Gigabyte U21M User Manual

Congratulations on your purchase of the GIGABYTE Notebook!

2

1

3

4

This Manual will help you to get started with setting up your notebook. For more detailed

information, please visit our website at http://www.gigabyte.com. All specications are subject to the
manufacturer's conguration at the time of shipping and may change without prior notice, written or

otherwise.

Using GIGABYTE Notebook for the First Time

1 Connect the the power cord to the AC adapter.

2 Connect the AC adapter to the DC-in jack on the back side of the notebook.

3 Connect the power cord to the power outlet.

4 While the Battery Indicator lights on, press the Power Button to turn on the Notebook.

1

English

Switching on the Power:

After you turn on the U21 for the very rst time, do not turn it off until the operating system has
been congured. Please note that the volume for the audio will not function until Windows® Setup

has completed.

Booting Up the U21 for the First Time:

Depending on your conguration, the Microsoft® Windows® Boot Screen will be the rst screen that

you will see as the notebook starts up. Follow the on screen prompts and instructions and enter
your personal information to complete the setup of the Windows® Operating System.

2

Panoramic View

Your GIGABYTE Notebook Tour

English

2

1 3

9

1 Webcam Status LED Indicator

2 Webcam

3 Light Sensor

4

4 Microphone

5 Windows Button

6 Speakers

7 Touchpad

5

8 Battery Indicator Button

9 LED Indicators

6



Back to Windows 8 Style UI Mode.



Press the right button of touchpad to
check the remaining battery power in
power off mode.



7

8

Bluetooth Status LED

Wireless LAN Status LED

HDD Status LED

Battery Status LED

Power Status LED







Left View

2 31 4 5

1 Power Button

2 USB Port

3 HDMI Port

4 USB Port

5

USB Port (Support USB Charge)

Right View

2 3 4 5 71 6

Rear View

1 2 3 4

3

English

1 Kensington Lock Slot

2 Headphone Jack

3 Microphone Jack

4 SD Card Reader

5 USB Port

6 Volume Control Key

7 Rotation Lock Button

1 DC-in Jack

2 SIM Card Slot

3 D-sub (VGA) Port

4 Ethernet Port

Base View

1

1 Memory Compartment
