Gigabyte GA-X99-UD5 Schematic rev.1.0

5

4

3

2

1

Model Name: GA-X99-UD5 WIFI

SHEET TITLE

01

D D

02

03
04-06
07-08
09-10

11-12
13-14

15-16

C C

17

18

20-21

22

23-24

COVER SHEET
BOM & PCB MODIFY HISTORY
BLOCK DIAGRAM
CPU_LGA2011-DDR
CPU_LGA2011-CTRL_PCIE_DMI
CPU_LGA2011-PWR
DDR III CHANNEL A/B
DDR III CHANNEL C/D
PCH_SATA_GPIO_AUDIO
PCH_DMI_USB_PCIE_PCI
PCH_PWR_GND
PCI EXPRESS X16 SLOT_1/2
PCI EXPRESS X16 Switch
PCI EXPRESS X8 SLOT 1/2

Rev 1.0

SHEET

44
45

46
47-48
49-52

53-55

BUTTON & PROBE
EC HWM ,FAN CTRL
SOUND LEVEL SENSOR
M.2 WIFI & 10Gb SSD
USB3 HUB A/B
ALC1150+NE5532

TITLE

56 USB3_LAN1/2 ,AUDIO JACK

57

58-59

60

61

62

PS2 , WIFI, HS BUTTON
LAN i210& i218
R_USB30
F_USB2 & F_USB3
PCH GPIO LIST

63 Parts Location

25

26-27

28

B B

29
30-31
33-35

36
37-38

39

40

A A

41

42

PCI EXPRESS X1 SLOTs
CPU& PEG CLOCK BUFFER
ITE 8620 SIO
DUAL BIOS
VCORE IR3580
DDR A/B & VPP&DDRVTT IR3570*2
PCH CORE POWER RT8120
DISCRETE POWER
FP ,TPM ,THB
ATX , 80 PORT
I/O HWM ,FAN CTRL
ITE EC 8791
ITE EC 895143

5

4

Title

Size Document Number Rev
Custom

3

2

Date: Sheet of

Gigabyte Technology

Cover Sheet

GA-X99-UD5 WIFI

1

1 64Tuesday, August 26, 2014

1.0

5

4

3

2

1

Model Name: GA-X99-UD5 WIFI

D D

Component value change history

Circuit or PCB layout change

DATE

2014/05/15
Rev 0.1

1. From GA-X99-Gaming G1 Rev 0.1

2. P53-P55 Creative change to ALC1150+NE5532

3. P58, E2201 change to i210

4. Remove P57 USB_DAC Power

Change Item

Reason

5. VRM change to SMD Choke 0.15uH (In & Out)

Date Change Item Reason

2014/05/15
Rev 0.1

1. SATA EXPRESS AC-Couple Cap change to 0 ohm

2. WR57(A_-PROCHOT) P.U. 1K ohm.

3. Audio use MW Cap 33uuF+220uF.

4. SL_MIC2

1.

2014/07/16

2014/07/24

C C

B B

2014/08/01
2014/08/12

󰼷󰼷󰼷󰼷󲒂󲒂󲒂󲒂

2.

󰼷󰼷󰼷󰼷󲒂󲒂󲒂󲒂󲦨󲦨󲦨󲦨󲤔󲤔󲤔󲤔󲓢󲓢󲓢󲓢󰸿󰸿󰸿󰸿

1.

󳑺󳑺󳑺󳑺

2.PCIEX16_1 rename to PCIE_1

3.PCIEX16_2 rename to PCIE_2

4.PCIEX8_1 rename to PCIE_4

5.PCIEX8_2 rename to PCIE_3

6.PCIEX1_1 rename to PCIE_5

7.PCIEX1_2 rename to PCIE_6

8.PCIEX1_3 rename to PCIE_7

9.ECR142,ECR143 change to 0402

10.PE3_LED rename to PE2_LED

11.PE4_LED rename to PE3_LED

12.PE2_LED rename to PE4_LED

13.ITB_PH2

14.DDR4_1_A1 rename to DDR4_1_1A

15.DDR4_2_A2 rename to DDR4_2_2A

16.DDR4_3_B1 rename to DDR4_3_1B

17.DDR4_4_B2 rename to DDR4_4_2B

18.DDR4_5_C1 rename to DDR4_5_1C

19.DDR4_6_C2 rename to DDR4_6_2C

20.DDR4_7_D1 rename to DDR4_7_1D

21.DDR4_8_D2 rename to DDR4_8_2D

1. CBC99 change to 0.01u/6/X7R/50V/K

󲓹󲓹󲓹󲓹󱟧󱟧󱟧󱟧

2.

󳥄󳥄󳥄󳥄󵖭󵖭󵖭󵖭

2014/08/25

2.32.768KHz resitor 1M to 10M

󲒽󲒽󲒽󲒽󳲍󳲍󳲍󳲍󰵖󰵖󰵖󰵖󰵓󰵓󰵓󰵓󰸿󰸿󰸿󰸿

x99 note 152~179

X99-UD5 WIFI Rev 0.1

󲒂󲒂󲒂󲒂󱘧󱘧󱘧󱘧

pin header

WIFI

󱡲󱡲󱡲󱡲󳴣󳴣󳴣󳴣󱙃󱙃󱙃󱙃󱫣󱫣󱫣󱫣󱟓󱟓󱟓󱟓󳆐󳆐󳆐󳆐

ECBR9,ECBR10

󵙄󵙄󵙄󵙄󵖄󵖄󵖄󵖄

󰻏󰻏󰻏󰻏󰼷󰼷󰼷󰼷󲒂󲒂󲒂󲒂

0402 8.2K

9MX99U5WF-00-01

9MX99U5WF-00-10A

2014/07/10

󵙄󵙄󵙄󵙄󵖄󵖄󵖄󵖄

2014/07/21

9MX99U5WF-00-10B

9MX99U5WF-00-10C1.

9MX99U5WF-00-10D1.M.2 N_GPIO73 pull-high resistor remove

6. SATA3_4_5 change to SATA Express

7. DDR12V Output choke change to SMD 0.3uH

8. SL_MIC1 & SL_MIC2

󲒂󲒂󲒂󲒂󲒇󲒇󲒇󲒇󴀕󴀕󴀕󴀕󲛈󲛈󲛈󲛈

9. Audio use MW Cap 33uuF+220uF(8Φ).

10. Add CQ33 & CQ34 for LED_CON1 & LED_CON2

11. N_ME_PWROK

12. UCF1 & UCF2

󲒂󲒂󲒂󲒂󲅙󲅙󲅙󲅙󳑺󳑺󳑺󳑺

󴄼󴄼󴄼󴄼

R_USB30

RT9018 (U8)

󴾗󴾗󴾗󴾗󰻏󰻏󰻏󰻏

󳗍󳗍󳗍󳗍󵇎󵇎󵇎󵇎󳫝󳫝󳫝󳫝󳑺󳑺󳑺󳑺2󱮭󱮭󱮭󱮭󱟧󱟧󱟧󱟧󱇩󱇩󱇩󱇩󳀃󳀃󳀃󳀃4󱮭󱮭󱮭󱮭

13. MH1 change to GND.

14. ANTENNA_HOLD-3 change to -4

15. IC8-ATRC change to IC8-ATRC-1

16. M2_WIFI change to 2 parts, Footprint modify.

17. CEC11 change to 6x5

18. N_ME_PWROK circuit change

1. Modify from X99-UD7 WIFI Rev 0.2 Rev 0.1

2.

󰼷󰼷󰼷󰼷󲒂󲒂󲒂󲒂

x99 note 152~179

󳑺󳑺󳑺󳑺

X99-UD5 WIFI Rev 0.1

2.PCIEX16_1 rename to PCIE_1

3.PCIEX16_2 rename to PCIE_2

4.PCIEX8_1 rename to PCIE_4

5.PCIEX8_2 rename to PCIE_3

6.PCIEX1_1 rename to PCIE_5

7.PCIEX1_2 rename to PCIE_6

8.PCIEX1_3 rename to PCIE_7

9.ECR142,ECR143 change to 0402

10.PE3_LED rename to PE2_LED

11.PE4_LED rename to PE3_LED

12.PE2_LED rename to PE4_LED

13.ITB_PH2

14.DDR4_1_A1 rename to DDR4_1_1A

15.DDR4_2_A2 rename to DDR4_2_2A

16.DDR4_3_B1 rename to DDR4_3_1B

17.DDR4_4_B2 rename to DDR4_4_2B

18.DDR4_5_C1 rename to DDR4_5_1C

19.DDR4_6_C2 rename to DDR4_6_2C

20.DDR4_7_D1 rename to DDR4_7_1D

21.DDR4_8_D2 rename to DDR4_8_2D

󲒂󲒂󲒂󲒂󱘧󱘧󱘧󱘧

pin header

󰻏󰻏󰻏󰻏󰼷󰼷󰼷󰼷󲒂󲒂󲒂󲒂

󵙄󵙄󵙄󵙄󵖄󵖄󵖄󵖄

Rev 1.01.

A A

Title

Size Document Number Rev
Custom

5

4

3

2

Date: Sheet of

Gigabyte Technology

BOM & PCB MODIFY HISTORY

GA-X99-UD5 WIFI

1

2 64Tuesday, August 26, 2014

1.0

5

BLOCK DIAGRAM

4

3

2

1

D D

PCI EXPRESS X16-2

PCI EXPRESS X16-1

SW

GEN3X16

GEN3X16

INTEL LGA2011 R3

HASWELL-E

PCI EXPRESS X8-1

PCI EXPRESS X8-2

C C

3 * PCI PEG X1 SLOT
INTEL i210 LAN

INTEL i218V LAN

FUSB3.0/2.0X2

GEN3X8

DMI 2.0

PCIE-1 gen2 X3

PCIEX1 gen2

PCIEX1 gen2

PCH

USB3.0 x4

VRD12.5

CHANNEL A
DDRIV DIMM X 2

CHANNEL B
DDRIV DIMM X 2

CHANNEL C
DDRIV DIMM X 2

CHANNEL D
DDRIV DIMM X 2

SATA 3.0

SATA3X10

SW

M.2 10Gb (SATA4/5)

SPI BUS

CHANNELA
CHANNELB

CPU

CHANNELD
CHANNELC

DUAL BIOS

USB3.0 Hubx2

B B

RUSB3.0/2.0 X8

X99

LPC BUS

TPM

USB2.0 0~13 usage

USB 2.0

AZALIA BUS

ALC1150

LPC I/O ITE8620

I/O PORTS :

KB/PS2

FRONT PANEL /SMART

AUDIO PORTS :

CLOCK GENERATOR

A A

LIN_ OUT
SURR

LINE_IN

SURR BACK

FRONT AUDIO

MIC

CD_IN

CEN/LFE

CLOCK BUFFER

5

4

3

2

FAN

IT8791 EC

IT8591 EC

Title

Size Document Number Rev
C

Date: Sheet of

Gigabyte Technology

BLOCK DIAGRAM

GA-X99-UD5 WIFI

1

3 64Tuesday, August 26, 2014

1.0

5

M_AAA[0..17](11) M_AAB[0..17](12) M_AAD[0..17](14)M_AAC[0..17](13)

M_AAA0 M_AAB0
M_AAA1
M_AAA2
M_AAA3 M_AAB3
M_AAA4
M_AAA5
M_AAA6
M_AAA7

D D

M_AAA8
M_AAA9
M_AAA10
M_AAA11
M_AAA12
M_AAA13
M_AAA14
M_AAA15
M_AAA16
M_AAA17

M_DDR_PARA(11) M_DDR_PARB (12) M_DDR_PARC(13) M_DDR_PARD (14)

M_SBAA0(11)
M_SBAA1(11)

M_-CSA0(11)
M_-CSA1(11)
M_-CSA2(11)
M_-CSA3(11) M_-CSB3 (12)
M_-CSA4(11)
M_-CSA5(11)
M_-CSA6(11)
M_-CSA7(11)

M_DCLKA0(11)

C C

B B

M_-DCLKA0(11)

M_DCLKA1(11)

M_-DCLKA1(11)

M_DCLKA2(11)

M_-DCLKA2(11)

M_DCLKA3(11)

M_-DCLKA3(11)

M_CKEA0(11)
M_CKEA1(11)
M_CKEA2(11)
M_CKEA3(11)

M_ODT_A0(11)
M_ODT_A1(11)
M_ODT_A2(11)
M_ODT_A3(11)

M_-ACT_A(11)

M_-ALERT_A(11)

M_BG_A0(11)
M_BG_A1(11)

M_C2_A(11)

CP22

DDR0_MA_0

CR21

DDR0_MA_1

CT22

DDR0_MA_2

CN21

DDR0_MA_3

CP20

DDR0_MA_4

CL19

DDR0_MA_5

CN19

DDR0_MA_6

CH18

DDR0_MA_7

CJ19

DDR0_MA_8

CK18

DDR0_MA_9

CP24

DDR0_MA_10

CP18

DDR0_MA_11

CR17

DDR0_MA_12

CE23

DDR0_MA_13

CJ21

DDR0_MA_14

CL25

DDR0_MA_15

CL23

DDR0_MA_16

CD24

DDR0_MA_17

CK20

DDR0_PAR

CL21

DDR0_BA_0

CH20

DDR0_BA_1

CD22

DDR0_CS_N_0

CH22

DDR0_CS_N_1

CF26

DDR0_CS_N_2/CID_0

CC25

DDR0_CS_N_3/CID_1

CK22

DDR0_CS_N_4

CH24

DDR0_CS_N_5

CH26

DDR0_CS_N_6/CID_3

CD26

DDR0_CS_N_7/CID_4

CK24

DDR0_CS_N_8

CK26

DDR0_CS_N_9

CC21

DDR0_CLK_DP_0

CE21

DDR0_CLK_DN_0

CD18

DDR0_CLK_DP_1

CF18

DDR0_CLK_DN_1

CD20

DDR0_CLK_DP_2

CF20

DDR0_CLK_DN_2

CC19

DDR0_CLK_DP_3

CE19

DDR0_CLK_DN_3

CJ17

DDR0_CKE_0

CE17

DDR0_CKE_1

CF16

DDR0_CKE_2

CC17

DDR0_CKE_3

CN15

DDR0_CKE_4

CC15

DDR0_CKE_5

CF22

DDR0_ODT_0

CN25

DDR0_ODT_1

CJ23

DDR0_ODT_2

CC23

DDR0_ODT_3

CF24

DDR0_ODT_4

CE25

DDR0_ODT_5

CK16

DDR0_ACT

CL17

DDR0_BG_0

CN17

DDR0_BG_1

CJ25

DDR0_CID_2

M_AAA[0..17] M_AAB[0..17] M_AAC[0..17] M_AAD[0..17]

LGA2011-3J

HASWELL_E_EDS

10 OF 19

4

DDR1_MA_0
DDR1_MA_1
DDR1_MA_2
DDR1_MA_3
DDR1_MA_4
DDR1_MA_5
DDR1_MA_6
DDR1_MA_7
DDR1_MA_8

DDR1_MA_9
DDR1_MA_10
DDR1_MA_11
DDR1_MA_12
DDR1_MA_13
DDR1_MA_14
DDR1_MA_15
DDR1_MA_16
DDR1_MA_17

DDR1_PAR

DDR1_BA_0
DDR1_BA_1

DDR1_CS_N_0

DDR1_CS_N_1
DDR1_CS_N_2/CID_0
DDR1_CS_N_3/CID_1

DDR1_CS_N_4

DDR1_CS_N_5
DDR1_CS_N_6/CID_3
DDR1_CS_N_7/CID_4

DDR1_CS_N_8

DDR1_CS_N_9

DDR1_CLK_DP_0
DDR1_CLK_DN_0
DDR1_CLK_DP_1
DDR1_CLK_DN_1
DDR1_CLK_DP_2
DDR1_CLK_DN_2
DDR1_CLK_DP_3
DDR1_CLK_DN_3

DDR1_CKE_0
DDR1_CKE_1
DDR1_CKE_2
DDR1_CKE_3
DDR1_CKE_4
DDR1_CKE_5

DDR1_ODT_0
DDR1_ODT_1
DDR1_ODT_2
DDR1_ODT_3
DDR1_ODT_4
DDR1_ODT_5

DDR1_ACT

DDR1_ALERTDDR0_ALERT

DDR1_BG_0
DDR1_BG_1

DDR1_CID_2

TEST_0
TEST_1

DDR01_VREF

RSVD
RSVD

CY22
DA21
CV20
CW21
CR19
CY20
CW19
CT18
DA19
CY18
CR23
CV18
CW17
CW25
CN23
CV24
CY24
CT24

CT20
CW23

CV22
DF22

DE23
CT26
CP26
DA23
DD24
CY26
CV26
DF24
DF26

DE21
DC21
DF18
DD18
DF20
DD20
DE19
DC19

DA17
DC17
DD16
DF16
CY16
DA15

DD22
DE25
DC23
DC25
DA25
DD26

CT16
CR15CD16
CV16
CP16
CR25

DB2
DB4
BY16
CF40
CP40

M_AAB1
M_AAB2

M_AAB4
M_AAB5
M_AAB6
M_AAB7
M_AAB8
M_AAB9
M_AAB10
M_AAB11
M_AAB12
M_AAB13
M_AAB14
M_AAB15
M_AAB16
M_AAB17

M_SBAB0 (12)
M_SBAB1 (12)

M_-CSB0 (12)
M_-CSB1 (12)
M_-CSB2 (12)

M_-CSB4 (12)
M_-CSB5 (12)
M_-CSB6 (12)
M_-CSB7 (12)

M_DCLKB0 (12)
M_-DCLKB0 (12)
M_DCLKB1 (12)
M_-DCLKB1 (12)
M_DCLKB2 (12)
M_-DCLKB2 (12)
M_DCLKB3 (12)
M_-DCLKB3 (12)

M_CKEB0 (12)
M_CKEB1 (12)
M_CKEB2 (12)
M_CKEB3 (12)

M_ODT_B0 (12)
M_ODT_B1 (12)
M_ODT_B2 (12)
M_ODT_B3 (12)

M_-ACT_B (12)
M_-ALERT_B (12)
M_BG_B0 (12)
M_BG_B1 (12)
M_C2_B (12)

A_VREFDQ_C01

WR5 49.9/4/1
WR9 49.9/4/1

A_VREFDQ_C01 (11)

3

LGA2011-3K

M_AAC0
M_AAC1
M
M_AAC3
M_AAC4
M_AAC5
M_AAC6
M_AAC7
M_AAC8
M_AAC9
M_AAC10
M_AAC11
M_AAC12
M_AAC13
M_AAC14
M_AAC15
M_AAC16
M_AAC17

M_SBAC0(13)
M_SBAC1(13)

M_-CSC0(13) M_-CSD0 (14)
M_-CSC1(13)
M_-CSC2(13)
M_-CSC3(13)
M_-CSC4(13)
M_-CSC5(13)
M_-CSC6(13)
M_-CSC7(13)

M_DCLKC0(13)

M_-DCLKC0(13)

M_DCLKC1(13)

M_-DCLKC1(13)

M_DCLKC2(13)

M_-DCLKC2(13)

M_DCLKC3(13)

M_-DCLKC3(13)

M_CKEC0(13)
M_CKEC1(13)
M_CKEC2(13)
M_CKEC3(13)

M_ODT_C0(13)
M_ODT_C1(13)
M_ODT_C2(13)
M_ODT_C3(13)

M_-ACT_C(13)

M_BG_C0(13)
M_BG_C1(13)

M_C2_C(13)

_AAC2

L15

DDR2_MA_0

M16

DDR2_MA_1

T18

DDR2_MA_2

L17

DDR2_MA_3

R19

DDR2_MA_4

P18

DDR2_MA_5

M18

DDR2_MA_6

U19

DDR2_MA_7

L19

DDR2_MA_8

P20

DDR2_MA_9

AA15

DDR2_MA_10

T20

DDR2_MA_11

W21

DDR2_MA_12

P12

DDR2_MA_13

Y14

DDR2_MA_14

P14

DDR2_MA_16

T14

DDR2_MA_17

R17

DDR2_PAR

M14

DDR2_BA_0

U17

DDR2_BA_1

AB16

DDR2_CS_N_0

T16

DDR2_CS_N_1

W13

DDR2_CS_N_2/CID_0

AA13

DDR2_CS_N_3/CID_1

P16

DDR2_CS_N_4

U15

DDR2_CS_N_5

AC13

DDR2_CS_N_6/CID_3

AD16

DDR2_CS_N_7/CID_4

AD18

DDR2_CS_N_8

T12

DDR2_CS_N_9

AA17

DDR2_CLK_DP_0

W17

DDR2_CLK_DN_0

AB20

DDR2_CLK_DP_1

Y20

DDR2_CLK_DN_1

AB18

DDR2_CLK_DP_2

Y18

DDR2_CLK_DN_2

AA19

DDR2_CLK_DP_3

W19

DDR2_CLK_DN_3

R21

DDR2_CKE_0

U21

DDR2_CKE_1

T22

DDR2_CKE_2

Y22

DDR2_CKE_3

AB22

DDR2_CKE_4

AD22

DDR2_CKE_5

Y16

DDR2_ODT_0

W15

DDR2_ODT_1

R15

DDR2_ODT_2

AB14

DDR2_ODT_3

AE17

DDR2_ODT_4

AD14

DDR2_ODT_5

AE21

DDR2_ACT

P22

DDR2_ALERT

AA21

DDR2_BG_0

AD20

DDR2_BG_1

U13

DDR2_CID_2

2

HASWELL_E_EDS

11 OF 19

DDR3_MA_0
DDR3_MA_1
DDR3_MA_2
DDR3_MA_3
DDR3_MA_4
DDR3_MA_5
DDR3_MA_6
DDR3_MA_7
DDR3_MA_8

DDR3_MA_9
DDR3_MA_10
DDR3_MA_11
DDR3_MA_12
DDR3_MA_13
DDR3_MA_14
DDR3_MA_15DDR2_MA_15
DDR3_MA_16
DDR3_MA_17

DDR3_PAR

DDR3_BA_0
DDR3_BA_1

DDR3_CS_N_0

DDR3_CS_N_1
DDR3_CS_N_2/CID_0
DDR3_CS_N_3/CID_1

DDR3_CS_N_4

DDR3_CS_N_5
DDR3_CS_N_6/CID_3
DDR3_CS_N_7/CID_4

DDR3_CS_N_8

DDR3_CS_N_9

DDR3_CLK_DP_0
DDR3_CLK_DN_0
DDR3_CLK_DP_1
DDR3_CLK_DN_1
DDR3_CLK_DP_2
DDR3_CLK_DN_2
DDR3_CLK_DP_3
DDR3_CLK_DN_3

DDR3_CKE_0
DDR3_CKE_1
DDR3_CKE_2
DDR3_CKE_3
DDR3_CKE_4
DDR3_CKE_5

DDR3_ODT_0
DDR3_ODT_1
DDR3_ODT_2
DDR3_ODT_3
DDR3_ODT_4
DDR3_ODT_5

DDR3_ACT

DDR3_ALERT

DDR3_BG_0
DDR3_BG_1

DDR3_CID_2

TEST_2
TEST_3
TEST_4

DDR23_VREF

RSVD
RSVD

G15
K16
F16
G17
J17
K18
F18
J19
G19
F20
L13
K20
M20
M12
K12
F12R13
J13
L11

J15
G13

K14
B16

C15
F10
H10
A15
F14
G11
A11
B14
B12

A17
C17
B20
D20
B18
D18
A19
C19

F22
E21
A21
D22
B22
K22

D16
A13
D14
D12
E13
E11

L21
M22
J21
G21
J11
D2
C3
BA55

A_VREFDQ_C23

T40
R41
M40

M_AAD0
M_AAD1
M_AAD2
M_AAD3
M_AAD4
M_AAD5
M_AAD6
M_AAD7
M_AAD8
M_AAD9
M_AAD10
M_AAD11
M_AAD12
M_AAD13
M_AAD14
M_AAD15
M_AAD16
M_AAD17

M_SBAD0 (14)
M_SBAD1 (14)

M_-CSD1 (14)
M_-CSD2 (14)
M_-CSD3 (14)
M_-CSD4 (14)
M_-CSD5 (14)
M_-CSD6 (14)
M_-CSD7 (14)

M_DCLKD0 (14)
M_-DCLKD0 (14)
M_DCLKD1 (14)
M_-DCLKD1 (14)
M_DCLKD2 (14)
M_-DCLKD2 (14)
M_DCLKD3 (14)
M_-DCLKD3 (14)

M_CKED0 (14)
M_CKED1 (14)
M_CKED2 (14)
M_CKED3 (14)

M_ODT_D0 (14)
M_ODT_D1 (14)
M_ODT_D2 (14)
M_ODT_D3 (14)

M_-ACT_D (14)
M_-ALERT_D (14)M_-ALERT_C(13)
M_BG_D0 (14)
M_BG_D1 (14)
M_C2_D (14)

WR10 49.9/4/1
WR11 49.9/4/1

A_VREFDQ_C23 (13)

1

HASWELL_E_EDS/LGA/[10SC1-J02011-41R]

ILM_BP/2011/CSP[12KRC-0F2011-61R]

A A

LGA2011-3

COUPON1

COUPON2 COUPON/X

COUPON2

COUPON4 COUPON/X

COUPON3

COUPON1 COUPON/X

COUPON4

COUPON3 COUPON/X

21

A_VREFDQ_C23

WBC1

1u/4/X5R/6.3V/K

21

21

21

A_VREFDQ_C01

WBC53

1u/4/X5R/6.3V/K

5

4

3

2

Title

Size Document Number Rev

Custom

Date: Sheet of

Gigabyte Technology

CPU LGA2011-A

GA-X99-UD5 WIFI

4 64Tuesday, August 26, 2014

1

1.0

5

4

3

2

1

CHANNEL BCHANNEL A

HASWELL_E_EDS

6 OF 19

DDR0_DQS_DP_0
DDR0_DQS_DN_0

DDR0_DQS_DP_1
DDR0_DQS_DN_1

DDR0_DQS_DP_2
DDR0_DQS_DN_2

DDR0_DQS_DP_3
DDR0_DQS_DN_3

DDR0_DQS_DP_4
DDR0_DQS_DN_4

DDR0_DQS_DP_5
DDR0_DQS_DN_5

DDR0_DQS_DP_6
DDR0_DQS_DN_6

DDR0_DQS_DP_7
DDR0_DQS_DN_7

DDR0_DQS_DP_8
DDR0_DQS_DN_8

DDR0_DQS_DP_9
DDR0_DQS_DN_9

DDR0_DQS_DP_10
DDR0_DQS_DN_10

DDR0_DQS_DP_11
DDR0_DQS_DN_11

DDR0_DQS_DP_12
DDR0_DQS_DN_12

DDR0_DQS_DP_13
DDR0_DQS_DN_13

DDR0_DQS_DP_14
DDR0_DQS_DN_14

DDR0_DQS_DP_15
DDR0_DQS_DN_15

DDR0_DQS_DP_16
DDR0_DQS_DN_16

DDR0_DQS_DP_17
DDR0_DQS_DN_17

BY6
BV6

BV12
BW11

CH10
CG11

CK14
CJ13

CK30
CM30

CD30
CF30

CC37
CE37

CJ37
CL37

CV10
CT10

BV8
BW9

BU13
BV14

CG9
CH8

CG13
CF14

CL29
CJ29

CE29
CC29

CF36
CD36

CM36
CK36

CU9
CW9

M_DQSA0

M_-DQSA0

M

_DQSA1

M_-DQSA1

M_DQSA2

M_-DQSA2

M_DQSA3

M_-DQSA3

M_DQSA4

M_-DQSA4

M_DQSA5

M_-DQSA5

M_DQSA6

M_-DQSA6

M_DQSA7

M_-DQSA7

M_DB0
M_DB1
M_DB2
M_DB3
M_DB4
M_DB5
M_DB6
M_DB7
M_DB8

M_DB9
M_DB10
M_DB11
M_DB12
M_DB13
M_DB14
M_DB15
M_DB16
M_DB17
M_DB18
M_DB19
M_DB20
M_DB21
M_DB22
M_DB23
M_DB24
M_DB25
M_DB26
M_DB27
M_DB28
M_DB29
M_DB30
M_DB31
M_DB32
M_DB33
M_DB34
M_DB35
M_DB36
M_DB37
M_DB38
M_DB39
M_DB40
M_DB41
M_DB42
M_DB43
M_DB44
M_DB45
M_DB46
M_DB47
M_DB48
M_DB49
M_DB50
M_DB51
M_DB52
M_DB53
M_DB54
M_DB55
M_DB56
M_DB57
M_DB58
M_DB59
M_DB60
M_DB61
M_DB62
M_DB63

BV4

BU1
CA3
CB4
BT4
BT2
CA1
BY2
CE3

CF4

CL5
CM4
CE5
CF6
CK6

CL3
CR3
CV2
CT6
CP6
CR1
CP2
CU5
CR5

DA7

DB8

DE11
DC11

DA5

CY6

DE9

DF10
CT28
CP28
CT32
CP32
CU27
CR27
CU31
CR31
DA29
DB30
DC33
DF34
DB28
CY28
DA33
DE33
CU35
CR35
CU39
CR39
CV34
CT34
CV38
CT38
DC37
DF36
DC39
DA39
DC35
DB36
DF38
DE39

CU13
CV14
DD14
DF14
CR13
CT14
DC13
DE13

LGA2011-3G

DDR1_DQ_0
DDR1_DQ_1
DDR1_DQ_2
D

DR1_DQ_3
DDR1_DQ_4
DDR1_DQ_5
DDR1_DQ_6
DDR1_DQ_7
DDR1_DQ_8
DDR1_DQ_9
DDR1_DQ_10
DDR1_DQ_11
DDR1_DQ_12
DDR1_DQ_13
DDR1_DQ_14
DDR1_DQ_15
DDR1_DQ_16
DDR1_DQ_17
DDR1_DQ_18
DDR1_DQ_19
DDR1_DQ_20
DDR1_DQ_21
DDR1_DQ_22
DDR1_DQ_23
DDR1_DQ_24
DDR1_DQ_25
DDR1_DQ_26
DDR1_DQ_27
DDR1_DQ_28
DDR1_DQ_29
DDR1_DQ_30
DDR1_DQ_31
DDR1_DQ_32
DDR1_DQ_33
DDR1_DQ_34
DDR1_DQ_35
DDR1_DQ_36
DDR1_DQ_37
DDR1_DQ_38
DDR1_DQ_39
DDR1_DQ_40
DDR1_DQ_41
DDR1_DQ_42
DDR1_DQ_43
DDR1_DQ_44
DDR1_DQ_45
DDR1_DQ_46
DDR1_DQ_47
DDR1_DQ_48
DDR1_DQ_49
DDR1_DQ_50
DDR1_DQ_51
DDR1_DQ_52
DDR1_DQ_53
DDR1_DQ_54
DDR1_DQ_55
DDR1_DQ_56
DDR1_DQ_57
DDR1_DQ_58
DDR1_DQ_59
DDR1_DQ_60
DDR1_DQ_61
DDR1_DQ_62
DDR1_DQ_63

DDR1_ECC_0
DDR1_ECC_1
DDR1_ECC_2
DDR1_ECC_3
DDR1_ECC_4
DDR1_ECC_5
DDR1_ECC_6
DDR1_ECC_7

D D

C C

B B

M_DA0
M_DA1
M_DA2
M_DA3
M_DA4
M_DA5
M_DA6
M_DA7
M_DA8
M_DA9
M_DA10
M_DA11
M_DA12
M_DA13
M_DA14
M_DA15
M_DA16
M_DA17
M_DA18
M_DA19
M_DA20
M_DA21
M_DA22
M_DA23
M_DA24
M_DA25
M_DA26
M_DA27
M_DA28
M_DA29
M_DA30
M_DA31
M_DA32
M_DA33
M_DA34
M_DA35
M_DA36
M_DA37
M_DA38
M_DA39
M_DA40
M_DA41
M_DA42
M_DA43
M_DA44
M_DA45
M_DA46
M_DA47
M_DA48
M_DA49
M_DA50
M_DA51
M_DA52
M_DA53
M_DA54
M_DA55
M_DA56
M_DA57
M_DA58
M_DA59
M_DA60
M_DA61
M_DA62
M_DA63

BU7
BT6
CA9
CB8
BT8
BU9
CA7
CB6

BT12

BU11

BW13

BY14

BT14
BU15
CA11
BY12

CE9
CF8

CK10

CJ11
CD10
CE11

CK8
CJ9

CE13

CG15
CM14

CH14
CC13
CD14

CM12

CL13
CK28
CH28
CK32
CH32
CL27

CJ27
CL31

CJ31
CD28
CB28
CD32
CB32
CE27
CC27
CE31
CC31
CE35
CC35
CE39
CC39
CF34
CD34
CF38
CD38
CL35

CJ35
CL39

CJ39

CM34

CK34

CM38

CK38

CT8
CV8

CW11

CU11

CP8

CN9
CP10
CR11

LGA2011-3F

DDR0_DQ_0
DDR0_DQ_1
DDR0_DQ_2
DDR0_DQ_3
DDR0_DQ_4
DDR0_DQ_5
DDR0_DQ_6
DDR0_DQ_7
DDR0_DQ_8
DDR0_DQ_9
DDR0_DQ_10
DDR0_DQ_11
DDR0_DQ_12
DDR0_DQ_13
DDR0_DQ_14
DDR0_DQ_15
DDR0_DQ_16
DDR0_DQ_17
DDR0_DQ_18
DDR0_DQ_19
DDR0_DQ_20
DDR0_DQ_21
DDR0_DQ_22
DDR0_DQ_23
DDR0_DQ_24
DDR0_DQ_25
DDR0_DQ_26
DDR0_DQ_27
DDR0_DQ_28
DDR0_DQ_29
DDR0_DQ_30
DDR0_DQ_31
DDR0_DQ_32
DDR0_DQ_33
DDR0_DQ_34
DDR0_DQ_35
DDR0_DQ_36
DDR0_DQ_37
DDR0_DQ_38
DDR0_DQ_39
DDR0_DQ_40
DDR0_DQ_41
DDR0_DQ_42
DDR0_DQ_43
DDR0_DQ_44
DDR0_DQ_45
DDR0_DQ_46
DDR0_DQ_47
DDR0_DQ_48
DDR0_DQ_49
DDR0_DQ_50
DDR0_DQ_51
DDR0_DQ_52
DDR0_DQ_53
DDR0_DQ_54
DDR0_DQ_55
DDR0_DQ_56
DDR0_DQ_57
DDR0_DQ_58
DDR0_DQ_59
DDR0_DQ_60
DDR0_DQ_61
DDR0_DQ_62
DDR0_DQ_63

DDR0_ECC_0
DDR0_ECC_1
DDR0_ECC_2
DDR0_ECC_3
DDR0_ECC_4
DDR0_ECC_5
DDR0_ECC_6
DDR0_ECC_7

HASWELL_E_EDS

7 OF 19

DDR1_DQS_DP_0
DDR1_DQS_DN_0

DDR1_DQS_DP_1
DDR1_DQS_DN_1

DDR1_DQS_DP_2
DDR1_DQS_DN_2

DDR1_DQS_DP_3
DDR1_DQS_DN_3

DDR1_DQS_DP_4
DDR1_DQS_DN_4

DDR1_DQS_DP_5
DDR1_DQS_DN_5

DDR1_DQS_DP_6
DDR1_DQS_DN_6

DDR1_DQS_DP_7
DDR1_DQS_DN_7

DDR1_DQS_DP_8
DDR1_DQS_DN_8

DDR1_DQS_DP_9
DDR1_DQS_DN_9

DDR1_DQS_DP_10
DDR1_DQS_DN_10

DDR1_DQS_DP_11
DDR1_DQS_DN_11

DDR1_DQS_DP_12
DDR1_DQS_DN_12

DDR1_DQS_DP_13
DDR1_DQS_DN_13

DDR1_DQS_DP_14
DDR1_DQS_DN_14

DDR1_DQS_DP_15
DDR1_DQS_DN_15

DDR1_DQS_DP_16
DDR1_DQS_DN_16

DDR1_DQS_DP_17
DDR1_DQS_DN_17

BY4
BW3

CJ5
CH6

CT4
CV4

DB10
DC9

CT30
CV30

DD32
DB32

CR37
CU37

DB38
DA37

DB14
DA13

BV2
BW1

CH4
CG3

CW3
CU3

DC7
DD8

CU29
CR29

DA31
CY32

CV36
CT36

DD36
DE37

CW13
CY14

M_DQSB0
M_-DQSB0

M_DQSB1
M_-DQSB1

M_DQSB2
M_-DQSB2

M_DQSB3
M_-DQSB3

M_DQSB4
M_-DQSB4

M_DQSB5
M_-DQSB5

M_DQSB6
M_-DQSB6

M_DQSB7
M_-DQSB7

M_DA[0..63](11)

A A

5

M_DQSA[0..7](11)
M_-DQSA[0..7](11)

M_DQSA[0..7] M_DQSB[0..7]
M_-DQSA[0..7] M_-DQSB[0..7]

4

M_DB[0..63](12)

M_DQSB[0..7](12)

M_-DQSB[0..7](12)

3

M_DB[0..63]M_DA[0..63]

Title

Size Document Number Rev

Custom

2

Date: Sheet of

Gigabyte Technology

CPU LGA2011-A

GA-X99-UD5 WIFI

5 64Tuesday, August 26, 2014

1

1.0

5

4

3

2

1

CHANNEL C CHANNEL D

HASWELL_E_EDS

8 OF 19

DDR2_DQS_DP_0
DDR2_DQS_DN_0

DDR2_DQS_DP_1
DDR2_DQS_DN_1

DDR2_DQS_DP_2
DDR2_DQS_DN_2

DDR2_DQS_DP_3
DDR2_DQS_DN_3

DDR2_DQS_DP_4
DDR2_DQS_DN_4

DDR2_DQS_DP_5
DDR2_DQS_DN_5

DDR2_DQS_DP_6
DDR2_DQS_DN_6

DDR2_DQS_DP_7
DDR2_DQS_DN_7

DDR2_DQS_DP_8
DDR2_DQS_DN_8

DDR2_DQS_DP_9
DDR2_DQS_DN_9

DDR2_DQS_DP_10
DDR2_DQS_DN_10

DDR2_DQS_DP_11
DDR2_DQS_DN_11

DDR2_DQS_DP_12
DDR2_DQS_DN_12

DDR2_DQS_DP_13
DDR2_DQS_DN_13

DDR2_DQS_DP_14
DDR2_DQS_DN_14

DDR2_DQS_DP_15
DDR2_DQS_DN_15

DDR2_DQS_DP_16
DDR2_DQS_DN_16

DDR2_DQS_DP_17
DDR2_DQS_DN_17

V38
W37

U31
V32

AB32
AD32

U25
W25

N7
P8

AB10
Y10

AH12
AJ13

AJ7
AH8

AC25
AE25

AB38
AC37

T34
R33

AC33
AA33

V26
T26

M8
L7

V8
W9

AH16
AJ15

AH10
AJ9

AD26
AB26

M_DQSC0

M_-DQSC0

M_DQSC1

M_-DQSC1

M_DQSC2

M_-DQSC2

M_DQSC3

M_-DQSC3

M_DQSC4

M_-DQSC4

M_DQSC5

M_-DQSC5

M_DQSC6

M_-DQSC6

M_DQSC7

M_-DQSC7

M_DD0
M_DD1
M_DD2
M_DD3
M_DD4
M_DD5
M_DD6
M_DD7
M_DD8
M_DD9
M_DD10
M_DD11
M_DD12
M_DD13
M_DD14
M_DD15 M_DQSD5
M_DD16
M_DD17
M_DD18
M_DD19
M_DD20
M_DD21
M_DD22
M_DD23
M_DD24
M_DD25
M_DD26
M_DD27
M_DD28
M_DD29
M_DD30
M_DD31
M_DD32
M_DD33
M_DD34
M_DD35
M_DD36
M_DD37
M_DD38
M_DD39
M_DD40
M_DD41
M_DD42
M_DD43
M_DD44
M_DD45
M_DD46
M_DD47
M_DD48
M_DD49
M_DD50
M_DD51
M_DD52
M_DD53
M_DD54
M_DD55
M_DD56
M_DD57
M_DD58
M_DD59
M_DD60
M_DD61
M_DD62
M_DD63

D38

M38
C39

G37

G31

D32

M34
M30

N31

G29
C25

AG3
AG1

AG5

AC3

B38
L37

K38
A35
B34

E31
F34
E35

E33
K34

K30

L35
L31

F28
E27
F24
E23

E29
B24

AL3
AL5

AE3
AJ3
AL1

AC5
AE5

AB6
L27
L23
K28

M28
M24
K24

J39

J35

K4
H4

J1
L1
P4
N3
K2
R3
E9
F8
E5
F6
C9
A9
D6
G7

V4

W3

U5
V6

J27
J23

M_DC0
M_DC1

D D

C C

B B

M_DC2
M_DC3
M_DC4
M_DC5
M_DC6
M_DC7
M_DC8
M_DC9
M_DC10
M_DC11
M_DC12
M_DC13
M_DC14
M_DC15
M_DC16
M_DC17
M_DC18
M_DC19
M_DC20
M_DC21
M_DC22
M_DC23
M_DC24
M_DC25
M_DC26
M_DC27
M_DC28
M_DC29
M_DC30
M_DC31
M_DC32
M_DC33
M_DC34
M_DC35
M_DC36
M_DC37
M_DC38
M_DC39
M_DC40
M_DC41
M_DC42
M_DC43
M_DC44
M_DC45
M_DC46
M_DC47
M_DC48
M_DC49
M_DC50
M_DC51
M_DC52
M_DC53
M_DC54
M_DC55
M_DC56
M_DC57
M_DC58
M_DC59
M_DC60
M_DC61
M_DC62
M_DC63

AD38
AA37

R37

Y38
AE37
AC39

T38

U37

V34

U33

V30

T30

U35
R35

T32

W31
AD34
AB34
AD30
AB30
AC35
AA35
AE31
AC31

U27
R27
U23
R23

V28
T28
V24
T24

W11
AA11

AB8

T10
U11
AA9

AE11
AF12
AK12
AL13
AG15
AF14
AK14
AL15

AG9
AG7

AK10

AL9
AE7
AE9
AK8

AL7

AC27
AA27
AC23
AA23
AD28
AB28
AD24
AB24

N9
K8
R7
P6
J9
L9
K6

M6

U9

Y8

LGA2011-3H

DDR2_DQ_0
DDR2_DQ_1
DDR2_DQ_2
DDR2_DQ_3
DDR2_DQ_4
DDR2_DQ_5
DDR2_DQ_6
DDR2_DQ_7
DDR2_DQ_8
DDR2_DQ_9
DDR2_DQ_10
DDR2_DQ_11
DDR2_DQ_12
DDR2_DQ_13
DDR2_DQ_14
DDR2_DQ_15
DDR2_DQ_16
DDR2_DQ_17
DDR2_DQ_18
DDR2_DQ_19
DDR2_DQ_20
DDR2_DQ_21
DDR2_DQ_22
DDR2_DQ_23
DDR2_DQ_24
DDR2_DQ_25
DDR2_DQ_26
DDR2_DQ_27
DDR2_DQ_28
DDR2_DQ_29
DDR2_DQ_30
DDR2_DQ_31
DDR2_DQ_32
DDR2_DQ_33
DDR2_DQ_34
DDR2_DQ_35
DDR2_DQ_36
DDR2_DQ_37
DDR2_DQ_38
DDR2_DQ_39
DDR2_DQ_40
DDR2_DQ_41
DDR2_DQ_42
DDR2_DQ_43
DDR2_DQ_44
DDR2_DQ_45
DDR2_DQ_46
DDR2_DQ_47
DDR2_DQ_48
DDR2_DQ_49
DDR2_DQ_50
DDR2_DQ_51
DDR2_DQ_52
DDR2_DQ_53
DDR2_DQ_54
DDR2_DQ_55
DDR2_DQ_56
DDR2_DQ_57
DDR2_DQ_58
DDR2_DQ_59
DDR2_DQ_60
DDR2_DQ_61
DDR2_DQ_62
DDR2_DQ_63

DDR2_ECC_0
DDR2_ECC_1
DDR2_ECC_2
DDR2_ECC_3
DDR2_ECC_4
DDR2_ECC_5
DDR2_ECC_6
DDR2_ECC_7

LGA2011-3I

DDR3_DQ_0
DDR3_DQ_1
DDR3_DQ_2
DDR3_DQ_3
DDR3_DQ_4
DDR3_DQ_5
DDR3_DQ_6
DDR3_DQ_7
DDR3_DQ_8
DDR3_DQ_9
DDR3_DQ_10
DDR3_DQ_11
DDR3_DQ_12
DDR3_DQ_13
DDR3_DQ_14
DDR3_DQ_15
DDR3_DQ_16
DDR3_DQ_17
DDR3_DQ_18
DDR3_DQ_19
DDR3_DQ_20
DDR3_DQ_21
DDR3_DQ_22
DDR3_DQ_23
DDR3_DQ_24
DDR3_DQ_25
DDR3_DQ_26
DDR3_DQ_27
DDR3_DQ_28
DDR3_DQ_29
DDR3_DQ_30
DDR3_DQ_31
DDR3_DQ_32
DDR3_DQ_33
DDR3_DQ_34
DDR3_DQ_35
DDR3_DQ_36
DDR3_DQ_37
DDR3_DQ_38
DDR3_DQ_39
DDR3_DQ_40
DDR3_DQ_41
DDR3_DQ_42
DDR3_DQ_43
DDR3_DQ_44
DDR3_DQ_45
DDR3_DQ_46
DDR3_DQ_47
DDR3_DQ_48
DDR3_DQ_49
DDR3_DQ_50
DDR3_DQ_51
DDR3_DQ_52
DDR3_DQ_53
DDR3_DQ_54
DDR3_DQ_55
DDR3_DQ_56
DDR3_DQ_57
DDR3_DQ_58
DDR3_DQ_59
DDR3_DQ_60
DDR3_DQ_61
DDR3_DQ_62
DDR3_DQ_63

DDR3_ECC_0
DDR3_ECC_1
DDR3_ECC_2
DDR3_ECC_3
DDR3_ECC_4
DDR3_ECC_5
DDR3_ECC_6
DDR3_ECC_7

HASWELL_E_EDS

9 OF 19

DDR3_DQS_DP_0

DDR3_DQS_DN_0
DDR3_DQS_DP_1

DDR3_DQS_DN_1
DDR3_DQS_DP_2

DDR3_DQS_DN_2
DDR3_DQS_DP_3

DDR3_DQS_DN_3
DDR3_DQS_DP_4

DDR3_DQS_DN_4
DDR3_DQS_DP_5

DDR3_DQS_DN_5
DDR3_DQS_DP_6

DDR3_DQS_DN_6
DDR3_DQS_DP_7

DDR3_DQS_DN_7
DDR3_DQS_DP_8

DDR3_DQS_DN_8
DDR3_DQS_DP_9

DDR3_DQS_DN_9

DDR3_DQS_DP_10
DDR3_DQS_DN_10

DDR3_DQS_DP_11
DDR3_DQS_DN_11

DDR3_DQS_DP_12
DDR3_DQS_DN_12

DDR3_DQS_DP_13
DDR3_DQS_DN_13

DDR3_DQS_DP_14
DDR3_DQS_DN_14

DDR3_DQS_DP_15
DDR3_DQS_DN_15

DDR3_DQS_DP_16
DDR3_DQS_DN_16

DDR3_DQS_DP_17
DDR3_DQS_DN_17

E37
C37

B32
A33

M32
K32

E25
G25

H2
G3

E7
C7

AK2
AJ1

AB4
AA5

L25
N25

F38
H38

C35
D34

J33
L33

F26
D26

M4
L3

B8
D8

AH4
AJ5

Y6
W5

M26
K26

M_DQSD0

M_-DQSD0

M_DQSD1

M_-DQSD1

M_DQSD2

M_-DQSD2

M_DQSD3

M_-DQSD3

M_DQSD4

M_-DQSD4

M_-DQSD5

M_DQSD6

M_-DQSD6

M_DQSD7

M_-DQSD7

M_DC[0..63](13)

A A

5

M_DQSC[0..7](13)

M_-DQSC[0..7](13)

M_DC[0..63]

M_DQSC[0..7]
M_-DQSC[0..7]

4

3

M_DD[0..63](14)

M_DQSD[0..7](14)
M_-DQSD[0..7](14)

M_DD[0..63]

M_DQSD[0..7]
M_-DQSD[0..7]

Title

Size Document Number Rev

Custom

2

Date: Sheet of

Gigabyte Technology

CPU LGA2011-A

GA-X99-UD5 WIFI

6 64Tuesday, August 26, 2014

1

1.0

5

VCCIO

WR21

240/4/1

A_-M_RSTC01
A_-M_RSTC23

A_TXT_AGENT
A_TXT_PLTEN

WR79

WR12 1K/4/1
WR28

240/4/1/X

WBC2

1u/4/X5R/6.3V/K/X

5

PU on die

A_-BMCINIT
A_-CATERR

A_CH01_SCL
A_CH23_SCL
A_CH01_SDA
A_CH23_SDA

A_FRMAGENT

A_TXT_AGENT
A_TXT_PLTEN

A_DDR4_STRAP

240/4/1

A_-DEBUG_EN
A_SAFE_BOOT

A_FIVR_FAULT

A_RSVD_AL55

AM48
CC51

CK42
CM42

DC15

CH16

A_EAR

CE53

AH52
AF52

BD48
AY46

AV46
CR51

BK56

CY56

CT50
DA11

CA53
AM54
AP48
AE45
AA41

BF48
BH48

AM44

CY40
CU51

CW51

DB56

WR2 49.9/4/1/X

WR22 240/4/1/X

VCCIO

D D

VCCIO

VCCIO

VCCIO

C C

B B

VCCIO

A A

A_CPU_OVERCLOCK(16)
A_CH01_SCL(11)

A_CH23_SCL(13)
A_CH01_SDA(11)
A_CH23_SDA(13)

A_-M_RSTC01(11,12)
A_-M_RSTC23(13,14)

A_DRAM_PWROK0(34)
A_DRAM_PWROK1(35)

WR4 240/4/1

VCCIO

Hi enable , Lo
disable

WR67 240/4/1

WR68 240/4/1/X
WR58 1K/4/1/X
WR59

VCCIO

VCCIO
VCCIO

WR13 1K/4/1

VCORE0

WR75 8.2K/4

WR44 240/4/1
WR45 1K/4/1/X

240/4/1

LGA2011-3L

AJ43

BIST_ENABLE
BMCINIT
CATERR

C53

RSVD
DDR_SCL_C01

V40

DDR_SCL_C23
DDR_SDA_C01

Y40

DDR_SDA_C23
DDR_RESET_C01

C23

DDR_RESET_C23
DRAM_PWR_OK_C01

W29

DRAM_PWR_OK_C23
EAR

Y48

FRMAGENT
TXT_AGENT

TXT_PLTEN

RSVD

AJ55

RSVD
RSVD
RSVD
RSVD

F40

DEBUG_EN
SAFE_MODE_BOOT

DC3

RSVD
RSVD

R53

RSVD

U53

RSVD
RSVD
RSVD

BL47

RSVD
RSVD
RSVD
RSVD
RSVD
RSVD

Y54

RSVD

W41

RSVD

V42

RSVD

R43

RSVD

P42

RSVD

J41

RSVD

H56

RSVD

G43

RSVD

F46

RSVD

E53

RSVD
RSVD

C41

RSVD

SVD

R
RSVD

N41

RSVD
FIVR_FAULT
RSVD
RSVD

B54

RSVD

F58

RSVD

E57

RSVD
RSVD

A53

RSVD

AL55

RSVD

HASWELL_E_EDS

12 OF 19

󲕸󱍯󴣊󰵓

A_CPU_N_COMP

?

4

LGA2011-3M

4

HASWELL_E_EDS

13 OF 19

RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD

RSVD
RSVD
RSVD
RSVD
RSVD

RSVD
PE_HP_SCL
PE_HP_SDA

PECI

PMSYNC

PRDY

PREQ

PROCHOT

PWRGOOD

RESET

MSMI

SKTOCC

BPM_N_0
BPM_N_1
BPM_N_2
BPM_N_3
BPM_N_4
BPM_N_5
BPM_N_6

BPM_N_7
MEM_HOT_C01
MEM_HOT_C23

SOCKET_ID_0
SOCKET_ID_1

PM_FAST_WAKE

PROC_ID

PWR_DEBUG

RSVD

ERROR_N_0
ERROR_N_1
ERROR_N_2

TDO
TMS

TRST
RSVD
RSVD

THERMTRIP

SVIDALERT

SVIDCLK

SVIDDATA

TCK

TDI

BK44
BN45
BM44
BR45
BL43
BP44
BU43
BR43
BD44
BF44
BH46
BG43
BE43
BJ45
BH44
BJ43
BT44
CA43
BV44
BY44

F56
D56
K58
H58
AU55
AR55

A_PE_HP_SCL_PU

B46

A_PE_HP_SDA_PU

D46

A_PECI

CG55

A_PMSYNC0

K52

A_-HPRDY

CU49

A_-HPREQ

CW49
BL51
BJ53

N_-CPURST

CR43

N_-CPU_SMI

H52

A_-SKTOC

BU49

BC43
BB44
BE47
BF46
BE45
BD46
BA43
AW43
CL33
P36

CP52
CC53

A_-PM_FAST_WAKE

AV44
AB48
AC41

A_CPU_N_COMP

DE53

BD50
BB48
BB52

A_TCK

CA45

A_TDI

CF42

A_TDO

CG41

A_TMS

BY46

A_-TRST

CV50

TP_EHERMADA

CN43

TP_EHERMADC

CL43

A_-THRMTRIP

BJ47

-H_VIDALRT

AN43

H_VIDCLK

AU43

H_VIDSOUT

AR43

3

VCCIO

WR73

240/4/1/X

WR74

240/4/1

240/4/1/X

WR84

WR50750/4/1/X

VCCIO
VCCIO

A_PECI (28,42)
A_PMSYNC0 (15)

A_-PROCHOT (28,30)

N_CPUPWROK (16)

N_-CPURST (16)

A_-SKTOC (16)

A_BPM_N0

A_BPM_N1

A_BPM_N2

A_BPM_N3

A_BPM_N4
A_BPM_N5
A_BPM_N6

A_BPM_N7

A_-MHOT_C01 (11,12)
A_-MHOT_C23 (13,14)

SOCKET0

SOCKET1

A_PROC_ID

A_-CPU_DBPWR

A_-ERROR0

A_-ERROR1

A_-ERROR2

WR47 0/4/SHT/20/X
WR35 0/4/SHT/20/X

VCCIO

WR83

75/4/1/X

A_PROC_ID (38) IO_GP27(28)

WTP6
WTP5

WR32 220/4 WBC33

A_-VIDALRT (30)

A_VIDSLCK (30)
A_VIDSOUT (30)

3

A_-THRMTRIP

A_-BMCINIT A_BPM_N1

VCCIO

WR82

SOCKET0

240/4/1

WR19 8.2K/4

VCCIO

WR6 0/4/X

WQ1

WR8

8.2K/4

VCCIO

N_CPUPWROK

DIS_T

DIS_T

WBC5

1n/4/X7R/50V/K/X

WBC13

10P/4/NPO/50V/J

For glitch reduce

2

8.2K/4

WR80 1K/4/1/X

240/4/1/X

WR16

N_-THRMTRIPA_-THRMTRIP

MMBT2222A/SOT23/600mA/40

SOT23

132

WQ2

BAT54A/SOT23/200mA

SOT23

N_-CPURSTA_DRAM_PWROK0

A_DRAM_PWROK1

2

VCCIO

WR78

A_DDR4_STRAP

VCCIO

WR15

SOCKET1

240/4/1

N_-THRMTRIP (15,28,30,31,32,33)

WBC32

1n/4/X7R/50V/K/X

1n/4/X7R/50V/K/X

1

PU HI and PU DOWN

VCCIO

A_BPM_N0

1 2
3 4

A_BPM_N2

5 6

A_BPM_N3

7 8

WRN2

51/8P4R/6/X

A_BPM_N4

WR17 51/4/1/X

A_BPM_N5

WR18 51/4/1/X

A_BPM_N6

WR20 51/4/1

A_BPM_N7

WR27 51/4/1

VCCIO

WR43 75/4/1
WR7 75/4/1

WR53 4.7K/4/X
WR30

WR72
WR31
WR71

VCCIO

WR37 51/4/1
WR48 56.2/4/1/X
WR36 100/4/1

WR33 240/4/1/X
WR1 75/4/1
WR26 75/4/1
WR81 75/4/1

WR3 75/4/1
WR23 75/4/1
WR24 75/4/1

WR66 1K/4/1/X
WR57 1K/4/1
WR49 1K/4/1/X

WR34 8.2K/4

WR52 51/4/1
WR41 51/4/1

WR42 75/4/1
WR40 51/4/1

A_TCK
A_-TRST

A_SAFE_BOOT

A_EAR

A_CPU_OVERCLOCK

VCC3

WR54 8.2K/4

Title

Size Document Number Rev

Custom

Date: Sheet of

Gigabyte Technology

A_-CATERR
A_-THRMTRIP

A_PECI
A_CH01_SCL

A_CH23_SCL
A_CH01_SDA

A_CH23_SDA

240/4/1
240/4/1
240/4/1WR56750/4/1/X
240/4/1

A_-VIDALRT

A_VIDSLCK

A

_VIDSOUT

A_-CPU_DBPWR

A_-MHOT_C01

A_-MHOT_C23

N_-CPU_SMI

A_-ERROR0

A_-ERROR1

A_-ERROR2

A_-HPRDY

A_-PROCHOT

N_CPUPWROK

A_-CPU_DBPWR

A_-HPREQ

A_TDI

A_TDO

A_TMS

WR51 51/4/1
WR29 51/4/1

WR39 240/4/1/X
WR77 0/4/X
WR76 0/4/X

A_PROC_ID

CPU LGA2011-B

GA-X99-UD5 WIFI

7 64Tuesday, August 26, 2014

1

1.0

5

LGA2011-3E

BJ51

QPI0_DRX_DP_0

BG51

QPI0_DRX_DN_0

BH52

QPI0_DRX_DP_1

BF52

QPI0_DRX_DN_1

BE53

QPI0_DRX_DP_2

BG53

QPI0_DRX_DN_2

BE55

QPI0_DRX_DP_3

BG55

QPI0_DRX_DN_3

BF56

QPI0_DRX_DP_4

BH56

QPI0_DRX_DN_4

D D

C C

B B

A A

BF54

BH54

BF50

BH50
BD58

BF58
BE57

BG57
BM56

BP56
BL55

BN55
BM54

BP54
BL53

BN53
BM52

BP52

BN51
BR51

BM50

BP50

BN49
BR49

BG49

BJ49

BM48

BP48

BN47
BR47

CK44
CM44

CL45

CN45
CK46

CM46

CL47

CN47
CK48

CM48

CL49

CN49
CK50

CM50

CL51

CN51
CT52

CV52
CR53

CU53
CP54

CT54
CU55

CR55
CV56

CT56
CU57

CR57
CT58

CP58
CM56

CK56

CJ55
CL55

CD54
CF54

CD56
CF56

CC55
CE55

QPI0_DRX_DP_5
QPI0_DRX_DN_5

QPI0_DRX_DP_6
QPI0_DRX_DN_6

QPI0_DRX_DP_7
QPI0_DRX_DN_7

QPI0_DRX_DP_8
QPI0_DRX_DN_8

QPI0_DRX_DP_9
QPI0_DRX_DN_9

QPI0_DRX_DP_10
QPI0_DRX_DN_10

QPI0_DRX_DP_11
QPI0_DRX_DN_11

QPI0_DRX_DP_12
QPI0_DRX_DN_12

QPI0_DRX_DP_13
QPI0_DRX_DN_13

QPI0_DRX_DP_14
QPI0_DRX_DN_14

QPI0_DRX_DP_15
QPI0_DRX_DN_15

QPI0_DRX_DP_16
QPI0_DRX_DN_16

QPI0_DRX_DP_17
QPI0_DRX_DN_17

QPI0_DRX_DP_18
QPI0_DRX_DN_18

QPI0_DRX_DP_19
QPI0_DRX_DN_19

QPI1_DRX_DP_0
QPI1_DRX_DN_0

QPI1_DRX_DP_1
QPI1_DRX_DN_1

QPI1_DRX_DP_2
QPI1_DRX_DN_2

QPI1_DRX_DP_3
QPI1_DRX_DN_3

QPI1_DRX_DP_4
QPI1_DRX_DN_4

QPI1_DRX_DP_5
QPI1_DRX_DN_5

QPI1_DRX_DP_6
QPI1_DRX_DN_6

QPI1_DRX_DP_7
QPI1_DRX_DN_7

QPI1_DRX_DP_8
QPI1_DRX_DN_8

QPI1_DRX_DP_9
QPI1_DRX_DN_9

QPI1_DRX_DP_10
QPI1_DRX_DN_10

QPI1_DRX_DP_11
QPI1_DRX_DN_11

QPI1_DRX_DP_12
QPI1_DRX_DN_12

QPI1_DRX_DP_13
QPI1_DRX_DN_13

QPI1_DRX_DP_14
QPI1_DRX_DN_14

QPI1_DRX_DP_15
QPI1_DRX_DN_15

QPI1_DRX_DP_16
QPI1_DRX_DN_16

QPI1_DRX_DP_17
QPI1_DRX_DN_17

QPI1_DRX_DP_18
QPI1_DRX_DN_18

QPI1_DRX_DP_19
QPI1_DRX_DN_19

HASWELL_E_EDS

QPI0_CLKRX_DP
QPI0_CLKRX_DN
QPI0_CLKTX_DP
QPI0_CLKTX_DN
QPI1_CLKRX_DP
QPI1_CLKRX_DN
QPI1_CLKTX_DP
QPI1_CLKTX_DN

QPI0_DTX_DP_0
QPI0_DTX_DN_0

QPI0_DTX_DP_1
QPI0_DTX_DN_1

QPI0_DTX_DP_2
QPI0_DTX_DN_2

QPI0_DTX_DN_3
QPI0_DTX_DP_3

QPI0_DTX_DP_4
QPI0_DTX_DN_4

QPI0_DTX_DP_5
QPI0_DTX_DN_5

QPI0_DTX_DP_6
QPI0_DTX_DN_6

QPI0_DTX_DP_7
QPI0_DTX_DN_7

QPI0_DTX_DP_8
QPI0_DTX_DN_8

QPI0_DTX_DP_9
QPI0_DTX_DN_9

QPI0_DTX_DP_10
QPI0_DTX_DN_10

QPI0_DTX_DP_11
QPI0_DTX_DN_11

QPI0_DTX_DP_12
QPI0_DTX_DN_12

QPI0_DTX_DP_13
QPI0_DTX_DN_13

QPI0_DTX_DP_14
QPI0_DTX_DN_14

QPI0_DTX_DP_15
QPI0_DTX_DN_15

QPI0_DTX_DP_16
QPI0_DTX_DN_16

QPI0_DTX_DP_17
QPI0_DTX_DN_17

QPI0_DTX_DP_18
QPI0_DTX_DN_18

QPI0_DTX_DP_19
QPI0_DTX_DN_19

QPI1_DTX_DP_0
QPI1_DTX_DN_0

QPI1_DTX_DP_1
QPI1_DTX_DN_1

QPI1_DTX_DP_2
QPI1_DTX_DN_2

QPI1_DTX_DP_3
QPI1_DTX_DN_3

QPI1_DTX_DP_4
QPI1_DTX_DN_4

QPI1_DTX_DP_5
QPI1_DTX_DN_5

QPI1_DTX_DP_6
QPI1_DTX_DN_6

QPI1_DTX_DP_7
QPI1_DTX_DN_7

QPI1_DTX_DP_8
QPI1_DTX_DN_8

QPI1_DTX_DP_9
QPI1_DTX_DN_9

QPI1_DTX_DP_10
QPI1_DTX_DN_10

QPI1_DTX_DP_11
QPI1_DTX_DN_11

QPI1_DTX_DP_12
QPI1_DTX_DN_12

QPI1_DTX_DP_13
QPI1_DTX_DN_13

QPI1_DTX_DP_14
QPI1_DTX_DN_14

QPI1_DTX_DP_15
QPI1_DTX_DN_15

QPI1_DTX_DP_16
QPI1_DTX_DN_16

QPI1_DTX_DP_17
QPI1_DTX_DN_17

QPI1_DTX_DP_18
QPI1_DTX_DN_18

QPI1_DTX_DP_19

5 OF 19

5

QPI1_DTX_DN_19

RSVD
RSVD
RSVD
RSVD
RSVD
RSVD

DE55
DD54
DA57
CY58
BP46
BM46
BK58
BM58
CD44
CF44
CJ53
CL53
DB54
CY54

BV50
BW49

BV52
BW51

BU53
BW53

BY54
BV54

BU55
BW55

BT58
BV58

BV48
BW47

BU57
BW57

BV56
BY56

BV46
BW45

CD46
CF46

CA51
BY52

BY48
CA47

BY50
CA49

CE47
CG47

CD48
CF48

CD50
CF50

CD52
CF52

CE51
CG51

CE49
CG49

DC41
DE41

DD42
DB42

CU41
CW41

DC43
DE43

DD44
DB44

CT42
CV42

DC45
DE45

DD46
DB46

CU43
CW43

DC47
DE47

DB48
DD48

CU45
CW45

DE49
DC49

DB50
DD50

CU47
CW47

DE51
DC51

DB52
DD52

CT48
CV48

CT46
CV46

CT44
CV44

4

PA_EXP_A_RXP0
PA_EXP_A_RXN0

P

A_EXP_A_RXP1

PA_EXP_A_RXN1
PA_EXP_A_RXP2

PA_EXP_A_RXN2
PA_EXP_A_RXP3

PA_EXP_A_RXN3
PA_EXP_A_RXP4

PA_EXP_A_RXN4
PA_EXP_A_RXP5

PA_EXP_A_RXN5
PA_EXP_A_RXP6

PA_EXP_A_RXN6
PA_EXP_A_RXP7

PA_EXP_A_RXN7
PA_EXP_A_RXP8

PA_EXP_A_RXN8
PA_EXP_A_RXP9

PA_EXP_A_RXN9

PA_EXP_A_RXP10
PA_EXP_A_RXN10

PA_EXP_A_RXP11
PA_EXP_A_RXN11

PA_EXP_A_RXP12
PA_EXP_A_RXN12

PA_EXP_A_RXP13
PA_EXP_A_RXN13

PA_EXP_A_RXP14
PA_EXP_A_RXN14

PA_EXP_A_RXP15
PA_EXP_A_RXN15

A_DMI_0TXP(17)
A_DMI_0TXN(17)
A_DMI_1TXP(17)
A_DMI_1TXN(17)
A_DMI_2TXP(17)
A_DMI_2TXN(17)
A_DMI_3TXP(17)
A_DMI_3TXN(17)

4

3

HASWELL_E_EDS

LGA2011-3B

L55

PE2A_RX_DN_0

V54

PE2A_RX_DP_1

T54

PE2A_RX_DN_1

V56

PE2A_RX_DP_2

T56

PE2A_RX_DN_2

W55

PE2A_RX_DP_3

U55

PE2A_RX_DN_3

AD54

PE2B_RX_DP_4

AB54

PE2B_RX_DN_4

AD56

PE2B_RX_DP_5

AB56

PE2B_RX_DN_5

AE55

PE2B_RX_DP_6

AC55

PE2B_RX_DN_6

AF58

PE2B_RX_DP_7

AE57

PE2B_RX_DN_7

AK56

PE2C_RX_DP_8

AH56

PE2C_RX_DN_8

AM58

PE2C_RX_DP_9

AK58

PE2C_RX_DN_9

AL57

PE2C_RX_DP_10

AJ57

PE2C_RX_DN_10

AU57

PE2C_RX_DP_11

AR57

PE2C_RX_DN_11

AV58

PE2D_RX_DP_12

AT58

PE2D_RX_DN_12

AT56

PE2D_RX_DP_13

AP56

PE2D_RX_DN_13

BA57

PE2D_RX_DP_14

AY58

PE2D_RX_DN_14

BB56

PE2D_RX_DP_15

AY56

PE2D_RX_DN_15

PA_EXP_A_RXP[0..15]
PA_EXP_A_RXN[0..15]

PA_EXP_A_TXP[0..15]
PA_EXP_A_TXN[0..15]

PG_EXP_C_RXP0(24)
PG_EXP_C_RXN0(24)

PG_EXP_C_RXP1(24)
PG_EXP_C_RXN1(24)

PG_EXP_C_RXP2(24)
PG_EXP_C_RXN2(24)

PG_EXP_C_RXP3(24)
PG_EXP_C_RXN3(24)

PG_EXP_C_RXP4(24)
PG_EXP_C_RXN4(24)

PG_EXP_C_RXP5(24)
PG_EXP_C_RXN5(24)

PG_EXP_C_RXP6(24)
PG_EXP_C_RXN6(24)

PG_EXP_C_RXP7(24)
PG_EXP_C_RXN7(24)

E51

C51
F52

D52
F54

D54
G55

E55

L53
J53

M54

K54
L57

J57

M56
K56

2 OF 19

LGA2011-3A

PE1A_RX_DP_0
PE1A_RX_DN_0

PE1A_RX_DP_1
PE1A_RX_DN_1

PE1A_RX_DP_2
PE1A_RX_DN_2

PE1A_RX_DP_3
PE1A_RX_DN_3

PE1B_RX_DP_4
PE1B_RX_DN_4

PE1B_RX_DP_5
PE1B_RX_DN_5

PE1B_RX_DP_6
PE1B_RX_DN_6

PE1B_RX_DP_7
PE1B_RX_DN_7

PE2A_TX_DP_0PE2A_RX_DP_0

PE2A_TX_DN_0

PE2A_TX_DP_1

PE2A_TX_DN_1

PE2A_TX_DP_2

PE2A_TX_DN_2

PE2A_TX_DP_3

PE2A_TX_DN_3

PE2B_TX_DP_4

PE2B_TX_DN_4

PE2B_TX_DP_5

PE2B_TX_DN_5

PE2B_TX_DP_6

PE2B_TX_DN_6

PE2B_TX_DP_7

PE2B_TX_DN_7
PE2C_TX_DP_8

PE2C_TX_DN_8
PE2C_TX_DP_9

PE2C_TX_DN_9

PE2C_TX_DP_10
PE2C_TX_DN_10

PE2C_TX_DP_11
PE2C_TX_DN_11

PE2D_TX_DP_12
PE2D_TX_DN_12

PE2D_TX_DP_13
PE2D_TX_DN_13

PE2D_TX_DP_14
PE2D_TX_DN_14

PE2D_TX_DP_15
PE2D_TX_DN_15

PA_EXP_A_RXP[0..15] (21)
PA_EXP_A_RXN[0..15] (21)

PA_EXP_A_TXP[0..15] (21)
PA_EXP_A_TXN[0..15] (21)

HASWELL_E_EDS

AR49N55
AN49

AP50
AM50

AR51
AN51

AP52
AM52

AJ53
AG53

AK54
AH54

AR53
AN53

AT54
AP54

AY52
AV52

BA53
AW53

BB54
AY54

BA51
AW51

AY50
AV50

BA49
AW49

AY48
AV48

BA47
AW47

PA_EXP_A_TXP0
PA_EXP_A_TXN0

PA_EXP_A_TXP1
PA_EXP_A_TXN1

PA_EXP_A_TXP2
PA_EXP_A_TXN2

PA_EXP_A_TXP3
PA_EXP_A_TXN3

PA_EXP_A_TXP4
PA_EXP_A_TXN4

PA_EXP_A_TXP5
PA_EXP_A_TXN5

PA_EXP_A_TXP6
PA_EXP_A_TXN6

PA_EXP_A_TXP7
PA_EXP_A_TXN7

PA_EXP_A_TXP8
PA_EXP_A_TXN8

PA_EXP_A_TXP9
PA_EXP_A_TXN9

PA_EXP_A_TXP10
PA_EXP_A_TXN10

PA_EXP_A_TXP11
PA_EXP_A_TXN11

PA_EXP_A_TXP12
PA_EXP_A_TXN12

PA_EXP_A_TXN13
PA_EXP_A_TXP14

PA_EXP_A_TXN14
PA_EXP_A_TXP15

PA_EXP_A_TXN15

PE1A_TX_DP_0
PE1A_TX_DN_0

PE1A_TX_DP_1
PE1A_TX_DN_1

PE1A_TX_DP_2
PE1A_TX_DN_2

PE1A_TX_DP_3
PE1A_TX_DN_3

PE1B_TX_DP_4
PE1B_TX_DN_4

PE1B_TX_DP_5
PE1B_TX_DN_5

PE1B_TX_DP_6
PE1B_TX_DN_6

PE1B_TX_DP_7
PE1B_TX_DN_7

PB_EXP_B_RXP[8..15]
PB_EXP_B_RXN[8..15]

PB_EXP_B_RXP0
PB_EXP_B_RXN0

PB_EXP_B_RXP1
PB_EXP_B_RXN1

PB_EXP_B_RXP2
PB_EXP_B_RXN2

PB_EXP_B_RXP3
PB_EXP_B_RXN3

PB_EXP_B_RXP4
PB_EXP_B_RXN4

PB_EXP_B_RXP5
PB_EXP_B_RXN5

PB_EXP_B_RXP6
PB_EXP_B_RXN6

PB_EXP_B_RXP7
PB_EXP_B_RXN7

PB_EXP_B_RXP8
PB_EXP_B_RXN8

PB_EXP_B_RXP9
PB_EXP_B_RXN9

PB_EXP_B_RXP10
PB_EXP_B_RXN10

PB_EXP_B_RXP11
PB_EXP_B_RXN11

PB_EXP_B_RXP12
PB_EXP_B_RXN12

PB_EXP_B_RXP13
PB_EXP_B_RXN13

PB_EXP_B_RXP14
PB_EXP_B_RXN14

PB_EXP_B_RXP15
PB_EXP_B_RXN15

PB_EXP_B_TXP[8..15]
PB_EXP_B_TXN[8..15]

A_EXP_C_TXP0

K42

A_EXP_C_TXN0

H42

A_EXP_C_TXP1

L43

A_EXP_C_TXN1

J43

A_EXP_C_TXP2

K44

A_EXP_C_TXN2

H44

A_EXP_C_TXP3

L45

A_EXP_C_TXN3

J45

A_EXP_C_TXP4

K46

A_EXP_C_TXN4

H46

A_EXP_C_TXP5

L47

A_EXP_C_TXN5

J47

A_EXP_C_TXP6

K48

A_EXP_C_TXN6

H48

A_EXP_C_TXP7

L49

A_EXP_C_TXN7

J49

AH44
AF44

AJ45

AG45

AH46
AF46

AC49
AA49

AB50

AB52

AC53
AA53

AC51
AA51

AH48
AF48

AJ51

AG51

AH50
AF50

AJ49

AG49

AJ47

AG47

AR47
AN47

AP46

AM46

AR45
AN45

PB_EXP_B_RXP[8..15] (20)
PB_EXP_B_RXN[8..15] (20)

PB_EXP_B_TXP[8..15] (20)
PB_EXP_B_TXN[8..15] (20)

LGA2011-3C

PE3A_RX_DP_0
PE3A_RX_DN_0

PE3A_RX_DP_1
PE3A_RX_DN_1

PE3A_RX_DP_2
PE3A_RX_DN_2

PE3A_RX_DP_3
PE3A_RX_DN_3

PE3B_RX_DP_4

Y50

PE3B_RX_DN_4
PE3B_RX_DP_5

Y52

PE3B_RX_DN_5
PE3B_RX_DP_6

PE3B_RX_DN_6
PE3B_RX_DP_7

PE3B_RX_DN_7
PE3C_RX_DP_8

PE3C_RX_DN_8
PE3C_RX_DP_9

PE3C_RX_DN_9
PE3C_RX_DP_10

PE3C_RX_DN_10
PE3C_RX_DP_11

PE3C_RX_DN_11
PE3D_RX_DP_12

PE3D_RX_DN_12
PE3D_RX_DP_13

PE3D_RX_DN_13
PE3D_RX_DP_14

PE3D_RX_DN_14
PE3D_RX_DP_15

PE3D_RX_DN_15

A_EXP_C_TXP0 (24)
A_EXP_C_TXN0 (24)

A_EXP_C_TXP1 (24)
A_EXP_C_TXN1 (24)

A_EXP_C_TXP2 (24)
A_EXP_C_TXN2 (24)

A_EXP_C_TXP3 (24)
A_EXP_C_TXN3 (24)

A_EXP_C_TXP4 (24)
A_EXP_C_TXN4 (24)

A_EXP_C_TXP5 (24)
A_EXP_C_TXN5 (24)

A_EXP_C_TXP6 (24)
A_EXP_C_TXN6 (24)

A_EXP_C_TXP7 (24)
A_EXP_C_TXN7 (24)

HASWELL_E_EDS

3 OF 19

2

PE3A_TX_DP_0
PE3A_TX_DN_0

P

E3A_TX_DP_1

PE3A_TX_DN_1
PE3A_TX_DP_2

PE3A_TX_DN_2
PE3A_TX_DP_3

PE3A_TX_DN_3
PE3B_TX_DP_4

PE3B_TX_DN_4
PE3B_TX_DP_5

PE3B_TX_DN_5
PE3B_TX_DP_6

PE3B_TX_DN_6
PE3B_TX_DP_7

PE3B_TX_DN_7
PE3C_TX_DP_8

PE3C_TX_DN_8
PE3C_TX_DP_9

PE3C_TX_DN_9

PE3C_TX_DP_10
PE3C_TX_DN_10

PE3C_TX_DP_11
PE3C_TX_DN_11

PE3D_TX_DP_12
PE3D_TX_DN_12

PE3D_TX_DP_13
PE3D_TX_DN_13

PE3D_TX_DP_14
PE3D_TX_DN_14

PE3D_TX_DP_15
PE3D_TX_DN_15

PB_EXP_B_RXP[0..7]
PB_EXP_B_RXN[0..7]

PB_EXP_B_TXP[0..7]
PB_EXP_B_TXN[0..7]

K50
H50

L51
J51

U47
R47

T48
P48

T52
P52

U51
R51

T50
P50

U49
R49

T46
P46

U45
R45

AC47
AA47

AB46
Y46

AC45
AA45

AB44
Y44

AA43
AC43

P44
T44

PB_EXP_B_TXP0
PB_EXP_B_TXN0

PB_EXP_B_TXP1
PB_EXP_B_TXN1

PB_EXP_B_TXP2
PB_EXP_B_TXN2

PB_EXP_B_TXP3
PB_EXP_B_TXN3

PB_EXP_B_TXP4
PB_EXP_B_TXN4

PB_EXP_B_TXP5
PB_EXP_B_TXN5

PB_EXP_B_TXP6
PB_EXP_B_TXN6

PB_EXP_B_TXP7
PB_EXP_B_TXN7

PB_EXP_B_TXP8
PB_EXP_B_TXN8

PB_EXP_B_TXP9
PB_EXP_B_TXN9

PB_EXP_B_TXP10
PB_EXP_B_TXN10

PB_EXP_B_TXP11
PB_EXP_B_TXN11

PB_EXP_B_TXP12
PB_EXP_B_TXN12

PB_EXP_B_TXP13PA_EXP_A_TXP13
PB_EXP_B_TXN13

PB_EXP_B_TXP14
PB_EXP_B_TXN14

PB_EXP_B_TXP15
PB_EXP_B_TXN15

PB_EXP_B_RXP[0..7] (22)
PB_EXP_B_RXN[0..7] (22)

PB_EXP_B_TXP[0..7] (22)
PB_EXP_B_TXN[0..7] (22)

1

1 OF 19

HASWELL_E_EDS

DMI_RX_DP_0
DMI_RX_DN_0
DMI_RX_DP_1
DMI_RX_DN_1
DMI_RX_DP_2
DMI_RX_DN_2
DMI_RX_DP_3
DMI_RX_DN_3

BCLK0_DN
BCLK0_DP
BCLK1_DN
BCLK1_DP

D50
B50
E49
C49
D48
B48
E47
C47

CN41
CL41
AW45
BA45

A_DMI_0RXP
A_DMI_0RXN
A_DMI_1RXP
A_DMI_1RXN
A_DMI_2RXP
A_DMI_2RXN
A_DMI_3RXP
A_DMI_3RXN

A_DMI_0RXP (17)
A_DMI_0RXN (17)
A_DMI_1RXP (17)
A_DMI_1RXN (17)
A_DMI_2RXP (17)
A_DMI_2RXN (17)
A_DMI_3RXP (17)
A_DMI_3RXN (17)

N_-CPU_BCLK0 (26)
N_CPU_BCLK0 (26)

N_-CPU_BCLK1 (26)
N_CPU_BCLK1 (26)

A_DMI_0TXP
A_DMI_0TXN
A_DMI_1TXP
A_DMI_1TXN
A_DMI_2TXP
A_DMI_2TXN
A_DMI_3TXP
A_DMI_3TXN

E45
C45
D44
B44
E43
C43
D42
B42

LGA2011-3D

DMI_TX_DP_0
DMI_TX_DN_0
DMI_TX_DP_1
DMI_TX_DN_1
DMI_TX_DP_2
DMI_TX_DN_2
DMI_TX_DP_3
DMI_TX_DN_3

4 OF 19

Title

Size Document Number Rev

Custom

3

2

Date: Sheet of

Gigabyte Technology

CPU LGA2011-B

GA-X99-UD5 WIFI

8 64Tuesday, August 26, 2014

1

1.0

5

VCORE VCORE

LGA2011-3N

BD10

BD8
BD6
BD4

BD2
BC17
BC15
BC13
BC11

BC9

D D

C C

B B

BC7

BC5

BC3

BC1
BB16
BB14
BB12
BB10

BB8

BB6

BB4

BB2
BA17
BA15
BA13
BA11

BA9

BA7

BA5

BA3

BA1
AY42

AW1
AV16
AV14
AV12
AV10

AV8
AV6
AV4

AV2
AU17
AU15
AU13
AU11

AU9

AU7

AU5

AU3

AU1

AT42
AT16
AT14
AT12
AT10

AT8

AT6

AT4

AT2
AR17
AR15
AR13
AR11

AR9

AR7

AR5

AR3

AR1
AP16
AP14
AP12
AP10

AP8

AP6

AP4

AP2
AN17
AN11
AM42

AL17
AH42
AG33
AG29
AG27
AG23

AF42 AG35

HASWELL_E_EDS

VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN VCCIN

14 OF 19

VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN

CCIN

V
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN
VCCIN

BY42
BY40
BY38
BY36
BY34
BY30
BY26
BY24
BY22
BY20
BY18
BV42
BU17
BR17
BP42
BP16
BP10
BN17
BN15
BN13
BN11
BN9
BN7
BN5
BN3
BM42
BM16
BM14
BM12
BM10
BM8
BM6
BM4
BM2
BL17
BL15
BL13
BL11
BL9
BL7
BL5
BL3
BL1
BK16
BK14
BK12
BK10
BK8
BK6
BK4
BK2
BJ17
BJ15
BJ13
BJ11
BJ9
BJ7
BJ5
BJ3
BJ1
BH42
BH16
BH14
BH12
BH10
BH8
BH6
BH4
BH2
BG1
BE17
BE15
BE13
BE11
BE9
BE7
BE5
BE3
BE1
BD42
BD16
BD14
BD12
AG41
AG39

LGA2011-3O

4

HASWELL_E_EDS

VSS_VCCIN_SENSE

15 OF 19

VCCIN

VCCIO_IN
VCCPECI

VCCIN_SENSE

VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01
VCCD_01

VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23
VCCD_23

VCORE

VCCIO

CE41
CC41

CD42

WR55 0/4/SHT/20/X

BN1

VCC_SENSE (30)

BP2

DDR_12V_A

DE17
DB26
DB24
DB22
DB20
DB18
DB16
CU25
CU23
CU21
CU19
CU17
CM26
CM24
CM22
CM20
CM18
CM16
CG25
CG23
CG21
CG19
CG17
CB26
CB24
CB22
CB20
CB18

DDR_12V_B

CB16
AC21

AC19
AC17
AC15
V22
V20
V18
V16
V14
N21
N19
N17
N15
N13
N11
H22
H20
H18
H16
H14
H12
E19
E17
E15
C21
C13
C11

VCCIO

VSS_SENSE (30)

3

2

VCORE

VCORE

WBC30

22u/8/X5R/6.3V/M

WBC8

22u/8/X5R/6.3V/M

WBC14

22u/8/X5R/6.3V/M

WBC18

22u/8/X5R/6.3V/M

WSBC31

22u/8/X5R/6.3V/M

WSBC12

22u/8/X5R/6.3V/M

WSBC9

22u/8/X5R/6.3V/M

WSBC29

22u/8/X5R/6.3V/M

WBC24

22u/8/X5R/6.3V/M

WBC22

22u/8/X5R/6.3V/M

WBC23

22u/8/X5R/6.3V/M

WBC17

22u/8/X5R/6.3V/M

WSBC1

22u/8/X5R/6.3V/M

WSBC18

22u/8/X5R/6.3V/M

WSBC3

22u/8/X5R/6.3V/M

WSBC23

22u/8/X5R/6.3V/M

WBC12

22u/8/X5R/6.3V/M

WBC11

22u/8/X5R/6.3V/M

WBC15

22u/8/X5R/6.3V/M

WBC16

22u/8/X5R/6.3V/M

WSBC28

22u/8/X5R/6.3V/M

WSBC7

22u/8/X5R/6.3V/M

WSBC13

22u/8/X5R/6.3V/M

WSBC16

22u/8/X5R/6.3V/M

22u/8/X5R/6.3V/M

VCORE

22u/8/X5R/6.3V/M

VCORE

22u/8/X5R/6.3V/M

VCORE

22u/8/X5R/6.3V/M

VCORE

22u/8/X5R/6.3V/M

VCORE

22u/8/X5R/6.3V/M

VCORE

22u/8/X5R/6.3V/M

VCORE

22u/8/X5R/6.3V/M

WBC31

WBC7

WBC36

WBC35

WSBC8

WSBC15

WSBC14

WSBC30

WBC9

22u/8/X5R/6.3V/M

WBC34

22u/8/X5R/6.3V/M

WBC21

22u/8/X5R/6.3V/M

WBC29

22u/8/X5R/6.3V/M

WSBC25

22u/8/X5R/6.3V/M

WSBC17

22u/8/X5R/6.3V/M

WSBC20

22u/8/X5R/6.3V/M

WSBC26

22u/8/X5R/6.3V/M

WBC26

22u/8/X5R/6.3V/M

WBC6

22u/8/X5R/6.3V/M

WBC20

22u/8/X5R/6.3V/M

WBC28

22u/8/X5R/6.3V/M

WSBC6

22u/8/X5R/6.3V/M

WSBC24

22u/8/X5R/6.3V/M

WSBC19

22u/8/X5R/6.3V/M

WSBC27

22u/8/X5R/6.3V/M

22u/8/X5R/6.3V/M

22u/8/X5R/6.3V/M

22u/8/X5R/6.3V/M

22u/8/X5R/6.3V/M

22u/8/X5R/6.3V/M

22u/8/X5R/6.3V/M

22u/8/X5R/6.3V/M

DDR_12V_A DDR_12V_B VCCIO

1

WBC10

WBC27

WBC19

MBBC31
22u/8/X5R/6.3V/M

WSBC10

WSBC2

WSBC22

WSBC21

WBC25

22u/8/X5R/6.3V/M

WSBC34

22u/8/X5R/6.3V/M

WSBC37

22u/8/X5R/6.3V/M

WSBC11

22u/8/X5R/6.3V/M

WSBC35

22u/8/X5R/6.3V/M

WSBC36

22u/8/X5R/6.3V/M

DDR_12V_A DDR_12V_B

WSBC5

A A

5

4

22u/8/X5R/6.3V/M

3

WSBC4

22u/8/X5R/6.3V/M

WSBC32

22u/8/X5R/6.3V/M

2

WSBC33

22u/8/X5R/6.3V/M

Title

Size Document Number Rev

Custom

Date: Sheet of

Gigabyte Technology

WBC3

22u/8/X5R/6.3V/M

22u/8/X5R/6.3V/M

CPU LGA2011-C

GA-X99-UD5 WIFI

1

VCCIO

WBC4

1.0

9 64Tuesday, August 26, 2014

5

4

3

2

1

LGA2011-3P

CB56

D D

C C

B B

CD8
CD6

CD4
CC49
CC47
CC45
CC43
CC33
CC11

CC9

CC7

CC5

CC3
BB58
BB50

AY44
AY16

AY14
CG45
CG43
CG39
CG37
CG35
CG33
CG31
CG29
CG27

CG7

CG5
CF32
CF28
CF12
CF10
CE45
CE43
CE33
CE15

CE7
CD40
CD12
BB46
BB42
BV10 BV16
BU51
BU47
BU45

BU5

BU3

BT56
BT54
BT52
BT50
BT48
BT46
BT42
BT16

BT10
BR57
BR55
BR53
BR15
BR13
BR11

BR9
BR7
BR5

BR3

BR1
BP58
BP14
BP12

BP8

BP6

BP4
BN57
BN43

BL57
BL49

BL45
BK54
BK52

HASWELL_E_EDS

VSS
VSS

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

16 OF 19

VSS
VSSVSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

AY12
CB52CB54
CB50
CB48
CB46
CB44
CB42
CB40
CB38
CB36
CB34
CB30
CB14
CB12
CB10
CB2
CA57
CA55
CA41
CA39
CA37
CA35
CA33
CA31
CA29
CA27
CA25
CA23
CA21
CA19
CA17
CA15
CA13
CA5
BY58
BY32
BY28
BY10
BY8
BW43
BW17
BW15
BW7
BW5

BK50
BK48
BK46
BK42
BJ57
BJ55
BH58
BG47
BG45
BG17
BG15
BG13
BG11
BG9
BG7
BG5
BG3
BF42
BF16
BF14
BF12
BF10
BF8
BF6
BF4
BF2
BE51
BE49
BD56
BD54
BD52
BC57
BC55
BC53
BC51
BC49
BC47
BC45

LGA2011-3Q

AW7
AW5

AW3
AV56
AV54
AV42

AU53
AU51
AU49
AU47
AU45

AT52
AT50
AT48
AF38
AF36
AF34
AF32
AF30
AF28
AF26
AF24
AF22
AF20
AF18
AF16
AF10

AF8
AF6
AF4

AF2
AE53
AE51
AE49
AE47
AE43
AE41
AE39
AE35
AE33
AE29
AE27
AE23
AE19
AE15
AE13

AD52
AD50
AD48
AD46
AD44
AD42
AD40
AD36
AD12
AD10

AD8
AD6

AD4
AC29
AC11

AC9

AC7

AB42
AB40

A47
A45
A43
A23

A7

A5
AW17
AW15
AW13

HASWELL_E_EDS

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

17 OF 19

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSSVSS

AT46
AT44
AP58
AP44
AP42
AN57
AN55
AN15
AN13
AN9
AN7
AN5
AN3
AN1
AM56
AM16
AM14
AM12
AM10
AM8
AM6
AM4
AM2
AL53
AL51
AL49
AL47
AL45
AL43
AL11
AK52
AK50
AK48
AK46
AK44
AK42
AK16
AK6
AK4
AJ17
AJ11
AH58
AH14
AH6
AH2
AG57
AG55
AG43
AG37
AG31
AG25
AG21
AG19
AG17
AG13
AG11
AF56
AF54
AF40
AB36
AB12
AA55
AA39
AA31
AA29
AA25
AA7
AA3
A51
A49
A41
A39
A37
AW55
AW9AW11

HASWELL_E_EDS

LGA2011-3R

DA27

VSS

DA9 DA3

VSS VSS

DB40
DB34
DB12

DB6
DA55
DA53
DA51
DA49
DA47
DA45
DA43
DA41
DA35

N49

N47

N45
DF52
DF50
DF48
DF46
DF44
DF42
DF40
DF12

DF8

DE35
DE15

DE7

DD40
DD38
DD34
DD12
DD10

DD6

DC55
DC53

DC5

DB58

N53

N51

CR47
CR45
CR41
CR33

CR9

CR7

CP56
CP50
CP48
CP46
CP44
CP42
CP38
CP36
CP34
CP30
CP14
CP12

CP4

CN57
CN55
CN53
CN39
CN37
CN35
CN33
CN31
CN29
CN27
CN13
CN11

CN7

CN5

CN3

CM54
CM52
CM40
CM32

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

P24

VSS

P10

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

18 OF 19

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSSVSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

CY52
CY50
CY48
CY46
CY44
CY42
CY38
CY36
CY34
CY30
CY12
CY10
CY8
CY4
CY2
CW57
CW55
CW53
CW39
CW37
CW35
CW33
CW31
CW29
CW27
CW15
CW7
CW5
CW1
CV58
CV54
CV40
CV32
CV28
CV12
CV6
CU33
CU15
CU7
CU1
CT40
CT12
CT2CR49
CM28
CM10
CM8
CM6
CL15
CL11
CL9
CL7
CK54
CK52
CK40
CK12
CK4
CJ51
CJ49
CJ47
CJ45
CJ43
CJ41
CJ33
CJ15
CJ7
CJ3
CH56
CH54
CH52
CH50
CH48
CH46
CH44
CH42
CH40
CH38
CH36
CH34
CH30
CH12
CG53

LGA2011-3S

HASWELL_E_EDS

Y56

VSS

Y42

V

SS

Y36

VSS

Y34

VSS

Y32

VSS

Y30

VSS

Y28

VSS

Y26

VSS

Y24

VSS

Y12

VSS

Y4

VSS

W53

VSS

W51

VSS

W49

VSS

M42

VSS

M36

VSS

M10

VSS

M2

VSS

L41

VSS

L39

VSS

L29

VSS

L5

VSS

K40

VSS

K36

VSS

K10

VSS

J55

VSS

J37

VSS

J31

VSS

J29

VSS

J25

VSS

J7

VSS

J5

VSS

J3

VSS

H54

VSS

H40

VSS

H36

VSS

H34

VSS

H32

VSS

H30

VSS

H28

VSS

H26

VSS

H24

VSS

H8

VSS

H6

VSS

G57

VSS

G53

VSS

G51

VSS

G49

VSS

G47

VSS

G45

VSS

G41

VSS

G39

VSS

G35

VSS

G33

VSS

G27

VSS

G23

VSS

G9

VSS

G5

VSS

G1

VSS

F50

VSS

F48

VSS

F44

VSS

F42

VSS

F36

VSS

F32

VSS

D4

VSS

C55

VSS

C33

VSS

B36

VSS

B10

VSS

B6

VSS

AY8

VSS

AY6

VSS

AY4

VSS

AY2 AW57

VSS VSS

19 OF 19

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

W47
W45
W43
W39
W35
W33
W27
W23
W7
V52
V50
V48
V46
V44
V36
V12
V10
U43
U41
U39
U29
U7
U3
T42
T36
T8
T6
T4
R55
R39
R31
R29
R25
R11
R9
R5
P56
P54
P40
P38
P34
P32
P30
P28
P26
N43
N39
N37
N35
N33
N29
N27
N23
N5
M52
M50
M48
M46
M44
F30
F4
F2
E41
E39
E3
E1
D40
D36
D24
D10
C5
B52
B40
AY10

A A

Title

Size Document Number Rev

Custom

5

4

3

2

Date: Sheet of

Gigabyte Technology

CPU LGA2011-C

GA-X99-UD5 WIFI

10 64Tuesday, August 26, 2014

1

1.0

8

DDRVTT_A

D D

M_DA[0..63](5)

M_AAA[0..17](4)
M_DQSA[0..7](5)
M_-DQSA[0..7](5)

C C

VDDSPD SHORT PROTECT

VPP_25V_A VDDSPDA

B B

A A

M_DA[0..63]
M_AAA[0..17]
M_DQSA[0..7]
M

_-DQSA[0..7]

DDR4_4_DET DDR4_8_DET

DDR4_4_DET(15) DDR4_8_DET(16)

DDR_12V_A

VPP_25V_A

MAC11 1u/4/X5R/6.3V/K

8

MAC16 0.1u/4/X7R/16V/K

VDDSPDA

M_CH01_SDA(12)

M_CH01_SCL(12)

M_SBAA1(4)
M_SBAA0(4)
M_BG_A1(4)
M_BG_A0(4)

M_-DCLKA2(4)

M_DCLKA2(4)

M_-DCLKA0(4)

M_DCLKA0(4)

M_C2_A(4)
M_-CSA3(4)
M_-CSA2(4)
M_-CSA1(4)
M_-CSA0(4)

M_CKEA1(4)
M_CKEA0(4)

M_AAA[0..17](4)

M_VREF_DDRA

M_A0_SA2
M_A0_SA1
M_A0_SA0

M_AAA0
M_AAA1
M_AAA2
M_AAA3
M_AAA4
M_AAA5
M_AAA6
M_AAA7
M_AAA8
M_AAA9
M_AAA10
M_AAA11
M_AAA12
M_AAA13
M_AAA14
M_AAA15
M_AAA16
M_AAA17

7

DDR4_1_1A

77

VTT

221

VTT

2

VSS

4

VSS

6

VSS

9

VSS

11

VSS

13

VSS

15

VSS

17

VSS

20

VSS

22

VSS

24

VSS

26

VSS

28

VSS

31

VSS

33

VSS

35

VSS

37

VSS

39

VSS

42

VSS

44

VSS

46

VSS

48

VSS

50

VSS

53

VSS

55

VSS

57

VSS

94

VSS

96

VSS

98

VSS

101

VSS

103

VSS

105

VSS

107

VSS

109

VSS

112

VSS

114

VSS

116

VSS

118

VSS

120

VSS

123

VSS

125

VSS

127

VSS

129

VSS

131

VSS

134

VSS

136

VSS

138

VSS

147

VSS

149

VSS

151

VSS

154

VSS

156

VSS

158

VSS

160

VSS

DM1/DQS10_DBI1

162

VSS

165

VSS

167

VSS

DM2/DQS11_DBI2

169

VSS

171

VSS

173

VSS

DM3/DQS12_DBI3

176

VSS

178

VSS

180

DM4/DQS13_DBI4

VSS

182

VSS

184

VSS

187

DM5/DQS14_DBI5

VSS

189

VSS

191

VSS

193

DM6/DQS15_DBI6

VSS

195

VSS

198

VSS

200

DM7/DQS16_DBI7

VSS

202

VSS

239

VSS

241

DM8/DQS17_DBI8

VSS

243

VSS

246

VSS

248

VSS

250

VSS

252

VSS

254

VSS

257

VSS

259

VSS

261

VSS

263

VSS

265

VSS

268

VSS

270

VSS

272

VSS

274

VSS

276

VSS

279

VSS

281

VSS

283

VSS

59

VDD

61

VDD

64

VDD

67

VDD

70

VDD

73

VDD

76

VDD

80

VDD

83

VDD

85

VDD

88

VDD

90

VDD

92

VDD

204

VDD

206

VDD

209

VDD

212

VDD

215

VDD

217

VDD

220

VDD

223

VDD

226

VDD

229

VDD

231

VDD

233

VDD

236

VDD

142

VPP

143

VPP

286

VPP

287

VPP

288

VPP

1

12V3_NC

145

12V3_NC

146

VREFCA

284

VDDSPD

238

SA2_RFU

140

SA1

139

SA0

285

SDA

141

SCL

224

BA1

81

BA0

207

BG1

63

BG0

219

CK1/NU*

218

CK1/NU

75

CK0*

74

CK0

235

C_2_NC

237

S3_N_C

93

S2_N_C

89

S1_N

84

S0_N

203

CKE1

60

CKE0

79

A0

72

A1

216

A2

71

A3

214

A4

213

A5

69

A6

211

A7

68

A8

66

A9

225

A10/AP

210

A11

65

A12

232

A13

228

A14_WE*

86

A15_CAS*

82

A16_RAS*

234

A17_NC

DDR4_288P[11SM1-520288-52R]

󲾹󲾹󲾹󲾹󶁜󶁜󶁜󶁜󵓀󵓀󵓀󵓀󴿓󴿓󴿓󴿓󱓷󱓷󱓷󱓷󳽼󳽼󳽼󳽼󲆬󲆬󲆬󲆬󶁜󶁜󶁜󶁜

7

NC2_SAVE*1

PARITY
RESET*
EVENT*
ALERT*

CB0_NC
CB1_NC
CB2_NC
CB3_NC
CB4_NC
CB5_NC
CB6_NC
CB7_NC

DM0/DQS9_DBI0

NC/DQS9*

NC/DQS10*

NC/DQS11*

NC/DQS12*

NC/DQS13*

NC/DQS14*

NC/DQS15*

NC/DQS16*

NC/DQS17*

DQS0*

DQS1*

DQS2*

DQS3*

DQS4*

DQS5*

DQS6*

DQS7*

DQS8*

RFU
RFU
RFU

ODT1
ODT0

ACT*

DQS0

DQS1

DQS2

DQS3

DQS4

DQS5

DQS6

DQS7

DQS8

DQ0
DQ1
DQ2
DQ3
DQ4
DQ5
DQ6
DQ7
DQ8

DQ9
DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46
DQ47
DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63

227
205
144

230

M_ODT_A1

91

M_ODT_A0

87
222

58
78
208
62

49
194
56
201
47
192
54
199

M_DQSA0

153

M_-DQSA0

152

M_DQSA1

164

M_-DQSA1

163

M_DQSA2

175

M_-DQSA2

174

M_DQSA3

186

M_-DQSA3

185

M_DQSA4

245

M_-DQSA4

244

M_DQSA5

256

M_-DQSA5

255

M_DQSA6

267

M_-DQSA6

266

M_DQSA7

278

M_-DQSA7

277
197

196
7

8
18

19
29

30
40

41
99

100
110

111
121

122
132

133
51

52

M_DA0

5

M_DA1

150

M_DA2

12

M_DA3

157

M_DA4

3

M_DA5

148

M_DA6

10

M_DA7

155

M_DA8

16

M_DA9

161

M_DA10

23

M_DA11

168

M_DA12

14

M_DA13

159

M_DA14

21

M_DA15

166

M_DA16

27

M_DA17

172

M_DA18

34

M_DA19

179

M_DA20

25

M_DA21

170

M_DA22

32

M_DA23

177

M_DA24

38

M_DA25

183

M_DA26

45

M_DA27

190

M_DA28

36

M_DA29

181

M_DA30

43

M_DA31

188

M_DA32

97

M_DA33

242

M_DA34

104

M_DA35

249

M_DA36

95

M_DA37

240

M_DA38

102

M_DA39

247

M_DA40

108

M_DA41

253

M_DA42

115

M_DA43

260

M_DA44

106

M_DA45

251

M_DA46

113

M_DA47

258

M_DA48

119

M_DA49

264

M_DA50

126

M_DA51

271

M_DA52

117

M_DA53

262

M_DA54

124

M_DA55

269

M_DA56

130

M_DA57

275

M_DA58

137

M_DA59

282

M_DA60

128

M_DA61

273

M_DA62

135

M_DA63

280

CHANNEL A
SA2:0=000

DIP

M_ODT_A1 (4)
M_ODT_A0 (4)

M_DDR_PARA (4)
A_-M_RSTC01 (7,12)
A_-MHOT_C01 (7,12)
M_-ALERT_A (4)
M_-ACT_A (4)

MAR30/4/SHT/20/X
MAR40/4/SHT/20/X
MAR50/4/SHT/20/X

M_A0_SA0
M_A0_SA1
M_A0_SA2

6

6

DDRVTT_A

MAC42 0.1u/4/X7R/16V/K

MAC43 0.1u/4/X7R/16V/K

VDDSPDA

M_CH01_SDA(12)
M_CH01_SCL(12)

M_SBAA1(4)
M_SBAA0(4)
M_BG_A1(4)
M_BG_A0(4)

M_-DCLKA3(4)
M_DCLKA3(4)
M_-DCLKA1(4)
M_DCLKA1(4)

M_C2_A(4)
M_-CSA7(4)
M_-CSA6(4)
M_-CSA5(4)
M_-CSA4(4)

M_CKEA3(4)
M_CKEA2(4)

M_AAA[0..17](4)

5

DDR_12V_A

VPP_25V_A

5

M_VREF_DDRA

M_A1_SA2
M_A1_SA1
M_A1_SA0

M_AAA0
M_AAA1
M_AAA2
M_AAA3
M_AAA4
M_AAA5
M_AAA6
M_AAA7
M_AAA8
M_AAA9
M_AAA10
M_AAA11
M_AAA12
M_AAA13
M_AAA14
M_AAA15
M_AAA16
M_AAA17

DDR4_2_2A

77

VTT

221

VTT

2

VSS

4

VSS

6

VSS

9

VSS

11

VSS

13

VSS

15

VSS

17

VSS

20

VSS

22

VSS

24

VSS

26

VSS

28

VSS

31

VSS

33

VSS

35

VSS

37

VSS

39

VSS

42

VSS

44

VSS

46

VSS

48

VSS

50

VSS

53

VSS

55

VSS

57

VSS

94

VSS

96

VSS

98

VSS

101

VSS

103

VSS

105

VSS

107

VSS

109

VSS

112

VSS

114

VSS

116

VSS

118

VSS

120

VSS

123

VSS

125

VSS

127

VSS

129

VSS

131

VSS

134

VSS

136

VSS

138

VSS

147

VSS

149

VSS

151

VSS

154

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

59

VDD

61

VDD

64

VDD

67

VDD

70

VDD

73

VDD

76

VDD

80

VDD

83

VDD

85

VDD

88

VDD

90

VDD

92

VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD

VPP
VPP
VPP
VPP
VPP

1

12V3_NC
12V3_NC

VREFCA
VDDSPD

SA2_RFU
SA1
SA0
SDA
SCL

BA1

81

BA0
BG1

63

BG0
CK1/NU*

CK1/NU

75

CK0*

74

CK0
C_2_NC

S3_N_C

93

S2_N_C

89

S1_N

84

S0_N
CKE1

60

CKE0

79

A0

72

A1
A2

71

A3
A4
A5

69

A6
A7

68

A8

66

A9
A10/AP
A11

65

A12
A13
A14_WE*

86

A15_CAS*

82

A16_RAS*
A17_NC

DDR4_288P[11SM1-520288-42R]

DM0/DQS9_DBI0

DM1/DQS10_DBI1

DM2/DQS11_DBI2

DM3/DQS12_DBI3

DM4/DQS13_DBI4

DM5/DQS14_DBI5

DM6/DQS15_DBI6

DM7/DQS16_DBI7

DM8/DQS17_DBI8

156
158
160
162
165
167
169
171
173
176
178
180
182
184
187
189
191
193
195
198
200
202
239
241
243
246
248
250
252
254
257
259
261
263
265
268
270
272
274
276
279
281
283

204
206
209
212
215
217
220
223
226
229
231
233
236

142
143
286
287
288

145

146
284

238
140
139
285
141

224
207

219
218

235
237

203

216
214

213
211

225
210

232
228

234

󵸚󵸚󵸚󵸚󶁜󶁜󶁜󶁜󵓀󵓀󵓀󵓀󴿓󴿓󴿓󴿓󱓷󱓷󱓷󱓷󳽼󳽼󳽼󳽼󲆬󲆬󲆬󲆬󶁜󶁜󶁜󶁜

NC2_SAVE*1

PARITY
RESET*
EVENT*

ALERT*

CB0_NC
CB1_NC
CB2_NC
CB3_NC
CB4_NC
CB5_NC
CB6_NC
CB7_NC

DQS0*

DQS1*

DQS2*

DQS3*

DQS4*

DQS5*

DQS6*

DQS7*

DQS8*

NC/DQS9*

NC/DQS10*

NC/DQS11*

NC/DQS12*

NC/DQS13*

NC/DQS14*

NC/DQS15*

NC/DQS16*

NC/DQS17*

227

RFU

205

RFU

144

RFU

230
91

ODT1

87

ODT0

222
58
78
208
62

ACT*

49
194
56
201
47
192
54
199

153

DQS0

152
164

DQS1

163
175

DQS2

174
186

DQS3

185
245

DQS4

244
256

DQS5

255
267

DQS6

266
278

DQS7

277
197

DQS8

196
7

8
18

19
29

30
40

41
99

100
110

111
121

122
132

133
51

52

5

DQ0

150

DQ1

12

DQ2

157

DQ3

3

DQ4

148

DQ5

10

DQ6

155

DQ7

16

DQ8

161

DQ9

23

DQ10

168

DQ11

14

DQ12

159

DQ13

21

DQ14

166

DQ15

27

DQ16

172

DQ17

34

DQ18

179

DQ19

25

DQ20

170

DQ21

32

DQ22

177

DQ23

38

DQ24

183

DQ25

45

DQ26

190

DQ27

36

DQ28

181

DQ29

43

DQ30

188

DQ31

97

DQ32

242

DQ33

104

DQ34

249

DQ35

95

DQ36

240

DQ37

102

DQ38

247

DQ39

108

DQ40

253

DQ41

115

DQ42

260

DQ43

106

DQ44

251

DQ45

113

DQ46

258

DQ47

119

DQ48

264

DQ49

126

DQ50

271

DQ51

117

DQ52

262

DQ53

124

DQ54

269

DQ55

130

DQ56

275

DQ57

137

DQ58

282

DQ59

128

DQ60

273

DQ61

135

DQ62

280

DQ63

DIP

4

M_ODT_A3
M_ODT_A2

M_DDR_PARA (4)
A_-M_RSTC01 (7,12)
A_-MHOT_C01 (7,12)
M_-ALERT_A (4)
M_-ACT_A (4)

M_DQSA0
M_-DQSA0

M_DQSA1
M_-DQSA1

M_DQSA2
M_-DQSA2

M_DQSA3
M_-DQSA3

M_DQSA4
M_-DQSA4

M_DQSA5
M_-DQSA5

M_DQSA6
M_-DQSA6

M_DQSA7
M_-DQSA7

M_DA0
M_DA1
M_DA2
M_DA3
M_DA4
M_DA5
M_DA6
M_DA7
M_DA8
M_DA9
M_DA10
M_DA11
M_DA12
M_DA13
M_DA14
M_DA15
M_DA16
M_DA17
M_DA18
M_DA19
M_DA20
M_DA21
M_DA22
M_DA23
M_DA24
M_DA25
M_DA26
M_DA27
M_DA28
M_DA29
M_DA30
M_DA31
M_DA32
M_DA33
M_DA34
M_DA35
M_DA36
M_DA37
M_DA38
M_DA39
M_DA40
M_DA41
M_DA42
M_DA43
M_DA44
M_DA45
M_DA46
M_DA47
M_DA48
M_DA49
M_DA50
M_DA51
M_DA52
M_DA53
M_DA54
M_DA55
M_DA56
M_DA57
M_DA58
M_DA59
M_DA60
M_DA61
M_DA62
M_DA63

MAR950/4/SHT/20/X
MAR970/4/SHT/20/X

CHANNEL A
SA2:0=001

4

M_ODT_A3 (4)
M_ODT_A2 (4)

M_A1_SA0
M_A1_SA1
M_A1_SA2

MAR94 0/4/SHT/20/X

VPP_25V_A

3

2

MABC4

0.1u/4/X7R/16V/K

DDR_12V_A

MAR15
1K/4/1

M_VREF_DDRA

MAR16
1K/4/1

M_VREF_DDRA

M_VREF_DDRA

M_CHA_ADJ (37)

MAR170/4/SHT/20/X

MAR250/4/SHT/20/X

MAR70/4/SHT/20/X

1

To 3933

A_VREFDQ_C01 (4)

M_VREF_DDRB (12)

To CPU

DDR15V Decouple

DDR_12V_A

DDR_12V_A

DDR_12V_A

DDRVTT Decouple

DDRVTT_A

VCCIO

MABC33

1u/4/X5R/6.3V/K

A_CH01_SCL(7)

3

MAU1

1

VCCA

VCCB

2

A1

3

A2

4 5

GND EN

PCA9617ADPJ/TSSOP8/S

2

DDR_12V_A

MABC18

0.1u/4/X7R/16V/K
MABC15

0.1u/4/X7R/16V/K
MABC11

0.1u/4/X7R/16V/K

DDR_12V_A

MABC37
1u/4/X5R/6.3V/K

MABC34
1u/4/X5R/6.3V/K

MABC35
1u/4/X5R/6.3V/K

MABC17
1u/4/X5R/6.3V/K

DDR_12V_A

DDRVTT_A

MABC25

0.1u/4/X7R/16V/K

MABC23

0.1u/4/X7R/16V/K

MABC28

0.1u/4/X7R/16V/K

DDRVTT_A

VPP_25V_A

MABC27
1u/4/X5R/6.3V/K

8

7

M_CH01_SCL (12)

B1

6

M_CH01_SDA (12)A_CH01_SDA(7)

B2

MAR29 8.2K/4

Gigabyte Technology

Title

Size Document Number Rev

Custom

Date: Sheet o f

MABC38

0.1u/4/X7R/16V/K
MABC39

0.1u/4/X7R/16V/K
MASC3

0.1u/4/X7R/16V/K/X

MASC4

0.1u/4/X7R/16V/K
MASC1

0.1u/4/X7R/16V/K
MASC2

0.1u/4/X7R/16V/K

MABC10

22u/8/X5R/6.3V/M

1u/4/X5R/6.3V/K
MABC21

1u/4/X5R/6.3V/K
MABC8

DDR_12V_A

1u/4/X5R/6.3V/KMABC19
1u/4/X5R/6.3V/KMABC20

1u/4/X5R/6.3V/KMABC14
1u/4/X5R/6.3V/KMABC30

1u/4/X5R/6.3V/KMABC13
1u/4/X5R/6.3V/KMABC12
1u/4/X5R/6.3V/KMABC16

MABC9
22u/8/X5R/6.3V/M
MABC22
1u/4/X5R/6.3V/K

MABC24
1u/4/X5R/6.3V/K

MAEC5

1

+

560u/FP/D/6.3V/68/C/8m

VPP_25V_A

VPP_25V_A

DDRIII CHANNEL A/B

GA-X99-UD5 WIFI

1

MABC36

2.2u/6/X5R/6.3V/K

MAR28

1.4K/4/1

11 64

MAR27

1.4K/4/1

M_CH01_SCL

M_CH01_SDA

1.0

5

DDRVTT_A

D D

C C

DDR4_2_DET(15)

DDR_12V_A

B B

VPP_25V_A

MAC12

MAC15 0.1u/4/X7R/16V/K

VDDSPDA

A A

M_AAB[0..17](4)

0.1u/4/X7R/16V/K

M_CH01_SDA(11)

M_CH01_SCL(11)

M_SBAB1(4)

M_SBAB0(4)
M_BG_B1(4)
M_BG_B0(4)

M_-DCLKB2(4)

M_DCLKB2(4)

M_-DCLKB0(4)

M_DCLKB0(4)

M_C2_B(4)
M_-CSB3(4)
M_-CSB2(4)
M_-CSB1(4)
M_-CSB0(4)

M_CKEB1(4)
M_CKEB0(4)

M_VREF_DDRB

󲾹󲾹󲾹󲾹󶁜󶁜󶁜󶁜󵓀󵓀󵓀󵓀󴿓󴿓󴿓󴿓󱓷󱓷󱓷󱓷󳽼󳽼󳽼󳽼󲆬󲆬󲆬󲆬󶁜󶁜󶁜󶁜

5

DDR4_2_DET

M_B0_SA2
M_B0_SA1
M_B0_SA0

M_AAB0
M_AAB1
M_AAB2
M_AAB3
M_AAB4
M_AAB5
M_AAB6
M_AAB7
M_AAB8
M_AAB9
M_AAB10
M_AAB11
M_AAB12
M_AAB13
M_AAB14
M_AAB15
M_AAB16
M_AAB17

DDR4_3_1B

77

VTT

221

VTT

2

VSS

4

VSS

6

VSS

9

VSS

11

VSS

13

VSS

15

VSS

17

VSS

20

VSS

22

VSS

24

VSS

26

VSS

28

VSS

31

VSS

33

VSS

35

VSS

37

VSS

39

VSS

42

VSS

44

VSS

46

VSS

48

VSS

50

VSS

53

VSS

55

VSS

57

VSS

94

VSS

96

VSS

98

VSS

101

VSS

103

VSS

105

VSS

107

VSS

109

VSS

112

VSS

114

VSS

116

VSS

118

VSS

120

VSS

123

VSS

125

VSS

127

VSS

129

VSS

131

VSS

134

VSS

136

VSS

138

VSS

147

VSS

149

VSS

151

VSS

154

VSS

156

VSS

158

VSS

160

VSS

162

VSS

165

VSS

167

VSS

169

VSS

171

VSS

173

VSS

176

VSS

178

VSS

180

VSS

182

VSS

184

VSS

187

VSS

189

VSS

191

VSS

193

VSS

195

VSS

198

VSS

200

VSS

202

VSS

239

VSS

241

VSS

243

VSS

246

VSS

248

VSS

250

VSS

252

VSS

254

VSS

257

VSS

259

VSS

261

VSS

263

VSS

265

VSS

268

VSS

270

VSS

272

VSS

274

VSS

276

VSS

279

VSS

281

VSS

283

VSS

59

VDD

61

VDD

64

VDD

67

VDD

70

VDD

73

VDD

76

VDD

80

VDD

83

VDD

85

VDD

88

VDD

90

VDD

92

VDD

204

VDD

206

VDD

209

VDD

212

VDD

215

VDD

217

VDD

220

VDD

223

VDD

226

VDD

229

VDD

231

VDD

233

VDD

236

VDD

142

VPP

143

VPP

286

VPP

287

VPP

288

VPP

1

12V3_NC

145

12V3_NC

146

VREFCA

284

VDDSPD

238

SA2_RFU

140

SA1

139

SA0

285

SDA

141

SCL

224

BA1

81

BA0

207

BG1

63

BG0

219

CK1/NU*

218

CK1/NU

75

CK0*

74

CK0

235

C_2_NC

237

S3_N_C

93

S2_N_C

89

S1_N

84

S0_N

203

CKE1

60

CKE0

79

A0

72

A1

216

A2

71

A3

214

A4

213

A5

69

A6

211

A7

68

A8

66

A9

225

A10/AP

210

A11

65

A12

232

A13

228

A14_WE*

86

A15_CAS*

82

A16_RAS*

234

A17_NC

DDR4_288P[11SM1-520288-52R]

DIP

RFU
RFU
RFU

NC2_SAVE*1

ODT1
ODT0

PARITY
RESET*
EVENT*

ALERT*

ACT*

CB0_NC
CB1_NC
CB2_NC
CB3_NC
CB4_NC
CB5_NC
CB6_NC
CB7_NC

DQS0

DQS0*

DQS1

DQS1*

DQS2

DQS2*

DQS3

DQS3*

DQS4

DQS4*

DQS5

DQS5*

DQS6

DQS6*

DQS7

DQS7*

DQS8

DQS8*

DM0/DQS9_DBI0

NC/DQS9*

DM1/DQS10_DBI1

NC/DQS10*

DM2/DQS11_DBI2

NC/DQS11*

DM3/DQS12_DBI3

NC/DQS12*

DM4/DQS13_DBI4

NC/DQS13*

DM5/DQS14_DBI5

NC/DQS14*

DM6/DQS15_DBI6

NC/DQS15*

DM7/DQS16_DBI7

NC/DQS16*

DM8/DQS17_DBI8

NC/DQS17*

DQ0
DQ1
DQ2
DQ3
DQ4
DQ5
DQ6
DQ7
DQ8

DQ9
DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46
DQ47
DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63

CHANNEL B
SA2:0=100

227
205
144

230

M_ODT_B1

91

M_ODT_B0

87
222

M_DDR_PARB (4)

58

A_-M_RSTC01 (7,11)

78

A_-MHOT_C01 (7,11)

208

M_-ALERT_B (4)

62

M_-ACT_B (4)

49
194
56
201
47
192
54
199

M_DQSB0

153

M_-DQSB0

152

M_DQSB1

164

M_-DQSB1

163

M_DQSB2

175

M_-DQSB2

174

M_DQSB3

186

M_-DQSB3

185

M_DQSB4

245

M_-DQSB4

244

M_DQSB5

256

M_-DQSB5

255

M_DQSB6

267

M_-DQSB6

266

M_DQSB7

278

M_-DQSB7

277
197

196
7

8
18

19
29

30
40

41
99

100
110

111
121

122
132

133
51

52

M_DB0

5

M_DB1

150

M_DB2

12

M_DB3

157

M_DB4

3

M_DB5

148

M_DB6

10

M_DB7

155

M_DB8

16

M_DB9

161

M_DB10

23

M_DB11

168

M_DB12

14

M_DB13

159

M_DB14

21

M_DB15

166

M_DB16

27

M_DB17

172

M_DB18

34

M_DB19

179

M_DB20

25

M_DB21

170

M_DB22

32

M_DB23

177

M_DB24

38

M_DB25

183

M_DB26

45

M_DB27

190

M_DB28

36

M_DB29

181

M_DB30

43

M_DB31

188

M_DB32

97

M_DB33

242

M_DB34

104

M_DB35

249

M_DB36

95

M_DB37

240

M_DB38

102

M_DB39

247

M_DB40

108

M_DB41

253

M_DB42

115

M_DB43

260

M_DB44

106

M_DB45

251

M_DB46

113

M_DB47

258

M_DB48

119

M_DB49

264

M_DB50

126

M_DB51

271

M_DB52

117

M_DB53

262

M_DB54

124

M_DB55

269

M_DB56

130

M_DB57

275

M_DB58

137

M_DB59

282

M_DB60

128

M_DB61

273

M_DB62

135

M_DB63

280

M_ODT_B1 (4)
M_ODT_B0 (4)

M_B0_SA0

MAR100/4/SHT/20/X

M_B0_SA1

MAR110/4/SHT/20/X

M_B0_SA2

4

MAR21 0/4/SHT/20/X

4

VPP_25V_A

DDR4_6_DET(15)

MAC44 1u/4/X5R/6.3V/K

MAC45 0.1u/4/X7R/16V/K

VDDSPDA

M_AAB[0..17](4)

M_CH01_SDA(11)
M_CH01_SCL(11)

M_SBAB1(4)

M_SBAB0(4)
M_BG_B1(4)
M_BG_B0(4)

M_-DCLKB3(4)

M_DCLKB3(4)

M_-DCLKB1(4)

M_DCLKB1(4)

M_C2_B(4)

M_-CSB7(4)

M_-CSB6(4)

M_-CSB5(4)

M_-CSB4(4)

M_CKEB3(4)

M_CKEB2(4)

DDRVTT_A

DDR4_6_DET

DDR_12V_A

VPP_25V_A

M_VREF_DDRB

DDR4_4_2B

77

VTT

221

VTT

2

VSS

4

VSS

6

VSS

9

VSS

11

VSS

13

VSS

15

VSS

17

VSS

20

VSS

22

VSS

24

VSS

26

VSS

28

VSS

31

VSS

33

VSS

35

VSS

37

VSS

39

VSS

42

VSS

44

VSS

46

VSS

48

VSS

50

VSS

53

VSS

55

VSS

57

VSS

94

VSS

96

VSS

98

VSS

101

VSS

103

VSS

105

VSS

107

VSS

109

VSS

112

VSS

114

VSS

116

VSS

118

VSS

120

VSS

123

VSS

125

VSS

127

VSS

129

VSS

131

VSS

134

VSS

136

VSS

138

VSS

147

VSS

149

VSS

151

VSS

154

VSS

156

VSS

158

VSS

160

VSS

162

VSS

165

VSS

167

VSS

169

VSS

171

VSS

173

VSS

176

VSS

178

VSS

180

VSS

182

VSS

184

VSS

187

VSS

189

VSS

191

VSS

193

VSS

195

VSS

198

VSS

200

VSS

202

VSS

239

VSS

241

VSS

243

VSS

246

VSS

248

VSS

250

VSS

252

VSS

254

VSS

257

VSS

259

VSS

261

VSS

263

VSS

265

VSS

268

VSS

270

VSS

272

VSS

274

VSS

276

VSS

279

VSS

281

VSS

283

VSS

59

VDD

61

VDD

64

VDD

67

VDD

70

VDD

73

VDD

76

VDD

80

VDD

83

VDD

85

VDD

88

VDD

90

VDD

92

VDD

204

VDD

206

VDD

209

VDD

212

VDD

215

VDD

217

VDD

220

VDD

223

VDD

226

VDD

229

VDD

231

VDD

233

VDD

236

VDD

142

VPP

143

VPP

286

VPP

287

VPP

288

VPP

1

12V3_NC

145

12V3_NC

146

VREFCA

284

VDDSPD

M_B1_SA2

238

SA2_RFU

M_B1_SA1

140

SA1

M_B1_SA0

139

SA0

285

SDA

141

SCL

224

BA1

81

BA0

207

BG1

63

BG0

219

CK1/NU*

218

CK1/NU

75

CK0*

74

CK0

235

C_2_NC

237

S3_N_C

93

S2_N_C

89

S1_N

84

S0_N

203

CKE1

60

CKE0

M_AAB0

79

A0

M_AAB1

72

A1

M_AAB2

216

A2

M_AAB3

71

A3

M_AAB4

214

A4

M_AAB5

213

A5

M_AAB6

69

A6

M_AAB7

211

A7

M_AAB8

68

A8

M_AAB9

66

A9

M_AAB10

225

A10/AP

M_AAB11

210

A11

M_AAB12

65

A12

M_AAB13

232

A13

M_AAB14

228

A14_WE*

M_AAB15

86

A15_CAS*

M_AAB16

82

A16_RAS*

M_AAB17

234

A17_NC

DDR4_288P[11SM1-520288-42R]

󵸚󵸚󵸚󵸚󶁜󶁜󶁜󶁜󵓀󵓀󵓀󵓀󴿓󴿓󴿓󴿓󱓷󱓷󱓷󱓷󳽼󳽼󳽼󳽼󲆬󲆬󲆬󲆬󶁜󶁜󶁜󶁜

3

NC2_SAVE*1

PARITY

RESET*

EVENT*
ALERT*

CB0_NC
CB1_NC
CB2_NC
CB3_NC
CB4_NC
CB5_NC
CB6_NC
CB7_NC

DQS0*

DQS1*

DQS2*

DQS3*

DQS4*

DQS5*

DQS6*

DQS7*

DQS8*

DM0/DQS9_DBI0

NC/DQS9*

DM1/DQS10_DBI1

NC/DQS10*

DM2/DQS11_DBI2

NC/DQS11*

DM3/DQS12_DBI3

NC/DQS12*

DM4/DQS13_DBI4

NC/DQS13*

DM5/DQS14_DBI5

NC/DQS14*

DM6/DQS15_DBI6

NC/DQS15*

DM7/DQS16_DBI7

NC/DQS16*

DM8/DQS17_DBI8

NC/DQS17*

DIP

3

227

RFU

205

RFU

144

RFU

230
91

ODT1

87

ODT0

222
58
78
208
62

ACT*

49
194
56
201
47
192
54
199

153

DQS0

152
164

DQS1

163
175

DQS2

174
186

DQS3

185
245

DQS4

244
256

DQS5

255
267

DQS6

266
278

DQS7

277
197

DQS8

196
7

8
18

19
29

30
40

41
99

100
110

111
121

122
132

133
51

52

5

DQ0

150

DQ1

12

DQ2

157

DQ3

3

DQ4

148

DQ5

10

DQ6

155

DQ7

16

DQ8

161

DQ9

23

DQ10

168

DQ11

14

DQ12

159

DQ13

21

DQ14

166

DQ15

27

DQ16

172

DQ17

34

DQ18

179

DQ19

25

DQ20

170

DQ21

32

DQ22

177

DQ23

38

DQ24

183

DQ25

45

DQ26

190

DQ27

36

DQ28

181

DQ29

43

DQ30

188

DQ31

97

DQ32

242

DQ33

104

DQ34

249

DQ35

95

DQ36

240

DQ37

102

DQ38

247

DQ39

108

DQ40

253

DQ41

115

DQ42

260

DQ43

106

DQ44

251

DQ45

113

DQ46

258

DQ47

119

DQ48

264

DQ49

126

DQ50

271

DQ51

117

DQ52

262

DQ53

124

DQ54

269

DQ55

130

DQ56

275

DQ57

137

DQ58

282

DQ59

128

DQ60

273

DQ61

135

DQ62

280

DQ63

M_ODT_B3
M_ODT_B2

A_-M_RSTC01 (7,11)
A_-MHOT_C01 (7,11)
M_-ALERT_B (4)
M_-ACT_B (4)

M_DQSB0
M_-DQSB0

M_DQSB1
M_-DQSB1

M_DQSB2
M_-DQSB2

M_DQSB3
M_-DQSB3

M_DQSB4
M_-DQSB4

M_DQSB5
M_-DQSB5

M_DQSB6
M_-DQSB6

M_DQSB7
M_-DQSB7

M_DB0
M_DB1
M_DB2
M_DB3
M_DB4
M_DB5
M_DB6
M_DB7
M_DB8
M_DB9
M_DB10
M_DB11
M_DB12
M_DB13
M_DB14
M_DB15
M_DB16
M_DB17
M_DB18
M_DB19
M_DB20
M_DB21
M_DB22
M_DB23
M_DB24
M_DB25
M_DB26
M_DB27
M_DB28
M_DB29
M_DB30
M_DB31
M_DB32
M_DB33
M_DB34
M_DB35
M_DB36
M_DB37
M_DB38
M_DB39
M_DB40
M_DB41
M_DB42
M_DB43
M_DB44
M_DB45
M_DB46
M_DB47
M_DB48
M_DB49
M_DB50
M_DB51
M_DB52
M_DB53
M_DB54
M_DB55
M_DB56
M_DB57
M_DB58
M_DB59
M_DB60
M_DB61
M_DB62
M_DB63

CHANNEL B
SA2:0=101

M_ODT_B3 (4)
M_ODT_B2 (4)

M_DDR_PARB (4)

MAR101 0/4/SHT/20/X

M_B1_SA0
M_B1_SA1
M_B1_SA2

MAR100 0/4/SHT/20/X
MAR104 0/4/SHT/20/X

2

VPP_25V_A
VPP_25V_A

2

1

DDR_12V_A

MAR20

MABC31

0.1u/4/X7R/16V/K

Title

Size Document Number Rev

Custom

Date: Sheet o f

1K/4/1/X

M_VREF_DDRB

MAR19
1K/4/1/X

A_-M_RSTC01

MAC13

100p/4/NPO/50V/J

M_DB[0..63]

M_DB[0..63](5)

M_AAB[0..17](4)

M_DQSB[0..7](5)

M_-DQSB[0..7](5)

M_AAB[0..17]
M_DQSB[0..7]
M_-DQSB[0..7]

Gigabyte Technology

DDRIII CHANNEL A/B

GA-X99-UD5 WIFI

1

M_VREF_DDRB (11)

12 64

1.0

8

DDR4_5_1C

77

DDRVTT_B

D D

C C

VDDSPD SHORT PROTECT

VPP_25V_B VDDSPDB

DDR4_3_DET(16) DDR4_7_DET(16)

DDR_12V_B

1u/4/X5R/6.3V/K

MBC6

MBC2 0.1u/4/X7R/16V/K

VDDSPDB

M_CH23_SDA(14)

M_CH23_SCL(14)

M_SBAC1(4)
M_SBAC0(4)
M_BG_C1(4)
M_BG_C0(4)

M_-DCLKC2(4)

M_DCLKC2(4)

M_-DCLKC0(4)

M_DCLKC0(4)

M_C2_C(4)
M_-CSC3(4)
M_-CSC2(4)
M_-CSC1(4)
M_-CSC0(4)

M_CKEC1(4)
M_CKEC0(4)

M_AAC[0..17](4)

󲾹󲾹󲾹󲾹󶁜󶁜󶁜󶁜󳜶󳜶󳜶󳜶󴿓󴿓󴿓󴿓󱓷󱓷󱓷󱓷󳽼󳽼󳽼󳽼󲆬󲆬󲆬󲆬󶁜󶁜󶁜󶁜

8

M_DC[0..63]
M_AAC[0..17]
M_DQSC[0..7]
M_-DQSC[0..7]

VPP_25V_B

M_VREF_DDRC

M_DC[0..63](6)

M_AAC[0..17](4)
M_DQSC[0..7](6)
M_-DQSC[0..7](6)

B B

A A

VTT

221

VTT

2

VSS

4

VSS

6

VSS

9

VSS

11

VSS

13

VSS

15

VSS

17

VSS

20

VSS

22

VSS

24

VSS

26

VSS

28

VSS

31

VSS

33

VSS

35

VSS

37

VSS

39

VSS

42

VSS

44

VSS

46

VSS

48

VSS

50

VSS

53

VSS

55

VSS

57

VSS

94

VSS

96

VSS

98

VSS

101

VSS

103

VSS

105

VSS

107

VSS

109

VSS

112

VSS

114

VSS

116

VSS

118

VSS

120

VSS

123

VSS

125

VSS

127

VSS

129

VSS

131

VSS

134

VSS

136

VSS

138

VSS

147

VSS

149

VSS

151

VSS

154

VSS

156

VSS

158

VSS

160

VSS

162

VSS

165

VSS

167

VSS

169

VSS

171

VSS

173

VSS

176

VSS

178

VSS

180

VSS

182

VSS

184

VSS

187

VSS

189

VSS

191

VSS

193

VSS

195

VSS

198

VSS

200

VSS

202

VSS

239

VSS

241

VSS

243

VSS

246

VSS

248

VSS

250

VSS

252

VSS

254

VSS

257

VSS

259

VSS

261

VSS

263

VSS

265

VSS

268

VSS

270

VSS

272

VSS

274

VSS

276

VSS

279

VSS

281

VSS

DDR4_3_DET DDR4_7_DET

283

VSS

59

VDD

61

VDD

64

VDD

67

VDD

70

VDD

73

VDD

76

VDD

80

VDD

83

VDD

85

VDD

88

VDD

90

VDD

92

VDD

204

VDD

206

VDD

209

VDD

212

VDD

215

VDD

217

VDD

220

VDD

223

VDD

226

VDD

229

VDD

231

VDD

233

VDD

236

VDD

142

VPP

143

VPP

286

VPP

287

VPP

288

VPP

1

12V3_NC

145

12V3_NC

146

VREFCA

284

VDDSPD

M_C0_SA2

238

SA2_RFU

M_C0_SA1

140

SA1

M_C0_SA0

139

SA0

285

SDA

141

SCL

224

BA1

81

BA0

207

BG1

63

BG0

219

CK1/NU*

218

CK1/NU

75

CK0*

74

CK0

235

C_2_NC

237

S3_N_C

93

S2_N_C

89

S1_N

84

S0_N

203

CKE1

60

CKE0

M_AAC0

79

A0

M_AAC1

72

A1

M_AAC2

216

A2

M_AAC3

71

A3

M_AAC4

214

A4

M_AAC5

213

A5

M_AAC6

69

A6

M_AAC7

211

A7

M_AAC8

68

A8

M_AAC9

66

A9

M_AAC10

225

A10/AP

M_AAC11

210

A11

M_AAC12

65

A12

M_AAC13

232

A13

M_AAC14

228

A14_WE*

M_AAC15

86

A15_CAS*

M_AAC16

82

A16_RAS*

M_AAC17

234

A17_NC

DDR4_288P[11SM1-520288-32R]

DIP

7

RFU
RFU
RFU

NC2_SAVE*1

ODT1
ODT0

PARITY
RESET*
EVENT*
ALERT*

ACT*

CB0_NC
CB1_NC
CB2_NC
CB3_NC
CB4_NC
CB5_NC
CB6_NC
CB7_NC

DQS0

DQS0*

DQS1

DQS1*

DQS2

DQS2*

DQS3

DQS3*

DQS4

DQS4*

DQS5

DQS5*

DQS6

DQS6*

DQS7

DQS7*

DQS8

DQS8*

DM0/DQS9_DBI0

NC/DQS9*

DM1/DQS10_DBI1

NC/DQS10*

DM2/DQS11_DBI2

NC/DQS11*

DM3/DQS12_DBI3

NC/DQS12*

DM4/DQS13_DBI4

NC/DQS13*

DM5/DQS14_DBI5

NC/DQS14*

DM6/DQS15_DBI6

NC/DQS15*

DM7/DQS16_DBI7

NC/DQS16*

DM8/DQS17_DBI8

NC/DQS17*

DQ0
DQ1
DQ2
DQ3
DQ4
DQ5
DQ6
DQ7
DQ8

DQ9
DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46
DQ47
DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63

CHANNEL C
SA2:0=000

7

6

227
205
144

230

M_ODT_C1

91
87

222
58
78
208
62

49
194
56
201
47
192
54
199

153
152

164
163

175
174

186
185

245
244

256
255

267
266

278
277

197
196

7
8

18
19

29
30

40
41

99
100

110
111

121
122

132
133

51
52

5
150
12
157
3
148
10
155
16
161
23
168
14
159
21
166
27
172
34
179
25
170
32
177
38
183
45
190
36
181
43
188
97
242
104
249
95
240
102
247
108
253
115
260
106
251
113
258
119
264
126
271
117
262
124
269
130
275
137
282
128
273
135
280

M_ODT_C0

M_DQSC0
M_-DQSC0

M_DQSC1
M_-DQSC1

M_DQSC2
M_-DQSC2

M_DQSC3
M_-DQSC3

M_DQSC4
M_-DQSC4

M_DQSC5
M_-DQSC5

M_DQSC6
M_-DQSC6

M_DQSC7
M

_-DQSC7

M_DC0
M_DC1
M_DC2
M_DC3
M_DC4
M_DC5
M_DC6
M_DC7
M_DC8
M_DC9
M_DC10
M_DC11
M_DC12
M_DC13
M_DC14
M_DC15
M_DC16
M_DC17
M_DC18
M_DC19
M_DC20
M_DC21
M_DC22
M_DC23
M_DC24
M_DC25
M_DC26
M_DC27
M_DC28
M_DC29
M_DC30
M_DC31
M_DC32
M_DC33
M_DC34
M_DC35
M_DC36
M_DC37
M_DC38
M_DC39
M_DC40
M_DC41
M_DC42
M_DC43
M_DC44
M_DC45
M_DC46
M_DC47
M_DC48
M_DC49
M_DC50
M_DC51
M_DC52
M_DC53
M_DC54
M_DC55
M_DC56
M_DC57
M_DC58
M_DC59
M_DC60
M_DC61
M_DC62
M_DC63

M_ODT_C1 (4)
M_ODT_C0 (4)

M_DDR_PARC (4)
A_-M_RSTC23 (7,14)
A_-MHOT_C23 (7,14)
M_-ALERT_C (4)
M_-ACT_C (4)

MBR30/4/SHT/20/X

M_C0_SA0

MBR40/4/SHT/20/X

M_C0_SA1

MBR50/4/SHT/20/X

M_C0_SA2

6

5

0.1u/4/X7R/16V/K

MBC42 0.1u/4/X7R/16V/K

VDDSPDB

M_CH23_SDA(14)

M_CH23_SCL(14)

M_-DCLKC3(4)
M_DCLKC3(4)
M_-DCLKC1(4)
M_DCLKC1(4)

M_AAC[0..17](4)

5

DDR4_6_2C

77

DDRVTT_B

DDR_12V_B

VPP_25V_B

MBC41

M_VREF_DDRC

M_SBAC1(4)
M_SBAC0(4)
M_BG_C1(4)
M_BG_C0(4)

M_C2_C(4)
M_-CSC7(4)
M_-CSC6(4)
M_-CSC5(4)
M_-CSC4(4)

M_CKEC3(4)
M_CKEC2(4)

DDR4_288P[11SM1-520288-22R]

󵸚󵸚󵸚󵸚󶁜󶁜󶁜󶁜󳜶󳜶󳜶󳜶󴿓󴿓󴿓󴿓󱓷󱓷󱓷󱓷󳽼󳽼󳽼󳽼󲆬󲆬󲆬󲆬󶁜󶁜󶁜󶁜

VTT

221

VTT

2

VSS

4

VSS

6

VSS

9

VSS

11

VSS

13

VSS

15

VSS

17

VSS

20

VSS

22

VSS

24

VSS

26

VSS

28

VSS

31

VSS

33

VSS

35

VSS

37

VSS

39

VSS

42

VSS

44

VSS

46

VSS

48

VSS

50

VSS

53

VSS

55

VSS

57

VSS

94

VSS

96

VSS

98

VSS

101

VSS

103

VSS

105

VSS

107

VSS

109

VSS

112

VSS

114

VSS

116

VSS

118

VSS

120

VSS

123

VSS

125

VSS

127

VSS

129

VSS

131

VSS

134

VSS

136

VSS

138

VSS

147

VSS

149

VSS

151

VSS

154

VSS

156

VSS

158

VSS

160

VSS

162

VSS

165

VSS

167

VSS

169

VSS

171

VSS

173

VSS

176

VSS

178

VSS

180

VSS

182

VSS

184

VSS

187

VSS

189

VSS

191

VSS

193

VSS

195

VSS

198

VSS

200

VSS

202

VSS

239

VSS

241

VSS

243

VSS

246

VSS

248

VSS

250

VSS

252

VSS

254

VSS

257

VSS

259

VSS

261

VSS

263

VSS

265

VSS

268

VSS

270

VSS

272

VSS

274

VSS

276

VSS

279

VSS

281

VSS

283

VSS

59

VDD

61

VDD

64

VDD

67

VDD

70

VDD

73

VDD

76

VDD

80

VDD

83

VDD

85

VDD

88

VDD

90

VDD

92

VDD

204

VDD

206

VDD

209

VDD

212

VDD

215

VDD

217

VDD

220

VDD

223

VDD

226

VDD

229

VDD

231

VDD

233

VDD

236

VDD

142

VPP

143

VPP

286

VPP

287

VPP

288

VPP

1

12V3_NC

145

12V3_NC

146

VREFCA

284

VDDSPD

M_C1_SA2

238

SA2_RFU

M_C1_SA1

140

SA1

M_C1_SA0 M_DC55

139

SA0

285

SDA

141

SCL

224

BA1

81

BA0

207

BG1

63

BG0

219

CK1/NU*

218

CK1/NU

75

CK0*

74

CK0

235

C_2_NC

237

S3_N_C

93

S2_N_C

89

S1_N

84

S0_N

203

CKE1

60

CKE0

M_AAC0

79

A0

M_AAC1

72

A1

M_AAC2

216

A2

M_AAC3

71

A3

M_AAC4

214

A4

M_AAC5

213

A5

M_AAC6

69

A6

M_AAC7

211

A7

M_AAC8

68

A8

M_AAC9

66

A9

M_AAC10

225

A10/AP

M_AAC11

210

A11

M_AAC12

65

A12

M_AAC13

232

A13

M_AAC14

228

A14_WE*

M_AAC15

86

A15_CAS*

M_AAC16

82

A16_RAS*

M_AAC17

234

A17_NC

DIP

4

RFU
RFU
RFU

NC2_SAVE*1

ODT1
ODT0

PARITY
RESET*
EVENT*

ALERT*

ACT*

CB0_NC
CB1_NC
CB2_NC
CB3_NC
CB4_NC
CB5_NC
CB6_NC
CB7_NC

DQS0

DQS0*

DQS1

DQS1*

DQS2

DQS2*

DQS3

DQS3*

DQS4

DQS4*

DQS5

DQS5*

DQS6

DQS6*

DQS7

DQS7*

DQS8

DQS8*

DM0/DQS9_DBI0

NC/DQS9*

DM1/DQS10_DBI1

NC/DQS10*

DM2/DQS11_DBI2

NC/DQS11*

DM3/DQS12_DBI3

NC/DQS12*

DM4/DQS13_DBI4

NC/DQS13*

DM5/DQS14_DBI5

NC/DQS14*

DM6/DQS15_DBI6

NC/DQS15*

DM7/DQS16_DBI7

NC/DQS16*

DM8/DQS17_DBI8

NC/DQS17*

DQ0
DQ1
DQ2
DQ3
DQ4
DQ5
DQ6
DQ7
DQ8

DQ9
DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46
DQ47
DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63

CHANNEL C

SA2:0=001

4

3

227
205
144

230

M_ODT_C3

91
87

222
58
78
208
62

49
194
56
201
47
192
54
199

153
152

164
163

175
174

186
185

245
244

256
255

267
266

278
277

197
196

7
8

18
19

29
30

40
41

99
100

110
111

121
122

132
133

51
52

5
150
12
157
3
148
10
155
16
161
23
168
14
159
21
166
27
172
34
179
25
170
32
177
38
183
45
190
36
181
43
188
97
242
104
249
95
240
102
247
108
253
115
260
106
251
113
258
119
264
126
271
117
262
124
269
130
275
137
282
128
273
135
280

M_ODT_C2

M_DQSC0
M_-DQSC0

M_DQSC1
M_-DQSC1

M_DQSC2
M_-DQSC2

M_DQSC3
M_-DQSC3

M_DQSC4
M_-DQSC4

M_DQSC5
M_-DQSC5

M_DQSC6
M_-DQSC6

M_DQSC7
M_-DQSC7

M_DC0
M_DC1
M_DC2
M_DC3
M_DC4
M_DC5
M_DC6
M_DC7
M_DC8
M_DC9
M_DC10
M_DC11
M_DC12
M_DC13
M_DC14
M_DC15
M_DC16
M_DC17
M_DC18
M_DC19
M_DC20
M_DC21
M_DC22
M_DC23
M_DC24
M_DC25
M_DC26
M_DC27
M_DC28
M_DC29
M_DC30
M_DC31
M_DC32
M_DC33
M_DC34
M_DC35
M_DC36
M_DC37
M_DC38
M_DC39
M_DC40
M_DC41
M_DC42
M_DC43
M_DC44
M_DC45
M_DC46
M_DC47
M_DC48
M_DC49
M_DC50
M_DC51
M_DC52
M_DC53
M_DC54

M_DC56
M_DC57
M_DC58
M_DC59
M_DC60
M_DC61
M_DC62
M_DC63

M_ODT_C3 (4)
M_ODT_C2 (4)

M_DDR_PARC (4)
A_-M_RSTC23 (7,14)
A_-MHOT_C23 (7,14)
M_-ALERT_C (4)
M_-ACT_C (4)

M_C1_SA0

MBR4190/4/SHT/20/X

M_C1_SA1

MBR4210/4/SHT/20/X

M_C1_SA2

MBBC1

1u/4/X5R/6.3V/K

A_CH23_SCL(7)

A_CH23_SDA(7)

MBR4180/4/SHT/20/X

VPP_25V_B

3

2

0.1u/4/X7R/16V/K

DDR12V Decouple

DDR_12V_B

DDR_12V_B

DDR_12V_B

DDR_12V_B

MBEC1 560u/FP/D/6.3V/68/C/8m

MBEC2 560u/FP/D/6.3V/68/C/8m

DDRVTT Decouple

DDRVTT_B

DDRVTT_B

VCCIO

MBU1

1

VCCA

2

A1

3

A2

4 5

GND EN

PCA9617ADPJ/TSSOP8/S

2

DDR_12V_B

MBR17
1K/4/1MBBC24

M_VREF_DDRC

MBR16
1K/4/1

M_VREF_DDRC

M_VREF_DDRC

MBBC38
1u/4/X5R/6.3V/K
MBSC3

0.1u/4/X7R/16V/K/X
MBBC39

0.1u/4/X7R/16V/K

MBSC4

0.1u/4/X7R/16V/K
MBSC2

0.1u/4/X7R/16V/K
MBSC1

1u/4/X5R/6.3V/K

MBBC26
1u/4/X5R/6.3V/K

MBBC21
1u/4/X5R/6.3V/K

MBBC13

2.2u/6/X5R/6.3V/K

1

+

1

+

MBBC12

0.1u/4/X7R/16V/K
MBBC27

0.1u/4/X7R/16V/K
MBBC11

0.1u/4/X7R/16V/K

MBEC5 560u/FP/D/6.3V/68/C/8m

1

+

8

VCCB

7

B1

6

B2

Title

Size Document Number Rev

Date: Sheet o f

VPP_25V_B

Custom

DDRVTT_B

MBBC2
1u/4/X5R/6.3V/K

M_CH23_SCL (14)

M_CH23_SDA (14)

MBR29 8.2K/4

MBR70/4/SHT/20/X

MBR250/4/SHT/20/X

Gigabyte Technology

1

M_CHC_ADJ (37)

MBR150/4/SHT/20/X

M_VREF_DDRD (14)

A_VREFDQ_C23 (4)

DDR_12V_B

DDR_12V_B

DDR_12V_B

DDR_12V_B

VPP_25V_B

1u/4/X5R/6.3V/KMBBC4

0.1u/4/X7R/16V/KMBBC9
1u/4/X5R/6.3V/KMBBC23

0.1u/4/X7R/16V/KMBBC5
1u/4/X5R/6.3V/KMBBC20

0.1u/4/X7R/16V/KMBBC15
1u/4/X5R/6.3V/KMBBC16

MBBC29
22u/8/X5R/6.3V/M

MBBC30
1u/4/X5R/6.3V/K

MBBC3
1u/4/X5R/6.3V/K

VPP_25V_B

MBBC14
1u/4/X5R/6.3V/K

MBBC18
1u/4/X5R/6.3V/K

MBBC7
1u/4/X5R/6.3V/K

MBBC8

0.1u/4/X7R/16V/K
MBBC10

0.1u/4/X7R/16V/K

MBBC6
1u/4/X5R/6.3V/K

MBBC17
1u/4/X5R/6.3V/K

MBR28

1.4K/4/1

DDRIII CHANNEL C/D

GA-X99-UD5 WIFI

13 64

1

To 3933

To CPU

1.4K/4/1

M_CH23_SCL

M_CH23_SDA

MBR27

1.0

5

DDRVTT_B

D D

C C

DDR4_1_DET

DDR4_1_DET(15)

DDR_12V_B

B B

VPP_25V_B

MBC4 0.1u/4/X7R/16V/K

MBC5 0.1u/4/X7R/16V/K

VDDSPDB

A A

M_AAD[0..17](4)

M_VREF_DDRD

M_CH23_SDA(13)
M_CH23_SCL(13)

M_SBAD1(4)
M_SBAD0(4)
M_BG_D1(4)
M_BG_D0(4)

M_-DCLKD2(4)

M_DCLKD2(4)

M_-DCLKD0(4)

M_DCLKD0(4)

M_C2_D(4)
M_-CSD3(4)
M_-CSD2(4)
M_-CSD1(4)
M_-CSD0(4)

M_CKED1(4)
M_CKED0(4)

󲾹󲾹󲾹󲾹󶁜󶁜󶁜󶁜󳜶󳜶󳜶󳜶󴿓󴿓󴿓󴿓󱓷󱓷󱓷󱓷󳽼󳽼󳽼󳽼󲆬󲆬󲆬󲆬󶁜󶁜󶁜󶁜

5

M_D0_SA2
M_D0_SA1
M_D0_SA0

M_AAD0
M_AAD1
M_AAD2
M_AAD3
M_AAD4
M_AAD5
M_AAD6
M_AAD7
M_AAD8
M_AAD9
M_AAD10
M_AAD11
M_AAD12
M_AAD13
M_AAD14
M_AAD15
M_AAD16
M_AAD17

DDR4_7_1D

77

VTT

221

VTT

2

VSS

4

VSS

6

VSS

9

VSS

11

VSS

13

VSS

15

VSS

17

VSS

20

VSS

22

VSS

24

VSS

26

VSS

28

VSS

31

VSS

33

VSS

35

VSS

37

VSS

39

VSS

42

VSS

44

VSS

46

VSS

48

VSS

50

VSS

53

VSS

55

VSS

57

VSS

94

VSS

96

VSS

98

VSS

101

VSS

103

VSS

105

VSS

107

VSS

109

VSS

112

VSS

114

VSS

116

VSS

118

VSS

120

VSS

123

VSS

125

VSS

127

VSS

129

VSS

131

VSS

134

VSS

136

VSS

138

VSS

147

VSS

149

VSS

151

VSS

154

VSS

156

VSS

158

VSS

160

VSS

162

VSS

165

VSS

167

VSS

169

VSS

171

VSS

173

VSS

176

VSS

178

VSS

180

VSS

182

VSS

184

VSS

187

VSS

189

VSS

191

VSS

193

VSS

195

VSS

198

VSS

200

VSS

202

VSS

239

VSS

241

VSS

243

VSS

246

VSS

248

VSS

250

VSS

252

VSS

254

VSS

257

VSS

259

VSS

261

VSS

263

VSS

265

VSS

268

VSS

270

VSS

272

VSS

274

VSS

276

VSS

279

VSS

281

VSS

283

VSS

59

VDD

61

VDD

64

VDD

67

VDD

70

VDD

73

VDD

76

VDD

80

VDD

83

VDD

85

VDD

88

VDD

90

VDD

92

VDD

204

VDD

206

VDD

209

VDD

212

VDD

215

VDD

217

VDD

220

VDD

223

VDD

226

VDD

229

VDD

231

VDD

233

VDD

236

VDD

142

VPP

143

VPP

286

VPP

287

VPP

288

VPP

1

12V3_NC

145

12V3_NC

146

VREFCA

284

VDDSPD

238

SA2_RFU

140

SA1

139

SA0

285

SDA

141

SCL

224

BA1

81

BA0

207

BG1

63

BG0

219

CK1/NU*

218

CK1/NU

75

CK0*

74

CK0

235

C_2_NC

237

S3_N_C

93

S2_N_C

89

S1_N

84

S0_N

203

CKE1

60

CKE0

79

A0

72

A1

216

A2

71

A3

214

A4

213

A5

69

A6

211

A7

68

A8

66

A9

225

A10/AP

210

A11

65

A12

232

A13

228

A14_WE*

86

A15_CAS*

82

A16_RAS*

234

A17_NC

DDR4_288P[11SM1-520288-32R]

DIP

RFU
RFU
RFU

NC2_SAVE*1

ODT1
ODT0

PARITY

RESET*

EVENT*
ALERT*

ACT*

CB0_NC
CB1_NC
CB2_NC
CB3_NC
CB4_NC
CB5_NC
CB6_NC
CB7_NC

DQS0

DQS0*

DQS1

DQS1*

DQS2

DQS2*

DQS3

DQS3*

DQS4

DQS4*

DQS5

DQS5*

DQS6

DQS6*

DQS7

DQS7*

DQS8

DQS8*

DM0/DQS9_DBI0

NC/DQS9*

DM1/DQS10_DBI1

NC/DQS10*

DM2/DQS11_DBI2

NC/DQS11*

DM3/DQS12_DBI3

NC/DQS12*

DM4/DQS13_DBI4

NC/DQS13*

DM5/DQS14_DBI5

NC/DQS14*

DM6/DQS15_DBI6

NC/DQS15*

DM7/DQS16_DBI7

NC/DQS16*

DM8/DQS17_DBI8

NC/DQS17*

DQ0
DQ1
DQ2
DQ3
DQ4
DQ5
DQ6
DQ7
DQ8

DQ9
DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46
DQ47
DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63

CHANNEL D
SA2:0=100

227
205
144

230

M_ODT_D1

91

M_ODT_D0

87
222

58

A_-M_RSTC23 (7,13)

78

A_-MHOT_C23 (7,13)

208

M_-ALERT_D (4)

62

M_-ACT_D (4)

49
194
56
201
47
192
54
199

M_DQSD0

153

M_-DQSD0

152

M_DQSD1

164

M_-DQSD1

163

M_DQSD2

175

M_-DQSD2

174

M_DQSD3

186

M_-DQSD3

185

M_DQSD4

245

M_-DQSD4

244

M_DQSD5

256

M_-DQSD5

255

M_DQSD6

267

M_-DQSD6

266

M_DQSD7

278

M_-DQSD7

277
197

196
7

8
18

19
29

30
40

41
99

100
110

111
121

122
132

133
51

52

M_DD0

5

M_DD1

150

M_DD2

12

M_DD3

157

M_DD4

3

M_DD5

148

M_DD6

10

M_DD7

155

M_DD8

16

M_DD9

161

M_DD10

23

M_DD11

168

M_DD12

14

M_DD13

159

M_DD14

21

M_DD15

166

M_DD16

27

M_DD17

172

M_DD18

34

M_DD19

179

M_DD20

25

M_DD21

170

M_DD22

32

M_DD23

177

M_DD24

38

M_DD25

183

M_DD26

45

M_DD27

190

M_DD28

36

M_DD29

181

M_DD30

43

M_DD31

188

M_DD32

97

M_DD33

242

M_DD34

104

M_DD35

249

M_DD36

95

M_DD37

240

M_DD38

102

M_DD39

247

M_DD40

108

M_DD41

253

M_DD42

115

M_DD43

260

M_DD44

106

M_DD45

251

M_DD46

113

M_DD47

258

M_DD48

119

M_DD49

264

M_DD50

126

M_DD51

271

M_DD52

117

M_DD53

262

M_DD54

124

M_DD55

269

M_DD56

130

M_DD57

275

M_DD58

137

M_DD59

282

M_DD60

128

M_DD61

273

M_DD62

135

M_DD63

280

M_ODT_D1 (4)
M_ODT_D0 (4)

M_DDR_PARD (4)

M_-DQSD[0..7](6)

4

DDR4_5_DET

DDR_12V_B

VPP_25V_B

M_VREF_DDRD

M_D1_SA2
M_D1_SA1
M_D1_SA0

M_AAD0
M_AAD1
M_AAD2
M_AAD3
M_AAD4
M_AAD5
M_AAD6
M_AAD7
M_AAD8
M_AAD9
M_AAD10
M_AAD11
M_AAD12
M_AAD13
M_AAD14
M_AAD15
M_AAD16
M_AAD17

DDR4_288P[11SM1-520288-22R]

77

221

11
13
15
17
20
22
24
26
28
31
33
35
37
39
42
44
46
48
50
53
55
57
94
96

98
101
103
105
107
109
112
114
116
118
120
123
125
127
129
131
134
136
138
147
149
151
154
156
158
160
162
165
167
169
171
173
176
178
180
182
184
187
189
191
193
195
198
200
202
239
241
243
246
248
250
252
254
257
259
261
263
265
268
270
272
274
276
279
281
283

59

61

64

67

70

73

76

80

83

85

88

90

92
204
206
209
212
215
217
220
223
226
229
231
233
236

142
143
286
287
288

145

146
284

238
140
139
285
141

224

81
207

63
219

218

75

74
235

237

93

89

84
203

60

79

72
216

71
214
213

69
211

68

66
225
210

65
232
228

86

82
234

DDRVTT_B

DDR4_5_DET(15)

MBC43 1u/4/X5R/6.3V/K

MBC44 0.1u/4/X7R/16V/K

VDDSPDB

M_CH23_SDA(13)

M_CH23_SCL(13)

M_SBAD1(4)
M_SBAD0(4)
M_BG_D1(4)
M_BG_D0(4)

M_-DCLKD3(4)

M_DCLKD3(4)

M_-DCLKD1(4)

M_DCLKD1(4)

M_C2_D(4)
M_-CSD7(4)
M_-CSD6(4)
M_-CSD5(4)

M_AAD[0..17](4)

VPP_25V_B

M_-CSD4(4)
M_CKED3(4)

M_CKED2(4)

󵸚󵸚󵸚󵸚󶁜󶁜󶁜󶁜󳜶󳜶󳜶󳜶󴿓󴿓󴿓󴿓󱓷󱓷󱓷󱓷󳽼󳽼󳽼󳽼󲆬󲆬󲆬󲆬󶁜󶁜󶁜󶁜

M_DD[0..63]

M_DD[0..63](6)

M_AAD[0..17](4)

M_DQSD[0..7](6)

M_AAD[0..17]
M_DQSD[0..7]
M_-DQSD[0..7]

M_D0_SA0

MBR100/4/SHT/20/X

M_D0_SA1

MBR120/4/SHT/20/X

M_D0_SA2

MBR200/4/SHT/20/X

4

2
4
6
9

1

DDR4_8_2D

VTT
VTT

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD

VPP
VPP
VPP
VPP
VPP

12V3_NC
12V3_NC

VREFCA
VDDSPD

SA2_RFU
SA1
SA0
SDA
SCL

BA1
BA0
BG1
BG0

CK1/NU*
CK1/NU
CK0*
CK0

C_2_NC
S3_N_C
S2_N_C
S1_N
S0_N

CKE1
CKE0

A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10/AP
A11
A12
A13
A14_WE*
A15_CAS*
A16_RAS*
A17_NC

DIP

3

RFU
RFU
RFU

NC2_SAVE*1

ODT1
ODT0

PARITY
RESET*
EVENT*
ALERT*

ACT*

CB0_NC
CB1_NC
CB2_NC
CB3_NC
CB4_NC
CB5_NC
CB6_NC
CB7_NC

DQS0
DQS0*

DQS1
DQS1*

DQS2
DQS2*

DQS3
DQS3*

DQS4
DQS4*

DQS5
DQS5*

DQS6
DQS6*

DQS7
DQS7*

DQS8
DQS8*

DM0/DQS9_DBI0

NC/DQS9*

DM1/DQS10_DBI1

NC/DQS10*

DM2/DQS11_DBI2

NC/DQS11*

DM3/DQS12_DBI3

NC/DQS12*

DM4/DQS13_DBI4

NC/DQS13*

DM5/DQS14_DBI5

NC/DQS14*

DM6/DQS15_DBI6

NC/DQS15*

DM7/DQS16_DBI7

NC/DQS16*

DM8/DQS17_DBI8

NC/DQS17*

DQ0
DQ1
DQ2
DQ3
DQ4
DQ5
DQ6
DQ7
DQ8

DQ9
DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46
DQ47
DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63

CHANNEL D
SA2:0=101

3

2

227
205
144

230

M_ODT_D3

91
87

222
58
78
208
62

49
194
56
201
47
192
54
199

153
152

164
163

175
174

186
185

245
244

256
255

267
266

278
277

197
196

7
8

18
19

29
30

40
41

99
100

110
111

121
122

132
133

51
52

5
150
12
157
3
148
10
155
16
161
23
168
14
159
21
166
27
172
34
179
25
170
32
177
38
183
45
190
36
181
43
188
97
242
104
249
95
240
102
247
108
253
115
260
106
251
113
258
119
264
126
271
117
262
124
269
130
275
137
282
128
273
135
280

M_ODT_D2

M_DQSD0
M_-DQSD0

M_DQSD1
M_-DQSD1

M_DQSD2
M_-DQSD2

M_DQSD3
M_-DQSD3

M_DQSD4
M_-DQSD4

M_DQSD5
M_-DQSD5

M_DQSD6
M_-DQSD6

M_DQSD7
M_-DQSD7

M_DD0
M_DD1
M_DD2
M_DD3
M_DD4
M_DD5
M_DD6
M_DD7
M_DD8
M_DD9
M_DD10
M_DD11
M_DD12
M_DD13
M_DD14
M_DD15
M_DD16
M_DD17
M_DD18
M_DD19
M_DD20
M_DD21
M_DD22
M_DD23
M_DD24
M_DD25
M_DD26
M_DD27
M_DD28
M_DD29
M_DD30
M_DD31
M_DD32
M_DD33
M_DD34
M_DD35
M_DD36
M_DD37
M_DD38
M_DD39
M_DD40
M_DD41
M_DD42
M_DD43
M_DD44
M_DD45
M_DD46
M_DD47
M_DD48
M_DD49
M_DD50
M_DD51
M_DD52
M_DD53
M_DD54
M_DD55
M_DD56
M_DD57
M_DD58
M_DD59
M_DD60
M_DD61
M_DD62
M_DD63

M_ODT_D3 (4)
M_ODT_D2 (4)

M_DDR_PARD (4)
A_-M_RSTC23 (7,13)
A_-MHOT_C23 (7,13)
M_-ALERT_D (4)
M_-ACT_D (4)

M_D1_SA0
M_D1_SA1

MBR4250/4/SHT/20/X

M_D1_SA2

MBR4240/4/SHT/20/X

VPP_25V_B
VPP_25V_B

MBR4280/4/SHT/20/X

2

MBBC25

0.1u/4/X7R/16V/K

DDR_12V_B

MBR11
1K/4/1/X

M

_VREF_DDRD

MBR24
1K/4/1/X

A_-M_RSTC23

100p/4/NPO/50V/J

M_VREF_DDRD (13)

MBC1

Title

Size Document Number Rev

Date: Sheet o f

Custom

1

DDR_12V_B

MBBC28

0.1u/4/X7R/16V/K

Gigabyte Technology

DDRIII CHANNEL C/D

GA-X99-UD5 WIFI

1

14 64

1.0

5

PCHA

CLKIN_PCILOOPBACK

C35

PME

J34

GPIO50/GSXCLK

L32

GPIO51/GSXDOUT

L34

GPIO52/GSXSLOAD

V48

GPIO53/GSXDIN

U49

GPIO54/GSXSRESET

J23

GPIO55
PIRQA

PIRQB
PIRQC
PIRQD

Y48

GPIO2/PIRQE
GPIO3/PIRQF
GPIO4/PIRQG

Y46

GPIO5/PIRQH_

V15

DMI_IREF

T15

DMI_RCOMP

AC1

PCIE_IREF
PCIE_RCOMP

WBG_X_PCH_EDS

3 OF 10

SATA4GP/GPIO16/MGPIO9

SATA5GP/GPIO49/MGPIO10

WBG_X_PCH_EDS

1 OF 10

SATA_TXP5/PETP2

SATA_TXN5/PETN2

SATA_TXP4/PETP1

SATA_TXN4/PETN1

SSATA_TXP3
SSATA_TXN3
SSATA_TXP2
SSATA_TXN2
SSATA_TXP1
SSATA_TXN1
SSATA_TXP0
SSATA_TXN0

SATA_TXP3
SATA_TXN3
SATA_TXP2
SATA_TXN2
SATA_TXP1
SATA_TXN1
SATA_TXP0
SATA_TXN0

SATALED

SSATALED
SSATA0GP

SSATA1GP
SSATA2GP
SSATA3GP

SATA0GP/GPIO21
SATA1GP/GPIO19
SATA2GP/GPIO36
SATA3GP/GPIO37

SDATAOUT0/GPIO39
SDATAOUT1/GPIO48

SSDATAOUT0
SSDATAOUT1

RCIN

SERIRQ

THRMTRIP

PECI

PM_SYNC

PM_SYNC2

DIFFCLK_BIASREF

SATA_IREF

SATA_RCOMP

USBRBIAS

USBRBIAS
RESERVED
RESERVED

MGPIO13
MGPIO14
MGPIO15
MGPIO16
MGPIO17

GPIO47
GPIO56

MEXP_SMBDATA2
MEXP_SMBDATA1
MEXP_SMBDATA0

MEXP_SMBCLK2
MEXP_SMBCLK1
MEXP_SMBCLK0

N_SATA5TXP

B10

N_SATA5TXN

D10

N_SATA4TXP

D8

N_SATA4TXN

B8

N_SSATA3TXP

BF40

N_SSATA3TXN

BH40

N_SSATA2TXP

BF42

N_SSATA2TXN

BH42

N_SSATA1TXP

BD46

N_SSATA1TXN

BE48

N_SSATA0TXP

BB48

N_SSATA0TXN

BB46

N_SATA3TXPN_SATA3RXP

D18

N_SATA3TXN

B18

N_SATA2TXP

D16

N_SATA2TXN

B16

N_SATA1TXP

B14

N_SATA1TXN

D14

N_SATA0TXP

D12

N_SATA0TXN

B12
J7

BH34

PCH_SATAS0

AW32

PCH_SATAS1

BF36

PCH_SATAS2

BH36

PCH_SATAS3

BF38

N_GPIO21

D4

N_GPIO19

B24

N_GPIO36

B5

N_GPIO37

G11

N_GPIO16

A9

N_GPIO49

B28

N_GPIO39

M21

N_GPIO48

D6

N_SAS_DOUT0

BH38

N_SAS_DOUT1

BF34

-RCIN N_-KBRST

C25

N_SERIRQ

L21
A13
A21

PCH_PMSYNC0

J18

PCH_PMSYNC1

BJ27

XCLK_BIASREF

BA11

N_SATA_IREF

L12

N_SATA_RCOMP

N10

AP40

N_USBRBIAS

AP41
D46
B26

BH26
BF28
BH28
BF26
BJ29

N_GPIO47

F27

N_GPIO56

M29

NR210 8.2K/4

BJ37

NR211 8.2K/4

BF30

NR213 8.2K/4

BJ33

NR217 8.2K/4

BH30

NR220 8.2K/4

BH32

NR7 8.2K/4

BF32

N_SATA5RXP(48)
N_SATA5RXN(48)
N_SATA4RXP(48)
N_SATA4RXN(48)

D D

N_SATA3RXP(48)
N_SATA3RXN(48)
N_SATA2RXP(48)
N_SATA2RXN(48)

C C

VCC15_05

VCC15_05

3VDUAL_PCH

VCC3

B B

VCC15_05
VCC15_05

VCC15_05
VCC15_05

A A

N_SATA5RXP
N_SATA5RXN
N_SATA4RXP
N_SATA4RXN
N_SSATA3RXP
N_SSATA3RXN
N_SSATA2RXP
N_SSATA2RXN
N_SSATA1RXP
N_SSATA1RXN
N_SSATA0RXP
N_SSATA0RXN

N_SATA3RXN
N_SATA2RXP
N_SATA2RXN
N_SATA1RXP
N_SATA1RXN
N_SATA0RXP
N_SATA0RXN

N_GPIO69(48)

IOTOPCH(28)

N_GPIO6(39)

N_GPIO1(57)
N_GPIO17(57)

N_SSTCTL(28)

NR24 0/4/X

N_SAS_IREF

NR193 0/4/SHT/20/X

N_SAS_RCOMP

NR194 7.5K/4/1

N_PCH33(17)

NR197 8.2K/4

NR198 8.2K/4

VCC3

NR200 8.2K/4/X
NR201 8.2K/4
NR202 8.2K/4/X

NR203 8.2K/4
NR204 8.2K/4
NR205 8.2K/4/X

N_GPIO53

NR305
1K/4/1

NR212 0/4/SHT/20/X

NR215 7.5K/4/1

NR219 0/4/SHT/20/X

NR1 7.5K/4/1

N_GPIO71
N_GPIO70

N_GPIO69
N_GPIO68
N_GPIO7
N_GPIO6
N_GPIO1
N_GPIO17

N_GPIO22
N_GPIO38

N_SAS_CLK
N_SAS_LOAD

L11
J11

G7
F7

AW39

BA39
BC43
BD43
BA44

AW44

AU43
AU44

G18

F18
M18
N18

L16

J16

F12
G12

V43
V40
V35
V38

V36
V41

T43
T36
T38
V44
T41
T40

C43

J12

G6

BD29
BC29

BD32

BC32

N_PCH33
N_-P_PME

N_GPIO50
N_GPIO52

N_GPIO53

N_GPIO55

N_GPIO55
N_-PIRQA

N_-PIRQB
N_-PIRQC
N_-PIRQD

N_-PIRQE

N_-PIRQF
N_-PIRQG
N_-PIRQH

N_DMI_REF
N_DMI_RCOMP

N_PCIE_REF
N_PCIE_RCOMP

5

PCHC

SATA_RXP5/PERN2
SATA_RXN5/PERP2
SATA_RXP4/PERN1
SATA_RXN4/PERP1
SSATA_RXP3
SSATA_RXN3
SSATA_RXP2
SSATA_RXN2
SSATA_RXP1
SSATA_RXN1
SSATA_RXP0
SSATA_RXN0

SATA_RXP3
SATA_RXN3
SATA_RXP2
SATA_RXN2
SATA_RXP1
SATA_RXN1
SATA_RXP0
SATA_RXN0

PWM3
PWM2
PWM1
PWM0

TACH7/GPIO71
TACH6/GPIO70

TACH5/GPIO69
TACH4/GPIO68
TACH3/GPIO7
TACH2/GPIO6
TACH1/GPIO1
TACH0/GPIO17

SST
SCLOCK/GPIO22

SLOAD/GPIO38
SSCLOCK

SSLOAD

SSATA_IREF

SSATA_RCOMP

AE47

AA47
AA49
AE49
AF48

AD48
AB48

AG12

4

N_SATA5TXP (48)
N_SATA5TXN (48)
N_SATA4TXP (48)
N_SATA4TXN (48)

N_SATA3TXP (48)
N_SATA3TXN (48)
N_SATA2TXP (48)
N_SATA2TXN (48)

N_-SATALED (39)
N_-SASLED (39)

N_GPIO21 (40)

N_GPIO16 (48)
N_GPIO49 (48)

N_SERIRQ (28,42)

N_-THRMTRIP (7,28,30,31,32,33)

NR8 0/4/SHT/20/X

NR196 7.5K/4/1

NTP8

NR206

N_-KBRST (16,28)

NR20 0/4/SHT/20/X

NR199

7.5K/4/1

NR82 22.6/4/1

8.2K/4

VCC3

VCC3

4

A_PMSYNC0 (7)

VCC15_05

VCC15_05
VCC15_05

N_SATA1TXP
N_SATA1TXN

N_SATA1RXN N_SATA1RXNC
N_SATA1RXP

NC104 MASK/0/5/SHT/X

1

NC103 MASK/0/5/SHT/X

1

NC102 MASK/0/5/SHT/X

1

NC101 MASK/0/5/SHT/X

1

N_SATA1TXPC
N_SATA1TXNC

N_SATA1RXPC

Remove SATA3_2_3

N_SSATA1TXPCN_SSATA1TXP
N_SSATA1TXNCN_SSATA1TXN

N_SSATA1RXNC
N_SSATA1RXPC

N_SSATA3TXPC N_SSATA2TXP
N_SSATA3TXNC

N_SSATA3RXNC
N_SSATA3RXPC

DDR4_1_DET(14)
DDR4_2_DET(12)

DDR4_4_DET(11)

DDR4_5_DET(14)
DDR4_6_DET(12)

WBG_X_PCH_EDS

PCHE

NC_DUT_DETECT_3
NC_DUT_DETECT_2
NC_DUT_DETECT_1TD_IREF

5 OF 10

N_SSATA1RXN
N_SSATA1RXP

N_SSATA3TXP
N_SSATA3TXN

N_SSATA3RXN
N_SSATA3RXP

Rev 2.0

N_-THRMTRIP

NC62

100p/4/NPO/50V/J/X

NR9 8.2K/4

NC147 MASK/0/5/SHT/X

1

NC149 MASK/0/5/SHT/X

1

NC151 MASK/0/5/SHT/X

1

NC153 MASK/0/5/SHT/X

1

NC155 MASK/0/5/SHT/X

1

NC157 MASK/0/5/SHT/X

1

NC159 MASK/0/5/SHT/X

1

NC3 MASK/0/5/SHT/X

1

DIMM_DET PCIE_DET

SATA3_0_1

SSATA3_0_1

SSATA3_2_3

DPWROK

3

GND

8

TX1+

9

TX1-

10

GND

11

RX1-

12

RX1+

13

GND

14

SATA/14/BK/H/OP/RA/D/2

GND

8

TX1+

9

TX1-

10

GND

11

RX1-

12

RX1+

13

GND

14

SATA/14/BK/H/OP/RA/D/2

GND

8

TX1+

9

TX1-

10

GND

11

RX1-

12

RX1+

13

GND

14

SATA/14/BK/H/OP/RA/D/2

N_GPIO71
N_GPIO68

N_GPIO50

N_GPIO39
N_GPIO52

BH46
BF2
B4BC6

NR17 0/4/SHT/20/X

N41

3

GND

1

TX0+

N_SATA0TXPC N_SATA0TXP

2

TX0-

N_SATA0TXNC

3

GND

4

RX0-

N_SATA0RXNC

5

RX0+

N_SATA0RXPC

6

GND

7

󶁜󶁜󶁜󶁜

Combine to SATA Express

GND

1

TX0+

N_SSATA0TXPC

2

TX0-

3

GND

4

RX0-

N_SSATA0RXNC

5

RX0+

N_SSATA0RXPC

6

GND

7

GND

1

TX0+

N_SSATA2TXPC

2

TX0-

N_SSATA2TXNC

3

GND

4

RX0-

N_SSATA2RXNC

5

RX0+

N_SSATA2RXPC

6

GND

7

1

NC106 MASK/0/5/SHT/X

1

NC105 MASK/0/5/SHT/X

1

NC100 MASK/0/5/SHT/X

1

NC99 MASK/0/5/SHT/X

1

NC148 MASK/0/5/SHT/X

1

NC150 MASK/0/5/SHT/X

1

NC152 MASK/0/5/SHT/X

1

NC154 MASK/0/5/SHT/X

1

NC156 MASK/0/5/SHT/X

1

NC158 MASK/0/5/SHT/X

1

NC160 MASK/0/5/SHT/X

1

NC4 MASK/0/5/SHT/X

N_SATA0TXN
N_SATA0RXN

N_SATA0RXP

N_SSATA0TXP
N_SSATA0TXNN_SSATA0TXNC

N_SSATA0RXN
N_SSATA0RXP

N_SSATA2TXN
N_SSATA2RXN

N_SSATA2RXP

SATA2
port5

PCIEX16_1_DET(20)
PCIEX8_1_DET(23)

N_GPIO56
N_GPIO48

N_PCH_DPW ROK (17,28)

NR207

0/4/SHT/20/X

PCIEX16_X8 RST

PCIE_X16_X8_RST(20,21,23,24)

PCIEX1 RST

PCIE_X1_RST(25)

3VDUALVCC3

2

NR209
0/4/X

2

RST_PWR

RST_PWR

O_-PCIE_RST(28)

RST_PWR

O_-PCIE_RST(28)

NR214 22/4

NR130 22/4

1

N_GPIO22

1 2

N_GPIO38

3 4

N_GPIO39

5 6

N_GPIO48

7 8

1 2
3 4
5 6
7 8

NRN1 8.2K/8P4R/6

1 2
3 4
5 6
7 8

NR195 8.2K/4
NRN2 8.2K/8P4R/6

1 2
3 4
5 6
7 8

NRN4 8.2K/8P4R/6

1 2
3 4
5 6
7 8

NR10 8.2K/4
NR11 8.2K/4
NR13 8.2K/4
NR14 8.2K/4

NR73 8.2K/4
NR66 8.2K/4

NR189 8.2K/4/X

GP36 is
strapping ?

N_GPIO36

N_GPIO19

PCH_PMSYNC1

VCC15_PLL

RST_PWR

NC22

0.1u/4/X7R/16V/K

RST_PWR

NR208 22/4

RST_PWR

NR218 22/4

NR300 22/4

1

N_GPIO21
N_GPIO36

N_GPIO37
N_GPIO16
N_GPIO49

N_GPIO71
N_GPIO68
N_GPIO70

N_GPIO7
N_GPIO1
N_GPIO6
N_GPIO17

N_SERIRQ
N_GPIO69

N_SAS_CLK
N_SAS_LOAD
N_SAS_DOUT1
N_SAS_DOUT0

-RCIN

N_-PIRQD
N_-PIRQC
N_-PIRQB
N_-PIRQA

N_-PIRQE
N_-PIRQF
N_-PIRQG
N_-PIRQH

PCH_SATAS0
PCH_SATAS1
PCH_SATAS2
PCH_SATAS3

N_GPIO47
N_GPIO56

PCH_PMSYNC1

NR1901K/4/1

NR448.2K/4/X

NR1918.2K/4/X

NR187 0/6/SHT/30/X
NR188 0/6/X

O_-PCIE_RST (28)

LAN RST

PCIE_OB1_RST (58,59)

O_-PCIE_RST (28)

M.2 RST

PCIE_OB2_RST (47,48)

PCIE_OB2B_RST (48)

15 64Tuesday, August 26, 2014

VCC3

NU2

1

1A

2

1B

3

1Y

4

2A

5

2B

6

2Y

7 8

GND 3Y

74LVC08AD/SO14

Title

Size Document Number Rev

Custom

Date: Sheet of

NR25 1K/4/1
NR38 8.2K/4/X

NR42 8.2K/4
NR27 8.2K/4
NR23 8.2K/4

NRN5 8.2K/8P4R/6

NRN7 8.2K/8P4R/6

NR62 8.2K/4
NR68 8.2K/4
NR70 8.2K/4
NR87 8.2K/4

NR192 8.2K/4
NR5 8.2K/4/X

VCC3

VCC3

VCC3

VCC3

3VDUAL

VCCIO

VCC1_05_WBG

14

VCC

13

4B

12

4A

11

4Y

10

3B

9

3A

Gigabyte Technology

PCH FDI,DMI,USB ,PCIE,NVRAM

GA-X99-UD5 WIFI

VCC15_05

1.0

5

NC52

N_LAD[0..3]

C_ACZ_SDOUT(53)

C_ACZ_SYNC(53)

N_ME_PWROK

O_PWROK1(28,42)

N_RTCVDD(18,41)

N_LAD3(28,42)
N_LAD2(28,42)
N_LAD1(28,42)
N_LAD0(28,42)

NR58 8.2K/4

VCC3

N_-LDRQ0(28)
N_-LFRAME(28,42)

C_ACZ_SDIN2(53)

NR296 33/4

C_ACZ_BITCLK(53)

C_-ACZ_RST(53)

NR299 33/4

N_-RTCRST(18,44,57)

NR49 0/4/SHT/20/X

N_SMBCLK(20,21,23,24,25,26,27,30,34,35,37,42,47,58)

N_SMBDATA(20,21,23,24,25,26,27,30,34,35,37,42,47,58)

N_SML0CLK(59)
N_SML0DAT(59)

N_ICH_SPI_CLK(29,43)

VCC3
VCC3

N_-ICH_SPI_CS(29)
N_ICH_SPI_MOSI(29,43)
N_ICH_SPI_MISO(29,43)

SPI_DQ2(29)
SPI_DQ3(29)

N_-SRTCRST(18)

N_-CPURST(7)

N_-PFMRST(28,42)

N_LAD3
N_LAD2
N_LAD1
N_LAD0

N_GPIO23
N_-LDRQ0
N_-LFRAME

NR297 33/4

NR298 33/4

N_-INTRUDER

NR981M/4

N_ME_PWROK

N_PCH_PCH_PWROK

N_CPUPWROK(7)

A_DRAM_PWROK(35)

N_DSWODVREN(18)

N_INTVRMEN(18)

N_GPIO11
N_SMBCLK
N_SMBDATA

N_SML1ART
N_SML1CLK
N_SML1DAT

N_SML0ART
N_SML0CLK
N_SML0DAT

NR50 8.2K/4
NR21 8.2K/4

NTP10

N_-SYS_RST(39)

O_-RSMRST(28,37)

N_PCH_TDI
N_PCH_TDO
N_PCH_TCK
N_PCH_TMS

N_A_SO

N_A_SYC

N_Y1
N_Y2

AC47

AD46

AN47
AN49

AR47

AM46

N_LAD[0..3](28,42)

D D

NR48 0/4/X

O_PWROK1(28,42)

C C

NX2
SHW/D0.64*5.08*6.74

N_Y1
N_Y2

NR97 10M/4

NX2

NC53

3 4

18P/4/NPO/50V/J

B B

32.768K/12.5p/20ppm/TF38/35K/D

18P/4/NPO/50V/J

4

PCHD

AA36

LAD3
LAD2

AA38

LAD1

AA40

LAD0

AA35

GPIO23/LDRQ1
LDRQ0

AA41

LFRAME
HDA_SDI3

HDA_SDI2

AL47

HDA_SDI1

AJ47

HDA_SDI0
HDA_SDO

AK48

HDA_BCLK
HDA_RST

AP48

HDA_SYNC

T46

RTCX1

R47

RTCX2

P48

RTCRST

N44

INTRUDER

G29

APWROK

M48

PCH_PWROK

F6

PROCPWRGD

B45

DRAMPWROK

N40

DSWVRMEN

N47

INTVRMEN

F39

GPIO11/SMBALERT

L39

SMBCLK

B40

SMBDATA

L44

GPIO74/MGPIO8/SML1ALERT_N_PCHHOT

L38

SML1CLK/GPIO58/MGPIO11

N36

SML1DATA/GPIO75/MGPIO12

D42

GPIO60/MGPIO4/SML0ALERT

J38

SML0CLK

F38

SML0DATA

C31

SPI_CLK

N21

SPI_CS2

L23

SPI_CS1

G23

SPI_CS0

B30

SPI_MOSI

N23

SPI_MISO

L27

SPI_IO2

C29

SPI_IO3

A33

NCTF/TP

D26

SYS_RESET

T44

RSMRST

M46

SRTCRST

A17

PLTRST_PROC

G38

PLTRST

F32

JTAG_TDI

C33

JTAG_TDO

G34

JTAG_TCK

B32

JTAG_TMS

4 OF 10

WBG_X_PCH_EDS

GPIO72

GPIO63/SLP_S5

SLP_S4
SLP_S3

RESERVED

SUSCLK/GPIO62

GPIO61

GPIO57/MGPIO5

GPIO46
GPIO45
GPIO44
GPIO26
GPIO25

GPIO20/SMI

GPIO18
GPIO73

GPIO35/NMI

GPIO34
GPIO33
GPIO32

GPIO31/MGPIO2

GPIO30/MGPIO1/SUSWARN

GPIO29/MGPIO3/SLP_WLAN

GPIO28/MGPIO7
GPIO27/MGPIO6
GPIO24/MGPIO0

LAN_PHY_PWR_CTRL/GPIO12

GPIO15

GPIO13

GPIO8

GPIO0/BMBUSY

PWRBTN

SLP_A

SLP_SUS

SLP_LAN

SPKR

SYS_PWROK

SUSACK

WAKE

CGC_DUT_DETECT

G47
D38

J49
B46
F34

J32
C37

C39
D34

G27
G32
J29
G39
M23
G21
F29

F11

F21
AJ49
J21
K48
F43
H48
M27

L29
B36

B34
L47
AM48
C41
A25
N43
J39

RI

E48
H46

J47
C27
D30

A41

F44
D48

3

N_GPIO72

N_-SLP_S5

N_-S4_S5 (28,38,39,42)

N_-SLP_S3 (28,34,35,37,38,39,42)

NTP9

N_SUSCLK
N_GPIO61

N_GPIO57

N_GPIO46
N_GPIO45
N_GPIO44
N_GPIO26
N_GPIO25
N_GPIO20
N_GPIO18
N_GPIO73

N_GPIO35

N_GPIO34
N_GPIO33

N_GPIO32
N_GPIO31

N_-S_WARN

N_GPIO29

N_GPIO28

N_GPIO27

N_GPIO24

N_GPIO15

N_GPIO12

N_GPIO8
N_GPIO0

N_-RI
N_-SLP_A

N_-SLP_LAN

N_PCH_SYS_PWROK

NR103 0/4/SHT/20/X

N_-PCIE_WAKE

N-GC_DUT_D

N_GPIO18 (57)
N_GPIO73 (48)

N_GPIO33 (39)

N_-LAN_WAKE (59)

NR65 0/4/SHT/20/X

N_-LPCPME (28)

O_PWRBTSW (28)

N_-SLP_A (38)

N_-DEPSLP (37)

N_SPKR (39)

NR139 0/4/SHT/20/X

N_-S_WARNN_-S_ACK

A_-SKTOC (7)

N_PCH_TDI
N_PCH_TDO
N_PCH_TMS
N_PCH_TCK

N_PCH_TDI
N_PCH_TDO
N_PCH_TMS
N_PCH_TCK

N_SUSCLK

EC2TOPCH(43)
EC1TOPCH(42)

PCIE_DET

PCIEX16_2_DET(21)

DDR4_3_DET(13)
PCIEX8_2_DET(24)

DDR4_8_DET(11)
DDR4_7_DET(13)

N_PCH_VRMPWRGD (26,28)

NR84 10/4

N_GPIO12

SOT23

VCC3

DR3
100K/4/1

2

NR170 200/4/1/X
NR141 200/4/1/X
NR169 200/4/1/X
NR51 200/4/1/X

NR171 100/4/1/X
NR168 100/4/1/X
NR142 100/4/1/X
NR52 51/4/1/X

N_SUSCLK_WIFI (47)

N_LAN_DIS- (59)

ND2

N_GPIO0

BAT54A/SOT23/200mA

N_GPIO34
N_GPIO25

N_GPIO57

N_GPIO32

N_GPIO31

DR4
1K/4/1

N_PCH_VRMPWRGD (26,28)

DBC1

0.1u/4/X7R/16V/K

3VDUAL

3VDUAL_PCH

3VDUAL_PCH

3VDUAL

NR93 1K/4/1
NR78 8.2K/4/X
NR86 8.2K/4
NR104 8.2K/4

NR76 8.2K/4
NR60 8.2K/4/X
NR45 8.2K/4/X

NR107 1K/4/1/X
NR28 1K/4/1/X

NR53 499/4/1
NR55 499/4/1
NR67 499/4/1
NR74 499/4/1

NR46 8.2K/4/X

1 2
3 4
5 6
7 8

NRN9

1K/8P4R/6

NR85 1K/4/1
NR80 1K/4/1

NR59 8.2K/4
NR61 8.2K/4/X
NR37 8.2K/4
NR56 8.2K/4
NR83 8.2K/4/X
NR35 8.2K/4
NR100 8.2K/4
NR79 8.2K/4
NR69 8.2K/4
NR94 8.2K/4
NR101 8.2K/4
NR81 8.2K/4

NR88 8.2K/4/X

NR92 8.2K/4
NR75 8.2K/4/X
NR57 8.2K/4/X
NR106 8.2K/4

N_GPIO46

NR119 8.2K/4/X

1

N_-PCIE_WAKE (20,21,23,24,25,47,58)

N_-SLP_A
N_GPIO31
N_GPIO27

N_GPIO72
N_-SLP_S5
N_-SLP_LAN

PU A_SO for ME_DEBUG

N_A_SO
N_A_SYC

N_SML0DAT
N_SML0CLK
N_SML1DAT
N_SML1CLK

N_-SLP_LAN

N_SML1ART
N_SML0ART

N_-RI

N_SMBDATA (20,21,23,24,25,26,27,30,34,35,37,42,47,58)
N_SMBCLK (20,21,23,24,25,26,27,30,34,35,37,42,47,58)

A_-SKTOC (7)

N_GPIO29
N_GPIO57
N_GPIO28
N_GPIO8
N_-LPCPME
N_GPIO11
N_GPIO12
N_GPIO15
N_GPIO25
N_GPIO26
N_GPIO44

N_GPIO45

N_GPIO61
N_SUSCLK
N_GPIO73

N-GC_DUT_D

NR229 8.2K/4/X

GP15 low to disable
TLS , high to enable
TLS

NR95 8.2K/4/X

GP62 int PU to enable
on DIE VRM

NR105 8.2K/4/X

ME PWROK

ND3

N_-SLP_A(38)

A A

VCC1_05_ME

VCC3_ME

BAT54A/SOT23/200mA

NR303
1/4/1

SOT23

NR304 8.2K/4 NR1281K/4/1

NC184
1u/4/X5R/6.3V/K

5

VCC3_ME

3VDUAL

NR302
22K/4

NQ27
MMBT2222A/SOT23/600mA/40

132

NR301

8.2K/4

N_ME_PWROK

NC183

0.01u/4/X7R/25V/K

NQ26

132

MMBT2222A/SOT23/600mA/40

N_ME_PWROK (42)

3VDUAL

N_GPIO8

NR129

8.2K/4

4

3VDUAL

NR127

8.2K/4

NR124

8.2K/4/X

NR125 0/4/SHT/20/X

NR126 0/4/X

MMBT2222A/SOT23/600mA/40/X

SOT23

132

NQ16
MMBT2222A/SOT23/600mA/40

SOT23

132

NQ15

A_CPU_OVERCLOCK (7)

NR182

8.2K/4/X

3

N_-SYS_RST

NC28

22P/4/NPO/50V/J/X

N_GPIO11

0.1u/4/X7R/16V/K/X

Close PCH

NC24

N_-PFMRST

NC39

22P/4/NPO/50V/J/X

N_ME_PWROK

NC25
100p/4/NPO/50V/J/X

N_-S_ACK

NC23

0.1u/4/X7R/16V/K

2

VCC3

NR30 1K/4/1
NR39 8.2K/4

NR121 8.2K/4
NR122 8.2K/4
NR29 8.2K/4
NR40 8.2K/4
NR33 8.2K/4
NR43 8.2K/4
NR54 8.2K/4
NR36 8.2K/4
NR47 8.2K/4

N_A_SYC

N_-SYS_RST

N_A20GATE
N_-KBRST
N_GPIO0
N_GPIO18
N_GPIO20
N_GPIO32
N_GPIO33
N_GPIO34
N_GPIO35

Gigabyte Technology

Title

Size Document Number Rev

Custom

Date: Sheet of

N_A20GATE (28)
N_-KBRST (15,28)

NR123 8.2K/4/X

PCH FDI,DMI,USB ,PCIE,NVRAM

GA-X99-UD5 WIFI

1

16 64Tuesday, August 26, 2014

1.0

5

AU12
AU10

AU7
AU6
AP7

AP9
AP12
AP14

AM6

AM7

AM10
AM12
AG15

AG7

AG6

AC9

AC7

AC12
AC14

AA15
AA14

G43

G44

BD16
BC16

AW11

BA12
BA23

AW12

BD38
BC38

BD4

BE2

AM36
AM35

L6

J6
N6
N7
T9
T7

T14
T12

AA6
AA7

J44

L43

B42
A37
B38

J43

P4
P2

AY2
AY4

B20
D20

V10
V12

PCHB

DMI_RXP3
DMI_RXN3
DMI_RXP2
DMI_RXN2
DMI_RXP1
DMI_RXN1
DMI_RXP0
DMI_RXN0

PERP8
PERN8
PERP7
PERN7
PERP6
PERN6
PERP5
PERN5
PERP4
PERN4
PERP3
PERN3
PERP2/USB3RP4

PERP1/USB3RP3
PERN1/USB3RN3

USB3RP6
USB3RN6
USB3RP5
USB3RN5
USB3RP2
USB3RN2
USB3RP1
USB3RN1

GPIO14/OC7
GPIO10/OC6
GPIO9/OC5
GPIO43/OC4
GPIO42/OC3
GPIO41/OC2
GPIO40/OC1
GPIO59/OC0

PCHF

CLKIN_CPY_P
CLKIN_CPY

CLKOUT_DMI_P1
CLKOUT_DMI_N1

CLKOUT_ITPXDP_P
CLKOUT_ITPXDP

ICLK_IREF
XTAL25_IN
REFCLK14IN
XTAL25_OUT

CLKIN_SATA_P
CLKIN_SATA

CLKIN_SSATA_P
CLKIN_SSATA

CLKOUT_DMI_P0
CLKOUT_DMI_N0

CLKIN_DOT96_P
CLKIN_DOT96

RESERVED
RESERVED

PCH_USB3_RXP3(64)
PCH_USB3_RXN3(64)
PCH_USB3_RXP2(64)
PCH_USB3_RXN2(64)

PCH_USB3_RXP5(51)
PCH_USB3_RXN5(51)
PCH_USB3_RXP4(49)
PCH_USB3_RXN4(49)
PCH_USB3_RXP1(61)
PCH_USB3_RXN1(61)
PCH_USB3_RXP0(61)
PCH_USB3_RXN0(61)

3VDUAL

A_DMI_3TXP
A_DMI_2TXP

A_DMI_2TXN
A_DMI_1TXP
A_DMI_1TXN
A_DMI_0TXP
A_DMI_0TXN

PK_PCIE_IP8(25)
PK_PCIE_IN8(25)
PJ_PCIE_IP7(25)
PJ_PCIE_IN7(25)
PI_PCIE_IP6(25)
PI_PCIE_IN6(25)

LC_ML_IP(58)

LC_ML_IN(58)
M2_WIFI_IP(47)
M2_WIFI_IN(47)

LB_ML_IP(59)

LB_ML_IN(59)

N_GPIO14

A_DMI_3TXP(8)
A_DMI_3TXN(8)
A_DMI_2TXP(8)
A_DMI_2TXN(8)
A_DMI_1TXP(8)
A_DMI_1TXN(8)
A_DMI_0TXP(8)
A_DMI_0TXN(8)

D D

C C

NR77

8.2K/4

B B

A A

WBC52 0.1u/4/X7R/16V/K
WBC50 0.1u/4/X7R/16V/K

WBC49 0.1u/4/X7R/16V/K
WBC48 0.1u/4/X7R/16V/K
WBC47 0.1u/4/X7R/16V/K
WBC46 0.1u/4/X7R/16V/K
WBC45 0.1u/4/X7R/16V/K

N_-USBOC_R(57)

N_-USBOC_F(61)

NC31

0.1u/4/X7R/16V/K

NC33

0.1u/4/X7R/16V/K

N_CPU_BK0(26)
N_-CPU_BK0(26)

VCC15_05

5

NR145

8.2K/4

DMI_PCH_R3P
DMI_PCH_R3N
DMI_PCH_R2P
DMI_PCH_R2N DMI_PCH_T2N
DMI_PCH_R1P
DMI_PCH_R1N
DMI_PCH_R0P
DMI_PCH_R0N

N_GPIO14

N_-USBOC_F

N_-USBOC_R

N_SRCCLK_CPY
N_-SRCCLK_CPY

N_CPU_BK0
N_-CPU_BK0

NR18 0/4/SHT/20/X

XTALI_PCH

N_PCHCLK14

XTALO_PCH

N_SRCCLK_SATA
N_-SRCCLK_SATA

N_SRCCLK_SAS
N_-SRCCLK_SAS

N_DOT96_CLK
N_-DOT96_CLK

N_SRCCLK_DMI
N_-SRCCLK_DMI

4

WBG_X_PCH_EDS

2 OF 10

WBG_X_PCH_EDS

6 OF 10

4

DMI_TXP3
DMI_TXN3
DMI_TXP2
DMI_TXN2
DMI_TXP1
DMI_TXN1
DMI_TXP0
DMI_TXN0

PETP8
PETN8
PETP7
PETN7
PETP6
PETN6
PETP5
PETN5
PETP4
PETN4
PETP3

PETN3
PETP2/USB3TP4
PETN2/USB3TN4PERN2/USB3RN4
PETP1/USB3TP3
PETN1/USB3TN3

USB3TP6
USB3TN6
USB3TP5
USB3TN5
USB3TP2
USB3TN2
USB3TP1
USB3TN1

USB2P13

USB2N13

USB2P12

USB2N12

USB2P11

USB2N11

USB2P10

USB2N10

USB2P9
USB2N9
USB2P8
USB2N8
USB2P7
USB2N7
USB2P6
USB2N6
USB2P5
USB2N5
USB2P4
USB2N4
USB2P3
USB2N3
USB2P2
USB2N2
USB2P1
USB2N1
USB2P0
USB2N0

CLKOUT_PCI4
CLKOUT_PCI3
CLKOUT_PCI2
CLKOUT_PCI1
CLKOUT_PCI0

CLKOUTFLEX3/GPIO67
CLKOUTFLEX2/GPIO66
CLKOUTFLEX1/GPIO65
CLKOUTFLEX0/GPIO64

CLKOUT_PCIE_P7

CLKOUT_PCIE_N7

CLKOUT_PCIE_P6

CLKOUT_PCIE_N6

CLKOUT_PCIE_P5

CLKOUT_PCIE_N5

CLKOUT_PCIE_P4

CLKOUT_PCIE_N4

CLKOUT_PCIE_P3

CLKOUT_PCIE_N3

CLKOUT_PCIE_P2

CLKOUT_PCIE_N2

CLKOUT_PCIE_P1

CLKOUT_PCIE_N1

CLKOUT_PCIE_P0

CLKOUT_PCIE_N0

CLKOUT_GPB_PCIE_P0
CLKOUT_GPB_PCIE_N0

CLKOUT_GPB_PCIE_P1
CLKOUT_GPB_PCIE_N1

CLKOUT_GPB_PCIE_P2
CLKOUT_GPB_PCIE_N2

DMI_PCH_T3P

F4

DMI_PCH_T3N

E2

DMI_PCH_T2P

H4
H2

DMI_PCH_T1P

K4
K2

DMI_PCH_T0P

M4

DMI_PCH_T0N

M2

AV4
AV2
AT2
AT4
AP2
AP4
AM2
AM4
AK2
AK4
AH2
AH4
AF2
AF4AG14
AD4
AD2

AB4
AB2
Y4
Y2
V4
V2
T4
T2

AC38
AC36
AC43
AC44
AC41
AC40
AG35
AG36
AG41
AG40
AG44
AG43
AM43
AM44
AJ43
AJ44
AJ41
AJ40
AM40
AM41
AP43
AP44
AJ35
AJ36
AY46
AY48
AV46
AV48

N_+USBP13
N_-USBP13
N_+USBP12
N_-USBP12

N_+USBP10
N_-USBP10
N_+USBP9
N_-USBP9
N_+USBP8
N_-USBP8
N_+USBP7
N_-USBP7
N_+USBP6
N_-USBP6
N_+USBP5
N_-USBP5
N_+USBP4
N_-USBP4
N_+USBP3
N_-USBP3
N_+USBP2
N_-USBP2
N_+USBP1
N_-USBP1
N_+USBP0
N_-USBP0

BF24
BH24
BF22
BJ21
BH22

BC23
BJ17
BD23
AW23

BD11
BC11
BB4
BB2
BH5
BF6
BH8
BF8
BH14
BF14
BH16
BF16
BH10
BF10
BC21
BD21

BH12
BF12

BA18
BC18

BH20
BF20

3

A_DMI_3RXP

WBC43 0.1u/4/X7R/16V/K
WBC42 0.1u/4/X7R/16V/K
WBC41 0.1u/4/X7R/16V/K
WBC40 0.1u/4/X7R/16V/K
WBC39 0.1u/4/X7R/16V/K
WBC38 0.1u/4/X7R/16V/K
WBC37 0.1u/4/X7R/16V/K

N_+USBP13 (57)
N_-USBP13 (57)
N_+USBP12 (57)
N_-USBP12 (57)

N_+USBP10 (47)
N_-USBP10 (47)
N_+USBP9 (61)
N_-USBP9 (61)
N_+USBP8 (61)
N_-USBP8 (61)
N_+USBP7 (61)
N_-USBP7 (61)
N_+USBP6 (61)
N_-USBP6 (61)
N_+USBP5 (51)
N_-USBP5 (51)
N_+USBP4 (49)
N_-USBP4 (49)
N_+USBP3 (64)
N_-USBP3 (64)
N_+USBP2 (64)
N_-USBP2 (64)
N_+USBP1 (61)
N_-USBP1 (61)
N_+USBP0 (61)
N_-USBP0 (61)

NR146 22/4
NR147 22/4
NR148 22/4

NR149 22/4 NR16

N_GPIO67

NR150 22/4

N_GPIO66

A_DMI_3RXNA_DMI_3TXN

A_DMI_2RXP

A_DMI_2RXN

A_DMI_1RXP

A_DMI_1RXN

A_DMI_0RXP

A_DMI_0RXN

PK_PCIE_TP8 (25)
PK_PCIE_TN8 (25)
PJ_PCIE_TP7 (25)
PJ_PCIE_TN7 (25)
PI_PCIE_TP6 (25)
PI_PCIE_TN6 (25)

LC_ML_OP (58)

LC_ML_ON (58)

M2_WIFI_TP (47)

M2_WIFI_TN (47)

LB_ML_OP (59)

LB_ML_ON (59)

PCH_USB3_TXP3 (64)

PCH_USB3_TXN3 (64)

PCH_USB3_TXP2 (64)

PCH_USB3_TXN2 (64)

PCH_USB3_TXP5 (51)

PCH_USB3_TXN5 (51)

PCH_USB3_TXP4 (49)

PCH_USB3_TXN4 (49)

PCH_USB3_TXP1 (61)

PCH_USB3_TXN1 (61)

PCH_USB3_TXP0 (61)

PCH_USB3_TXN0 (61)

KB/MS/USB

To WIFI

Front USB

Rear USB HUB

Front USB3.0

N_EC33 (42)
N_PCH33 (15)
N_LPC33 (28)

N_LPCCLK48 (28)
EC_LPCCLK48 (42)

PK_PCIE_CLK (25)
PK_-PCIE_CLK (25)
PJ_PCIE_CLK (25)
PJ_-PCIE_CLK (25)
PI_PCIE_CLK (25)
PI_-PCIE_CLK (25)
LB_SRCCLK_LAN (59)
LB_-SRCCLK_LAN (59)
LC_SRCCLK_LAN (58)
LC_-SRCCLK_LAN (58)
CK_M2_100M_DP (48)
CK_M2_100M_DN (48)
CK_WIFI_100M_DP (47)
CK_WIFI_100M_DN (47)

N_BUF_REFCLK (27)
N_-BUF_REFCLK (27)

3

A_DMI_3RXP (8)

A_DMI_3RXN (8)

A_DMI_2RXP (8)

A_DMI_2RXN (8)

A_DMI_1RXP (8)

A_DMI_1RXN (8)

A_DMI_0RXP (8)

A_DMI_0RXN (8)

2

NX1

25M/16p/30ppm/49US/20/D

NC34

20p/4/NPO/50V/J

XTALO_PCHDMI_PCH_T1N

2

NR15
1M/4

NC35

20p/4/NPO/50V/J

N

_PGDMON

NR72
1K/4/1/X

Title

Size Document Number Rev

Custom

Date: Sheet of

1

N_SRCCLK_CPY
N_-SRCCLK_CPYXTALI_PCH

N_SRCCLK_SATA
N_-SRCCLK_SATA

N_SRCCLK_SAS
N_-SRCCLK_SAS

N_DOT96_CLK
N_-DOT96_CLK
N_SRCCLK_DMI
N_-SRCCLK_DMI

PCH_HS

2

PCH_HS/HEAT SINK/X99-UD5 WIFI/KG[12SP2-PTX995-01R]

NR152 8.2K/4WBC44 0.1u/4/X7R/16V/K
NR153 8.2K/4WBC51 0.1u/4/X7R/16V/K

NR154 8.2K/4
NR155 8.2K/4

NR156 8.2K/4
NR157 8.2K/4

NR158 8.2K/4
NR159 8.2K/4
NR160 8.2K/4
NR161 8.2K/4

1

󱭣󱭣󱭣󱭣󳺃󳺃󳺃󳺃󲓢󲓢󲓢󲓢󴖨󴖨󴖨󴖨󶁜󶁜󶁜󶁜󱻎󱻎󱻎󱻎󴣘󴣘󴣘󴣘󲞅󲞅󲞅󲞅󳠃󳠃󳠃󳠃󴧖󴧖󴧖󴧖,󲙈󲙈󲙈󲙈󳑱󳑱󳑱󳑱󲓢󲓢󲓢󲓢󱂑󱂑󱂑󱂑󰵓󰵓󰵓󰵓

WBG_X_PCH_EDS

AH46

V6
V7

AG10

AG9
BA7

AW7
AW6

BA6

3VDUAL_PCH

PCHG

NCTF/TP
NCTF/TP

NCTF/TP
NCTF/TP

NCTF/TP
NCTF/TP

NCTF/TP
RESERVED

RESERVED

7 OF 10

At least 10ms delay after
3VDUAL_PCH stabel

8.2K/4

NC17
1n/4/X7R/50V/K

BD7

NCTF/TP

BC7

NCTF/TP

N14

NCTF/TP

N15

NCTF/TP

BA34

NCTF/TP

BC34

NCTF/TP

BH45

NCTF/TP

BJ45

NCTF/TP

N49

NCTF/TP

N_PCH_DPWROK (15,28)

Eup from PCH

Gigabyte Technology

PCH DISPLAY ,CLK BUFFER

GA-X99-UD5 WIFI

17 64Tuesday, August 26, 2014

1

1.0

5

VCC1_05_ME

VCCCLK

D D

1u/4/X5R/6.3V/K

C C

1u/4/X5R/6.3V/K

1u/4/X5R/6.3V/K

B B

NC143

NC120

NC136

1u/4/X5R/6.3V/K

VCCCLK

1u/4/X5R/6.3V/K

VCC3

NC20

VCC1_05_WBG

0.1u/4/X7R/16V/K

1u/4/X5R/6.3V/K

1u/4/X5R/6.3V/K

VCC3_GATED

NC125

1u/4/X5R/6.3V/K

NC135

NC128

VCC3

NC18

VCC3

NC36

1u/4/X5R/6.3V/K

NC132

NO_VCC_XCK_DCB

NC126

1u/4/X5R/6.3V/K

VCC1_05_WBG

NR1625.1/4/1

VCCCLK

NO_DMIPLL
NO_SATA3IPLL
NO_SATAIPLL

NO_USBPLL

NO_VCC_XCK_VRM

NR163 0/4/SHT/20/X

VCC1_05_WBG

AA26
AA27
AA29
AC26
AC27
AC29

W29

AP24

AG29

AJ29
AU18
AA21

AA23
AA24
AC21
AC23
AC24
AF21
AF23
AF24
AF26
AF27

AG21
AG23
AG24
AG26
AG27

AL18
AL19
AL24
AL26
AL27

W21

AC31
AF29
AF31

AG31

AL21
AL23

AU21
AU23

AP36

AC15
AU29

AV29
AP27
AP29

AU15

AU27
AV27

AT46

NC30

0.1u/4/X7R/16V/K

J27
T27
V26
V27
V29

T21
T23
V21
V23

N29

AA9

N9

PCHH

VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW

VCCCLK
VCCAUSBPLL

VCCAUSBPLL
VCCCLK
VCC

VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC

DCPSUSBYP
VCC

VCC
VCC
VCC

VCCCLK
VCCCLK

VCCCLK
VCCCLK

VCCVRM
VCCVRM
VCCVRM

VCCVRM
VCCCLK3_3

VCCCLK3_3
VCCCLK3_3
VCCCLK3_3

VCCVRM

VCCCLK3_3
VCCCLK3_3

VCCST3_3

WBG_X_PCH_EDS

8 OF 10

V_PROC_IO
V_PROC_IO

VCCCLK
VCCCLK

VCCCLK
DCPSUS1
DCPSUS2

VCCIO
V

CCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO

VCCSUSHDA

VCC3_3
VCC3_3
VCC3_3
VCC3_3

VCCASW
VCCASW
VCCASW

VCCDSW3_3

VCC3_3

VCCRTC

VCCSUS3_3

VCCSPI

VCCSUS3_3
VCCSUS3_3

VCCST3_3

VCCSUS3_3
VCCSUS3_3

DCPSST

DCPSUS3
DCPSUS3

VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3

VCCCLK3_3
VCCCLK3_3

VCCCLK
VCCCLK

VCCVRM
VCCVRM

DCPRTC

L18
AP26

AM23
AP23

AP21
T29
AC35
AA12

AA18
AA19
AG18
AG19
AJ18
N12
T18
T19
V18
V19
V9

AG38
J25

T24
V24
AP32

V31
V32
Y35

T32
T31
N38
T35
T26
AA31

AA32

AJ15
AC18

AC19

N27
AF18

AF19
AC32

AF32
AG32
AJ32

AU32
AV32

AM24
AM26

AP18
AP19

AL29

VCC

AL31

VCC

AL32

VCC

AW34

VCC

N35

VCCCLK

NTP3
NTP1

VCC1_05_WBG

3VDUAL

VCC3
VCC3

VCC1_05_ME

3VDUAL_PCH
VCC3

N_RTCVDD

3VDUAL

NR164 0/4/SHT/20/X

3VDUAL

N_VCCSST

3VDUAL

VCC3

VCCCLK

VCC15_PLL

VCC1_05_WBG

N_VCCRTCEXT

4

VCCCLK

VCCIO

VCCCLK

1u/4/X5R/6.3V/K

NC47 1u/4/X5R/6.3V/K

Change to 3VDUAL from 3VDUAL_PCH by
INTEL , rev 1.0 should update.

NC1

1u/4/X5R/6.3V/K

VCC3_ME

NC37 1u/4/X5R/6.3V/K

3VDUAL

NC121 1u/4/X5R/6.3V/K

VCC3_GATED

NC118 1u/4/X5R/6.3V/K

NTP11

NSBC1

0.1u/4/X7R/16V/K

1
3 4
5 6
7 8

NRN10 MASK/0/8P4R/0402/SHT/X

NC145

NSBC2

0.1u/4/X7R/16V/K

NC21

1u/4/X5R/6.3V/K

2

1u/4/X5R/6.3V/K

NBC54

VCC1_05_WBG

3

VCC1_05_WBG

VCC1_05_WBG

VCC1_05_WBG

VCC1_05_WBG

VCC1_05_WBG

VCC1_05_WBG

N_VCC_XCK_DCB

VCC15_PLL

N_VCC_XCK_VRM

VCC15_PLL

N_USBPLL NO_USBPLL

VCC15_PLL

VCC15_PLL

N_SATAIPLL

VCC15_PLL

N_SATA3IPLL

VCC15_PLL

NL3

30/4/4A/S

NL6

30/4/4A/S/X

NL1

30/4/4A/S/X

NL5

30/4/4A/S/X

NL4

30/4/4A/S/X

NL2

30/4/4A/S/X

NR1670/4/SHT/20/X

NR1720/4/X

NR1730/4/X

NR1740/4/SHT/20/X

NR1750/4/X

NR1760/4/SHT/20/X

NR1770/4/X

NR1780/4/SHT/20/X

NR1790/4/X

NR1800/4/SHT/20/X

NR1810/4/X

NR2480/4/SHT/20/X

NR1650/4/SHT/20/X
NC38

22u/8/X5R/6.3V/M

NR1660/4/X

NC48

22u/8/X5R/6.3V/M/X

N_USBPLL

NC59

22u/8/X5R/6.3V/M/X

N_DMIPLL

NC60

22u/8/X5R/6.3V/M/X

N_SATAIPLL

NC61

22u/8/X5R/6.3V/M/X

N_SATA3IPLL

NC63

22u/8/X5R/6.3V/M/X

NO_VCC_XCK_DCB

NO_VCC_XCK_VRM

NO_DMIPLLN_DMIPLL

NO_SATAIPLL

NO_SATA3IPLL

N_VCC_XCK_DCB

NC133

1u/4/X5R/6.3V/K

N_VCC_XCK_VRM

NC131

1u/4/X5R/6.3V/K/X

NC116

NC129

NC127

NC142

1u/4/X5R/6.3V/K/X

1u/4/X5R/6.3V/K/X

1u/4/X5R/6.3V/K/X

1u/4/X5R/6.3V/K/X

2

VCC3

VCC3_ME

NBC53

1u/4/X5R/6.3V/K

VCC1_05_ME

1 2
3 4
5 6
7 8

NRN6

0/8P4R/6/X

1 2
3 4
5 6
7 8

NRN8

0/8P4R/6/X

VCC3

VCC1_05_WBG

VCC3

NC26

1u/4/X5R/6.3V/K

3VDUAL_PCH

VCC3

NC19

0.1u/4/X7R/16V/K

NQ10
L1117LG/N/SOT223/1A

301/4/1

NC66

0.1u/4/X7R/16V/K

0.1u/4/X7R/16V/K

NR113

NC50

1

22u/8/X5R/6.3V/M

234
1

NC65

NR114
510/4/1

NC45

0.1u/4/X7R/16V/K

VCC3

NC74

0.1u/4/X7R/16V/K

3VDUAL

NC81

NC139

0.1u/4/X7R/16V/K

0.1u/4/X7R/16V/K

VCC15_PLL 3VDUAL_PCH VCC3_ME

VCC15_PLL

NC140

1u/4/X5R/6.3V/K

NC107

0.1u/4/X7R/16V/K

NC55

0.1u/4/X7R/16V/K

3VDUAL_PCH

NC108

0.1u/4/X7R/16V/K

0.1u/4/X7R/16V/K

NC54

NC40

0.1u/4/X7R/16V/K

NC109

1u/4/X5R/6.3V/K

VCC1_05_WBG

NC111

10u/6/X5R/6.3V/M

NC146

1u/4/X5R/6.3V/K

NC122

1u/4/X5R/6.3V/K

NC117

1u/4/X5R/6.3V/K

NC141

1u/4/X5R/6.3V/K

NC112

10u/6/X5R/6.3V/M

1u/4/X5R/6.3V/K

NC64

3VDUAL_PCH

NC68

1u/4/X5R/6.3V/K

NC67

22u/8/X5R/6.3V/M

22u/8/X5R/6.3V/M

0.1u/4/X7R/16V/K

VCC3_ME

VCC1_05_WBG

NC123

VCC1_05_WBG

5VSB

NC72

NC78

0.1u/4/X7R/16V/K

3VDUAL

NC82

0.1u/4/X7R/16V/K

NC110

1u/4/X5R/6.3V/K

NC119

1u/4/X5R/6.3V/K

NC130

NC113

1u/4/X5R/6.3V/K

10u/6/X5R/6.3V/M

VCC1_05_ME

N_DSWODVREN
N_RTCVDD
N_INTVRMEN
N_-RTCRST

NC42

1u/4/X5R/6.3V/K

1u/4/X5R/6.3V/KNC43

N_-SRTCRST (16)
N_DSWODVREN (16)
N_RTCVDD (16,41)
N_INTVRMEN (16)
N_-RTCRST (16,44,57)

CLR_CMOS

PH/1*2/BK/2.54/VA/D

NR112
0/4/SHT/X

VCCIOA

N_-RTCRST (16,44,57)

2

2
1

BAT

ND1

N_VBAT

NR91 20K/4/1

󱡟󱡟󱡟󱡟

NR90 390K/4

NR99 390K/4
NR89 20K/4/1

3

NC49
1u/4/X5R/6.3V/K

N_VBAT (28,42)

3

RB

+

3VDUAL_PCH

RB 1K/4/1

󱼎󱼎󱼎󱼎󵝑󵝑󵝑󵝑󲒇󲒇󲒇󲒇󱙱󱙱󱙱󱙱

BAS40-05/0.2A/SOT23

RB_TP

BATTERY
CR2032

CR2032

N_VBATT

A A

5

4

BAT

BAT-SK/BK/P/S/D/SN

12

NC114

0.1u/4/X7R/16V/K

NC115

NC124

0.1u/4/X7R/16V/K

22u/8/X5R/6.3V/M

VCC1_05_ME

NC163
10u/6/X5R/6.3V/M

VCCIO

NC182
22u/8/X5R/6.3V/M

Title

Size Document Number Rev

Custom

Date: Sheet of

NC134
22u/8/X5R/6.3V/M

NC144
22u/8/X5R/6.3V/M

NC9
22u/8/X5R/6.3V/M

1u/4/X5R/6.3V/K

0.1u/4/X7R/16V/K

Gigabyte Technology

PCH PWR ,GND

GA-X99-UD5 WIFI

1

NC137
22u/8/X5R/6.3V/M

NC165

NC11

22u/8/X5R/6.3V/M

NC166

1u/4/X5R/6.3V/K

NC10

0.1u/4/X7R/16V/K

18 64Tuesday, August 26, 2014

NC138

1.0

5

WBG_X_PCH_EDS

WBG_X_PCH_EDS

PCHI

AT41

VSS

AT44

VSS

AT48

VSS

AT6

VSS

AT9

VSS

AU1

VSS

AU14

D D

C C

B B

A A

AU3
AU35
AU36
AU38
AU40
AU41
AU49

AU9

AV18
AV20
AV21
AV23
AV25
AV30

AW1
AW16
AW18
AW21
AW27
AW29

AW3
AW38
AW43
AW47
AW49

B22

BA1
BA14
BA16
BA20
BA21
BA25
BA27
BA29

BA3
BA30
BA32
BA36
BA38
BA41
BA43
BA47
BA49

BA9

BC12
BC27

BC3

AJ3
AJ31
AJ38

AJ6

AJ7

AJ9
AK12
AK15
AK35
AK38
AK41
AK44
AK46

AK6
AK9
AL1
AL3

AL49

AM14
AM15
AM18
AM19
AM21
AM27
AM29
AM31
AM32

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
V
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

9 OF 10

SS

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

BC39
BC44
BC47
BC49
BD12
BD14
BD18
BD20
BD25
BD27
BD30
BD34
BD36
BD39
BD41
BD44
BD6
BD9
BF18
BF4
BF44
BF46
BF48
BG11
BG13
BG15
BG17
BG19
BG21
BG23
BG25
BG27
BG29
BG31
BG33
BG35
BG37
BG39
BG41
BG43
BG7
BG9
BH18
BH4
BJ11
BJ13
BJ15
BJ19
BJ23
BJ25
BJ31
BJ35
BJ39
BJ41
BJ43
BJ7
BJ9
C11
C13
C15
C17
C19
AM38
AM9
AN1
AN3
AP10
AP15
AP31
AP35
AP38
AP46
AP6
AR1
AR3
AR49
AT12
AT15
AT35
AT38
AJ27

L1117LG/N/SOT223/1A

5

PCHJ

AA1

AA10

AA3
AA43
AA44
AB46
AC10

AC3
AC49

AC6
AD18
AD19
AD21
AD23
AD24
AD26
AD27
AD29
AD31
AD32

AE1
AE12
AE15

AE3
AE35
AE38
AE41
AE44

AE6

AE9
AF46

AG1

AG3
AG47
AG49
AH48

AJ1
AJ10
AJ12
AJ14
AJ19
AJ21
AJ23
AJ24
AJ26

L49

M20
M25
M30
M32

N32

P12

P15

P35

P38

P41

P44

P46

R49

T10

AU47

A45

A46

A48

B48

B49

BC1
BE1

BE49

BF1

BF49

BH1

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

10 OF 10

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

L3

VSS
VSS

L7

VSS
VSS
VSS
VSS
VSS

N1

VSS

N3

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

P6

VSS

P9

VSS

R1

VSS

R3

VSS
VSS
VSS

VSS

A4

VSS
VSS
VSS
VSS

A5

VSS

A7

VSS

B2

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

VSS
V
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

4

A11
A15

SS

A19
A23
A27
A29
A31
A35
A39
A43
C21
C23
C7
C9
D22
D24
D28
D32
D36
D40
D44
F14
F16
F20
F23
F25
F30
F36
F41
F46
F9
G16
G3
G49
J1
J14
J20
J3
J30
J36
J41
J9
K46
L1
Y12
Y15
Y38
Y41
Y44
Y6
Y9
U1
U3
U47
V14
V46
W1
W18
W19
W23
W24
W26
W27
W3
W31
W32
W47
W49
T48
T6

G1
BH2
BH48
BH49
BJ2
BJ4
BJ46
BJ48
BJ5
D1
D2
D49
E1
E49

4

3

3

2

Title

Size Document Number Rev

Custom

2

Date: Sheet of

Gigabyte Technology

PCH PWR ,GND

GA-X99-UD5 WIFI

1

1.0

19 64Tuesday, August 26, 2014

1

8

7

6

5

4

3

2

1

PCIESLOT-164DN-2

+12V

B1

B10
B11

B12
B13
B14
B15
B16
B17
B18

B19
B20
B21
B22
B23
B24
B25
B26
B27
B28
B29
B30
B31
B32

B33
B34
B35
B36
B37
B38
B39
B40
B41
B42
B43
B44
B45
B46
B47
B48
B49

B50
B51
B52
B53
B54
B55
B56
B57
B58
B59
B60
B61
B62
B63
B64
B65
B66
B67
B68
B69
B70
B71
B72
B73
B74
B75
B76
B77
B78
B79
B80
B81
B82

B2
B3
B4
B5
B6
B7
B8
B9

D D

N_-PCIE_WAKE(16,21,23,24,25,47,58)

N_SMBCLK(16,21,23,24,25,26,27,30,34,35,37,42,47,58)

N_SMBDATA(16,21,23,24,25,26,27,30,34,35,37,42,47,58)

PB_EXP_B_TXP15C
PB_EXP_B_TXN15C

PB_EXP_B_TXP13C
PB_EXP_B_TXN13C

PB_EXP_B_TXP12C
PB_EXP_B_TXN12C

PB_EXP_B_TXN11C

PB_EXP_B_TXP10C
PB_EXP_B_TXN10C

PB_EXP_B_TXP9C
PB_EXP_B_TXN9C

PB_EXP_B_TXP8C
PB_EXP_B_TXN8C

PB_EXP_B1_TXP7C
PB_EXP_B1_TXN7C

PB_EXP_B1_TXP6C
PB_EXP_B1_TXN6C

PB_EXP_B1_TXP5C
PB_EXP_B1_TXN5C

PB_EXP_B1_TXP4C
PB_EXP_B1_TXN4C

PB_EXP_B1_TXP3C
PB_EXP_B1_TXN3C

PB_EXP_B1_TXP2C
PB_EXP_B1_TXN2C

PB_EXP_B1_TXP1C
PB_EXP_B1_TXN1C

PB_EXP_B1_TXP0C
PB_EXP_B1_TXN0C

PB_EXP_B_TXP14C
PB_EXP_B_TXN14C

PB_EXP_B_TXP11C

PCIEX16_1_DET

+12V

1

+

270u/FP/D/16V/88/C/12m

C C

B B

A A

PBEC1

PB_EXP_B1_TXP0
PB_EXP_B1_TXN0
PB_EXP_B1_TXP1

PB_EXP_B1_TXP2
PB_EXP_B1_TXN2
PB_EXP_B1_TXP3
PB_EXP_B1_TXN3
PB_EXP_B1_TXP4
PB_EXP_B1_TXN4
PB_EXP_B1_TXP5
PB_EXP_B1_TXN5
PB_EXP_B1_TXP6
PB_EXP_B1_TXN6
PB_EXP_B1_TXP7
PB_EXP_B1_TXN7

PB_EXP_B_TXP8
PB_EXP_B_TXN8
PB_EXP_B_TXP9
PB_EXP_B_TXN9
PB_EXP_B_TXP10
PB_EXP_B_TXN10
PB_EXP_B_TXP11
PB_EXP_B_TXN11
PB_EXP_B_TXP12
PB_EXP_B_TXN12
PB_EXP_B_TXP13
PB_EXP_B_TXN13
PB_EXP_B_TXP14
PB_EXP_B_TXN14
PB_EXP_B_TXP15
PB_EXP_B_TXN15

PB_EXP_B_RXP[8..15]
PB_EXP_B_RXN[8..15]

PB_EXP_B_TXP[8..15]
PB_EXP_B_TXN[8..15]

PB_EXP_B1_RXP[0..7]
PB_EXP_B1_RXN[0..7]

PB_EXP_B1_TXP[0..7]
PB_EXP_B1_TXN[0..7]

PBC1

0.1u/4/X7R/16V/K

PBC2 0.22u/4/X5R/6.3V/K
PBC3 0.22u/4/X5R/6.3V/K
PBC4 0.22u/4/X5R/6.3V/K
PBC5 0.22u/4/X5R/6.3V/K
PBC6 0.22u/4/X5R/6.3V/K
PBC7 0.22u/4/X5R/6.3V/K
PBC8 0.22u/4/X5R/6.3V/K
PBC9 0.22u/4/X5R/6.3V/K
PBC10 0.22u/4/X5R/6.3V/K
PBC11 0.22u/4/X5R/6.3V/K
PBC12 0.22u/4/X5R/6.3V/K
PBC13 0.22u/4/X5R/6.3V/K
PBC14 0.22u/4/X5R/6.3V/K
PBC15 0.22u/4/X5R/6.3V/K
PBC16 0.22u/4/X5R/6.3V/K
PBC17 0.22u/4/X5R/6.3V/K

PBC18 0.22u/4/X5R/6.3V/K
PBC19 0.22u/4/X5R/6.3V/K
PBC20 0.22u/4/X5R/6.3V/K
PBC21 0.22u/4/X5R/6.3V/K
PBC22 0.22u/4/X5R/6.3V/K
PBC23 0.22u/4/X5R/6.3V/K
PBC24 0.22u/4/X5R/6.3V/K
PBC25 0.22u/4/X5R/6.3V/K
PBC26 0.22u/4/X5R/6.3V/K
PBC27 0.22u/4/X5R/6.3V/K
PBC28 0.22u/4/X5R/6.3V/K
PBC29 0.22u/4/X5R/6.3V/K
PBC31 0.22u/4/X5R/6.3V/K
PBC32 0.22u/4/X5R/6.3V/K
PBC37 0.22u/4/X5R/6.3V/K
PBC35 0.22u/4/X5R/6.3V/K

VCC3+12V

1

+

PBEC2

560u/FP/D/6.3V/68/C/8m

PB_EXP_B1_TXP0C
PB_EXP_B1_TXN0C
PB_EXP_B1_TXP1C
PB_EXP_B1_TXN1CPB_EXP_B1_TXN1
PB_EXP_B1_TXP2C
PB_EXP_B1_TXN2C
PB_EXP_B1_TXP3C
PB_EXP_B1_TXN3C
PB_EXP_B1_TXP4C
PB_EXP_B1_TXN4C
PB_EXP_B1_TXP5C
PB_EXP_B1_TXN5C
PB_EXP_B1_TXP6C
PB_EXP_B1_TXN6C
PB_EXP_B1_TXP7C
PB_EXP_B1_TXN7C

PB_EXP_B_TXP8C
PB_EXP_B_TXN8C
PB_EXP_B_TXP9C
PB_EXP_B_TXN9C
PB_EXP_B_TXP10C
PB_EXP_B_TXN10C
PB_EXP_B_TXP11C
PB_EXP_B_TXN11C
PB_EXP_B_TXP12C
PB_EXP_B_TXN12C
PB_EXP_B_TXP13C
PB_EXP_B_TXN13C
PB_EXP_B_TXP14C
PB_EXP_B_TXN14C
PB_EXP_B_TXP15C
PB_EXP_B_TXN15C

PB_EXP_B_RXP[8..15] (8)
PB_EXP_B_RXN[8..15] (8)

PB_EXP_B_TXP[8..15] (8)
PB_EXP_B_TXN[8..15] (8)

PB_EXP_B1_RXP[0..7] (22)
PB_EXP_B1_RXN[0..7] (22)

PB_EXP_B1_TXP[0..7] (22)
PB_EXP_B1_TXN[0..7] (22)

PCIEX16_1_DET(15)

PBR1 0/4/SHT/X

N_SMBCLK
N_SMBDATA

3VDUAL

VCC3

N_-PCIE_WAKE

PCIE_1

12V
1

2V
RSVD
GND
SMCLK
SMDAT
GND

3.3V
JTAG1

3.3VAUX
WAKE*

RSVD
GND
HSOP0
HSON0
GND
PRSNT2*
GND

HSOP1
HSON1
GND
GND
HSOP2
HSON2
GND
GND
HSOP3
HSON3
GND
RSVD
PRSNT2*
GND

HSOP4
HSON4
GND
GND
HSOP5
HSON5
GND
GND
HSOP6
HSON6
GND
GND
HSOP7
HSON7
GND
PRSNT2*
GND

HSOP8
HSON8
GND
GND
HSOP9
HSON9
GND
GND
HSOP10
HSON10
GND
GND
HSOP11
HSON11
GND
GND
HSOP12
HSON12
GND
GND
HSOP13
HSON13
GND
GND
HSOP14
HSON14
GND
GND
HSOP15
HSON15
GND
PRSNT2*
RSVD

3GIO_*16

KEY

PRSNT1*

12V
12V

GND
JTAG2
JTAG3
JTAG4
JTAG5

3.3V

3.3V

PWRGD

GND

REFCLK+

REFCLK-

GND

HSIP0
HSIN0

GND

RSVD

GND

HSIP1
HSIN1

GND

GND

HSIP2
HSIN2

GND

GND

HSIP3
HSIN3

GND

RSVD
RSVD

GND

HSIP4
HSIN4

GND

GND

HSIP5
HSIN5

GND

GND

HSIP6
HSIN6

GND

GND

HSIP7
HSIN7

GND

RSVD

GND

HSIP8
HSIN8

GND

GND

HSIP9
HSIN9

GND

GND

HSIP10

HSIN10

GND

GND

HSIP11

HSIN11

GND

GND

HSIP12

HSIN12

GND

GND

HSIP13

HSIN13

GND

GND

HSIP14

HSIN14

GND

GND

HSIP15

HSIN15

GND

A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11

A12
A13
A14
A15
A16
A17
A18

A19
A20
A21
A22
A23
A24
A25
A26
A27
A28
A29
A30
A31
A32

A33
A34
A35
A36
A37
A38
A39
A40
A41
A42
A43
A44
A45
A46
A47
A48
A49

A50
A51
A52
A53
A54
A55
A56
A57
A58
A59
A60
A61
A62
A63
A64
A65
A66
A67
A68
A69
A70
A71
A72
A73
A74
A75
A76
A77
A78
A79
A80
A81
A82

+12V

VCC3

PCIE_X16_X8_RST

PB_EXP_B_RXP15
PB_EXP_B_RXN15

PB_EXP_B_RXP14
PB_EXP_B_RXN14

PB_EXP_B_RXP13
PB_EXP_B_RXN13

PB_EXP_B_RXP12
PB_EXP_B_RXN12

PB_EXP_B_RXP11
PB_EXP_B_RXN11

PB_EXP_B_RXP10
PB_EXP_B_RXN10

PB_EXP_B_RXP9
PB_EXP_B_RXN9

PB_EXP_B_RXP8
PB_EXP_B_RXN8

PB_EXP_B1_RXP7
PB_EXP_B1_RXN7

PB_EXP_B1_RXP6
PB_EXP_B1_RXN6

PB_EXP_B1_RXP5
PB_EXP_B1_RXN5

PB_EXP_B1_RXP4
PB_EXP_B1_RXN4

PB_EXP_B1_RXP3
PB_EXP_B1_RXN3

PB_EXP_B1_RXP2
PB_EXP_B1_RXN2

PB_EXP_B1_RXP1
PB_EXP_B1_RXN1

PB_EXP_B1_RXP0
PB_EXP_B1_RXN0

PBR2

0/4/SHT/X

PB_SRCCLK (27)
PB_-SRCCLK (27)

PCIE_X16_X8_RST

PCIE_X16_X8_RST (15,21,23,24)

PBC33

0.1u/4/X7R/16V/K

PBC34

0.1u/4/X7R/16V/K

PBC30
22p/4/NPO/50V/J

PBC36

0.1u/4/X7R/16V/K

VCC3

PBC38

0.1u/4/X7R/16V/K

3VDUAL

PBC39

0.1u/4/X7R/16V/K

11AC1-023164-A1R

PCI-E/16X-164P/BK/LONG DOUBLE/[11AC1-023164-A1R]

8

7

6

5

4

3

Title

Size Document Number Rev
Custom

Date: Sheet of

2

Gigabyte Technology

PCI EXPRESS X16 PORT_2

GA-X99-UD5 WIFI

20 64Tuesday, August 26, 2014

1

1.0

8

7

6

5

4

3

2

1

PCIESLOT-164DN-2

+12V

B1

B10
B11

B12
B13
B14
B15
B16
B17
B18

B19
B20
B21
B22
B23
B24
B25
B26
B27
B28
B29
B30
B31
B32

B33
B34
B35
B36
B37
B38
B39
B40
B41
B42
B43
B44
B45
B46
B47
B48
B49

B50
B51
B52
B53
B54
B55
B56
B57
B58
B59
B60
B61
B62
B63
B64
B65
B66
B67
B68
B69
B70
B71
B72
B73
B74
B75
B76
B77
B78
B79
B80
B81
B82

B2
B3
B4
B5
B6
B7
B8
B9

D D

N_-PCIE_WAKE(16,20,23,24,25,47,58)

N_SMBCLK(16,20,23,24,25,26,27,30,34,35,37,42,47,58)

N_SMBDATA(16,20,23,24,25,26,27,30,34,35,37,42,47,58)

PA_EXP_A_TXP0C
PA_EXP_A_TXN0C

PA_EXP_A_TXP1C
PA_EXP_A_TXN1C

PA_EXP_A_TXP2C
PA_EXP_A_TXN2C

PA_EXP_A_TXP3C
PA_EXP_A_TXN3C

PA_EXP_A_TXP4C
PA_EXP_A_TXN4C

PA_EXP_A_TXP5C
PA_EXP_A_TXN5C

PA_EXP_A_TXP6C
PA_EXP_A_TXN6C

PA_EXP_A_TXP7C
PA_EXP_A_TXN7C

PA_EXP_A_TXP8C
PA_EXP_A_TXN8C

PA_EXP_A_TXP9C
PA_EXP_A_TXN9C

PA_EXP_A_TXP10C
PA_EXP_A_TXN10C

PA_EXP_A_TXP11C
PA_EXP_A_TXN11C

PA_EXP_A_TXP12C
PA_EXP_A_TXN12C

PA_EXP_A_TXP13C
PA_EXP_A_TXN13C

PA_EXP_A_TXP14C
PA_EXP_A_TXN14C

PA_EXP_A_TXP15C
PA_EXP_A_TXN15C

PCIEX16_2_DET

+12V

1

+

270u/FP/D/16V/88/C/12m

C C

B B

A A

PAEC2

PA_EXP_A_TXP0
PA_EXP_A_TXN0
PA_EXP_A_TXP1
PA_EXP_A_TXN1 PA_EXP_A_TXN1C
PA_EXP_A_TXP2
PA_EXP_A_TXN2
PA_EXP_A_TXP3
PA_EXP_A_TXN3
PA_EXP_A_TXP4
PA_EXP_A_TXN4
PA_EXP_A_TXP5
PA_EXP_A_TXN5
PA_EXP_A_TXP6
PA_EXP_A_TXN6
PA_EXP_A_TXP7
PA_EXP_A_TXN7

PA_EXP_A_TXP8
PA_EXP_A_TXN8
PA_EXP_A_TXP9
PA_EXP_A_TXN9
PA_EXP_A_TXP10
PA_EXP_A_TXN10
PA_EXP_A_TXP11
PA_EXP_A_TXN11
PA_EXP_A_TXP12
PA_EXP_A_TXN12

PA_EXP_A_TXN13
PA_EXP_A_TXP14
PA_EXP_A_TXN14
PA_EXP_A_TXP15
PA_EXP_A_TXN15

PA_EXP_A_RXP[0..15]
PA_EXP_A_RXN[0..15]

PA_EXP_A_TXP[0..15]
PA_EXP_A_TXN[0..15]

+12V

PAC1

0.1u/4/X7R/16V/K

PAC3 0.22u/4/X5R/6.3V/K
PAC4 0.22u/4/X5R/6.3V/K
PAC5 0.22u/4/X5R/6.3V/K
PAC6 0.22u/4/X5R/6.3V/K
PAC7 0.22u/4/X5R/6.3V/K
PAC8 0.22u/4/X5R/6.3V/K
PAC9 0.22u/4/X5R/6.3V/K
PAC10 0.22u/4/X5R/6.3V/K

PAC11 0.22u/4/X5R/6.3V/K
PAC12 0.22u/4/X5R/6.3V/K
PAC13 0.22u/4/X5R/6.3V/K
PAC14 0.22u/4/X5R/6.3V/K
PAC15 0.22u/4/X5R/6.3V/K
PAC16 0.22u/4/X5R/6.3V/K
PAC17 0.22u/4/X5R/6.3V/K
PAC18 0.22u/4/X5R/6.3V/K

PAC19 0.22u/4/X5R/6.3V/K
PAC20 0.22u/4/X5R/6.3V/K
PAC21 0.22u/4/X5R/6.3V/K
PAC22 0.22u/4/X5R/6.3V/K
PAC23 0.22u/4/X5R/6.3V/K
PAC24 0.22u/4/X5R/6.3V/K
PAC25 0.22u/4/X5R/6.3V/K
PAC26 0.22u/4/X5R/6.3V/K
PAC27 0.22u/4/X5R/6.3V/K
PAC28 0.22u/4/X5R/6.3V/K
PAC29 0.22u/4/X5R/6.3V/K
PAC30 0.22u/4/X5R/6.3V/K
PAC31 0.22u/4/X5R/6.3V/K
PAC33 0.22u/4/X5R/6.3V/K
PAC34 0.22u/4/X5R/6.3V/K
PAC35 0.22u/4/X5R/6.3V/K

3VDUAL

PAC2

0.1u/4/X7R/16V/K

PA_EXP_A_RXP[0..15] (8)
PA_EXP_A_RXN[0..15] (8)

PA_EXP_A_TXP[0..15] (8)
PA_EXP_A_TXN[0..15] (8)

PA_EXP_A_TXP0C
PA_EXP_A_TXN0C
PA_EXP_A_TXP1C

PA_EXP_A_TXP2C
PA_EXP_A_TXN2C
PA_EXP_A_TXP3C
PA_EXP_A_TXN3C
PA_EXP_A_TXP4C
PA_EXP_A_TXN4C
PA_EXP_A_TXP5C
PA_EXP_A_TXN5C
PA_EXP_A_TXP6C
PA_EXP_A_TXN6C
PA_EXP_A_TXP7C
PA_EXP_A_TXN7C

PA_EXP_A_TXP8C
PA_EXP_A_TXN8C
PA_EXP_A_TXP9C
PA_EXP_A_TXN9C
PA_EXP_A_TXP10C
PA_EXP_A_TXN10C
PA_EXP_A_TXP11C
PA_EXP_A_TXN11C
PA_EXP_A_TXP12C
PA_EXP_A_TXN12C
PA_EXP_A_TXP13CPA_EXP_A_TXP13
PA_EXP_A_TXN13C
PA_EXP_A_TXP14C
PA_EXP_A_TXN14C
PA_EXP_A_TXP15C
PA_EXP_A_TXN15C

PCIEX16_2_DET(16)

3VDUAL

PAR1 0/4/SHT/X

N_SMBCLK
N_SMBDATA

VCC3

N_-PCIE_WAKE

PCIE_2

12V
1

2V
RSVD
GND
SMCLK
SMDAT
GND

3.3V
JTAG1

3.3VAUX
WAKE*

RSVD
GND
HSOP0
HSON0
GND
PRSNT2*
GND

HSOP1
HSON1
GND
GND
HSOP2
HSON2
GND
GND
HSOP3
HSON3
GND
RSVD
PRSNT2*
GND

HSOP4
HSON4
GND
GND
HSOP5
HSON5
GND
GND
HSOP6
HSON6
GND
GND
HSOP7
HSON7
GND
PRSNT2*
GND

HSOP8
HSON8
GND
GND
HSOP9
HSON9
GND
GND
HSOP10
HSON10
GND
GND
HSOP11
HSON11
GND
GND
HSOP12
HSON12
GND
GND
HSOP13
HSON13
GND
GND
HSOP14
HSON14
GND
GND
HSOP15
HSON15
GND
PRSNT2*
RSVD

3GIO_*16

KEY

PRSNT1*

12V
12V

GND
JTAG2
JTAG3
JTAG4
JTAG5

3.3V

3.3V

PWRGD

GND

REFCLK+

REFCLK-

GND

HSIP0
HSIN0

GND

RSVD

GND

HSIP1
HSIN1

GND

GND

HSIP2
HSIN2

GND

GND

HSIP3
HSIN3

GND

RSVD
RSVD

GND

HSIP4
HSIN4

GND

GND

HSIP5
HSIN5

GND

GND

HSIP6
HSIN6

GND

GND

HSIP7
HSIN7

GND

RSVD

GND

HSIP8
HSIN8

GND

GND

HSIP9
HSIN9

GND

GND

HSIP10

HSIN10

GND

GND

HSIP11

HSIN11

GND

GND

HSIP12

HSIN12

GND

GND

HSIP13

HSIN13

GND

GND

HSIP14

HSIN14

GND

GND

HSIP15

HSIN15

GND

A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11

A12
A13
A14
A15
A16
A17
A18

A19
A20
A21
A22
A23
A24
A25
A26
A27
A28
A29
A30
A31
A32

A33
A34
A35
A36
A37
A38
A39
A40
A41
A42
A43
A44
A45
A46
A47
A48
A49

A50
A51
A52
A53
A54
A55
A56
A57
A58
A59
A60
A61
A62
A63
A64
A65
A66
A67
A68
A69
A70
A71
A72
A73
A74
A75
A76
A77
A78
A79
A80
A81
A82

+12V

VCC3

PCIE_X16_X8_RST

PA_EXP_A_RXP0
PA_EXP_A_RXN0

PA_EXP_A_RXP1
PA_EXP_A_RXN1

PA_EXP_A_RXP2
PA_EXP_A_RXN2

PA_EXP_A_RXP3
PA_EXP_A_RXN3

PA_EXP_A_RXP4
PA_EXP_A_RXN4

PA_EXP_A_RXP5
PA_EXP_A_RXN5

PA_EXP_A_RXP6
PA_EXP_A_RXN6

PA_EXP_A_RXP7
PA_EXP_A_RXN7

PA_EXP_A_RXP8
PA_EXP_A_RXN8

PA_EXP_A_RXP9
PA_EXP_A_RXN9

PA_EXP_A_RXP10
PA_EXP_A_RXN10

PA_EXP_A_RXP11
PA_EXP_A_RXN11

PA_EXP_A_RXP12
PA_EXP_A_RXN12

PA_EXP_A_RXP13
PA_EXP_A_RXN13

PA_EXP_A_RXP14
PA_EXP_A_RXN14

PA_EXP_A_RXP15
PA_EXP_A_RXN15

PAR2

0/4/SHT/X

PA_SRCCLK (27)
PA_-SRCCLK (27)

PCIE_X16_X8_RST

PAC32
22p/4/NPO/50V/J

PCIE_X16_X8_RST (15,20,23,24)

VCC3

PAC36

0.1u/4/X7R/16V/K

VCC3

1

+

PAEC1

560u/FP/D/6.3V/68/C/8m

PAC37

0.1u/4/X7R/16V/K

PAC40

0.1u/4/X7R/16V/K

PAC41

0.1u/4/X7R/16V/K

Title

PCI-E/16X-164P/BK/LONG DOUBLE/[11AC1-023164-A1R]

8

7

6

5

4

3

Size Document Number Rev
Custom

Date: Sheet of

2

Gigabyte Technology

PCI EXPRESS X16 PORT_1

GA-X99-UD5 WIFI

21 64Tuesday, August 26, 2014

1

1.0

8

VCC3

PBBC1

0.1u/4/X7R/16V/K

D D

PBR4

8.2K/4

PE_16_8_SWB(23)

C C

PBBC4

0.1u/4/X7R/16V/K

B B

VCC3

PBR3

8.2K/4

0.1u/4/X7R/16V/K

PB_EXP_B_RXN0
PB_EXP_B_RXP0

PB_EXP_B_TXN0
PB_EXP_B_TXP0

PB_EXP_B_RXN1
PB_EXP_B_RXP1

PB_EXP_B_TXN1
PB_EXP_B_TXP1

PCIE_16_SWB

MMBT2222A/SOT23/600mA/40

132

VCC3

PBBC5

0.1u/4/X7R/16V/K

PB_EXP_B_RXN2
PB_EXP_B_RXP2

PB_EXP_B_TXN2
PB_EXP_B_TXP2

PB_EXP_B_RXN3
PB_EXP_B_RXP3

PB_EXP_B_TXP3

PI3PCIE3415ZHE/TQFN42[ 10TA1-084083-10R_10TA1-081480-10R]

PBQ1

SOT23

PCIE_16_SWB

7

PBU4

9

VDD

19

VDD

21

VDD

26

VDD

31

VDD

34

VDD

39

VDD

41

VDD

1

A0

2

A1

5

A2

6

A3

10

A4

11

A5

14

A6

15

A7

30

SEL

43

GNDPAD

PI3PCIE3415ZHE/TQFN42[ 10TA1-084083-10R_10TA1-081480-10R]

Function

A--> B

A--> C

PBU3

9

VDD

19

VDD

21

VDD

26

VDD

31

VDD

34

VDD

39

VDD

41

VDD

1

A0

2

A1

5

A2

6

A3

10

A4

11

A5

14

A6

15

A7

30

SEL

43

GNDPAD

SEL

GND
GND
GND
GND
GND
GND
GND
GND
GND

37

B0

36

B1

33

B2

32

B3

28

B4

27

B5

24

B6

23

B7

3

C0

4

C1

7

C2

8

C3

12

C4

13

C5

16

C6

17

C7

18

GND

20

GND

22

GND

25

GND

29

GND

35

GND

38

GND

40

GND

42

GND

L
H

37

B0

36

B1

33

B2

32

B3

28

B4

27

B5

24

B6

23

B7

3

C0

4

C1

7

C2

8

C3

12

C4

13

C5

16

C6

17

C7

18
20
22
25
29
35
38
40
42

6

PB_EXP_B1_RXN0
PB_EXP_B1_RXP0

PB_EXP_B1_TXN0
PB_EXP_B1_TXP0

PB_EXP_B1_RXN1
PB_EXP_B1_RXP1

PB_EXP_B1_TXN1
PB_EXP_B1_TXP1

PF_EXP_B2_RXN0
PF_EXP_B2_RXP0

PF_EXP_B2_TXN0
PF_EXP_B2_TXP0

PF_EXP_B2_RXN1
PF_EXP_B2_RXP1

PF_EXP_B2_TXN1
PF_EXP_B2_TXP1

PB_EXP_B1_RXN2
PB_EXP_B1_RXP2

PB_EXP_B1_TXN2
PB_EXP_B1_TXP2

PB_EXP_B1_RXN3
PB_EXP_B1_RXP3

PB_EXP_B1_TXN3
PB_EXP_B1_TXP3

PF_EXP_B2_RXN2
PF_EXP_B2_RXP2

PF_EXP_B2_TXN2
PF_EXP_B2_TXP2

PF_EXP_B2_RXN3
PF_EXP_B2_RXP3

PF_EXP_B2_TXN3
PF_EXP_B2_TXP3

5

PF_EXP_B2_RXP[0..7]
PF_EXP_B2_RXN[0..7]

PF_EXP_B2_TXP[0..7]
PF_EXP_B2_TXN[0..7]

PB_EXP_B1_RXP[0..7]
PB_EXP_B1_RXN[0..7]

PB_EXP_B1_TXP[0..7]
PB_EXP_B1_TXN[0..7]

PB_EXP_B_RXP[0..7]
PB_EXP_B_RXN[0..7]

PB_EXP_B_TXP[0..7]
PB_EXP_B_TXN[0..7]

PF_EXP_B2_RXP[0..7] (23)
PF_EXP_B2_RXN[0..7] (23)

PF_EXP_B2_TXP[0..7] (23)
PF_EXP_B2_TXN[0..7] (23)

PB_EXP_B1_RXP[0..7] (20)
PB_EXP_B1_RXN[0..7] (20)

PB_EXP_B1_TXP[0..7] (20)
PB_EXP_B1_TXN[0..7] (20)

PB_EXP_B_RXP[0..7] (8)
PB_EXP_B_RXN[0..7] (8)

PB_EXP_B_TXP[0..7] (8)
PB_EXP_B_TXN[0..7] (8)

VCC3

PBBC13
10u/6/X5R/6.3V/M

4

PBBC14
10u/6/X5R/6.3V/M

PBBC15

0.1u/4/X7R/16V/K

PBBC17

0.1u/4/X7R/16V/K

3

2

19
21
26
31
34
39
41

10
11

14
15

30

43

19
21
26
31
34
39
41

10
11

14
15

30

43

9

1
2

5
6

9

1
2

5
6

PBU2

VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD

A0
A1

A2
A3

A4
A5

A6
A7

SEL

GNDPAD

PBU1

VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD

A0
A1

A2
A3

A4
A5

A6
A7

SEL

GNDPAD

VCC3

PBBC16

0.1u/4/X7R/16V/KPBBC2

PB_EXP_B_RXN4
PB_EXP_B_RXP4

PB_EXP_B_TXN4
PB_EXP_B_TXP4

PB_EXP_B_RXN5
PB_EXP_B_RXP5

PB_EXP_B_TXN5
PB_EXP_B_TXP5

PCIE_16_SWB

PI3PCIE3415ZHE/TQFN42[ 10TA1-084083-10R_10TA1-081480-10R]

VCC3

PBBC18

0.1u/4/X7R/16V/K

PB_EXP_B_RXN6
PB_EXP_B_RXP6

PB_EXP_B_TXN6
PB_EXP_B_TXP6

PB_EXP_B_RXN7
PB_EXP_B_RXP7

PB_EXP_B_TXN7
PB_EXP_B_TXP7

PCIE_16_SWB

PI3PCIE3415ZHE/TQFN42[ 10TA1-084083-10R_10TA1-081480-10R]

GND
GND
GND
GND
GND
GND
GND
GND
GND

GND
GND
GND
GND
GND
GND
GND
GND
GND

1

37

B0

36

B1

33

B2

32

B3

28

B4

27

B5

24

B6

23

B7

3

C0

4

C1

7

C2

8

C3

12

C4

13

C5

16

C6

17

C7

18
20
22
25
29
35
38
40
42

37

B0

36

B1

33

B2

32

B3

28

B4

27

B5

24

B6

23

B7

3

C0

4

C1

7

C2

8

C3

12

C4

13

C5

16

C6

17

C7

18
20
22
25
29
35
38
40
42

PB_EXP_B1_RXN4
PB_EXP_B1_RXP4

PB_EXP_B1_TXN4
PB_EXP_B1_TXP4

PB_EXP_B1_RXN5
PB_EXP_B1_RXP5

PB_EXP_B1_TXN5
PB_EXP_B1_TXP5

PF_EXP_B2_RXN4
PF_EXP_B2_RXP4

PF_EXP_B2_TXN4
PF_EXP_B2_TXP4

PF_EXP_B2_RXN5
PF_EXP_B2_RXP5

PF_EXP_B2_TXN5
PF_EXP_B2_TXP5

PB_EXP_B1_RXN6
PB_EXP_B1_RXP6

PB_EXP_B1_TXN6
PB_EXP_B1_TXP6

PB_EXP_B1_RXN7
PB_EXP_B1_RXP7

PB_EXP_B1_TXN7
PB_EXP_B1_TXP7

PF_EXP_B2_RXN6
PF_EXP_B2_RXP6

PF_EXP_B2_TXN6
PF_EXP_B2_TXP6

PF_EXP_B2_RXN7
PF_EXP_B2_RXP7

PF_EXP_B2_TXN7
PF_EXP_B2_TXP7PB_EXP_B_TXN3

VCC3

A A

PBBC6

0.1u/4/X7R/16V/K

0.1u/4/X7R/16V/K

0.1u/4/X7R/16V/K

0.1u/4/X7R/16V/K

0.1u/4/X7R/16V/K

0.1u/4/X7R/16V/K

0.1u/4/X7R/16V/K

PBBC7

8

PBBC8

PBBC9

PBBC10

PBBC11

PBBC12

Gigabyte Technology

Title

Size Document Number Rev
Custom

7

6

5

4

3

Date: Sheet of

PCI EXPRESS X16 SWITCH_2

GA-X99-UD5 WIFI

2

22 64Tuesday, August 26, 2014

1

1.0

VCC3

8

7

+12V

6

5

4

3

2

1

PFC1

0.1u/4/X7R/16V/K

D D

C C

3VDUAL

PF_EXP_B2_TXP0
PF_EXP_B2_TXN0
PF_EXP_B2_TXP1
PF_EXP_B2_TXN1
PF_EXP_B2_TXP2
PF_EXP_B2_TXN2
PF_EXP_B2_TXP3
PF_EXP_B2_TXN3
PF_EXP_B2_TXP4
PF_EXP_B2_TXN4
PF_EXP_B2_TXP5
PF_EXP_B2_TXN5
PF_EXP_B2_TXP6
PF_EXP_B2_TXN6
PF_EXP_B2_TXP7
PF_EXP_B2_TXN7

PFC6

0.1u/4/X7R/16V/K

PF_EXP_B2_TXP[0..7]
PF_EXP_B2_TXN[0..7]

PFC2

0.1u/4/X7R/16V/K

PFC7 0.22u/4/X5R/6.3V/K
PFC8 0.22u/4/X5R/6.3V/K
PFC9 0.22u/4/X5R/6.3V/K
PFC10 0.22u/4/X5R/6.3V/K
PFC11 0.22u/4/X5R/6.3V/K
PFC12 0.22u/4/X5R/6.3V/K
PFC13 0.22u/4/X5R/6.3V/K
PFC14 0.22u/4/X5R/6.3V/K
PFC15 0.22u/4/X5R/6.3V/K
PFC16 0.22u/4/X5R/6.3V/K
PFC17 0.22u/4/X5R/6.3V/K
PFC18 0.22u/4/X5R/6.3V/K
PFC19 0.22u/4/X5R/6.3V/K
PFC20 0.22u/4/X5R/6.3V/K
PFC21 0.22u/4/X5R/6.3V/K
PFC22 0.22u/4/X5R/6.3V/K

PFC3

0.1u/4/X7R/16V/K

PF_EXP_B2_TXP[0..7] (22)
PF_EXP_B2_TXN[0..7] (22)

PF_EXP_B2_TXP0C
PF_EXP_B2_TXN0C
PF_EXP_B2_TXP1C
PF_EXP_B2_TXN1C
PF_EXP_B2_TXP2C
PF_EXP_B2_TXN2C
PF_EXP_B2_TXP3C
PF_EXP_B2_TXN3C
PF_EXP_B2_TXP4C
PF_EXP_B2_TXN4C
PF_EXP_B2_TXP5C
PF_EXP_B2_TXN5C
PF_EXP_B2_TXP6C
P

F_EXP_B2_TXN6C
PF_EXP_B2_TXP7C
PF_EXP_B2_TXN7C

PCIEX8_1_DET(15)

PFC4

0.1u/4/X7R/16V/K

PFC5

0.1u/4/X7R/16V/K

N_SMBCLK(16,20,21,24,25,26,27,30,34,35,37,42,47,58)

N_SMBDATA(16,20,21,24,25,26,27,30,34,35,37,42,47,58)

N_-PCIE_WAKE(16,20,21,24,25,47,58)

N_SMBCLK
N_SMBDATA

3VDUAL

PF_EXP_B2_TXP7C
PF_EXP_B2_TXN7C

PF_EXP_B2_TXP6C
PF_EXP_B2_TXN6C

PF_EXP_B2_TXP5C
PF_EXP_B2_TXN5C

PF_EXP_B2_TXP4C
PF_EXP_B2_TXN4C

PF_EXP_B2_TXP3C
PF_EXP_B2_TXN3C

PF_EXP_B2_TXP2C
PF_EXP_B2_TXN2C

PF_EXP_B2_TXP0C
PF_EXP_B2_TXN0C

PCIEX8_1_DET

+12V

PFR1 0/4/SHT/X
PFR2 0/4/SHT/20/X
PFR3 0/4/SHT/20/X

VCC3

N_-PCIE_WAKE

PF_EXP_B2_TXP1C
PF_EXP_B2_TXN1C

B10
B11

B12
B13
B14
B15
B16
B17
B18

B19
B20
B21
B22
B23
B24
B25
B26
B27
B28
B29
B30
B31
B32

B33
B34
B35
B36
B37
B38
B39
B40
B41
B42
B43
B44
B45
B46
B47
B48
B49

B1
B2
B3
B4
B5
B6
B7
B8
B9

PCIE_4

12V
1

2V
RSVD
GND
SMCLK
SMDAT
GND

3.3V
JTAG1

3.3VAUX
WAKE*

RSVD
GND
HSOP0
HSON0
GND
PRSNT2*
GND

HSOP1
HSON1
GND
GND
HSOP2
HSON2
GND
GND
HSOP3
HSON3
GND
RSVD
PRSNT2*
GND

HSOP4
HSON4
GND
GND
HSOP5
HSON5
GND
GND
HSOP6
HSON6
GND
GND
HSOP7
HSON7
GND
PRSNT2*
GND

3GIO_*8

KEY

PRSNT1*

12V
12V

GND
JTAG2
JTAG3
JTAG4
JTAG5

3.3V

3.3V

PWRGD

GND

REFCLK+

REFCLK-

GND

HSIP0

HSIN0

GND

RSVD

GND

HSIP1
HSIN1

GND

GND

HSIP2
HSIN2

GND

GND

HSIP3
HSIN3

GND

RSVD
RSVD

GND

HSIP4
HSIN4

GND

GND

HSIP5
HSIN5

GND

GND

HSIP6
HSIN6

GND

GND

HSIP7
HSIN7

GND

+12V

A1
A2
A3

PFR4 0/4/SHT/X

A4
A5
A6
A7
A8
A9
A10
A11

A12
A13
A14
A15
A16
A17
A18

A19
A20
A21
A22
A23
A24
A25
A26
A27
A28
A29
A30
A31
A32

A33
A34
A35
A36
A37
A38
A39
A40
A41
A42
A43
A44
A45
A46
A47
A48
A49

VCC3

PF_EXP_B2_RXP7
PF_EXP_B2_RXN7

PF_EXP_B2_RXP6
PF_EXP_B2_RXN6

PF_EXP_B2_RXP5
PF_EXP_B2_RXN5

PF_EXP_B2_RXN4

PF_EXP_B2_RXP3
PF_EXP_B2_RXN3

PF_EXP_B2_RXP2
PF_EXP_B2_RXN2

PF_EXP_B2_RXP1
PF_EXP_B2_RXN1

PF_EXP_B2_RXP0
PF_EXP_B2_RXN0

PFR5

0/4/SHT/X

PF_SRCCLK (27)
PF_-SRCCLK (27)

PCIE_X16_X8_RST

PFC23
22P/4/NPO/50V/J

PF_EXP_B2_RXP[0..7]
PF_EXP_B2_RXN[0..7]PF_EXP_B2_RXP4

PCIE_X16_X8_RST (15,20,21,24)

PF_EXP_B2_RXP[0..7] (22)
PF_EXP_B2_RXN[0..7] (22)

B B

VCC3

PFR8
1K/4/1

A A

8

PE_16_8_SWB(22)

7

PFR70/4/SHT/20/X

PFR9

0/4/SHT/20/X

SEC_2x8_B (28)

6

B81

PRSNT2*

PCI-E/8X-99P/BK/G30/LONG DOUBL/[11AC1-023099-61R]

5

4

11AC1-023099-61R

Gigabyte Technology

Title

Size Document Number Rev
Custom

3

Date: Sheet of

PCI EXPRESS X8_2

GA-X99-UD5 WIFI

2

23 64Tuesday, August 26, 2014

1

1.0

8

7

6

5

4

3

2

1

+12V

VCC3

R958.2K/4/X

R92 0/4/SHT/X

N_-PCIE_WAKE

D D

A_EXP_C_TXP7(8)

A_EXP_C_TXN7(8)

A_EXP_C_TXP6(8)

A_EXP_C_TXN6(8)

A_EXP_C_TXP5(8)

A_EXP_C_TXN5(8)

A_EXP_C_TXP4(8)

A_EXP_C_TXN4(8)

C C

A_EXP_C_TXP3(8)

A_EXP_C_TXN3(8)

A_EXP_C_TXP2(8)

A_EXP_C_TXN2(8)

A_EXP_C_TXP1(8)

A_EXP_C_TXN1(8)

A_EXP_C_TXP0(8)

A_EXP_C_TXN0(8)

PGC1 0.22u/4/X5R/6.3V/K
PGC2 0.22u/4/X5R/6.3V/K

PGC3 0.22u/4/X5R/6.3V/K
PGC4 0.22u/4/X5R/6.3V/K

PGC5 0.22u/4/X5R/6.3V/K
PGC6 0.22u/4/X5R/6.3V/K

PGC7 0.22u/4/X5R/6.3V/K
PGC8 0.22u/4/X5R/6.3V/K

PGC9 0.22u/4/X5R/6.3V/K
PGC10 0.22u/4/X5R/6.3V/K

PGC11 0.22u/4/X5R/6.3V/K
PGC12 0.22u/4/X5R/6.3V/K

PGC13 0.22u/4/X5R/6.3V/K
PGC14 0.22u/4/X5R/6.3V/K

PGC15 0.22u/4/X5R/6.3V/K
PGC16 0.22u/4/X5R/6.3V/K

N_SMBCLK(16,20,21,23,25,26,27,30,34,35,37,42,47,58)

N_SMBDATA(16,20,21,23,25,26,27,30,34,35,37,42,47,58)

3VDUAL

N_-PCIE_WAKE(16,20,21,23,25,47,58)

PG_EXP_C_TXP0_C
PG_EXP_C_TXN0_C

PG_EXP_C_TXP1_C
PG_EXP_C_TXN1_C

PG_EXP_C_TXP2_C
PG_EXP_C_TXN2_C

PG_EXP_C_TXP3_C
PG_EXP_C_TXN3_C

PG_EXP_C_TXP4_C
PG_EXP_C_TXN4_C

PG_EXP_C_TXP5_C
PG_EXP_C_TXN5_c

PG_EXP_C_TXP6_C
PG_EXP_C_TXN6_C

PG_EXP_C_TXP7_C
PG_EXP_C_TXN7_C

Close to SLOT

B B

PCIEX8_2_DET(16)

PCIEX8_2_DET

B10
B11

B12
B13
B14
B15
B16
B17
B18

B19
B20
B21
B22
B23
B24
B25
B26
B27
B28
B29
B30
B31
B32

B33
B34
B35
B36
B37
B38
B39
B40
B41
B42
B43
B44
B45
B46
B47
B48
B49

PCIE_3

12V
1

2V
RSVD
GND
SMCLK
SMDAT
GND

3.3V
JTAG1

3.3VAUX
WAKE*

RSVD
GND
HSOP0
HSON0
GND
PRSNT2*
GND

HSOP1
HSON1
GND
GND
HSOP2
HSON2
GND
GND
HSOP3
HSON3
GND
RSVD
PRSNT2*
GND

HSOP4
HSON4
GND
GND
HSOP5
HSON5
GND
GND
HSOP6
HSON6
GND
GND
HSOP7
HSON7
GND
PRSNT2*
GND

3GIO_*8

KEY

PRSNT1*

GND
JTAG2
JTAG3
JTAG4
JTAG5

3.3V

3.3V

PWRGD

GND

REFCLK+

REFCLK-

GND

HSIP0
HSIN0

GND

RSVD

GND

HSIP1
HSIN1

GND

GND

HSIP2
HSIN2

GND

GND

HSIP3
HSIN3

GND

RSVD
RSVD

GND

HSIP4
HSIN4

GND

GND

HSIP5
HSIN5

GND

GND

HSIP6
HSIN6

GND

GND

HSIP7
HSIN7

GND

12V
12V

B1
B2
B3
B4
B5
B6
B7
B8
B9

+12V

A1
A2
A3

R93 0/4/SHT/X

A4
A5
A6
A7
A8
A9
A10
A11

A12
A13
A14
A15
A16
A17
A18

A19
A20
A21
A22
A23
A24
A25
A26
A27
A28
A29
A30
A31
A32

A33
A34
A35
A36
A37
A38
A39
A40
A41
A42
A43
A44
A45
A46
A47
A48
A49

VCC3

PG_SRCCLK (27)
PG_-SRCCLK (27)

R94

0/4/SHT/X

PG_EXP_C_RXP7 (8)
PG_EXP_C_RXN7 (8)

PG_EXP_C_RXP6 (8)
PG_EXP_C_RXN6 (8)

PG_EXP_C_RXP5 (8)
PG_EXP_C_RXN5 (8)

PG_EXP_C_RXP4 (8)
PG_EXP_C_RXN4 (8)

PG_EXP_C_RXP3 (8)
PG_EXP_C_RXN3 (8)

PG_EXP_C_RXP2 (8)
PG_EXP_C_RXN2 (8)

PG_EXP_C_RXP1 (8)
PG_EXP_C_RXN1 (8)

PG_EXP_C_RXP0 (8)
PG_EXP_C_RXN0 (8)

PCIE_X16_X8_RST (15,20,21,23)

PCIE_X16_X8_RST

C1

22p/4/NPO/50V/J

3VDUAL

PGC17

0.1u/4/X7R/16V/K

+12V

PGC18

0.1u/4/X7R/16V/K

PGC19

0.1u/4/X7R/16V/K

VCC3

PGC20

0.1u/4/X7R/16V/K

PGC21

PGC22

0.1u/4/X7R/16V/K

0.1u/4/X7R/16V/K

B81

A A

8

7

6

PRSNT2*

PCI-E/8X-99P/BK/G30/LONG DOUBL/[11AC1-023099-61R]

5

Title

Size Document Number Rev
Custom

4

3

Date: Sheet of

2

Gigabyte Technology

PCI EXPRESS X 8 PORT

GA-X99-UD5 WIFI

24 64Tuesday, August 26, 2014

1

1.0

PCIEX1 SLOT

5

4

3

2

1

PCIEX1_1

+12V

PIBC1 0.1u/4/X7R/16V/K/X

PIR3 0/4/SHT/X

N

D D

PI_PCIE_TP6(17)
PI_PCIE_TN6(17)

PCH PCIE  PO R T6

PCH PCIE  PO R T6

PCH PCIE  PO R T6PCH PCIE  PO R T6

C C

PJ_PCIE_TP7(17)
PJ_PCIE_TN7(17)

N_SMBCLK

58)
N_SMBDATA

58)

N_-PCIE_WAKE(16,20,21,23,24,47,58)

PIC2 0.1u/4/X7R/16V/K
PIC3 0.1u/4/X7R/16V/K

N_SMBCLK

58)
N_SMBDATA

58)

PJC2 0.1u/4/X7R/16V/K

PCH PCIE  PO R T7

PCH PCIE  PO R T7

PCH PCIE  PO R T7PCH PCIE  PO R T7

PJC3 0.1u/4/X7R/16V/K

_SMBCLK

N_SMBDATA

PCIEX1_2

PJBC1 0.1u/4/X7R/16V/K/X

N_SMBCLK
N_SMBDATA

1

VCC3

3VDUAL

PI_PCIE_TP6_C
PI_PCIE_TN6_C

PJR3 0/4/SHT/X

1

VCC3

3VDUAL

PJ_PCIE_TP7_C
PJ_PCIE_TN7_C

B1
B2 A2

B4
B5
B6
B7
B8

B9
B10
B11

B12
B13
B14
B15
B16
B17
B18

PCI-E/1X-36P/BK/OL

+12V

B1

B2 A2

B4

B5

B6

B7

B8

B9
B10
B11

B12
B13
B14
B15
B16
B17
B18

3GIO_X1

PCIE_5

12V
1

2V 12V

GND
SMCLK
SMDAT
GND

3.3V
JTAG1

3.3VAUX
WAKE*

RVSD
GND
HSOP0
HSON0
GND
PRSNT2*
GND

PCIE_6

12V
12V 12V

GND
SMCLK
SMDAT
GND

3.3V
JTAG1

3.3VAUX
WAKE*

RVSD
GND
HSOP0
HSON0
GND
PRSNT2*
GND

KEY

3GIO_X1

KEY

PRSNT1*

GND
JTAG2
JTAG3
JTAG4
JYAG5

3.3V

3.3V

PWRGD

GND

REFCLK+

REFCLK-

GND

HSIP0
HSIN0

GND

PRSNT1*

GND
JTAG2
JTAG3
JTAG4
JYAG5

3.3V

3.3V

PWRGD

GND

REFCLK+

REFCLK-

GND

HSIP0
HSIN0

GND

12VRSVD

12VRSVD

PIR1 0/4/SHT/X

A1
A3B3

A4
A5
A6
A7
A8
A9
A10
A11

A12
A13
A14
A15
A16
A17
A18

A1
A3B3

A4
A5
A6
A7
A8
A9
A10
A11

A12
A13
A14
A15
A16
A17
A18

1

+12V

PIR2 0/4/SHT/X

1

PIBC3 0.1u/4/X7R/16V/K/X

VCC3

PI_PCIE_CLK (17)
PI_-PCIE_CLK (17)

PJR1 0/4/SHT/X

1

+12V

PJR2 0/4/SHT/X

1

PJBC3 0.1u/4/X7R/16V/K/X

VCC3

PJ_PCIE_CLK (17)
PJ_-PCIE_CLK (17)

PCIE_X1_RST (15)

PIC1
22p/4/NPO/50V/J/X

PI_PCIE_IP6 (17)
PI_PCIE_IN6 (17)

PCH PCIE  PO R T6

PCH PCIE  PO R T6

PCH PCIE  PO R T6PCH PCIE  PO R T6

PCIE_X1_RST (15)N_-PCIE_WAKE(16,20,21,23,24,47,58)

PJC1
22p/4/NPO/50V/J/X

PJ_PCIE_IP7 (17)
PJ_PCIE_IN7 (17)

PCH PCIE  PO R T7

PCH PCIE  PO R T7

PCH PCIE  PO R T7PCH PCIE  PO R T7

PCI-E/1X-36P/BK/OL

B B

PCIEX1_3

PKBC1 0.1u/4/X7R/16V/K/X

PKR3 0/4/SHT/X

N_SMBCLK

58)
N_SMBDATA

58)

N_-PCIE_WAKE(16,20,21,23,24,47,58)

PK_PCIE_TP8(17)
PK_PCIE_TN8(17)

PCH PCIE  PO R T8

PCH PCIE  PO R T8

PCH PCIE  PO R T8PCH PCIE  PO R T8

A A

PKC2 0.1u/4/X7R/16V/K
PKC3 0.1u/4/X7R/16V/K

5

N_SMBCLK
N_SMBDATA

PK_PCIE_TP8_C
PK_PCIE_TN8_C

1

VCC3

3VDUAL

+12V

B1
B2 A2

B4
B5
B6
B7
B8

B9
B10
B11

B12
B13
B14
B15
B16
B17
B18

PCI-E/1X-36P/BK/OL

4

3GIO_X1

PCIE_7

12V
12V 12V

GND
SMCLK
SMDAT
GND

3.3V
JTAG1

3.3VAUX
WAKE*

RVSD
GND
HSOP0
HSON0
GND
PRSNT2*
GND

KEY

PRSNT1*

12VRSVD

GND
JTAG2
JTAG3
JTAG4
JYAG5

3.3V

3.3V

PWRGD

GND

REFCLK+

REFCLK-

GND

HSIP0

HSIN0

GND

PKR1 0/4/SHT/X

A1
A3B3

A4
A5
A6
A7
A8
A9
A10
A11

A12
A13
A14
A15
A16
A17
A18

1

+12V

PKR2 0/4/SHT/X

1

PKBC3 0.1u/4/X7R/16V/K/X

VCC3

PK_PCIE_CLK (17)
PK_-PCIE_CLK (17)

3

PCIE_X1_RST (15)

PKC1
22p/4/NPO/50V/J/X

PK_PCIE_IP8 (17)
PK_PCIE_IN8 (17)

PCH PCIE  PO R T8

PCH PCIE  PO R T8

PCH PCIE  PO R T8PCH PCIE  PO R T8

Title

Size Document Number Rev

Custom

Date: Sheet of

Gigabyte Technology

PCIE_X1 1,2,3

GA-X99-UD5 WIFI

2

25 64Tuesday, August 26, 2014

1.0

1

5

1K/4/1

CKVDDB

CK_SCLK
CK_SDATA

SMB_A0

CK_PEX_REFCLK
CK_-PEX_REFCLK

1
2
3
4
5
6
7
8

CK_SDATA
CK_SCLK

D D

CKVDDB

CKR5 1K/4/1/X
CKR6

C C

CKVDDB

CKR39 0/4/SHT/20/X

CKR40 0/4/X

B B

SMB_A0

CKU2

VDD
GND
NC
NC
NC
NC
VDD
GND

SMB_A1

CKR1 10/4
CKR2 10/4

CKVDDB

CK_BANDWIDTH

32313029282726

33

VDD

GND

CLK_IN

SMB_A0

CLK_IN#

HIGH_BW#

6V49322

SMB_A1

SDATA

SCLK

SMB_A2_PLLBYP#NCNC

9101112131415

CKR4

100p/4/NPO/50V/J/X
CKR3
100p/4/NPO/50V/J/X

CKVDDB

CKR10

CK_IREF

475/4/1

CK_OE

CKR13 1K/4/1

25

GND

IREF

OE_0_1#

VTTPWRG#/PD

GND

VDD

16

0 : Fanout mode (PLL bypassed)
1 : ZDB mode (PLL used)

24

DIF_1

23

DIF_1#

22

VDD

21

GND

20

DIF_0

19

DIF_0#

18

vFS_C

17

6V49322/[10HL6-2C4932-10R]

SMB_A2

4

N_SMBCLK (16,20,21,23,24,25,27,30,34,35,37,42,47,58)
N_SMBDATA (16,20,21,23,24,25,27,30,34,35,37,42,47,58)

CKVDDB

CKVDDB

CKR21 1K/4/1

CK_BANDWIDTH

CKR23 1K/4/1
CKR24

1K/4/1

CKR7
CKR8 1K/4/1/X

CKVDDB

CK_DIF1

-CK_DIF1

CK_DIF0

-CK_DIF0
VFS_C

CKVDDB

CKR9 1K/4/1

CK_BANDWIDTH

VFS_C

CKR20 1K/4/1/X

1K/4/1/X

-VTTPWRG

N_PCH_VRMPWRGD(16,28)

SMB_A1

SMB_A1

N_-CPU_BK0(17)
N_CPU_BK0(17)

CK_DIF0SMB_A0

-CK_DIF0

CK_DIF1

-CK_DIF1

CKR26 8.2K/4

3

N_-CPU_BK0
N_CPU_BK0

(

󵚩󵚩󵚩󵚩󴼚󴼚󴼚󴼚

buffer)

CKR11 33/4
CKR12 33/4

CKR14 49.9/4/1
CKR15

CKR16 33/4
CKR17 33/4

CKR18 49.9/4/1
CKR19

CKVDDB

NR292 0/4/SHT/20/X
NR293 0/4/SHT/20/X

49.9/4/1

49.9/4/1

CKVDDB

CKR35 8.2K/4
CKR36

CKR22
1K/4/1

-VTTPWRG

CKQ1

SOT23

132

MMBT2222A/SOT23/600mA/40

CK_-PEX_REFCLK
CK_PEX_REFCLK

1K/4/1/X

SMB_A2

SMB_A2

2

N_CPU_BCLK0 (8)
N_-CPU_BCLK0 (8)

N_CPU_BCLK1 (8)
N_-CPU_BCLK1 (8)

-CLK_BYPASS(42)

CKR37

CKVDDB

1u/4/X5R/6.3V/K

CKVDDB

CKR38 8.2K/4

1K/4/1

CKBC20

1u/4/X5R/6.3V/K CKBC22

CKBC21

1u/4/X5R/6.3V/K

SMB_A2

CKQ2

SOT23

132

MMBT2222A/SOT23/600mA/40

1

VCC3

1u/4/X5R/6.3V/K

CKFB7
30/4/4A/S

CKBC23

3VDUAL

CKFB8
30/4/4A/S/X

CKBC24
1u/4/X5R/6.3V/K

A A

Title

PCH DISPLAY ,CLK BUFFER

Size Document Number Rev

Custom

5

4

3

2

Date: Sheet of

GA-X99-UD5 WIFI

1

26 64Tuesday, August 26, 2014

1.0

5

D D

N_BUF_REFCLK(17)

YCKVDD

YR1 1K/4/1/X

C C

B B

YR2

1K/4/1

YR3 1K/4/1

YR4

BANDWIDTH

1K/4/1

YCKVDD

YSCLK
YSDATA

BANDWIDTH

DB_OE_1

DB_OE_4

DB_IREF

YR5

475/4/1

7 5
13
16
22
28

2

3
15

14

1

4

25

26

4

YU3

VDD DIF_0
VDD
VDD
V

DD

VDDA

SRC_IN
SRC_IN#

SCLK
SDATA

PLL_BW

OE_1#

OE_4#

IREF

9DB633AGILF/TSSOP28

[SMBus add = 0xD8]

DIF_0#

DIF_1

DIF_1#

DIF_2

DIF_2#

DIF_3

DIF_3#

DIF_4

DIF_4#

DIF_5

DIF_5#

GNDA

GND
GND

3

(

󵚩󵚩󵚩󵚩󴼚󴼚󴼚󴼚

buffer)

-DIF1

-DIF3

-DIF0

DIF1

-DIF2

DIF3

DIF0

DIF2

YR8 33/4
YR9 33/4

YR10 49.9/4/1
YR11

YR12 33/4
YR13 33/4 YC4

YR14 49.9/4/1
YR15

YR18 33/4
YR20 33/4

YR19 49.9/4/1
YR23

YR16 33/4
YR21 33/4

YR17 49.9/4/1
YR22

49.9/4/1

49.9/4/1

49.9/4/1

49.9/4/1

PG_SRCCLK (24)
PG_-SRCCLK (24)

PF_SRCCLK (23)
PF_-SRCCLK (23)N_-BUF_REFCLK(17)

PA_SRCCLK (21)
PA_-SRCCLK (21)

PB_SRCCLK (20)
PB_-SRCCLK (20)

DIF0

-DIF0

6

DIF1

9

-DIF1

10

DIF2

11

-DIF2

12

DIF3

18

-DIF3

17
20

19
24

23

27
8
21

2

YCKVDD

YC3

1u/4/X5R/6.3V/K

1u/4/X5R/6.3V/K

1u/4/X5R/6.3V/K

YC5

1

YFB1
30/4/4A/S

YC6

1u/4/X5R/6.3V/K

3VDUALVCC3

YFB2
30/4/4A/S/X

YC7
1u/4/X5R/6.3V/K

YSCLK
YSDATA

A A

5

4

YR6 10/4
YR7 10/4

3

YC2

100p/4/NPO/50V/J/X
YC1
100p/4/NPO/50V/J/X

N_SMBCLK (16,20,21,23,24,25,26,30,34,35,37,42,47,58)
N_SMBDATA (16,20,21,23,24,25,26,30,34,35,37,42,47,58)

Title

PEG CLOCK BUFFER

Size Document Number Rev

Custom

2

Date: Sheet of

GA-X99-UD5 WIFI 1.0

27 64Tuesday, August 26, 2014

1

5

SIO IT8620

JP2
JP3

D D

OR171 8.2K/4

VCC3

VCC3

ITE_PWROK2

OR1 1K/4/1

OC1

TPM_GP14

MB1

IT_VCCH

OR80 1K/4/1

PWOK

OR172 0/4/SHT/20/X

IO_GP21

OR177 0/4/SHT/20/X

OR2 22/4
OR4 22/4

IT_VCCH

N_-PFMRST
N_-LDRQ0

N_-PFMRST

OC2
22p/4/NPO/50V/J/X

USB_SEL(43)

THR_PWM

-IO_HOT

-RST_BTN
TPM_GP14

SIO_18V

N_-PFMRST (16,42)

-SPI_HOLD0(29)

-SPI_HOLD1(29)
FANIO1(41)

FANPWM1(41)

FANIO2(41)

FANPWM2(41)

Pu GP34 to disable
GBT Beep alarm

C C

-PRCOHOT

B B

VCC3

VCC3

5VAUX_SW(37)

PWOK(37,40,42)
IO_GP27(7)

BEEP-(39)
IO_GP24(38)

N_PCH_DPWROK(15,17)

A_-PROCHOT(7,30)

VCC3

O_PWROK1(16,42)
O_-PCIE_RST(15)

N_-PFMRST(16,42)

N_-LDRQ0(16)

N_SERIRQ(15,42)

N_-LFRAME(16,42)

PWOK

1n/4/X7R/50V/K

OR170 8.2K/4

OR126 8.2K/4/X

OR168 8.2K/4

JP5

ITE_PWROK1
PCIRST1
PCIRST2

N_LAD[0..3](16,42)

N_A20GATE(16)

N_LPC33(17)

N_LPCCLK48(17)

N_-KBRST(15,16)

IO_GP21

32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69

For MB-ID

VCC3

SIO CAP

OR127 8.2K/4
OR129 8.2K/4

IT_VCCH

A A

IO_GP21

-IO_HOT

5

DUAL BIOS OPT STRAP

JP4

-PROCHOT_CON

SLP_SUS#/PCIRSTIN#/CIRTX2/GP15
3VSB
HOLD_M#/GP64
HOLD_B#/GP63
FAN_TAC1
FAN_CTL1
FAN_TAC2/GP52
FAN_CTL2/GP51
FAN_TAC3/GP37
FAN_CTL3/GP36
VCC18_EN/GP35
VTT_PWRGD/GP34
GNDD
SLP_SUS_FET/5VSB_CTRL#
SUS_WARN_5VDUAL/5VAUX_SW
PWRGD2
ATXPG/GP30
INV_IN1/SIN2/GP27
INV_OUT1/SOUT2/GP26
FAN_TAC4/DSR2#/GP25
FAN_TAC5/RTS2#/GP24
DPWORK/CPU_PG/GP23
SPI_SI/GP22
IO_SMI#/DCD2#/GP21
THR_PWM/CTS2#/GP20
R12#/GP17
DTR2#/JP5
SPI_SO/CIRTX1
PCH_C1/GP14
SUSACK#/PWRGD1
PCIRST1#/GP12
PCIRST2#/GP11
3VSB
VCORE
LRESET#
LDRQ#
SERIRQ
LFRAME#

LAD[0..3]

-CASEOPEN

OC122
1u/4/X5R/6.3V/K

4

31

BEEP_GB/FAN_CTL5/CIRRX2/GP16

LAD0

70

LAD0

OC125

1u/4/X5R/6.3V/K

4

RTS1#/JP2

DTR1#/JP4

SOUT1/JP3

CTS1#/GP31

OCWDT3/RI1#/GP32

OCWDT1/SIN1/GP41

OCWDT0/DSR1#/GP45

OCWDT2/DCD1#/GP33

USB_FS5/P80LED4/PD4/GP74

USB_FS6/P80LED5/PD5/GP75

USB_FS7/P80LED6/PD6/GP76

USB_FS8/P80LED_L/PD7/GP77

IT8620E_CX

KRST#/GP62

LAD3

LAD2

GA20

LAD1

GPO50/JP1

PCICLK

GNDD

CLKIN

CPUPWRGD/GP95

VCC1_05_EN/GP66

747372

75

71

LAD3

LAD2

LAD1

VLDT_EN/PCH_D0/GP65

76777879808182838485868788899091929394

-DUAL_BIOSDIS(29,42)

IT_VCCH

OC126

0.1u/4/X7R/16V/K/X

80P_DL (40)
80P_SEGG (40)
80P_SEGF (40)
80P_SEGE (40)
80P_SEGD (40)
80P_SEGC (40)
80P_SEGB (40)
80P_SEGA (40)

MB_ID2

MB1 IO_GP27

GNDD

OC_IN/INIT#GP85

LS_IN2/BUSY/GP82

OC_OUT/AFD#/GP86

USB_OC2/STB#GP87

LS_OUT2/ACK#/GP83

USB_OC1/P80LED_H//ERR#

USB_FS1/P80LED0/PD0/GP70

USB_FS2/P80LED1/PD1/GP71

USB_FS3/P80LED2/PD2/GP72

USB_FS4/P80LED3/PD3/GP73

VCORE_EN/PCH_C0

VR_RDY/GP97

IPHONE_CHARGE#/SLIN#GP84

PCH_VRMPWRGD/GP96

SUSWARN#/SST/AMDTSI_D/PCH_D

GP67

PECI/AMDTSI_C

PROCHOT#/GP94

HDLED_IN/GP93

HDLED_OUT/GP92

PWRLED/GP91

DDR_EN/GP90

GP42/SCK/FAN_CTL4/THRMTRIP#

OR178 0/4/X

CEB_N

OR30 680/4/1/X
OR31 1K/4/1

IT_VCCH IT_AVCC

OC127
10u/6/X5R/6.3V/M

SEC_2x8_B (23)
80P_DH (40)

G_PLED1
G_PLED2
G_PLED3

6789101112131415161718192021222324252627282930

SIO

LS_IN1/SLCT/GP80

VREF_2.5

TR6/VIN9
TR5/VIN8
TR4/VIN7

LS_OUT1/PE/GP81

VIN0/VCORE(1.1V)

VIN1/VDIMM_STR(1.5V)

VIN2(+12V_SEN)

VIN3(+5V_SEN)

VIN4/VLDT_12

VIN5/5VDUAL

RSMRST#/CIRRX1/GP55

CPURST#/GP10
MCLK/FAN_TAC6/GP56
MDAT/FAN_CTL6/GP57

KCLK/GP60
KDAT/GP61

3VSBSW#/GP40

PWRGD3

SUSC#/GP53

PANSWH#/GP43

PME#/GP54

PWRON#GP44

CE_N/GPO47/JP6

SYS_3VSB

95

IT8620E/CX/S

28_3VSB

SVID_CTRL

-PROCHOT_CON

IO_GP67

OR174 0/4/SHT/20/X
OR175 0/4/SHT/20/X

3VDUAL

OC128
1u/4/X5R/6.3V/K

AVCC3

TMPIN1
TMPIN2
TMPIN3

PSON#

SUSB#

COPEN#

G_PLED1 (55,61)
G_PLED2 (55)
G_PLED3 (61)

5
4
3
2
1
128
127
126
125
124
123
122
121

VIN6

120

VREF

119
118
117
116

TSD-

115

GNDA

114
113
112
111
110
109
108
107
106
105
104
103

GNDD

102
101
100
99
98

VBAT

97
96

3VSB

VCC3

3

B_SW (29)

VREF_25

IT_AVCC

CEB_N

IT_VCCH

OC121

0.1u/4/X7R/16V/K

N_-THRMTRIP (7,15,30,31,32,33)
MPD- (39,55)
LED_PWR_CTRL (43)

For IT8728

A_PECI (7,42)
IO_GP67 (43)
N_SSTCTL (15)
N_PCH_VRMPWRGD (16,26)
VR_RDY (30)

Pop OR31 PU for dual Bios 2014-05-26

OC13
10u/6/X5R/6.3V/M

3

TR6 (41)
TR5 (41)
TR4 (41)

VIN0 (41)
VIN1 (41)
VIN2 (41)
VIN3 (41)
VIN4 (41)
VIN5 (41)
VIN6 (41)
VREF (41)
SYS_TEMP (41)
PCH_TEMP (41)
CPU_TEMP (41)

IOTOPCH (15)
MCLK (57)
MDAT (57)
KCLK (57)
KDAT (57)
ECIO_SMBCLK (42)
ECIO_SMBDATA (42)

N_VBAT (18,42)

-CASEOPEN (39,41)

OC129
1u/4/X5R/6.3V/K

3VDUAL_PCH

OC14

0.1u/4/X7R/16V/K

OR7 22/4

-THRMTRIP

SIO_18V

-RSMRST
O_-RSMRST (16,37)

N_-S4_S5 (16,38,39,42)

-PSON (34,35,38,40,42)

-PWRBTSW (39,42)

OR5

OC5

8.2K/4

0.01u/4/X7R/25V/K

3VDUAL_PCH

internal power pin, max 22nF cap

SIO_18V

OC123

0.1u/4/X7R/16V/K

OC124

0.1u/4/X7R/16V/K/X

MB ID

VREF_25

OC15

0.1u/4/X7R/16V/K

VCC3

OR28 8.2K/4
OR29 8.2K/4/X

2

PWR SHT

SIO PU

SIO STRAP

N_-LPCPME (16)
O_PWRBTSW (16)
N_-SLP_S3 (16,34,35,37,38,39,42)

Power leakage

2N7002/SOT23/25pF/5

+12V

MB_ID2

2

OR249

8.2K/4

1

For 8728 EUP function

3VDUAL_PCH

FANPWM1(41)
FANPWM2(41)

OQ1

G S

Title

Size Document Number Rev

Date: Sheet of

OR8 0/4/SHT/20/X

IO_GP24
IO_GP67
SVID_CTRL

-PROCHOT_CON

N_-LDRQ0
ITE_PWROK2
ITE_PWROK1
O_-PCIE_RST
PCIRST1

FANPWM1
FANPWM2

H61M-S2 1.1 JP6 stuff
pull down

JP2
JP3
JP4
JP5

EUP control by PCH

OR26 100/4/1

3VDUAL

JP3--- High SPI-Flash Disable
Low SPI-Flash Enable

IT_AVCC

3

D

VCC3

SOT23

2

1

Gigabyte Technology

PCH GPIO , CTRL , AUDIO

Custom

GA-X99-UD5 WIFI

IT_VCCH

OR176 8.2K/4
OR32 1K/4/1/X
OR11 1K/4/1/X
OR12 8.2K/4

OR13 8.2K/4

OR14 1K/4/1
OR15 1K/4/1
OR16 1K/4/1
OR17 1K/4/1
OR18 1K/4/1

OR19 8.2K/4/X
OR20 8.2K/4/X

OR21 8.2K/4
OR22 8.2K/4
OR23 8.2K/4
OR24 8.2K/4/X
OR25 8.2K/4/X

28_3VSB

1

VCC3
VCC3
VCC3
VCC3

VCC3
3VDUAL_PCH
3VDUAL_PCH
3VDUAL_PCH

VCC3

VCC3
VCC3
VCC3
VCC3
VCC3

VCC
VCC

ITE recommand

28 64Tuesday, August 26, 2014

1.0

8

VCC3_ME

MMBT2222A/SOT23/600mA/40/[10IT1-002222-11R]

D D

C C

DIS_DB1

-SPI_HOLD_B

DIS_DB2

-SPI_HOLD_M

R6

1K/4/1

R222 8.2K/4

VCC3_ME

R220

1K/4/1

R9 8.2K/4

Q42

7

VCC3_ME

R3

For IT8951 sink capability

1K/4/1

-SPI_CS_1

SOT23

132

N_-ICH_SPI_CS

Q43
MMBT2222A/SOT23/600mA/40/[10IT1-002222-11R]

SOT23

132

VCC3_ME

R8
330/4

-SPI_CS_2

Q44
MMBT2222A/SOT23/600mA/40/[10IT1-002222-11R]

SOT23

132

Q45
MMBT2222A/SOT23/600mA/40/[10IT1-002222-11R]

SOT23

132

R7

10p/4/NPO/50V/J/X

0/4/X

-SPI_CS_1(43)

6

C4

-SPI_CS_1

SPI_DQ2(16)

R11 0/4/SHT/20/X

-SPI_CS_2

SPI_DQ2(16) N_ICH_SPI_CLK (16,43)

R13 0/4/SHT/20/X

R10 22/4

SPI_MISO

-SPI_WP0

R12 22/4

SPI_MISO

-SPI_WP1N_-ICH_SPI_CS

5

M_BIOS

1

CS#

2

SO

3

WP#

4

VSS

128M/Q/SPI/SO8/S/[10HP4-112512-20R]

B_BIOS

1

CS#

2

SO

3

WP#

4

VSS

128M/Q/SPI/SO8/S/[10HP4-112512-20R]

VDD

HOLD#

SCK

VDD

HOLD#

SCK

8
7
6
5

SI

MAIN BIOS

8
7
6
5

SI

BACKUP BIOS

4

VCC3_ME

R14
0/4/SHT/M/X

C3
1u/4/X5R/6.3V/K

R16

8.2K/4/X

N_ICH_SPI_CLK
ICH_SPI_MOSI

VCC3_ME

R223
0/4/SHT/M/X

NBC52
1u/4/X5R/6.3V/K

R17

8.2K/4/X

N_ICH_SPI_CLK
N_ICH_SPI_MOSI

-SPI_HOLD_M

R18 0/4/SHT/20/X

-SPI_HOLD_B

VCC3_ME

R15 0/4/SHT/20/X

C5
10p/4/NPO/50V/J/X

SPI_DQ3 (16)

N_ICH_SPI_MOSI (16,43)

3

C2

0.1u/4/X7R/16V/K

SPI_DQ3 (16)

MOSI For DMI RX Termination Voltage

N_ICH_SPI_MOSI(16,43)

N_-ICH_SPI_CS(16)

-SPI_HOLD0(28)

-SPI_HOLD1(28)

N_ICH_SPI_MISO(16,43)

M_BIOS

LCP/G-FL/1.27mm/200MIL/WHITE[10SL2-000008-31R]/X

2

SPI_MISO

ICH_SPI_MOSI

-ICH_SPI_CS

-SPI_HOLD0

-SPI_HOLD1

-SPI_WP1

-SPI_WP0

ICH_SPI_MISO

NR6 22/4

R19 8.2K/4/X
R20 8.2K/4/X
R21 8.2K/4
R22 8.2K/4

R23 8.2K/4/X
R24 8.2K/4/X
R25 8.2K/4

N_ICH_SPI_MISO (16,43)

-SPI_HOLD_B

-SPI_HOLD_M

R215

-SPI_HOLD_PH

R221

1

VCC3_ME

VCC3_ME

VCC3_ME

1K/4/1
1K/4/1

R26

1K/4/1

DIS_DB1

DIS_DB2

D8

BAT54C/SOT23/200mA

ECB_GPIO1 (43)

LED/O/6/S[10DL3-22000O-02R]

VCC

R28

R31
1K/4/1/X

R34

8.2K/4

B B

B_SW(28)

A A

SW/1/B/DIP/[11NH7-110003-21R]

8

-SPI_HOLD_M

B_SW

ON

G2 G1

BIOS_SW

1
2
3

MBIOS_LED

5VDUAL

R42
1K/4/1

VCC

D

G S

2

1K/4/1

7

VCC

R27
680/6

3

D

G S

2

1

5VDUAL

R33
1K/4/1/X

3

Q50
2N7002/SOT23/25pF/5

1

󲦡󲦡󲦡󲦡

Q46
2N7002/SOT23/25pF/5

R32

8.2K/4

R43
1K/4/1

R35 8.2K/4

-SPI_HOLD_M

Q47

MMBT2222A/SOT23/600mA/40

SOT23

132

-SPI_HOLD0 (28)

-SPI_HOLD_M

Q51

MMBT2222A/SOT23/600mA/40

SOT23

132

-SPI_HOLD1 (28)

6

LED/O/6/S[10DL3-22000O-02R]

-SPI_HOLD_B

R30

R36

R37

5

BBIOS_LED

8.2K/4

8.2K/4

8.2K/4

VCC

R29
680/6

󲦡󲦡󲦡󲦡

3

D

Q48

G S

2N7002/SOT23/25pF/5

2

1

-SPI_HOLD_B

Q49

MMBT2222A/SOT23/600mA/40

SOT23

132

-SPI_HOLD1 (28)

-SPI_HOLD_B

Q52

MMBT2222A/SOT23/600mA/40

SOT23

132

-SPI_HOLD0 (28)

4

BIOS_PH

N_-ICH_SPI_CS

N_ICH_SPI_MISO

R38 0/4/X
R39 0/4/X

SB_SW

1

R237 100/4/1

2

ON

3

G2 G1

SB

SW/1/B/DIP/[11NH7-110003-21R]

3

BIOS_PH

3
5 6

9 10

2
4

8

-SPI_HOLD_PH

R40 0/4/X
R41 0/4/X

N_-SPI_CS
N_SPI_MISO

MASK/PH/2*5K1,K7/BK/2.54/VA/D[11NH2-020205-81R]/X

VCC3_ME

N_ICH_SPI_CLK
N_ICH_SPI_MOSI

󲒇󱙱󵓀󱊪󲐔󰵖󱅹󳗍󱙹󲔂

-DUAL_BIOSDIS (28,42)

Gigabyte Technology

Title

Size Document Number Rev
Custom

Date: Sheet of

DUAL BIOS

GA-X99-UD5 WIFI

2

29 64Tuesday, August 26, 2014

1

1.0

5

4

3

2

1

VCC

DAR61

5.76K/4/1

DAR60
1K/4/1

D D

ISEN8(31)

IRTN8(31)

IRTN1
IRTN2
IRTN3
IRTN4
IRTN5
IRTN6
IRTN7
IRTN8

V18A

VR_RDY

VR_RDY(28)

VREF1_8

DAC24

0.01u/4/X7R/25V/K

VREF1_8

C C

B B

DAR6 0/4/SHT/X
DAR9 0/4/SHT/X
DAR12 0/4/SHT/X
DAR15 0/4/SHT/X
DAR18 0/4/SHT/X
DAR5 0/4/SHT/X
DAR21 0/4/SHT/X
DAR39 0/4/SHT/X

DAR80 0/4/SHT/20/X

DAR48 10K/4/1

ISEN7(31)
IRTN7(31)
ISEN5(31)
IRTN5(31)
ISEN4(31)
IRTN4(31)
ISEN3(31)
IRTN3(31)
ISEN2(31)
IRTN2(31)
ISEN1(31)
IRTN1(31)

IRTN6(31)
ISEN6(31)

DAR23 10K/4/1

DAR20 10K/4/1

DAR17 10K/4/1

DAR14 10K/4/1

DAR11 10K/4/1

DAR8 10K/4/1

DAR4 10K/4/1

VCC_SENSE(9)

VSS_SENSE(9)

8.45K/4/1

VCORE

DAR1

100/4/1

DAR49 0/4/SHT/20/X

DAR2

100/4/1

DAR93 2.49K/4/1

DAR94 2.49K/4/1

DAR95 2.49K/4/1

DAR96 2.49K/4/1

DAR97 2.49K/4/1

DAR98 2.49K/4/1

DAR99 2.49K/4/1

DAR100 2.49K/4/1

DAR41

DAC11

3.3n/4/X7R/50V/K

3VDUAL

VCC3

DAR57

0/4/SHT/20/X

0/4/X

PWM_VCC

DAC12

1u/4/X5R/6.3V/K

37
38
39

41
42
43
44
45
46
47
48
49

VCORE_RCSP

DAC9
47p/4/NPO/50V/J

VCORE_RCSM

For Phase margin and
gain margin measure

VSEN

VSEN-

DAR55

DAC13

0.1u/4/X7R/16V/K

ISEN7
IRTN7
ISEN5
IRTN5
ISEN4
IRTN4
ISEN3
IRTN3
ISEN2
IRTN2
ISEN1
IRTN1
GND_TH

PWM8 (31)
PWM7 (31)
PWM6 (31)
PWM5 (31)
PWM4 (31)
PWM3 (31)
PWM2 (31)
PWM1 (31)

25

34

354036

334

32

NC

VCCRCSM

IRTN8

ISEN8

PWM7

PWM8

IR3580

VRTN

ISEN6

IRTN6

VSEN

RCSP

6

2

1

5

3

DAC14

0.01u/4/X7R/25V/K

2631272829

307

PWM1

PWM2

PWM3

PWM4

PWM5

PWM6RRES

INMODE/PWROK

TSEN1

VRDY1

V18A

8

111310

9

V18A

VR_RDY

DAR54 7.5K/4/1/X

DAC16
1u/4/X5R/6.3V/K

DAR109 8.2K/4

VCC3

VDG/VAUXSEN

SM_CLK

SM_DIO

SM_ALERT

ADDR_PROT

VRHOT_ICRIT
SV_DIO/ VIDSEL0
SV_CLK/VIDSEL1

SV_ALERT#

SV_ADDR/VDDIO

VINSEN

12

DAR62 8.2K/4

DAC18

4.7u/6/X5R/6.3V/K

DAR58

13K/4/1

24
23
22
21
20
19

EN

18
17
16
15
14

NC

DAU1

IR3580-8+0_B/[10TA1-603580-04R]

VCC3

CPU_TSEN_R1

DAR59

-CPU_TSEN_R1

0/4/SHT/X

125 degree assert

DAC15

0.01u/4/X7R/25V/K

10p/4/NPO/50V/J/X

DAR79 4.7K/4

VRHOT_ICRIT

SV_ADDR

DAC19

10p/4/NPO/50V/J/X

DAR71

V12

DAC17

SV_DIO
SV_CLK
SV_ALERT

8.2K/4

DAL1

150nH/61A/S/0.29m/[10LC5-61150C-00R]

R15

DAC6

1u/6/X7R/16V/K

270u/FP/D/16V/88/C/12m

Debug Only

DAC23

22p/4/NPO/50V/J/X

VCC3

DAR107 0/4/SHT/20/X

DAR74 845/4/1

DAC21 0.01u/4/X7R/25V/K
DAR106 475/4/1/X
DAC8 0.1u/4/X7R/16V/K/X

VCC3

DAEC5

560u/FP/D/6.3V/68/C/8m

DART7_8
47K/1/4/S

DAEC13

560u/FP/D/6.3V/68/C/8m

DAR108 0/4/X

VCORE_EN (37,38)
VCCIO_PWRGD (38)

DAR65 2.2/4
DAR64 2.2/4
DAR63 2.2/4

VIN

DAR81
13K/4/1

DAR73
1K/4/1

VCORE VCORE VCOREVCORE V COREVCORE VCOREVCORE

1

+

DAEC6

560u/FP/D/6.3V/68/C/8m

560u/FP/D/6.3V/68/C/8m

VCORE

1

+

1

+

+

DAEC3

270u/FP/D/16V/88/C/12m

DAR68 0/4/SHT/20/X
DAR67 0/4/SHT/20/X

DAC22 0.01u/4/X7R/25V/K
DAR66 845/4/1

DAC7

0.01u/4/X7R/25V/K

DAC20

0.01u/4/X7R/25V/K

1

+

1

1

+

DAEC2

DAEC1

270u/FP/D/16V/88/C/12m

270u/FP/D/16V/88/C/12m

Remove PinHeader in

3

modify PBOM

DAJP1

2
1

PH/1*3/BK/2.54/VA/D/X

N_SMBCLK (16,20,21,23 ,24,25,26,27,34,35,37,42,47,58)
N_SMBDATA (16,20,21,23,24,25,26,27,34,35,37,42,47,58)

PWM_VCC

DAR78

8.2K/4

1

+

DAEC7

560u/FP/D/6.3V/68/C/8m

1

+

DAEC4

Addr: 70h

DAR77
115/4/1

DAC3

10p/4/NPO/50V/J/X

1

+

DAEC8

560u/FP/D/6.3V/68/C/8m

VIN

VCCIO

DAR76
51/4/1

DAC2

10p/4/NPO/50V/J/X

10p/4/NPO/50V/J/X

+

DAEC9

560u/FP/D/6.3V/68/C/8m

1

DAR75
200/4/1/X

DAC1

DAC10
1u/4/X5R/6.3V/K

A_VIDSOUT (7)
A_VIDSLCK (7)
A_-VIDALRT (7)

VRHOT_ICRIT

1

+

DAEC10

560u/FP/D/6.3V/68/C/8m

DAD1

BAT54C/SOT23/200mA

1

+

DAEC11

DAR102 0/4/X
DAR103 0/4/SHT/20/X

+

DAEC12

560u/FP/D/6.3V/68/C/8m

A_-PROCHOT (7,28)
N_-THRMTRIP (7,15,28,31,32,33)

1

MOS HEATSINK

1

MOS_HS1

1

PLX HEATSINK

A A

5

4

3

2

1

MOS HS/X

MOS_HS2

1

MOS HS/X

2

2

Title

IR 3580

Size Docu ment Number Rev

Custom

Date: Sheet of

2

2

GA-X99-UD5 WIFI 1.0

1

30 64Tuesday, August 26, 2014

10u/8/X6S/16V/K
10u/8/X6S/16V/K

DA_DC1

24

FAULT

D D

25
26

ISEN1(30)

27

VCC

28
29

PWM1(30)

30

IRTN1(30)

VCC

1u/6/X7R/16V/K

VIN

DA_DC6

23

22

VIN6

VIN5

VIN4

VIN7

NC
TOUT/FAULT

IR3555/6/7 6x6

IOUT
ZCD_EN#
LGND
PWM
REFIN

VCC

VDRV

123

DA_DC5

5

DA_DC2

0.22u/6/X7R/16V/K

16

19

17

18

202134

33

DA_DU1

VIN2

VIN1

VIN3

PGND2

PGND3

PGND5

15

SW10

14

SW9

13

SW8

12

SW7

11

SW6

10

SW5

9

SW4

8

SW3

7

SW2

BOOST

PGND1

LGATE1

SW1

PGND

LGATE2

IR3556MTRPBF/PQFN32

4

5

6

31

32

DA_DC3 0.22u/6/X7R/16V/K

BOOST1 PHASE1

PHASE1

DA_DL1

150nH/61A/S/0.29m/[10LC5-61150C -00R]

R15

Width=30mil CAP Close to PIN

VCORE

4

10u/8/X6S/16V/K
10u/8/X6S/16V/K

DB_DC1

FAULT

ISEN2(30)

VCC

PWM2(3 0)
IRTN2(30)

VCC

Width=30mil CAP Close to PIN

24

NC

25

TOUT/FAULT

26

IOUT

27

ZCD_EN#

28

LGND

29

PWM

30

REFIN

DB_DC5

1u/6/X7R/16V/K

DB_DC6

VIN7

VIN

19

18

23

22

202134

VIN2

VIN1

VIN6

VIN5

VIN3

VIN4

IR3555/6/7 6x6

BOOST

VCC

VDRV

12345

DB_DC2

0.22u/6/X7R/16V/K

16

17

33

DB_DU1

PGND2

PGND3

PGND5

SW10

SW9
SW8

SW7

SW6
SW5
SW4
SW3
SW2

PGND1

LGATE1

PGND

LGATE2

6

31

32

DB_DC3 0.22u/6/X7R/16V/K

15
14

13
12

11
10
9
8
7

SW1

IR3556MTRPBF/PQFN32

PHASE2

PHASE2BOOST2

3

DB_DL1

150nH/61A/S/0.29m/[10LC5-61150C -00R]

R15

VCORE

10u/8/X6S/16V/K
10u/8/X6S/16V/K

VCC

ISEN3(30)

VCC

PWM3(3 0)
IRTN3(30)

DC_DC6

DC_DC1

23

22

VIN6

VIN5

VIN7

24

NC

FAULT

25

TOUT/FAULT

IR3555/6/7 6x6

26

IOUT

27

ZCD_EN#

28

LGND

29

PWM

30

REFIN

VCC

12345

DC_DC5

1u/6/X7R/16V/K

Width=30mil CAP Close to PIN

2

VIN

202134

VIN4

VDRV

19

18

VIN2

VIN3

BOOST

17

33

VIN1

PGND5

PGND1

PGND

31

DC_DC3 0.22u/6/X7R/16V/K

DC_DC2

0.22u/6/X7R/16V/K

16

DC_DU1

PGND2

PGND3

SW10

SW9
SW8

SW7

SW6
SW5
SW4
SW3
SW2

LGATE1

SW1

LGATE2

6

32

PHASE3

15
14

13
12

11
10
9
8
7

IR3556MTRPBF/PQFN32

150nH/61A/S/0.29m/[10LC5-61150C -00R]

PHASE3BOOST3

DC_DL1

VCORE

R15

1

VCORE

VCORE

10u/8/X6S/16V/K
10u/8/X6S/16V/K

FAULT

ISEN6(30)

VCC

PWM6(30)
IRTN6(30)

VCC

DF_DC1

24

NC

25

TOUT/FAULT

26

IOUT

27

ZCD_EN#

28

LGND

29

PWM

30

REFIN

DF_DC5

1u/6/X7R/16V/K

DF_DC6

VIN7

VIN

19

18

23

22

202134

VIN2

VIN1

VIN6

VIN5

VIN3

VIN4

IR3555/6/7 6x6

BOOST

PGND1

VCC

VDRV

12345

2

DF_DC2

0.22u/6/X7R/16V/K

16

17

33

DF_DU1

PGND2

PGND3

PGND5

SW10

SW9
SW8

SW7

SW6
SW5
SW4
SW3
SW2

LGATE1

SW1

PGND

LGATE2

6

31

32

DF_DC3 0.22u/6/X7R/16 V/K

PHASE6

15
14

13
12

11
10
9
8
7

IR3556MTRPBF/PQFN32

PHASE6BOOST6

DF_DL1

150nH/61A/S/0.29m/[10LC5-61150C -00R]

R15

VCORE

Title

VCORE MOSFET

Size Doc ument Number R ev

Custom

Date: Sheet of

GA-X99-UD5 WIFI 1.0

1

31 6 4Tuesday, August 26, 2014

10u/8/X6S/16V/K

VCC

ISEN5(30)

VCC

PWM5(3 0)
IRTN5(30)

10u/8/X6S/16V/K

DE_DC1

FAULT

24

NC

25

TOUT/FAULT

26

IOUT

27

ZCD_EN#

28

LGND

29

PWM

30

REFIN

DE_DC5

1u/6/X7R/16V/K

DE_DC6

VIN7

VIN

19

18

23

22

202134

VIN2

VIN1

VIN6

VIN5

VIN3

VIN4

IR3555/6/7 6x6

BOOST

PGND1

VCC

VDRV

12345

DE_DC2

0.22u/6/X7R/16V/K

16

17

33

DE_DU1

PGND2

PGND3

PGND5

SW10

SW9
SW8

SW7

SW6
SW5
SW4
SW3
SW2

LGATE1

SW1

PGND

LGATE2

6

31

32

DE_DC3 0.22u/6/X7R/16V/K

PHASE5

15
14

13
12

11
10
9
8
7

IR3556MTRPBF/PQFN32

150nH/61A/S/0.29m/[10LC5-61150C -00R]

PHASE5BOOST5

DE_DL1

R15

Width=30mil CAP Close to PIN Width=30mil CAP Close to PIN

10u/8/X6S/16V/K
10u/8/X6S/16V/K

DH_DC1

FAULT

ISEN8(30)

VCC

PWM8(30)
IRTN8(30)

VCC

24

NC

25

TOUT/FAULT

26

IOUT

27

ZCD_EN#

28

LGND

29

PWM

30

REFIN

DH_DC5

1u/6/X7R/16V/K

DH_DC6

VIN7

VIN

19

18

23

22

202134

VIN2

VIN1

VIN6

VIN5

VIN3

VIN4

IR3555/6/7 6x6

BOOST

PGND1

VCC

VDRV

12345

DH_DC2

0.22u/6/X7R/16V/K

16

17

33

DH_DU1

PGND2

PGND3

PGND5

SW10

SW9
SW8

SW7

SW6
SW5
SW4
SW3
SW2

LGATE1

SW1

PGND

LGATE2

6

31

32

DH_DC3 0.22u/6/X7R/16V/K

PHASE8

15
14

13
12

11
10
9
8
7

IR3556MTRPBF/PQFN32

150nH/61A/S/0.29m/[10LC5-61150C -00R]

PHASE8BOOST8

DH_DL1

R15

Width=30mil CAP Close to PIN

3

10u/8/X6S/16V/K
10u/8/X6S/16V/K

VIN

DD_DC6

DD_DC1

C C

FAULT

ISEN4(30)

VCC

PWM4(3 0)
IRTN4(30)

VCC

24

NC

25

TOUT/FAULT

26

IOUT

27

ZCD_EN#

28

LGND

29

PWM

30

REFIN

DD_DC5

1u/6/X7R/16V/K

VIN7

23

22

202134

VIN6

VIN5

VIN4

IR3555/6/7 6x6

DRV

VCC

V

123

19

18

VIN2

VIN3

BOOST

33

VIN1

PGND5

PGND1

PGND

4

31

DD_DC2

0.22u/6/X7R/16V/K

16

17

DD_DU1

PGND2

PGND3

15

SW10

14

SW9

13

SW8

12

SW7

11

SW6

10

SW5

9

SW4

8

SW3

7

SW2

LGATE1

SW1

LGATE2

IR3556MTRPBF/PQFN32

5

6

32

DD_DC3 0.22u/6/X7R/16V/K

PHASE4

PHASE4BOOST4

DD_DL1

150nH/61A/S/0.29m/[10LC5-61150C -00R]

R15

VCORE

Width=30mil CAP Close to PIN

B B

A A

10u/8/X6S/16V/K
10u/8/X6S/16V/K

DG_DC1

24

FAULT

25
26

ISEN7(30)

27

VCC

28
29

PWM7(3 0)

30

IRTN7(30)

VCC

1u/6/X7R/16V/K

Width=30mil CAP Close to PIN

VIN

DG_DC6

23

22

VIN6

VIN5

VIN4

VIN7

NC
TOUT/FAULT

IR3555/6/7 6x6

IOUT
ZCD_EN#
LGND
PWM
REFIN

DRV

VCC

V

12345

DG_DC5

19

202134

VIN3

5

18

VIN2

VIN1

BOOST

PGND1

PGND

31

DG_DC2

0.22u/6/X7R/16V/K

16

17

33

DG_DU1

PGND2

PGND3

PGND5

15

SW10

14

SW9

13

SW8

12

SW7

11

SW6

10

SW5

9

SW4

8

SW3

7

SW2

LGATE1

SW1

LGATE2

IR3556MTRPBF/PQFN32

6

32

DG_DC3 0.22u/6/X7R/16V/K

DAR10 100K/4/1/X

FAULT

PHASE7

PHASE7BOOST7

DAR3
100K/4/1/X

DG_DL1

150nH/61A/S/0.29m/[10LC5-61150C -00R]

R15

N_-THRMTRIP

3

D

DAQ1

G S

2N7002/SOT23/25pF/5/X

SOT23

2

1

VCORE

N_-THRMTRIP (7,15,28,30,32,33)

4

5

DDR_A

DDR_A(3553)

MA_VIN

MAAC42

D D

MAAC44 0.22u/6/X7R/16V/K

5VDUAL

C C

N_-THRMTRIP(7,15,28,30,31,33)

DDRA_PHSFLT-

MA_PWM1(34)

MAAR3 0/4/SHT/20/X

17

BOOST

18

PHSFLT#

19

PWM

20

BBRK#
LGND

22

REFIN

23

IOUT

MAAC45

1u/6/X7R/16V/K

123

DDRA_PHSFLT-

0.1u/4/X7R/16V/K/X

24

TGND

CSIN-

CSIN+

MAAC40

VCC

1u/4/X5R/6.3V/K

16

15

27

VIN

VIN

MAAC41

14

VIN

VIN

PGND

PGND

4

122125

13

PGND

PGND

26

10u/6/X5R/6.3V/M

MAAC43
10u/6/X5R/6.3V/M

MAAU4
IR3553MTRPBF/PQFN25

SW6
SW5
SW4
SW3
SW2
SW1

LGATE1

LGATE2

5

0.5uH/25A/INC0909/F/D

MA_PHASE1

11
10
9
8
7
6

MA_ISEN1(34)

MA_IRTN1(34)

MAL1

MAAC8

1u/4/X5R/6.3V/K

MAAL1

R15

0.3uH/32A/SLPI107975MT/S

MAAR1

1.02K/4/1

1u/4/X5R/6.3V/K

MAAR4 340/4/1/X

MACS1_TP

4

5VDUAL

MAAC46

Close Choke

MAAC7

0.1u/4/X7R/16V/K

MA_VIN

DDR_12V_A

MAAR2
0/4/SHT/M/X

MACS2_TP

15A@1.8

15A@1.8

15A@1.8V15A@1.8

DDR_12V_A

+

MAEC3
560u/FP/D/6.3V/68/C/8m

DDR_12V_A

V

V

V

+

MAEC2
560u/FP/D/6.3V/68/C/8m

MAEC1

560u/FP/D/6.3V/68/C/8m

15A@1.8

15A@1.8

15A@1.8V15A@1.8

1

1

+

1

1

+

V

V

V

MAEC4
560u/FP/D/6.3V/68/C/8m

DDR_12V_A

1

+

MAEC6
560u/FP/D/6.3V/68/C/8m

3

DDR_B

DDR_B(3553)

MBAC44 0.22u/6/X7R/16V/K

5VDUAL DDR_12V_B

MB_PWM1(35)

N_-THRMTRIP(7,15,28,30,31,33)

DDRB_PHSFLT-

17

BOOST

18

PHSFLT#

19

PWM

20

BBRK#
LGND

22

REFIN

23

IOUT

MBAC45

1u/6/X7R/16V/K

MBAR3 0/4/SHT/20/X

123

DDRB_PHSFLT-

MB_VIN

MBAC40

0.1u/4/X7R/16V/K/X

24

TGND

CSIN-

CSIN+

16

27

VIN

VCC

MBAC41

1u/4/X5R/6.3V/K

14

15

VIN

VIN

VIN

PGND

PGND

4

122125

MBAC42
10u/6/X5R/6.3V/M

PGND

PGND

13

26

MBAU4
IR3553MTRPBF/PQFN25

LGATE1

5

MBAC43
10u/6/X5R/6.3V/M

SW6
SW5
SW4
SW3
SW2
SW1

LGATE2

2

5VDUAL

MBL1

0.5uH/25A/INC0909/F/D

MBAC8

1u/4/X5R/6.3V/K

MB_PHASE1

11
10
9
8
7
6

MB_ISEN1(35)

MB_IRTN1(35)

MBAL1

R15

0.3uH/32A/SLPI107975MT/S

MBAR1

MBAC46

1.02K/4/1

1u/4/X5R/6.3V/K

MBAR4 340/4/1/X

MBCS1_TP

MBAR2
0/4/SHT/M/X

MBCS2_TP

Close Choke

MBAC7

0.1u/4/X7R/16V/K

MB_VIN

1

+

MBEC7

560u/FP/D/6.3V/68/C/8m

DDR_12V_B

MBAC1

22u/8/X5R/6.3V/M

Option for layout ,close to choke

Option for layout ,close to choke

Option for layout ,close to choke

Option for layout ,close to choke

1

560u/FP/D/6.3V/68/C/8m

DDR_12V_B

1

+

MBEC3
560u/FP/D/6.3V/68/C/8m

MBAC2

22u/8/X5R/6.3V/M

MBEC6

15A@1.8

15A@1.8

15A@1.8V15A@1.8

.

.

.

.

1

+

V

V

V

1

+

MBEC4
560u/FP/D/6.3V/68/C/8m

DDR_A(3553)

MA_VIN

MABC42
10u/6/X5R/6.3V/M

MABC40

0.1u/4/X7R/16V/K/X

MABC44 0.22u/6/X7R/16V/K

5VDUAL

B B

A A

MA_PWM2(34)

DDRA_PHSFLT-

17

BOOST

18

PHSFLT#

19

PWM

20

BBRK#
LGND

22

REFIN

23

IOUT

MABC45

1u/6/X7R/16V/K

5

24

TGND

CSIN-

CSIN+

123

16

27

VIN

VIN

VCC

MABC43
10u/6/X5R/6.3V/M

MABC41

1u/4/X5R/6.3V/K MBBC44 0.22u/6/X7R/16V/K

MABU4

14

15

IR3553MTRPBF/PQFN25

VIN

VIN

PGND

PGND

4

122125

13

MA_PHASE2

11

SW6

10

SW5

9

SW4

8

SW3

7

SW2

6

SW1

LGATE1

LGATE2

PGND

PGND

5

26

MA_ISEN2(34)

MA_IRTN2(34)

MABL1

R15

0.3uH/32A/SLPI107975MT/S

MABR1

1u/4/X5R/6.3V/K

1.02K/4/1

MABR4 340/4/1/X

MACS3_TP

DDR_12V_A

MABR2
0/4/SHT/M/X

MABC46

MACS4_TP

4

DDR_B(3553)

5VDUAL

3

DDRB_PHSFLT-

MB_PWM2(35)

17

BOOST

18

PHSFLT#

19

PWM

20

BBRK#
LGND

22

REFIN

23

IOUT

MBBC45

1u/6/X7R/16V/K

0.1u/4/X7R/16V/K/X

24

TGND

CSIN-

CSIN+

123

MB_VIN

MBBC40

27

VCC

1u/4/X5R/6.3V/K

16

15

VIN

VIN

VIN

MBBC41

14

VIN

PGND

PGND

PGND

4

122125

13

26

MBBC42
10u/6/X5R/6.3V/M

MBBU4
IR3553MTRPBF/PQFN25

LGATE1

PGND

5

MBBC43
10u/6/X5R/6.3V/M

SW6
SW5
SW4
SW3
SW2
SW1

LGATE2

2

MB_PHASE2

11
10
9
8
7
6

MB_ISEN2(35)

MB_IRTN2(35)

MBBL1

R15

0.3uH/32A/SLPI107975MT/S

MBBR1

1.02K/4/1

1u/4/X5R/6.3V/K

MBBR4 340/4/1/X

MBCS3_TP

MBBC46

MBBR2
0/4/SHT/M/X

MBCS4_TP

DDR_12V_B

Title

ISL6322 CPUVTT

Size Document Number Rev

Custom

Date: Sheet o f

GA-X99-UD5 WIFI 1.0

1

32 64Tuesday, August 26, 2014

5

4

3

2

1

24

TGND

CSIN-

CSIN+

123

5VDUAL

MBL3

0.5uH/25A/INC0909/F/D

MBC31
1u/4/X5R/6.3V/K

MB_VPPIN

16

27

VIN

VCC

MBC45

1u/4/X5R/6.3V/K

14

15

VIN

VIN

VIN

PGND

PGND

4

122125

13

MBC29
1u/4/X5R/6.3V/K

Close Choke

PGND

PGND

26

MBC24
10u/6/X5R/6.3V/M

MBU5
IR3553MTRPBF/PQFN25

11

SW6

10

SW5

9

SW4

8

SW3

7

SW2

6

SW1

LGATE1

LGATE2

5

MBC30

0.1u/4/X7R/16V/K

MBC25
10u/6/X5R/6.3V/M

MB_VPP_PHASE1

MBR74
1K/4/1

VPPBCS1_TP

MBL2

0.5uH/25A/INC0909/F/D

MBC27

1u/4/X5R/6.3V/K

MBR81 340/4/1

VPP_25V_B

1

+

MBEC10
560u/FP/D/6.3V/68/C/8m

VPP_25V_B

MBR73
0/4/SHT/M/X

VPPBCS2_TP

1

+

MBEC11
560u/FP/D/6.3V/68/C/8m

MA_VPPIN

MAC2
10u/6/X5R/6.3V/M

MAC4
10u/6/X5R/6.3V/M

MAL2

0.5uH/25A/INC0909/F/D

MA_VPP_PHASE1

11

SW6

10

SW5

9

SW4

8

SW3

7

SW2

6

SW1

LGATE2

VPP_25V_A

30A@1.1

30A@1.1

30A@1.1V30A@1.1

1

+

MAEC10
560u/FP/D/6.3V/68/C/8m

MAR62
1K/4/1

VPPACS1_TP

V

V

V

1

+

MAEC11
560u/FP/D/6.3V/68/C/8m

1u/4/X5R/6.3V/K

MAR35 340/4/1

VPP_25V_A

MAR63
0/4/SHT/M/X

MAC5

VPPACS2_TP

1

VPP_25_A

5VDUAL

N_-THRMTRIP(7,15,28,30,31,32)

MA_VPPIN

󴾩󵘫

pin17& Phase

MA_VPP_PWM1(34)

MA_VPP_IRTN1(34)
MA_VPP_ISEN1(34)

VR1 0/4/SHT/20/X

MAC3 0.22u/6/X7R/16V/K

MA_VPP_PHSFLT-

MA_VPP_PHSFLT-

5VDUAL

MAL3

0.5uH/25A/INC0909/F/D

MAC18
1u/4/X5R/6.3V/K

17

BOOST

18

PHSFLT#

19

PWM

20

BBRK#
LGND

22

REFIN

23

IOUT

MAC6

1u/6/X7R/16V/K

MAC7
1u/4/X5R/6.3V/K

Close Choke

123

D D

C C

MA_VPPIN

+

MAEC12

560u/FP/D/6.3V/68/C/8m

24

TGND

CSIN-

27

VIN

CSIN+

VCC

MAC8

0.1u/4/X7R/16V/K

16

15

VIN

MAC46

1u/4/X5R/6.3V/K

14

VIN

VIN

PGND

PGND

4

122125

13

PGND

PGND

5

26

MAU5
IR3553MTRPBF/PQFN25

LGATE1

VPP_25_B

5VDUAL

MB_VPP_IRTN1(35)
MB_VPP_ISEN1(35)

N_-THRMTRIP(7,15,28,30,31,32)

MBEC12

560u/FP/D/6.3V/68/C/8m

󴾩󵘫

pin17& Phase

MB_VPP_PWM1(35)

VR2 0/4/SHT/20/X

MB_VPPIN

1

+

MBC26 0.22u/6/X7R/16V/K

MB_VPP_PHSFLT-

MB_VPP_PHSFLT-

MB_VPPIN

17

BOOST

18

PHSFLT#

19

PWM

20

BBRK#
LGND

22

REFIN

23

IOUT

MBC28

1u/6/X7R/16V/K

B B

A A

Title

<Title>

Size Document Number Rev

GA-X99-UD5 WIFI 1.0

Custom

5

4

3

2

Date: Sheet o f

1

33 64Tuesday, August 26, 2014

5

4

MAC19

1u/4/X5R/6.3V/K

3VDUAL

MAFB1

0/4/SHT/20/X

MA_PWM_VCC

MAC20

0.1u/4/X7R/16V/K

3

DDR_12V_A

2

1

D D

2

MAR77

8.2K/4

MA_VSEN

MAC22

3.3n/4/X7R/50V/K

25

2631272829

24

23

VCC

Vsen_L2

RCSM_L2

RCSM

Vsen

VRRDY_L2

4

3

Vrtn_L2

Vrtn

5

PWM1_L2

PWM2_L2

Tsen1

Pres

6

7

MAR82 7.5K/4/1

0.01u/4/X7R/25V/K

PWM3

VR_HOT/Icritical

V18A

8

3

MA_RCSM_R

MA_VPP_ISEN1(33)
MA_VPP_IRTN1(33)

MART1

10K/1/4/S

MA_ISEN1(32)
MA_IRTN1(32)
MA_ISEN2(32)
MA_IRTN2(32)

MAR50

2.15K/4/1

MA_RCSP_R

MAR105 1.5K/4/1

MAR49 1.5K/4/1

MAR51 1.5K/4/1

Close to Vcore
output inductor

C C

MA_VTT_RCSP_R

MART2

10K/1/4/S

MA_VTT_RCSM_R

B B

should be routed as
differential pair,
7mil width,8mil
spacing

DDR_12V_A

MAR85 1.69K/4/1

MAR84

2.26K/4/1
MAR83 1.69K/4/1

MA_ISEN1
MA_IRTN1
MA_ISEN2
MA_IRTN2

MAR107 49.9/4/1

MA_VTT_RCSP

MAC30
220p/4/NPO/50V/J

MA_VTT_RCSM

Diff pair

VPP_25V_A

MAR53

200/4/1

MAR55

0/4/SHT/20/X

MAR33 0/4/SHT/20/X

DDRVTT

MAC37

1u/4/X5R/6.3V/K

A A

MAC10

1u/4/X5R/6.3V/K

MA_VTT_ADJ MA_VTT_REF

VTT_ADJ(37)

5

RT9173DPSP/3A/SO8/S[10GL2-309173-20R]

MAR40
1K/4/1

MA_VTT_REF

MAR41
1K/4/1

1
2
3
4 5

MAR92

0/4/SHT/X

MAU2

VIN
GND

ENABLE
VREF1
VOUT BOOT_SEL

GND

9

DDRVTT_A

VREF2

VCNTL

VCC

8
7
6

MAC38
10u/6/X5R/6.3V/M

For power sequence require

MAR46 301/4/1
MAR45 301/4/1
MAR44 301/4/1
MAR43 301/4/1

MAR47 301/4/1
MAR48 301/4/1

DDR_12V_A_PG(35)

MAR34

1K/4/1

VPP_25V_A

MAR74
10K/4/1

MAR73
1K/4/1/X

4

MA_RCSM

MAC21
150p/4/NPO/50V/J

MA_RCSP

MAC31

3.3n/4/X7R/50V/K

3VDUAL

MAC32

0.1u/4/X7R/16V/K

MA_ISEN1_L2
MA_IRTN1_L2
MA_ISEN2_L2
MA_IRTN2_L2
MA_ISEN3_L1

MA_ISEN2_L1

MA_ISEN1_L1
MA_IRTN1_L1

DDR_12V_A

MAR75
22K/4

132

MMBT2222A/SOT23/600mA/40

MAQ5

SOT23

32
33
34
35
36

38
39
40
41

MAR52

8.2K/4/X

VPP_25V_A

3

D

G S

2

MAR76

1

ISEN1_L2
IRTN1_L2
ISEN2_L2
IRTN2_L2
ISEN3
IRTN3

IRTN2
ISEN1
IRTN1
GND

8.2K/4/X

30

RCSP_L2

RCSP

1

MA_VPP_SEN

3VDUAL

MA_EN MA_EN

MAQ6
2N7002/SOT23/25pF/5

SOT23

MAR79

0/4/SHT/20/X

MAR80
0/4/SHT/20/X

MAR81 0/4/SHT/20/X

MA_PWM1

MA_PWM2

MAU40

22

21

IR3570A-C-2+1[10TA1-603570-ANR]

WM2
P

PWM1

20

SM_CLK

19

SM_DIO

18

ADDR_PROT

17

EN

16
15

SV_DIO

1437

SV_CLKISEN2

13

SV_ALERT#

12

SV_ADDR

11

Vin_sense

EN_L2/INMODE

VRRDY_L1

10

9

MA_EN

MAC29

0.01u/4/X7R/25V/K

MAR71 0/4/X

MAR58

8.2K/4/X

3VDUAL

MA_VPP_IRTN1

MA_TSEN_R1

MAC34

MAR61
13K/4/1

-PSON(28,35,38,40,42)

N_-SLP_S3(16,28,35,37,38,39,42)

POWER ISSUE

0.1u/4/X7R/16V/K/X

MA_VPP_EN

MAC26 0.01u/4/X7R/25V/K
MAR86 845/4/1

MA_EN

MAR32 10/4

MAR60

0/4/SHT/X

MAR78
22K/4

MAC39

MA_PWM1 (32)
MA_PWM2 (32)

MA_VPP_PWM1 (33)

MAC23

22p/4/NPO/50V/J/X

MA_VPP_EN (38)

MAR72 8.2K/4

MA_DIO
MA_CLK
MA_ALRT

MA_EN (38)

MAC41

4.7u/6/X5R/6.3V/K

MART3
47K/1/4/S

3

D

MAQ1
2N7002/SOT23/25pF/5

G S

2

1

-PSON(28,35,38,40,42)

MAQ4
MMBT2222A/SOT23/600mA/40

SOT23

132

MAC40

2.2u/6/X5R/6.3V/K

To reduce noise

MAC25 0.01u/4/X7R/25V/K
MAR87 1.78K/4/1

5VDUAL

MAR69
13K/4/1

MAR70
1K/4/1

MAR59 75/4/1

MAC33

0.47u/6/X7R/16V/K

G S

MAC24
22p/4/NPO/50V/J/X

MA_PWM_VCC

MAC28

0.01u/4/X7R/25V/K

MA_PWM_VCC

MA_VPP_EN

3

D

MAQ3

2N7002/SOT23/25pF/5

2

1

2

MAR88 0/4/SHT/X
MAR89 0/4/SHT/X

Addr: 72h

MAR66

8.2K/4

VPP_25V_A

-DRAM_PWROK(35)

N_SMBCLK (16,20,21,23,24,25,26,27,30,35,37,42,47,58)
N_SMBDATA (16,20,21,23,24,25,26,27,30,35,37,42,47,58)

MAR68

MAR67

8.2K/4

8.2K/4

VPP_25V_A

MAR1

MAR2

82/4

82/4

3

D

MAQ7

2N7002/SOT23/25pF/5

G S

2

-PSON(28,35,38,40,42)

D3

DDR_12V_A

SOT23

BAT54A/SOT23/200mA

Rev 1.01

1u/4/X5R/6.3V/K

DDR_12V_A

MAC1

MAR26

132

8.2K/4

Title

DDR_A& CPU_VTT POWER IR3570

Size Document Number Rev

C

Date: Sheet of

1

MA_VPP_EN

MAC36

0.01u/4/X7R/25V/K

MAR22
150/4/1

MAR24 100/4/1

MAQ2

MMBT2222A/SOT23/600mA/40

SOT23

GA-X99-UD5 WIFI 1.0

1

MAR30

A_DRAM_PWROK0 (7)

MAR23

1K/4/1/X

34 64Tuesday, August 26, 2014

3VDUAL

8.2K/4

5

4

MBC3

1u/4/X5R/6.3V/K

3VDUAL

MBFB1

0/4/SHT/20/X

MB_PWM_VCC

MBC8

0.1u/4/X7R/16V/K

3

DDR_12V_B

2

1

D D

MB_VSEN

2631272829

Vsen_L2

Vsen

5

4

MBR77 0/4/SHT/20/X

MBC9

3.3n/4/X7R/50V/K

25

24

Vrtn_L2

PWM1_L2

PWM2_L2

Pres

Vrtn

Tsen1

6

7

MBR43 7.5K/4/1

MBU40

22

21

23

IR3570A-C-2+1[10TA1-603570-ANR]

PWM2

PWM1

PWM3

SM_CLK
SM_DIO

ADDR_PROT

EN

VR_HOT/Icritical

SV_DIO

SV_CLKISEN2

SV_ALERT#

SV_ADDR
Vin_sense

V18A

EN_L2/INMODE

VRRDY_L1

8

10

9

0/4/X

MBR42

MBR39

8.2K/4/X

3VDUAL

MB_VPP_IRTN1

MBR76 0/4/SHT/20/X

MB_PWM1

MB_PWM2

MB_RCSM_R

Close to Vcore
output inductor

C C

MB_VTT_RCSP_R

MBRT2

10K/1/4/S

MB_VTT_RCSM_R

B B

should be routed as
differential pair,
7mil width,8mil
spacing

DDR_12V_B

10K/1/4/S

MB_VPP_ISEN1(33)
MB_VPP_IRTN1(33)

Diff pair

Diff pair

MBRT1

MB_ISEN1(32)
MB_IRTN1(32)
MB_ISEN2(32)
MB_IRTN2(32)

MBR56

2.15K/4/1

MB_RCSP_R

MBR105 1.5K/4/1

MBR55 1.5K/4/1

MBR57 1.5K/4/1

MBR64 1.69K/4/1

MBR65

2.26K/4/1

MB_ISEN1
MB_IRTN1
MB_ISEN2
MB_IRTN2

MBR107 49.9/4/1

MB_VTT_RCSP

MBC11
220p/4/NPO/50V/J

MB_VTT_RCSM

DDR_12V_B_PG

VPP_25V_B

200/4/1

0/4/SHT/20/X

MBR66 1.69K/4/1

DDR_12V_B

MBR51

MBR50 0/4/SHT/20/X

MBR53

MBR63 301/4/1
MBR62 301/4/1
MBR61 301/4/1
MBR60 301/4/1

MBR58 301/4/1
MBR59 301/4/1

MBR54

8.2K/4/X

MBR49
1K/4/1

MB_RCSM

MBC20
150p/4/NPO/50V/J

MB_RCSP

30

MB_ISEN1_L2
MB_IRTN1_L2
MB_ISEN2_L2
MB_IRTN2_L2

MB_ISEN3_L1

MB_ISEN2_L1 MB_CLK

MB_ISEN1_L1
MB_IRTN1_L1

MBC12

3.3n/4/X7R/50V/K

ISEN1_L2

32

IRTN1_L2

33

ISEN2_L2

34

IRTN2_L2

35

ISEN3

36

IRTN3

38

IRTN2

39

ISEN1

40

IRTN1

41

GND

RCSP_L2

RCSP

1

MB_VPP_SEN

VCC

RCSM_L2

RCSM

VRRDY_L2

2

3

DDRVTT

3VDUAL

MBC36

1u/4/X5R/6.3V/K

A A

MBC10

1u/4/X5R/6.3V/K

MB_VTT_ADJ MB_VTT_REF

VTT_ADJ2(37)

5

RT9173DPSP/3A/SO8/S[10GL2-309173-20R]

MBR40
1K/4/1

MB_VTT_REF

MBR41
1K/4/1

1
2
3
4 5

MBR85

0/4/SHT/X

MBU2

VIN
GND

ENABLE
VREF1
VOUT BOOT_SEL

GND

9

DDRVTT_B

VREF2

VCNTL

VCC

8
7
6

MBC37

10u/6/X5R/6.3V/M

VPP_25V_B

MBR33
10K/4/1

MBR34
1K/4/1/X

For power sequence require

4

VPP_25V_B

3VDUAL

MBR32

G S

22K/4

MBQ4

SOT23

132

MMBT2222A/SOT23/600mA/40

MBC13

0.1u/4/X7R/16V/K

MBR30

8.2K/4/X

3

D

2

1

MBC21

MBR31

8.2K/4 MBR21

MB_EN

MBQ5
2N7002/SOT23/25pF/5

SOT23

0.01u/4/X7R/25V/K

-PSON(28,34,38,40,42) -PSON(28,34,38,40,42)

MBR23

0.1u/4/X7R/16V/K/X

3

22K/4

MBC38

N_-SLP_S3(16,28,34,37,38,39,42)

POWER ISSUE

20
19
18
17
16
15
1437
13
12
11

MB_TSEN_R1

MBR35
13K/4/1

G S

MBR78

0/4/SHT/20/X

MB_PWM1 (32)
MB_PWM2 (32)

MB_VPP_PWM1 (33)

MB_VPP_EN

MBC16 0.01u/4/X7R/25V/K
MBR79 1.78K/4/1

MB_EN

MBR38 10/4

MBR36

4.7u/6/X5R/6.3V/K

0/4/SHT/X

MB_EN

3

D

MBQ1
2N7002/SOT23/25pF/5

MBQ3

2

1

MMBT2222A/SOT23/600mA/40

SOT23

132

MBC39

2.2u/6/X5R/6.3V/K

To reduce noise

MBC22

22p/4/NPO/50V/J/X

MB_VPP_EN (38)

MBR75 8.2K/4

MB_DIO

MB_ALRT

MB_EN (38)

MBC17

0.01u/4/X7R/25V/K

MBC40

MBRT3
47K/1/4/S

2N7002/SOT23/25pF/5

5VDUAL

MBC14

0.47u/6/X7R/16V/K

MBQ2

MBR44
13K/4/1

MBR45
1K/4/1

MBR37 75/4/1

G S

MBC23
22p/4/NPO/50V/J/X

MBC15 0.01u/4/X7R/25V/K
MBR80 2.87K/4/1

MB_PWM_VCC

MBC18

0.01u/4/X7R/25V/K

MB_PWM_VCC

MB_VPP_EN

3

D

2

1

2

Addr: ?

A_DRAM_PWROK(16)

DDR_12V_A_PG(34)

DDR_12V_B_PG

MBR84 0/4/SHT/X
MBR83 0/4/SHT/X

MBR70

MBR71

8.2K/4

8.2K/4

VPP_25V_B

DDR_12V_B

MAR6 2.2/4

MAR31 0/4/SHT/20/X
MAR91 0/4/SHT/20/X

N_SMBCLK (16,20,21,23,24,25,26,27,30,34,37,42,47,58)
N_SMBDATA (16,20,21,23,24,25,26,27,30,34,37,42,47,58)

MBR72

8.2K/4

VPP_25V_B

MBR1

82/4

3

D

G S

2

-PSON(28,34,38,40,42)

D4

DDR_12V_B

SOT23

BAT54A/SOT23/200mA

5VDUAL

NR102

1K/4/1

NQ11

MMBT2222A/SOT23/600mA/40
NR111
1K/4/1

MAR90
2K/4/1

MAC35

0.01u/4/X7R/25V/K/X

SOT23

132

NR108

8.2K/4

-DRAM_PWROK (34)

Title

DDR_A& CPU_VTT POWER IR3570

Size Document Number Rev

C

Date: Sheet of

1

MB_VPP_EN

MBC35

0.01u/4/X7R/25V/K

DDR_12V_B

NR110
150/4/1

MBR22 100/4/1

NQ9

MMBT2222A/SOT23/600mA/40

SOT23

132

GA-X99-UD5 WIFI 1.0

1

MBR2
82/4

MBQ7

2N7002/SOT23/25pF/5

8.2K/4

MBR416

Rev 1.01

MBC7
1u/4/X5R/6.3V/K

A_DRAM_PWROK1 (7)

1K/4/1/X

35 64Tuesday, August 26, 2014

3VDUAL

5

4

3

2

1

PBG_1.1V

VCC3

NR115

D D

V_PCH_EN(37)

VCC1_05PHASE

C C

NR273 0/4/SHT/20/X

NR132

20K/4/1/X

NR118
13K/4/1

3.3n/4/X7R/50V/K

NC58

VCC

+12V

22p/4/NPO/50V/J

NR133
0/4/X

NR134

0/4/SHT/20/X

2.2/6/X

NR116

2.2/6

NU1 RT8120DGS/SOP8

7

COMP

3

VREF IS 0.8V

B B

5

BOOT

VCC

UGATE
PHASE

LG/OCFB

GND

PGND

9

NR117
0/4/SHT/X

VCC1_05_PCH_ADJ (37)

NBC51
1u/6/X7R/16V/K

NQ18
BAT54C/SOT23/200mA/X

1

VCC1_GATE

2
8

46

NR96

8.2K/4

OCP:26A

PBG_BOOT

NR64

2.2/6

VCC1_05L_G

VCC1_05U_G

VCC1_05PHASE

V

VCC1_05U_G

VCC1_05_IN

NR63

8.2K/4

CC1_05L_G

OCP :
Rocset=(Iocp*Lgate,rdson)/Iocset
Iocset=10uA

NC51

0.1u/4/X7R/16V/K

VCC1_05PHASE

NR71

2.2/6

NC44

2.2n/4/X7R/50V/K

D2D3D4

G

G

CLOSE CHOKE

D5

NQ5
SiRA14DP-T1/PPAKSO-8/1450pF/5.1m/[10IF9-050014-01R]

S1D1S3

S2

D2D3D4

D5

NQ6

NL8

0.5uH/25A/INC0909/F/DNC57

VCC1_05L_G

NBC48

0.1u/4/X7R/16V/K

NR135
470/4/1

NBC50
33p/4/NPO/50V/J

G

D2D3D4

VCC1_05_WBG

NRF_PCH1
499/4/1

NRF_PCH2

1.54K/4/1

D5

NQ25

560u/FP/D/6.3V/68/C/8m

DEF=1.05V

NEC4

1

+

0.5uH/25A/INC0909/F/D

NBC49

22u/8/X5R/6.3V/M

VCC1_05_WBG

1

+

NEC3
560u/FP/D/6.3V/68/C/8m

NL7

VCC1_05_IN

20Amp

+

NC32

0.1u/4/X7R/16V/K

1

+

NEC1
560u/FP/D/6.3V/68/C/8m

NC41

0.1u/4/X7R/16V/K

1

NEC2

560u/FP/D/6.3V/68/C/8m

S1D1S3

S2

A A

5

4

SiRA14DP-T1/PPAKSO-8/1450pF/5.1m/[10IF9-050014-01R]

3

SiRA14DP-T1/PPAKSO-8/1450pF/5.1m/[10IF9-050014-01R]

S1D1S3

S2

Title

Size Document Number Rev

2

Date: Sheet of

Gigabyte Technology

RT8120 PCH

Custom

GA-X99-UD5 WIFI

1.0

36 64Tuesday, August 26, 2014

1

5

5VDUAL

5VDL_G1

R52
1K/4/1

R51

8.2K/4

132

R53
1K/4/1

SOT23

R76

22K/4

R70
100K/4/1

3

D

Q32

G S

SOT23

2

1

C41
1n/4/X7R/50V/K/X

R56
100K/4/1/X

5VSB

R77

8.2K/4

PWR_EN

Q57

SOT23

132

Q59

SOT23

132

MMBT2222A/SOT23/600mA/40

5VSB

5VSB

R48

8.2K/4/X
2N7002/SOT23/25pF/5

5VAUX_SW(28)

PWOK(28,40,42)

Q54

R198

8.2K/4

5VSB

MMBT2222A/SOT23/600mA/40

N_-SLP_S3(16,28,34,35,38,39,42)

VCC3

R75

100K/4/1

R71

8.2K/4/X

BC57

0.1u/4/X7R/16V/K

D D

C C

B B

MMBT2222A/SOT23/600mA/40

R49 0/4/SHT/20/X

5VAUX_SW(28)

Add the enable delay
for S19,S37 PSU
abnormal main power
delivery

P_EN

5VSB

C23

0.1u/4/X7R/16V/K

C38
1n/4/X7R/50V/K/X

+12V

R57

8.2K/4

VCCIO_EN

3

D

G S

2

1

2N7002/SOT23/25pF/5

V_PCH_EN

3

D

G S

2

1

2N7002/SOT23/25pF/5/X

VCC

SOT23

SOT23

4

Q30

SiRA18DP-T1/PPAKSO-8/1000pF/7.5m

5VDUAL

G

S3
S2
S1

22u/8/X5R/6.3V/M

Q60

Q58

D1
D2
D3
D4

D5

Q31
P2003ED/P/TO252/30m

1

2

3

1

+

EC10
100u/FP/D/6.3V/65/C/13m

5VDUAL

BC59

VCCIO_EN (38)

V_PCH_EN (36)

1

+

EC11
100u/FP/D/6.3V/65/C/13m

6/8Φ

BC58
22u/8/X5R/6.3V/M

3

2

1

3VDUAL_LDO

O_-RSMRST

5VDUAL

2

Q23

L1085DG/TO252/5A

3
1

3VDUAL

C33

0.1u/4/X7R/16V/K

R207
100/4/1

R206
169/4/1

BC62
22u/8/X5R/6.3V/M

3VDUAL

C32

0.1u/4/X7R/16V/K

C34

0.1u/4/X7R/16V/K

1

+

EC2

100u/FP/D/6.3V/65/C/13m

5VSB

3VDUAL

R217 75K/4/1

R219

27K/4/1

N_-DEPSLP(16)

At least 10ms delay after 3VDUAL ready
Pop when PCH & SIO both use 3VDUAL-PCH

3VDUAL

C35
1u/4/X5R/6.3V/K

D2

SOT23

BAT54A/SOT23/200mA

R216 1K/4/1

0.01u/4/X7R/25V/K

C37

3

D

R218

G S

22K/4

SOT23

132

MMBT2222A/SOT23/600mA/40

2

1

C36
1u/4/X5R/6.3V/K/X

Q28

O_-RSMRST (16,28)

SOT23

Q29
2N7002/SOT23/25pF/5

Meet the rise time

Vcore_EN

5VSB

BC48

VCC

5VSB

+12V

VCC=4.2V

R83 8.2K/4

R84

12K/4/1

R85 10K/4/1

R86
10K/4/1

+12V=10V

R87 8.2K/4

R88

2.74K/4/1

C29
1u/6/X7R/16V/K

C30
1u/4/X5R/6.3V/K

C31

0.1u/4/X7R/16V/K

0.1u/4/X7R/16V/K

84

U17A

3

+

1

2

-

KA393D/SO8

5VSB

U17B

84

5

+

7

6

-

KA393D/SO8

VCC3

R91
1K/4/1

VCORE_EN (30,38)

BC45

BC47

A A

3VDUAL

0.1u/4/X7R/16V/K
U9

1

R168

8.2K/4/X

2

8.2K/4
R160

3

N_SMBDATA N_SMBDATA

4 5

NCT3933U/SOT23-8

5

VDD

VREF1

B_SEL

VREF2

GND

VREF3

SDA SCL

8
7
6

VTT_ADJ (34)
M_CHA_ADJ (11)

N_SMBCLK

3VDUAL

N_SMBCLK

N_SMBCLK (16,20,21,23,24,25,26,27,30,34,35,42,47,58)

N_SMBDATA

N_SMBDATA (16,20,21,23,24,25,26,27,30,34,35,42,47,58)

4

BC46

0.1u/4/X7R/16V/K

R102

1.3K/4/1

3.9K/4/1
R103

0X62(0x22)0x6A(0x2A) 0x60(0x20)

U4

1
2
3
4 5

NCT3933U/SOT23-8

VDD

VREF1

B_SEL

VREF2

GND

VREF3

SDA SCL

8
7
6

N_SMBCLK

VCC1_05_PCH_ADJ (36)
VCC15_PLL_ADJ (38)

VCCIO_ADJ (38)

3

3VDUAL

0.1u/4/X7R/16V/K

R200

8.2K/4

8.2K/4/X
R208

N_SMBDATA

U5

1

VDD

VREF1

2

B_SEL

VREF2

3

GND

VREF3

4 5

SDA SCL

NCT3933U/SOT23-8

2

8
7
6

VTT_ADJ2 (35)
M_CHC_ADJ (13)

N_SMBCLK

Gigabyte Technology

Title

DISCRETE POWER

Size Document Number Rev

C

Date: Sheet of

GA-X99-UD5 WIFI

1

37 64Tuesday, August 26, 2014

1.0

VCC15_PLL VCCIO

5

VCC3

VCC

R104

D D

1u/6/X7R/16V/K

2.2/4

BC44

R105 8.2K/4

C

PU_PLL_EN CPU_PLL_FB

R106 0/4/SHT/20/X

VCC3

C18

10u/6/X5R/6.3V/M

U2

1

POK

2

EN

3

VIN

4 5

CNTL REFIN

9

C17
1u/4/X5R/6.3V/K

8

GND

7

FB

6

VOUT

PGND

RT9018B-18GSP/SO8/3A

VCC15_PLL

R107
1K/4/1

0.1u/4/X7R/16V/K/X

R108

1.13K/4/1

4

SPEC: 1.05V +/- 5%

BC43

C13

1u/4/X5R/6.3V/K

22u/8/X5R/6.3V/M

R109 0/4/SHT/20/X

C15

22u/8/X5R/6.3V/M

VCC15_PLL_ADJ (37)

1

EC8

+

C16

560u/FP/D/6.3V/68/C/8m

3

1u/6/X7R/16V/K

R110

2.2/4

BC41

2

VCC3

R111

U3

8.2K/4

VCCIO_PWRGD(30)

N_-SLP_S3(16,28,34,35,37,39,42)

R112 0/4/X

VCC3

C12

10u/6/X5R/6.3V/M

VCCIO_EN(37)

VCCIO_EN

C11
1u/4/X5R/6.3V/K

1

POK

2

EN

3

VIN

4 5

CNTL REFIN

A_PROC_ID(7)

8

GND

7

FB

6

VOUT

PGND

9

RT9018B-18GSP/SO8/3A

R116 8.2K/4

VCCIO_FB

D

G S

2

VCCIOVCC

3

SPEC: 1.05V +/- 5%

R113
1K/4/1

0.1u/4/X7R/16V/K/X

R114

5.36K/4/1

R115

7.68K/4/1

SOT23

Q24

1

2N7002/SOT23/25pF/5

BC40

R118 0/4/SHT/20/X

VCC

C8

1u/4/X5R/6.3V/K

22u/8/X5R/6.3V/M

R117

8.2K/4

VCCIO_EN

1

C9

22u/8/X5R/6.3V/M

VCCIO_ADJ (37)

A_PROC_ID

1

+

C10

560u/FP/D/6.3V/68/C/8m

H 1.05V
L

0.95V

EC9

Q1
2N7002/SOT23/25pF/5

SOT23

1

SOT23

Q5

1

2N7002/SOT23/25pF/5

SOT23

Q6

1

2N7002/SOT23/25pF/5

SOT23

Q7

1

2N7002/SOT23/25pF/5

R122
0/4/X

SOT23

1

MB_EN

MA_EN

MA_VPP_EN

IO_GP24 (28)

3

D

G S

5VSB

Q532N7002/SOT23/25pF/5

SOT23

G S

R50

22K/4/X

2

3

D

G S

2

3

D

G S

SOT23

132

2

3

D

G S

2

3

D

SOT23

2

1

3

D

Q9

G S

2

C C

8.2K/4

MMBT2222A/SOT23/600mA/40

N_-S4_S5(16,28,39,42)

VCORE_EN

VCORE_EN(30,37)

B B

C19

2.2u/6/X5R/6.3V/K/X

Q8

R124

22K/4

R5

22K/4

2N7002/SOT23/25pF/5/X

-PSON(28,34,35,40,42)

2N7002/SOT23/25pF/5/X

VCCIO_PWRGD(30)

132

Q10

VCC1_05_ME

5VDUAL

A A

N_-SLP_A(16)

R146

2.2/6

BC31
1u/4/X5R/6.3V/K

10u/6/X5R/6.3V/M

1_05ME_EN

3VDUAL

R147

8.2K/4/X

1_05ME_EN

3VDUAL

BC32

R150 0/4/SHT/20/X
R151 22K/4

5

1
2
3
4 5

BC33
10u/6/X5R/6.3V/M

1u/4/X5R/6.3V/KC27

U8
RT9018B-18GSP/SO8/3A

POK

GND
EN
VIN
CNTL REFIN

FB

VOUT

PGND

9

8
7
6

VOUT=0.8*[(R1+R2)/R2]

󲇉󴞜󴽣󱝺

VCC1_05_ME

R&D

󲇉󴞜󴽣󱝺

22u/8/X5R/6.3V/M

1A MAX

R1

R148
100K/4/1

R149
300K/4/1

R2

MB_VPP_EN (35)

MA_EN (34)

MA_VPP_EN (34)

BC34

180p/4/NPO/50V/J

156



22u/8/X5R/6.3V/M

VCC1_05_ME

BC26

MB_EN (35)

VCC1_05_ME

BC29

BC27

22u/8/X5R/6.3V/M

4

MMBT2222A/SOT23/600mA/40

N_-SLP_S3(16,28,34,35,37,39,42)

VCC1_05_WBG

MMBT2222A/SOT23/600mA/40

BC36
1u/4/X5R/6.3V/K

R128

22K/4

R129

BC39

8.2K/4

0.1u/4/X7R/16V/K

R127

8.2K/4

5VSB

132

132

R130

100K/4/1/X

R132 22K/4

Q11

SOT23

R133 22K/4

Q12

SOT23

R134 22K/4

VCC3_ME

3

G S

D

G S

2

G S

N_-SLP_A(16)

3

D

2

3

1

3

D

2

CPU_PLL_EN

SOT23

Q13

1

2N7002/SOT23/25pF/5

R135 8.2K/4

SOT23

Q15

2N7002/SOT23/25pF/5

VCORE_EN

SOT23

Q18

1

2N7002/SOT23/25pF/5

R153
75K/4/1

VCC15_PLL

5VDUAL

3

D

G S

2

C6
1u/4/X5R/6.3V/K

R152

8.2K/4

SOT23

1

Q25
2N7002/SOT23/25pF/5

VCC1_05_WBG

ME_G

C7
1u/4/X5R/6.3V/K

R136 8.2K/4/X

VCC15_PLL

N_-SLP_S3(16,28,34,35,37,39,42)

R154 220/6

R155 220/6

R137
1K/4/1/X

R140 8.2K/4/X

VCC3_ME

BC49
10u/6/X5R/6.3V/M

2

5VSB

R139
2K/4/1/X

VCC3_ME

Q26
PMBT2907A/SOT23/-600mA/50

SOT23

132

VCC3_ME

Q27
PMBT2907A/SOT23/-600mA/50

SOT23

132

R138

8.2K/4/X

Q19

R141 22K/4/X

SOT23

132

MMBT2222A/SOT23/600mA/40/X

Q20

MMBT2222A/SOT23/600mA/40/X

SOT23

132

3VDUAL

3VDUAL

ME_G (42)

VCC3_ME

BC50
10u/6/X5R/6.3V/M

+12V

R143

22K/4/XR125

Q55

SOT23

132

MMBT2222A/SOT23/600mA/40/X

R142 22K/4/X

Gigabyte Technology

Title

DISCRETE POWER II

Size Document Number Rev

C

Date: Sheet of

VCC3

3

D

G S

Q21

SOT23

2

1

2N7002/SOT23/25pF/5/X
R144
51/4/1/X

3

D

Q22

G S

2N7002/SOT23/25pF/5/X

SOT23

2

1

GA-X99-UD5 WIFI

1

38 64Tuesday, August 26, 2014

0/4/SHT/20/X

VCC3_GATED

R145

1.0

8

INTEL FRONT PANEL

D D

RESET(44)

0.01u/4/X7R/25V/K/X

5VSB

N_-SYS_RST(16)

FPR5 100/4/1

0.01u/4/X7R/25V/K

VCC3

FPR19
330/6 FPR4

FPBC1

FPR6

8.2K/4/X

-CASEOPEN(28,41)

FPBC2

VCC

7

FPR1
330/6/X

-HDLED

-RST

-CASEOPEN

PD+
MPD-

BH/2*10K10,12,13/BK/2.54/VA/PA

6

5VDUAL

FPR7

8.2K/4

MPD-

PW+

-PWRBT_1(44)

PD+HD+

2
4
6
8

PW-

14

SP+

16

NC

18

NC

SPK-

20

SP-

F_PANEL

1

HD+

MSG/PD+

3

HD-

MSG/PD-

5

GND

7

RESET

9

CI-

11

CI+

15

PWR+

17

PWR-

19

PWR-

3VDUAL_PCH

MPD- (28,55)

-PWRBT_1

FPC1

0.01u/4/X7R/25V/K/X

VCC

FPR3

8.2K/4
FPR9 33/4

FPBC3

0.01u/4/X7R/25V/K

5

-PWRBTSW (28,42)

-PWRBT_1

PD+

FPESD1

1
2
3 4

4

3

2

1

Thunderbolt

VCC

5VDUAL

FPR2

330/6

330/6/X

THB_C

1

N_GPIO33 (16)

2

N_GPIO6 (15)

3

N_-SLP_S3 (16,28,34,35,37,38,42)

4

N_-S4_S5 (16,28,38,42)

5

THB_C/1*5[11NH5-010105-24R]

6
5

5VSB

RESET

RESET (44)

C C

VCC3

FPR11

8.2K/4/X

VCC3

FPR21 0/4/SHT/20/X

-HDLED

FPR10
1K/4/1/X

SOT23

132

FPQ4
MMBT2222A/SOT23/600mA/40/X

FPC2
180p/4/NPO/50V/J/X

FPQ1

MMBT2222A/SOT23/600mA/40/X

SOT23

132

-HDLED

SATA LED

FPR12

FPD2

SOT23

FPD3

SOT23

1K/4/1/X

BAT54A/SOT23/200mA

N_-SATALED(15)
N_-SASLED(15)

BAT54A/SOT23/200mA

-M2_LED(48)

B B

AOZ8902CIL/SOT23-6

SPKR

VCC

FPR20
1K/4/1

EC_BEEP-(42)

A A

BEEP-(28)

2N7002/SOT23/25pF/5

VCC

8

132

FPR18

8.2K/4

SOT23

FPQ9

FPR17
1K/4/1

BEEP-

SOT23

132

FPQ8

MMBT2222A/SOT23/600mA/40

FPQ7
MMBT2222A/SOT23/600mA/40

SOT23

132

SPK-

FPQ5
MMBT2222A/SOT23/600mA/40

SOT23

132

7

FPR13
75/6/1

FPR14
75/6/1

VCC

FPD1

CD4148WP/1206/300mA

To disable TCO
timer

FPQ6
MMBT2222A/SOT23/600mA/40

FPR15

132

1K/4/1

N_SPKR

N_SPKR

N_SPKR (16)

6

VCC3

FPR16

8.2K/4

Title

Size Document Number Rev
Custom

5

4

3

Date: Sheet of

2

FP,TPM THB

GA-X99-UD5 WIFI

39 64Tuesday, August 26, 2014

1

1.0

Gigabyte Technology

8

5VSB

R156

-PSON(28,34,35,38,42)

D D

-5V
VCC
VCC

BC16

1u/6/X7R/16V/K/X

22K/4

BC19

0.1u/4/X7R/16V/K/X

BC17

0.1u/4/X7R/16V/K/X

APW/2*12/BK/VA/SN/2SHK/PA66/[11NH4-020024-S1R]

BC8

22u/8/X5R/6.3V/M

C C

BC13

1u/4/X5R/6.3V/K

7

ATX POWER CONNECTOR

VCC3

-12V

BC18

0.1u/4/X7R/16V/K/X

VCC3VCC3 VCC3

BC15

1u/4/X5R/6.3V/K

ATX

13

3.3V

14

-12V

15

GND

16

PSON

17

GND

18

GND

19

GND

20

-5V

21

5V

22

5V

23

5V

24

GND

MH1

MH4

6

VCC3

1

3.3V

2

3.3V

3

GND

4

5V

5

GND

6

5V

7

GND

8

POK

9

5VSB

10

12V

11

12V

12

3.3V

󵊖󵊖󵊖󵊖󵄚󵄚󵄚󵄚󱬯󱬯󱬯󱬯󱼌󱼌󱼌󱼌

654

7
8

101112

654

7
8

101112

MH7

654

7
8

101112

3
2
19

3
2
19

3
2
19

HOLE_3/X

HOLE_3/X

HOLE_3/X

BC20
510/6/X

To prevent the S28
PSU 5VSB under
loading when boot

MH2

654

7
8

101112

MH5

654

7
8

101112

MH8

654

7
8

101112

3
2
19

BC21
510/6/X

HOLE_3/X

3
2
19

HOLE_3/X

3
2
19

HOLE_3/X

BC22
1u/6/X7R/16V/K

MH3

7
8

MH6

7
8

MH9

V12

BC65

0.1u/4/X7R/16V/K

654

101112

654

101112

654

7
8

101112

5

BC23

0.1u/4/X7R/16V/K

3
2
19

HOLE_3/X

3
2
19

HOLE_3/X

3
2
19

HOLE_3/X

VCC

BC25

0.1u/4/X7R/16V/K/X

BC24

0.1u/4/X7R/16V/K

VCC

+12V

BC1

4.7u/6/X5R/6.3V/K

PWOK (28,37,42)

1

AD1

AZ2225-01L/SOD323

4

ATX_12V_2X4

1

GND

+12V

2

GND

+12V

3

GND

+12V

4

GND

+12V

5VSB

APW/2*4/BK/OC/P/4.2/VA/GF/OH/S/[11NH4-020008-K1R]::ATX_12V_2X4

V12

5

6

7

8

󵊖󵊖󵊖󵊖󵄚󵄚󵄚󵄚󱬯󱬯󱬯󱬯󱼌󱼌󱼌󱼌

3

V12

2

To fix 12V light load
abnromal issue

󲇉󲇉󲇉󲇉󴞜󴞜󴞜󴞜󴽣󴽣󴽣󴽣󱝺󱝺󱝺󱝺

N_GPIO21(15)

R&D

󲇉󲇉󲇉󲇉󴞜󴞜󴞜󴞜󴽣󴽣󴽣󴽣󱝺󱝺󱝺󱝺

+12V

1 2
3 4

RN17

5 6

2.7K/8P4R/6

7 8
1 2
3 4

RN18

5 6

2.7K/8P4R/6

7 8
1 2
3 4

RN19

5 6

2.7K/8P4R/6

7 8
1 2

RN20

3 4

2.7K/8P4R/6

5 6
7 8
1 2

RN21

3 4

2.7K/8P4R/6

5 6
7 8

MMBT2222A/SOT23/600mA/40

R197 330/4

+12V

VCC

15
14
13
12
11
10

9
8
7
6
5
4
3
2
1

SATA/15/BK/OH/P/RA/D/1

ATX4P

+12V
+12V
+12V
GND
GND
GND
VCC
VCC
VCC
GND
GND
GND
VCC3
VCC3
VCC3

1

153



20 mils

+12V_LOAD

Q3

SOT23

132

I2

I1

4MMH/X

4MMH/X

I3

I4

80 PORT

VCC

RN12

B B

A A

80P_SEGF
80P_SEGB
80P_SEGA
80P_DL
80P_SEGG
80P_SEGC
80P_SEGD
80P_SEGE

80P_DH

8

1K/8P4R/6

7 8
5 6
3 4
1 2
7 8
5 6
3 4
1 2

RN13 1K/8P4R/6

R199 1K/4/1

7

80P_DL(28)
80P_SEGA(28)
80P_SEGB(28)
80P_DH(28)
80P_SEGF(28)

COMMON CATHODE

U6

6

CATH2

7

A

8

B

9

CATH1

10

F

TOD-2281AMRL-B3-1/D/[11DL1-020070-42R]

5

DOT

4

G

3

C

2

D

1

E

6

80P_SEGG (28)
80P_SEGC (28)
80P_SEGD (28)
80P_SEGE (28)

5

Physical Package
(TOP VIEW)

10

F

E
1

69

8

7

BCAT1 A

CAT2

G

C

2

4

5D3

4

3

4MMH/X

I5

4MMH/X

For CPU

1

1

K2

K1_ICT/X

K3

K1_ICT/X

4MMH/X

PR

L L
H
L
H
H H
H No Change
H No Change
H

Title

Size Document Number Rev
C

Date: Sheet of

2

OVER CLOCKING

K5

K1_ICT/X

1

K8

K1_ICT/X

1

INPUT

CL

H
L
L
H
H
H
H
H

1

1

CLOCK

X

Rising

L
H

Falling

K4

K1_ICT/X

K7

K1_ICT/X

DATA

Gigabyte Technology

ATX , 80PORT

GA-X99-UD5 WIFI

K1

K1_ICT/X

1

K6

K1_ICT/X

1

OUTPUT

-Q

Q
HX

X
X
X
H
L
X
X
X

L
H
H
LRising

No Change

40 64Tuesday, August 26, 2014

1

H
HX
L

1.0

8

7

6

5

CPU SMART FAN

4

3

2

1

TEMP H/W MONITOR

VREF(28)

OR73
10K/4/1

SYS_TEMP(28)

PCH_TEMP(28)

D D

CPU_TEMP(28)

OC7

1u/4/X5R/6.3V/K

OC6

1u/4/X5R/6.3V/K

Close MB

RS_SYS

10K/1/4/S

󱴯󰵓

OR151
10K/4/1

RS_PCH

10K/1/4/S

OR152
10K/4/1

OC120
1u/4/X5R/6.3V/K

SYS FAN2

CASE OPEN

FPR8

1M/4

FPBC4

C C

0.01u/4/X7R/25V/K

VOLTAGE-- H/W MONITOR

VCORE0

OR250

8.2K/4

OC8

1u/4/X5R/6.3V/K

Rev 1.01

VIN5(28)

1u/4/X5R/6.3V/K

VPP_25V_B

OR74

8.2K/4

OC4

1u/4/X5R/6.3V/K

OC3

VCORE

OR75

8.2K/4/X

Rev 1.01

VIN0(28)

VIN6(28)

VIN1(28)
VIN2(28)
VIN4(28) VIN3(28)

OC9

1u/4/X5R/6.3V/K

B B

-CASEOPEN

VPP_25V_A

OR60

8.2K/4
OR79

75K/4/1

OC12

1u/4/X5R/6.3V/K

OR53 8.2K/4

-CASEOPEN (28,39)N_RTCVDD(16,18)

VIN2 must +12V input
VIN3 must VCC input

*

+12V

VCCIO

2V

OR70
15K/4/1

1u/4/X5R/6.3V/K

VCC1_05_WBG

OR163

8.2K/4

OC10

OC11

1u/4/X5R/6.3V/K

*

VCC

OR78
15K/4/1

2V

OR77
10K/4/1

SYS FAN3

VCC3

FAR2
1K/4/1

FANPWM1(28)

FAC3
1u/4/X5R/6.3V/K

VCC3

FCR2
1K/4/1

FANPWM2(28)

FCC3
1u/4/X5R/6.3V/K

1u/6/X7R/16V/K

FAR3
22K/4

INTERNAL PULL HI

1u/6/X7R/16V/K

FCR3
22K/4

INTERNAL PULL HI

8620 PROCHOT

Enable Function (NCT3941S)
Full Turn On Function

+12V

(NCT3941S-A)

FAC1

VCC3

FAR4 8.2K/4/X

+12V

FCC1

VCC3

FCR4 8.2K/4/X

FANA_VOUT

FANC_VOUT

FAU14
NCT3941S-A/SOP8-EP

2

VIN

1 8

VOUT NC

3

FANA_SET FANA_VOUT

Enable Function (NCT3941S)
Full Turn On Function
(NCT3941S-A)

ENABLE/FON#

4

VSET

FCU14
NCT3941S-A/SOP8-EP

2

VIN

1 8

VOUT NC

3

ENABLE/FON#

4

VSET

GND

PGND

GND

PGND

NC
NC

NC
NC

5
7

6
9

10u/8/X5R/16V/K

5
7

6
9

10u/8/X5R/16V/K

R157

8.2K/4

FAC4

213

4

GVS

C

SYS_FAN2 FAN/1*4/BK/A3/PA66

VCC

R192

8.2K/4

FANC_VOUTFANC_SET

213

FCC4

4

GVS

C

SYS_FAN3
FAN/1*4/BK/A3/PA66

+12VVCC

+12V

R202

3.3K/4/1

R201
15K/4/1

R131

3.3K/4/1

R64
15K/4/1

R203

6.2K/4/1

R54

6.2K/4/1

FANIO1 (28)

C28

0.047u/4/X7R/16V/K

FANIO2 (28)

C14

0.047u/4/X7R/16V/K

VREF(28)

PR1
10K/4/1

TR4(28)
TR5(28)
TR6(28)

A A

C24

1u/4/X5R/6.3V/K

PRS1
100K/1/4/S

PR2
10K/4/1/X

PR3
10K/4/1/X

Gigabyte Technology

Title

Size Document Number Rev

Custom

8

7

6

5

4

3

Date: Sheet of

HWM,FAN CTRL

GA-X99-UD5 WIFI

2

41 64Tuesday, August 26, 2014

1.0

1

5

ECR7

8.2K/4

ECC23

ECC22

1u/4/X5R/6.3V/K

ECD1

ECR98 0/4/X

EC_FANIO3(45)

EC_LPCCLK48(17)

N_SERIRQ(15,28)

N_-LFRAME(16,28)

N_LAD0(16,28)
N_LAD1(16,28)
N_LAD2(16,28)
N_LAD3(16,28)

MIC_VIN1

ECR147 100/4/1

SOT23

ECR21 100K/4/1

VCC3VCC15_PLL VCC3

ECR8

8.2K/4/X

ECR27 0/4/SHT/10/M/X
ECR30 0/4/SHT/10/M/X
ECR33 0/4/SHT/10/M/X

N_-PFMRST(16,28)

ECR9

6.49K/4/1

8.2K/4

ECR35
10K/4/1

ECC24

1u/4/X5R/6.3V/K

1u/4/X5R/6.3V/K

BAT54A/SOT23/200mA

EC_FANIO1(45)
EC_FANPWM1(45)
EC_FANIO2(45)
EC_FANPWM2(45)

N_-S4_S5

EC_GP30
IT_HMOSI
IT_HSCK

-IT_HCE

SIO_18V_A

ITE_LAD0
ITE_LAD1
ITE_LAD2
ITE_LAD3

N_EC33(17)

ECC25

ECD2

VCORE

ECR6

8.2K/4

VINA0
VINA1
VINA2
VINA3
VINA4

D D

C C

B B

A A

VINA5

1u/4/X5R/6.3V/K

EC_GP30

ITA_VCCH

ECC27

1u/4/X5R/6.3V/K

ECC21

1u/4/X5R/6.3V/K

-DUAL_BIOSDIS(28,29)

BAT54A/SOT23/200mA

EC_FANPWM3(45)
PWOK(28,37,40)

DDR_12V_B

DDR_12V_A

ECR11

ECR10

8.2K/4

8.2K/4

ECC26

1u/4/X5R/6.3V/K

SOT23

ECU1

N_-S4_S5 (16,28,38,39)

1

FAN_TAC3/GP37

2

FAN_CTL3/GP36

3

ATXPG/GP30

4

SI

5

SCK

6

CE_N

7

3VSB

8

VCORE

9

CLKIN

10

SERIRQ

11

LFRAME#

12

LAD0

13

LAD1

14

LAD2

15

LAD3

16

GA20

ECR45 0/4/SHT/10/M/X

10p/4/NPO/50V/J/X

N_-PFMRST

1u/4/X5R/6.3V/K

EC_GPIO74

ECC12

IT_HMISO

ECC1

64

FAN_CTL1

FAN_CTL2/GP51

FAN_TAC2/GP52

IT8792E

PCICLKSOLRESET#

17181920212223

internal power pin, max 22nF cap

SIO_18V_A

ECC8

0.1u/4/X7R/16V/K

ECC9
1u/4/X5R/6.3V/K/X

5

1u/4/X5R/6.3V/K

ITA_VCCH

ECC6

SYS1_TEMP
SYS2_TEMP
SYS3_TEMP

EC_GPT1
EC_GPT2

GP70

GP71

GP72

GP73

GP74

FAN_TAC1

WRST#

SMBCLK1

SMBDAT1

PECI

NCNCNCNCGP86/SMBCLK0

242526272829303132

ECR46 0/4/SHT/10/M/X

IT_SMBDATA
IT_SMBCLK

ECC13
1u/4/X5R/6.3V/K

N_-PFMRST

ECC11
22p/4/NPO/50V/J/X

4

EC_VREF

ECC2
1u/4/X5R/6.3V/K

ECR124 10/4

ECR123 0/4/SHT/10/M/X

EC1TOEC2
EC2TOEC1

555657585960616263

54

VIN0

A3VSB

4

VINA0
VINA1
VINA2
VINA3
VINA4
VINA5

495051

52

53

VIN5

VIN4

VIN3

VIN2

VIN1

PWROK2/GP41

PANSWH#/GP43

PME#/GP54/USBPW REN1#

PWRON#/GP44

IO_SCI#/GP85/SMBDAT0

D_TX0/SMBDAT2/GP47

D_RX0/SMBCLK2/GP46

3VSB

IT8792E/LQFP64[10HP2-118792-10R]

ECR47 0/4/X

ECR48 0/4/X

ECR49 100K/4/1

N_-PFMRST (16,28)

3

ECR2
10K/4/1

ECRS_MOS
10K/1/4/S

VCC3DET

TMPIN1
TMPIN2
TMPIN3

GNDA / TSD­SUSC#/GP53

PSON#/GP42

SYS_3VSB

EC_GPIO85
EC_GPIO86

A_PECI (7,28)
N_SMBDATA (16,20,21,23,24,25,26,27,30,34,35,37,47,58)
N_SMBCLK (16,20,21,23,24,25,26,27,30,34,35,37,47,58)

ITA_VCCH

10K/1/4/S

Close MB

N_-PFMRST (16,28)

-CLK_BYPASS (26)
EC1TOEC2 (43)
EC2TOEC1 (43)

ITA_VCCH

48
47

VREF

46
45
44
43
42
41
40
39
38

GNDD

37
36
35

SUSB#

34
33

VBAT

EC_GP46
EC_GP47

ECR3
10K/4/1

ECRS_SYS

󱴯󰵔

ECR19 8.2K/4

ECR20 0/4/SHT/10/M/X

SYS1_TEMP
SYS2_TEMP
SYS3_TEMP

EC_PWROK
EC_GP53
E

C_GP42

-EC_PANSW
EC_GP54

EC_GP44
EC_GP
SYS_3VSB

IT_SMBCLK

IT_PH
0/6/X

IT_SMBDATA

ECC3
1u/4/X5R/6.3V/K/X

ECR23 33/4
ECR79 0/4/SHT/20/X
ECR28 33/4
ECR31 33/4

ITA_VCCH

ECR4
10K/4/1

ECRS_PCH
10K/1/4/S

1u/4/X5R/6.3V/K/X

VCC3

EC_VREF

NA_VBAT

ECC7
1u/4/X5R/6.3V/K

ECIO_SMBDATA(28)
ECIO_SMBCLK(28)

ECC4

0.1u/4/X7R/16V/K

EC_SMBDATA(43)
EC_SMBCLK(43)

EC_GP44

For EC firmware update ,PVT remove

3

N_-SLP_S3(16,28,34,35,37,38,39)

5VDUAL

ECR148

8.2K/4
ECD3

BAT54C/SOT23/200mA

O_PWROK1 (16,28)
EC1TOPCH (16)

-PSON (28,34,35,38,40)

-PWRBTSW (28,39)

ITA_VCCH

ECC10

ECR137 0/4/SHT/20/X
ECR138 0/4/SHT/20/X

ECR142 33/4
ECR143 33/4

ECR15 10/4

-IT_HCE

ECR16 10/4

2

ITA_VCCH

ECR135

8.2K/4ECR149

3

D

ME_G (38)
N_ME_PWROK (16)

IT_SMBDATA
IT_SMBCLK

EC_GPIO85
EC_GPIO86

VDD

HOLD#

SCK

G S

2

EC_GPIO85

IT1_PH
0/6/X

EC_GPIO86

SI

8
7
6
5

N_-SLP_S3

ECR136 8.2K/4

For EC debug ,replace Pin header

EC_BIOS

1

CS#

2

SO

3

WP#

4

VSS

4M/SPI/SO8/200mil/S/[10HP4-112540-30R]

3

D

G S

2

SOT23

1

ECQ2
2N7002/SOT23/25pF/5

ITA_VCCH

-SPI_HOLD_ITIT_HMISO

ECR17 10/4
ECR18 10/4

2

EC_GP30

SOT23

1

ECQ1
2N7002/SOT23/25pF/5/X

Remove GP74 PU for dual Bios
2014-05-26

ECR14
0/4/SHT/20/M/X

ECC5
1u/4/X5R/6.3V/K

IT_HSCK-SPI_IT_WP1
IT_HMOSI

1

3VDUAL_PCH

3VDUAL_PCH

Note.142

󵕻󲹘󵙄

EC_GP

Title

IT8790

Size Document Number Rev

Custom

GA-X99-UD5 WIFI 1.0

Date: Sheet of

ECR1 0/6/SHT/30/X

ECR5 0/6/X

3VDUAL

ECR13

NA_VBAT

EUP control detect

3VDUAL

-IT_HCE
IT_HMISO
IT_HMOSI

-SPI_IT_WP1

-SPI_HOLD_IT
IT_HSCK
EC_GP53

-EC_PANSW
EC_GP54
EC_GP42
EC_GP44
EC_GP
EC_GP30

EC_GPIO85
EC_GPIO86
EC_GPIO74
IT_SMBDATA
IT_SMBCLK

EC1TOEC2
EC2TOEC1

EC_GP46
EC_GP47

EC_PWROK

EC_GP54

ECR74 100/4/1/X

ECR150 100/4/1

ECR22 8.2K/4
ECR24 8.2K/4
ECR26 8.2K/4
ECR29 8.2K/4
ECR32 8.2K/4
ECR34 8.2K/4
ECR37 8.2K/4/X

ECR40 8.2K/4
ECR84 1K/4/1
ECR90 1K/4/1/X
ECR92 1K/4/1/X
ECR94 8.2K/4
ECR100 8.2K/4/X

ECR77 1K/4/1
ECR78 1K/4/1
ECR80 1K/4/1
ECR81 1K/4/1
ECR82 1K/4/1
ECR131 1K/4/1
ECR133 1K/4/1

ECR144 1K/4/1
ECR145 1K/4/1

ECR83 8.2K/4

DIRECT_KEY (44)

0/6/SHT/30/X

ECR44 1K/4/1

1

ITA_VCCH

N_VBAT (18,28)

SYS_3VSB

ITA_VCCH

ITA_VCCH
ITA_VCCH
ITA_VCCH
3VDUAL
3VDUAL

3VDUAL
3VDUAL

ITA_VCCH
ITA_VCCH

VCC3

EC_BEEP- (39)

42 64Tuesday, August 26, 2014

5

ITB_VCCH

ECBC4

ECBC3

ECBC2

0.1u/4/X7R/16V/K

D D

C C

B B

A A

0.1u/4/X7R/16V/K

0.1u/4/X7R/16V/K

ECB_LED

ECB_GPIO3

ECB_LED

ECB_GPIO5 ECB_GPIO6

ECB_LED

ECB_GPIO7

ECB_LED

ECB_GPIO9

ECB_LED

ECB_PE1

ECB_LED ECB_LED

ECB_PE4

0.1u/4/X7R/16V/K

1.8VD 1.8VD

ECBC32

ECBC33

0.1u/4/X7R/16V/K

PE3_LED
LED/B/6/S[10DL3-32000B-37R]/X

ECBR28
330/6

0.1u/4/X7R/16V/K

ECB_LED

D7_LED
LED/B/6/S[10DL3-32000B-37R]/X

ECBR11
330/6

ECB_GPIO4

ECB_LED

D5_LED
LED/B/6/S[10DL3-32000B-37R]/X

ECBR13
330/6

ECB_LED

D8_LED
LED/B/6/S[10DL3-32000B-37R]/X

ECBR15
330/6

ECB_GPIO8

ECB_LED

D6_LED
LED/B/6/S[10DL3-32000B-37R]/X

ECBR23
330/6

ECB_GPIO10

ECB_LED

PE1_LED
LED/B/6/S[10DL3-32000B-37R]/X

ECBR25
330/6

ECB_PE3

ECB_PE2

1.8VD

ECBC6

ECBC5

0.1u/4/X7R/16V/K

0.1u/4/X7R/16V/K

ECBC34

ECBC35

0.1u/4/X7R/16V/K

Note.120

D3_LED

LED/B/6/S[10DL3-32000B-37R]/X
ECBR12
330/6

D1_LED

LED/B/6/S[10DL3-32000B-37R]/X
ECBR14
330/6

D4_LED

LED/B/6/S[10DL3-32000B-37R]/X

ECBR16
330/6

D2_LED

LED/B/6/S[10DL3-32000B-37R]/X
ECBR24
330/6

PE2_LED

LED/B/6/S[10DL3-32000B-37R]/X

ECBR27

330/6

Note.120

PE4_LED

LED/B/6/S[10DL3-32000B-37R]/X

ECBR26
330/6

ECBC7

0.1u/4/X7R/16V/K

ECBC36

0.1u/4/X7R/16V/K

1.8VD

-ECB_RESET
TEST_EN
TEST_CFG0
TEST_CFG1
TEST_CFG2

ECBTP1
ECBTP2

3.3VD
GNDD

USB_RREF

ECBR20
12K/4/1

GNDD

ECBC37

0.1u/4/X7R/16V/K

1
2
3
4
5
6
7
8

9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32

ITB_VCCH

VCC3

EC_SMBDATA(42)
EC_SMBCLK(42)

GNDD

1.8VD

128

ECBU1

VCCK
RESET#
TEST_EN
TEST_CFG0
TEST_CFG1
TEST_CFG2
UART_TX
UART_RX
HOST_HWE#
HOST_HRD#
HOST_HCS#
HOST_HD_C
HOST_HRDY
HOST_HIRQ
HOST_HDB0
HOST_HDB1
HOST_HDB2
HOST_HDB3
HOST_HDB4
VCC3IO
VSS
HOST_HDB5
HOST_HDB6
HOST_HDB7
HOST_HDB8
HOST_HDB9
HOST_HDB10
HOST_HDB11
HOST_HDB12
HOST_HDB13
HOST_HDB14
HOST_HDB15

ECBR34 0/6/X

ECBR35 0/6/X

VSS

VCC33A

33343536373839404142434445464748495051525354555657585960616263

3.3VD

Note.120

5

4

ITB_VCCH

ITB_PH

0/6/X

Power For USB PLL

VCC33A_HSRT3.3VD

ECBC9
22u/8/X5R/6.3V/M

GND33A_HSRTGNDD

ECB_SDA

ECB_SCL

For EC debug ,PVT remove

ECR139 0/4/SHT/20/X
ECR140 0/4/SHT/20/X

3.3VD

GNDD

125

126

127

VCC3IO

VCC_SDRIO

VREF

TS_EXDNGNDA

ECB_GPIO13
ECB_GPIO14
ECB_GPIO12

ECB_LED

1.8VD

122

123

124

VSS

SPI2_SCK/I2C2_SCL

SPI2_SI/UART_CTS#

SPI2_SO/UART_RTS#

VD33

SAR_VREF

3.3VD

3.3VD

GNDD

GNDD

GNDD

1.8VD

-ECB_SPI_CS

ECB_SPI_SO

ECB_SPI_SI

ECB_SPI_SCK

113

114

115

116

117

118

119

120

121

VSS

SPI_SI

SPI_SO

SPI_CS#

SPI_SCK

VCC_SDRIO

VCC_SDRIO

SPI2_CS#/I2C2_SDA

LQFP128 (14x14x1.4 mm)

X_POS

Y_POS

X_NEG

Y_NEG

PENIRQ#

VS33D

XSCI

XSCO

XSCO

GNDD

XSCI

VCC33A_HSRT

4

ECB_SDA

PWR_ALERT

112

VSS

PWR_ALERT

VCC33A_HSRT

GND33A_HSRT

USB_RREF

GND33A_HSRT

ECB_SCL

109

110

111

SDCLK

I2C_SCL

I2C_SDA

RREFDMDP

VCC33A_U20

USB_DM

USB_DP

EC1TOEC2 (42)
EC2TOEC1 (42)
EC2TOPCH (16)

107

108

SDLE

SDSHR

VCC33A_U20

GND33A_U20

GND33A_U20

LED_PWR_CTRL(28)

ECBC10

0.1u/4/X7R/16V/K

ECB_SDA
ECB_SCL

GNDD

1.8VD

ECB_GPIO5

ECB_GPIO7

ECB_GPIO6

102

103

104

105

106

VSS

VCC_SDRIO

SDDO13/GPIO5

SDDO14/GPIO6

SDDO15/GPIO7

VCCK

PWR_S_P/VCOMIN0_0

PWR_S_N/VCOMIN0_1

PWR_G_P/VCOMIN1_0

PWR_G_N/VCOMIN1_1

1.8VD

ECB_PE3

ECB_PE2

ECB_PE1

ECB_PE4

GNDD

ECB_GPIO4

1.8VD

100

101

VSS

SDDO12/GPIO4

VCC3IO

VSS

GNDD

3.3VD

ECBC11

0.1u/4/X7R/16V/K

1.8VD

GNDD

979899

VSS

VCCK

VCC_SDRIO

GPIO8/PWR0

GPIO9/PWR1

GPIO10/PWR2

64

ECBC12

0.1u/4/X7R/16V/K

ECB_SDA

ECBR9 8.2K/4/X

ECB_SCL

ECBR10 8.2K/4/X

VCC18A

GND18A

VCC3IO
SDDO11/GPIO3
SDDO10/GPIO2

SDDO9/GPIO1
SDDO8/GPIO0

SDDO7
SDDO6
SDDO5
SDDO4
SDDO3
SDDO2
SDDO1

SDDO0
SDCE_N3
SDCE_N2
SDCE_N1
SDCE_N0

SDOE

VSS

VCCK

GDCLK

GDRL

GDOE

GDSPV

BORDER/SHD#

GPIO15/PWR7
GPIO14/PWR6
GPIO13/PWR5
GPIO12/PWR4
GPIO11/PWR3

IT8951E-B/S[10HP2-118951-10R]

ECB_GPIO10
ECB_GPIO9
ECB_GPIO8

18p/4/NPO/50V/J

3VDUAL_PCH

ECBR36

8.2K/4

ECBR37

1K/4/1

ECBR38

1K/4/1

Active blinking

Note.133

Orange

96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
80
79
78
77
76
75
74
73
72
71
70

ECB_GPIO15

69

ECB_GPIO14

68

ECB_GPIO13

67

ECB_GPIO12

66

ECB_GPIO11

65

ECBC21

3

ITB_VCCH

GNDD GND33A_U20

ITB_VCCH

ITB_VCCH

FBIOS_LED
LED/O/6/S[10DL3-22000O-02R]

ECRB1
330/6

ECB_GPIO15

1.8VD
GNDD

3.3VD
ECB_GPIO3
ECB_GPIO2
ECB_GPIO1
ECB_GPIO0

GNDD

1.8VD

ECBC22
18p/4/NPO/50V/J

ECB_LED

Q33
PMBT2907A/SOT23/-600mA/50

SOT23

132

ECB_LED

Q34
PMBT2907A/SOT23/-600mA/50

SOT23

132

3

Power For USB PLL

VCC33A_U203.3VD

22u/8/X5R/6.3V/M

ITB_VCCH

ECBR8

100K/4/1

-ECB_RESET

ECBC20
1u/4/X5R/6.3V/K

TEST_CFG0

TEST_CFG1
TEST_CFG2
TEST_EN
PWR_ALERT

XSCI

ECBY1

12MHz\DIP[11XH5-212000-01R]

XSCO

ITB_VCCH

ITB_VCCH

ECBC13

SEL

X

H

BIOS

USB
CONNECTOR

ECBC14

0.1u/4/X7R/16V/K

Reset Button

ECBR3 8.2K/4
ECBR4 8.2K/4
ECBR5 8.2K/4
ECBR6 8.2K/4
ECBR7 8.2K/4

ECB_GPIO1(29)

-SPI_CS_1(29)

BIOS

N_ICH_SPI_CLK(16,29)

OE
H
LL
L

N_ICH_SPI_MISO(16,29)

N_ICH_SPI_MOSI(16,29)

DB_+USBP(60)

DB_-USBP(60)

ECBC16

ECBC15

0.1u/4/X7R/16V/K

ECB_GPIO1

Y+

Hi-Z

M+
D+

To force disable DUAL BIOS+

0.1u/4/X7R/16V/K

-ECB_SPI_CS
ECB_SPI_SI

-ECB_SPI_WP

ECBR29

8.2K/4/X

-SPI_CS_1

N_ICH_SPI_CLK

PI3USB102ZLE/TQFN10

Y-

Hi-Z

M­D-

N_ICH_SPI_MISO

N_ICH_SPI_MOSI

PI3USB102ZLE/TQFN10

Mainboard SPI controller

SIO GPIO21

USB_SEL(28)

DB_+USBP

DB_-USBP

PI3USB102ZLE/TQFN10

󲒇󲒇󲒇󲒇󵚩󵚩󵚩󵚩󴼚󴼚󴼚󴼚󱻕󱻕󱻕󱻕󳧠󳧠󳧠󳧠

2

3.3VD

ECB_BIOS

1

CS#

2

SO

3

WP#

4

VSS

4M/SPI/SO8/200mil/S/[10HP4-112540-30R]

ITB_VCCH

85

9

ECBU2

OEM+

1

Vcc

D+

Y+

2

Y-

D-

GND SEL

M-

3 10

4

ITB_VCCH

ECB_GPIO1

85

9

ECBU3

OEM+

1

Vcc

D+

Y+

2

Y-

D-

GND SEL

M-

3 10

4

ECB_SPI_SI
ECB_SPI_SO

3VDUAL_USB3_A

ECBR33

1K/4/1/X

85

9

ECBU4

OEM+

1

Vcc

D+

Y+

2

Y-

D-

GND SEL

M-

3 10

4

2

VDD

ECBC8
1u/4/X5R/6.3V/K

GNDD

8

VDD

ECB_GPIO0

7

HOLD#

ECB_SPI_SCK

6

SCK

ECB_SPI_SO

5

SI

EBC1

0.1u/4/X7R/16V/K

ECB_GPIO0

MB SPI I/F

7

6

-ECB_SPI_CS
ECB_SPI_SCK

IT8951 SPI I/F

ECBC23

0.1u/4/X7R/16V/K

ECB_GPIO0

MB SPI I/F

7

6

IT8951 SPI I/F

ECBC24

0.1u/4/X7R/16V/K

USB_DP

7

USB_DM

6

U2DP1_A (49)
U2DM1_A (49)

ITB_VCCH

ECBC25
1u/4/X5R/6.3V/K

IO_GP67(28)

IO_GP67
Default:High
S3:Low

1

22u/8/X5R/6.3V/M

ECBC18

ECBR2
510/4/1

3
2
1

ECBR30

ECBC27

301/4/1

22u/8/X5R/6.3V/M

ECBR31
510/4/1

ITB_VCC

ITB_VCC

3

132

ITB_VCC

132

FORCE IT8951 CODE BACKUP
Default 2-3 short

5VDUAL

ECBR39

8.2K/4

-ECB_SPI_WP

-ECB_SPI_CS
ECB_GPIO0
ECB_GPIO1
ECB_GPIO2

ECB_GPIO11

1.8VD

0.1u/4/X7R/16V/K

ITB_VCCH

5VDUAL

VCC

5VDUAL

ECBR40
1K/4/1

3

D

ECBQ2
2N7002/SOT23/25pF/5

G S

2

1

ECBR17 8.2K/4
ECBR18 8.2K/4
ECBR19 8.2K/4
ECBR21 8.2K/4
ECBR22 8.2K/4

ECBR32 8.2K/4

PH/1*2/BK/2.54/VA/D

ECQ3
L1117LG/N/SOT223/1A

3
2

4

1

ECBR1

1.13K/4/1

ECB1

ECBQ1
L1117LG/N/SOT223/1A

4

ECBC26

0.1u/4/X7R/16V/K

ECBR41 0/6/X

ECBD1

BAS40-05/0.2A/SOT23

2
1

ECBR42 1K/4/1

ECBR43 1K/4/1

ITB_VCCH

ITB_PH2

ECB_GPIO2

For EC firmware update ,PVT remove

Title

Size Document Number Rev

Date: Sheet of

EC8951

Custom

GA-X99-UD5 WIFI

1

ECBC1

ITB_VCCH

1.8VD

ECBC17

1u/4/X5R/6.3V/K

ECBC19

22u/8/X5R/6.3V/M

22u/8/X5R/6.3V/M

ECBC29

ITB_VCC

22u/8/X5R/6.3V/M

ITB_VCCH

ECBC31

1u/4/X5R/6.3V/K

ECBC28

22u/8/X5R/6.3V/M

ECBQ3
PMBT2907A/SOT23/-600mA/50

SOT23

5VDUAL

ECBQ4
PMBT2907A/SOT23/-600mA/50

SOT23

5VDUAL

43 64Tuesday, August 26, 2014

1.0

5

PW_SW

POWER

D D

Reset

Clear CMOS

TS/BK/4.3/VA

C C

L1L2

6
5 2
4

SWITCH LOCK/[11NH7-020008-61R]

1 3
2 4

RST_SW

CMOS_SW

1 3
2 4

3
1

R194680/6

TS/BU/4.3/VA/[11NH7-030001-B1R]

N_-RTCRST_C

R190 33/4

5VDUAL

R209 33/4

R191 33/4

N_-RTCRST_C (57)

0.01u/4/X7R/25V/K

0.01u/4/X7R/25V/K

BC69

0.01u/4/X7R/25V/K

4

-PWRBT_1 (39)

BC66

BC68

N_-RTCRST (16,18,57)

RESET (39)

VRIN

PH/1*2/BK/2.54/VA/D/X

DIMM_A

PH/1*2/BK/2.54/VA/D/X

DIMM_B

PH/1*2/BK/2.54/VA/D/X

DDRVTT_A

PH/1*2/BK/2.54/VA/D/X

DDRVTT_B

3

VCORE

DDR_12V_A

DDR_12V_B

DDRVTT_A

DDRVTT_B

VPP25_A

PH/1*2/BK/2.54/VA/D/X

VPP25_B

PH/1*2/BK/2.54/VA/D/X

PCHV

PH/1*2/BK/2.54/VA/D/X

VPP_25V_A

VPP_25V_B

VCC1_05_WBG

2

1

Direct Key

DTB

B B

A A

1 3
2 4

TS/BK/4.3/VA

5

R5505 33/4

BC1209

0.01u/4/X7R/25V/K

DIRECT_KEY (42)

4

PH/1*2/BK/2.54/VA/D/X

Title

SWITCH

Size Document Number Rev

B

3

2

Date: Sheet of

GA-X99-UD5 WIFI 1.0

44 64Tuesday, August 26, 2014

1

8

CPU SMART FAN

EC_FANPWM1(42)

D D

100u/OS/D/16V/66/30m/[11CO5-C61000-01R]

100U/16V

ECEC1

ECR146
1K/4/1

1

+

1u/6/X7R/16V/K

VCC

ECC30

7

0/6/SHT/10/X

ECR50 100/4/1

+12V

ECR55

213

4

GVS

C

CPU_FAN
FAN/1*4/WH/A3/PA66

+12V

6

ECR51

3.3K/4/1
ECR53

15K/4/1

ECR54

6.2K/4/1

100U/16V

ECC14

0.047u/4/X7R/16V/K

5

EC_FANIO1 (42)

4

3

2

1

CPUOPT FAN

C C

ECR57
22K/4

1u/6/X7R/16V/K

VCC3

ECR12
1K/4/1

EC_FANPWM2(42)

ECC15
1u/4/X5R/6.3V/K

SYS FAN1

B B

INTERNAL PULL HI

VCC3

ECR60
1K/4/1

EC_FANPWM3(42)

ECC18
1u/4/X5R/6.3V/K

1u/6/X7R/16V/K

ECR62
22K/4

INTERNAL PULL HI

Enable Function (NCT3941S)
Full Turn On Function

+12V

(NCT3941S-A)

ECC17

ECFANA_VOUT

VCC3

ECR59 8.2K/4/X

ECFANA_SET

Enable Function (NCT3941S)
Full Turn On Function

+12V

(NCT3941S-A)

ECC19

ECFANB_VOUT

VCC3

ECR64 8.2K/4/X

ECFANB_SET

FAU15
NCT3941S-A/SOP8-EP

2

VIN

1 8

VOUT NC

3

ENABLE/FON#

4

VSET

FAU16
NCT3941S-A/SOP8-EP

2

VIN

1 8

VOUT NC

3

ENABLE/FON#

4

VSET

GND

PGND

GND

PGND

NC
NC

NC
NC

+12V

VCC

5
7

6
9

5
7

6
9

ECC31

10u/8/X5R/16V/K

ECFANA_VOUT

ECFANB_VOUT

10u/8/X5R/16V/K

213

GVS

CPU_OPT
FAN/1*4/BK/A3/PA66

ECC32

ECR56

ECR58

3.3K/4/1
ECR61

8.2K/4

15K/4/1

4

C

+12VVCC

ECR68

8.2K/4

213

4

GVS

C

SYS_FAN1
FAN/1*4/BK/A3/PA66

ECR70

3.3K/4/1

ECR71
15K/4/1

ECR63

6.2K/4/1

ECR73

6.2K/4/1

EC_FANIO2 (42)

ECC16

0.047u/4/X7R/16V/K

EC_FANIO3 (42)

ECC20

0.047u/4/X7R/16V/K

A A

Gigabyte Technology

Title

Size Document Number Rev

Custom

8

7

6

5

4

3

Date: Sheet of

HWM,KB/MS, FAN CTRL

GA-X99-UD5 WIFI

2

45 64Tuesday, August 26, 2014

1

1.0

5

4

3

2

1

Sound Level (dB-->DC Level)

VCC3

SLR1

2.2K/4/1/X

D D

SL_MIC1

A

2V BIAS

1

1

234

234

[MIC1󲒇󱙱PCH_SINK

C C

SL_MIC1

DUST STICKER[11WL1-014090-01R]/X

+/- 10mV AC

SLC1
1u/4/X5R/6.3V/K/X
SLR2

4.7K/4/X

MIC/S/[10BM1-014030-01R]/X

󰵔󶁜󵚩󴼚

VCC

Gain=1+(R1/R2)

SLC2

SL_MIC1_EN

SLR5
1K/4/1/X

SLR4
56K/4/1/X

SLR3
150K/4/X SLR6

0.01u/4/X7R/25V/K/X

󲽇󲋒󵨡󵞄

PCIEX16_1󴖞]

SLU1A

84

LM358DR/SO8/X

3

+

2

-

󱆖󳱣󲒇󱡰

1

330K/4/1/X

R1R2

SOT23

SLD1

BAT54A/SOT23/200mA/X

1u/4/X5R/6.3V/K/X

SLC3 0.1u/4/X7R/16V/K/X

VCC

󲽇󲅙

SLR7
56K/4/1/X

DC

SLC4

SLR8
1K/4/1/X

VCC

SLU1B

84

LM358DR/SO8/X

5

+

6

-

󱻕󳱣󲒇󱡰

7

SLR9
1K/4/1/X

R1R2

BIOS & S/W Notice:

1. 󰾐󴥶User

2.

󳒿󱖳󵜼󵖖󰺗󱅹

3. 󴳎󴾗Th

B B

󴥶󱫣󳱄󳲺󱖳󵜼󴣊󰺗󲔅

VINx󰺗󲔅1.65V(󱊼1.75V-0.1V)󲖋󶁜8620

󲖋󶁜󱭐

CPU & VGA

󵖖󵞄󲅟

CPU

A

A A

PCH

5

H/W Notice:

1.

󵷮󱂔󵟱󰵖󱌸󴟴

2.

󵷮󱂔󵟱󵙉󱏕

3. IT8620

B

4

4.

󵷮󱂔󵟱󲓢󴖨󳀃󶁪

CPU_FAN & VGA_FAN

OP-AMP

󴳓󵚩󴼚󴳓󱣆󶁜

󰾾󲵵󱅹dB󰾅󴳎󴾗

[10BM1-014030-01R]

3

user

󴥶󱫣󰾅󶁜󴽣󳜮

SOT23

󱇩󱼴 󲒇󵙄󴽨󱷯

SLD2

BAT54A/SOT23/200mA/X

SLR10
100K/4/1/X

<=3.3V DC

8620's VIN1

22u/8/X5R/6.3V/M/X

SLC5
22u/8/X5R/6.3V/M/X

󵕻󲪫󳛵󵓜
󱖳󵜼󱌖󲄒󴾗󱼴

MIC_VIN1

SLC6

󵓔󲦨󱻕

Delay

1u/4/X5R/6.3V/K/X

SLR11

1M/4/X

SLC7

󲓁󳤛󲆖

VCC3

Enable

SLR12

8.2K/4/X

5VDUAL

D

G S

2

45dB(󱊼VINx=1.75V)󶁜󳒿VINx󵨡󲔅1.75V󶁜8620󲙌󲇓PCH󳗍GPI7󲈒Low

󲙌󱃖󲇓

Throttle

󱎂󱅹󶁜󳑱

<1000mil

PCH󳗍GPI7󲈒Low

󰺗󲔅Tl󲖋󶁜󱆐󱘧󱻲󲪬󱶁󵞄󳋐󴾔󰺥

DIP

󵙄󱬂󲐔󰺘󵞸󱊪󳗍󵟱



PCH󳗍GPI7󳗅SMI



2

󰵉󲩪

󲪭

Table

󱌳󲕸󰾐󴥶󰾅󶁜 󵙉󴄼󳁪󵝈󱫭󲵵󴦯󱻕󳠃󴧖

Title

Size Document Number Rev

B

Date: Sheet of

Gigabyte Technology

Sound Level

GA-X99-UD5 WIFI

󵷮󱂔󵟱󰾾󲵵󱇨󴁆

G S

3

SLQ2
2N7002/SOT23/25pF/5/X

SLQ1

SOT23

1

2N7002/SOT23/25pF/5/X

󰵉󲩪

1

S

L_MIC1_EN

3

D

2

1

dB
30
35
40

50
55
60
65 2.35V
70
75
80
85
90
95

100

46 64Tuesday, August 26, 2014

SOT23

VINx

1.30V

1.45V

1.60V

1.75V45

1.90V

2.05V

2.20V

2.50V

2.65V

2.80V

2.95V

3.10V

3.25V

3.33V

1.0

5

D D

󴨔󴿁󲐐󴾲󳑱󳗍

SOC/UD7/UD5/G1/G7 : USB3

;UD3/G5:USB5

WIFI use PCIE port4 in X99

C C

DIP

󴜃󴜃󴜃󴜃󳲻󳲻󳲻󳲻

30

CR/[12KS2-110202-01R]

B B

USBport :

M2_WIFI_TP(17)
M2_WIFI_TN(17)

SMD

󴜃󴜃󴜃󴜃󲜺󲜺󲜺󲜺

30

1

1

CR/[10KS2-040109-01R]

should be SMD level

M2WC4 0.1u/4/X7R/16V/K
M2WC5 0.1u/4/X7R/16V/K

N_-PCIE_WAKE(16,20,21,23,24,25,58)

3VDUAL

4

N_+USBP10(17)

N_-USBP10(17)

M2_WIFI_IP(17)
M2_WIFI_IN(17)

CK_WIFI_100M_DP(17)

CK_WIFI_100M_DN(17)

M2WR6 0/4/SHT/20/X

M2_WIFI_TP_C
M2_WIFI_TN_C

M2WR4 8.2K/4

WIFI_CLKREQ_N
WIFI_WAKE_N

3

M2_WIFI

1 2

GND 3P3VAUX_2

3

USB_D+

5

USB_D-

7

GND

9

SDIO CLK

11

SDIO CMD

13

SDIO DATA0

15

SDIO DATA1

17

SDIO DATA2

19

SDIO DATA3

21

SDIO WAKE#

23

SDIO RESET#

REV=1

PCM_OUT/I2S SD_OUT

3P3VAUX_4

LED1#

PCM_CLK/I2S SCK

PCM_SYNC/I2S WS

PCM_IN/I2S SD_IN

LED2#

GND

UART WAKE#

UART RXD

Module Key E

33

GND

35

PETP0

37

PETN0

39

GND

41

PERP0

43

PERN0

47

REFCLKP0

49

REFCLKN0

53

CLKREQ0#

55

PEWAKE0#

59

RSVD/PETP1

61

RSVD/PETN1

63

GND

65

RSVD/PERP1

67

RSVD/PERN1

69

GND

71

RSVD/REFCLKP1

73

RSVD/REFCLKN1

75

GND

NGFF_M2_E-KEY/[10NR5-130067-22R]

UIM_PWR_SNK/CLKREQ1#
UIM_PWR_SRC/PEWAKE1#

NGFF_M2_E-KEY[10NR5-130067-22R]

UART TXD
UART CTS

UART_RTS
VENDOR DEFINED
VENDOR DEFINED
VENDOR DEFINED

COEX3GND
COEX2
COEX1

SUSCLK(32KHz)GND

PERST0#
W_DISABLE2#
W_DISABLE1#GND

I2C_DATA

I2C_CLK

ALERT#

UIM_SWP/PERST1#

RSVD

3P3VAUX_72
3P3VAUX_74

4
6
8
10
12
14
16
18
20
22

32
34
36
38
40
42
4445
46
48
5051
52
54
5657
58
60
62
64
66
68
70
72
74

3VDUAL

LED1_HDR

LED2_HDR

PCH_SUSCLK
WLAN_RST_N

3VDUAL

2

3VDUAL 3VDUAL

M2WR1
330/4/X

M2WD1
LED/B/6/S[10DL3-32000B-37R]/X

WiFi

1

M2WR3 0/4/SHT/M/X

1

M2WR5 0/4/SHT/M/X
M2WR7 8.2K/4
M2WR8 8.2K/4

1

M2WR9 0/4/SHT/M/X

1

M2WR10 0/4/SHT/M/X

M2WR11 8.2K/4

WLAN_RST_N

M2WR2
330/4/X

M2WD2
LED/B/6/S[10DL3-32000B-37R]/X

BT

3VDUAL

M2WC1 0.01u/4/X7R/25V/K

M2WC2 0.01u/4/X7R/25V/K

M2WC3 0.1u/4/X7R/16V/K
M2WC6 10u/6/X5R/6.3V/M

N_SUSCLK_WIFI (16)

3VDUAL

3VDUAL

PCIE_OB2_RST (15,48)

N_SMBDATA (16,20,21,23,24,25,26,27,30,34,35,37,42,58)
N_SMBCLK (16,20,21,23,24,25,26,27,30,34,35,37,42,58)

M2WBC1
10p/4/NPO/50V/J/X

1

M_PCIE_H

WIFI_MODULE
WI-FI WITH BT MINI CARD INTEL/[20CB1-027260-20R]

PVT need pop this part !

A A

Title

Size Document Number Rev

B

5

4

3

2

Date: Sheet of

M2_WIFI

47 64Tuesday, August 26, 2014

1.0

1

5

D D

M2SATA_RX5N
M2SATA_RX5P

M2SATA_TX5N
M2SATA_TX5P

M2SATA_RX4P
M2SATA_RX4N

M2SATA_TX4N
M2SATA_TX4P

0: PCIE M.2

C C

SATA_PCIE_DET

VCC3

M2R5
1K/4/1

M2SSD_IFDET

M2R6
22K/4

B B

M2R19
0/4/X

132

M2Q1
MMBT2222A/SOT23/600mA/40

BAT54A/SOT23/200mA

PCH

-M2_DETECT

N_GPIO69(15)

PCH GPIO69

󴣊󳥄󵖭

VCC3

M2R16
1K/4/1

M2R17 22K/4

M2R18 1K/4/1

5

A A

󴽬󲋮

GPIO69 PU HI

1: SATA M.2

M2R2 0/4/SHT/M/X
M2R3 0/4/SHT/M/X

SOT23

M2D1

-M2_DETECT

M2BC1

1u/4/X5R/6.3V/K

N_SATA4TXP(15)
N_SATA4TXN(15)

N_SATA4RXN(15)
N_SATA4RXP(15)

N_SATA5TXP(15)
N_SATA5TXN(15)

N_SATA5RXN(15)
N_SATA5RXP(15)

VCC3

M2R15

8.2K/4

M2SATA_SW

3

D

G S

2

1

1

1

M2BC2
1u/4/X5R/6.3V/K

N_SATA4TXP
N_SATA4TXN

N_SATA4RXN
N_SATA4RXP

N_SATA5TXP
N_SATA5TXN

N_SATA5RXN
N_SATA5RXP

M2Q2
2N7002/SOT23/25pF/5

N_GPIO16 (15)

N_GPIO49 (15)

M2BC3

0.1u/4/X7R/16V/K

M2SATA_SW

CBTL04083BBS/HVQFN32/[10TA1-084083-10R_10TA1-081480-10R]

Priority : M2 > SATA_EXPRESS

VCC3

M2C6MASK/0/5/SHT/X
M2C7MASK/0/5/SHT/X

M2C90.1u/4/X7R/16V/K
M2C100.1u/4/X7R/16V/K

M2C12MASK/0/5/SHT/X
M2C13MASK/0/5/SHT/X

M2C150.1u/4/X7R/16V/K
M2C160.1u/4/X7R/16V/K

SATA
PCIE󶁪NC

M2U1

9

VDD

19

V

21

VDD

26

VDD

31

VDD

34

VDD

39

VDD

41

VDD

1

AI+

2

AI-

5

BI+

6

BI-

10

CI+

11

CI-

14

DI+

15

DI-

30

SEL

43

GNDPAD

4

M2_10G

1 2

GND 3.3V

3

GND

5 6

PERN3 NC

7 8

PERP3 NC

9 10

GND DAS/DSS*

11

PETN3

13

PETP3

15

GND

Key B

M2SATA_RX5N_C

1

M2SATA_RX5P_C

1

M2SATA_TX5N_C
M2SATA_TX5P_C N_GPIO73M2SSD_SATA_DEVSLP

M2SATA_RX4P_C

1

M2SATA_RX4N_C

1

M2SATA_TX4N_C
M2SATA_TX4P_C

CK_M2_100M_DN(17)

CK_M2_100M_DP(17)

17

PERN2

19

PERP2

21

GND

23 24

PETN2 NC

25 26

PETP2 NC

27 28

GND NC

29 30

PERN1 NC

31 32

PERP1 NC

33 34

GND NC

35 36

PETN1 NC

37 38

PETP1 DEVSLP

39 40

GND NC

41 42

PERN0/SATA_B+ NC

43 44

PERP0/SATA_B- NC

45 46

GND NC

47 48

PETN0/SATA_A- NC

49 50

PETP0/SATA_A+ PERST*/NC

51 52

GND CLKREQ*/NC

53 54

REFCLKN PEWAKE*/NC

55 56

REFCLKP NC

57 58

GND NC

SKT3

SSD PIN OUT

3

3.3V

3.3V

3.3V

3.3V

3.3V
NC
NC

4

12
14
16
18
20
22

M2SATAE_PERST_N

KEY M

KEY M

KEY M

󶁪

GND.

M2SSD_IFDET

M2

󲌛󱊪󲖋󳀃

AOa+
AOa-

BOa+
BOa-

COa+
COa-

DOa+
DOa-

AOb+
AOb-

BOb+
BOb-

COb+
COb-

DOb+
DOb-

GND
GND
GND
GND
GND
GND
GND
GND
GND

-M2_DETECT

37
36

33
32

28
27

24
23

3
4

7
8

12
13

16
17

18
20
22
25
29
35
38
40
42

M2R38 0/4/X

DD

4

67 68

NC SUSCLK

69 70

PEDET 3.3V

71 72

GND 3.3V

73 74

GND 3.3V

75

Low

SE_SATA4TXP
SE_SATA4TXN

SE_SATA4RXN
SE_SATA4RXP

SE_SATA5TXP
SE_SATA5TXN

SE_SATA5RXN
SE_SATA5RXP

M2SATA_TX4P
M2SATA_TX4N

M2SATA_RX4N
M2SATA_RX4P

M2SATA_TX5P
M2SATA_TX5N

M2SATA_RX5N
M2SATA_RX5P

GND

M2/67/BK/RA/S/H8.5mm/M KEY/[10NR5-130067-52R]

M2/67/BK/RA/S/H8.5mm/M KEY/[10NR5-130067-52R]

To SATA3
port4/5

M.2 X2

Function

SEL
xI--> xOa
xI--> xOb

L
H

( 32KHz )

SE_SATA4TXP
SE_SATA4TXN

SE_SATA4RXN
SE_SATA4RXP

SE_SATA5TXP
SE_SATA5TXN

SE_SATA5RXN
SE_SATA5RXP

PCIE_OB2B_RST(15)

N_GPIO73(16)

-SE_HSERST

3

SEC1 MASK/0/5/SHT/X
SEC2 MASK/0/5/SHT/X

SEC3 MASK/0/5/SHT/X
SEC4 MASK/0/5/SHT/X

SEC5 MASK/0/5/SHT/X
SEC6 MASK/0/5/SHT/X

SEC7 MASK/0/5/SHT/X
SEC8 MASK/0/5/SHT/X

SER1 0/4/SHT/X
SER2 0/4/SHT/X

VCC3

VCC3

-M2_DETECT

Key B

M2SATAE_PERST_N

M2SATAE_PERST_N

VCC3

1
1

1
1

1
1

1
1

1
1

M2BC8
10p/4/NPO/50V/J/X

SER11
1K/4/1/X

SE_IFDET

SER6
22K/4

-M2_LED (39)

1

M2R10 0/4/SHT/M/X

1

M2R11 0/4/SHT/M/X

N_SATA4TXPC
N_SATA4TXNC

N_SATA4RXNC
N_SATA4RXPC

N_SATA5TXPC
N_SATA5TXNC

N_SATA5RXNC
N_SATA5RXPC

-SE_HSERST
SE_DEVSLP
SE_IFDET

VCC3

SER5

1K/4/1

SER8 22K/4

M2R7 8.2K/4/X

M2BC7
10p/4/NPO/50V/J/X

SATA_EXPRESS

L1
L2
L3
L4
L5
L6
L7
L8
L9

L10
L11
L12
L13
L14

P1
P2
P3
P4

SE_PCIE_DET

SEQ1
MMBT2222A/SOT23/600mA/40

132

SER7

0/4/X

M2Q3
MMBT2222A/SOT23/600mA/40

SOT23

132

2

VCC3

M2C1 0.01u/4/X7R/25V/K

M2C2 0.01u/4/X7R/25V/K

M2C3 0.1u/4/X7R/16V/K

VCC3

N_GPIO73 (16)

PCIE_OB2_RST (15,47)

LGND0
LPETp0/A0+
LPETn0/A0­LGND1
LPERn0/B0­LPERp0/B0+
LGND2
LGND3
LPETp1/A1+
LPETn1/A1­LGND4
LPERn1/B1­LPERp1/B1+
LGND5
LReserved
LPERST#
LCLKR#/DESLP
LIFDet

GND6

G1

SATA EXPRESS/36P/BK/H/RA/D/GF/2::Location SATA_EXPRESS

GND7

G2

HGND0

HPETp0/A0+

HPETn0/A0-

HGND1

PHERn0/B0-

HPERp0/B0+

HGND2
HGND3

HPETp1/A1+

HPETn1/A1-

HGND4

HPERn1/B1-

HPERp1/B1+

HGND5

HReserved

HPERST#

HCLKR#/DESLP

HIFDet

M2C37 10u/6/X5R/6.3V/M

L15
L16
L17
L18
L19
L20
L21
L22
L23
L24
L25
L26
L27
L28
P5
P6
P7
P8

0: SATA EXPRESS
1: SATA (STandard)

1

SER9 0/4/SHT/X

1

SER10 0/4/SHT/X

2

N_GPIO16 (15)
N_GPIO49 (15)

1

VCC3

M2C5 0.01u/4/X7R/25V/K

M2C8 0.01u/4/X7R/25V/K

M2C11 0.1u/4/X7R/16V/K
M2C14 10u/6/X5R/6.3V/M

SMD

󴜃󴜃󴜃󴜃󲜺󲜺󲜺󲜺

60

CR/[11KS2-040002-01R]

DIP

󴜃󴜃󴜃󴜃󲜺󲜺󲜺󲜺

80

CR/[12KSF-F10303-11R]

N_SATA2TXPC
N_SATA2TXNC

N_SATA2RXNC
N_SATA2RXPC

N_SATA3TXPC
N_SATA3TXNC

N_SATA3RXNC
N_SATA3RXPC

SATA6G:20/5/7/5/20(breakout min 4/4/4/4/4)
Impedance=85 +- 17.5%

SATA6G:20/5/6.5/5/20(breakout min 4/4/4/4/4)
Impedance=85 +- 12%

Title

M2_X2_10G

Size Document Number Rev

Custom

Date: Sheet of

80

CR/[11KS2-040002-01R]

DIP

󴜃󴜃󴜃󴜃󳲻󳲻󳲻󳲻

80

CR/[12KS2-110202-01R]

N_SATA2TXP

SEC9MASK/0/5/SHT/X

1

N_SATA2TXN

SEC10MASK/0/5/SHT/X

1

N_SATA2RXN

SEC11MASK/0/5/SHT/X

1

N_SATA2RXP

SEC12MASK/0/5/SHT/X

1

N_SATA3TXP

SEC13MASK/0/5/SHT/X

1

N_SATA3TXN

SEC14MASK/0/5/SHT/X

1

N_SATA3RXN

SEC15MASK/0/5/SHT/X

1

N_SATA3RXP

SEC16MASK/0/5/SHT/X

1

1

N_SATA2TXP (15)
N_SATA2TXN (15)

N_SATA2RXN (15)
N_SATA2RXP (15)

N_SATA3TXP (15)
N_SATA3TXN (15)

N_SATA3RXN (15)
N_SATA3RXP (15)

48 64Tuesday, August 26, 2014

󱡟󱡟󱡟󱡟󱮭󱮭󱮭󱮭

󱂰󱂰󱂰󱂰󱮭󱮭󱮭󱮭

1.0

5

3VDUAL_USB3_A3VDUAL_USB3_A

4

3

2

1

HAC14

0.1u/4/X7R/16V/K

D D

C C

HAC15

0.1u/4/X7R/16V/K

PCH U S B P O R T4

PCH U S B P O R T4

PCH U S B P O R T4PCH U S B P O R T4

PCH_USB3_RXN4(17)
PCH_USB3_RXP4(17)

PCH_USB3_TXN4(17)
PCH_USB3_TXP4(17)

HAC1

0.1u/4/X7R/16V/K

N_-USBP4(17)

N_+USBP4(17)

HAC2

0.1u/4/X7R/16V/K

PCH_USB3_RXN4
PCH_USB3_RXP4

PCH_USB3_TXN4
PCH_USB3_TXP4

HAC3

0.1u/4/X7R/16V/K

5VDUAL

3VDUAL_USB3_A

HAC4

0.1u/4/X7R/16V/K

HAR8 10K/4/1

HAC21 0.1u/4/X7R/16V/K
HAC22 0.1u/4/X7R/16V/K

HAC23 0.1u/4/X7R/16V/K
HAC24 0.1u/4/X7R/16V/K

Power on Reset

0.1u/4/X7R/16V/K

5VDUAL

HAR3 10K/4/1

HAR9 15K/4/1

HAR10 10K/4/1
HAD1
1N4148W/SOD123/300mA/X

HAC5

0.1u/4/X7R/16V/K

USB SS (90Ohm-differential)

HAC25 10u/6/X5R/6.3V/M

HAC6

0.1u/4/X7R/16V/K

HAR4 15K/4/1

HAC18 10u/6/X5R/6.3V/M
HAC19 0.1u/4/X7R/16V/K

RESETB_A(50)

HAC7

HAR7 15K/4/1

HAC20 0.1u/4/X7R/16V/K

HATP1

HAC8

0.1u/4/X7R/16V/K

3VDUAL_USB3_A

SPISCK_A(50)
SPICSB_A(50)
SPISI_A(50)
SPISO_A(50)

LED1B_A(50)

HAR6

0/4/SHT/M/X

V33OUT_A
V33IN_A
BUSSEL_A
VBUSM_A

U3TXDPU_A
U3RXDNU_A

U3RXDPU_A

RESETB_A

SPISCK_A
SPICSB_A
SPISI_A
SPISO_A

LED1B_A
SUSPEND_A

0/4/SHT/M/X

48
50
44
43

63
62

65
66

68
69

2

41
38
39
40

37

1

HAR2

3VDUAL_USB3_A 3VDUAL_USB3_A

V50IN_A

49

V33OUT
V33IN
BUSSEL
VBUSM

U2DMU
D2DPU

U3TXDNU
U3TXDPU

U3RXDNU
U3RXDPU

RESETB

SPISCK/LED4B
SPICSB
SPISI/LED2B
SPISO/LED3B

LED1B/SUSPEND
SUSPEND/NRDCLKO

251734

8

V50IN

VDD33

VDD33

VDD33

61

42

76

VDD33

VDD33

VDD33

VDD33

uPD720210

USB_1V05_A

HAC12 0.1u/4/X7R/16V/K

HAC11 0.1u/4/X7R/16V/K

A1.05V_A

221411

5

VDD10

VDD10

VDD10

VDD10

642847

31

VDD10

VDD10

VDD10

VDD10

A3.3V_A

71

67

70

VDD10

VDD10

AVDD33

U3TXDP4
U3TXDN4

U2DM4
U2DP4

U3RXDP4
U3RXDN4

OCI4B
OCI3B

PPON4B
PPON3B

U3TXDP3
U3TXDN3

U2DM3
U2DP3

U3RXDP3
U3RXDN3

HAC16 0.1u/4/X7R/16V/K

HAC17 0.1u/4/X7R/16V/K

HAU1
UPD720210/[10HB2-700210-10R]

U3TXDP4_A

29

U3TXDN4_A

30

U2DM4_A

36

U2DP4_A

35

U3RXDP4_A

32

U3RXDN4_A

33

OCI4B_A

59

OCI3B_AU3TXDNU_A

57

PPON4B_A

60

PPON3B_A

58

USB SS (90Ohm-differential)

U3TXDP3_A

20

U3TXDN3_A

21

U2DM3_A

27

U2DP3_A

26

U3RXDP3_A

23

U3RXDN3_A

24

USB SS (90Ohm-differential)

USB SS (90Ohm-differential)

PPON4B_A (50)
PPON3B_A (50)

USB SS (90Ohm-differential)

U3TXDP4_A (60)
U3TXDN4_A (60)

U2DM4_A (60)
U2DP4_A (60)

U3RXDP4_A (60)
U3RXDN4_A (60)

OCI4B_A (60)
OCI3B_A (60)

4  STE P U SB3 . 0  CO N N E CT

4  STE P U SB3 . 0  CO N N E CT

4  STE P U SB3 . 0  CO N N E CT4  S TE P U S B3 . 0  CO N N E CT

U3TXDP3_A (60)
U3TXDN3_A (60)

U2DM3_A (60)
U2DP3_A (60)

U3RXDP3_A (60)
U3RXDN3_A (60)

USB HS (90Ohm-differential)

HAR15 0/4/SHT/M/X

B B

3VDUAL_USB3_A

HAY1

Put close to U1
Do check with crystal vendor
if the value of C31, C32 and
R31 are all appropriate.

A A

24M/20p/30ppm/49US/30/D

HAC27
10p/4/NPO/50V/J

USB_1V05_AUSB_1V05_A

HAR20 0/4/SHT/M/X

HAR22 0/4/SHT/M/X

HAR23 680/4/1

HAC28
10p/4/NPO/50V/J

PGDRV_A

51

PGDRV

52

NGDRV

ILIM_A

53

V10FB_A

HAXT1_A

HAXT2_A

RREF_A

HAR24

1.6K/4/1

Put close to U1
Short and broad connection to GND
Don't split R32 into multiple
resistors.

ILIM

54

V10FB

74

XT1

75

XT2

72

RREF

73

IC(L)

U3TXDP2_A

12

U3TXDP2

U3TXDN2_A

13

U3TXDN2

U2DM2_A

19

U2DM2

U2DP2_A

18

U2DP2

U3RXDP2_A

15

U3RXDP2

U3RXDN2_A

16

U3RXDN2

OCI2B_A

55

OCI2B

OCI1B_A

45

OCI1B

PPON2B_A

56

PPON2B

PPON1B_A

U3TXDP1
U3TXDN1

U2DM1
U2DP1

U3RXDP1
U3RXDN1

46

U3TXDP1_A

3

U3TXDN1_A

4

U2DM1_A

10

U2DP1_A

9

U3RXDP1_A

6

U3RXDN1_A

7

PPON1B/NRDRSTB

GND

77

PPON2B_A (50)
PPON1B_A (50)

USB SS (90Ohm-differential)

USB SS (90Ohm-differential)

USB HS (90Ohm-differential)

U3TXDP2_A (60)
U3TXDN2_A (60)

U2DM2_A (60)
U2DP2_A (60)

U3RXDP2_A (60)
U3RXDN2_A (60)

OCI2B_A (60)
OCI1B_A (60)

4  STE P U SB3 . 0  CO N N E CT

4  STE P U SB3 . 0  CO N N E CT

4  STE P U SB3 . 0  CO N N E CT4  S TE P U S B3 . 0  CO N N E CT

U3TXDP1_A (60)
U3TXDN1_A (60)

U2DM1_A (43)
U2DP1_A (43)

U3RXDP1_A (60)
U3RXDN1_A (60)

HAC29

0.1u/4/X7R/16V/K

HAC30

0.1u/4/X7R/16V/K

HAC31

0.1u/4/X7R/16V/K

5

HAC32

0.1u/4/X7R/16V/K

HAC33

0.1u/4/X7R/16V/K

HAC34

0.1u/4/X7R/16V/K

4

HAC35

0.1u/4/X7R/16V/K

HAC36

0.1u/4/X7R/16V/K

HAC37

0.1u/4/X7R/16V/K

HAC38

0.1u/4/X7R/16V/K

HAC39

0.1u/4/X7R/16V/K

3

HAC40

0.1u/4/X7R/16V/K

HAC41

0.1u/4/X7R/16V/K

Title

Size Document Number Rev

2

Date: Sheet of

Gigabyte Technology

C

D720210

GA-X99-UD5 WIFI

1

49 64Tuesday, August 26, 2014

1.0

5

4

3

2

1

3VDUAL_USB_1

5VDUAL

HAC56

D D

C C

5VDUAL

HAR42

2.2/4

5VDUAL

HAR47

2.2/4

HABC2
1u/4/X5R/6.3V/K

3VDUAL_USB3_A

VCC2_2_A

B B

HABC1
1u/4/X5R/6.3V/K

A A

HAC57

1u/4/X5R/6.3V/K

3VDUAL_USB3_A

HAR54

8.2K/4

E

N_P_A

HAC50

10u/6/X5R/6.3V/M

HAR53

8.2K/4/X

EN_VCC22_A

HAC54

10u/6/X5R/6.3V/M

2

L1085DG/TO252/5A

EN_VCC22_A

SPEC: 1.05V +/- 5%

1
2
3
4 5

HAC51
1u/4/X5R/6.3V/K

RESETB_A

HAR45

0/4/SHT/M/X

HAC55
1u/4/X5R/6.3V/K

0.1u/4/X7R/16V/K

3

HAR51

1

3VDUAL_USB3_A

HAC46

0.1u/4/X7R/16V/K

GND

FB

VOUT

PGND

9

RT9018B-18GSP/SO8/3A

RESETB_A (49)

100/4/1

HAR52
169/4/1

HAQ3

HAU3

POK
EN
VIN
CNTL REFIN

Reserved

HAU4

1

POK

2
3
4 5

GND
EN
VIN

VOUT

CNTL REFIN

PGND

9

RT9018B-18GSP/SO8/3A

FB

8
7
6

HAC59

0.1u/4/X7R/16V/K

HAR36 8.2K/4

8
7
6

3VDUAL_USB3_A

HAC58

0.1u/4/X7R/16V/K

VCC2_2_A

HAR41
169K/4/1

HAR43
100K/4/1

USB_1V05_A

1

+

HAEC2
100u/FP/D/6.3V/65/C/13m

HAC47

0.1u/4/X7R/16V/K/X

SPEC: 1.05V +/- 5%

HAR46

HAC52

100K/4/1

0.1u/4/X7R/16V/K/X

HAR48
316K/4/1

EN_P_A

HAC45

0.1u/4/X7R/16V/K

HAC53
1u/4/X5R/6.3V/K

10u/6/X5R/6.3V/M

HAC49
1u/4/X5R/6.3V/K

HAC60

HAC61
10u/6/X5R/6.3V/M

# External SPI ROM ; SPI ROM
attached mode

# Battery Charging

# Number of Ports ; 4Ports
mode

PPON3B / PPON4B : H / H ( 4 port )
PPON3B / PPON4B : L / L ( 2 port )

#5 VBUS Power Control
; Individual mode

# PPON1B Pin Function ;
Port1 PPONB mode

3VDUAL_USB3_A

SPICSB_A

SPISI_A

SPISCK_A

SPISO_A

LED1B_A

LED1B_A(49)

PPON4B_A(49)

PPON3B_A(49)

PPON2B_A(49)

PPON1B_A(49)

PPON4B-A

PPON3B_A

PPON2B_A

PPON1B_A

HAR25 10K/4/1
HAR26 1K/4/1/X

HAR28 10K/4/1
HAR29 1K/4/1/X

HAR55 10K/4/1/X
HAR30 1K/4/1

HAR56 10K/4/1/X
HAR31 1K/4/1

HAR32 10K/4/1

HAR49 10K/4/1/X

HAR33 10K/4/1
HAR57 1K/4/1/X

HAR34 10K/4/1
HAR58 1K/4/1/X

HAR35 10K/4/1/X
HAR40 10K/4/1

HAR38 10K/4/1
HAR39 10K/4/1/X

3VDUAL_USB3_A

3VDUAL_USB3_A

3VDUAL_USB3_A

3VDUAL_USB3_A

3VDUAL_USB3_A

3VDUAL_USB3_A

3VDUAL_USB3_A

SPICSB_A(49)
SPISO_A(49)

3VDUAL_USB3_A

SPICSB_A
SPISO_A

3VDUAL_USB3_A

HAR27
10K/4/1

HAU2

1

CS#

2 7

SO HOLD#

3

WP#

4

GND

4M/SPI/SO8/200mil/S/[10HP4-112540-30R]

8

VCC

SCK

SI

SPISCK_A

6
5

SPISI_A

HAC42

0.1u/4/X7R/16V/K

SPISCK_A (49)
SPISI_A (49)

Title

Size Document Number Rev

5

4

3

2

Date: Sheet of

Gigabyte Technology

Custom

D720210

GA-X99-UD5 WIFI

50 64Tuesday, August 26, 2014

1

1.0

3VDUAL_USB3_B

5

3VDUAL_USB3_B

4

3

2

1

HBC14

0.1u/4/X7R/16V/K

D D

C C

HBC15

0.1u/4/X7R/16V/K

PCH U S B P O R T5

PCH U S B P O R T5

PCH U S B P O R T5PCH U S B P O R T5

N_-USBP5(17)
N_+USBP5(17)

PCH_USB3_RXN5(17)
PCH_USB3_RXP5(17)

PCH_USB3_TXN5(17)
PCH_USB3_TXP5(17)

HBC1

0.1u/4/X7R/16V/K

HBC2

0.1u/4/X7R/16V/K

PCH_USB3_RXN5
PCH_USB3_RXP5

PCH_USB3_TXN5
PCH_USB3_TXP5

HBC3

0.1u/4/X7R/16V/K

5VDUAL

3VDUAL_USB3_B

Power on Reset

HBC4

0.1u/4/X7R/16V/K

5VDUAL

HBR8 10K/4/1

HBC21 0.1u/4/X7R/16V/K
HBC22 0.1u/4/X7R/16V/K

HBC23 0.1u/4/X7R/16V/K
HBC24 0.1u/4/X7R/16V/K

HBC5

0.1u/4/X7R/16V/K

HBR3 10K/4/1

HBR9 15K/4/1

HBR10 10K/4/1
HBD1

1N4148W/SOD123/300mA/X

HBC6

0.1u/4/X7R/16V/K

0.1u/4/X7R/16V/K

HBR4 15K/4/1

HBC18 10u/6/X5R/6.3V/M
HBC19 0.1u/4/X7R/16V/K

HBR7 15K/4/1
HBC20

USB SS (90Ohm-differential)

RESETB_B(52)

HBC25 10u/6/X5R/6.3V/M

HBC7

0.1u/4/X7R/16V/K

SPISCK_B(52)
SPICSB_B(52)

SPISO_B(52)

HBTP1

HBC8

3VDUAL_USB3_B

0.1u/4/X7R/16V/K

SPISI_B(52)

LED1B_B(52)

HBR6

0/4/SHT/M/X

V33OUT_B
V33IN_B
BUSSEL_B
VBUSM_B

U3TXDNU_B
U3TXDPU_B

U3RXDNU_B
U3RXDPU_B

RESETB_B

SPISCK_B
SPICSB_B
SPISI_B
SPISO_B

LED1B_B
SUSPEND_B

HBR2

0/4/SHT/M/X

48

V33OUT

50

V33IN

44

BUSSEL

43

VBUSM

63

U2DMU

62

D2DPU

65

U3TXDNU

66

U3TXDPU

68

U3RXDNU

69

U3RXDPU

2

RESETB

41

SPISCK/LED4B

38

SPICSB

39

SPISI/LED2B

40

SPISO/LED3B

37

LED1B/SUSPEND

1

SUSPEND/NRDCLKO

3VDUAL_USB3_B

V50IN_B

49

V50IN

USB_1V05_B 3VDUAL_USB3_B

HBC12 0.1u/4/X7R/16V/K

HBC11 0.1u/4/X7R/16V/K

A1.05V_B

61

42

251734

8

VDD33

VDD33

VDD33

VDD33

5

76

VDD33

VDD33

VDD10

VDD10

VDD10

VDD33

642847

31

221411

VDD10

VDD10

VDD10

VDD10

VDD10

uPD720210

A3.3V_B

71

67

70

VDD10

VDD10

AVDD33

U3TXDP4
U3TXDN4

U2DM4

U2DP4

U3RXDP4
U3RXDN4

OCI4B
OCI3B

PPON4B
PPON3B

U3TXDP3
U3TXDN3

U2DM3

U2DP3

U3RXDP3
U3RXDN3

HBC16 0.1u/4/X7R/16V/K

HBC17 0.1u/4/X7R/16V/K

HBU1
UPD720210/[10HB2-700210-10R]

USB SS (90Ohm-differential)

U3TXDP4_B

29

U3TXDN4_B

30

U2DM4_B

36

U2DP4_B

35

U3RXDP4_B

32

U3RXDN4_B

33

OCI4B_B

59

OCI3B_B

57

PPON4B_B

60
58

20
21

27
26

23
24

PPON4B_B (52)

PPON3B_B

PPON3B_B (52)

USB SS (90Ohm-differential)

U3TXDP3_B
U3TXDN3_B

U2DM3_B
U2DP3_B

U3RXDP3_B
U3RXDN3_B

USB HS (90Ohm-differential)

USB SS (90Ohm-differential)

U3TXDP4_B (56)
U3TXDN4_B (56)

U2DM4_B (56)
U2DP4_B (56)

U3RXDP4_B (56)
U3RXDN4_B (56)

OCI4B_B (56)
OCI3B_B (56)

U SB3 0

L AN 2  or

U SB3 0L AN 2  or

U SB3 0L AN 2  orU SB3 0L AN 2  or



K BM SU SB3 0

K BM SU SB3 0

K BM SU SB3 0K BM SU SB3 0

U3TXDP3_B (56)
U3TXDN3_B (56)

U2DM3_B (56)
U2DP3_B (56)

U3RXDP3_B (56)
U3RXDN3_B (56)

USB SS (90Ohm-differential)

USB HS (90Ohm-differential)

HBR15 0/4/SHT/M/X

B B

3VDUAL_USB3_B

HBY1

Put close to U1
Do check with crystal vendor
if the value of C31, C32 and
R31 are all appropriate.

A A

24M/20p/30ppm/49US/30/D

HBC27
10p/4/NPO/50V/J

USB_1V05_BUSB_1V05_B

HBR20 0/4/SHT/M/X

HBR22 0/4/SHT/M/X

HBR23 680/4/1

HBC28
10p/4/NPO/50V/J

PGDRV_B

51

PGDRV

52

NGDRV

ILIM_B

53

ILIM

V10FB_B

54

V10FB

HAXT1_B

74

XT1

HAXT2_B

75

XT2

HBR24

RREF_B

72

1.6K/4/1

Put close to U1
Short and broad connection to GND
Don't split R32 into multiple
resistors.

RREF

73

IC(L)

U3TXDP2_B

12

U3TXDP2

U3TXDN2_B

13

U3TXDN2

U2DM2_B

19

U2DM2

U2DP2_B

18

U2DP2

U3RXDP2_B

15

U3RXDP2

U3RXDN2_B

16

U3RXDN2

OCI2B_B

55

OCI2B

OCI1B_B

45

OCI1B

PPON2B_B

56

PPON2B

U3TXDP1
U3TXDN1

U2DM1

U2DP1

U3RXDP1
U3RXDN1

46

3
4

10
9

6
7

PPON1B/NRDRSTB

GND

77

PPON1B_B

U

3TXDP1_B

U3TXDN1_B
U2DM1_B

U2DP1_B
U3RXDP1_B

U3RXDN1_B

PPON2B_B (52)
PPON1B_B (52)

USB SS (90Ohm-differential)

USB SS (90Ohm-differential)

USB HS (90Ohm-differential)

U3TXDP2_B (56)
U3TXDN2_B (56)

U2DM2_B (56)
U2DP2_B (56)

U3RXDP2_B (56)
U3RXDN2_B (56)

OCI2B_B (56)
OCI1B_B (56)

U SB3 0L AN 1

U SB3 0L AN 1

U SB3 0L AN 1U SB3 0L AN 1

U3TXDP1_B (56)
U3TXDN1_B (56)

U2DM1_B (56)
U2DP1_B (56)

U3RXDP1_B (56)
U3RXDN1_B (56)

HBC29

0.1u/4/X7R/16V/K

HBC30

0.1u/4/X7R/16V/K

HBC31

0.1u/4/X7R/16V/K

5

HBC32

0.1u/4/X7R/16V/K

HBC33

0.1u/4/X7R/16V/K

HBC34

0.1u/4/X7R/16V/K

4

HBC35

0.1u/4/X7R/16V/K

HBC36

0.1u/4/X7R/16V/K

HBC37

0.1u/4/X7R/16V/K

HBC38

0.1u/4/X7R/16V/K

HBC39

0.1u/4/X7R/16V/K

3

HBC40

0.1u/4/X7R/16V/K

HBC41

0.1u/4/X7R/16V/K

Title

Size Document Number Rev

2

Date: Sheet of

Gigabyte Technology

C

D720210

GA-X99-UD5 WIFI

1

51 64Tuesday, August 26, 2014

1.0

5

4

3

2

1

3VDUAL_USB_2

5VDUAL

HBC56

D D

HBC57

1u/4/X5R/6.3V/K

C C

3VDUAL_USB3_B

HBR54

3VDUAL_USB3_B

10u/6/X5R/6.3V/M

HBR53

8.2K/4/X

VCC2_2_B

10u/6/X5R/6.3V/M

8.2K/4

EN_P_B

HBC50

HBC54

5VDUAL

HBR42

2.2/4

B B

HBBC1
1u/4/X5R/6.3V/K

5VDUAL 3VDUAL_USB3_B

HBR47

2.2/4

HBBC2
1u/4/X5R/6.3V/K

A A

EN_VCC22_B

2

L1085DG/TO252/5A

EN_VCC22_B

HBC51
1u/4/X5R/6.3V/K

RESETB_B

HBR45

0/4/SHT/M/X

HBC55
1u/4/X5R/6.3V/K

0.1u/4/X7R/16V/K

3

HBR51

1

HBQ3

SPEC: 1.05V +/- 5%

HBU3

1

POK

2

EN

3

VIN

4 5

CNTL REFIN

100/4/1

HBR52
169/4/1

3VDUAL_USB3_B

HBC46

0.1u/4/X7R/16V/K

GND

FB

VOUT

PGND

9

RT9018B-18GSP/SO8/3A

RESETB_B (51)

Reserved

HBU4

1

POK

2
3
4 5

GND
EN
VIN

VOUT

CNTL REFIN

PGND

9

RT9018B-18GSP/SO8/3A

FB

HBC59

0.1u/4/X7R/16V/K

HBR36 8.2K/4

8
7
6

8
7
6

3VDUAL_USB3_B

HBC58

0.1u/4/X7R/16V/K

VCC2_2_B

USB_1V05_B

1

+

HBEC2
100u/FP/D/6.3V/65/C/13m

HBR41

HBC47

169K/4/1

0.1u/4/X7R/16V/K/X
HBR43

100K/4/1

SPEC: 1.05V +/- 5%

HBR46
100K/4/1

0.1u/4/X7R/16V/K/X

HBR48
316K/4/1

HBC52

EN_P_B

HBC45

0.1u/4/X7R/16V/K

HBC53
1u/4/X5R/6.3V/K

HBC49
1u/4/X5R/6.3V/K

HBC60

10u/6/X5R/6.3V/M

# External SPI ROM ; SPI ROM
attached mode

# Battery Charging

# Number of Ports ; 4Ports
mode

PPON3B / PPON4B : H / H ( 4 port )
PPON3B / PPON4B : L / L ( 2 port )

#5 VBUS Power Control
; Individual mode

# PPON1B Pin Function ;
Port1 PPONB mode

HBC61

10u/6/X5R/6.3V/M

3VDUAL_USB3_B

S

PICSB_B

SPISI_B

SPISCK_B

SPISO_B

LED1B_B(51)

PPON4B_B(51)

PPON3B_B(51)

PPON2B_B(51)

PPON1B_B(51)

LED1B_B

PPON4B_B

PPON3B_B

PPON2B_B

PPON1B_B

HBR25 10K/4/1
HBR26 1K/4/1/X

HBR28 10K/4/1
HBR29 1K/4/1/X

HBR55 10K/4/1/X
HBR30 1K/4/1

HBR56 10K/4/1/X
HBR31 1K/4/1

HBR32 10K/4/1
HBR49 10K/4/1/X

HBR33 10K/4/1
HBR57 1K/4/1/X

HBR34 10K/4/1
HBR58 1K/4/1/X

HBR35 10K/4/1/X
HBR40 10K/4/1

HBR38 10K/4/1
HBR39 10K/4/1/X

3VDUAL_USB3_B

3VDUAL_USB3_B

3VDUAL_USB3_B

3VDUAL_USB3_B

3VDUAL_USB3_B

3VDUAL_USB3_B

3VDUAL_USB3_B

SPICSB_B

SPICSB_B(51)

SPISO_B

SPISO_B(51)

3VDUAL_USB3_B

HBR27
10K/4/1

HBU2

1

CS#

2 7

SO HOLD#

3

WP#

4

GND

4M/SPI/SO8/200mil/S/[10HP4-112540-30R]

8

VCC
SCK

SPISCK_B

6
5

SI

SPISI_B

HBC42

0.1u/4/X7R/16V/K

SPISCK_B (51)
SPISI_B (51)

Title

Size Document Number Rev

5

4

3

2

Date: Sheet of

Gigabyte Technology

Custom

D720210

GA-X99-UD5 WIFI

1

52 64Tuesday, August 26, 2014

1.0

5

AZALIA CODEC

EAPD-

D D

CR38 MASK/0/6/SHT/X

VCC3

SPDIFO2_HDMI(54)

C_ACZ_SDOUT(16)
C_ACZ_BITCLK(16)

C C

C_ACZ_SDIN2(16)

C_ACZ_SYNC(16)

C_-ACZ_RST(16)

Thermal pad is DGND

CBC24

10u/6/X5R/6.3V/M

CBC41 10u/6/X5R/6.3V/M

CR54 MASK/0/4/SHT/X
CBC31 10p/4/NPO/50V/J/X

CR55 22/4

VCC3

CBC32 0.1u/4/X7R/16V/K

CBC46

0.1u/4/X7R/16V/K

SPDIF(56)

1

DVDD

2

GPIO0/SPO2

3

REGREF

4

GPIO2/I2S-SDO

5

SDATA-OUT

6

BIT-CLK

7

I2S-MCLK

8

SDATA-IN

9

DVDD-IO

10

SYNC

11

RESET#

12

I2S-SCLK

49

GND

Digital Area

SMOATR1 MASK/0/6/X

0/6/X For AGND/GND
moat under Codec
Body

B B

MASK/AZC099-04S.R7G/SOT23-6L/[10DEF-550099-20R_10TA1-0I8902-10R]/X

MIC2_R

MIC2_L

CESD1

1
2
3 4

LINE2_L

6
5

5VDUAL

LINE2_R

Analog Area

CR36

20K/4/1

FRONT_JD(56)

LINE1_JD(56)

MIC1_JD(56)

SURR_JD(56)
CEN_JD(56)

JD resistors close CODEC

FAUDIO_JD(54)

1n/4/X7R/50V/K

CR18 10K/4/1
CR39 20K/4/1

CR16 39.2K/4/1

CR48 10K/4/1
CR40 39.2K/4/1

CR28 47/4/1

CBC11

BAT54C/SOT23/200mA

EAPD: Default L

A A

H : ON
L : OFF

EAPD-

Close to ALC1150

5

4

AVDD

CR49
0/4/X

LINE2_VREFO

44

45

46

47

48

SPDIF-OUT

LINE2-VREFO

PIN46-VREFO

EAPD/I2S-LRCLK

(54)

CBC35 0.1u/4/X7R/16V/K

CBC12 10u/6/X5R/6.3V/M

1

+

CEC11

100u/D/6.3V/65

40

41

42

43

VRP

AVSS2

FRONT-R-

LDO-OUT2

FRONT-R+

39

FRONT-L+

Thermal pad is DGND

JDREF

SENSE A

SENSE B

SENSE C

MIC2-VREFO

MIC1-L

MIC1-R

LINE1-L

LINE1-R

MIC1-VREFO-L

1314151617181920212223

SENSE-B

SENSE-A

SENSE-C

LINE1_R
LINE1_L
MIC1_RR
MIC1_LL

5VDUAL +12V

CD2

3

D

G S

2

1

CR9

8.2K/4

CQ6

SOT23

CBC99

0.01u/6/X7R/50V/K

VCC3

CR8

8.2K/4/X

2N7002/SOT23/25pF/5

4

FRONT-R­F

RONT-R+

FRONT-L+
FRONT-L-

37

38

FRONT-L-

SIDESURR-R

SIDESURR-L

MIC1-VREFO-R

24

CBC1 22u/8/X5R/6.3V/M
CBC2 22u/8/X5R/6.3V/M
CBC7 10u/6/X5R/6.3V/M
CBC9 10u/6/X5R/6.3V/M

+12V

3

D

G S

2

1

CU1
ALC1150-CG/QFN48

LINE2-R

36

LINE2-L

35
34
33

LFE

32

CEN

31

SURR-R

30

SURR-L

29

MIC2-R

28

MIC2-L

27

VREF

26

AVSS1

25

LDO-OUT

LDO-IN

CR17 8.2K/4
CR30 8.2K/4

CR10
1M/4

CQ7
2N7002/SOT23/25pF/5

SOT23

0.01u/6/X7R/50V/K

FRONT-R- (54)
FRONT-R+ (54)

FRONT-L+ (54)
FRONT-L- (54)
LINE2_R (54)

AVDD

CBC3

10u/6/X5R/6.3V/M

MIC1_VREFO_R (54,56)
MIC1_VREFO_L (54,56)

LINE_IN_R (54)
LINE_IN_L (54)
MIC1_R (54)
MIC1_L (54)
MIC2_VREFO (54)

MUTE- (54)

CBC14
1u/6/X7R/16V/K/X

3

3

CBC5
22u/8/X5R/6.3V/M

CBC36

0.1u/4/X7R/16V/K

LINE2_L (54)

LFE_R (54)
CEN_L (54)
SURR_R (54)
SURR_L (54)
MIC2_R (54)
MIC2_L (54)

CFB1 60/4/3A/S

CBC4
22u/8/X5R/6.3V/M

1

ALC1150

1

AUDIO_HS

1

󵄚󱮵󱡟󳺲

GND

AUDIO_HS/[11NH1-00Z97S-03R]

󱅐󱆻

+

2

5VDUAL

CD1
AZ2225-01L/SOD323

2

2

Title

HD AUDIO ALC887B-VD2/VT1708S/VT2021

Size Document Number Rev
Custom

2

Date: Sheet of

Gigabyte Technology

GA-X99-UD5 WIFI

1

53 64Tuesday, August 26, 2014

1

1.0

5

CR23 2.2/6

AZALIA JACK

CR44 MASK/0/6/SHT/X

4

Audio jack -> USB(

Under Audio jack(

󱍍󱍍󱍍󱍍󲆜󲆜󲆜󲆜

2 VIA hole)

󱍍󱍍󱍍󱍍󲆜󲆜󲆜󲆜

2 VIA hole)

3

LINE-OUT

AJ_B5_R_R

AJ_B2_L_L

2

CR21 10/4

CR22 10/4

CBC23

180p/4/NPO/50V/J

1

AJ_B5_R

AJ_B2_L

CBC26
180p/4/NPO/50V/J

AJ_B5_R (56)

AJ_B2_L (56)

LINE-IN

MOATR1 MASK/0/4/SHT/X

D D

SPDIF_OUT

1

SPDIFO2_HDMI(53)

CR52 MASK/0/4/SHT/X

CBC37

100p/4/NPO/50V/J

SPDIF_O

PH/1*2/BK/2.54/VA/D

MOATC1 0.1u/4/X7R/16V/K

MOATR2 MASK/0/4/SHT/X
MOATC2 0.1u/4/X7R/16V/K

MOATR3 MASK/0/4/SHT/X
MOATC3 0.1u/4/X7R/16V/K

MOATR4 MASK/0/4/SHT/X
MOATC4 0.1u/4/X7R/16V/K

Near F_AUDIO(

Near Codec (

Near R_AUDIO(

Near AMP (

󱍍󱍍󱍍󱍍󲆜󲆜󲆜󲆜

󱍍󱍍󱍍󱍍󲆜󲆜󲆜󲆜

2 VIA hole)

󱍍󱍍󱍍󱍍󲆜󲆜󲆜󲆜

2 VIA hole)

󱍍󱍍󱍍󱍍󲆜󲆜󲆜󲆜

2 VIA hole)

2 VIA hole)

MIC-IN

SURROUND

For HDMI SPDIF

C C

FRONT-R-(53)

FRONT-R+(53)

B B

FRONT-L-(53)

FRONT-L+(53)

A A

Differential to Single-End AMPLIFIED

CR79 390/4/1
CBC82 1n/4/X7R/50V/K

CEC14 100u/D/6.3V/65

FRONT-R-

FRONT-L- FRONT-L-_C_L

FRONT-L+

FRONT-R-_C_R

1

+

CBC76
22p/4/NPO/50V/J

FRONT-R+_C_R

1

+

CEC15 100u/D/6.3V/65

CEC16 100u/D/6.3V/65

1

+

CBC79
22p/4/NPO/50V/J

FRONT-L+_C_L

1

+

CEC17 100u/D/6.3V/65

5

CR73 374/4/1

CR74 374/4/1

CR90 374/4/1

CR91 374/4/1

FRONT-R-_R

FRONT-R+_RFRONT-R+

FRONT-L-_L

FRONT-L+_L

CR76 100/4/1

CBC77

0.01u/4/X7R/25V/K

CR78 100/4/1

CR128
390/4/1

CR93 100/4/1

CBC80

0.01u/4/X7R/25V/K

CR95 100/4/1

CR129
390/4/1

4

OP_INA-_R
OP_INA+_R

CBC78
1n/4/X7R/50V/K

CR96 390/4/1
CBC83 1n/4/X7R/50V/K

OP_INB-_L
OP_INB+_L

CBC81
1n/4/X7R/50V/K

-12V

CBC49

0.1u/4/X7R/16V/K

-

2

1

+

3

CU2A

8 4

NE5532PSR/SOP-PS/[10TA1-705532-11R]

+12V

CBC50

0.1u/4/X7R/16V/K

-12V

CBC51
10u/8/X5R/16V/K

-

6

7

+

5

CU2B
NE5532PSR/SOP-PS/[10TA1-705532-11R]

8 4

+12V

CBC52
10u/8/X5R/16V/K

AMP_R

AMP_L

CEN/LFE

AMP_L (55)

3

AZALIA FRONT PANEL

MIC2_L(53)

MIC2_R(53)

FAUDIO_JD(53)

LINE2_R(53)
LINE2_L(53)

LINE_IN_R(53)

LINE_IN_L(53)

MIC1_R(53)

MIC1_L(53)

SURR_R(53)

SURR_L(53)

LFE_R(53)

CEN_L(53)

MUTE-(53)

2N7002/SOT23/25pF/5/[10IF1-2A7002-0CR]

2N7002/SOT23/25pF/5/[10IF1-2A7002-0CR]

BAT54A/SOT23/200mA

LINE2_VREFO(53)

BAT54A/SOT23/200mA

MIC2_VREFO(53)

CBC20 10u/6/X5R/6.3V/M
CBC15 10u/6/X5R/6.3V/M

CEC12 100u/D/6.3V/65

1

+

1

+

CEC13 100u/D/6.3V/65

CR5 62/4

CR13 62/4

CR29 62/4

CR32 62/4

MIC1_VREFO_L(53,56)
MIC1_VREFO_R(53,56)

CEC5 100u/D/6.3V/65

SURR_C_R

1

+

CEC7 100u/D/6.3V/65

SURR_C_L

1

+

CEC9 100u/D/6.3V/65

1

+

CEC10 100u/D/6.3V/65

1

+

AMP_R

AMP_L

2
1

2
1

CQ2

CQ1

EMI

CR2 62/4
CR11 62/4

L2_R

CR33 62/4
CR34 62/4

L2_R
L2_L

2

LFE_C_R

CEN_C_L

CQ8

G S

D

SOT23

CQ10

G S

D

SOT23

SOT23

CR25 8.2K/4
CR15 8.2K/4

SOT23

CR12 8.2K/4
CR3 8.2K/4

CBC18

180p/4/NPO/50V/J

CBC19

180p/4/NPO/50V/J

CR20 22K/4

CR46 62/4

CR19 62/4

CR50 62/4

CR41 62/4

3

3

M2_L
M2_R
L2-R

L2-LL2_L

CBC10

180p/4/NPO/50V/J

Title

Size Document Number Rev
Custom

Date: Sheet of

CR45 22K/4

CBC29

180p/4/NPO/50V/J

CR42 22K/4
CR51 22K/4

CBC25

180p/4/NPO/50V/J

SOT23

CQ9

1

3

D

2

G S

2N7002/SOT23/25pF/5/[10IF1-2A7002-0CR]

SOT23

CQ11

1

3

D

2

G S

2N7002/SOT23/25pF/5/[10IF1-2A7002-0CR]

CR27 22K/4
CR26 22K/4

CBC16

180p/4/NPO/50V/J

Gigabyte Technology

AJ_A5_R

AJ_A5_R (56)

AJ_A2_L

AJ_C5_R

AJ_C2_L

BJ_C5_R

BJ_C2_L

BJ_B5_R

BJ_B2_L

AJ_A2_L (56)

AJ_C5_R (53,56)

AJ_C2_L (53,56)

BJ_C5_R (56)

BJ_C2_L (56)

BJ_B5_R (56)

BJ_B2_L (56)

CBC27
180p/4/NPO/50V/J

CBC22
180p/4/NPO/50V/J

CBC28
180p/4/NPO/50V/J

CBC34
180p/4/NPO/50V/J

AJ_B5_R_R

AJ_B2_L_L

Digital Area

F_AUDIO

1

2

3

4

CR35 20K/4/1

5

6

7

CR31 39.2K/4/1

9

10

BH/2*5K8/BK/2.54/VA/AUDIO/PRT/TUR180

CBC6

CBC17

180p/4/NPO/50V/J

180p/4/NPO/50V/J

AUDIO JACK

GA-X99-UD5 WIFI

1

VCC3

CR56

8.2K/4/X

54 64Tuesday, August 26, 2014

1.0

5

D D

C C

4

LED/W/6/S/[10DL3-32000W -11R]

LED/W/6/S/[10DL3-32000W -11R]

3

VCC V CC VCC VCC VCC

CR188
330/6

C_LED1

LED/W/6/S/[10DL3-32000W -11R]

CR99
330/6

C_LED5

CR133
330/6

C_LED12

LED/W/6/S/[10DL3-32000W -11R]

CR189
330/6

C_LED2

LED/W/6/S/[10DL3-32000W -11R]

C_LED13

LED/W/6/S/[10DL3-32000W -11R]

C_LED3

LED/W/6/S/[10DL3-32000W -11R]

CR100
330/6

C_LED6

LED/W/6/S/[10DL3-32000W -11R]

CR134
330/6

C_LED14

LED/W/6/S/[10DL3-32000W -11R]

CR97
330/6

C_LED4

LED/W/6/S/[10DL3-32000W -11R]

CR101
330/6

C_LED7

LED/W/6/S/[10DL3-32000W -11R]

CR135
330/6

C_LED15

LED/W/6/S/[10DL3-32000W -11R]

CR98
330/6

C_LED9

LED/W/6/S/[10DL3-32000W -11R]

CR102
330/6

C_LED8

LED/W/6/S/[10DL3-32000W -11R]

VCCVCC VCC VCC

CR136
330/6

C_LED

2

CR104
330/6

C_LED

VCCVCC VCCV CC VCC

CR105
330/6

C_LED10

C_LED

1

CR178 20K/4/1

+12V

CU11A

84

LM358DR/SO8

3

AMP_L(54)

+

1

2

HPOUT L

B B

-

-12V

󰵓󰵓󰵓󰵓󵖙󵖙󵖙󵖙󲅳󲅳󲅳󲅳󲪫󲪫󲪫󲪫󵞄󵞄󵞄󵞄󳋐󳋐󳋐󳋐

fH=1/[2pi*(R*C)]=194Hz

CR177 8.2K/4

0.1u/4/X7R/16V/K

R

CBC98

+12V

CU11B

84

LM358DR/SO8

5

+

7

6

-

C

-12V

CR180 100K/4/1

Rf

CR181

Rn

1K/4/1

󵙄󵙄󵙄󵙄󱠜󱠜󱠜󱠜󱟧󱟧󱟧󱟧󳘓󳘓󳘓󳘓

Av=1+(Rf/Rn)=100

3.5V

󰽖󰽖󰽖󰽖

CD7
BAT54C/SOT23/200mA

VCC

CR179

8.2K/4

5
6

ITE8620 GP83
(

ITE8620 GP91

A A

L E D O N

LED OFF

LED BREATH

LED TEMPO

IO_GP83 IO_GP82

5

H
L
OD
H

IO_GP91

L
L

BREATH

L

L
L
L
OD

4

3

84

+

7

-

CU10B
KA393D/SO8

ITE8620 GP82

G_PLED1(28,61)

H

󱌸󱌸󱌸󱌸󰸮󰸮󰸮󰸮󱏕󱏕󱏕󱏕

MPD-(28,39)

L

VCC+12V

3

D

CQ28

CR182

2N7002/SOT23/25pF/5

8.2K/4

G S

SOT23

2

1

G_PLED2(28)

L OFF

VCC

CR103

8.2K/4

MPD-

󰵖󰵖󰵖󰵖󱍕󱍕󱍕󱍕󲪮󲪮󲪮󲪮

VCC

CR107

8.2K/4/X

Title

Size Docu ment Number Rev

Date: Sheet of

2

G_PLED1

Custom

)

G S

G S

3

D

2

1

3

D

CQ31

SOT23

2

1

2N7002/SOT23/25pF/5

CQ27
2N7002/SOT23/25pF/5

SOT23

Creative Sound3Di

GA-X99-UD5 WIFI

3

D

CQ18

G S

2

1

2N7002/SOT23/25pF/5

3

D

G S

SOT23

2

2N7002/SOT23/25pF/5

1

C_LED

CQ19

SOT23

1

1.0

55 64Tuesday, August 26, 2014

5

LCBC1 0.1u/4/X7R/16V/K

LC_AVDD_CEN

LC_MDI0+

LC_MDI0+(58)

LC_MDI0-

LC_MDI0-(58)

LC_MDI1+

LC_MDI1+(58)

LC_MDI1-

LC_MDI1-(58)

LC_MDI2+

LC_MDI2+(58)

LC_MDI2-

LC_MDI2-(58)

LC_MDI3+
LC_MDI3-

LC_MDI3-(58)

FUSEVCC_R1

D D

U3TXDN3_B(51)
U3TXDP3_B(51)

LABC26

0.1u/4/X7R/16V/K

U3TXDN3_B
U3TXDP3_B

LCBC3 MASK/0/4/SHT/X

U2DM3_B(51)
U2DP3_B(51)

U3RXDN3_B

U3RXDN3_B(51)

U3RXDP3_B

U3RXDP3_B(51)

UAC1 0.1u/4/X7R/16V/K
UAC2 0.1u/4/X7R/16V/K

U2DM3_B
U2DP3_B

SSTXDN3BC
SSTXDP3BC

USB30_LAN1

L1

L1

L2

L2

L3

L3

L4

L4

L5

L5

L6

L6

L7

L7

L8

L8

L9

L9

L10

L10

U1

USB3.0

VBUS

U2

D-

U3

D+

U4

GND

U5

SSRX-

U6

SSRX+

U7

USB3.0

GND

U8

SSTX-

U9

SSTX+

USB3+RJ45/[11NR6-702009-X1R]

11NR6-702009-X1R

5VDUAL

UABC1

22u/8/X5R/6.3V/M

UAF1
SPR-P260T/6V/8/S

FUSEVCC_R1

VBUS

GND

SSRX-

SSRX+

GND

SSTX-

SSTX+

FUSEVCC_R1

FUSEVCC_R1

4

LC_LED_ACT_TXRX_1

D1

D1

LC_LED_D2

D2

D2

LC_LED_LINK100_1

D3

D3

LC_LED_LINK1000_1

D4

D4

P1

DT

P2

DT

U10

U2DM4_B

U11

D-

U2DP4_B

U12

D+

U13
U14
U15
U16
U17
U18

UAR1 8.2K/4

UAR3 8.2K/4

U3RXDN4_B
U3RXDP4_B

SSTXDN4BC
SSTXDP4BC

UAR2
15K/4/1

UAR4
15K/4/1

LCR29 150/4/1
LCR30 MASK/0/ 4/SHT/X

LCR31 150/4/1
LCR32 150/4/1

U2DM4_B (51)
U2DP4_B (51)

U3RXDN4_B (51)
U3RXDP4_B (51)

UAC3 0.1u/4/X7R/16V/K
UAC4 0.1u/4/X7R/16V/K

OCI3B_B (51)

OCI4B_B (51)

3VDUAL_LAN1

LC_LED_ACT_TXRX (58)

LC_3VDUAL_LED

LC_LED_LINK100 (58)
LC_LED_LINK1000 (58)LC_MDI3+(58)

FUSEVCC_R1

LABC27

0.1u/4/X7R/16V/K/X

U3TXDN4_B

U3TXDN4_B (51)

U3TXDP4_B

U3TXDP4_B (51)

3

LCFB3
MASK/0/4/SHT/X

LCBC2

0.1u/4/X7R/16V/K/X

2

U3RXDP4_B
U3RXDN4_B

10

UAE2

NC

D1+

1

U3RXDN4_B
U3RXDP4_B

AZC099-04S.R7G/SOT23-6L/[10DEF-550099-20R_10TA1-0I8902-10R]

U2DP4_B

U2DP3_B

9

NC

D1-

2

1
2
3 4

8

GND

11

GND

354

UAESD1

6

7

NC

NC

D2-

D2+

U2DM4_B

6
5

FUSEVCC_R1

U2DM3_B

SSTXDN4BC
SSTXDP4BC

AZ1045-04F/MSOP10

SSTXDP4BC
SSTXDN4BC

1

SSTXDP3BC
SSTXDN3BC

10

UAE1

NC

D1+

1

SSTXDN3BC U3RXDP3_B
SSTXDP3BC

8

9

NC

GND

11

D1-

GND

2

354

7

NC

D2+

U3RXDN3_B
U3RXDP3_B

6

NC

D2-

AZ1045-04F/MSOP10

U3RXDN3_B

EMI SHORT PAD

PS:

󴣟󴣟󴣟󴣟

EMI

󵙉󵙉󵙉󵙉󲮋󲮋󲮋󲮋

LAR24 MASK/0/4/SHT/X

C C

LBC5 1u/4/X5R/6.3V/K

LB_MDI0+

LB_MDI0+(59)

LB_MDI0-

LB_MDI0-(59)

LB_MDI1+

LB_MDI1+(59)

LB_MDI1-

LB_MDI1-(59)

LB_MDI2+

LB_MDI2+(59)

LB_MDI2-

LB_MDI2-(59)

LB_MDI3+

LB_MDI3+(59)

LB_MDI3-

LB_MDI3-(59)

LBC19 0.1u/4/X7R/16V/K

FUSEVCC_R2

LBBC1

0.1u/4/X7R/16V/K

U3TXDN1_B

U3TXDN1_B(51)

U3TXDP1_B

U3TXDP1_B(51)

B B

emi check

U2DM1_B(51)
U2DP1_B(51)

U3RXDN1_B

U3RXDN1_B(51)

U3RXDP1_B U3RXDP2_B

U3RXDP1_B(51)

UBC1 0.1u/4/X7R/16V/K
UBC2 0.1u/4/X7R/16V/K

5VDUAL

SSTXDN1BC
SSTXDP1BC

UBF1

1

SPR-P260T/6V/8/S

+

UAEC1
100u/FP/D/6.3V/65/C/13m

USB30_LAN2

L1

L1

L2

L2

L3

L3

L4

L4

L5

L5

L6

L6

L7

L7

L8

L8

L9

L9

L10

L10

U1

VBUS

U2DM1_B

U2

D-

U2DP1_B

U3

D+

U4

GND

U5

SSRX-

U6

SSRX+

U7

GND

U8

SSTX-

U9

SSTX+

USB3+RJ45/[11NR6-702009-X1R]

FUSEVCC_R2

USB3.0

USB3.0

D1
D2

D3
D4
DT

DT

VBUS

D-

D+

GND

SSRX-

SSRX+

GND

SSTX-

SSTX+

FUSEVCC_R2

FUSEVCC_R2

LB_LED_ACT_TXRX

D1

LB_D2

D2

LB_LED_LINK100

D3

LB_LED_LINK1000

D4
P1

P2
U10

U2DM2_B

U11

U2DP2_B

U12
U13
U14
U15
U16

SSTXDN2BC

U17

SSTXDP2BC

U18

UBR1 8.2K/4

UBR3 8.2K/4

LBR8 MASK/0/4/SHT/X
LBR10 150/4/1

LBR9 150/4/ 1
LBR3 MASK/0/4/SHT/X

U2DM2_B (51)
U2DP2_B (51)

U3RXDN2_B

U3RXDN2_B (51)
U3RXDP2_B (51)

UBC3 0.1u/4/X7R/16V/K
UBC4 0.1u/4/X7R/16V/K

UBR2
15K/4/1

UBR4
15K/4/1

LBBC2

0.1u/4/X7R/16V/K/X

U3TXDN2_B
U3TXDP2_B

OCI1B_B (51)

OCI2B_B (51)

LB_LED0

LB_LED2
LB_LED1

FUSEVCC_R2

3VDUAL_LAN2

LB_LED0 (59)

LB_LED2 (59)
LB_LED1 (59)

U3TXDN2_B (51)
U3TXDP2_B (51)

LBFB2
MASK/0/4/SHT/X

LBBC3

0.1u/4/X7R/16V/K/X

U3RXDP2_B
U3RXDN2_B

U3RXDP2_B

9

10

UBE2

NC

NC

D1+

D1-

1

2

U2DP2_B U2DM2_B

1
2

U2DP1_B U2DM1_B

3 4

AZC099-04S/SOT23-6L/[10DEF-550099-20R_10TA1-0I8902-10R]

UBESD1

8

GND

11

GND

354

7

NC

D2+

6
5

SSTXDN2BC
SSTXDP2BC U3RXDN1_B

6

NC

D2-

AZ1045-04F/MSOP10

SSTXDP2BCU3RXDN2_B
SSTXDN2BC

FUSEVCC_R2

U3RXDP1_BLB_D2_1

U3RXDN1_B
U3RXDP1_B

UBE1

10

NC

D1+

1

8

9

NC

GND

11

D1-

GND

2

354

EMI SHORT PAD

PS:

󴣟󴣟󴣟󴣟

EMI

LBR1 MASK/0/4/SHT/X

󵙉󵙉󵙉󵙉󲮋󲮋󲮋󲮋

7

NC

D2+

SSTXDP1BC
SSTXDN1BC

6

NC

D2-

AZ1045-04F/MSOP10

SSTXDN1BC
SSTXDP1BC

Close to connector

AUDIOB

A3

A3

LINE1_JD

LINE1_JD(53)
AJ_A5_R(54)

AJ_A2_L(54)

FRONT_JD(53)

AJ_B5_R(54)

A A

AJ_B2_L(54)

MIC1_JD(53)

AJ_C5_R(53,54)
AJ_C2_L(53,54)

A2

A2

AJ_A5_R BJ_B5_R

A4

A4

AJ_A2_L

A1

A1

B3

B3

FRONT_JD

B2

B2

AJ_B5_R

B4

B4

AJ_B2_L BJ_C2_L

B1

B1

CEN/LFE

C3

C3

MIC1_JD

C2

C2

AJ_C5_R

C4

C4

AJ_C2_L

C1

C1

C0

C0

2X3RP/25P/OR,BK,BU,GR,RE/RA/[11NR6-403025-A2R]

AZALIA JACK

BLUE Orange

LINE-IN

GND

REAR

GREEN

LINE-OUT

GND

PINK

MIC-IN

GND

SIDE

BJ_B5_R(54)
BJ_B2_L(54)

SURR_JD(53)
BJ_C5_R(54)

BJ_C2_L(54)

SPDIF(53)

FUSEVCC_R1

CEN_JD(53)

11NR6-403025-A2R

5

4

AUDIOA

D3

D3

CEN_JD

D2

D2

D4

D4

BJ_B2_L

D1

D1

GND

LINE-IN

E3

E3

SURR_JD

E2

E2

BJ_C5_R

E4

E4

E1

E1

GND

LINE-OUT

F0

AGND

I

SPDIF

V

VCC

G

GND

OPTICAL

G1

G1

G2

G2

G3

G3

G4

G4

2X3RP/25P/OR,BK,BU,GR,RE/RA/[11NR6-403025-A2R]

3

CEN/LFE

Black

SURROUND

SPDIF

Title

Size Document Number Rev
Custom

2

Date: Sheet of

Gigabyte Technology

LAN , AUDIO CONNECT

GA-X99-UD5 WIFI

1

56 64Tuesday, August 26, 2014

1.0

8

FUSEVCC_R5FUSEVCC_R5

KBC1

0.1u/4/X7R/16V/K

N_-USBP13(17)

N_+USBP13(17)

D D

KBDATA
MSDATA
KBCLK
MSCLK

FUSEVCC_R5

KB_MS_USB

U5
U6
U7
U8

1
2
5
6

KB/USB/A/PC99(DUAL)/GF/2/RA/D/[11NR6-804006-11R]

KR1 8.2K/4

U1
U2

1 3 5 7

U3
U4

2 4 6 8

USB

4

3

KB

G1G2G3

G4

11NR6-804006-11R

N_-USBOC_R (17)

KR2
15K/4/1

KB/USB/A/PC99(DUAL)/GF/2/RA/D

C C

KBDATA

MSDATA

B B

KESD1

1
2
3 4

AZC099-04S/SOT23-6L/[10DEF-550099-20R_10TA1-0I8902-10R]/X

6
5

7

KBC2

0.1u/4/X7R/16V/K KR3 82/6

N_-USBP12 (17)
N_+USBP12 (17)

FUSEVCC_R5

KBC3

0.1u/4/X7R/16V/K

KBCLK

FUSEVCC_R5

MSCLK

KCLK(28)

MCLK(28)

KDAT(28)

MDAT(28)

FUSEVCC_R5

5VDUAL

N_-USBP13

N_+USBP12

6

FOR

KCLK
MCLK
KDAT
MDAT

KRN1

78
56
34
12

8.2K/8P4R/6

KF1
SPR-P200T/6V/8/S

1

+

KEC1
100u/FP/D/6.3V/65/C/13m

KESD2

1
2
3 4

AZC099-04S/SOT23-6L/[10DEF-550099-20R_10TA1-0I8902-10R]

󵷆󵷆󵷆󵷆󱉟󱉟󱉟󱉟󳜶󳜶󳜶󳜶󴴸󴴸󴴸󴴸

KR4 82/6
KR5 82/6
KR6 82/6

MDAT
KDAT
MCLK
KCLK

N_+USBP13

6
5

FUSEVCC_R5

N_-USBP12

KBCLK
MSCLK
KBDATA

MSDATA

180p/8P4C/6/NPO/50V/K

KCN1

For EMI

KR7 MASK/0/4/SHT/X

FUSEVCC_R5

5

4

3

2

1

4GHz

HS

4G_LED_C

Fast Boot

01A

FB_LED_C

2 1

4 3

6 5

8 7

N_GPIO18(16)

01A

N_-RTCRST_C(44)

N_GPIO18

N_-RTCRST_C

SWITCH FAST[11NR8-E00301-21R]

WIFI-BRACKET_Vertical/[12AC2-000001-31R]::Location ANTENNA_BRACKET

4G

7
2

12
1
3

F-BOOT

8
5

10

9

ANTENNA_BRACKET

11
4
6

CLR

G1
G2
G3
G4

1

1

2

2

SMA

ANTENNA_BRACKET

󱞚󴃩󱟓󳆐/[11KWP-000001-01R]

Orange

Green

N_GPIO1_C

4G_LED_CN_GPIO1_C

FB_LED_C

HSR4 330/4

HSR1 330/4

CLR

N_-RTCRST_C

SMA

ANT2

SMA/[11NH6-010001-31R]

󱭣󱭣󱭣󱭣󳺃󳺃󳺃󳺃󲓢󲓢󲓢󲓢󴖨󴖨󴖨󴖨󶁜󶁜󶁜󶁜󱻎󱻎󱻎󱻎󴣘󴣘󴣘󴣘󲞅󲞅󲞅󲞅󳠃󳠃󳠃󳠃󴧖󴧖󴧖󴧖

HSR3 33/4

SOT23

1

3

2

Q163
PMBT2907A/SOT23/-600mA/50

SOT23

1

3

Q164
PMBT2907A/SOT23/-600mA/50

HSR6 33/4

SMA

SMA/[11NH6-010001-31R]

HSR2 8.2K/4

2

0.01u/4/X7R/25V/K

ANT1

VCC3

VCC3

HSR5 8.2K/4

HSBC2

N_GPIO1 (15)

HSBC1

0.01u/4/X7R/25V/K

N_GPIO18 (16)

N_-RTCRST (16,18,44)

N_GPIO17 (15)

A A

Gigabyte Technology

Title

USB DAC-UP , PS2 , HS ,WIFI

Size Document Number Rev
Custom

GA-X99-UD5 WIFI

8

7

6

5

4

3

Date: Sheet of

2

57 64Tuesday, August 26, 2014

1

1.0

5

4

3

2

1

3VDUAL_LAN1

D D

LCC2
100p/4/NPO/50V/J/X

PCIE_OB1_RST

LC_ML_OP(17)
LC_ML_ON(17)

LC_SRCCLK_LAN(17)
LC_-SRCCLK_LAN(17)

PCIE_OB1_RST(15,59)

C C

LC_ML_IP(17)

LC_ML_IN(17)

B B

A A

N_-PCIE_WAKE(16,20,21,23,24,25,47)

N_SMBCLK(16,20,21,23,24,25,26,27,30,34,35,37,42,47)

N_SMBDATA(16,20,21,23,24,25,26,27,30,34,35,37,42,47)

3VDUAL_LAN1

LCC12 0.1u/4/X7R/16V/K
LCC14 0.1u/4/X7R/16V/K

3VDUAL_LAN1

5

3VDUAL_LAN1

LCR13 8.2K/4

0.1u/4/X7R/16V/K

LC_ML_OP_C

LCC3

LC_ML_ON_C

LCC5 0.1u/4/X7R/16V/K

LCR17 8.2K/4

LC_ML_IP_C
LC_ML_IN_C

LCR18 8.2K/4
LCR19 8.2K/4
LCR20 8.2K/4

LCR21 8.2K/4
LCR22 8.2K/4

LCR23 8.2K/4
LCR24 8.2K/4

WGI210AT/QFN64/S/[10HP2-400210-10R]

3VDUAL_LAN1

LC_XTALO

LC_XTALI

LCR1 3.3K/4/1

LCR15 100K/4/1

LCR14 8.2K/4

LCR16 100K/4/1

LCU1

24

PE_RP

23

PE_RN

26

PE_CLKP

25

PE_CLKN

17

PE_RST_N

16

PE_WAKE_N

34

SMB_CLK

36

SMB_DATA

35

SMB_ALRT_N

21

PE_TP

20

PE_TN

2

NC_SI_CLK_IN

3

NC_SI_CRS_DV

7

NC_SI_TX_EN

43

NC_SI_ARB_IN

44

NC_SI_ARB_OUT

9

NC_SI_TXD0

8

NC_SI_TXD1

6

NC_SI_RXD0

5

NC_SI_RXD1

1 2
3 4
5 6
7 8

LCRN1 8.2K/8P4R/4

LC_LED_LINK100(56)
LC_LED_ACT_TXRX(56)
LC_LED_LINK1000(56)

LCR2 1K/4/1

464519294184828115121413

XTAL1

XTAL2

JTAG_CLK

SUPPORT CIRCUITS

PCIE_NC-SI_SMB

I211-AT_MDI_LED_SDP

SDP0

SDP1/PCIE_DIS

SDP2

SDP3

63616260313033

4

LCR4 3.3K/4/1

LCR3 3.3K/4/1

JTAG_TDI

JTAG_TDO

JTAG_TMS

LED0

LED1

LC_LED_ACT_TXRX

LC_LED_LINK100

LCR6 3.3K/4/1

LCR5 4.99K/4/1

RSET

POWER
SUPPLY &
I210
REGULATOR

LED2

MDI_3_N

49

LC_MDI3+

LC_MDI3-

LC_LED_LINK1000

LCR7 3.3K/4/1

DEV_OFF_N

LAN_PWR_GOOD

MDI_2_N

MDI_3_P

LC_MDI2+

LC_MDI2-

-LC_NVM_CS
LC_NVM_SI
LC_NVM_SO
LC_NVM_SK

LCR34
33K/4/1

LCR9 33/4

LCR8 33/4

LCR10 33/4

LCR11 33/4

NC_22

VDD1P5_56
VDD1P5_47

VDD0P9_42
VDD0P9_32
VDD0P9_11
VDD0P9_59

VDD3P3_27
VDD3P3_10
VDD3P3_64

VDD3P3_41
VDD3P3_51

CTOP
CBOT

E_PAD_GND

22

56
47

42
32
11
59

27
10
64

41
51

39
38

40
37

65

RSVD_22_NG

NVM_SI

NVM_SK

NVM_SO

NVM_CS_N

VDD1P5_OUT
VDD0P9_OUT

MDI_0_P

MDI_0_N

MDI_1_P

MDI_1_N

MDI_2_P

58575554535250

LC_MDI1+

LC_MDI1-

LC_MDI0+

LC_MDI0-

LC_MDI0+ (56)
LC_MDI0- (56)
LC_MDI1+ (56)
LC_MDI1- (56)
LC_MDI2+ (56)
LC_MDI2- (56)
LC_MDI3+ (56)
LC_MDI3- (56)

LCC4 0.1u/4/X7R/16V/K

VDD1P5_LAN

VDD0P9_LAN

3VDUAL_LAN1

LCC13
10u/6/X5R/6.3V/M

VDD0P9_LAN

LCC21
10u/6/X5R/6.3V/M

LCC22

0.047u/4/X7R/16V/K

3

3VDUAL_LAN1

VDD1P5_LAN

LCC20
10u/6/X5R/6.3V/M

LCX1
25M/16p/30ppm/49US/20/D

LCC28
20p/4/NPO/50V/J

LC_XTALI

LC_XTALO

LCR37

8.2K/4

22u/8/X5R/6.3V/M

LCC29
20p/4/NPO/50V/J

-LC_NVM_CS
LC_NVM_SO

-LC_SPI_WP0

LCC6

VDD1P5_LAN

10u/6/X5R/6.3V/M

VDD0P9_LAN

10u/6/X5R/6.3V/M

3VDUAL_LAN1

LCC15

LC_B1

1

CS#

2

SO

3

WP#

4

VSS

8M/SPI/SO8/200mil/S/[10HP4-112580-40R]

LCC7
10u/6/X5R/6.3V/M

LCC23

LCC8

0.1u/4/X7R/16V/K

LCC16

0.1u/4/X7R/16V/K

LCC24

0.1u/4/X7R/16V/K

3VDUAL_LAN1 3VDUAL_USB3_B

SHARE HUB2 <--> USB30_LAN1

2

VDD

HOLD#

SCK

SI

LCC9

0.1u/4/X7R/16V/K

LCC17

0.1u/4/X7R/16V/K

LCC25

0.1u/4/X7R/16V/K

3VDUAL_LAN1

LCC1

8
7
6
5

1u/4/X5R/6.3V/K

LCR38 8.2K/4

LC_NVM_SK
LC_NVM_SI

3VDUAL_LAN1

LCC10

0.1u/4/X7R/16V/K

LCC18

0.1u/4/X7R/16V/K

LCC26

0.1u/4/X7R/16V/K

Title

Size Document Number Rev
Custom

Date: Sheet of

LCC11

0.1u/4/X7R/16V/K

LCC19

0.1u/4/X7R/16V/K

LCC27

0.1u/4/X7R/16V/K

Gigabyte Technology

INTEL LAN 1 (i210)

GA-X99-UD5 WIFI

1

58 64Tuesday, August 26, 2014

1.0

5

4

3

2

1

3VDUAL_LAN2

D D

PCIE_OB1_RST(15,58)

LB_SRCCLK_LAN(17)
LB_-SRCCLK_LAN(17)

N_SML0CLK(16)
N_SML0DAT(16)

C C

LBC14 20p/4/NPO/50V/J

LBC13 20p/4/NPO/50V/J

B B

LBR20 MASK/0/4/SHT/X

N_LAN_DIS-(16)

A A

N_-LAN_WAKE(16)

3VDUAL_LAN2

5

LB_ML_IP(17)
LB_ML_IN(17)

LB_ML_OP(17)
LB_ML_ON(17)

LBR17

8.2K/4/X

LBR14

8.2K/4/X

3VDUAL_LAN2

LBC6 0.1u/4/X7R/16V/K
LBC8 0.1u/4/X7R/16V/K

LBC12 0.1u/4/X7R/16V/K
LBC16 0.1u/4/X7R/16V/K

LB_LED0(56)
LB_LED1(56)
LB_LED2(56)

3VDUAL_LAN2

LBX1
25M/16p/30ppm/49US/20/D

LBR7 1K/4/1

LBR12 3.01K/4/1

PU in PCH

LB_-LAN_DIS

LBR11

8.2K/4

LB_LAN_CLKREQ- LB_MDI0+

LBR15 4.7K/4/X
LBR16 MASK/0/4/SHT/X

LB_-LAN_DIS

LB_LED0
LB_LED1
LB_LED2

LBR6 8.2K/4/X
LBR5 8.2K/4/X

LBR4 8.2K/4/X

LB_LAN_BIAS

LBU1

48

CLK_REQ_N

36

P

E_RST_N

44

PE_CLKP

45

LB_TP
LB_TN

LB_RN

PE_CLKN

38

PETP

39

PETN

41

PERP

42

PERN

28

SMB_CLK

31

SMB_DATA

2 5

LANWAKE_N VDD3_P3_IN

3

LAN_DISABLE_N

26

LED0

27

LED1

25

LED2

32

JTAG_TDI

34

JTAG_TDO

33

JTAG_TMS

35

JTAG_TCK

9

XTAL_OUT

10

XTAL_IN

30

TEST_ENABLE

12

RBIAS

WGI218V/QFN48

PCIE_OB1_RST

PCIESMBUSLEDJTAG

LBC2 100p/4/NPO/50V/J/X

MDI

RSVD_1/VCCP3P3

4

MDI_PLUS_0

MDI_MINUS_0

MDI_PLUS_1

MDI_MINUS_1

MDI_PLUS_2

MDI_MINUS_2

MDI_PLUS_3

MDI_MINUS_3

SVR_EN_N

VDD3P3_OUT

VDD3P3
VDD3P3
VDD3P3

VDD0P9
VDD0P9
VDD0P9

VDD0P9
VDD0P9
VDD0P9

VDD0P9
VDD0P9
VDD0P9

CTRL_0P9

VSS_EPAD

13

LB_MDI0-

14

LB_MDI1+

17

LB_MDI1-

18

LB_MDI2+

20

LB_MDI2-

21

LB_MDI3+LB_RP

23

LB_MDI3-

24

LBR19 MASK/0/4/SHT/X
LBR18 4.7K/4/X

6

LBR13 4.7K/4

1

4
15

19
29

47
46
37

43
11
40

22
16
8

LB_CTRL_1P0

7
49

LB_MDI0+ (56)
LB_MDI0- (56)

LB_MDI1+ (56)
LB_MDI1- (56)

LB_MDI2+ (56)
LB_MDI2- (56)

LB_MDI3+ (56)
LB_MDI3- (56)

3VDUAL_LAN2

3VDUAL_LAN2

LBC10
1u/6/X7R/16V/K

LAN_V_1P0

LBL1 4.7uH/3.3A/29m/S

For 82579
Keep short & wide

LAN_V_1P0

3VDUAL_LAN2

LBC1
22u/8/X5R/6.3V/M

LAN_V_1P0

LBC7

0.1u/4/X7R/16V/K

LBC11

22u/8/X5R/6.3V/M/X

LBC15

0.1u/4/X7R/16V/K

LBC3

0.1u/4/X7R/16V/K

LBC23
10u/6/X5R/6.3V/M

LBC17

0.1u/4/X7R/16V/K

LBC29
22u/8/X5R/6.3V/M

LBC21

0.1u/4/X7R/16V/K

LBC18

0.1u/4/X7R/16V/K

LBC22

0.1u/4/X7R/16V/K

LBC9

0.1u/4/X7R/16V/K

LBC4

0.1u/4/X7R/16V/K

Dual Color LED

D4 D3

3VDUAL_USB3_A3VDUAL_LAN2

SHARE HUB1<--> USB30_LAN2

U2U4

U1

U3

U7

U5

U6U8

L7

L5

L3

L1

D1

L9

L2

D2

L10L8

L4

L6

D4

D3

Green

D4

D3
Orange

Single Color LED

D1

D2

Yellow

GREEN

ORANGEYELLOW

(-,+)

(+,-)

Orange

1Gb
100Mb

Green

10Mb

Off

Gigabyte Technology

Title

Size Document Number Rev
Custom

3

2

Date: Sheet of

INTEL LAN - i218V

GA-X99-UD5 WIFI

Access

1

Link

Blinking
Yellow

1.0

64Tuesday, August 26, 2014 59

5

4

3

2

1

R_USB30 PORT

FUSEVCC_R3

UCBC1

D D

U3TXDN3_A(49)
U3TXDP3_A(49)

FUSEVCC_R4

0.1u/4/X7R/16V/K

U3TXDN1_A(49)
U3TXDP1_A(49)

C C

B B

0.1u/4/X7R/16V/K

U3RXDN3_A(49)

UCC1 0.1u/4/X7R/16V/K
UCC2 0.1u/4/X7R/16V/K

UCC5 0.1u/4/X7R/16V/K
UCC6 0.1u/4/X7R/16V/K

UCF1

SPR-P260T/6V/8/S

FUSEVCC_R3

UCR1 8.2K/4

FUSEVCC_R3

UCR3 8.2K/4

U3RXDP3_A(49)

U3RXDN1_A(49)
U3RXDP1_A(49)

U3TXDN3_A

UCBC3

U3TXDP1_A

5VDUAL FUSEVCC_R3

Remove UCEC1 for space

U2DM3_A(49)
U2DP3_A(49)

U3RXDN3_A
U3RXDP3_A

DB_-USBP(43)
DB_+USBP(43)

U3RXDN1_A
U3RXDP1_A

UCR2
15K/4/1

UCR4
15K/4/1

U2DM3_A
U2DP3_A

SSTXDN3AC
SSTXDP3ACU3TXDP3_A

SSTXDN1ACU3TXDN1_A
SSTXDP1AC

OCI3B_A (49)

OCI4B_A (49)

R_USB30
USB30X4PORT/36P[11NR6-304036-31R]

C1

VBUS

C2

D-

C3

D+

C4

GND

C5

SSRX-

C6

SSRX+

C7

GND

C8

SSTX-

C9

SSTX+

A1

DB_-USBP
DB_+USBP

VBUS

A2

D-

A3

D+

A4

GND

A5

SSRX-

A6

SSRX+

A7

GND

A8

SSTX-

A9

SSTX+

11NR6-304036-31R

USB3.0/2.0

D

C

B

A

AGND

AGND

G2G3G4

G1

D1

VBUS

U2DM4_A

D2

D-

U2DP4_A

D3

D+

D4

GND

D5

SSRX-

D6

SSRX+

D7

GND

SSTXDN4AC

D8

SSTX-

SSTXDP4AC

D9

SSTX+

B1

VBUS

U2DM2_A

B2

D-

U2DP2_A

B3

D+

B4

GND

B5

SSRX-

B6

SSRX+

B7

GND

B8

SSTX-

SSTXDP2AC

B9

SSTX+

AGND

AGND

AGND

AGND

G5

G6

UCF2

5VDUAL FUSEVCC_R4

1

+

UCEC2
100u/FP/D/6.3V/65/C/13m

FUSEVCC_R4

UCR5 8.2K/4

FUSEVCC_R4

UCR7 8.2K/4

U3RXDN4_A
U3RXDP4_A

U3RXDN2_A
U3RXDP2_A

SPR-P260T/6V/8/S

FUSEVCC_R3

0.1u/4/X7R/16V/K

U2DM4_A (49)
U2DP4_A (49)

U3RXDN4_A (49)
U3RXDP4_A (49)

UCC3 0.1u/4/X7R/16V/K
UCC4 0.1u/4/X7R/16V/K

U2DM2_A (49)
U2DP2_A (49)

U3RXDN2_A (49)
U3RXDP2_A (49)

UCC7 0.1u/4/X7R/16V/K
UCC8 0.1u/4/X7R/16V/K

OCI1B_A (49)

UCR6
15K/4/1

OCI2B_A (49)

UCR8
15K/4/1

UCBC2

U3TXDN4_A
U3TXDP4_A

UCBC4

0.1u/4/X7R/16V/K

U3TXDN2_ASSTXDN2AC
U3TXDP2_A

U3TXDN4_A (49)
U3TXDP4_A (49)

FUSEVCC_R4

U3TXDN2_A (49)
U3TXDP2_A (49)

SSTXDP3AC
SSTXDN3AC

8

9

10

UCE2

NC

NC

D1+

SSTXDN3AC
SSTXDP3AC

1

SSTXDP1AC
SSTXDN1AC

10

UCE4

NC

D1+

1

SSTXDN1AC
SSTXDP1AC

U2DP3_A

U2DP4_A

AZC099-04S/SOT23-6L/[10DEF-550099-20R_10TA1-0I8902-10R]

11

D1-

2

8

9

NC

GND

11

GND

D1-

2

354

UCESD1

1
2
3 4

GND

GND

354

Close to connector

6
5

7

NC

D2+

7

NC

D2+

U2DM3_A

FUSEVCC_R3

U2DM4_A

SSTXDN4AC
SSTXDP4AC

6

NC

D2-

AZ1045-04F/MSOP10

SSTXDP4AC
SSTXDN4AC

SSTXDN2AC

6

NC

D2-

AZ1045-04F/MSOP10

SSTXDN2AC
SSTXDP2AC

U3RXDP4_A
U3RXDN4_A

U3RXDN4_A
U3RXDP4_A

U3RXDN1_ASSTXDP2AC
U3RXDP1_A

U3RXDP1_A
U3RXDN1_A

UCE1

UCE3

NC

NC

D1+

1

10

NC

D1+

1

DB_+USBP

U2DM2_A U2DP2_A

GND

11

GND

D1-

2

354

8

9

NC

GND

11

GND

D1-

2

354

UCESD2

1
2
3 4

AZC099-04S/SOT23-6L/[10DEF-550099-20R_10TA1-0I8902-10R]

8

9

10

Close to connector

7

NC

D2+

7

NC

D2+

6
5

6

NC

D2-

U3RXDN2_A
U3RXDP2_A

6

NC

D2-

AZ1045-04F/MSOP10

U3RXDP2_A
U3RXDN2_A

DB_-USBP

FUSEVCC_R4

U3RXDN3_A
U3RXDP3_A

AZ1045-04F/MSOP10

U3RXDP3_A
U3RXDN3_A

A A

Gigabyte Technology

Title

Size Document Number Rev
Custom

5

4

3

2

Date: Sheet of

R_USB30

GA-X99-UD5 WIFI

1

1.0

64Tuesday, August 26, 2014 60

8

Front USB3.0 F_USB30 ESD PROTECT

FUSEVCC_F1 FUSEVCC_F1

UDC2

D D

PCH_USB3_TXN0(17)
PCH_USB3_TXP0(17)

C C

UDC3 0.1u/4/X7R/16V/K
UDC4 0.1u/4/X7R/16V/K

0.1u/4/X7R/16V/K

PCH_USB3_RXP0(17)

N_+USBP0(17)

SSTXDN0C_F
SSTXDP0C_F

FRONT USB1

FUSEVCC_F2

UDC7

0.1u/4/X7R/16V/K UDC10

N_-USBP6(17) N_-USBP7 (17)

B B

N_-USBP7

Close to connector

A A

5VDUAL

8

FUSEVCC_F2

UDC8

4
87

10

N_+USBP7

6
5

N_-USBP6N_+USBP6

FUSEVCC_F2

0.1u/4/X7R/16V/K

N_+USBP7 (17)N_+USBP6(17)

F_USB1

132
5 6

BH/2*5K9/BK/ON/2.54/VA/USB/PRT/TUR180

UDESD1

1
2
3 4

AZC099-04S.R7G/SOT23-6L/[10DEF-550099-20R_10TA1-0I8902-10R]

UDF2 SPR-P200T/6V/8/S

1

+

UDEC2
560u/FP/D/6.3V/68/C/8m

3VDUAL

7

F_USB30_1

REV=1

1

VBUS

10

ID

2

SSRX1-

3

SSRX1+

5

SSTX1-

6

SSTX1+

8

D1-

9

D1+

7

GND

4

GND

BH/2*10K20/BK/ON/2.0/VA/D/GF

FRONT USB2

0.1u/4/X7R/16V/K

7

6

UDC1

19

VBUS

15

SSTX2-

14

SSTX2+

18

SSRX2-

17

SSRX2+

12

D2-

11

D2+

16

GND

13

GND

UDC9

N_-USBP9

N_+USBP8

AZC099-04S.R7G/SOT23-6L/[10DEF-550099-20R_10TA1-0I8902-10R]

0.1u/4/X7R/16V/K

SSTXDN1C_F

UDC5 0.1u/4/X7R/16V/K

S

STXDP1C_F

UDC6 0.1u/4/X7R/16V/K

PCH_USB3_RXN1 (17)
PCH_USB3_RXP1 (17)

N_-USBP1 (17)N_-USBP0(17)
N_+USBP1 (17)

FUSEVCC_F3

BH/2*5K9/BK/ON/2.54/VA/USB/PRT/TUR180

FUSEVCC_F3

F_USB2

132

4

5 6

87
10

UDESD2

1
2
3 4

N_+USBP9

6
5

N_-USBP8

0.1u/4/X7R/16V/K

F_USB30 PWR

UDF1
SPR-P260T/6V/8/S

N_-USBP9 (17)N_-USBP8(17)
N_+USBP9 (17)N_+USBP8(17)

3VDUAL

Close to connector

UDF3 SPR-P200T/6V/8/S

5VDUAL

󱂺󳑱󰵉󰽔

560uF

6

FUSEVCC_F3

5

PCH_USB3_TXN1 (17)PCH_USB3_RXN0(17)
PCH_USB3_TXP1 (17)

FUSEVCC_F15VDUAL

1

+

UDEC1
100u/FP/D/6.3V/65/C/13m

-USBOC_F

5VDUAL

R E A R L E D O N
R E A R L E D O F F

5

UDR1 8.2K/4

IO_GP83

4

N_+USBP0
N_-USBP0

6

Close to connector

FUSEVCC_F1

SOT23

UDD2

3

BAT54A/SOT23/200mA

UDD1

3

BAT54A/SOT23/200mA

N_-USBOC_F

UDR2
15K/4/1

1
2

FUSEVCC_F2

SOT23

1
2

N_-USBOC_F (17)

FUSEVCC_F4

FUSEVCC_F3

IO_GP81

H
X

H
L

4

5

I/O

I/O

UDE1

AZ1065-06Q/MSOP8L

2

3

4

I/O

I/O

I/O

GND

7

CLOSE TO AUDIO JACK

JW/1*2/BK/2.0/VA/D/[11NH5-040102-61R]

G_PLED3(28)

ITE8620 GP81

ITE8620 GP83

3

SSTXDP1C_F

SSTXDN1C_F
SSTXDP0C_F

SSTXDN0C_F

1

I/O

Black

VCC

G_PLED1(28,55)

3

VDD

8

V
G

LED_CON1

CR183

8.2K/4

VCC

1
2

D

G S

2

G S

3

1

3

D

2

N_-USBP1
N_+USBP1

CQ30
2N7002/SOT23/25pF/5

SOT23

CQ33
2N7002/SOT23/25pF/5

SOT23

1

2

4

5

6

I/O

I/O

I/O

UDE2

AZ1065-06Q/MSOP8L

CLOSE TO HEATSINK

Black

V
G

G_PLED1(28,55)

2

3

I/O

I/O

VCC

LED_CON2
JW/1*2/BK/2.0/VA/D/[11NH5-040102-61R]

1
2

3

D

CQ34
2N7002/SOT23/25pF/5

G S

SOT23

2

1

1

GND

7

1

PCH_USB3_RXP1
PCH_USB3_RXN1
PCH_USB3_RXP0

PCH_USB3_RXN0

I/O

VDD

8

3VDUAL3VDUAL

Gigabyte Technology

Title

Size Document Number Rev
Custom

Date: Sheet of

2

FP,F_USB,USB PWR,FDD,BZ

GA-X99-UD5 WIFI

1

61 64Tuesday, August 26, 2014

1.0

PCH GPIO

5

4

3

2

1

PIN NAME POWER WELL

GP[0]
GP[1]

D D

GP[2]
GP[3]
GP[4]
GP[5]
GP[6]
GP[7]
GP[8]
GP[9]
GP[10]
GP[11]
GP[12]
GP[13]
GP[14]

C C

GP[15]
GP[16]
GP[17]
GP[18]
GP[19]
GP[20]
GP[21]
GP[22]
GP[23]

GP[24]

GP[25]

P[26]

G
GP[27]

GP[28]

B B

GP[29]
GP[30]

GP[31]

GP[32]
GP[33]
GP[34]
GP[35]
GP[36]
GP[37]
GP[38]

VCC3
VCC3
VCC3
VCC3
VCC3
VCC3
VCC3

VCC3
3VDUAL
3VDUAL
3VDUAL
3VDUAL
3VDUAL
3VDUAL
3VDUAL
3VDUAL

VCC3

VCC3

VCC3

VCC3

VCC3

VCC3

VCC3

VCC3
3VDUAL
3VDUAL
3VDUAL

3VDUAL_PCH

3VDUAL
3VDUAL
3VDUAL

3VDUAL_PCH

VCC3

VCC3

VCC3

VCC3

VCC3

VCC3

VCC3

USAGE

-ICH_PSI

-PIRQE

-PIRQF

-PIRQG

-PIRQH
GPIO6
GPIO7
GPIO8

-USBOC5

-USBOC6
GPIO11

-LPCPME
GPIO14
SPARE
SPARE
SPARE

-SPI_WP0
SPARE 8.2K P/U TO VCC3

-SPI_WP1 8.2K P/U TO VCC3
SPARE
SPARE

-SKTOC
GPIO25
SPARE 8.2K P/U TO 3VDUAL
SPARE 8.2K P/U TO 3VDUAL_PCH
GPIO28

-S_WARN
SPARE
SPARE
SPARE
SPARE

-ACZ_DET
SPARE 8.2K P/U TO VCC3(N/A)
SPARE
SPARE

AFTER
PLTRST

IN
IN
IN
IN
IN
IN
IN
IN
OUT
IN
IN
IN
OUT
IN
IN
OUT
IN
IN
OUT
OUT
OUT
IN
IN
IN
IN
OUT
OUT
OUT
OUT
OUT
OUT
IN
OUT
OUT
IN
OUT
IN
IN
IN

S3/S5 NOTES

8.2K P/U TO VCC3

8.2K P/U TO VCC3SPARE

8.2K P/U TO VCC3

8.2K P/U TO VCC3

8.2K P/U TO VCC3

8.2K P/U TO VCC3

8.2K P/U TO VCC3

8.2K P/U TO VCC3

8.2K P/U TO 3VDUAL
USB OVER-CURRENT
USB OVER-CURRENT

8.2K P/U TO 3VDUAL

8.2K P/U TO 3VDUALGPIO12

8.2K P/U TO 3VDUAL

8.2K P/U TO 3VDUAL

8.2K P/U TO 3VDUAL (N/A)

8.2K P/U TO VCC3

8.2K P/U TO VCC3

8.2K P/U TO VCC3

8.2K P/U TO VCC3
1K P/U TO VCC3

8.2K P/U TO VCC3SPARE

8.2K P/U TO 3VDUAL (N/A)

8.2K P/U TO 3VDUAL

8.2K P/U TO 3VDUAL

8.2K P/U TO 3VDUAL (N/A)SPARE
CONNECT TO -S_ACK

8.2K P/U TO 3VDUAL_PCH(N/A)

8.2K P/U TO VCC3

8.2K P/U TO VCC3

8.2K P/U TO VCC3

8.2K P/U TO VCC3

8.2K P/U TO VCC3
1K P/U TO VCC3

PIN NAME

GP[39]
GP[40]
GP[41]
GP[42]
GP[43]
GP[44]
GP[45]
GP[46]
GP[47]
GP[48]
GP[49]
GP[50]
GP[51]
GP[52]
GP[53]
GP[54]
GP[55]
GP[56]
GP[57]
GP[58]
GP[59]
GP[60]
GP[61]
GP[62]
GP[63]
GP[64]
GP[65]
GP[66]
GP[67]
GP[68]
GP[69]
GP[70]
GP[71]
GP[72]
GP[73]
GP[74]
GP[75]

POWER WELL

VCC3
3VDUAL
3VDUAL
3VDUAL
3VDUAL
3VDUAL
3VDUAL
3VDUAL
3VDUAL
VCC3
VCC3
VCC3
VCC3
VCC3
VCC3
VCC3
VCC3
3VDUAL
3VDUAL
3VDUAL
3VDUAL
3VDUAL
3VDUAL
3VDUAL

VCC3
VCC3
VCC3
VCC3
VCC3
VCC3
VCC3
VCC3
3VDUAL
3VDUAL
3VDUAL
3VDUAL

USAGE

SPARE

-USBOC1

-USBOC2

-USBOC3

-USBOC4
SPARE
SPARE
SPARE
SPARE
SPARE
SPARE

-REQ1

-GNT1

-REQ2

-GNT2

-REQ3

-GNT3
SPARE

SML1CLK

-USBOC0
SML0ART
SPARE
SUSCLK

-SLP_S5
SPARE
SPARE
SPARE
SPARE
SPARE
SPARE
SPARE
SPARE
SPARE
SPARE
SML1ART
SML1DAT

AFTER
PLTRST

IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
OUT
OUT
OUT
IN
IN
IN
IN
IN
OUT
IN
OUT
OUT
OUT
OUT
OUT
OUT
OUT
OUT
OUT
OUT
OUT
OUT
OUT
OUT
OUT

IN/OUT

S3/S5

1K P/U TO VCC3

NOTES

USB OVER-CURRENT
USB OVER-CURRENT
USB OVER-CURRENT
USB OVER-CURRENT
1K P/U TO 3VDUAL
1K P/U TO 3VDUAL
1K P/U TO 3VDUAL
1K P/U TO 3VDUAL
1K P/U TO VCC3

8.2K P/U TO VCC3

8.2K P/U TO VCC3
1K P/U TO VCC3

8.2K P/U TO VCC3

8.2K P/U TO VCC3(N/A)

8.2K P/U TO VCC3

8.2K P/U TO VCC3(N/A)

8.2K P/U TO 3VDUAL

8.2K P/U TO 3VDUALSPARE

8.2K P/U TO 3VDUAL
USB OVER-CURRENT
1K P/U TO 3VDUAL

8.2K P/U TO 3VDUAL

8.2K P/U TO 3VDUAL(N/A)

8.2K P/U TO 3VDUAL(N/A)3VDUAL

8.2K P/U TO VCC3

8.2K P/U TO VCC3

8.2K P/U TO VCC3

8.2K P/U TO VCC3

8.2K P/U TO VCC3

8.2K P/U TO VCC3

8.2K P/U TO VCC3

8.2K P/U TO VCC3

8.2K P/U TO 3VDUAL

8.2K P/U TO 3VDUAL
1K P/U TO 3VDUAL

8.2K P/U TO 3VDUAL

A A

Title

Size Document Number Rev

Custom

5

4

3

2

Date: Sheet of

Gigabyte Technology

PCH GPIO LIST

GA-X99-UD5 WIFI

1

62 64Tuesday, August 26, 2014

1.0

5

4

3

2

1

RS_SYS

D D

PE4_LED

C C

PE3_LED

PE2_LED

LED_CON1

PE1_LED

DDR4_4
DDR4_8
DDR4_2
DDR4_6

REAR PANEL

D4_LED
D8_LED
D2_LED
D6_LED

CHOKE

DF_DL1

DB_DL1

PRS1

DE_DL1

MOSFET

DF_DU1

6

DB_DU1

DE_DU1

52

CPU SOCKET

DA_DU1

DA_DL1

B_BIOS

M2_WIFI

M_BIOS

M2_20G

M2WD1

B B

M2WD2

SL_MIC1

DDR4_5
DDR4_1
DDR4_7
DDR4_3

D5_LED
D1_LED
D7_LED
D3_LED

SL_MIC2

DART7_8

DD_DL1

DH_DL1

ECRS_MOS

DC_DL1

DD_DU1

DH_DU1

DC_DU1

1

4

8

3

PCH

ECRS_PCH

RS_PCH

󲒇󲒇󲒇󲒇󱙱󱙱󱙱󱙱

PCH

󴀕󴀕󴀕󴀕󲛈󲛈󲛈󲛈󲪬󲪬󲪬󲪬󰵶󰵶󰵶󰵶󱡷󱡷󱡷󱡷

LED_CON2

FBIOS_LED
ECRS_SYS

A A

Title

Size Document Number Rev

Custom

5

4

3

Date: Sheet of

2

Gigabyte Technology

Location

GA-X99-UD5 WIFI

DG_DL1

63 64Tuesday, August 26, 2014

1

DG_DU1

7

1.0

5

4

3

2

1

D D

C C

B B

Front USB3.0 F_USB30 ESD PROTECT

FUSEVCC_F4 FUSEVCC_F4

UDC13

0.1u/4/X7R/16V/K

PCH_USB3_RXP2(17)

PCH_USB3_TXN2(17)
PCH_USB3_TXP2(17)

UDC11 0.1u/4/X7R/16V/K
UDC15 0.1u/4/X7R/16V/K

SSTXDN2C_F
SSTXDP2C_F

N_+USBP2(17)

F_USB30_2

REV=1

1

VBUS

10

I

D

2

SSRX1-

3

SSRX1+

5

SSTX1-

6

SSTX1+

8

D1-

9

D1+

7

GND

4

GND

BH/2*10K20/BK/ON/2.0/VA/D/GF

VBUS

SSTX2-

SSTX2+
SSRX2-

SSRX2+

GND
GND

UDC12

0.1u/4/X7R/16V/K

19

SSTXDN3C_F
S

STXDP3C_F

UDC16 0.1u/4/X7R/16V/K
UDC14 0.1u/4/X7R/16V/K

PCH_USB3_RXN3 (17)
PCH_USB3_RXP3 (17)

N_-USBP3 (17)N_-USBP2(17)
N_+USBP3 (17)

F_USB30 PWR

UDF4
SPR-P260T/6V/8/S

PCH_USB3_TXN3 (17)PCH_USB3_RXN2(17)
PCH_USB3_TXP3 (17)

FUSEVCC_F45VDUAL

1

+

UDEC3
100u/FP/D/6.3V/65/C/13m

15
14

18
17

12

D2-

11

D2+

16
13

N_+USBP2
N_-USBP2

5

6

I/O

I/O

UDE4

AZ1065-06Q/MSOP8L

Close to connector

4

I/O

SSTXDP3C_F

SSTXDN3C_F
SSTXDP2C_F

SSTXDN2C_F

1

2

3

I/O

I/O

I/O

GND

7

VDD

8

N_-USBP3
N_+USBP3

5

6

I/O

I/O

UDE3

AZ1065-06Q/MSOP8L

3

4

I/O

I/O

2

I/O

1

I/O

GND

7

PCH_USB3_RXP3
PCH_USB3_RXN3
PCH_USB3_RXP2

PCH_USB3_RXN2

VDD

8

3VDUAL3VDUAL

A A

Title

F_USB30_2

Size Document Number Rev

GA-X99-UD5 WIFI 1.0

C

5

4

3

2

Date: Sheet of

64 64Tuesday, August 26, 2014

1
