GA-Z170X-UD5
User's Manual
Rev. 1001
12ME-Z170UD5-1001R
For more product details, please visit GIGABYTE's website.
To reduce the impacts on global warming, the packaging materials of this product are recyclable and reusable. GIGABYTE works with you to protect the environment.
Motherboard
GA-Z170X-UD5
Motherboard
GA-Z170X-UD5
Jul. 30, 2015
Jul. 30, 2015
Copyright
© 2015 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specifications and features in this manual may be made by GIGABYTE without prior notice.
No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or by any means without GIGABYTE's prior written permission.
Documentation Classifications
In order to assist in the use of this product, GIGABYTE provides the following types of documentations:
For quick set-up of the product, read the Quick Installation Guide included with the product.For detailed product information, carefully read the User's Manual.
For product-related information, check on our website at: http://www.gigabyte.com
Identifying Your Motherboard Revision
The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0" means the revision of the motherboard is 1.0. Check your motherboard revision before updating motherboard BIOS, drivers, or when looking for technical information.
Example:
Table of Contents
Box Contents.................................................................................................................... |
|
|
6 |
Optional Items.................................................................................................................. |
|
6 |
|
GA-Z170X-UD5 Motherboard Layout............................................................................... |
7 |
||
Chapter 1 Hardware Installation...................................................................................... |
9 |
||
1-1 |
Installation Precautions..................................................................................... |
9 |
|
1-2 |
Product Specifications.................................................................................... |
10 |
|
1-3 Installing the CPU and CPU Cooler................................................................ |
13 |
||
|
1-3-1 |
Installing the CPU................................................................................................... |
13 |
|
1-3-2 Installing the CPU Cooler........................................................................................ |
15 |
|
1-4 |
Installing the Memory...................................................................................... |
16 |
|
|
1-4-1 Dual Channel Memory Configuration...................................................................... |
16 |
|
|
1-4-2 |
Installing a Memory................................................................................................. |
17 |
1-5 Installing an Expansion Card.......................................................................... |
18 |
||
1-6 Setting up AMD CrossFire™/NVIDIA® SLI™ Configuration............................... |
19 |
||
1-7 |
Back Panel Connectors.................................................................................. |
20 |
|
1-8 Onboard Buttons, Switch, and Voltage Measurement Points......................... |
22 |
||
1-9 |
Internal Connectors........................................................................................ |
24 |
|
Chapter 2 BIOS Setup................................................................................................... |
37 |
||
2-1 |
Startup Screen................................................................................................ |
38 |
|
2-2 |
The Main Menu............................................................................................... |
39 |
|
2-3 |
M.I.T................................................................................................................ |
41 |
|
2-4 |
System Information......................................................................................... |
53 |
|
2-5 |
BIOS Features................................................................................................ |
54 |
|
2-6 |
Peripherals...................................................................................................... |
57 |
|
2-7 |
Chipset............................................................................................................ |
59 |
|
2-8 |
Power Management........................................................................................ |
60 |
|
2-9 |
Save & Exit..................................................................................................... |
62 |
|
Chapter 3 Configuring a RAID Set................................................................................ |
63 |
||
3-1 |
Configuring SATA Controllers......................................................................... |
63 |
|
3-2 Installing the SATA RAID/AHCI Driver and Operating System....................... |
75 |
- 4 -
Chapter 4 Drivers Installation........................................................................................ |
79 |
|
4-1 |
Chipset Drivers............................................................................................... |
79 |
4-2 |
Application Software....................................................................................... |
80 |
4-3 |
Information...................................................................................................... |
80 |
Chapter 5 Unique Features........................................................................................... |
81 |
||
5-1 |
BIOS Update Utilities...................................................................................... |
81 |
|
|
5-1-1 |
Updating the BIOS with the Q-Flash Utility............................................................. |
81 |
|
5-1-2 |
Updating the BIOS with the @BIOS Utility.............................................................. |
84 |
5-2 |
APP Center..................................................................................................... |
85 |
|
|
5-2-1 |
EasyTune................................................................................................................ |
86 |
|
5-2-2 |
System Information Viewer..................................................................................... |
87 |
|
5-2-3 |
Fast Boot................................................................................................................. |
88 |
|
5-2-4 |
Smart TimeLock...................................................................................................... |
89 |
|
5-2-5 |
USB Blocker............................................................................................................ |
90 |
|
5-2-6 |
Smart Keyboard...................................................................................................... |
91 |
|
5-2-7 |
Smart Backup.......................................................................................................... |
92 |
|
5-2-8 |
Ambient LED........................................................................................................... |
94 |
|
5-2-9 |
3D OSD................................................................................................................... |
95 |
|
5-2-10 |
Cloud Station........................................................................................................... |
96 |
|
5-2-11 |
AutoGreen............................................................................................................. |
101 |
|
5-2-12 |
Easy RAID............................................................................................................. |
102 |
5-3 |
Smart Switch................................................................................................. |
105 |
Chapter 6 Appendix..................................................................................................... |
|
107 |
|
6-1 |
Configuring Audio Input and Output.............................................................. |
107 |
|
|
6-1-1 |
Configuring 2/4/5.1/7.1-Channel Audio................................................................. |
107 |
|
6-1-2 |
Configuring S/PDIF Out........................................................................................ |
109 |
|
6-1-3 |
Configuring Microphone Recording....................................................................... |
110 |
|
6-1-4 Using the Sound Recorder.................................................................................... |
112 |
|
6-2 |
Troubleshooting............................................................................................ |
113 |
|
|
6-2-1 |
Frequently Asked Questions ................................................................................ |
113 |
|
6-2-2 |
Troubleshooting Procedure................................................................................... |
114 |
6-3 |
Debug LED Codes........................................................................................ |
116 |
|
Regulatory Statements............................................................................................ |
120 |
||
Contact Us............................................................................................................... |
|
123 |
- 5 -
55 GA-Z170X-UD5 motherboard
55 Motherboard driver disk
55 User's Manual
55 Quick Installation Guide
55 Four SATA cables
55 I/O Shield
55 One 2-Way SLI bridge connector
55 One G Connector
55 One pack of back I/O dust covers
The box contents above are for reference only and the actual items shall depend on the product package you obtain. The box contents are subject to change without notice.
2-port USB 2.0 bracket (Part No. 12CR1-1UB030-6*R)eSATA bracket (Part No. 12CF1-3SATPW-4*R)
3.5" Front Panel with 2 USB 3.0/2.0 ports (Part No. 12CR1-FPX582-2*R)HDMI-to-DVI adapter (Part No. 12CT2-HDMI01-1*R)
COM port cable (Part No. 12CF1-1CM001-3*R)
- 6 -
KB_MS_USB SYS_FAN1 ATX_12V_2X4
DVI |
LGA1151 |
|
|
||
DP |
|
|
|
Intel® |
|
LAN2 |
GbE LAN |
|
|
||
TYPEC |
|
|
|
Intel® |
|
USB30_ |
Thunderbolt™ 3 |
|
Controller |
||
LAN1 |
||
|
R_USB30
TH_HDMI
AUDIO |
80D |
60D |
42D |
|
|
|
|
PCIEX1_1 |
|
|
|
Intel® GbE |
|
|
|
LAN |
GA-Z170X-UD5 |
||
PCIEX16 |
|||
PCIEX1_2 |
|
|
|
PCIEX1_3 |
80H |
60H |
42H |
PCIEX8
CODEC
PCIEX1_4
BAT
PCIEX4
SPDIF_O
|
PW_SW |
|
CPU_FAN |
|
|
|
|
Debug LED (Note) |
CPU_OPT |
SW |
ECO |
|
RST |
|
|
OC |
|
|
SW |
|
|
ATX |
|
|
CMOS |
|
|
|
M2D_32G |
F USB30 1 |
SYS_FAN3 |
|
|
|
|
|
USB30 2 |
ATX4P |
DDR4 4 |
DDR4 2 |
DDR4 3 |
DDR4 1 F_ |
|
M2H_32G
Intel® Z170
iTE® Super I/O
M_BIOS B_BIOS
ASMedia® |
EXPRESS |
7 23 |
|
ASM1061 |
|
6 |
|
SATA3 |
SATA |
|
|
|
|
SATA3 |
EXPRESSSATA |
4 0 |
|
5 1 |
|
CLR_CMOS |
|
|
|
|
|
|
|
|
|
|
|
SYS_ |
|
FAN2 |
F_ |
|
PANEL |
F_AUDIO COMA THB |
_C |
TPM F_USB2 F_USB1 SB |
|
|
(Note) For debug code information, please refer to Chapter 6.
- 7 -
- 8 -
The motherboard contains numerous delicate electronic circuits and components which can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read the user's manual and follow these procedures:
•• Prior to installation, make sure the chassis is suitable for the motherboard.
•• Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or warranty sticker provided by your dealer. These stickers are required for warranty validation.
•• Always remove the AC power by unplugging the power cord from the power outlet before installing or removing the motherboard or other hardware components.
•• When connecting hardware components to the internal connectors on the motherboard, make sure they are connected tightly and securely.
•• When handling the motherboard, avoid touching any metal leads or connectors.
•• It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic components such as a motherboard, CPU or memory. If you do not have an ESD wrist strap, keep your hands dry and first touch a metal object to eliminate static electricity.
•• Prior to installing the motherboard, please have it on top of an antistatic pad or within an electrostatic shielding container.
•• Before connecting or unplugging the power supply cable from the motherboard, make sure the power supply has been turned off.
•• Before turning on the power, make sure the power supply voltage has been set according to the local voltage standard.
•• Before using the product, please verify that all cables and power connectors of your hardware components are connected.
•• To prevent damage to the motherboard, do not allow screws to come in contact with the motherboard circuit or its components.
•• Make sure there are no leftover screws or metal components placed on the motherboard or within the computer casing.
•• Do not place the computer system on an uneven surface.
•• Do not place the computer system in a high-temperature or wet environment.
•• Turning on the computer power during the installation process can lead to damage to system components as well as physical harm to the user.
•• If you are uncertain about any installation steps or have a problem related to the use of the product, please consult a certified computer technician.
•• If you use an adapter, extension power cable, or power strip, ensure to consult with its installation and/or grounding instructions.
- 9 - |
Hardware Installation |
1-2 |
Product Specifications |
|
|
|
|
|
CPU |
Support for Intel® Core™ i7 processors/Intel® Core™ i5 processors/ |
|
|
Intel® Core™ i3 processors/Intel® Pentium® processors/ |
|
|
Intel® Celeron® processors in the LGA1151 package |
|
|
(Go to GIGABYTE's website for the latest CPU support list.) |
|
|
L3 cache varies with CPU |
|
Chipset |
Intel® Z170 Express Chipset |
|
Memory |
4 x DDR4 DIMM sockets supporting up to 64 GB of system memory |
* Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
Dual channel memory architecture
Support for DDR4 2133 MHz memory modules
Support for ECC UDIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC UDIMM 1Rx8/2Rx8/1Rx16 memory modulesSupport for Extreme Memory Profile (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory modules.)
Onboard
Graphics
Integrated Graphics Processor-Intel® HD Graphics support:
-1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
*The DVI-D port does not support D-Sub connection by adapter.
-1 x DisplayPort, supporting a maximum resolution of 4096x2160@24 Hz or 3840x2160@60 Hz
*Support for DisplayPort 1.2 version.
-1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz
*Support for HDMI 1.4 version.
Support for up to 3 displays at the same time
Maximum shared memory of 512 MB
Audio |
|
Realtek® ALC1150 codec |
|
High Definition Audio |
|
|
|
2/4/5.1/7.1-channel |
|
Support for S/PDIF Out |
|
LAN |
|
2 x Intel® GbE LAN chips (10/100/1000 Mbit) |
|
|
Support for Teaming |
Expansion Slots |
|
1 x PCI Express x16 slot, running at x16 (PCIEX16) |
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
1 x PCI Express x16 slot, running at x8 (PCIEX8)
* The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot will operate at up to x8 mode.
1 x PCI Express x16 slot, running at x4 (PCIEX4)
* The PCIEX4 slot shares bandwidth with the M2H_32G connector. The PCIEX4 slot will become unavailable when an SSD is installed in the M2H_32G connector.
4 x PCI Express x1 slots
(All of the PCI Express slots conform to PCI Express 3.0 standard.)
Hardware Installation |
- 10 - |
Multi-Graphics |
|
Support for 3-Way/2-Way AMD CrossFire™and 2-Way NVIDIA® SLI™ Technology |
|
Technology |
|
|
|
Storage Interface |
|
Chipset: |
|
|
|
- 2 x M.2 Socket 3 connectors |
|
|
|
- 3 x SATA Express connectors |
|
|
|
- 6 x SATA 6Gb/s connectors (SATA3 0~5) |
|
|
|
- Support for RAID 0, RAID 1, RAID 5, and RAID 10 |
|
|
|
* Refer to "1-9 Internal Connectors," for the supported configurations with the M.2, |
|
|
|
SATA Express, and SATA connectors. |
|
|
|
ASMedia® ASM1061 chip: |
|
|
|
- 2 x SATA 6Gb/s connectors (SATA3 6~7), supporting AHCI mode only |
|
USB |
|
Chipset+Intel® Thunderbolt™ 3 Controller: |
|
|
|
- 1 x USB Type-C™ port on the back panel, with USB 3.1 support |
|
|
|
- 1 x USB 3.1 port on the back panel |
|
|
|
Chipset: |
|
|
|
- 7 x USB 3.0/2.0 ports (3 ports on the back panel, 4 ports available through |
|
|
|
the internal USB headers) |
|
|
|
- 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through |
|
|
|
the internal USB headers) |
|
Internal |
|
1 x 24-pin ATX main power connector |
|
Connectors |
|
1 x 8-pin ATX 12V power connector |
|
|
|
2 x M.2 Socket 3 connectors |
|
|
|
3 x SATA Express connectors |
|
|
|
8 x SATA 6Gb/s connectors |
|
|
|
1 x CPU fan header |
|
|
|
1 x water cooling fan header (CPU_OPT) |
|
|
|
3 x system fan headers |
|
|
|
1 x front panel header |
|
|
|
1 x front panel audio header |
|
|
|
1 x S/PDIF Out header |
|
|
|
2 x USB 3.0/2.0 headers |
|
|
|
2 x USB 2.0/1.1 headers |
|
|
|
1 x Trusted Platform Module (TPM) header |
|
|
|
1 x Thunderbolt™ add-in card connector |
|
|
|
1 x serial port header |
|
|
|
1 x Clear CMOS jumper |
|
|
|
1 x power button |
|
|
|
1 x reset button |
|
|
|
1 x Clear CMOS button |
|
|
|
1 x ECO button |
|
|
|
1 x OC button |
|
|
|
Voltage measurement points |
|
Back Panel |
|
2 x USB 2.0/1.1 ports |
|
Connectors |
|
1 x PS/2 keyboard/mouse port |
|
|
|
1 x DVI-D port |
|
|
|
1 x DisplayPort |
|
|
|
1 x HDMI port |
|
|
|
3 x USB 3.0/2.0 ports |
|
|
|
1 x USB Type-C™ port, with USB 3.1 support |
|
|
|
|
|
|
|
- 11 - |
Hardware Installation |
Back Panel
Connectors
1 x USB 3.1 port
2 x RJ-45 ports
1 x optical S/PDIF Out connector
5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In, Line Out, Mic In)
I/O Controller |
|
iTE® I/O Controller Chip |
Hardware |
|
System voltage detection |
Monitor |
|
CPU/System/Chipset temperature detection |
|
CPU/CPU OPT/System fan speed detection |
|
|
|
CPU/System/Chipset overheating warning |
|
CPU/CPU OPT/System fan fail warning |
|
|
CPU/CPU OPT/System fan speed control |
* Whether the fan speed control function is supported will depend on the cooler you install.
BIOS |
|
2 x 128 Mbit flash |
|
|
Use of licensed AMI UEFI BIOS |
Support for DualBIOS™
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features |
Support for APP Center |
|
|
|
* Available applications in APP Center may vary by motherboard model. Supported |
|
|
functions of each application may also vary depending on motherboard specifications. |
|
- |
3D OSD |
|
- |
@BIOS |
|
- |
Ambient LED |
|
- |
AutoGreen |
|
- |
Cloud Station |
|
- |
EasyTune |
|
- |
Easy RAID |
|
- |
Fast Boot |
|
- |
Smart TimeLock |
|
- |
Smart Keyboard |
|
- |
Smart Backup |
|
- |
System Information Viewer |
|
- |
USB Blocker |
|
Support for Q-Flash |
|
|
Support for Smart Switch |
|
|
Support for Xpress Install |
|
Bundled |
Norton® Internet Security (OEM version) |
|
Software |
Intel® Smart Response Technology |
cFosSpeed
Operating |
|
Support for Windows 10/8.1/7 |
|
System |
|||
|
|
||
Form Factor |
|
ATX Form Factor; 30.5cm x 24.4cm |
*GIGABYTE reserves the right to make any changes to the product specifications and product-related information without prior notice.
Hardware Installation |
- 12 - |
Please visit GIGABYTE's website for support lists of CPU, memory modules, SSDs, and M.2 devices.
Please visit the Support & Downloads\Utility page on GIGABYTE's website to download the latest version of apps.
Read the following guidelines before you begin to install the CPU:
•• Make sure that the motherboard supports the CPU.
(Go to GIGABYTE's website for the latest CPU support list.)
•• Always turn off the computer and unplug the power cord from the power outlet before installing the CPU to prevent hardware damage.
•• Locate the pin one of the CPU. The CPU cannot be inserted if oriented incorrectly. (Or you may locate the notches on both sides of the CPU and alignment keys on the CPU socket.)
•• Apply an even and thin layer of thermal grease on the surface of the CPU.
•• Do not turn on the computer if the CPU cooler is not installed, otherwise overheating and damage of the CPU may occur.
•• Set the CPU host frequency in accordance with the CPU specifications. It is not recommended that the system bus frequency be set beyond hardware specifications since it does not meet the standard requirements for the peripherals. If you wish to set the frequency beyond the standard specifications, please do so according to your hardware specifications including the CPU, graphics card, memory, hard drive, etc.
A. Locate the alignment keys on the motherboard CPU socket and the notches on the CPU.
|
LGA1151 CPU Socket |
Alignment |
Alignment |
Key |
Key |
Pin One Corner of the CPU Socket
|
LGA1151 CPU |
Notch |
Notch |
Triangle Pin One Marking on the CPU
Please visit GIGABYTE's website for details on hardware installation.
- 13 - |
Hardware Installation |
B. Follow the steps below to correctly install the CPU into the motherboard CPU socket.
• Before installing the CPU, make sure to turn off the computer and unplug the power cord from the power outlet to prevent damage to the CPU.
•To protect the socket contacts, do not remove the protective plastic cover unless the CPU is inserted into the CPU socket. Save the cover properly and replace it if the CPU is removed.
Step 1:
Gently press the CPU socket lever handle down and away from the socket with your finger. Then completely lift the CPU socket lever and the metal load plate/plastic cover will be lifted as well.
Step 3:
Once the CPU is properly inserted, carefully replace the load plate. When replacing the load plate, make sure the front end of the load plate is under the shoulder screw. Then press the CPU socket lever. The protective plastic cover may pop off from the load plate during the process of engaging the lever. Remove the cover. (Save the cover properly and always replace it when the
CPU is not installed.)
Step 2:
Hold the CPU with your thumb and index fingers. Align the CPU pin one marking (triangle) with the pin one corner of the CPU socket (or you may align the CPU notches with the socket alignment keys) and gently insert the CPU into position.
Step 4:
Finally, secure the lever under its retention tab to complete the installation of the CPU.
NOTE:
Hold the CPU socket lever by the handle, not the lever base portion.
Hardware Installation |
- 14 - |
Refer to the steps below to correctly install the CPU cooler on the motherboard. (Actual installation process may differ depending the CPU cooler to be used. Refer to the user's manual for your CPU cooler.)
Step 1:
Apply an even and thin layer of thermal grease on the surface of the installed CPU.
Step 3:
Place the cooler atop the CPU, aligning the four push pins through the pin holes on the motherboard. Push down on the push pins diagonally.
|
|
|
|
|
Male |
|
|
|
|
|
|
Direction of |
|
|
Push Pin |
||
the Arrow Sign |
|
|
|
||
on the Male |
|
|
|
The Top |
|
Push Pin |
|
|
|||
|
|
of Female |
|||
|
|
|
|
|
Push Pin |
|
|
|
|
|
Female |
|
|
|
|
||
|
|
|
|
|
Push Pin |
Step 2:
Before installing the cooler, note the direction of the arrow sign on the male push pin. (Turning the push pin along the direction of arrow is to remove the cooler, on the contrary, is to install.)
Step 4:
You should hear a "click" when pushing down each push pin. Check that the Male and Female push pins are joined closely.
(Refer to your CPU cooler installation manual for instructions on installing the cooler.)
Step 5:
After the installation, check the back of the motherboard. If the push pin is inserted as the picture above shows, the installation is complete.
Step 6:
Finally, attach the power connector of the CPU cooler to the CPU fan header (CPU_FAN) on the motherboard.
Use extreme care when removing the CPU cooler because the thermal grease/tape between the CPU cooler and CPU may adhere to the CPU. Inadequately removing the CPU cooler may damage the CPU.
- 15 - Hardware Installation
Read the following guidelines before you begin to install the memory:
•• Make sure that the motherboard supports the memory. It is recommended that memory of the same capacity, brand, speed, and chips be used.
(Go to GIGABYTE's website for the latest supported memory speeds and memory modules.)
•• Always turn off the computer and unplug the power cord from the power outlet before installing the memory to prevent hardware damage.
•• Memory modules have a foolproof design. A memory module can be installed in only one direction.
If you are unable to insert the memory, switch the direction.
This motherboard provides four memory sockets and supports Dual Channel Technology. After the memory is installed, the BIOS will automatically detect the specifications and capacity of the memory. Enabling Dual
Channel memory mode will double the original memory bandwidth.
The four DDR4 memory sockets are divided into two channels and each channel has two memory sockets as following:
Channel A: DDR4_2, DDR4_4Channel B: DDR4_1, DDR4_3
Dual Channel Memory Configurations Table
|
DDR4_4 |
DDR4_2 |
DDR4_3 |
DDR4_1 |
2 Modules |
- - |
DS/SS |
- - |
DS/SS |
|
DS/SS |
- - |
DS/SS |
- - |
4 Modules |
DS/SS |
DS/SS |
DS/SS |
DS/SS |
(SS=Single-Sided, DS=Double-Sided, "- -"=No Memory) |
|
DDR4_1
DDR4_3
DDR4_2
DDR4_4
Due to CPU limitations, read the following guidelines before installing the memory in Dual Channel mode.
1.Dual Channel mode cannot be enabled if only one memory module is installed.
2.When enabling Dual Channel mode with two or four memory modules, it is recommended that memory of the same capacity, brand, speed, and chips be used and installed in the same colored sockets.
Hardware Installation |
- 16 - |
Before installing a memory module, make sure to turn off the computer and unplug the power cord from the power outlet to prevent damage to the memory module. DDR4 and DDR3 DIMMs are not compatible to each other or DDR2 DIMMs. Be sure to install DDR4 DIMMs on this motherboard.
Notch
DDR4 DIMM
ADDR4 memory module has a notch, so it can only fit in one direction. Follow the steps below to correctly install your memory modules in the memory sockets.
Step 1:
Note the orientation of the memory module. Spread the retaining clip at the right end of the memory socket. Place the memory module on the socket. As indicated in the picture on the left, place your fingers on the top edge of the memory, push down on the memory and insert it vertically into the memory socket.
Step 2:
The clip at the right end of the socket will snap into place when the memory module is securely inserted.
- 17 - |
Hardware Installation |
Read the following guidelines before you begin to install an expansion card:
•• Make sure the motherboard supports the expansion card. Carefully read the manual that came with your expansion card.
•• Always turn off the computer and unplug the power cord from the power outlet before installing an expansion card to prevent hardware damage.
PCI Express x1 Slot
PCI Express x16 Slot
Follow the steps below to correctly install your expansion card in the expansion slot.
1.Locate an expansion slot that supports your card. Remove the metal slot cover from the chassis back panel.
2.Align the card with the slot, and press down on the card until it is fully seated in the slot.
3.Make sure the metal contacts on the card are completely inserted into the slot.
4.Secure the card's metal bracket to the chassis back panel with a screw.
5.After installing all expansion cards, replace the chassis cover(s).
6.Turn on your computer. If necessary, go to BIOS Setup to make any required BIOS changes for your expansion card(s).
7.Install the driver provided with the expansion card in your operating system.
Example: Installing and Removing a PCI Express Graphics Card:
•• Installing a Graphics Card:
Gently push down on the top edge of the card until it is fully inserted into the PCI Express slot. Make sure the card is securely seated in the slot and does not rock.
•• Removing the Card:
Gently push back on the lever on the slot and then lift the card straight out from the slot.
Hardware Installation |
- 18 - |
A.System Requirements
-- Windows 10/8.1/7 operating system
-- A CrossFire/SLI-supported motherboard with two or more PCI Express x16 slots and correct driver -- CrossFire/SLI-ready graphics cards of identical brand and chip and correct driver
(Current GPUs that support 3-Way CrossFire technology include theATI Radeon™ HD 3800, HD 4800, HD
5800 series, and AMD Radeon™ HD 6800, HD 6900, HD 7800, and HD 7900 series. For the latest GPU support information, please refer to the AMD website.)
-- CrossFire (Note)/SLI bridge connectors
-- A power supply with sufficient power is recommended (Refer to the manual of your graphics cards for the power requirement)
B.Connecting the Graphics Cards
Step 1:
Observe the steps in "1-5 Installing an Expansion Card" and install CrossFire/SLI graphics cards on the PCI
Express x16 slots. (To set up a 2-Way configuration, we recommend installing the graphics cards on the PCIEX16 and PCIEX8 slots.)
Step 2:
Insert the CrossFire (Note)/SLI bridge connectors in the CrossFire/SLI gold edge connectors on top of the cards. Step 3:
Plug the display cable into the graphics card on the PCIEX16 slot.
C. Configuring the Graphics Card Driver
C-1. To Enable CrossFire Function
After installing the graphics card driver in the operating system,
go to the Catalyst Control Center. Browse to Performance\ AMD CrossFireX™ and ensure the Enable AMD CrossFireX
check box is selected. If your system has more than two CrossFire cards, select the GPU combination you want to use and click Apply. (Available combination options are dependent on the number of graphics cards.)
C-2. To Enable SLI Function
After installing the graphics card driver in the operating system, go to the NVIDIA Control Panel. Browse to the Configure
SLI, Surround, Physx screen and ensure Maximize 3D performance is enabled.
(Note) The bridge connector(s) may be needed or not depending on your graphics cards.
•• Procedure and driver screen for enabling CrossFire/SLI technology may differ by graphics cards
and driver version. Refer to the manual that came with your graphics cards for more information about enabling CrossFire/SLI technology.
•• When two or more graphics cards are installed, we recommend that you connect the SATA power cable from the power supply to the ATX4P connector to ensure system stability.
- 19 - |
Hardware Installation |
USB 2.0/1.1 Port
The USB port supports the USB 2.0/1.1 specification. Use this port for USB devices such as a USB keyboard/mouse, USB printer, USB flash drive and etc.
PS/2 Keyboard/Mouse Port
Use this port to connect a PS/2 mouse or keyboard.
DVI-D Port (Note)
The DVI-D port conforms to the DVI-D specification and supports a maximum resolution of 1920x1200@60 Hz (the actual resolutions supported depend on the monitor being used). Connect a monitor that supports DVI-D connection to this port.
DisplayPort
DisplayPort delivers high quality digital imaging and audio, supporting bi-directional audio transmission. DisplayPort can support both DPCP and HDCP content protection mechanisms. You can use this port to connect your DisplayPort-supported monitor. The maximum supported resolution is 4096x2160@24 Hz or 3840x2160@60 Hz, but the actual resolutions supported are dependent on the monitor being used.
RJ-45 LAN Port
The Gigabit Ethernet LAN port provides Internet connection at up to 1 Gbps data rate. The following describes the states of the LAN port LEDs.
Connection/ |
|
|
|
Activity LED |
Connection/Speed LED: |
|
Activity LED: |
|
|||||||||||
Speed LED |
|
|
|
|
|
||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
State |
Description |
|
State |
Description |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Orange |
1 Gbps data rate |
|
Blinking |
Data transmission or receiving is occurring |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Green |
100 Mbps data rate |
|
On |
No data transmission or receiving is occurring |
|
|
|
|
LAN Port |
Off |
10 Mbps data rate |
|
|
|
||||||||||
|
|
|
|
|
|
|
|
|
USB Type-C™ Port
The reversible USB port supports the USB 3.1 specification and is compatible to the USB 3.0/2.0 specification. Use this port for USB devices.
USB 3.0/2.0 Port
The USB 3.0 port supports the USB 3.0 specification and is compatible to the USB 2.0/1.1 specification. Use this port for USB devices such as a USB keyboard/mouse, USB printer, USB flash drive and etc.
USB 3.1 Port
TheUSB3.1portsupportstheUSB3.1specification andiscompatibletotheUSB3.0/2.0/1.1specification. Use this port for USB devices such as a USB keyboard/mouse, USB printer, USB flash drive and etc.
HDMI Port
The HDMI port is HDCP compliant and supports Dolby True HD and DTS HD
Master Audio formats. It also supports up to 192KHz/24bit 8-channel LPCM audio output. You can use this port to connect your HDMI-supported monitor. The maximum supported resolution
is 4096x2160@24 Hz, but the actual resolutions supported are dependent on the monitor being used.
(Note) The DVI-D port does not support D-Sub connection by adapter.
Hardware Installation |
- 20 - |
•• To set up a triple-display configuration, you must install motherboard drivers in the operating system first.
•• After installing the HDMI/DisplayPort device, make sure to set the default sound playback device to
HDMI/DisplayPort. (The item name may differ depending on your operating system.)
In Windows 8.1, select Apps>Control Panel>Hardware and
Sound>Sound>Playback, set Intel(R) Display Audio to the default playback device.
Center/Subwoofer Speaker Out Jack (Orange)
Use this audio jack to connect center/subwoofer speakers in a 5.1/7.1-channel audio configuration.
Rear Speaker Out Jack (Black)
This jack can be used to connect front speakers in a 4/5.1/7.1-channel audio configuration.
Optical S/PDIF Out Connector
This connector provides digital audio out to an external audio system that supports digital optical audio. Before using this feature, ensure that your audio system provides an optical digital audio in connector.
Line In Jack (Blue)
The line in jack. Use this audio jack for line in devices such as an optical drive, walkman, etc.
Line Out Jack (Green)
The line out jack. This jack supports audio amplifying function. For better sound quality, it is recommended that you connect your headphone/speaker to this jack (actual effects may vary by the device being used).
Use this audio jack for a headphone or 2-channel speaker. This jack can be used to connect front speakers
in a 4/5.1/7.1-channel audio configuration.
Mic In Jack (Pink)
The Mic in jack.
If you want to install a Side Speaker, you need to retask either the Line in or Mic in jack to be Side Speaker out through the audio driver. Refer to the instructions on setting up a 2/4/5.1/7.1-channel
audio configuration in Chapter 6, "Configuring 2/4/5.1/7.1-Channel Audio."
•• When removing the cable connected to a back panel connector, first remove the cable from your device and then remove it from the motherboard.
•• When removing the cable, pull it straight out from the connector. Do not rock it side to side to prevent an electrical short inside the cable connector.
- 21 - |
Hardware Installation |
SB Switch
The SB switch allows enabling or disabling of the Dual BIOS function.
SB
2 1 1: Dual BIOS
2 1 2: Single BIOS
SB
Quick Buttons
This motherboard has 3 quick buttons: power button, reset button and clear CMOS button. The power button and reset button allow users to quickly turn on/off or reset the computer in an open-case environment when they want to change hardware components or conduct hardware testing. Use this button to clear the BIOS configuration and reset the CMOS values to factory defaults when needed.
PW_SW
RST_SW
CMOS_SW
PW_SW: Power Button
RST_SW: Reset Button
CMOS_SW: Clear CMOS Button
•• Always turn off your computer and unplug the power cord from the power outlet before using the clear CMOS button.
•• Do not use the clear CMOS button when the system is on, or the system may shutdown and data loss or damage may occur.
•• Aftersystemrestart,gotoBIOSSetuptoloadfactorydefaults(selectLoadOptimizedDefaults)or manuallyconfiguretheBIOSsettings(refertoChapter2,"BIOSSetup,"forBIOSconfigurations).
Hardware Installation |
- 22 - |
ECO Button and OC Button
GIGABYTE's unique ECO button provides power-saving features by automatically reducing the overall power consumption according to current system load. The OC button helps enthusiasts and overclockers not only get the most performance from their hardware, but also the absolute most enjoyable OC experience.
ECO Button:
ECO Press this button to enable this feature.
OC
OC Button:
Press this button to load the most optimized GIGABYTE overclocking configuration for your hardware.
Voltage Measurement Points
Users can use a multimeter to measure the following component voltages. Refer to the steps below.
|
|
VCCIO VAXG VDIMM DDRVTT PCHIO VSA VCORE 25VVPP |
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
Pin No. |
Definition |
|
|
|
|
|
|
|
|
|
|
|
1 |
Power |
|
|
|
|
|
|
|
|
|
|
|
2 |
GND |
|
|
Pin 1 Pin 1 Pin 1 Pin 1 Pin 1 Pin 1 Pin 1 Pin 1 |
||||||||||
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Steps:
Connecttheredleadofthemultimetertothepin1(Power)ofavoltage measurement point and the black lead to the pin 2 (ground).
- 23 - |
Hardware Installation |
5 |
1 |
6 |
4 |
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2 |
|
|
|
|
|
5 |
10 |
|
|
|
|
3 |
|
|
|
|
|
14 |
|
|
|
|
|
9 |
|
|
|
|
|
8 |
10 |
|
|
|
|
7 |
|
|
|
|
|
|
20 |
|
|
|
|
8 |
|
|
|
|
|
|
13 |
|
|
|
|
7 |
|
|
|
|
19 |
|
12 |
|
|
|
|
|
|
|
|
|
|
|
16 |
18 |
17 |
15 |
5 |
11 |
1) |
ATX_12V_2X4 |
11) |
F_PANEL |
2) |
ATX |
12) |
F_AUDIO |
3) |
ATX4P |
13) |
SPDIF_O |
4) |
CPU_FAN |
14) |
F_USB30_1/F_USB30_2 |
5) |
SYS_FAN1/2/3 |
15) |
F_USB1/F_USB2 |
6) |
CPU_OPT |
16) |
COMA |
7) |
SATA EXPRESS |
17) |
TPM |
8) |
SATA3 0/1/2/3/4/5 |
18) |
THB_C |
9) |
SATA3 6/7 |
19) |
CLR_CMOS |
10) |
M2H_32G/M2D_32G |
20) |
BAT |
Read the following guidelines before connecting external devices:
•• First make sure your devices are compliant with the connectors you wish to connect.
•• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power cord from the power outlet to prevent damage to the devices.
•• After installing the device and before turning on the computer, make sure the device cable has been securely attached to the connector on the motherboard.
Hardware Installation |
- 24 - |
1/2) ATX_12V_2X4/ATX (2x4 12V Power Connector and 2x12 Main Power Connector)
With the use of the power connector, the power supply can supply enough stable power to all the components on the motherboard. Before connecting the power connector, first make sure the power supply is turned off and all devices are properly installed. The power connector possesses a foolproof design. Connect the power supply cable to the power connector in the correct orientation.
The 12V power connector mainly supplies power to the CPU. If the 12V power connector is not connected, the computer will not start.
To meet expansion requirements, it is recommended that a power supply that can withstand high power consumption be used (500W or greater). If a power supply is used that does not provide the required power, the result can lead to an unstable or unbootable system.
12 24
1 |
13 |
ATX
|
|
|
|
|
ATX_12V_2X4: |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Pin No. |
Definition |
|
|
|
|
|
|
1 |
GND (Only for 2x4-pin 12V) |
|
|
|
|
|
|
2 |
GND (Only for 2x4-pin 12V) |
|
5 |
8 |
|
3 |
GND |
||
|
|
4 |
GND |
||||
|
|
1 |
4 |
|
|||
|
|
|
5 |
+12V (Only for 2x4-pin 12V) |
|||
|
|
|
|
|
|
|
|
|
|
|
ATX_12V_2X4 |
|
|
6 |
+12V (Only for 2x4-pin 12V) |
|
|
|
|
||||
|
|
|
|
|
|
7 |
+12V |
|
|
|
|
|
|
8 |
+12V |
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
ATX: |
|
|
|
Pin No. |
Definition |
Pin No. |
Definition |
1 |
3.3V |
13 |
3.3V |
2 |
3.3V |
14 |
-12V |
3 |
GND |
15 |
GND |
4 |
+5V |
16 |
PS_ON (soft On/Off) |
5 |
GND |
17 |
GND |
6 |
+5V |
18 |
GND |
7 |
GND |
19 |
GND |
8 |
Power Good |
20 |
-5V |
9 |
5VSB (stand by +5V) |
21 |
+5V |
10 |
+12V |
22 |
+5V |
11 |
+12V (Only for 2x12-pin |
23 |
+5V (Only for 2x12-pin ATX) |
|
ATX) |
|
|
12 |
3.3V (Only for 2x12-pin |
24 |
GND (Only for 2x12-pin |
|
ATX) |
|
ATX) |
- 25 - |
Hardware Installation |
3)ATX4P (PCIe Power Connector)
The power connector provide auxiliary power to the onboard PCI Express x16 slots. When two or more graphics cards are installed, we recommend that you connect the SATA power cable from the power supply to the ATX4P connector to ensure system stability.
|
Pin No. |
Definition |
|
|
1 |
NC |
|
|
2 |
NC |
|
1 |
3 |
NC |
|
4 |
GND |
||
|
|||
|
5 |
GND |
|
15 |
6 |
GND |
|
7 |
VCC |
||
|
8 |
VCC |
|
|
9 |
VCC |
|
|
10 |
GND |
|
|
11 |
GND |
|
|
12 |
GND |
|
|
13 |
+12V |
|
|
14 |
+12V |
|
|
15 |
+12V |
4/5) CPU_FAN/SYS_FAN1/SYS_FAN2/SYS_FAN3 (Fan Headers)
All fan headers on this motherboard are 4-pin. Most fan headers possess a foolproof insertion design. When connecting a fan cable, be sure to connect it in the correct orientation (the black connector wire is the ground wire). The motherboard supports CPU fan speed control, which requires the use of a CPU fan with fan speed control design. For optimum heat dissipation, it is recommended that a system fan be installed inside the chassis.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
CPU_FAN: |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Pin No. |
Definition |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1 |
GND |
|
|
|
|
|
|
|
|
1 |
|
|
2 |
+12V |
|||
|
|
|
|
|
|
|
|
3 |
Sense |
||||||
|
|
|
|
|
|
CPU_FAN |
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4 |
Speed Control |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SYS_FAN1/2/3: |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
1 |
1 |
|
|
|
|
Pin No. |
Definition |
||
|
|
|
|
|
|
|
|
1 |
GND |
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
SYS_FAN1 |
|
|
|
SYS_FAN2 |
|
|
||||||
|
2 |
+12V / Speed Control |
|||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3 |
Sense |
|
|
|
|
|
|
|
|
|
1 |
|
|
|
4 |
VCC |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
SYS_FAN3 |
|
|
•• Be sure to connect fan cables to the fan headers to prevent your CPU and system from overheating. Overheating may result in damage to the CPU or the system may hang.
•• Thesefanheadersarenotconfigurationjumperblocks.Donotplaceajumpercapontheheaders.
Hardware Installation |
- 26 - |
6)CPU_OPT (Water Cooling CPU Fan Header)
The fan header is 4-pin and possesses a foolproof insertion design. When connecting a fan cable, be sure to connect it in the correct orientation (the black connector wire is the ground wire). The speed control function requires the use of a fan with fan speed control design.
|
|
|
|
|
|
|
Pin No. |
Definition |
|
|
|
|
|
|
|
1 |
GND |
|
|
|
|
1 |
2 |
+12V / Speed Control |
||
|
|
|
|
|
|
|
3 |
Sense |
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
4 |
VCC |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
7)SATA EXPRESS (SATA Express Connectors)
Each SATA Express connector supports a single SATA Express device.
- 27 - |
Hardware Installation |
8)SATA3 0/1/2/3/4/5 (SATA 6Gb/s Connectors, Controlled by Intel® Z170 Chipset)
The SATA connectors conform to SATA 6Gb/s standard and are compatible with SATA 3Gb/s and SATA 1.5Gb/s standard. Each SATA connector supports a single SATA device. The Intel® Chipset supports
RAID 0, RAID 1, RAID 5, and RAID 10. Refer to Chapter 3, "Configuring a RAID Set," for instructions on configuring a RAID array.
|
|
|
|
|
|
SATA3 |
|
|
|
|
|
|
||||||
|
7 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1 |
||
|
7 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
5 |
4 |
|
|
|
|
|
|
3 |
2 |
|
|
|
|
||
|
|
|
1 |
0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Pin No. |
Definition |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1 |
GND |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2 |
TXP |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3 |
TXN |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4 |
GND |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
5 |
RXN |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
6 |
RXP |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
7 |
GND |
|
|
|
|
|
|
|
|
|
|
|
|
To enable hot-plugging for the SATA ports, refer to Chapter 2, "BIOS Setup," "Peripherals\SATA
Configuration," for more information.
9)SATA3 6/7 (SATA 6Gb/s Connectors, Controlled by ASMedia® ASM1061 Chip)
The SATA connectors conform to SATA 6Gb/s standard and are compatible with SATA 3Gb/s and SATA 1.5Gb/s standard. Each SATA connector supports a single SATA device.
SATA3 7 6
7 1
Hardware Installation |
- 28 - |
10)M2H_32G/M2D_32G (M.2 Socket 3 Connectors)
The M.2 connectors support M.2 SATASSDs and M.2 PCIe SSDs and support RAID configuration through the Intel® Chipset. Please note that an M.2 PCIe SSD cannot be used to create a RAID set either with an M.2 SATASSD or a SATAhard drive and can only be used to build a RAID set with UEFI. Refer to Chapter 3, "Configuring a RAID Set," for instructions on configuring a RAID array.
M2D_32G
80D 60D 42D
M2H_32G
80H |
60H |
42H |
Follow the steps below to correctly install an M.2 SSD in the M.2 connector.
Step 1: |
Step 2: |
||
Use a screw driver to unfasten the screw and nut |
Slide the M.2 SSD into the connector at an angle. |
||
from the motherboard. Locate the proper mounting |
|
|
|
hole for the M.2 SSD to be installed and then |
|
|
|
screw the nut first. |
|
|
|
|
|
|
|
|
|
|
|
Step 3: |
Step 4: |
Press the M.2 SSD down and then secure it with |
The installation is completed, as shown in the |
the screw. |
picture above. |
•• On the motherboard there are three length adjustment holes for the M.2 SSD. Select the proper hole for the M.2 SSD to be installed and refasten the screw and nut.
•• The PCIEX4 slot shares bandwidth with the M2H_32G connector. The PCIEX4 slot will become unavailable when an SSD is installed in the M2H_32G connector.
- 29 - |
Hardware Installation |
When installing different types of M.2 SSDs (including SATA SSDs, PCIe x4 SSDs, and PCIe x2 SSDs), be sure to refer to the supported configurations in the tables below according to the operating mode of your SATA controller (AHCI mode or RAID mode).
•• AHCI mode: |
|
|
|
|
|
|
M2D_32G M.2 connector |
|
|
|
|
|
|
Connector |
SATA3_0 |
SATA3_1 |
SATA3_2 |
SATA3_3 |
SATA3_4 |
SATA3_5 |
Type of SSD |
SATA Express |
SATA Express |
SATA Express |
|||
SATA SSD |
a |
a |
a |
r |
a |
a |
|
a |
|
|
r |
|
a |
PCIe x4 SSD |
r |
r |
r |
r |
a |
a |
|
a(Note) |
|
|
r |
|
a |
PCIe x2 SSD |
a |
a |
r |
r |
a |
a |
|
a |
|
|
r |
|
a |
a: Supported, r: Not supported. |
|
|
|
|
|
M2H_32G M.2 connector
Connector |
SATA3_0 |
|
SATA3_1 |
SATA3_2 |
|
SATA3_3 |
SATA3_4 |
|
SATA3_5 |
Type of SSD |
SATA Express |
SATA Express |
SATA Express |
||||||
SATA SSD |
r |
|
a |
a |
|
a |
a |
|
a |
|
|
a |
|
a |
|
a |
|||
PCIe x4 SSD |
a |
|
a |
a |
|
a |
a |
|
a |
|
|
a |
|
a |
|
a |
|||
PCIe x2 SSD |
a |
|
a |
a |
|
a |
a |
|
a |
|
a |
|
|
a |
|
a |
a: Supported, r: Not supported. |
|
|
|
|
|
|
•• RAID mode: |
|
|
|
|
|
|
M2D_32G M.2 connector |
|
|
|
|
|
|
Connector |
SATA3_0 |
SATA3_1 |
SATA3_2 |
SATA3_3 |
SATA3_4 |
SATA3_5 |
Type of SSD |
SATA Express |
SATA Express |
SATA Express |
|||
SATA SSD |
a |
a |
a |
r |
a |
a |
|
a |
|
|
r |
|
a |
PCIe x4 SSD |
r |
r |
r |
r |
a |
r |
|
a(Note) |
|
|
r |
|
r |
PCIe x2 SSD |
a |
a |
r |
r |
a |
r |
|
a |
|
|
r |
|
r |
No SSD |
a |
a |
a |
a |
a |
a |
installed |
a |
|
|
a |
|
a |
a: Supported, r: Not supported. |
|
|
|
|
|
M2H_32G M.2 connector |
|
|
|
|
|
|
Connector |
SATA3_0 |
SATA3_1 |
SATA3_2 |
SATA3_3 |
SATA3_4 |
SATA3_5 |
Type of SSD |
SATA Express |
SATA Express |
SATA Express |
|||
SATA SSD |
r |
a |
a |
a |
a |
a |
|
a |
|
|
a |
|
a |
PCIe x4 SSD |
a |
a |
a |
a |
a |
r |
|
a |
|
|
a |
|
r |
PCIe x2 SSD |
a |
a |
a |
a |
a |
r |
|
a |
|
|
a |
|
r |
No SSD |
a |
a |
a |
a |
a |
a |
installed |
a |
|
|
a |
|
a |
a: Supported, r: Not supported. |
|
|
|
|
|
(Note) The PCIe x4 SSD runs at x2 speed. |
|
Hardware Installation |
- 30 - |
