Page 1
Flex 200
Worktable – Operating instructions
Page 2
D
E
F
2x
G H I J
C
4x 4x
K L M
8x
2x
1x 4x
6x 10x
B
N
12x
A
1
H
G
I
A
2
Page 3
2
J
K
I
B
J
K
I
B
3
L
6x
3
Page 4
4
D
N
12x
M
M
F
C
E
4
Page 5
Bordsskiva
Installation instructions
• Place the table at least 120 mm from other objects, eg,
adjoining tables, equipment, wall mounted shelves, etc to
avoid trap hazard.
• Make the top of the table level, ie, with the aid of the
adjustable feet on the frame.
IMPOr TAn T!
T e table must be activated by press the down button on the
table control one or two times and then keep the button pressed
until the table has reach its bottom level. T e table will then raise
app. 5mm. Don’t release the button until the table stands still.
Observe! If the button is released before the complete procedure
is carried out, the table will not be activated and the procedure
has to be started from the beginning again. Sometimes the down
button has to be pressed two times to start the activating due to
that the electronic can be in dif erent positions.
• Ensure that electric cables are undamaged and plug in the
power cable of the table, 230 V AC, ±10%, 50 Hz.
• Test run the table and ensure that the drive axle works on both
sides.
Additional safety devices must be mounted in accordance with
instructions from Gigant if the table is to be placed in series.
When moving the table, never lift it by the top of the table
because the frame is too heavy.
Description
T e table is made for indoor use in an industrial or of ce environment and for 10% intermittent lifting operation, ie, max
2 min per 18 min.
Accessories
Accessories that are approved by Gigant for tables Flex 200
include the following:
• Set of wheels.
• Drawer and drawer suspension.
• Extensionframe for extensions.
• Table control with 3 memory positions.
• Tiltable tabletop.
• Undershelf.
Operating instruction
Raising and lowering the table
• Ensure that the table top, and anything placed on the table,
has clearance in relation to surrounding objects.
• Press the switch to give the desired action. (T e motor runs so
long as the switch is actuated.)
WAr n In G!
Observe the danger of crushing between the table top or frame
and adjoining equipment when raising and lowering.
T e danger of tipping must be considered if load protrudes
beyond the extent of the frame.
For tables with a top that can be sloped:
WAr n In G!
Observe the danger of crushing if the table is f tted with an
adjustable sloping top.
T e top may not be sloped when loose objects are on the table
since this could otherwise result in personal injury.
Conf guration
T e f gure shows the main parts of the table. T e table should be
completed with a suitable tapletop from Gigant product range.
Styrbox
Control box
Electric actuator
Elektrisk motor
Table top
Bordskontroll
Control switch
Teleskopben
Telescopic leg
Function
Lifting action of the table is achieved by an electric actuator
in each teleskopic leg. Glide plates f tted in each telescopic leg
ensure smooth and even lifting action. T e sound pressure level
of the table is lower than 70 dB(A).
Manual reset / zero position
In case of a failure so that the teleskopic legs are not working
parallel, stroke or upper / lower end position is changed, a manual
reset has to be performed, please see Installation Instructions.
Maintenance
T e power cable must be unplugged before attempting any
service work on the table.
All moving parts are lubricated at the factory and are therefore
free from maintenance.
