Notes on the operating instructions
Notes on the operating
instructions
This section explains the meaning of certain
symbols and typographical conventions
used in this user guide.
Symbols used
On / Off (example)
Select one of the two menu
functions specified.
~ Enter digits or letters.
§Back§ The display keys' current func-
tions are shown in reverse and
are highlighted in the lower display line. Press the display key
below to launch the function.
q Press the top or the bottom of
the control key: scroll up or
down.
c / Q / * etc.
Press the corresponding key of
the handset.
Example: menu input
In the user guide, the steps you need to perform are shown in abbreviated form. This is
illustrated here using "Changing the display
language" as an example.
What you need to do is explained in the box.
§Menu§ ¢ Settings ¢ Handset
¢ Language ¢ English / Español /
Français
¤ With the handset in idle status, press the
right display key to open the main menu.
¤ Select Settings using the control key q
– press the control key at the top or bottom.
¤ Press the §OK§ display key to confirm the
function Settings.
The Settings submenu is displayed.
¤ Press the bottom of the control key s
repeatedly until Handset is selected.
¤ Press the §OK§ display key to confirm the
function.
The Handset submenu is displayed.
¤ Press the bottom of the control key s
repeatedly until Language is selected.
¤ Press the §OK§ display key to confirm the
function.
The Language submenu is displayed.
¤ Select the language you want using the
control key q – press the control key at
the top or bottom.
¤ Press the §OK§ display key to confirm the
selected language.
The language is now changed for all text.
5
Gigaset C28H – First Steps
1
2
Underside of the charging cradle
Gigaset C28H –
First Steps
Package contents
u One Gigaset C28H handset with battery
cover
u Two batteries
u One belt clip
u One Gigaset charging cradle
u One AC adapter for the charging cradle
u One User Guide
Headset socket
Which headsets are compatible?
Please call the Service number
1-866-247-8758 or contact us at
www.gigaset.com/service
Caution:
Do not charge the handset in the charging unit or
base station while the headset is connected.
Connecting the charging cradle
¤ First connect the power adapter to the
charging cradle (1) and then the AC
power adapter to the 110V AC power
socket (2) as shown below.
for information.
Setting up the handset for use
Inserting the batteries
Caution:
Use only rechargeable Nickel-metal hydride
(NiMH) UL-approved AAA batteries. Never use a
conventional (non-rechargeable) battery or
other battery types as this could result in significant health risks and personal injury. For example, the batteries could explode. The phone
could also malfunction or be damaged as a result
of using batteries that are not of the recommended type.
Note:
If attached, remove the belt clip before opening
the battery cover.
¤ Open the battery cover.
¤ Insert the batteries according to the cor-
rect polarity (see diagram).
The polarity is indicated in/on the battery
compartment.
6
¤ Close the cover, and press the top so that
it clicks into place.
Gigaset C28H – First Steps
Attaching the belt clip
There are notches on the sides of the handset for attaching the belt clip, nearly at the
same height as the handset earpiece.
¤ Press the belt clip onto the back of the
handset so that the protrusions on the
belt clip engage the notches.
Placing the handset in the charging cradle
¤ Place the handset in the charging cradle
with the handset's display facing
outwards.
Registering and de-registering handsets
Before you can use additional handsets, you
must first register them to the base station.
A Gigaset C28H handset can be registered
with up to four base stations.
Registering the Gigaset C28H handset
On the handset
§Menu§ ¢ Settings ¢ Registration
¢ Register HS
q Select the base you want to reg-
ister your handset with and
§OK§. Bases that have been
press
registered will be marked by ½.
~ Enter the system PIN of the base
station and press
The handset will be registered.
On the base station
Within 60 secs. press and hold the registration/page key (approx. 5 secs.) on the base
station.
§OK§.
De-registering handsets
You can de-register any registered handset
from your Gigaset C285.
§Menu§ ¢ Settings ¢ Registration
¢ Unregister HS
~ Enter the base station’s system
PIN and press
q Select the handset you want to
de-register and press
§OK§ Press the display key to confirm
deletion.
§OK§.
§OK§.
Changing the base station
If your handset is registered to more than
one base station, you can set it to a particular
base station or to the base station that has
the best reception (Best Base).
§Menu§ ¢ Settings ¢ Registration
¢ Select Base
q Select one of the registered
base stations or Best Base and
§OK§.
press
Charging the batteries for the first time
¤ To charge the batteries, leave the handset
in the charging cradle continuously for
ten hours.
The alternately flashing battery icons =
on the upper right side of the display screen
indicate that the batteries are being
charged.
Note:
– If the handset has turned itself off because its
batteries are empty, and you then place the
handset into the base station, it will turn on
automatically.
– Only place the handset into the base station
or charging cradle specifically intended for it.
– During handset operation, the battery icon
e indicates the charge status of the batter-
ies (page 1).
– The batteries may feel warm when they are
charging. This is not dangerous.
U
For questions and troubleshooting,
seepage14.
7
Gigaset C28H – First Steps
Äe
INT 1
01/31 9:45AM
§§§§Menu§§§§
Setting the date and time
You should set the date and time, for example, to ensure the correct time of incoming
calls is recorded.
To change the time and date, open the input
field using:
§Menu§ ¢ s ¢ Settings ¢ Date/Time
¢ Set Date/Time
~ Enter the time and date using
10 digits, for example, Q M
1 5 Q 1 1 5
Q N for January 15, 2008,
07:15 AM. If the 12-hour time
format is set, use the * key to
switch between am and pm.
To correct an incorrect entry,
overwrite the character by typing the correct one.
§OK§ Press the display key to save
changes.
You can change the date and time format:
§Menu§ ¢ s ¢ Settings ¢ Date/Time
¢ Set Format
¤ Choose between day/month and month/
day date formats:
¢ Date Format ¢ DD/MM or MM/DD
s
¤ Choose between 12- and 24-hour time
formats:
¢ Time Format ¢ 12 Hours / 24 Hours
s
Selecting the line settings
For each handset and the base station, you
can set how your telephone will use the two
telephone lines:
Auto All incoming calls will ring. For
outgoing calls, your phone will
use whichever line is currently
free.
Line 1 / Line 2
Only incoming calls on the
respective line can be answered
with the c key. For outgoing
calls, your phone will always use
the selected line.
If you have selected Line 1 or Line 2, you can
still answer or make a call on the free line by
using the C or h keys.
Selecting line settings for a handset
§Menu§ ¢ s ¢ Settings ¢ Handset
¢ Line Setting
Auto / Line 1 / Line 2
Select entry and press
§OK§.
Display in idle status
Once the phone is registered to a base station (page 7)and the time set, the idle display looks as shown here (example).
Note:
Date and time settings apply to base station and
all registered handsets.
Date and time format settings apply only to your
own handset. You must set date and time format
at each device separately.
8
Your phone is now ready to use.
This user manual describes the functions of
your Gigaset C28H handset. For all base station related functions, please consult the
Gigaset C285 user manual.
Making calls
Making calls
Making an external call
External calls are calls using the outside telephone network.
~c Enter the number and press the
Tal k key c or Handsfree key
d.
Or:
c~ Briefly press the Talk key c or
Handsfree key d, and then
enter the number.
To cancel the dialing operation, press the
End Call key a.
Depending on the line settings of the used
handset, the telephone selects the line. You
can use the line keys C or h instead of
the c or d key to select the line for this
call.
You are shown the duration of the call while
the call is in progress.
Ending a call
a Press the End Call key.
Answering a call
The handset indicates an incoming call in
three ways: by ringing, by a display on the
screen, and by the flashing Talk key c.
The base station indicates an incoming call
in three ways: by ringing, by a display on the
screen, and by the flashing line key C or
h.
You can accept the call by:
¤ Pressing the Talk key c.
¤ Pressing the line key C or h.
¤ Pressing the Handsfree key d.
Depending on the line settings of the used
handset, the telephone reacts differently:
u If you have selected Auto, you can use
the Talk key c or Handsfree key d
for calls on both lines.
u If you have selected Line 1 or Line 2, you
can only answer calls on the selected line
with the Talk key c or Handsfree key
d. For calls on the other line, you must
use the C key or h key to answer the
call.
If the handset is in the base station or
charger and the Auto Answer function is
activated (page 13), the call will be answered
automatically when you lift the handset
from the base station or charger. Lifting the
handset from the base station or charger in
this case has the same effect as pressing the
Tal k key c.
You can press the
the ring tone of your handset without
answering the call. The other registered
handsets and the base station keep ringing
.
Note:
If two calls are ringing simultaneously on the two
lines, your telephone display will switch from one
line to the other every 3 seconds.
§Quiet§ display key to mute
¥ Use the C key or h key to answer the
call.
9
Operating the handset
1
Last number redial list
The Last Number Redial list contains the ten
numbers last dialed with the handset (max.
32 digits). If a number has been dialed several times, only the last try is shown in the
list.
Last number redial
k Press the key.
q Select the entry.
c / d Press the Talk key or the Hands-
free key.
The number is dialed.
You can press the C or h key instead, if
you want to specify which line to use.
When displaying a name, you can have the
respective phone number displayed:
§Menu§ ¢ View
Managing entries in the Last Number Redial list
k Press the key.
q Select the entry.
§Menu§ Open menu.
The following functions can be selected with
q:
u View
In the list long numbers are shown abbreviated. Select View to show the whole
number.
u Copy To Dir.
Copy the displayed entry to the directory
of the base station.
¤ Complete the entry as described in
the user guide of base station.
u Delete
Delete the displayed entry from the list.
u Delete List
¤ Confirm question Delete? by pressing
§OK§.
All entries in the last number redial list
will be deleted.
Operating the handset
Activating/deactivating the handset
a Press and hold the End Call key
to turn the handset on/off.
Activating/deactivating the keypad lock of the handset
# Press and hold the pound key.
Keypad Locked appears in the display when
the keypad lock is activated.
The keypad lock is deactivated automatically if someone calls you. It is re-activated
when the call is finished.
Control key
1 Control key
In the description below, the top or bottom
of the Control key (up, down), which you
must press depending on the operating
situation, is marked in black, for example,
for "press up on the Control key".
The Control key has different functions:
When the handset is in idle status
s Open the base station’s direc-
tory
t Open the base station’s Calls list
In input fields
You can use the Control key to move the cursor backwards
t or s forwards.
t
10
Operating the handset
§§§§§Back§§§§§ U §§§§Menu§§§§§
1
2
When the handset is off the hook or
when the answering machine is
playing
t / s Increase/decrease volume
In the main menu, lists and submenus
t / s Scroll up/down line by line.
At the bottom/top of a menu or a list:
A feedback tone signals that the menu/list
has wrapped around automatically (the first/
last entry is selected in the display).
Display keys
The function of the display keys changes
depending on the particular operating situation. Example:
1 The display keys' current functions are shown
on the bottom display line.
2Display keys
The most important display symbols are:
§§§§§Menu§§§§ Open the main menu (in idle
mode) or the context-dependent menu.
§§§§§Back§§§§ Go back one menu level.
§§§§§§§OK§§§§§§§ Confirm your choice or save
edited characters.
§§§§Clear§§§§§ Clear key: deletes one character
at a time from right to left (press
briefly), or deletes all characters
(hold).
Returning to idle status
You can return to idle status from anywhere
in the menu as follows:
¤ Press the End Call key a.
Or:
¤ Do not press any key: after 2 minutes, the
display will automatically return to idle
status.
Changes that you have not confirmed or
saved by pressing
An example of the display in idle status is
shown on page 8.
§OK§ will not be saved.
Menu guidance
Your phone's functions are accessed using a
menu that has a number of levels.
Main menu (first menu level)
¤ Press the display key §Menu§ with the hand-
set in idle status to open the main menu.
The main menu functions are shown on the
screen in a list.
To access a function, open the corresponding submenu (next menu level):
¤ Navigate to the function using the con-
trol key q.
¤ Press the display key §OK§.
Submenus
The functions in the submenus are displayed
as lists.
To access a function:
¤ Scroll to the function with the control key
q and press
Pressing the §Back§ display key returns you to
the previous menu level. a cancels the
operation.
§OK§.
11
Using several handsets
Correcting incorrect entries
You can correct incorrect characters in the
text by navigating to the incorrect entry
using the control key. You can then:
u Press §§§§Clear§§§§§ to delete the character to
the left of the cursor.
u Insert characters to the left of the cursor.
u Overwrite the (flashing) character when
entering the time and date, etc.
Using several handsets
Making internal calls
Internal calls to other handsets registered
with the same base station are free.
j Initiate internal call.
q Select the handset you want to
call and press
Note:
If only two handsets are registered to the base,
the internal call will be established immediately
after pressing
jkey.
Ending a call
a Press the End Call key.
§OK§.
Handset settings
Your handset is preconfigured, but you can
change these settings to suit your individual
needs.
Changing the name of a handset
The names "INT 1", "INT 2", etc., are assigned
automatically during registration. You can
change these names. The number of the
handset, however, never changes. The
changed name is only displayed on this
handset.
§Menu§ ¢ Settings ¢ Handset
¢ Handset Name
~ Enter the name and press §OK§.
The name must not exceed 12
characters.
Changing the display language
You can view the display texts in different
languages.
§Menu§ ¢ Settings ¢ Handset
¢ Language
English / Español / Français
q Select a language and press §OK§.
Setting the display contrast
You have a choice of five different contrast
levels.
§Menu§ ¢ Settings ¢ Handset
¢ Display Contr.
Level 1 / ... / Level 5
Select your preferred level and
§OK§.
press
12
Handset settings
Activating/deactivating auto answer
This function is active by default, so that
when you get a call, you can simply lift the
handset out of the charging cradle or the
base station without having to press the Talk
key c.
§Menu§ ¢ Settings ¢ Handset
¢ Auto Answer ¢ On / Off
Default setting is On.
Adjusting the loudspeaker and earpiece volume
You can set the loudspeaker volume and the
earpiece volume to five different levels. You
can only make these adjustments during a
call.
The handsfree volume can only be adjusted
when this function is in use.
You are conducting a call.
q Increase or decrease the
volume.
Changing ring tones
You can set different ring tones for Line1 and
Line2.
Volume
You can choose between five volumes (0–5;
for example, volume 4 = ˆ).
§Menu§ ¢ Settings ¢ Audio Settings
¢ HS Ring Volume
Line 1 / Line 2
Select the line for which you
want to set the volume and
§OK§.
press
q Select the volume and press §OK§.
Ring tones
You can choose between 15 different melodies.
§Menu§ ¢ Settings ¢ Audio Settings
¢ HS Ring Tones ¢Line 1 / Line 2
q Select a melody and press §OK§.
Activating/deactivating the ring tone
You can deactivate the ring tone on your
handset before you answer a call or when
the handset is in idle status; the ring tone
can be deactivated permanently or just for
the current call.
Deactivating and reactivating the ring
tone permanently
* Press and hold the star key.
Line 1 / Line 2
Select the line for which you
want to deactivate or reactivate
the ring tone and press
On / Off Select if you want to deactivate
or reactivate the ring tone and
§OK§.
press
If the ring tone is deactivated, the Åicon
appears in the display for the respective line.
§OK§.
Deactivating the ring tone for the
current incoming call
§Quiet§ Press the display key.
Ajusting the ring tone volume during
an incoming call
¤ Press the s or tkey until the ring tone
volume reaches the desired level.
You can press the s key until you no longer
hear the ring tone.
Activating/deactivating the key-touch tone
Each key press is acknowledged by a beep.
You can deactivate this function:
§Menu§ ¢ Settings ¢ Audio Settings
¢ Key Touch Tone ¢ On / Off
13
Appendix
!
Appendix
Care
Wipe the base station and handset with a
damp cloth (do not use solvents) or an antistatic cloth.
Never use a dry cloth. This can cause static.
Contact with liquid
If the handset has come into contact with
liquid:
1. Immediately switch the handset off
and remove the batteries.
2. Allow the liquid to drain from the handset.
3. Pat all parts dry, then place the handset,
with the battery compartment open and
the keypad facing down, in a dry, warm
place for at least 72 hours (not in a microwave oven, convection oven, or similar place).
4. Do not switch on the handset again until it has completely dried.
When it has fully dried, you should be able to
use it again normally.
The handset does not respond to a key press.
The keypad lock is activated.
¥ Press and hold the pound key
Base Search and
screen.
1. The handset is outside the range of the base
station.
Ä is flashing on the display
#
(page 1).
¥ Reduce the distance between handset/
base station.
2. The handset has been de-registered. Please
Register is flashing on the display screen.
¥ Register the handset (page 12).
3. The base station is not switched on.
¥ Check the base station power cord
(page 6).
Handset does not ring.
The ring tone is switched off.
¥ Activate the ring tone (page 13).
The other party cannot hear you.
You have pressed the display key §Mute§ or the
j key. The handset is on hold.
¥ Press the left display key to switch on the
microphone again.
Questions and answers
If you have any questions about the use of
your telephone, you can contact us at any
time atwww.gigaset.com/service
The troubleshooting section (page 14) contains a list of common problems and possible solutions.
Troubleshooting
The display is blank.
1. The handset is not switched on.
¥ Press a and hold the End Call key.
2. The batteries are empty.
¥ Charge or replace the batteries (page 6).
14
Appendix
Specifications
Recommended batteries
Technology: Nickel-metal hydride
(NiMH)
Type: AAA (Micro, HR03)
Tension: 1.2 V
Capacity: 550 mAh
The handset is supplied with the authorized
AAA batteries.
Handset operating times/charging times
Standby time Approx. 280 hours
(11.6 days)
Tal k ti me Ap prox . 10 hou rs
Charge time Approx. 10 hours
The operating and charge times apply only
when using the recommended batteries.
General specifications
DECT 6.0 is supported
No. of channels 30 duplex channels
Radio frequency
range 1920–1930 MHz
Duplex method Time multiplex, 10ms frame
Channel grid 1728 kHz
Bitrate 1152 kbit/s
Modulation GFSK
Language code 32 kbit/s
Transmission
power
Range Up to 984 feet outdoors, up
Charging cradle
power supply 110 V ~/60 Hz
Environmental
operating conditions
Dialing mode DTMF (tone dialing)/DP
length
10 mW, average power per
channel
to 165 feet indoors
+41°F to +113°F;
20% to 75% relative humid-
ity
(pulse dialing)
15
FCC / ACTA Information
Industry Canada Certification
Operation is subject to the following two conditions (1) this device may not cause interference,
and (2) this device must accept any interference,
including interference that may cause undesired
operation of the device.
NOTICE: The Industry Canada label identifies certified equipment. This certification means that the
equipment meets certain telecommunications
network, protective, operational and safety
requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s). The Department does not guarantee the
equipment will operate to the user’s satisfaction.
Before installing this equipment, users should
ensure that it is permissible to be connected to
the facilities of the local telecommunications
company. The equipment must also be installed
using an acceptable method of connection. The
customer should be aware that compliance with
the above conditions may not prevent
degradation of service in some situations.
Repairs to certified equipment should be coordinated by a representative designated by the supplier. Any repairs or alterations made by the user
to this equipment, or equipment malfunctions,
may give the telecommunications company cause
to request the user to disconnect the equipment.
Users should ensure for their own protection that
the electrical ground connections of the power
utility, telephone lines and internal metallic water
pipe system, if present, are connected together.
This precaution may be particularly important in
rural areas
NOTE: Users should not attempt to make such
connections themselves, but should contact the
appropriate electric inspection authority,
or electrician, as appropriate.
This product meets the applicable Industry
Canada technical specifications.
The Ringer Equivalence Number is an indication of
the maximum number of devices allowed to be
connected to a telephone interface. The termination of an interface may consist of any combination of devices subject only to the requirement
that the sum of the RENs of all devices does not
exceed five.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
FCC / ACTA Information
Warning: Changes or modifications to this unit
not expressly approved by Gigaset Communications USA LLC could void the FCC authority to
operate the equipment. This includes the addition
of any external antenna device.
This equipment complies with Part 68 of the FCC
rules and the requirements adopted by the ACTA.
On the bottom of the base station is a label that
contains, among other information, a product
identifier in the format US:AAAEQ##TXXXX. If
requested, this number must be provided to the
telephone company.
A p lu g an d j ack us ed to c on nec t t hi s eq ui pme nt to
the premises wiring and telephone network must
comply with the applicable FCC Part 68 rules and
requirements adopted by the ACTA. A compliant
telephone cord and modular plug is provided
with this product. It is designed to be connected
to a compatible modular jack that is also compliant. See installation instructions for details.
The REN is used to determine the number of
devices that may be connected to a telephone
line. Excessive RENs on a telephone line may result
in the devices not ringing in response to an
incoming call. In most but not all areas, the sum of
RENs should not exceed five (5.0). To be certain of
the number of devices that may be connected to
a line, as determined by the total RENs, contact
the local telephone company. For products
approved after July 23, 2001, the REN for this product is part of the product identifier that has the
format US:AAAEQ##TXXXX. The digits represented by ## are the REN without a decimal point
(e.g., 03 is a REN of 0.3). For earlier products, the
REN is separately shown on the label.
A copy of the supplier's Declaration of Conformity
(SDoC) is available at this Internet address:
www.gigaset.com/docs.
If this equipment causes harm to the telephone
network, the telephone company will notify you
advance, that temporary discontinuance of service may be required. But if advance notice isn’t
practical, the telephone company will notify the
customer as soon as possible. Also, you will be
advised of your right to file a complaint with the
FCC if you believe it is necessary.
The telephone company may make changes in its
facilities, equipment, operations or procedures
that could affect the operation of the equipment.
If this happens the telephone company will provide advance notice in order for you to make necessary modifications to maintain uninterrupted
service. If you experience trouble with this telephone system, disconnect it from the network
in
16
FCC / ACTA Information
until the problem has been corrected or until you
are sure that the equipment is not malfunctioning.
If trouble is experienced with this equipment, for
repair or warranty information, please contact
Support at 1-866 247-8758. If the equipment is
causing harm to the telephone network, the telephone company may request that you disconnect
the equipment until the problem is resolved. This
equipment is of a type that is not intended to be
repaired by the Customer (user).
This telephone system may not be used on coin
service provided by the telephone company. Connection to party line service is subject to state tariffs. Contact the state public utility commission,
public service commission or corporation commission for information. Privacy of communications may not be ensured when using this phone.
If your home has specially wired alarm equipment
connected to the telephone line, ensure the
installation of this equipment does not disable
your alarm equipment. If you have questions
about what will disable alarm equipment, consult
your telephone company or a qualified installer.
This telephone system equipment has been
tested and found to comply with the limits for
Class B digital device, pursuant to Part 15 of the
FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) This device must
accept any interference received, including interference that may cause undesired operation.
These limits are designed to provide reasonable
protection against harmful interference in a residential installation. Some cordless telephones
operate at frequencies that may cause interference to nearby T V’s and VCR’s; to minimize or prevent such interference, the system base should
not be placed near or on top of a TV or VCR; and, if
interference is experienced, moving the base farther away from theTV or VCR will often reduce or
eliminate the interference.
However, there is no guarantee that interference
will not occur in a particular installation. If this telephone system does cause harmful interference
to radio or television reception, which can be
determined by turning the system off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the base station and receiver.
3. Connect the base station into an outlet on a circuit different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio TV
technician for help.
Notice for Direct Inward Dialing
("DID")
ALLOWING THIS EQUIPMENT TO BE OPERATED IN
SUCH A MANNER AS TO NOT PROVIDE FOR
PROPER ANSWER SUPERVISION IS A VIOLATION
OF PART 68 OF THE FCC‘S RULES.
Notice to Hearing Aid Wearers:
This phone system is compatible with inductively
coupled hearing aids.
Power Outage:
In the event of a power outage, your cordless
telephone will not operate. The cordless telephone requires electricity for operation. You
should have a telephone that does not require
electricity available for use during power outages.
Notice:
The installation of the base unit should allow
at least 8 inches between the base and persons to
be in compliance with FCC RF exposure guidelines.
For body worn operation, the portable part (handset) has been tested and meets FCC RF exposure
guidelines. Use with an accessory that contains
metal parts may not ensure compliance with FCC
RF exposure guidelines.
Notice to telephone company service:
If you need service from your telephone company,
please provide them with the information
– Facility interface Code (FIC)
– Service Order Code (SOC)
– Universal Service Order Code (USOC)
as indicated on the label on the bottom side of the
base station.
Safety precautions
Before using your telephone equipment, basic
safety instructions should always be followed to
reduce the risk of fire, electric shock and injury to
persons.
1. Read and understand all instructions.
2. Follow all warnings and instructions m arked on
the product.
3. Unplug this product from the wall telephone
jack and power outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use damp
cloth for cleaning.
4. Do not use this product near water, for example,
near a bathtub, wash bowl, kitchen sink, or laundry tub, in a wet basement or near a swimming
pool.
17
FCC / ACTA Information
5. Place this product securely on a stable surface.
Serious damage and/or injury may result if the
unit falls.
6. Slots or openings in the cabinet and the back
and bottom are provided for ventilation, to protect it from overheating. These openings must not
be blocked or covered. This product should never
be placed near or over a radiator or heat register,
or in a place where proper ventilation is not provided.
7. This product should be operated only from the
type of power source indicated on the marking
label. If you are not sure of the type of AC line
power to your home, consult your dealer or local
power company.
8. Do not place objects on the power cord. Install
the unit where no one can step or trip on the cord.
9. Do not overload wall outlets and extension
cords as this can result in the risk of fire or electric
shock.
10. Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or short out parts that could
result in the risk of fire or electric shock. Never spill
liquid of any kind on this product.
11. To reduce the risk of electric shock or burns, do
not disassemble this product. Take it to a qualified
service center when service is required. Opening
or removing covers may expose you to dangerous
voltages, dangerous electrical current or other
risks. Incorrect reassembly can cause electric
shock when the appliance is subsequently used.
Disconnect TNV circuit connector before removing cover.
12. Unplug the product from the wall outlet and
refer servicing to qualified service personnel
under the following conditions:
a.) When the power cord is damaged or frayed.
b.) If liquid has been spilled into the product.
c.) If the product has been exposed to rain or
water.
d.) If the product does not operate normally by fol-
ing the operating instructions. Adjust only
low
those controls
instructions because improper adjustment of
other controls may result in damage and may
require extensive work by a qualified technician to
restore the product to normal operation.
e.) If the product has been dropped or physically
has been damaged.
f.) If the product exhibits a distinct change in performance.
13. Avoid using a telephone (other than a cordless
type) during a thunderstorm. There may be a
remote risk of electrical shock from lightning.
Therefore we suggest a surge arrestor.
that are covered by the operating
14. Do not use the telephone to report a gas leak
in the vicinity of the leak.
15. Emergency/911 numbers may not be dialed if
the keypad is locked.
16. Minimum No. 26 AWG telecommunication line
cord must be used with this phone.
BATTERY SAFETY PRECAUTIONS
To reduce the risk of fire, injury or electric shock,
and to properly dispose of batteries, please read
and understand the following instructions.
CONTAINS NICKEL METAL HYDRIDE BATTERY. BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY. DO NOT DISPOSE OF IN MUNICIPAL WASTE.
1. Only use the batteries specified for use with this
product.
2. DO NOT USE NICKEL CADMIUM OR LITHIUM
BATTERIES, or mix batteries of different sizes or
from different manufacturers in this product. DO
NOT USE NONRECHARGEABLE BATTERIES.
3. Do not dispose of the batteries in a fire; the cells
may explode. Do not expose batteries to water.
Check with local codes for special disposal instructions.
4. Do not open or mutilate the batteries. Released
electrolyte is corrosive and may cause damage to
the eyes or skin. The electrolyte may be toxic if
swallowed.
5. Exercise care in handling the batteries in order
not to short the batteries with conducting materials such as rings, bracelets, and keys. The batteries
or conducting material may overheat and cause
burns or fire.
6. Charge the batteries provided with, or identified for use with, this product only in accordance
with the instructions and limitations specified in
the user’s manual. Do not attempt to charge the
batteries with any means other than that specified
in the users manual.
7. Periodically clean the charge contacts on both
the charger and handset.
18
FCC / ACTA Information
Service (Customer Care)
Customer Care Warranty for Cordless Products
To obtain Customer Care Warranty service,
product operation information, or for problem resolution, call:
Toll Free:
1-866 247-8758
End-user limited warranty
This product is covered by a one year limited warranty. Any repair replaceme nt or warranty ser vice,
and all questions about this product should be
directed to: 1-866 247-8758.
This limited, non-transferable warranty is provided to the original buyer/end-consumer ("you")
for systems, handsets and accessories (collectively, "Product") provided by Gigaset Communications USA LLC or Gigaset Communications Canada Inc. (collectively "Gigaset NAM"). Gigaset NAM
warrants to you that at the date of purchase, the
Product is free of defects in workmanship and
materials and the software included in the Product will perform in substantial compliance to its
program specifications.
1. WARRANTY PERIOD
The Product warranty period is one (1) year from
the original date of purchase by you. Proof of purchase (e.g., sales slip or invoice) must be provided
with any Product returned during the warranty
period. Batteries supplied with the Products are
warranted to be free from defects at the time of
purchase only.
2. EXCLUSIVE REMEDY
Gigaset NAM's entire liability and your exclusive
remedy if the Product is defective in materials or
workmanship during the warranty period and is
returned shall be that the Product will be repaired
or replaced as set forth in Section 4 below. Reconditioned replacement components, parts or materials may be used in the replacement or repair.
Data in the memory of the Product may be lost
during repair.
3. THIS LIMITED WARRANTY DOES NOT
COVER AND IS VOID WITH RESPECT
TO THE FOLLOWING:
– Cosmetic damage, physical damage to the sur-
face of the Product, including, without limitation, breakage, cracks, dents, scratches or
adhesive marks on the LCD screen or outside
casing of the Product.
– Products which have been repaired, main-
tained or modified (including the antenna) by
anyone other than Gigaset NAM or a Gigaset
NAM-approved repair facility, or that have
been improperly installed.
– Cost of installation, removal or reinstallation.
– Damage due to any telephone, electronic,
hardware or software program, network, Inter-
net or computer malfunctions, failures, or diffi-
culties of any kind, including without limita-
tion, server failure or incomplete, incorrect,
garbled or delayed computer transmissions.
– Equipment and components not manufac-
tured, supplied or authorized by Gigaset NAM.
– Modification of the Product's components, or
operation of the Product in an unsuitable envi-
ronment or in a manner for which it is not
intended, including but not limited to failures
or defects caused by misuse, abuse, accidents,
physical damage, abnormal operation,
improper handling or storage, neglect, altera-
tions, unauthorized installation, removal or
repairs, failure to follow instructions, problems
caused by the carrier's network coverage,
exposure to fire, water or excessive moisture or
dampness, floods, or extreme changes in cli-
mate or temperature, acts o f God, riots, acts of
terrorism, spills of food or liquids, viruses or
other software flaws introduced into the Prod-
uct or other acts which are not the fault of
Gigaset NAM and which the Product is not
specified to tolerate, including damage caused
by mishandling or blown fuses.
– Products which have had warranty stickers,
electronic serial number and/or serial number
label removed, altered, rendered illegible or
fraudulently applied to other equipment.
– Signal reception problems (unless caused by
defect in material or workmanship in the Prod-
uct).
– Products operated outside published maxi-
mum ratings.
– Performance of the Products when used in
combination with other products or equip-
ment not manufactured, supplied or author-
ized by Gigaset NAM.
– Consumables (such as batteries and fuses).
19
FCC / ACTA Information
– Payments for labor or service to representa-
tives or service centers not authorized to per-
form product maintenance by Gigaset NAM.
– Loss of data.
– Testing and examination discloses that the
alleged defect or malfunction in the Product
does not exist.
This warranty does not cover customer education,
instruction, installation or removal, set up adjustments, problems related to service(s) provided by
a carrier or other service provider, and/or signal
reception problems. Gigaset NAM shall not be
responsible for software, firmware, information, or
memory data contained in, stored on, or integrated with any Products returned for repair,
whether under warranty or not. This warranty is
valid only in the country in which it is purchased
(i.e., the United States of America or Canada
respectively, but not both).
USE WITH ACCESSORIES NOT SUPPLIED BY
GIGASET NAM OR NOT OTHERWISE EXPRESSLY
AUTHORIZED BY GIGASET NAM MAY VOID
WAR RAN TY.
4. WARRANTY CLAIM PROCEDURE
All warranty claims must be made by notifying
Gigaset NAM prior to the expiration of the warranty period. Gigaset NAM's obligation to provide
warranty support shall not extend past the end of
the warranty period, except that any product
repaired or replaced during the warranty period
shall continue to be warranted for the balance of
such warranty period or thirty (30) days, whichever is greater.
Support service will be provided for you by
accessing the toll free customer service number:
1-866 247-8758
5. LIMITATION OF WARRANTY
Gigaset NAM makes no warranty or representation that the software in the Products will meet
your requirements or will work in combination
with any hardware or applications software products provided by third parties, that the operation
of the software will be uninterrupted or error free,
or that all defects in the software products will be
corrected.
6. LIMITATION ON REMEDIES; NO
CONSEQUENTIAL OR OTHER
DAMAGES
Your exclusive remedy for any breach of this limited warranty is as set forth above. Except for any
refund elected by Gigaset NAM, YOU ARE NOT
ENTITLED TO ANY DAMAGES, INCLUDING BUT
NOT LIMITED TO CONSEQUENTIAL DAMAGES,
if the Product does not meet the limited warranty
, and, to the maximum extent allowed by applicable law, even if any remedy fails of its essential
purpose. The terms below ("Exclusion of Incidental, Consequential and Certain Other Damages")
are also incorporated into this limited warranty .
Some states/jurisdictions/provinces do not allow
the exclusion or limitation of incidental or consequential damages, so the above limitation or
exclusion may not apply to you. This limited warranty gives you specific legal rights. You may have
others which vary from state/jurisdiction/province to state/jurisdiction/province.
7. DISCLAIMER OF WARRANTIES
GIGASET NAM AND ITS SUPPLIERS PROVIDE THE
PRODUCT AND SUPPORT SERVICES (IF ANY) AS IS
AND WITH ALL FAULTS. THE LIMITED WARRANTY
IS IN LIEU OF ANY OTHER EXPRESS WARRANTIES
(IF ANY) CREATED BY ANY DOCUMENTATION OR
PACKAGING EXCEPT FOR THE LIMITED WARRANTY, AND TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW IS IN LIEU OF ANY
IMPLIED OR STATUTORY WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, OF ACCURACY OR COMPLETENESS OR RESPONSES, OF RESULTS, OF
WORKMANLIKE EFFORT, OF LACK OF VIRUSES
AND OF LACK OF NEGLIGENCE, ALL WITH REGARD
TO THE PRODUCT, AND THE PROVISION OF OR
FAILURE TO PROVIDE SUPPORT SERVICES. ALSO,
THERE IS NO WARRANTY OR CONDITION OF TITLE,
QUIET ENJOYMENT, QUIET POSSESSION, OR CORRESPONDENCE TO DESCRIPTION OR NONINFRINGEMENT WITH REGARD TO THE PRODUCT.
Some states/jurisdictions/provinces do not allow
limitations on how long an implied warranty lasts
or the exclusion or limitation of incidental or consequential damages, so the above exclusions or
limitations may not apply to you. If an implied
warranty or condition is created by your state/
province and federal or state/provincial law prohibits disclaimer of it, you also have an implied
warranty or condition, BUT ONLY AS TO DEFECTS
DISCOVERED DURING THE PERIOD OF THIS LIMITED WARRANTY (ONE YEAR). AS TO ANY DEFEC TS
DISCOVERED AFTER THE ONE YEAR PERIOD,
THERE IS NO WARRANTY OR CONDITION OF ANY
20
FCC / ACTA Information
KIND. This limited warranty gives you specific legal
rights, and you may also have other rights which
vary from state to state/province to province. In
no event shall Gigaset NAM's liability exceed the
cost of repairing or replacing defective Products
as provided herein, and any such liabilities will terminate upon expiration of the warranty period.
Any supplements or updates to the Product or the
software in the Product, including without limitatio n, an y (if any ) sof tware fi xes o r upgr ades or bu g
fixes provided to you after the expiration of the
one year limited warranty period are not covered
by any warranty or condition, express, implied or
statutory.
8. EXCLUSION OF INCIDENTAL,
CONSEQUENTIAL AND CERTAIN
OTHER DAMAGES
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL GIGASET NAM,
SELLER OR THEIR SUPPLIERS BE LIABLE FOR ANY
SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING, BUT
NOT LIMITED TO, DAMAGES FOR LOSS OF PROFITS
OR CONFIDENTIAL OR OTHER INFORMATION, FOR
BUSINESS INTERRUPTION, FOR PERSONAL INJURY,
FOR LOSS OF PRIVACY, FOR FAILURE TO MEET ANY
DUTY INCLUDING OF GOOD FAITH OR OF REASONABLE CARE, FOR NEGLIGENCE, AND FOR ANY
OTHER PECUNIARY OR OTHER LOSS WHATSOEVER) ARISING OUT OF OR IN ANY WAY RELATED
TO THE USE OF OR INABILITY TO USE THE PRODUCT, THE PROVISION OF OR FAILURE TO PROVIDE
SUPPORT SERVICES, OR OTHERWISE UNDER OR IN
CONNECTION WITH ANY PROVISION OF THIS LIMITED WARRANTY, EVEN IN THE EVENT OF THE
FAULT, TORT (INCLUDING NEGLIGENCE), STRICT
LIABILITY, BREACH OF CONTRACT OR BREACH OF
WARRANTY OF GIGASET NAM OR SELLER OR ANY
SUPPLIER, AND EVEN IF GIGASET NAM OR SELLER
OR ANY SUPPLIER HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. REPAIR OR
REPLACEMENT, AS PROVIDED UNDER THE WARRANTY, IS YOUR SOLE AND EXCLUSIVE REMEDY
FOR BREACH OF THE LIMITED WARRANTY.
9. LIMITATION OF LIABILITY AND
REMEDIES
NOTWITHSTANDING ANY DAMAGES THAT YOU
MIGHT INCUR FOR ANY REASON WHATSOEVER
(INCLUDING, WITHOUT LIMITATION, ALL DAMAGES REFERENCED ABOVE AND ALL DIRECT OR
GENERAL DAMAGES), THE ENTIRE LIABILITY OF
GIGASET NAM, SELLER AND ANY OF THEIR SUPPLIERS UNDER ANY PROVISION OF THIS LIMITED
WARRANTY AND YOUR EXCLUSIVE REMEDY FOR
ALL OF THE FOREGOING (EXCEPT FOR ANY REMEDY OF REPAIR OR REPLACEMENT ELECTED BY
GIGASET NAM OR SELLER OR SUPPLIER WITH
RESPECT TO ANY BREACH OF THE LIMITED WARRANTY) SHALL BE LIMITED TO THE GREATER OF
THE AMOUNT ACTUALLY PAID BY YOU FOR THE
PRODUCT OR FIVE DOLLARS ($5.00 USD/CAN).
THE FOREGOING LIMITATIONS, EXCLUSIONS AND
DISCLAIMERS SHALL APPLY TO THE MAXIMUM
EXTENT PERMITTED BY APPLICABLE LAW, EVEN IF
ANY REMEDY FAILS ITS ESSENTIAL PURPOSE.
10. GOVERNING LAW
If this Product was purchased in the United States
of America this limited warranty will be governed
by the laws of Texas, and exclude the United
Nations Convention on Contracts for the International Sale of Goods. If this Product was purchased
in Canada this limited warranty will be governed
by the laws of the Province of Ontario and the federal laws of Canada applicable therein, and
exclude the United Nations Convention on Contracts for the
International Sale of Goods.
If you want to learn more about Gigaset Service or
for Support on your Gigaset phone, visit our web
site at http://www.gigaset.com or please call
1-866 247-8758.
Issued by
Gigaset Communications GmbH
Frankenstr. 2a, D-46395 Bocholt
© Gigaset Communications GmbH 2011
All rights reserved.
Subject to availability. Rights of modifications
reserved.
Product attributes subject to change.
We reserve the right, to make changes without
notice in equipment design and/or components.
Part Number: A31008-M1963-R401-2-5819
© Copyright 2011.
21
Menu of the handset
Menu of the handset
Directory Opens the base station’s directory
Answer Machine Only on base stations with answering machine:
Opens the base station’s menu for the control of the answering machine
Voice Mail Call VM Line 1
Line 2
Settings Line 1
Line 2
Settings Date/Time Set Date/Time
Set Format
Audio Settings HS Ring Volume Line 1
Line 2
HS Ring Tones Line 1
Line 2
Key Touch Tone
Registration Register HS
Unregister HS
Select Base
Handset Handset Name
Language
Display Contr.
Auto Answer
Line Setting Auto
Line 1
Line 2
System Opens the base station’s menu for the control of the
phone system
£ page 8
£ page 13
£ page 13
£ page 7
£ page 7
£ page 7
£ page 12
£ page 12
£ page 12
£ page 13
£ page 8
22
Index
Index
A
Activating
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
handset
keypad lock
Auto answer
B
Base station, changing. . . . . . . . . . . . . . . . . . .7
Batteries
charge status
fitting
recommended batteries
Best base station
C
Call
answering
duration
ending
external
history
internal
Care of the telephone
Changing
base station
name of handset
ring tone
Charge status of the batteries
Charge time
Charging cradle, connecting
Clear key
Contact with liquid
Control key
Correcting incorrect input
Customer Care
D
Date format. . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Deactivating
auto answer
handset
keypad lock
ring tone
Deleting characters
De-registering handset
Directory
opening
. . . . . . . . . . . . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . . . . . . . . . . . 9, 13
. . . . . . . . . . . . . . . . . . . . . . . . .1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
. . . . . . . . . . . . . 15
. . . . . . . . . . . . . . . . . . . . . . . .7
. . . . . . . . . . . . . . . . . . . . . . . . . . . .9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
. . . . . . . . . . . . . . . . . 14
. . . . . . . . . . . . . . . . . . . . . . . . . .7
. . . . . . . . . . . . . . . . . . . . 12
. . . . . . . . . . . . . . . . . . . . . . . . . . . 13
. . . . . . . . . 1, 2
. . . . . . . . . . . . . . . . . . . . . . . . . . 15
. . . . . . . . . . . . .6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
. . . . . . . . . . . . . . . . . . . . 14
. . . . . . . . . . . . . . . . . . . . . . . . . 1, 10
. . . . . . . . . . . . . 12
. . . . . . . . . . . . . . . . . . . . . . . . 19
. . . . . . . . . . . . . . . . . . . . . . . . 13
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . . . . . . . . . . . . . . 13
. . . . . . . . . . . . . . . . . . . . 12
. . . . . . . . . . . . . . . . . .7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Display
charge status of the batteries
contrast
in idle status
keys
language
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
. . . . . . . . . . . . . . . . . . . . . . 1, 11
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1, 11
. . . . . . . . . . . . . . . . . . . . . . . . . . . 12
. . . . . . . . . .1
E
End Call key . . . . . . . . . . . . . . . . . . . . . . . . . 1, 9
Ending call
Entry, selecting (menu)
Example for menu input
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
. . . . . . . . . . . . . . . . . .5
. . . . . . . . . . . . . . . . .5
F
Format of Date, Time . . . . . . . . . . . . . . . . . . . .8
H
Handset
activating/deactivating
changing the base station
changing to best reception
idle status
registering with another base
Headset plug
. . . . . . . . . . . . . . . . . . . . . . . . 8, 11
. . . . . . . . . . . . . . . . . . . . . . . . . . .7
station
. . . . . . . . . . . . . . . . . . . . . . . . . . .1
. . . . . . . . . . . . . . 10
. . . . . . . . . . . . .7
. . . . . . . . . . . .7
I
Icon
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
display
keypad lock
Icon, ring tone
Idle status
display
Idle status, returning to
Incorrect input (correction)
Industry Canada Certification
Internal call
. . . . . . . . . . . . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . . . . . . . . . . . 13
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
. . . . . . . . . . . . . . . . 11
. . . . . . . . . . . . 12
. . . . . . . . . . 16
. . . . . . . . . . . . . . . . . . . . . . . . . . . 12
K
Keypad lock . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Keys
clear key
Control key
display keys
End Call key
Last Number Redial key
Line 1
Line 2
menu key
mute/unmute microphone
On/Off key
. . . . . . . . . . . . . . . . . . . . . . . . . . . 11
. . . . . . . . . . . . . . . . . . . . . . . 1, 10
. . . . . . . . . . . . . . . . . . . . . . 1, 11
. . . . . . . . . . . . . . . . . . . . . . . 1, 9
. . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
. . . . . . . . . . . . . . . . . . . . . . . . . . 11
. . . . . . . . . . . .1
. . . . . . . . . . . . . . . . . . . . . . . . . . .1
23
Index
Pound key . . . . . . . . . . . . . . . . . . . . . . . . 1, 10
. . . . . . . . . . . . . . . . . . . . . . . . . . 1, 13
star key
. . . . . . . . . . . . . . . . . . . . . . . . . . . 1, 9
Tal k key
Key-touch tone
. . . . . . . . . . . . . . . . . . . . . . . 13
L
Last number redial list . . . . . . . . . . . . . . . . . 10
Line keys
Line settings
Liquid
List, call history
Lock keypad
Loudspeaker volume
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
. . . . . . . . . . . . . . . . . . . . . . . . . . . .8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
. . . . . . . . . . . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . . . . . 13
M
Making calls
answering a call
external
internal
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Medical equipment
Menu
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
key
menu guidance
Menu input
Microphone
mute/unmute
Mute key
. . . . . . . . . . . . . . . . . . . . . . . . . . . 1, 14
. . . . . . . . . . . . . . . . . . . . . . .9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
. . . . . . . . . . . . . . . . . . . . .4
. . . . . . . . . . . . . . . . . . . . . 11
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
. . . . . . . . . . . . . . . . . . . . . . . . . . . .1
. . . . . . . . . . . . . . . . . . . . 1, 14
N
Name of handset, changing . . . . . . . . . . . . 12
O
On/Off key. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Operating time
. . . . . . . . . . . . . . . . . . . . . . . 15
P
Pack contents . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Plug for headset
Pound key
Power consumption
Power supply unit
. . . . . . . . . . . . . . . . . . . . . . . .1
. . . . . . . . . . . . . . . . . . . . . . . . . . 1, 10
. . . . . . . . . . . . . . . . . . . 15
. . . . . . . . . . . . . . . . . . . . . . .4
Q
Questions and answers . . . . . . . . . . . . . . . . 14
R
Redial key . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Registering handset
Ring tone
activating/deactivating
ajusting
changing
setting melody
setting volume
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
. . . . . . . . . . . . . . . . . . . . . . . . . . . 13
. . . . . . . . . . . . . . . . . . . . .7
. . . . . . . . . . . . . . 13
. . . . . . . . . . . . . . . . . . . . . 13
. . . . . . . . . . . . . . . . . . . . . 13
S
Safety precautions . . . . . . . . . . . . . . . . . . . . . .4
Service (Customer Care)
Settings
Setup
Sound, see ring tone
Specifications
Star key
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
auto answer
date
display contrast
key-touch tone
line settings
loudspeaker volume
ring tone melody
ring tone volume
time
. . . . . . . . . . . . . . . . . . . . . . . . 13
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
. . . . . . . . . . . . . . . . . . . . . . . . . .8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
. . . . . . . . . . . . . . . . . . . . . . . . . 15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1, 13
. . . . . . . . . . . . . . . 19
. . . . . . . . . . . . . . . . . . . . . 12
. . . . . . . . . . . . . . . . . . . . . 13
. . . . . . . . . . . . . . . . 13
. . . . . . . . . . . . . . . . . . . 13
. . . . . . . . . . . . . . . . . . . 13
T
Tal k key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1, 9
Time format
Troubleshooting
. . . . . . . . . . . . . . . . . . . . . . . . . . . .8
. . . . . . . . . . . . . . . . . . . . . . 14
U
Unmute key
Unmute microphone
Using several handsets
. . . . . . . . . . . . . . . . 14
. . . . . . . . . . . . . . . . 12
V
Volume
loudspeaker
ring tone
. . . . . . . . . . . . . . . . . . . . . . . . 13
. . . . . . . . . . . . . . . . . . . . . . . . . . . 13
24
Index
25
A31008-M1963-R401-2-5819
U ZZ01 EB(0)U 116
Loading...
