Gigabyte GA-H77-DS3H Service Schematics

Gigabyte Confidential

Do not Copy

5

4

3

2

1

Model Name: GA-H77-DS3H

SHEET TITLE

01

D D

02
03
04
05
06
07
08
09

C C

10
11
12
13
14
15
16
17

B B

18
19
20
21

COVER SHEET
BOM & PCB MODIFY HISTORY
BLOCK DIAGRAM
CPU_LGA1155-A
CPU_LGA1155-B
CPU_LGA1155-C
DDR III CHANNEL A
DDR III CHANNEL B
PCH_FDI,DMI,USB,PCIE
PCH_DP,CLK BUFFER
PCH_HOST,SATA,PCI
PCH_GPIO,CTRL,AUDIO
PCH_PWR,GND
PCI EXPRESS*16 SLOT
PCI EXPRESSX4 SLOT / PCIE X1 SLOT
PCI SLOT 1~2
I/O ITE8728
COM, LPT, TPM
Dual BIOS
VIA2021
REAR AUDIO JACK

1.0

SHEET TITLE

28
29
30
31
32
33
34

F_PANEL , F_USB
ATX POWER, CLOCK GEN
HWM,KB/MS , FAN CTRL
ARTHEROS AR8161/AR8151
mSATA
RT8120_DDR POWER

DVI
35
36
37
38
39
40

CPU_VTT

TQ4

MOSFET

CHOKE

TQ3

TL1

CPU SOCKET

DQ38

DQ39

DL2

3

VCORE

DQ47

DL3

2

DL4

1

DQ41 DQ44

DQ42

VCORE

DQ44

DQ45DQ41

22
23
24

A A

25
26
27

ISL95836_VCORE_1
ISL95836_VCORE_2
DISCRETE POWER
PCH CORE / VOLTAGE CONSOLE
RT8120_CPU_VTT
VCCSA POWER

5

4

DQ13

1

DQ15

DQ14

MOS

DQ13

VAXG

135Tuesday, February 21, 2012

1.0

of

PCH

Title

Size Document Number Rev
Custom

3

2

Date: Sheet

DL18

CHOKE

Gigabyte Technology

Cover Sheet

GA-H77-DS3H

Gigabyte Confidential

Do not Copy

5

4

3

2

1

GA-H77-DS3H

Component value change history

D D

Circuit or PCB layout change

DATE Change Item Reason

2011/12/14
PCB:0.1

1.由P75-D3-0.1 修改 成B75-D3V

2011/12/14
PCB:0.1

0.2 1. DDR DIP 560uF

Data Change Item Reason

2011/12/15
EBOM:01

2011/12/15
EBOM:01

02-0125

H77-DS3H

C C

B B

1.FOR B75-D3V

1.FOR Z77-DS3H

1.ADD R756,R757,R758,C232,RS_PWM. RS_PWM

2. DRT1,DR59

1. Z77 --> H77

2. Add IDT4105

3. Remove U9 NCT3931

請放到

DRT3

右邊

請放到

DQ12附近.

1.0 1. 0 ohm ahort pad (audio , lan , rt8120)

1.由B75-D3V-0.1

2. SATA0RXP

3. DDR3_1~4

修改

CPU_VAXG 包含PHASE部份,以及VIN Bottom

4.

5.ADD R756,R757,R758,C232,RS_PWM. RS_PWM

電容移除

第二層

文字面對齊

修改成

REF

Z77-DS3H

挖空位置

增加鋪銅散熱

請放到

DQ12附近.

A A

Title

Size Document Number Rev
Custom

5

4

3

2

Date: Sheet

Gigabyte Technology

BOM & PCB MODIFY HISTORY

GA-H77-DS3H

1

235Tuesday, February 21, 2012

1.0

of

Gigabyte Confidential

Do not Copy

5

4

3

2

1

BLOCK DIAGRAM

CHANNEL A
DDRIII DIMM X 2

D D

PCI EXPRESS X16

INTEL LGA1155

DDRIII BUS

CHANNEL B
DDRIII DIMM X 2

VRD12

FDI

AR8151

C C

PCI EXPRESSX1_1~2

PCI EXPRESS X4

USB2.0 PORTS 0~12

USB3.0 PORTS 1~4

B B

PCI SLOT 1/2

PCIE-1 gen2

PCIE-1 gen2

PCIE-4 gen2

USB 2.0

USB 3.0

PCI

ITE8892

PCH

PCIE-1 gen2

AZALIA BUS

DMI

SATA III / II

SPI BUS

LPC BUS

DVI

D-SUB

MSATA

SATAIIIX2/SATAIIX3

SPI BIOS

LPC I/O ITE8728

I/O PORTS :

KB/PS2COMA

AZALIA ALC887

AUDIO PORTS :

CLOCK GENERATOR

A A

LIN_ OUT

LINE_IN

FRONT AUDIO

MIC

SPDIF OUT

FRONT PANEL / FAN

Title

Size Document Number Rev
C

5

4

3

2

Date: Sheet

Gigabyte Technology

BLOCK DIAGRAM

GA-H77-DS3H

1

1.0

of

335Tuesday, February 21, 2012

Gigabyte Confidential

Do not Copy

5

CPUCLK[10]

-CPUCLK[10]

VIDSLCK_VR[22]

CFG5

LH

RSVD

Reverse

RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD

1

00

VIDSOUT_VR[22]

-VIDALRT_VR[22]

DRAM_PWROK[12]

PMSYNC[11]

-THRMTRIP[11]

NOTE
RSVD
RSVD
LANE REVERSAL[0],x16
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD

PCIE CONFIG
1X16 , Default
2X80
RSVD1
X8,X4,X4

CPUPWROK[12,24]

PECI[11,17]

-PROCHOT[24]

-SKTOCC[12]

-H_SNB[9]

D D

C C

CFG5:1: 1X16 PEG
CFG5=0: 2X8 PEG

CFG

RSVD RSVD

0

B B

1
2
3
4
7
8
9
10
11
12
13
14
15
16
17

CFG6

RSVD

NORM

RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD
RSVD

1
1
0

CPUCLK

-CPUCLK

VIDSLCK_VR
VIDSOUT_VR

-VIDALRT_VR

CPUPWROK
DRAM_PWROK

-CPURST

PMSYNC
PECI

-PROCHOT

-THRMTRIP

SM_VREF

LGA1155E

W2

BCLK[0]

W1

BCLK#[0]

C37

VIDSCLK

B37

VIDSOUT

A37

VIDALERT#

J40

UNCOREPWRGOOD

AJ19

SM_DRAMPWROK

F36

RESET#

E38

PM_SYNC

J35

PECI

E37

CATERR#

H34

PROCHOT#

G35

THERMTRIP#

AJ33

SKTOCC#

K32

FC_K32

AJ22

SM_VREF

H36

CFG[0]

J36

CFG[1]

J37

CFG[2]

K36

CFG[3]

L36

CFG[4]

N35

CFG[5]

L37

CFG[6]

M36

CFG[7]

J38

CFG[8]

L35

CFG[9]

M38

CFG[10]

N36

CFG[11]

N38

CFG[12]

N39

CFG[13]

N37

CFG[14]

N40

CFG[15]

G37

CFG[16]

G36

CFG[17]

AT14

RSVD_016

AY3

RSVD_023

H7

RSVD_028

H8

RSVD_029

VCCAXG_VALIDATION_SENSE

CPU-SK/1155/S/15

DRAM_PWROK

BC76

100p/4/NPO/50V/J/X

VCC_VALIDATION_SENSE

VSSU_VALIDATION_SENSE

VSSGT_VALIDATION_SENSE

CFG 0-17 all internal PULL-UP

A A

R309 8.2K/4

-PFMRST1[17]

MMBT2222A/SOT23/600mA/40

5

4

VCCIO_SELECT

VCCSA_VID_0

VCCSA_SENSE

VCC_SENSE
VSS_SENSE

VCCIO_SENSE
VSSIO_SENSE

VCCAXG_SENSE
VSSAXG_SENSE

TRST#
PRDY#
PREQ#

DBR#

BCLK_ITP

BCLK_ITP#

BPM#[0]
BPM#[1]
BPM#[2]
BPM#[3]
BPM#[4]
BPM#[5]
BPM#[6]
BPM#[7]

RSVD_024
RSVD_030
RSVD_037
RSVD_036
RSVD_033
RSVD_040
RSVD_039
RSVD_018
RSVD_020
RSVD_038
RSVD_032
RSVD_034
RSVD_035

5 OF 10

BC257

1u/4/X5R/6.3V/K

3VDUAL

R308
1K/4/1

Q26

SOT23

132

4

According intel

P33

CDI/IBP#476733

P34
T2

A_VCC_SENSE

A36

A_VSS_SENSE

B36

VTT_SENSE

AB4

VTT_VSS

AB3

VAXG_SENSE

L32

VAXG_VSS

M32

TDO

L39

TDO
TCK

TMS

TDI

TDI

L40

TCK

M40

TMS

L38

-TRST

J39

-HPRDY

K38
K40
E39
C40
D40

H40
H38
G38
G40
G39
F38
E40
F40

B39
J33
L34
L33
K34
N33
M34
AV1
AW2
L9
J9
K9
L31
J31
K31
AD34
AD35

DDR_15V

R275
100/4/1

R277
100/4/1

VCC3

R217
200/4/1

Q19

SOT23

132

MMBT2222A/SOT23/600mA/40

TDI [22]

TP3
TP2

SM_VREF

BC258

0.1u/4/X7R/16V/K

-CPURST

VSA_SENSE [27]
A_VCC_SENSE [22]

A_VSS_SENSE [22]
VTT_SENSE [26]

VTT_VSS [26]
VAXG_SENSE [22]

VAXG_VSS [22]

VCC1_05_PCH

DR415 0/4/SHT/M/X

CPU_VTTP

CPU_VTT

CPU_VTT

BC123

0.1u/4/X7R/16V/K/X

1.1V

分壓

R199
100/4/1

3

CPU_VTT CPU_VTT CPU_VTT CPU_VTT

BBC16

0.1u/4/X7R/16V/K

BBC14

0.1u/4/X7R/16V/K

BBC10

0.1u/4/X7R/16V/K

BBC15

1u/4/X5R/6.3V/K

BBC11

0.1u/4/X7R/16V/K

0.1u/4/X7R/16V/K

BBC13

1u/4/X5R/6.3V/K

0.1u/4/X7R/16V/K

CPU_VTTCPU_VTT CPU_VTT CPU_VTT

Stitching caps for PCIE,DMI bus

CPU_VTTPCPU_VTT

DR414 0/4/X

close cpu socket

R201 51/4/1/X
R202 100/4/1
R203 100/4/1

1 2
3 4
5 6
7 8

RN5 51/8P4R/4

R242 51/4/1
R241 51/4/1

R216 1K/4/1/X
R220 51/4/1
R228 51/4/1/X

R236 1K/4/1

BC65
1n/4/X7R/50V/K

PCIEX16:16/5/5/5/16(breakout min 10/4/4/4/10)
Impedance=80 +- 17.5%;L<5inch

VIDSLCK_VR
VIDSOUT_VR

-VIDALRT_VR
TMS

TDI
TDO

-HPRDY

TCK

-TRST

-THRMTRIP

-PROCHOT
CPUPWROKCPUPWROKCPUPWROKCPUPWROK

DMI:12/4/5/4/12(breakout min 8/4/4/4/8)
Impedance=85 +- 17.5%

CPU_VTT CPU_VTT CPU_VTT CPU_VTT

BBC1

0.1u/4/X7R/16V/K
1u/4/X5R/6.3V/K

BBC2

0.1u/4/X7R/16V/K

0.1u/4/X7R/16V/K

Stitching caps for PCIE,DMI bus

3

2

LGA1155D

FDI:12/4/5/4/12(breakout min 6/4/4/4/6)

FDI:4/5(SINGLE END)

FDI_FSYNC0[9]

FDI_LSYNC0[9]

BBC12

FDI_FSYNC0
FDI_LSYNC0

AC5
AC4

FDI_FSYNC[0]
FDI_LSYNC[0]

FDI:4/5(SINGLE END)

FDI_FSYNC1[9]

FDI_LSYNC1[9]

BBC7

FDI:4/5(SINGLE END)

FDI_INT[9]

CPU_VTT

R174

24.9/4/1

FDI_FSYNC1
FDI_LSYNC1

FDI_INT

FDI_RCOMP

AG3

AE5
AE4

AE2
AE1

FDI_FSYNC[1]
FDI_LSYNC[1]

FDI_INT
FDI_COMPIO

FDI_ICOMPO

FDI:10/5(SINGLE END)

CPU-SK/1155/S/15

EXP_RXP0
EXP_RXN0
EXP_RXP1
EXP_RXN1
EXP_RXP2
EXP_RXN2
EXP_RXP3
EXP_RXN3
EXP_RXP4
EXP_RXN4
EXP_RXP5
EXP_RXN5
EXP_RXP6
EXP_RXN6
EXP_RXP7
EXP_RXN7
EXP_RXP8
EXP_RXN8
EXP_RXP9
EXP_RXN9
EXP_RXP10
EXP_RXN10
EXP_RXP11
EXP_RXN11
EXP_RXP12
EXP_RXN12
EXP_RXP13
EXP_RXN13
EXP_RXP14
EXP_RXN14
EXP_RXP15
EXP_RXN15

DMI_0RXP[9]
DMI_0RXN[9]
DMI_1RXP[9]
DMI_1RXN[9]
DMI_2RXP[9] DMI_2TXP [9]
DMI_2RXN[9]
DMI_3RXP[9]
DMI_3RXN[9]

BBC9

0.1u/4/X7R/16V/K

CPU_VTTCPU_VTT CPU_VTT CPU_VTT

BBC3

0.1u/4/X7R/16V/K

DMI_0RXP
DMI_0RXN

DMI_1RXN
DMI_2RXP
DMI_2RXN
DMI_3RXP
DMI_3RXN DMI_3TXN

BBC4

BBC8

0.1u/4/X7R/16V/K

BBC5

BBC6

0.1u/4/X7R/16V/K

B11

PEG_RX[0]

B12

PEG_RX#[0]

D12

PEG_RX[1]

D11

PEG_RX#[1]

C10

PEG_RX[2]

C9

PEG_RX#[2]

E10

PEG_RX[3]

E9

PEG_RX#[3]

B8

PEG_RX[4]

B7

PEG_RX#[4]

C6

PEG_RX[5]

C5

PEG_RX#[5]

A5

PEG_RX[6]

A6

PEG_RX#[6]

E2

PEG_RX[7]

E1

PEG_RX#[7]

F4

PEG_RX[8]

F3

PEG_RX#[8]

G2

PEG_RX[9]

G1

PEG_RX#[9]

H3

PEG_RX[10]

H4

PEG_RX#[10]

J1

PEG_RX[11]

J2

PEG_RX#[11]

K3

PEG_RX[12]

K4

PEG_RX#[12]

L1

PEG_RX[13]

L2

PEG_RX#[13]

M3

PEG_RX[14]

M4

PEG_RX#[14]

N1

PEG_RX[15]

N2

PEG_RX#[15]

W5

DMI_RX[0]

W4

DMI_RX#[0]

V3

DMI_RX[1]

V4

DMI_RX#[1]

Y3

DMI_RX[2]

Y4

DMI_RX#[2]

AA4

DMI_RX[3]

AA5

DMI_RX#[3]

P3

PE_RX[0]

P4

PE_RX#[0]

R2

PE_RX[1]

R1

PE_RX#[1]

T4

PE_RX[2]

T3

PE_RX#[2]

U2

PE_RX[3]

U1

PE_RX#[3]

CPU-SK/1155/S/15

2

3 OF 10

Impedance=85 +- 17.5%; L< 12inch

FDI_TXP0

AC8

FDI_TX[0]

FDI_TX#[0]

FDI_TX[1]

FDI_TX#[1]

FDI_TX[2]

FDI_TX#[2]

FDI_TX[3]

FDI_TX#[3]

FDI_TX[4]

FDI_TX#[4]

FDI_TX[5]

FDI_TX#[5]

FDI_TX[6]

FDI_TX#[6]

FDI_TX[7]

FDI_TX#[7]

FDI
LINK

4 OF 10

LGA1155C

PEG_TX[0]

PEG_TX#[0]

PEG_TX[1]

PEG_TX#[1]

PEG_TX[2]

PEG_TX#[2]

PEG_TX[3]

PEG_TX#[3]

PEG_TX[4]

PEG_TX#[4]

PEG_TX[5]

PEG_TX#[5]

PEG_TX[6]

PEG_TX#[6]

PEG_TX[7]

PEG_TX#[7]

PEGDMIGEN

PEG_TX[8]

PEG_TX#[8]

PEG_TX[9]
PEG_TX#[9]
PEG_TX[10]

PEG_TX#[10]

PEG_TX[11]

PEG_TX#[11]

PEG_TX[12]

PEG_TX#[12]

PEG_TX[13]

PEG_TX#[13]

PEG_TX[14]

PEG_TX#[14]

PEG_TX[15]

PEG_TX#[15]

DMI_TX[0]

DMI_TX#[0]

DMI_TX[1]

DMI_TX#[1]

DMI_TX[2]

DMI_TX#[2]

DMI_TX[3]

DMI_TX#[3]

PE_TX[0]

PE_TX#[0]

PE_TX[1]

PE_TX#[1]

PE_TX[2]

PE_TX#[2]

PE_TX[3]

PE_TX#[3]

PEG_ICOMPO

PEG_RCOMPO

PEG_ICOMPI

Title

Size Document Number Rev

Date: Sheet

Custom

FDI_TXN0

AC7

FDI_TXP1

AC2

FDI_TXN1

AC3

FDI_TXP2

AD2

FDI_TXN2

AD1

FDI_TXP3

AD4

FDI_TXN3

AD3

FDI_TXP4

AD7

FDI_TXN4

AD6

FDI_TXP5

AE7

FDI_TXN5

AE8

FDI_TXP6

AF3

FDI_TXN6

AF2

FDI_TXP7

AG2

FDI_TXN7

AG1

EXP_TXP[0..15]
EXP_TXN[0..15]
EXP_RXP[0..15]
EXP_RXN[0..15]

EXP_TXP0

C13

EXP_TXN0

C14

EXP_TXP1

E14

EXP_TXN1

E13

EXP_TXP2

G14

EXP_TXN2

G13

EXP_TXP3

F12

EXP_TXN3

F11

EXP_TXP4

J14

EXP_TXN4

J13

EXP_TXP5

D8

EXP_TXN5

D7

EXP_TXP6

D3

EXP_TXN6

C3

EXP_TXP7

E6

EXP_TXN7

E5

EXP_TXP8

F8

EXP_TXN8

F7

EXP_TXP9

G10

EXP_TXN9

G9

EXP_TXP10

G5

EXP_TXN10

G6

EXP_TXP11

K7

EXP_TXN11

K8

XP12

EXP_T

J5

EXP_TXN12

J6

EXP_TXP13

M8

EXP_TXN13

M7

EXP_TXP14

L6

EXP_TXN14

L5

EXP_TXP15

N5

EXP_TXN15

N6

DMI_0TXP

V7

DMI_0TXN

V6

DMI_1TXPDMI_1RXP

W7

DMI_1TXN

W8

DMI_2TXP

Y6

DMI_2TXN

Y7

DMI_3TXP

AA7
AA8

P8
P7
T7
T8
R6
R5
U5
U6

GRCOMP

B5
C4

W=12 mil out of CPU

B4

S=15 mil out of CPU

Gigabyte Technology

FDI_TXP[0..7]
FDI_TXN[0..7]

DMI_0TXP [9]
DMI_0TXN [9]
DMI_1TXP [9]
DMI_1TXN [9]

DMI_2TXN [9]
DMI_3TXP [9]
DMI_3TXN [9]

R187 24.9/4/1

CPU LGA1155-A

GA-H77-DS3H

1

EXP_TXP[0..15] [14]
EXP_TXN[0..15] [14]
EXP_RXP[0..15] [14]
EXP_RXN[0..15] [14]

CPU_VTT

435Tuesday, February 21, 2012

1

FDI_TXP[0..7] [9]
FDI_TXN[0..7] [9]

1.0

of

Gigabyte Confidential

Do not Copy

5

4

3

2

1

MAAA0
MAAA1
MAAA2
MAAA3
MAAA4
MAAA5
MAAA6

D D

-SWEA[7]

-SCASA[7]

-SRASA[7]

SBAA0[7]
SBAA1[7]
SBAA2[7]

-CSA0[7]

-CSA1[7]

-CSA2[7]

-CSA3[7]

CKEA0[7]
CKEA1[7]
CKEA2[7]
CKEA3[7]

C C

DCLKA0[7]

-DCLKA0[7]
DCLKA1[7]

-DCLKA1[7]
DCLKA2[7]

-DCLKA2[7]
DCLKA3[7]

-DCLKA3[7]

-DDR3_RST[7,8]

B B

A A

MAAA7
MAAA8
MAAA9
MAAA10
MAAA11
MAAA12
MAAA13
MAAA14
MAAA15

-SWEA

-SCASA

-SRASA
SBAA0

SBAA1
SBAA2

-CSA0

-CSA1

-CSA2

-CSA3
CKEA0

CKEA1
CKEA2
CKEA3

MODT_A0
MODT_A1
MODT_A2
MODT_A3

DCLKA0

-DCLKA0
DCLKA1

-DCLKA1
DCLKA2

-DCLKA2
DCLKA3

-DCLKA3

TR1

0/4/SHT/M/X

TBC9

0.1u/4/X7R/16V/K/X

LGA1155A

AV27

SA_MA[0]

AY24

SA_MA[1]

AW24

SA_MA[2]

AW23

SA_MA[3]

AV23

SA_MA[4]

AT24

SA_MA[5]

AT23

SA_MA[6]

AU22

SA_MA[7]

AV22

SA_MA[8]

AT22

SA_MA[9]

AV28

SA_MA[10]

AU21

SA_MA[11]

AT21

SA_MA[12]

AW32

SA_MA[13]

AU20

SA_MA[14]

AT20

SA_MA[15]

AW29

SA_WE#

AV30

SA_CAS#

AU28

SA_RAS#

AY29

SA_BS[0]

AW28

SA_BS[1]

AV20

SA_BS[2]

AU29

SA_CS#[0]

AV32

SA_CS#[1]

AW30

SA_CS#[2]

AU33

SA_CS#[3]

AV19

SA_CKE[0]

AT19

SA_CKE[1]

AU18

SA_CKE[2]

AV18

SA_CKE[3]

AV31

SA_ODT[0]

AU32

SA_ODT[1]

AU30

SA_ODT[2]

AW33

SA_ODT[3]

AY25

SA_CK[0]

AW25

SA_CK#[0]

AU24

SA_CK[1]

AU25

SA_CK#[1]

AW27

SA_CK[2]

AY27

SA_CK#[2]

AV26

SA_CK[3]

AW26

SA_CK#[3]

AW18

SM_DRAMRST#

AV13

SA_DQS[8]

AV12

SA_DQS#[8]

AU12

SA_ECC_CB[0]

AU14

SA_ECC_CB[1]

AW13

SA_ECC_CB[2]

AY13

SA_ECC_CB[3]

AU13

SA_ECC_CB[4]

AU11

SA_ECC_CB[5]

AY12

SA_ECC_CB[6]

AW12

SA_ECC_CB[7]

DDR_0

1 OF 10

CPU-SK/1155/S/15

5

SA_DQS[0]

SA_DQS#[0]

SA_DQ[0]
SA_DQ[1]
SA_DQ[2]
SA_DQ[3]
SA_DQ[4]
SA_DQ[5]
SA_DQ[6]
SA_DQ[7]

SA_DQS[1]

SA_DQS#[1]

SA_DQ[8]

SA_DQ[9]
SA_DQ[10]
SA_DQ[11]
SA_DQ[12]
SA_DQ[13]
SA_DQ[14]
SA_DQ[15]

SA_DQS[2]

SA_DQS#[2]

SA_DQ[16]
SA_DQ[17]
SA_DQ[18]
SA_DQ[19]
SA_DQ[20]
SA_DQ[21]
SA_DQ[22]
SA_DQ[23]

SA_DQS[3]

SA_DQS#[3]

SA_DQ[24]
SA_DQ[25]
SA_DQ[26]
SA_DQ[27]
SA_DQ[28]
SA_DQ[29]
SA_DQ[30]
SA_DQ[31]

SA_DQS[4]

SA_DQS#[4]

SA_DQ[32]
SA_DQ[33]
SA_DQ[34]
SA_DQ[35]
SA_DQ[36]
SA_DQ[37]
SA_DQ[38]
SA_DQ[39]

SA_DQS[5]

SA_DQS#[5]

SA_DQ[40]
SA_DQ[41]
SA_DQ[42]
SA_DQ[43]
SA_DQ[44]
SA_DQ[45]
SA_DQ[46]
SA_DQ[47]

SA_DQS[6]

SA_DQS#[6]

SA_DQ[48]
SA_DQ[49]
SA_DQ[50]
SA_DQ[51]
SA_DQ[52]
SA_DQ[53]
SA_DQ[54]
SA_DQ[55]

SA_DQS[7]

SA_DQS#[7]

SA_DQ[56]
SA_DQ[57]
SA_DQ[58]
SA_DQ[59]
SA_DQ[60]
SA_DQ[61]
SA_DQ[62]
SA_DQ[63]

AK3
AK2

AJ3
AJ4
AL3
AL4
AJ2
AJ1
AL2
AL1

AP3
AP2

AN1
AN4
AR3
AR4
AN2
AN3
AR2
AR1

AW4
AV4

AV2
AW3
AV5
AW5
AU2
AU3
AU5
AY5

AV8
AW8

AY7
AU7
AV9
AU9
AV7
AW7
AW9
AY9

AV37
AV36

AU35
AW37
AU39
AU36
AW35
AY36
AU38
AU37

AP38
AP39

AR40
AR37
AN38
AN37
AR39
AR38
AN39
AN40

AK38
AK39

AL40
AL37
AJ38
AJ37
AL39
AL38
AJ39
AJ40

AF38
AF39

AG40
AG37
AE38
AE37
AG39
AG38
AE39
AE40

DQSA0

-DQSA0

MDA0
MDA1
MDA2
MDA3
MDA4
MDA5
MDA6
MDA7

DQSA1

-DQSA1

MDA8
MDA9
MDA10
MDA11
MDA12
MDA13
MDA14
MDA15

DQSA2

-DQSA2

MDA16
MDA17
MDA18
MDA19
MDA20
MDA21
MDA22
MDA23

DQSA3

-DQSA3

MDA24
MDA25
MDA26
MDA27
MDA28
MDA29
MDA30
MDA31

DQSA4

-DQSA4

MDA32
MDA33
MDA34
MDA35
MDA36
MDA37
MDA38
MDA39

DQSA5

-DQSA5

MDA40
MDA41
MDA42
MDA43
MDA44
MDA45
MDA46
MDA47

DQSA6

-DQSA6

MDA48
MDA49
MDA50
MDA51
MDA52
MDA53
MDA54
MDA55

DQSA7

-DQSA7

MDA56
MDA57
MDA58
MDA59
MDA60
MDA61
MDA62
MDA63

DCLKB0[8]

-DCLKB0[8]
DCLKB1[8]

-DCLKB1[8]
DCLKB2[8]

-DCLKB2[8]
DCLKB3[8]

-DCLKB3[8]

VREF_DQB[8]
VREF_DQA[7]

MODT_A[0..3][7]
MODT_B[0..3][8]

MDA[0..63][7]
MDB[0..63][8]

DQSA[0..7][7]

-DQSA[0..7][7]

MAAA[0..15][7]
MAAB[0..15][8]

DQSB[0..7][8]

-DQSB[0..7][8]

4

MODT_A[0..3]
MODT_B[0..3]

MDA[0..63]
MDB[0..63]

DQSA[0..7]

-DQSA[0..7]

MAAA[0..15]
MAAB[0..15]

DQSB[0..7]

-DQSB[0..7]

MAAB0
MAAB1
MAAB2
M

AAB3
MAAB4
MAAB5
MAAB6
MAAB7
MAAB8
MAAB9
MAAB10
MAAB11
MAAB12
MAAB13
MAAB14
MAAB15

-SWEB

-SWEB[8]

-SCASB

-SCASB[8]

-SRASB

-SRASB[8]
SBAB0

SBAB0[8]

SBAB1

SBAB1[8]

SBAB2

SBAB2[8]

-CSB0

-CSB0[8]

-CSB1

-CSB1[8]

-CSB2

-CSB2[8]

-CSB3

-CSB3[8]

CKEB0[8]
CKEB1[8]
CKEB2[8]
CKEB3[8]

CKEB0
CKEB1
CKEB2
CKEB3

MODT_B0
MODT_B1
MODT_B2
MODT_B3

DCLKB0

-DCLKB0
DCLKB1

-DCLKB1
DCLKB2

-DCLKB2
DCLKB3

-DCLKB3

AK24
AM20
AM19
AK18
AP19
AP18
AM18
AL18
AN18
AY17
AN23
AU17
AT18
AR26
AY16
AV16

AR25
AK25
AP24

AP23
AM24

AW17

AN25
AN26
AL25
AT26

AU16
AY15

AW15

AV15
AL26

AP26

AM26

AK26

AL21
AL22
AL20
AK20
AL23

AM22

AP21
AN21

AH1
AH4

AN16
AN15

AL16

AM16

AP16
AR16
AL15

AM15

AR15
AP15

3

LGA1155B

SB_MA[0]
SB_MA[1]
SB_MA[2]
SB_MA[3]
SB_MA[4]
SB_MA[5]
SB_MA[6]
SB_MA[7]
SB_MA[8]
SB_MA[9]
SB_MA[10]
SB_MA[11]
SB_MA[12]
SB_MA[13]
SB_MA[14]
SB_MA[15]

SB_WE#
SB_CAS#
SB_RAS#

SB_BS[0]
SB_BS[1]
SB_BS[2]

SB_CS#[0]
SB_CS#[1]
SB_CS#[2]
SB_CS#[3]

SB_CKE[0]
SB_CKE[1]
SB_CKE[2]
SB_CKE[3]

SB_ODT[0]
SB_ODT[1]
SB_ODT[2]
SB_ODT[3]

SB_CK[0]
SB_CK#[0]
SB_CK[1]
SB_CK#[1]
SB_CK[2]
SB_CK#[2]
SB_CK[3]
SB_CK#[3]

FC_AH1
FC_AH4

SB_DQS[8]
SB_DQS#[8]

SB_ECC_CB[0]
SB_ECC_CB[1]
SB_ECC_CB[2]
SB_ECC_CB[3]
SB_ECC_CB[4]
SB_ECC_CB[5]
SB_ECC_CB[6]
SB_ECC_CB[7]

DDR_1

2 OF 10

CPU-SK/1155/S/15

SB_DQS[0]

SB_DQS#[0]

SB_DQ[0]
SB_DQ[1]
SB_DQ[2]
SB_DQ[3]
SB_DQ[4]
SB_DQ[5]
SB_DQ[6]
SB_DQ[7]

SB_DQS[1]

SB_DQS#[1]

SB_DQ[8]

SB_DQ[9]
SB_DQ[10]
SB_DQ[11]
SB_DQ[12]
SB_DQ[13]
SB_DQ[14]
SB_DQ[15]

SB_DQS[2]

SB_DQS#[2]

SB_DQ[16]
SB_DQ[17]
SB_DQ[18]
SB_DQ[19]
SB_DQ[20]
SB_DQ[21]
SB_DQ[22]
SB_DQ[23]

SB_DQS[3]

SB_DQS#[3]

SB_DQ[24]
SB_DQ[25]
SB_DQ[26]
SB_DQ[27]
SB_DQ[28]
SB_DQ[29]
SB_DQ[30]
SB_DQ[31]

SB_DQS[4]

SB_DQS#[4]

SB_DQ[32]
SB_DQ[33]
SB_DQ[34]
SB_DQ[35]
SB_DQ[36]
SB_DQ[37]
SB_DQ[38]
SB_DQ[39]

SB_DQS[5]

SB_DQS#[5]

SB_DQ[40]
SB_DQ[41]
SB_DQ[42]
SB_DQ[43]
SB_DQ[44]
SB_DQ[45]
SB_DQ[46]
SB_DQ[47]

SB_DQS[6]

SB_DQS#[6]

SB_DQ[48]
SB_DQ[49]
SB_DQ[50]
SB_DQ[51]
SB_DQ[52]
SB_DQ[53]
SB_DQ[54]
SB_DQ[55]

SB_DQS[7]

SB_DQS#[7]

SB_DQ[56]
SB_DQ[57]
SB_DQ[58]
SB_DQ[59]
SB_DQ[60]
SB_DQ[61]
SB_DQ[62]
SB_DQ[63]

AH7
AH6

AG7
AG8
AJ9
AJ8
AG5
AG6
AJ6
AJ7

AM8
AL8

AL7
AM7
AM10
AL10
AL6
AM6
AL9
AM9

AR8
AP8

AP7
AR7
AP10
AR10
AP6
AR6
AP9
AR9

AN13
AN12

AM12
AM13
AR13
AP13
AL12
AL13
AR12
AP12

AN29
AN28

AR28
AR29
AL28
AL29
AP28
AP29
AM28
AM29

AP33
AR33

AP32
AP31
AP35
AP34
AR32
AR31
AR35
AR34

AL33
AM33

AM32
AM31
AL35
AL32
AM34
AL31
AM35
AL34

AG35
AG34

AH35
AH34
AE34
AE35
AJ35
AJ34
AF33
AF35

DQSB0

-DQSB0

MDB0
MDB1
MDB2
MDB3
MDB4
MDB5
MDB6
MDB7

DQSB1

-DQSB1

MDB8
MDB9
MDB10
MDB11
MDB12
MDB13
MDB14
MDB15

DQSB2

-DQSB2

MDB16
MDB17
MDB18
MDB19
MDB20
MDB21
MDB22
MDB23

DQSB3

-DQSB3

MDB24
MDB25
MDB26
MDB27
MDB28
MDB29
MDB30
MDB31

DQSB4

-DQSB4

MDB32
MDB33
MDB34
MDB35
MDB36
MDB37
MDB38
MDB39

DQSB5

-DQSB5

MDB40
MDB41
MDB42
MDB43
MDB44
MDB45
MDB
MDB47

DQSB6

-DQSB6

MDB48
MDB49
MDB50
MDB51
MDB52
MDB53
MDB54
MDB55

DQSB7

-DQSB7

MDB56
MDB57
MDB58
MDB59
MDB60
MDB61
MDB62
MDB63

LGA1155
ILM_BP/1156/CSP

Need check the new CPU ME

VREF_DQA
VREF_DQB

TBC1

46

0.1u/4/X7R/16V/K

Place in CPU bottom side

2

TBC2

0.1u/4/X7R/16V/K

Title

Size Document Number Rev

Custom

Date: Sheet

Intel CRB

CPU LGA1155-B

GA-H77-DS3H

1

535Tuesday, February 21, 2012

1.0

of

Gigabyte Confidential

Do not Copy

5

4

3

2

1

VCOREVCORE

LGA1155F

A12

VCC

A13

VCC

A14

VCC

A15

VCC

A16

VCC

A18

VCC

A24

VCC

D D

C C

B B

VCORE

A A

VCORE

A25
A27
A28
B15
B16
B18
B24
B25
B27
B28
B30
B31
B33
B34
C15
C16
C18
C19
C21
C22
C24
C25
C27
C28
C30
C31
C33
C34
C36
D13
D14
D15
D16
D18
D19
D21
D22
D24
D25
D27
D28
D30
D31
D33
D34
D35
D36
E15
E16
E18
E19
E21
E22
E24
E25
E27
E28
E30
E31
E33
E34
E35
F15
F16
F18
F19
F21
F22
F24
F25
F27
F28
F30
F31

BC98
10u/8/X5R/6.3V/K/X

VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC

CPU

VCC

POWER

6 OF 10

CPU-SK/1155/S/15

BC92
10u/8/X5R/6.3V/K/X

VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC

F32
F33
F34
G15
G16
G18
G19
G21
G22
G24
G25
G27
G28
G30
G31
G32
G33
H13
H14
H15
H16
H18
H19
H21
H22
H24
H25
H27
H28
H30
H31
H32
J12
J15
J16
J18
J19
J21
J22
J24
J25
J27
J28
J30
K15
K16
K18
K19
K21
K22
K24
K25
K27
K28
K30
L13
L14
L15
L16
L18
L19
L21
L22
L24
L25
L27
L28
L30
M14
M15
M16
M18
M19
M21
M22
M24
M25
M27
M28
M30

BC83
22u/8/X5R/6.3V/M

BC94
10u/8/X5R/6.3V/K/X

BC85
22u/8/X5R/6.3V/M

5

BC107
10u/8/X5R/6.3V/K/X

CPU_VTT

VCCSA

BC121

0.1u/4/X7R/16V/K/X

BC84
22u/8/X5R/6.3V/M

BC106
10u/8/X5R/6.3V/K/X

DDR_15V

VCCPLL

CPU_VTT

CPU_VTT

CPU_VTT

CPU_VAXG

BC97

22u/8/X5R/6.3V/M

SBC12

10u/8/X5R/6.3V/K/X

SBC10

10u/8/X5R/6.3V/K/X

BC100
10u/8/X5R/6.3V/K/X

SBC1
10u/8/X5R/6.3V/K/X

LGA1155H

AB33

VCCAXG

AB34

VCCAXG

AB35

VCCAXG

AB36

VCCAXG

AB37

VCCAXG

AB38

VCCAXG

AB39

VCCAXG

AB40

VCCAXG

AC33

VCCAXG

AC34

VCCAXG

AC35

VCCAXG

AC36

VCCAXG

AC37

VCCAXG

AC38

VCCAXG

AC39

VCCAXG

AC40

VCCAXG

T33

VCCAXG

T34

VCCAXG

T35

VCCAXG

T36

VCCAXG

T37

VCCAXG

T38

VCCAXG

T39

VCCAXG

T40

VCCAXG

U33

VCCAXG

U34

VCCAXG

U35

VCCAXG

U36

VCCAXG

U37

VCCAXG

U38

VCCAXG

U39

VCCAXG

U40

VCCAXG

W33

VCCAXG

W34

VCCAXG

W35

VCCAXG

W36

VCCAXG

W37

VCCAXG

W38

VCCAXG

Y33

VCCAXG

Y34

VCCAXG

Y35

VCCAXG

Y36

VCCAXG

Y37

VCCAXG

Y38

VCCAXG

POWER

CPU-SK/1155/S/15

BC91

22u/8/X5R/6.3V/M

SBC13

10u/8/X5R/6.3V/K/X

SBC6

10u/8/X5R/6.3V/K/X

BC95
10u/8/X5R/6.3V/K/X

SBC4
10u/8/X5R/6.3V/K/X

LGA1155G

A11

VCCIO_01

A7

VCCIO_02

AA3

VCCIO_03

AB8

VCCIO_04

AF8

VCCIO_05

AG33

VCCIO_06

AJ16

VCCIO_07

AJ17

VCCIO_08

AJ26

VCCIO_09

AJ28

VCCIO_10

AJ32

VCCIO_11

AK15

VCCIO_12

AK17

VCCIO_13

AK19

VCCIO_14

AK21

VCCIO_15

AK23

VCCIO_16

AK27

VCCIO_17

AK29

VCCIO_18

AK30

VCCIO_19

B9

VCCIO_20

D10

VCCIO_21

D6

VCCIO_22

E3

VCCIO_23

E4

VCCIO_24

G3

VCCIO_25

G4

VCCIO_26

J3

VCCIO_27

J4

VCCIO_28

J7

VCCIO_29

J8

VCCIO_30

L3

VCCIO_31

L4

VCCIO_32

L7

VCCIO_33

M13

VCCIO_34

N3

VCCIO_35

N4

VCCIO_36

N7

VCCIO_37

R3

VCCIO_38

R4

VCCIO_39

R7

VCCIO_40

U3

VCCIO_41

U4

VCCIO_42

U7

VCCIO_43

V8

VCCIO_44

W3

VCCIO_45

H10

VCCSA_01

H11

VCCSA_02

H12

VCCSA_03

J10

VCCSA_04

K10

VCCSA_05

K11

VCCSA_06

L11

VCCSA_07

L12

VCCSA_08

M10

VCCSA_09

M11

VCCSA_10

M12

VCCSA_11

POWER

CPU-SK/1155/S/15

VCC1_8_PCH

FB3

VCCPLL

0/4

BC120

0.1u/4/X7R/16V/K

BC93
10u/8/X5R/6.3V/K/X

VCORE

SBC5
10u/8/X5R/6.3V/K/X

VDDQ_01
VDDQ_02
VDDQ_03
VDDQ_04
VDDQ_05
VDDQ_06
VDDQ_07
VDDQ_08
VDDQ_09
VDDQ_10
VDDQ_11
VDDQ_12
VDDQ_13
VDDQ_14
VDDQ_15
VDDQ_16
VDDQ_17
VDDQ_18
VDDQ_19
VDDQ_20
VDDQ_21
VDDQ_22
VDDQ_23

VCCPLL_01
VCCPLL_02

7 OF 10

BC119
1u/6/X7R/16V/K

AJ13
AJ14
AJ20
AJ23
AJ24
AR20
AR21
AR22
AR23
AR24
AU19
AU23
AU27
AU31
AV21
AV24
AV25
AV29
AV33
AW31
AY23
AY26
AY28

AK11
AK12

BC256

1u/4/X5R/6.3V/K

BC99
10u/8/X5R/6.3V/K/X

SBC2
10u/8/X5R/6.3V/K/X

4

RSVD_04
RSVD_05
RSVD_08
RSVD_10
RSVD_11
RSVD_12
RSVD_19
RSVD_21

RSVD_43
RSVD_44
RSVD_45
RSVD_46
RSVD_47
RSVD_48
RSVD_49

NCTF_01
NCTF_02
NCTF_03
NCTF_04
NCTF_05

RSVD_15
RSVD_14
RSVD_13
RSVD_17
RSVD_22

RSVD_07
RSVD_03
RSVD_06
RSVD_09

RSVD_27
RSVD_26
RSVD_25
RSVD_31
RSVD_41

8 OF 10

BC55

10u/8/X5R/6.3V/K/X

SBC14

10u/8/X5R/6.3V/K/X

SBC18

10u/8/X5R/6.3V/K/X

AB7
AD37
AG4
AJ29
AJ30
AJ31
AV34
AW34

P35
P37
P39
R34
R36
R38
R40

A38
AU40
AW38
C2
D1

AT11
AP20
AN20
AU10
AY10

AF4
AB6
AE6
AJ11

D38
C39
C38
J34
N34

BC111
22u/8/X5R/6.3V/M

BC117

22u/8/X5R/6.3V/M

SBC16

10u/8/X5R/6.3V/K/X

SBC17

10u/8/X5R/6.3V/K/X

BC86
10u/8/X5R/6.3V/K/X

CPU_VAXG

3

DDR_15V

BC116
10u/8/X5R/6.3V/K

CPU_VTT

BC103
22u/8/X5R/6.3V/M

VCCSA

BC82

22u/8/X5R/6.3V/M

CPU_VAXG

BC101

22u/8/X5R/6.3V/M

BC114

22u/8/X5R/6.3V/M

SBC15

10u/8/X5R/6.3V/K/X

SBC11

10u/8/X5R/6.3V/K/X

BC110
22u/8/X5R/6.3V/M

SBC7

10u/8/X5R/6.3V/K/X

BC113
10u/8/X5R/6.3V/K

BC109
10u/8/X5R/6.3V/K/X

SBC3
10u/8/X5R/6.3V/K/X

BC104
22u/8/X5R/6.3V/M

BC108
10u/8/X5R/6.3V/K/X

SBC9

10u/8/X5R/6.3V/K/X

SBC20
10u/8/X5R/6.3V/K/X

BC115
10u/8/X5R/6.3V/K

BC105
10u/8/X5R/6.3V/K/X

SBC8

10u/8/X5R/6.3V/K/X

SBC21
10u/8/X5R/6.3V/K/X

SBC19

10u/8/X5R/6.3V/K/X

2

LGA1155I

A17
A23
A26
A29
A35

AA33
AA34
AA35
AA36
AA37
AA38

AA6
AB5

AC1

AC6
AD33
AD36
AD38
AD39
AD40

AD5

AD8

AE3
AE33
AE36

AF1

AF34
AF36
AF37
AF40

AF5

AF6

AF7
AG36

AH2

AH3
AH33
AH36
AH37
AH38
AH39
AH40

AH5

AH8

AJ12
AJ15
AJ18
AJ21
AJ25
AJ27
AJ36

AJ5

AK1
AK10
AK13
AK14
AK16
AK22
AK28
AK31
AK32
AK33
AK34
AK35
AK36
AK37

AK4
AK40

AK5

AK6

AK7

AK8

AK9

AL11
AL14
AL17
AL19
AL24
AL27
AL30
AL36

AL5

AM1
AM11
AM14
AM17

AM2
AM21
AM23

A4

AV39

CPU-SK/1155/S/15

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

GND

VSS_NCTF_01
VSS_NCTF_02

9 OF 10

LGA1155J

AM27

VSS

AM3

VSS

AM30

VSS

AM36

VSS

AM37

VSS

AM38

VSS

AM39

VSS

AM4

VSS

AM40

VSS

AM5

VSS

AN10

VSS

AN11

VSS

AN14

VSS

AN17

VSS

AN19

VSS

AN22

VSS

AN24

VSS

AN27

VSS

AN30

VSS

AN31

VSS

AN32

VSS

AN33

VSS

AN34

VSS

AN35

VSS

AN36

VSS

AN5

VSS

AN6

VSS

AN7

VSS

AN8

VSS

AN9

VSS

AP1

VSS

AP11

VSS

AP14

VSS

AP17

VSS

AP22

VSS

AP25

VSS

AP27

VSS

AP30

VSS

AP36

VSS

AP37

VSS

AP4

VSS

AP40

VSS

AP5

VSS

AR11

VSS

AR14

VSS

AR17

VSS

AR18

VSS

AR19

VSS

AR27

VSS

AR30

VSS

AR36

VSS

AR5

VSS

AT1

VSS

AT10

VSS

AT12

VSS

AT13

VSS

AT15

VSS

AT16

VSS

AT17

VSS

AT2

VSS

AT25

VSS

AT27

VSS

AT28

VSS

AT29

VSS

AT3

VSS

AT30

VSS

AT31

VSS

AT32

VSS

AT33

VSS

AT34

VSS

AT35

VSS

AT36

VSS

AT37

VSS

AT38

VSS

AT39

VSS

AT4

VSS

AT40

VSS

AT5

VSS

AT6

VSS

AT7

VSS

AT8

VSS

AT9

VSS

AU1

VSS

AU15

VSS

AU26

VSS

AU34

VSS

AU4

VSS

AU6

VSS

AU8

VSS

AV10AM25

VSSVSS

Title

Size Document Number Rev

Custom

Date: Sheet

AV11

VSS

AV14

VSS

AV17

VSS

AV3

VSS

AV35

VSS

AV38

VSS

AV6

VSS

AW10

VSS

AW11

VSS

AW14

VSS

AW16

VSS

AW36

VSS

AW6

VSS

AY11

VSS

AY14

VSS

AY18

VSS

AY35

VSS

AY4

VSS

AY6

VSS

AY8

VSS

B10

VSS

B13

VSS

B14

VSS

B17

VSS

B23

VSS

B26

VSS

B29

VSS

B32

VSS

B35

VSS

B38

VSS

B6

VSS

C11

VSS

C12

VSS

C17

VSS

C20

VSS

C23

VSS

C26

VSS

C29

VSS

C32

VSS

C35

VSS

C7

VSS

C8

VSS

D17

VSS

D2

VSS

D20

VSS

D23

VSS

D26

VSS

D29

VSS

D32

VSS

D37

VSS

D39

VSS

D4

VSS

D5

VSS

D9

VSS

E11

VSS

E12

VSS

E17

VSS

E20

VSS

E23

VSS

E26

VSS

E29

VSS

E32

VSS

E36

VSS

E7

VSS

E8

VSS

F1

VSS

F10

VSS

F13

VSS

F14

VSS

F17

VSS

F2

VSS

F20

VSS

F23

VSS

F26

VSS

F29

VSS

F35

VSS

F37

VSS

F39

VSS

F5

VSS

F6

VSS

F9

VSS

G11

VSS

G12

VSS

G17

VSS

G20

VSS

G23

VSS

G26

VSS

G29

VSS

G34

VSS

G7

VSS

GND

CPU-SK/1155/S/15

Intel CRB

CPU LGA1155-C

GA-H77-DS3H

1

VSS_NCTF_03
VSS_NCTF_04

10 OF 10

635Tuesday, February 21, 2012

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

of

G8
H1
H17
H2
H20
H23
H26
H29
H33
H35
H37
H39
H5
H6
H9
J11
J17
J20
J23
J26
J29
J32
K1
K12
K13
K14
K17
K2
K20
K23
K26
K29
K33
K35
K37
K39
K5
K6
L10
L17
L20
L23
L26
L29
L8
M1
M17
M2
M20
M23
M26
M29
M33
M35
M37
M39
M5
M6
M9
N8
P1
P2
P36
P38
P40
P5
P6
R33
R35
R37
R39
R8
T1
T5
T6
U8
V1
V2
V33
V34
V35
V36
V37
V38
V39
V40
V5
W6
Y5
Y8

AY37
B3

1.0

Gigabyte Confidential

Do not Copy

8

DDRVTT

D D

MODT_A[0..3]

-DQSA[0..7]
DQSA[0..7]

C C

B B

A A

MODT_A[0..3] [5]

-DQSA[0..7] [5]
DQSA[0..7] [5]

DDR_15V

TC2 0.1u/4/X7R/16V/K TC1 0.1u/4/X7R/16V/K

TC6 0.1u/4/X7R/16V/K
TC4 0.1u/4/X7R/16V/K

MAAA[0..15][5]

8

VCC3

VREFCA_A
VREFDQ_A

SMBCLK

SMBCLK[8,12,14,15,16,25,29]

SMBDATA

SMBDATA[8,12,14,15,16,25,29]

SBAA2

SBAA2[5]

SBAA1

SBAA1[5]

SBAA0

SBAA0[5]

CKEA1

CKEA1[5]

CKEA0

CKEA0[5]

-CSA1

-CSA1[5]

-CSA0

-CSA0[5]

-DCLKA1

-DCLKA1[5]
DCLKA1

DCLKA1[5]

-DCLKA0

-DCLKA0[5]
DCLKA0

DCLKA0[5]

MAAA0
MAAA1
MAAA2
MAAA3
MAAA4
MAAA5
MAA
MAAA7
MAAA8
MAAA9
MAAA10
MAAA11
MAAA12
MAAA13
MAAA14

-DDR3_RST[5,8]

MAAA15

-SCASA

-SCASA[5]

-SRASA

-SRASA[5]

-SWEA

-SWEA[5]

7

DDR3_4

120

VTT

2

VSS

5

VSS

8

VSS

11

VSS

14

VSS

17

VSS

20

VSS

23

VSS

26

VSS

29

VSS

32

VSS

35

VSS

38

VSS

41

VSS

44

VSS

47

VSS

80

VSS

83

VSS

86

VSS

89

VSS

92

VSS

95

VSS

98

VSS

101

VSS

104

VSS

107

VSS

110

VSS

113

VSS

116

VSS

119

VSS

121

VSS

124

VSS

127

VSS

130

VSS

133

VSS

136

VSS

139

VSS

142

VSS

145

VSS

148

VSS

151

VSS

154

VSS

157

VSS

160

VSS

163

VSS

166

VSS

199

VSS

202

VSS

205

VSS

208

VSS

211

VSS

214

VSS

217

VSS

220

VSS

223

VSS

226

VSS

229

VSS

232

VSS

235

VSS

239

VSS

51

VDD

54

VDD

57

VDD

60

VDD

62

VDD

65

VDD

66

VDD

69

VDD

72

VDD

75

VDD

78

VDD

170

VDD

173

VDD

176

VDD

179

VDD

182

VDD

183

VDD

186

VDD

189

VDD

191

VDD

194

VDD

197

VDD

236

VDDSPD

67

VREFCA

1

VREFDQ

118

SCL

238

SDA

237

SA1

117

SA0

52

BA2

190

BA1

71

BA0

169

CKE1

50

CKE0

76

S1*

193

S0*

64

CK1/NU*

63

CK1/NU

185

CK0*

184

CK0

188

A0

181

A1

61

A2

180

A3

59

A4

58

A5

A6

178

A6

56

A7

177

A8

175

A9

70

A10/AP

55

A11

174

A12

196

A13

172

A14

171

A15

168

RESET*

74

CAS*

192

RAS*

73

WE*

DDR3/240/BU/VA/D

7

48

FREE

49240

FREEVTT

187

FREE

198

FREE

79

RSVD

77

ODT1

195

ODT0

68

NC/PAR_IN

53

NC/ERR_OUT

167

NC/TEST4

39

CB0

40

CB1

45

CB2

46

CB3

158

CB4

159

CB5

164

CB6

165

CB7

7

DQS0

6

DQS0*

16

DQS1

15

DQS1*

25

DQS2

24

DQS2*

34

DQS3

33

DQS3*

85

DQS4

84

DQS4*

94

DQS5

93

DQS5*

103

DQS6

102

DQS6*

112

DQS7

111

DQS7*

43

DQS8

42

DQS8*

125

DM0/DQS9

126

NC/DQS9*

134

DM1/DQS10

135

NC/DQS10*

143

DM2/DQS11

144

NC/DQS11*

152

DM3/DQS12

153

NC/DQS12*

203

DM4/DQS13

204

NC/DQS13*

212

DM5/DQS14

213

NC/DQS14*

221

DM6/DQS15

222

NC/DQS15*

230

DM7/DQS16

231

NC/DQS16*

161

DM8/DQS17

162

NC/DQS17*

3

DQ0

4

DQ1

9

DQ2

10

DQ3

122

DQ4

123

DQ5

128

DQ6

129

DQ7

12

DQ8

13

DQ9

18

DQ10

19

DQ11

131

DQ12

132

DQ13

137

DQ14

138

DQ15

21

DQ16

22

DQ17

27

DQ18

28

DQ19

140

DQ20

141

DQ21

146

DQ22

147

DQ23

30

DQ24

31

DQ25

36

DQ26

37

DQ27

149

DQ28

150

DQ29

155

DQ30

156

DQ31

81

DQ32

82

DQ33

87

DQ34

88

DQ35

200

DQ36

201

DQ37

206

DQ38

207

DQ39

90

DQ40

91

DQ41

96

DQ42

97

DQ43

209

DQ44

210

DQ45

215

DQ46

216

DQ47

99

DQ48

100

DQ49

105

DQ50

106

DQ51

218

DQ52

219

DQ53

224

DQ54

225

DQ55

108

DQ56

109

DQ57

114

DQ58

115

DQ59

227

DQ60

228

DQ61

233

DQ62

234

DQ63

MODT_A1
MODT_A0

DQSA0

-DQSA0
DQSA1

-DQSA1
DQSA2

-DQSA2
DQSA3

-DQSA3
DQSA4

-DQSA4
DQSA5

-DQSA5
DQSA6

-DQSA6
DQSA7

-DQSA7

MDA0
MDA1
MDA2
MDA3
MDA4
MDA5
MDA6
MDA7
MDA8
MDA9
MDA10
MDA11
MDA12
MDA13
MDA14
MDA15
MDA16
MDA17
MDA18
MDA19
MDA20
MDA21
MDA22
MDA23
MDA24
MDA25
MDA26
MDA27
MDA28
MDA29
MDA30
MDA31
MDA32
MDA33
MDA34
MDA35
MDA36
MDA37
MDA38
MDA39
MDA40
MDA41
MDA42
MDA43
MDA44
MDA45
MDA46
MDA47
MDA48
MDA49
MDA50
MDA51
MDA52
MDA53
MDA54
MDA55
MDA56
MDA57
MDA58
MDA59
MDA60
MDA61
MDA62
MDA63

6

MDA[0..63] [5]

TC5 0.1u/4/X7R/16V/K
TC3 0.1u/4/X7R/16V/K

MAAA[0..15][5]

6

5

DDRVTT

DDR_15V

VCC3

VREFCA_A
VREFDQ_A

SMBCLK

SMBCLK[8,12,14,15,16,25,29]

SMBDA

SMBDATA[8,12,14,15,16,25,29]

VCC3

SBAA2

SBAA2[5]

SBAA1

SBAA1[5]

SBAA0

SBAA0[5]

CKEA3

CKEA3[5]

CKEA2

CKEA2[5]

-CSA3

-CSA3[5]

-CSA2

-CSA2[5]

-DCLKA3

-DCLKA3[5]
DCLKA3

DCLKA3[5]

-DCLKA2

-DCLKA2[5]
DCLKA2

DCLKA2[5]

MAAA0
MAAA1
MAAA2
MAAA3
MAAA4
MAAA5
MAAA6
MAAA7
MAAA8
MAAA9
MAAA10
MAAA11
MAAA12
MAAA13
MAAA14

-DDR3_RST[5,8]

MAAA15

-SCASA

-SCASA[5]

-SRASA

-SRASA[5]

-SWEA

-SWEA[5]

5

TA

DDR3_2

120

VTT

2

VSS

5

VSS

8

VSS

11

VSS

14

VSS

17

VSS

20

VSS

23

VSS

26

VSS

29

VSS

32

VSS

35

VSS

38

VSS

41

VSS

44

VSS

47

VSS

80

VSS

83

VSS

86

VSS

89

VSS

92

VSS

95

VSS

98

VSS

101

VSS

104

VSS

107

VSS

110

VSS

113

VSS

116

VSS

119

VSS

121

VSS

124

VSS

127

VSS

130

VSS

133

VSS

136

VSS

139

VSS

142

VSS

145

VSS

148

VSS

151

VSS

154

VSS

157

VSS

160

VSS

163

VSS

166

VSS

199

VSS

202

VSS

205

VSS

208

VSS

211

VSS

214

VSS

217

VSS

220

VSS

223

VSS

226

VSS

229

VSS

232

VSS

235

VSS

239

VSS

51

VDD

54

VDD

57

VDD

60

VDD

62

VDD

65

VDD

66

VDD

69

VDD

72

VDD

75

VDD

78

VDD

170

VDD

173

VDD

176

VDD

179

VDD

182

VDD

183

VDD

186

VDD

189

VDD

191

VDD

194

VDD

197

VDD

236

VDDSPD

67

VREFCA

1

VREFDQ

118

SCL

238

SDA

237

SA1

117

SA0

52

BA2

190

BA1

71

BA0

169

CKE1

50

CKE0

76

S1*

193

S0*

64

CK1/NU*

63

CK1/NU

185

CK0*

184

CK0

188

A0

181

A1

61

A2

180

A3

59

A4

58

A5

178

A6

56

A7

177

A8

175

A9

70

A10/AP

55

A11

174

A12

196

A13

172

A14

171

A15

168

RESET*

74

CAS*

192

RAS*

73

WE*

DDR3/240/WH/VA/D

FREE
FREEVTT
FREE
FREE

RSVD
ODT1

ODT0

NC/PAR_IN

NC/ERR_OUT

NC/TEST4

DQS0

DQS0*

DQS1

DQS1*

DQS2

DQS2*

DQS3

DQS3*

DQS4

DQS4*

DQS5

DQS5*

DQS6

DQS6*

DQS7

DQS7*

DQS8

DQS8*

DM0/DQS9

NC/DQS9*

DM1/DQS10

NC/DQS10*

DM2/DQS11

NC/DQS11*

DM3/DQS12

NC/DQS12*

DM4/DQS13

NC/DQS13*

DM5/DQS14

NC/DQS14*

DM6/DQS15

NC/DQS15*

DM7/DQS16

NC/DQS16*

DM8/DQS17

NC/DQS17*

DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46
DQ47
DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63

4

48
49240
187
198

79

MODT_A3

77

MODT_A2

195
68

53
167

39

CB0

40

CB1

45

CB2

46

CB3

158

CB4

159

CB5

164

CB6

165

CB7

DQSA0

7

-DQSA0

6

DQSA1

16

-DQSA1
DQSA2

-DQSA2
DQSA3

-DQSA3
DQSA4

-DQSA4
DQSA5

-DQSA5
DQSA6

-DQSA6
DQSA7

-DQSA7

MDA0
MDA1
MDA2
MDA3
MDA4
MDA5
MDA6
MDA7
MDA8
MDA9
MDA10
MDA11
MDA12
MDA13
MDA14
MDA15
MDA16
MDA17
MDA18
MDA19
MDA20
MDA21
MDA22
MDA23
MDA24
MDA25
MDA26
MDA27
MDA28
MDA29
MDA30
MDA31
MDA32
MDA33
MDA34
MDA35
MDA36
MDA37
MDA38
MDA39
MDA40
MDA41
MDA42
MDA43
MDA44
MDA45
MDA46
MDA47
MDA48
MDA49
MDA50
MDA51
MDA52
MDA53
MDA54
MDA55
MDA56
MDA57
MDA58
MDA59
MDA60
MDA61
MDA62
MDA63

1u/4/X5R/6.3V/K

15
25

24
34

33
85

84
94

93
103

102
112

111
43

42
125

126
134

135
143

144
152

153
203

204
212

213
221

222
230

231
161

162

3

DQ0

4

DQ1

9

DQ2

10

DQ3

122

DQ4

123

DQ5

128

DQ6

129

DQ7

12

DQ8

13

DQ9

18
19
131
132
137
138
21
22
27
28
140
141
146
147
30
31
36
37
149
150
155
156
81
82
87
88
200
201
206
207
90
91
96
97
209
210
215
216
99
100
105
106
218
219
224
225
108
109
114
115
227
228
233
234

4

3

DDR_15V

TR7
1K/4/1

VREFCA_A

TR6
1K/4/1

DDR_15V

TBC4

TR5
1K/4/1

VREFDQ_A

TR4
1K/4/1

TBC10
1u/4/X5R/6.3V/K

DDR TERMINATION
CHANNEL A/B

DDR15V Decouple

DDR_15V

TEC1 560u/FP/D/6.3V/69/A/11m

TEC4 560u/FP/D/6.3V/69/A/11m

MDA[0..63] [5]

DDR_15V

DDR_15V

3

TR3 10/4

Check

1

+

1

+

電容限高

TBC22

0.1u/4/X7R/16V/K
TBC23

0.1u/4/X7R/16V/K
TBC25

0.1u/4/X7R/16V/K
TBC14

1u/4/X5R/6.3V/K

TBC24
1u/4/X5R/6.3V/K

TBC11
1u/4/X5R/6.3V/K

TBC17
1u/4/X5R/6.3V/K

TBC18
1u/4/X5R/6.3V/K

TBC19
1u/4/X5R/6.3V/K

TBC20
1u/4/X5R/6.3V/K

TBC12
1u/4/X5R/6.3V/K

TBC3
1u/4/X5R/6.3V/K

TBC5
1u/4/X5R/6.3V/K

TBC6
1u/4/X5R/6.3V/K

TBC7
1u/4/X5R/6.3V/K

TBC8
1u/4/X5R/6.3V/K

2

-DDR3_RST

TC10

100p/4/NPO/50V/J

SMBDATA
SMBCLK

TC14

100p/4/NPO/50V/J/X

VREF_DQA [5]

DDRVTT Decouple

10mm

DDRVTT

TBC43 22u/8/X5R/6.3V/M

DDRVTT

DDRVTT

DDRVTT

Title

Size Document Number Rev

Date: Sheet

Intel CRB

DDRIII CHANNEL A

Custom

2

TC15
100p/4/NPO/50V/J/X

TBC16
22u/8/X5R/6.3V/M/X

TBC13
22u/8/X5R/6.3V/M

TBC27

0.1u/4/X7R/16V/K

TBC26

0.1u/4/X7R/16V/K

TBC21
1u/4/X5R/6.3V/K

TBC15
1u/4/X5R/6.3V/K

GA-H77-DS3H

1

1

735

1.0

of

Gigabyte Confidential

Do not Copy

8

DDRVTT

D D

-DQSB[0..7]

-DQSB[0..7] [5]

DQSB[0..7]

DQSB[0..7] [5]

MODT_B[0..3]

C C

B B

A A

MODT_B[0..3] [5]

DDR_15V

TC11 0.1u/4/X7R/16V/K

VCC3

TC9 0.1u/4/X7R/16V/K

SMBCLK[7,12,14,15,16,25,29]

SMBDATA[7,12,14,15,16,25,29]

VCC3

SBAB2[5]
SBAB1[5]
SBAB0[5]

CKEB1[5]
CKEB0[5]

-CSB1[5]

-CSB0[5]

-DCLKB1[5]
DCLKB1[5]

-DCLKB0[5]
DCLKB0[5]

MAAB[0..15][5]

-DDR3_RST[5,7]

-SCASB[5]

-SRASB[5]

-SWEB[5]

8

VREFCA_B
VREFDQ_B

SMBCLK
SMBDATA

SBAB2
SBAB1
SBAB0

CKEB1
CKEB0

-CSB1

-CSB0

-DCLKB1
DCLKB1

-DCLKB0
DCLKB0

MAAB0
MAAB1
MAAB2
MAAB3
MAAB4
MAAB5
MAAB6
MAAB7
MAAB8
MAAB9
MAAB10
MAAB11
MAAB12
MAAB13
MAAB14
MAAB

-SCASB

-SRASB

-SWEB

7

DDR3_3

120

VTT

2

VSS

5

VSS

8

VSS

11

VSS

14

VSS

17

VSS

20

VSS

23

VSS

26

VSS

29

VSS

32

VSS

35

VSS

38

VSS

41

VSS

44

VSS

47

VSS

80

VSS

83

VSS

86

VSS

89

VSS

92

VSS

95

VSS

98

VSS

101

VSS

104

VSS

107

VSS

110

VSS

113

VSS

116

VSS

119

VSS

121

VSS

124

VSS

127

VSS

130

VSS

133

VSS

136

VSS

139

VSS

142

VSS

145

VSS

148

VSS

151

VSS

154

VSS

157

VSS

160

VSS

163

VSS

166

VSS

199

VSS

202

VSS

205

VSS

208

VSS

211

VSS

214

VSS

217

VSS

220

VSS

223

VSS

226

VSS

229

VSS

232

VSS

235

VSS

239

VSS

51

VDD

54

VDD

57

VDD

60

VDD

62

VDD

65

VDD

66

VDD

69

VDD

72

VDD

75

VDD

78

VDD

170

VDD

173

VDD

176

VDD

179

VDD

182

VDD

183

VDD

186

VDD

189

VDD

191

VDD

194

VDD

197

VDD

236

VDDSPD

67

VREFCA

1

VREFDQ

118

SCL

238

SDA

237

SA1

117

SA0

52

BA2

190

BA1

71

BA0

169

CKE1

50

CKE0

76

S1*

193

S0*

64

CK1/NU*

63

CK1/NU

185

CK0*

184

CK0

188

A0

181

A1

61

A2

180

A3

59

A4

58

A5

178

A6

56

A7

177

A8

175

A9

70

A10/AP

55

A11

174

A12

196

A13

172

A14

15

171

A15

168

RESET*

74

CAS*

192

RAS*

73

WE*

DDR3/240/BU/VA/D

7

FREE
FREEVTT
FREE
FREE

RSVD
ODT1

ODT0

NC/PAR_IN

NC/ERR_OUT

NC/TEST4

DQS0

DQS0*

DQS1

DQS1*

DQS2

DQS2*

DQS3

DQS3*

DQS4

DQS4*

DQS5

DQS5*

DQS6

DQS6*

DQS7

DQS7*

DQS8

DQS8*

DM0/DQS9

NC/DQS9*

DM1/DQS10

NC/DQS10*

DM2/DQS11

NC/DQS11*

DM3/DQS12

NC/DQS12*

DM4/DQS13

NC/DQS13*

DM5/DQS14

NC/DQS14*

DM6/DQS15

NC/DQS15*

DM7/DQS16

NC/DQS16*

DM8/DQS17

NC/DQS17*

DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46
DQ47
DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63

DQ0
DQ1
DQ2
DQ3
DQ4
DQ5
DQ6
DQ7
DQ8
DQ9

6

48
49240
187
198

79

MODT_B1

77

MODT_B0

195
68

53
167

39

CB0

40

CB1

45

CB2

46

CB3

158

CB4

159

CB5

164

CB6

165

CB7

DQSB0

7

-DQSB0

6

DQSB1

16

-DQSB1

15

DQSB2

25

-DQSB2

24

DQSB3

34

-DQSB3

33

DQSB4

85

-DQSB4

84

DQSB5

94

-DQSB5

93

DQSB6

103

-DQSB6

102

DQSB7

112

-DQSB7

111
43

42
125

126
134

135
143

144
152

153
203

204
212

213
221

222
230

231
161

162

MDB0

3

MDB1

4

MDB2

9

MDB3

10

MDB4

122

MDB5

123

MDB6

128

MDB7

129

MDB8

12

MDB9

13

MDB10

18

MDB11

19

MDB12

131

MDB13

132

MDB14

137

MDB15

138

MDB16

21

MDB17

22

MDB18

27

MDB19

28

MDB20

140

MDB21

141

MDB22

146

MDB23

147

MDB24

30

MDB25

31

MDB26

36

MDB27

37

MDB28

149

MDB29

150

MDB30

155

MDB31

156

MDB32

81

MDB33

82

MDB34

87

MDB35

88

MDB36

200

MDB37

201

MDB38

206

MDB39

207

MDB40

90

MDB41

91

MDB42

96

MDB43

97

MDB44

209

MDB45

210

MDB46

215

MDB47

216

MDB48

99

MDB49

100

MDB50

105

MDB51

106

MDB52

218

MDB53

219

MDB54

224

MDB55

225

MDB56

108

MDB57

109

MDB58

114

MDB59

115

MDB60

227

MDB61

228

MDB62

233

MDB63

234

6

MDB[0..63] [5]

5

DDRVTT

TC7 0.1u/4/X7R/16V/K

TC12 0.1u/4/X7R/16V/KTC13 0.1u/4/X7R/16V/K
TC8 0.1u/4/X7R/16V/K

SMBCLK[7,12,14,15,16,25,29]

SMBDATA[7,12,14,15,16,25,29]

VCC3

SBAB2[5]
SBAB1[5]
SBAB0[5]

CKEB3[5]
CKEB2[5]

-CSB3[5]

-CSB2[5]

-DCLKB3[5]
DCLKB3[5]

-DCLKB2[5]
DCLKB2[5]

MAAB[0..15][5]

-DDR3_RST[5,7]

-SCASB[5]

-SRASB[5]

-SWEB[5]

5

DDR_15V

VCC3

VREFCA_B
VREFDQ_B

SMBCLK
SMBDATA

SBAB2
SBAB1
SBAB0

CKEB3
CKEB2

-CSB3

-CSB2

-DCLKB3
DCLKB3

-DCLKB2
DCLKB2

MAAB0
MAAB1
MAAB2
MAAB3
MAAB4
MAAB5
MAAB6
MAAB7
MAAB8
MAA
MAAB10
MAAB11
MAAB12
MAAB13
MAAB14
MAAB15

-SCASB

-SRASB

-SWEB

120

101
104
107
110
113
116
119
121
124
127
130
133
136
139
142
145
148
151
154
157
160
163
166
199
202
205
208
211
214
217
220
223
226
229
232
235
239

170
173
176
179
182
183
186
189
191
194
197

236

118
238
237
117

190

169

193

185
184

188
181

180

178
177

B9

175

174
196
172
171

168
192

4

DDR3_1

VTT

2

VSS

5

VSS

8

VSS

11

VSS

14

VSS

17

VSS

20

VSS

23

VSS

26

VSS

29

VSS

32

VSS

35

VSS

38

VSS

41

VSS

44

VSS

47

VSS

80

VSS

83

VSS

86

VSS

89

VSS

92

VSS

95

VSS

98

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

51

VDD

54

VDD

57

VDD

60

VDD

62

VDD

65

VDD

66

VDD

69

VDD

72

VDD

75

VDD

78

VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD
VDD

VDDSPD

67

VREFCA

1

VREFDQ

SCL
SDA
SA1
SA0

52

BA2
BA1

71

BA0
CKE1

50

CKE0

76

S1*
S0*

64

CK1/NU*

63

CK1/NU
CK0*

CK0
A0

A1

61

A2
A3

59

A4

58

A5
A6

56

A7
A8
A9

70

A10/AP

55

A11
A12
A13
A14
A15

RESET*

74

CAS*
RAS*

73

WE*

DDR3/240/WH/VA/D

4

FREE
FREEVTT
FREE
FREE

RSVD
ODT1

ODT0

NC/PAR_IN

NC/ERR_OUT

NC/TEST4

DQS0

DQS0*

DQS1

DQS1*

DQS2

DQS2*

DQS3

DQS3*

DQS4

DQS4*

DQS5

DQS5*

DQS6

DQS6*

DQS7

DQS7*

DQS8

DQS8*

DM0/DQS9

NC/DQS9*

DM1/DQS10

NC/DQS10*

DM2/DQS11

NC/DQS11*

DM3/DQS12

NC/DQS12*

DM4/DQS13

NC/DQS13*

DM5/DQS14

NC/DQS14*

DM6/DQS15

NC/DQS15*

DM7/DQS16

NC/DQS16*

DM8/DQS17

NC/DQS17*

DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46
DQ47
DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63

3

48
49240
187
198

79

MODT_B3

77

MODT_B2

195
68

53
167

39

CB0

40

CB1

45

CB2

46

CB3

158

CB4

159

CB5

164

CB6

165

CB7

DQSB0

7

-DQSB0

6

DQSB1

16

-DQSB1

15

DQSB2

25

-DQSB2

24

DQSB3

34

-DQSB3

33

DQSB4

85

-DQSB4

84

DQSB5

94

-DQSB5

93

DQSB6

103

-DQSB6

102

DQSB7

112

-DQSB7

111
43

42
125

126
134

135
143

144
152

153
203

204
212

213
221

222
230

231
161

162

MDB0

3

DQ0

MDB1

4

DQ1

MDB2

9

DQ2

MDB3

10

DQ3

MDB4

122

DQ4

MDB5

123

DQ5

MDB6

128

DQ6

MDB7

129

DQ7

MDB8

12

DQ8

MDB9

13

DQ9

MDB10

18

MDB11

19

MDB12

131

MDB13

132

MDB14

137

MDB15

138

MDB16

21

MDB17

22

MDB18

27

MDB19

28

MDB20

140

MDB21

141

MDB22

146

MDB23

147

MDB24

30

MDB25

31

MDB26

36

MDB27

37

MDB28

149

MDB29

150

MDB30

155

MDB31

156

MDB32

81

MDB33

82

MDB34

87

MDB35

88

MDB36

200

MDB37

201

MDB38

206

MDB39

207

MDB40

90

MDB41

91

MDB42

96

MDB43

97

MDB44

209

MDB45

210

MDB46

215

MDB47

216

MDB48

99

MDB49

100

MDB50

105

MDB51

106

MDB52

218

MDB53

219

MDB54

224

MDB55

225

MDB56

108

MDB57

109

MDB58

114

MDB59

115

MDB60

227

MDB61

228

MDB62

233

MDB63

234

3

DDR_15V

DDR_15V

DDR3 1066,1333,1600MHZ BANDWIDTH

DDR3 1066MHZ
DDR3 clock=533MHZ
DDR3 single channel bandwidth=533x2x8Byte=8.5GB/s
DDR3 dual channel bandwidth=533x2x2x8Byte=17GB/s

DDR3 1333MHZ
DDR3 clock=667MHZ
DDR3 single channel bandwidth=10.6GB/s
DDR3 dual channel bandwidth=21GB/s

DDR3 1600MHZ
DDR3 clock=800MHZ
DDR3 single channel bandwidth=12.8GB/s
DDR3 dual channel bandwidth=25.6GB/s

MDB[0..63] [5]

TR13
1K/4/1

VREFCA_B

TR12
1K/4/1

TR11
1K/4/1

VREFDQ_B

TR10
1K/4/1

2

TR9 10/4

COUPON1

COUPON2

VREF_DQB [5]

COUPON1 COUPON/X

COUPON2 COUPON/X

1

21

21

CPU

DIMM1
DIMM2

Title

Size Document Number Rev

Custom

Date: Sheet

Intel CRB

DDRIII CHANNEL B

GA-H77-DS3H

2

CHA
CHB

835

1

VCC3

1.0

of

Gigabyte Confidential

Do not Copy

5

4

3

2

1

PCHB

R350 49.9/4/1

BC178

1u/4/X5R/6.3V/K

DMI_0TXN
DMI_0TXP
DMI_0RXN
DMI_0RXP
DMI_1TXN
DMI_1TXP
DMI_1RXN
DMI_1RXP
DMI_2TXN
DMI_2TXP
DMI_2RXN
DMI_2RXP
DMI_3TXN
DMI_3TXP
DMI_3RXN
DMI_3RXP
DMI_COMP

-SRCCLK_PCH
SRCCLK_PCH

PET_N1
PET_P1

PET_N2
PET_P2

PET_N5
PET_P5

PET_N6
PET_P6

PET_N7
PET_P7

PET_N8
PET_P8

DMI_0TXN[4]
DMI_0TXP[4]
DMI_0RXN[4]
DMI_0RXP[4]

D D

W=4 mil out of PCH
S=15 mil out of PCH

LA_ML_IN[31]
LA_ML_IP[31]

LA_ML_ON[31]

C C

LA_ML_OP[31]

VCC1_05_PCH

PCIE_IN1[15]

PCIE_IP1[15]
PCIE_TN1[15]
PCIE_TP1[15]

PCIE_IN2[15]

PCIE_IP2[15]
PCIE_TN2[15]
PCIE_TP2[15]

G_PCIEBIN[35]

G_PCIEBIP[35]
G_PCIEBON[35]
G_PCIEBOP[35]

PCIE_IN5[15]

PCIE_IP5[15]
PCIE_TN5[15]
PCIE_TP5[15]

PCIE_IN6[15]

PCIE_IP6[15]
PCIE_TN6[15]
PCIE_TP6[15]

PCIE_IN7[15]

PCIE_IP7[15]
PCIE_TN7[15]
PCIE_TP7[15]

PCIE_IN8[15]

PCIE_IP8[15]
PCIE_TN8[15]
PCIE_TP8[15]

放靠近

PCIEX1:16/5/5/5/16 (breakout min 8/4/4/4/8)
Impedance=80 +- 17.5%

B B

DMI_1TXN[4]
DMI_1TXP[4]
DMI_1RXN[4]
DMI_1RXP[4]
DMI_2TXN[4]
DMI_2TXP[4]
DMI_2RXN[4]
DMI_2RXP[4]
DMI_3TXN[4]
DMI_3TXP[4]
DMI_3RXN[4]
DMI_3RXP[4]

-SRCCLK_PCH[29]
SRCCLK_PCH[29]

C18 0.1u/4/X7R/16V/K
C17 0.1u/4/X7R/16V/K

C2 0.1u/4/X7R/16V/K
C3 0.1u/4/X7R/16V/K

C42 0.1u/4/X7R/16V/K
C35 0.1u/4/X7R/16V/K

C41 0.1u/4/X7R/16V/K
C33 0.1u/4/X7R/16V/K

C204 0.1u/4/X7R/16V/K
C205 0.1u/4/X7R/16V/K

C202 0.1u/4/X7R/16V/K
C203 0.1u/4/X7R/16V/K

Device & PCI-E Slot

VCC3

PCH_HS

D33

DMI0RXN

B33

DMI0RXP

J36

DMI0TXN

H36

DMI0TXP

A36

DMI1RXN

B35

DMI1RXP

P38

DMI1TXN

R38
C36

H38

M41

R33

R20
C22

H17

M17

N15
M15

C16

H12

H10

D13

B37

J38
E37
F38

P41
B31
E31

P33

J20
L20
F25
F23
P20

A22
J17

E21
B21
P17

F18
E17

B17
J15

L15
A16
B15
J12

F15
F13

J10
B13

DMI1TXP
DMI2RXN
DMI2RXP
DMI2TXN
DMI2TXP
DMI3RXN
DMI3RXP
DMI3TXN
DMI3TXP
DMI_IRCOMP
DMI_ZCOMP

CLKIN_DMI_N
CLKIN_DMI_P

PERN1
PERP1
PETN1
PETP1
PERN2
PERP2
PETN2
PETP2
PERN3
PERP3
PETN3
PETP3
PERN4
PERP4
PETN4
PETP4
PERN5
PERP5
PETN5
PETP5
PERN6
PERP6
PETN6
PETP6
PERN7
PERP7
PETN7
PETP7
PERN8
PERP8
PETN8
PETP8

DMI PCI-E

-USBOC_F -USBOC_R

BC168

0.1u/4/X7R/16V/K

1

USB

OC0#/GPIO59
OC1#/GPIO40
OC2#/GPIO41
OC3#/GPIO42
OC4#/GPIO43

OC5#/GPIO9
OC6#/GPIO10
OC7#/GPIO14

USBRBIAS#

USBRBIAS

CLKIN_DOT_96N
CLKIN_DOT_96P

DMI2RBIAS

2 OF 11

BD82H77/S

BC170

0.1u/4/X7R/16V/K

USBP0N
USBP0P
USBP1N
USBP1P
USBP2N
USBP2P
USBP3N
USBP3P
USBP4N
USBP4P
USBP5N
USBP5P
USBP6N
USBP6P
USBP7N
USBP7P
USBP8N
USBP8P
USBP9N

USBP9P
USBP10N
USBP10P
USBP11N
USBP11P
USBP12N
USBP12P
USBP13N
USBP13P

USB2.0:12/4.5/7.5/4.5/12
(breakout min 8/4/4/4/8)

Impedance=90 +- 17.5%

BF36
BD36
BC33
BA33
BM33
BM35
BT33
BU32
BR32
BT31
BN29
BM30
BK33
BJ33
BF31
BD31
BN27
BR29
BR26
BT27
BK25
BJ25
BJ31
BK31
BF27
BD27
BJ27
BK27

BM43
BD41
BG41
BK43
BP43
BJ41
BT45
BM45

BP25
BM25

BD38
BF38

A32

-USBP0
+USBP0

-USBP1
+USBP1

-USBP2
+USBP2

-USBP3
+USBP3

-USBP4
+USBP4

-USBP5
+USBP5

B75 CHIP USB PORT
6/7 are Disable

-USBP8
+USBP8

-USBP9
+USBP9

-USBP10
+USBP10

-USBP11
+USBP11

-USBP12
+USBP12

-USBP13
+USBP13

-USBOC_F

GPIO42

GPIO14

USBRBIAS

-DOTCLK
DOTCLK

R351 750/4/1

W=4 mil out of PCH
S=15 mil out of PCH

-USBP0 [28]
+USBP0 [28]

-USBP1 [28]
+USBP1 [28]

-USBP2 [31]
+USBP2 [31]

-USBP3 [31]
+USBP3 [31]

-USBP4 [28]
+USBP4 [28]

-USBP5 [28]
+USBP5 [28]

-USBP8 [28]
+USBP8 [28]

-USBP9 [28]
+USBP9 [28]

-USBP10 [30]
+USBP10 [30]

-USBP11 [30]
+USBP11 [30]

-USBP12 [31]
+USBP12 [31]

-USBP13 [31]
+USBP13 [31]

-USBOC_F [28]

-USBOC_R [28,31]

R341 22.6/4/1

W=4 mil out of PCH
S=15 mil out of PCH

-DOTCLK [29]
DOTCLK [29]

3VDUAL

GPIO42
GPIO14

R732

8.2K/4

3VDUAL

R371

8.2K/4

USB3.0:20/5/7/5/20 (breakout min
8/4/4/4/8) ; ONLY 3 VIAS

Impedance=85 +- 17.5%
Back Panel < 10000 MILS

Front Panel < 6000 MILS

PCH_USB3_RXN1[28]

PCH_USB3_RXP1[28]
PCH_USB3_TXN1[28]
PCH_USB3_TXP1[28]

PCH_USB3_RXN2[28]

PCH_USB3_RXP2[28]
PCH_USB3_TXN2[28]
PCH_USB3_TXP2[28]

PCH_USB3_RXN3[31]

PCH_USB3_RXP3[31]
PCH_USB3_TXN3[31]
PCH_USB3_TXP3[31]

PCH_USB3_RXN4[31]

PCH_USB3_RXP4[31]
PCH_USB3_TXN4[31]
PCH_USB3_TXP4[31]

OC[3:0]# for
Device 29
(ports 0-7)

OC[7:4]# for
Device 26
(ports 8-13)

USB OC# Configure

OC0#
OC1#
OC2#
OC3#
OC4#
OC5#

USB0,1
USB2,3
USB4,5
USB6,7
USB8,9

USB10,11
OC6# USB12,13
OC7#

Not Use

SRCCLK_PCH

-SRCCLK_PCH

DOTCLK

-DOTCLK

R102 short to GND in non
graphic SKU

R267 8.2K/4/X
R268 8.2K/4/X

R246 8.2K/4/X
R251 8.2K/4/X

VCC1_8_PCH

PCH_USB3_TXN1
PCH_USB3_TXP1

PCH_USB3_TXN2
PCH_USB3_TXP2

PCH_USB3_TXN3
PCH_USB3_TXP3

PCH_USB3_TXN4
PCH_USB3_TXP4

NV_CLE

H31
C29

E29

F28
E27

C26
B27

B25
D25

M48
R47
Y41
M50
M49
U43

J31

J27
L27

J25
L25

L22
J22

J57

PCHG

USB3_RXN1
USB3_RXP1
USB3_TXN1
USB3_TXP1

USB3_RXN2
USB3_RXP2
USB3_TXN2
USB3_TXP2

USB3_RXN3
USB3_RXP3
USB3_TXN3
USB3_TXP3

USB3_RXN4
USB3_RXP4
USB3_TXN4
USB3_TXP4

PCHE

RESERVED_29
DF_TVS
RESERVED_6
RESERVED_4
RESERVED_3
RESERVED_2
RESERVED_1

NVRAM

FDILINK

FDI_RXN0
FDI_RXP0
FDI_RXN1
FDI_RXP1
FDI_RXN2
FDI_RXP2
FDI_RXN3
FDI_RXP3
FDI_RXN4
FDI_RXP4
FDI_RXN5
FDI_RXP5
FDI_RXN6
FDI_RXP6
FDI_RXN7
FDI_RXP7

FDI_FSYNC0
FDI_LSYNC0
FDI_FSYNC1
FDI_LSYNC1

7 OF 11

FDI_INT

BD82H77/S

FDI_TXP[0..7]
FDI_TXN[0..7]

RESERVED_22
RESERVED_21
RESERVED_14
RESERVED_13
RESERVED_12
RESERVED_11
RESERVED_10

RESERVED_9
RESERVED_8

RESERVED_7
RESERVED_20
RESERVED_19
RESERVED_18
RESERVED_17
RESERVED_16
RESERVED_15

RESERVED_28
RESERVED_27
RESERVED_26
RESERVED_25

RESERVED_24
RESERVED_23

RESERVED_5

5 OF 11

C42
B43
F45
F43
H41
J41
C46
D47
B45
A46
B47
C49
J43
H43
M43
P43

B51
E49
C52
D51

H46

BD82H77/S

FDI_TXN0
FDI_TXP0
FDI_TXN1
FDI_TXP1
FDI_TXN2
FDI_TXP2
FDI_TXN3
FDI_TXP3
FDI_TXN4
FDI_TXP4
FDI_TXN5
FDI_TXP5
FDI_TXN6
FDI_TXP6
FDI_TXN7
FDI_TXP7

FDI_FSYNC0
FDI_LSYNC0
FDI_FSYNC1
FDI_LSYNC1

FDI_INT

FDI_TXP[0..7] [4]
FDI_TXN[0..7] [4]

AB50
Y50
AB49
AB44
U49
R44
U50
U46
U44
H50
K46
L56
J55
F53
H52
E52

K50
K49
AB46
G56

Y44
L53

NV_RCOMP

R50

FDI_FSYNC0 [4]
FDI_LSYNC0 [4]
FDI_FSYNC1 [4]
FDI_LSYNC1 [4]

FDI_INT [4]

R422 33/4

R407

NEW 7 MODEL

Footprint: BGAHSINK-75;
3mm

A A

2

HEAT SINK/N-BG/GBT MK/Z77/KWOG/[12SP2-S04208-01R_12SP2-S04208-02R_12SP2-S04208-03R]

5

孔徑

4

3

2.2K/4/1
R408 4.7K/4

-H_SNB [4]

BC186

0.1u/4/X7R/16V/K

NV_CLE

DMI /FDI termination voltage

Title

Size Document Number Rev

Custom

2

Date: Sheet

Gigabyte Technology

PCH FDI,DMI,USB ,PCIE

GA-H77-DS3H

1

935Tuesday, February 21, 2012

1.0

of

Gigabyte Confidential

Do not Copy

5

4

3

2

1

33 OHM

PCHF

DVI_HDP_F

DVI_TX2
DVI_TX2­DVI_TX1
DVI_TX1­DVI_TX0
DVI_TX0­DVI_TXC
DVI_TXC-

U14
U12

R14
R12
M11
M12

T1
N2
M1

R8
R9

N6
R6

H8
K8

L5

M3

L2

J3
G2
G4
F3
F5
E4
E2
D5
B5
C6
D7
B7
C9

E11
B11

U2
T3

W3

U5
U8

U9

DDPB_HPD
DDPC_HPD
DDPD_HPD

DDPB_AUXP
DDPB_AUXN
DDPC_AUXP
DDPC_AUXN
DDPD_AUXP
DDPD_AUXN

DDPB_0P
DDPB_0N
DDPB_1P
DDPB_1N
DDPB_2P
DDPB_2N
DDPB_3P
DDPB_3N
DDPC_0P
DDPC_0N
DDPC_1P
DDPC_1N
DDPC_2P
DDPC_2N
DDPC_3P
DDPC_3N
DDPD_0P
DDPD_0N
DDPD_1P
DDPD_1N
DDPD_2P
DDPD_2N
DDPD_3P
DDPD_3N

SDVO_INTP
SDVO_INTN

SDVO_STALLP
SDVO_STALLN

SDVO_TVCLKINP
SDVO_TVCLKINN

CRT_HSYNC
CRT_VSYNC

CRT_GREEN

CRT_DDC_DATA

CRT_DDC_CLK

DDPC_CTRLCLK

DDPC_CTRLDATA

DDPD_CTRLCLK

DDPD_CTRLDATA

SDVO_CTRLCLK

SDVO_CTRLDATA

6 OF 11

BD82H77/S

CRT_RED

CRT_BLUE

CRT_IRTN

DAC_IREF

D D

C C

DVI_HDP_F[34]
HDMI_HDP_F[34]

DVI_TX2[34]

DVI_TX2-[34]

DVI_TX1[34]

DVI_TX1-[34]

DVI_TX0[34]

DVI_TX0-[34]

DVI_TXC[34]

DVI:15/4/6/4/15
(breakout
8/4/4/4/8)

DVI_TXC-[34]

HDMI_TX2[34]

HDMI_TX2-[34]

HDMI_TX1[34]

HDMI_TX1-[34]

HDMI_TX0[34]
HDMI_TX0-[34]
HDMI_TXC[34]

HDMI_TXC-[34]

close PCH
<750mils

H_SYNC

AR4

V_SYNC

AR2
AN6

AN2
AM1

AM6

DDCDATA

AW1

DDCCLK

AW3

VGA_RSET

AT3

Pop 0/4 for non graphic skus

DAC_IREF:4/12

Y18

TP6

Y17

TP7

AB18

TP8

AB17

TP9

AL12
AL14

DDPD_CTRLCLK

AL9

DDPD_CTRLDATA

AL8

DDPB_CTRLCLK

AL15

DDPB_CTRLDATA

AL17

R
G
B

VGA DDC

R744

2.2K/4/1

GS

D

3

VCCVCC3

R745

2.2K/4/1

VGADDCDATA

VGADDCCLK GHSYNC

B B

Q2

R741

2N7002/SOT23/25pF/5

R314

2.2K/4/1

DDCDATA

DDCCLK

R294

2.2K/4/1

VCC

1K/4/1

GS

2
1

SOT23

VCC

D

R746
1K/4/1

3

Q3
2N7002/SOT23/25pF/5

2
1

SOT23

VGA DDC

R

A A

B

R743

R742

75/4/1

75/4/1

R740

Close to Filter

75/4/1

5

FB7 60/6/3A/S
FB8 60/6/3A/S
FB9 60/6/3A/S

C223

C219

C222
10p/4/NPO/50V/J
10p/4/NPO/50V/J
10p/4/NPO/50V/J

C226

C225

22p/4/NPO/50V/J
22p/4/NPO/50V/J
22p/4/NPO/50V/J

SYNC:4/10
(breakout 4/6)

GHSYNC

R212 33/4

GVSYNC

R213 33/4

RGB:4/20 (breakout

7.5/10)

DDC:4/5

R315 1K/4/1

DDPD_CTRLCLK [34]
DDPD_CTRLDATA [34]

DDPB_CTRLCLK [34]
DDPB_CTRLDATA [34]

GVSYNC

VGA_R
VGA_GG
VGA_B

C227

4

Flex0,2 : 33MHZ
Flex1,3 :

27/14/24/48/25MHZ

PCHCLK14

25M/20p/30ppm/49US/20/D

C107

27p/4/NPO/50V/J

C224
100p/4/NPO/50V/J

C221
100p/4/NPO/50V/J

TPMCLK[18]

LPC33[17]
PCH33[11]

LPCCLK48[17]

VCC1_05_PCH

R231 8.2K/4/X

XTALI_PCH

X2

XTALO_PCH

R716 33/4
R286 33/4
R313 33/4

R262 33/4

R316 90.9/4/1

PCHCLK14[29]

R282
1M/4

C106

27p/4/NPO/50V/J

PCHCLK14

PCH_48M

CLK_RCOMP

XTALO_PCH
XTALI_PCH

AT11

CLKOUT_PCI0

AN14

CLKOUT_PCI1

AT12

CLKOUT_PCI2

AT17

CLKOUT_PCI3

AT14

CLKOUT_PCI4

AT9

CLKOUTFLEX0/GPIO64

BA5

CLKOUTFLEX1/GPIO65

AW5

CLKOUTFLEX2/GPIO66

BA2

CLKOUTFLEX3/GPIO67

AL2

XCLK_RCOMP

AN8

REFCLK14IN

AJ5

XTAL25_OUT

AJ3

XTAL25_IN

8 OF 11

VGA CONNECTOR VGA ESD

FUSEVCC_R10

GHSYNC

BC271

0.1u/4/X7R/16V/K/X

1617

VGA

VGA_R
VGA_G
VGA_B

6
1
7
2
8
3
9
4

10

5

VGA/BU/SC/RA/D/2/HR

3

11
12
13
14
15

VGADDCDATA
GHSYNC
GVSYNC
VGADDCCLK

R

PCHH

CLKIN_GND1_N
CLKIN_GND1_P

CLKIN_GND0_N
CLKIN_GND0_P

CLKOUT_ITPXDP_N
CLKOUT_ITPXDP_P

CLKOUT_PCIE7N
CLKOUT_PCIE7P

CLKOUT_DMI_N
CLKOUT_DMI_P

CLKOUT_DP_N
CLKOUT_DP_P

CLKOUT_PCIE0N
CLKOUT_PCIE0P

CLKOUT_PCIE1N
CLKOUT_PCIE1P

CLKOUT_PCIE2N
CLKOUT_PCIE2P

CLKOUT_PCIE3N
CLKOUT_PCIE3P

CLKOUT_PCIE4N
CLKOUT_PCIE4P

CLKOUT_PCIE5N
CLKOUT_PCIE5P

CLKOUT_PCIE6N
CLKOUT_PCIE6P

CLKOUT_PEG_A_N

CLKOUT_PEG_A_P

CLKOUT_PEG_B_N

CLKOUT_PEG_B_P

BD82H77/S

ESD14

1
2
3 4

AZC009-04S/SOT23-6L

SSOP6_ESD

ESD15

1
2
3 4

AZC009-04S/SOT23-6L

2

-PCHCLK

R27

PCHCLK

P27

-CLK_GND

W53

CLK_GND

V52
R52

N52
AE2

AF1
P31

R31
N56

120Mhz for DP

M55
AE6

AC6
AA5

W5
AB12

AB14
AB9

AB8
Y9

Y8
AF3

AG2
AB3

AA2
AG8

AG9
AE12

AE11

Differential Clock:18/6/4/6/18
Impedance=90 +- 15%

VGADDCCLKGVSYNC

6
5

VGADDCDATA

B

6
5

G

VCC3

VCC

Title

Size Document Number Rev

Custom

Date: Sheet

-PCHCLK

R254 8.2K/4

PCHCLK

R250 8.2K/4

-CLK_GND

R402 8.2K/4

CLK_GND

R403 8.2K/4

-PCIE_CLK1 [15]
PCIE_CLK1 [15]

-CPUCLK [4]
CPUCLK [4]

-PCIE_CLK2 [15]
PCIE_CLK2 [15]

LA_-SRCCLK_LAN [31]
LA_SRCCLK_LAN [31]

-SRCCLK_3GIO1 [15]
SRCCLK_3GIO1 [15]

G_-PBCLK [35]
G_PBCLK [35]

-SRCCLK_3GIO [14]
SRCCLK_3GIO [14]

Gigabyte Technology

PCH DISPLAY ,CLK BUFFER

GA-H77-DS3H

1

10 35Tuesday, February 21, 2012

1.0

of

Gigabyte Confidential

Do not Copy

PWROK1[12,17,29]

GPIO17
GPIO1
GPIO6

-CPU_HOT
GPIO68

GPIO70
GPIO71

GPIO22
GPIO38
GPIO39
GPIO48

GPIO70
GPIO6

GPIO17
GPIO1

-PIRQG
GPIO71
GPIO68

-CPU_HOT

5

PCHC

SATA0RXN
SATA0RXP

For WIFI

BA50

CL_CLK1

BF50

CL_DATA1

BF49

CL_RST1#

BC46

APWROK

BN21

PWM0

BT21

PWM1

BM20

PWM2

BN19

PWM3

BT17

TACH0/GPIO17

BR19

TACH1/GPIO1

BA22

TACH2/GPIO6

BR16

TACH3/GPIO7

BU16

TACH4_GPIO68

BM18

TACH5_GPIO69

BN17

TACH6_GPIO70

BP15

TACH7_GPIO71

BC43

SST

BA53

SCLOCK/GPIO22

BE54

SLOAD/GPIO38

BF55

SDATAOUT0/GPIO39

AW53

SDATAOUT1/GPIO48

AY20

NC_5

-CPU_HOT [24]

3 OF 11

SATA0TXPC

C1480.01u/4/X7R/25V/K

SATA0TXNC

C1450.01u/4/X7R/25V/K

SATA0RXNC

C1400.01u/4/X7R/25V/K C1710.01u/4/X7R/25V/K

SATA0RXPC

C1360.01u/4/X7R/25V/K

SATA2/7/WH/H/OP/VA/D/1/B/PA66

1
2
3
4
5
6
7

CLINK

FANGPIO

SATA3_0

GND
T+
T­GND
R­R+
GND

SATA0TXN

SATA0TXP
SATA1RXN
SATA1RXP
SATA1TXN

SATA3

SATA1TXP

SATA2RXN
SATA2RXP
SATA2TXN

SATA2TXP
SATA3RXN

SATA2

SATA3RXP
SATA3TXN

SATA3TXP
SATA4RXN
SATA4RXP
SATA4TXN

SATA4TXP
SATA5RXN
SATA5RXP
SATA5TXN

SATA5TXP

CLKIN_SATA_N
CLKIN_SATA_P

SATALED#

SATAICOMPI

SATAICOMPO

SATA0GP/GPIO21
SATA1GP/GPIO19
SATA2GP/GPIO36
SATA3GP/GPIO37
SATA4GP/GPIO16
SATA5GP/GPIO49

SATA3COMPI

SATA3RCOMPO

SATA3RBIAS

A20GATE

INIT3_3V#

HOST

THRMTRIP#

PMSYNCH

BD82H77/S

SATA3 : 20/7.5/4.5/7.5/20 (breakout min 8/4/4/4/8)
Impedance=90 +- 17.5%

SATA2 : 15/7.5/4.5/7.5/15 (breakout min 8/4/4/4/8)
Impedance=90 +- 17.5%

D D

SSTCTL[17]

C C

VCC3

RN13

8.2K/8P4R/4

1 2
3 4
5 6
7 8

1 2
3 4
5 6

B B

7 8

RN12

8.2K/8P4R/4

White connector for SATA3

SATA0TXP
SATA0TXN

SATA0RXN
SATA0RXP

TP16

RCIN#

SERIRQ

PECI

4

AC56
AB55
AE46
AE44
AA53
AA56
AG49
AG47

AL50
AL49
AL56
AL53
AN46
AN44
AN56
AM55
AN49
AN50
AT50
AT49
AT46
AT44
AV50
AV49

AF55
AG56

BF57
AJ55
AJ53

BC54
AY52
BB55
BG53
AU56
BA56

AE54
AE52

AE50
AC52

BB57
BN56
BG56
AV52
E56
H48
F55

SATA0RXN
SATA0RXP
SATA0TXN
SATA0TXP
SATA1RXN
SATA1RXP
SATA1TXN
SATA1TXP

SATA2RXN
SATA2RXP
SATA2TXN
SATA2TXP
SATA3RXN
SATA3RXP
SATA3TXN

A3TXP

SAT
SATA4RXN
SATA4RXP
SATA4TXN
SATA4TXP
SATA5RXN
SATA5RXP
SATA5TXN
SATA5TXP

-SRCCLK_SATA
SRCCLK_SATA

-SATALED [28]

SATACOMP
GPIO21

GPIO19

GPIO16
TEMP_ALART-

SATA3COMP

SATA3BIAS

A20GATE

-KBRST
SERIRQ

-THRMTRIP
SB_PECI

SATA5RXN [32]
SATA5RXP [32]
SATA5TXN [32]
SATA5TXP [32]

-SRCCLK_SATA [29]
SRCCLK_SATA [29]

R390 37.4/4/1

W=4 mil out of PCH
S=15 mil out of PCH

R391 49.9/4/1

R392 750/4/1

A20GATE [17]

-KBRST [17]

SERIRQ [17,18]

-THRMTRIP [4]

R377 0/4/X

PMSYNC [4]

SRCCLK_SATA

-SRCCLK_SATA

MB-ID

R331 8.2K/4/X
R468 8.2K/4/X

R436 1K/4/1/X

TEMP_ALART-[17]

GPIO0[12]

VCC1_05_PCH

GPIO20[12]

R447 1K/4/1/X

VCC1_05_PCH

W=4 mil out of PCH
S=15 mil out of PCH

PECI

PECI [4,17]

3

R265 8.2K/4/X
R266 8.2K/4/X

GPIO17
GPIO19

GPIO22

-KBRST

RN16 8.2K/8P4R/4

GPIO19
TEMP_ALART-

GPIO22

A20GATE

GPIO16
SERIRQ
GPIO48

GPIO0

RN17 8.2K/8P4R/4

GPIO21
GPIO38
GPIO39
GPIO20

RN18 8.2K/8P4R/4

GPIO20

SATA3TXP
SATA3TXN

SATA3RXN
SATA3RXP

R401 1K/4/1

1 2
3 4
5 6
7 8

1 2
3 4
5 6
7 8

1 2
3 4
5 6
7 8

VCC3

VCC3

2

PCHA

BH8

BD15

AV14
BF11
AV15

BC12

BA17

BC11

BA15

BU12

AV11

BK10

BM15

BT15

SATA2_3

GND
T+
T­GND
R­R+
GND

BH9

BR6

BC8

BM3

AV8
BE2

BG5
BT5
BK8

BP5
BN9
AV9

BR4

PAR
DEVSEL#
CLKIN_PCILOOPBACK
PCIRST#
IRDY#
PME#
SERR#
STOP#
PLOCK#
TRDY#
PERR#
FRAME#

GNT0#
GNT1#/GPIO51
GNT2#/GPIO53
GNT3#/GPIO55

REQ0#
REQ1#/GPIO50
REQ2#/GPIO52
REQ3#/GPIO54

PIRQA#

BJ5

PIRQB#
PIRQC#
PIRQD#
PIRQE#/GPIO2
PIRQF#/GPIO3
PIRQG#/GPIO4
PIRQH#/GPIO5

PCI

BD82H77/S

1 OF 11

AD0
AD1
AD2
AD3
AD4
AD5
AD6
AD7
AD8

AD9
AD10
AD11
AD12
AD13
AD14
AD15
AD16
AD17
AD18
AD19
AD20
AD21
AD22
AD23
AD24
AD25
AD26
AD27
AD28
AD29
AD30
AD31

C/BE0#
C/BE1#
C/BE2#
C/BE3#

BF15
BF17
BT7
BT13
BG12
BN11
BJ12
BU9
BR12
BJ3
BR9
BJ10
BM8
BF3
BN2
BE4
BE6
BG15
BC6
BT11
BA14
BL2
BC4
BL4
BC2
BM13
BA9
BF9
BA8
BF8
AV17
BK12

BN4
BP7
BG2
BP13

-DEVSEL
PCH33

PCH33[10]

-IRDY

TP1

-SERR

-STOP

-PLOCK

-TRDY

-PERR

-FRAME

-GNT0[19]

-GNT1[19]

C1780.01u/4/X7R/25V/K

SATA3TXPC

C1770.01u/4/X7R/25V/K

SATA3TXNC

C1740.01u/4/X7R/25V/K

SATA3RXNC
SATA3RXPC

-GNT0

-GNT1

-REQ0

-REQ1

-REQ2

-REQ3

-PIRQA

-PIRQB

-PIRQC

-PIRQD

-PIRQE

-PIRQF

-PIRQG

-PIRQH

1
2
3
4
5
6
7

SATA2/7/BU/H/OP/VA/D/1/B/PA66

1

-DEVSEL

-IRDY

-FRAME

-STOP

-PERR

-PIRQB

-REQ0

-SERR

-REQ1

-PIRQD

-PIRQH

-PIRQC

-PIRQA

-PIRQE

-REQ2

-PIRQF

-REQ3

-TRDY

-PLOCK

RN21

8.2K/8P4R/4

1 2
3 4
5 6
7 8

RN22

8.2K/8P4R/4

1 2
3 4
5 6
7 8

RN23

8.2K/8P4R/4

1 2
3 4
5 6
7 8

RN24

8.2K/8P4R/4

1 2
3 4
5 6
7 8

RN25

8.2K/8P4R/4

1 2
3 4
5 6
7 8

VCC3

A A

SATA1TXP
SATA1TXN

SATA1RXN
SATA1RXP

5

SATA1TXPC

C2280.01u/4/X7R/25V/K

SATA1TXNC

C2290.01u/4/X7R/25V/K

SATA1RXNC

C2300.01u/4/X7R/25V/K

SATA1RXPC

C2310.01u/4/X7R/25V/K

SATA2/7/WH/H/OP/VA/D/1/B/PA66

SATA3_1

1

GND

2

T+

3

T-

4

GND

5

R-

6

R+

7

GND

SATA2TXP
SATA2TXN

SATA2RXN
SATA2RXP

4

C147 0.01u/4/X7R/25V/K
C144 0.01u/4/X7R/25V/K

C139 0.01u/4/X7R/25V/K
C135 0.01u/4/X7R/25V/K

SATA2TXPC
SATA2TXNC

SATA2RXNC
SATA2RXPC

SATA2_2

1

GND

2

T+

3

T-

4

GND

5

R-

6

R+

7

GND

SATA2/7/BU/H/OP/VA/D/1/B/PA66

3

SATA4TXP
SATA4TXN

SATA4RXN
SATA4RXP

C146 0.01u/4/X7R/25V/K
C143 0.01u/4/X7R/25V/K

C138 0.01u/4/X7R/25V/K
C134 0.01u/4/X7R/25V/K

SATA4TXPC
SATA4TXNC

SATA4RXNC
SATA4RXPC

SATA2/7/BU/H/OP/VA/D/1/B/PA66

SATA2_4

1
2
3
4
5
6
7

GND
T+
T­GND
R­R+
GND

Title

Size Document Number Rev

B

2

Date: Sheet

Gigabyte Technology

PCH HOST , SATA, PCI

GA-H77-DS3H

1

1.0

of

11 35Tuesday, February 21, 2012

Gigabyte Confidential

Do not Copy

5

3VDUAL

D D

1 2
3 4
5 6
7 8

1 2
3 4
5 6
7 8

R378 1K/4/1 R675 0/4/X
R379 1K/4/1

GPIO27

GPIO11
SML0DAT
SML1DAT
SML0CLK

-RI
SML1CLK

-PCH_HOT
GPIO60

SMBCLK
SMBDATA

R606 8.2K/4

3VDUAL_PCH

RN15

2.2K/8P4R/4

RN14

8.2K/8P4R/4

R605

ACZ_SDOUT

8.2K/4

Q87

SOT23

132

PMBT2907A/SOT23/-600mA/50

ICH_SPI_MOSI[19]
ICH_SPI_MISO[19] -PFMRST [17]

-ICH_SPI_CS[19]

ICH_SPI_CLK[19]

ACZ_SDOUT : Hi --> Disable ME
GPIO15 : Hi --> Enable TLS

GPIO15 : Lo --> Disable

C C

B B

3VDUAL_PCH

TLS

-SRTCRST

C111
1u/4/X5R/6.3V/K

R413 75K/4/1
R412 27K/4/1

C122 1u/4/X5R/6.3V/K

R360 20K/4/1

3VDUAL_PCH

5VSB

D

R395

GS

22K/4

2

SOT23

132

At least 10ms delay after
3VDUAL_PCH stabel

Q32

MMBT2222A/SOT23/600mA/40

RTCVDD [13,28]

R414

8.2K/4

PCH_DPWROK

3

SOT23

1

Q31
2N7002/SOT23/25pF/5

C112
1n/4/X7R/50V/K

ACZ_SDOUT[20]

ACZ_SYNC[20]

VCC3

4

VCC3

LAD0[17,18]
LAD1[17,18]
LAD2[17,18]
LAD3[17,18]

-LDRQ0[17]

-LFRAME[17,18]

ACZ_BITCLK[20]

-ACZ_RST[20]

ACZ_SDIN2[20]

R457 8.2K/4

GPIO11[28]

SMBCLK[7,8,14,15,16,25,29]

SMBDATA[7,8,14,15,16,25,29]

3

PCHD

BMBUSY#_GPIO0

R326 8.2K/4/X

R338 33/4
R336 33/4

GPIO23

BA20

LAD0
LAD1
LAD2
LAD3

-LDRQ0

-LFRAME -LPCPME

R332 33/4
R330 33/4

A_SO

Y2

-RTCRST

-SRTCRST
PCH_DPWROK
DSWVRMEN

GPIO11
SMBCLK
SMBDATA
GPIO60
SML0CLK
SML0DAT

-PCH_HOT

SML1CLK
SML1DAT

LDRQ1#/GPIO23

BK15

FWH0/LAD0

BJ17

FWH1/LAD1

BJ20

FWH2/LAD2

BG20

FWH3/LAD3

BK17

LDRQ0#

BG17

FWH4/LFRAME#

BU22

HDA_BCLK

BC22

HDA_RST#

BD22

HDA_SDIN0

BF22

HDA_SDIN1

BK22

HDA_SDIN2

BJ22

HDA_SDIN3

BT23

HDA_SDO

BP23

HDA_SYNC

AU53

SPI_MOSI

AT55

SPI_MISO

AT57

SPI_CS0#

AR54

SPI_CLK

AR56

SPI_CS1#

BR39

RTCX1

BN39

RTCX2

BT41

RTCRST#

BN37

SRTCRST#

BT37

DPWROK

BR42

DSWVRMEN

BN49

SMBALERT#/GPIO11

BT47

SMBCLK

BR49

SMBDATA

BU49

SML0ALERT#/GPIO60

BT51

SML0CLK

BM50

SML0DATA

BR46

SML1ALERT#_PCHHOT#_GPIO74

BJ46

SML1CLK/GPIO58

BK46

SML1DATA/GPIO75

LPC

AUDIO RTC

SPI

SUSWARN#_SUSPWRDNACK/GPIO30

SMB

CLKRUN#_GPIO32

HDA_DOCK_EN#_GPIO33

STP_PCI#_GPIO34

GPIO35

LAN_PHY_PWR_CTRL_GPIO12

HDA_DOCK_RST#_GPIO13

PCIECLKRQ2#_GPIO20
PCIECLKRQ5#_GPIO44
PCIECLKRQ6#_GPIO45
PCIECLKRQ7#_GPIO46

SUS_STAT#_GPIO61

4 OF 11

GPIO15

GPIO24_MEM_LED

GPIO28

SLP_LAN#_GPIO29

GPIO57

SYS_PWROK

PLTRST#

WAKE#

SLP_A#
SLP_S3#
SLP_S4#

SLP_S5#_GPIO63
SUSCLK_GPIO62

BATLOW#_GPIO72

SUSACK#

DRAMPWROK

GPIO27
GPIO31

SLP_SUS#

PWRBTN#

SYS_RESET#

PROCPWRGD

JTAG_TCK

JTAG_TDI
JTAG_TDO
JTAG_TMS

INTVRMEN

RSMRST#

PWROK

INTRUDER#

BD82H77/S

GPIO8

SPKR

TP12

2

GPIO0

AW55
BC56
BC25

-PCI_STOP

BL56

-ACZ_DET

BJ57

-IGC_EN

BP51
BK50
BA25

GPIO15

BM55
BP53

GPIO28

BJ55

-SLP_LAN

BH49

GPIO20

AV43

GPIO44

BL54

GPIO45

AV44

GPIO46

BP55

GPIO57A_SYC

BT53
BJ53
BJ48

RI#

BK48
BC44
BC41
BM53
BN52

BH50

-SUSTAT

BN54

SUSCLK

BA47

GPIO72

AV46
BP45

-S_WARN

BU46

DRAM_PWROKY1

BG46

GPIO27

BJ43

GPIO31

BG43
BD43
BT43

-SYS_RST

BE52

SPKR

BE56

CPUPWROK

D53

PCH_RST

BC49

PCH_TCK

BA43

PCH_TDI

BC52

PCH_TDO

BF47

PCH_TMS

BC50

INTVRMEN

BN41

-RSMRST

BK38

PWROK1

BJ38

R365 1M/4

BM38

GPIO0 [11]

-ACZ_DET [21]

-LPCPME [17]

GPIO28 [28]
GPIO20 [11]

N_PCH_VRMPWRGD [22]

-RI [18]

-PCIE_WAKE [14,15,16,31]

-SLP_S3 [17,24,33]

-S4_S5 [17,33]

SUSCLK [18]

-DEPSLP [24]
PWRBTSW [17]

-SYS_RST [28,29]
SPKR [28]

CPUPWROK [4,24]

-RSMRST [17,24]
PWROK1 [11,17,29]
RTCVDD [13,28]

GP28:Lo disable
VRM ,Hi enable
VRM

-SKTOCC [4]

GP15:Low to Disable TLS,
Hi to Enable TLS

-SPI_WP1 [19]

-SPI_WP0 [19]

GP8:Low to enable
PCH clock chip

R397 1K/4/1/X

R432 8.2K/4/X
R448 8.2K/4/X
R475 8.2K/4/X

R464 8.2K/4/X

R607 8.2K/4/X

-LPCPME

GPIO28

-SLP_LAN

-SUSTAT
SUSCLK

-PCIE_WAKE

-PCI_STOP

-ACZ_DET

-SYS_RST

PCH_RST
PCH_TDI
PCH_TDO
PCH_TMS

PCH_TDI
PCH_TDO
PCH_TMS
PCH_TCK

-IGC_EN

GPIO72
GPIO44
GPIO45
GPIO15

GPIO46

-SKTOCC
GPIO57

-S_WARN
GPIO27
GPIO31

1

R340 8.2K/4
R426 8.2K/4/X

R451 1K/4/1
R417 8.2K/4/X

1 2
3 4
5 6
7 8

1 2
3 4
5 6
7 8

R431 8.2K/4/X
R466 8.2K/4/X

R428 1K/4/1

3VDUAL_PCH

R380 8.2K/4
R608 8.2K/4
R385 8.2K/4

R399 8.2K/4
R400 8.2K/4
R427 1K/4/1

R459 20K/4/1
R473 200/4/1
R410 200/4/1
R460 200/4/1

R471 100/4/1
R396 100/4/1
R445 100/4/1
R446 51/4/1

3VDUAL

VCC3

3VDUAL

RN20

8.2K/8P4R/4

RN19

8.2K/8P4R/4

BATTERY-DUAL-4

X3-SHT
SHW/D0.64*5.08*6.74

Y1
Y2

A A

32.768K/12.5p/20ppm/TF38/35K/D
C117

18P/4/NPO/50V/J

R38110M/4

X3

BAT-SK/BK/P/S/D/SN

3 4

C118

18P/4/NPO/50V/J

5

12

BAT

PH/1*2/BK/2.54/VA/D

CLR_CMOS

BATTERY
CR2032

CR2032

+

3VDUAL_PCH

VBATT

RB

4

BAS40-05/0.2A/SOT23

RB 1K/4/1

必須放在

2
1

D8

BAT

VBAT

-RTCRST

R369 390K/4

R368 390K/4
R364 20K/4/1

3

C110
1u/4/X5R/6.3V/K

外

VBAT [17]

DSWVRMEN
RTCVDD
INTVRMEN

-RTCRST

C113
1u/4/X5R/6.3V/K

3

RTCVDD [13,28]

DDR_15V

R382
1K/4/1

DRAM_PWROK

R383
3K/4/1/X

DRAM_PWROK [4]

2

Title

Size Document Number Rev

B

Date: Sheet

Gigabyte Technology

PCH GPIO , CTRL , AUDIO

GA-H77-DS3H

1

of

12 35Tuesday, February 21, 2012

1.0

Gigabyte Confidential

Do not Copy

5

AA34
AA36

AL40
AN40
AN41
AG38
AG40
AG41

BA38

BC174
1u/4/X5R/6.3V/K

BC137
1u/4/X5R/6.3V/K

F20
F30
V25
V27
V31
V33
Y24
Y26
Y30
Y32
Y34

V22
Y20
Y22

B41
E41

U56
B53
C54
AL5
A19

VCC1_05_PCH

BC235

D D

VCC1_05_ME VCC3

BC232

1u/4/X5R/6.3V/K/X

C C

B B

BC126

1u/4/X5R/6.3V/K

BC129

1u/4/X5R/6.3V/K

DMI_PLL_PCH

1u/4/X5R/6.3V/K/X

BC133

BC182
1u/4/X5R/6.3V/K/X
1u/4/X5R/6.3V/K

BC179
1u/4/X5R/6.3V/K/X

BC172
1u/4/X5R/6.3V/K

VCC1_05_PCH

1u/4/X5R/6.3V/K

1u/4/X5R/6.3V/K

1u/4/X5R/6.3V/K

CPU_VTT

BC165

BC166
1u/4/X5R/6.3V/K
1u/4/X5R/6.3V/K

VCC1_05_PCH

1u/4/X5R/6.3V/K/X

IPL_PLL_PCHSATA_PLL_PCH

CLK_PLL_PCH

BC145

BC146

BC147

BC234

BC152

1u/4/X5R/6.3V/K

VCC1_05_PCH

SATA_PLL_PCH
DMI_PLL_PCH
IPL_PLL_PCH
CLK_PLL_PCH
USB3_PLL_PCH

PCHI

VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO

VCCIO
VCCIO
VCCIO
VCCIO
VCCIO

VCCDMI_02
VCCDMI_01

VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO

VCCDIFFCLKN_01
VCCDIFFCLKN_02
VCCDIFFCLKN_03

VCCIO
VCCAPLLSATA

VCCAPLLEXP
VCCAFDIPLL
VCCACLK
VCCAPLLDMI2

BD82H77/S

USB3_PLL_PCH

VCC_PCH_SRC

4

9 OF 11

VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE

VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW
VCCASW

VCCASW
VCCASW
VCCASW

VCCCLKDMI

VCCIO
VCCSSC_01
VCCSSC_02

VCCIO

VCCIO

VCCIO

VCCIO

VCCIO

VCCIO

VCCIO

VCCIO

VCC1_05_PCH

AC24
AC26
AC28
AC30
AC32
AE24
AE28
AE30
AE32
AE34
AE36
AG32
AG34
AJ32
AJ34
AJ36
AL32
AL34
AN32
AN34
AR32
AR34

AG24
AG26
AG28
AJ24
AJ26
AJ28
AL24
AL28
AN22
AN24
AN26
AN28
AR24
AR26
AR28
AR30
AR36
AR38
AU30
AU36

AU34
AV36
AU32

AE15
AE17
AG15
AJ20
AE40
AC20
AE20

AV24
AV26
AY25
AY27

V36
Y36
AJ38
Y28

BC140
1u/4/X5R/6.3V/K

BC135
1u/4/X5R/6.3V/K

BC155
1u/4/X5R/6.3V/K

BC156
1u/4/X5R/6.3V/K

BC154
1u/4/X5R/6.3V/K

VCC1_05_ME

BC127
1u/4/X5R/6.3V/K

BC128
1u/4/X5R/6.3V/K

VCC1_05_PCH

VCC_PCH_SRC

Need isolation

VCC1_05_PCH

3VDUAL 5VDUAL

SOT23

132

Q28
MMBT2222A/SOT23/600mA/40

FB6 0/6/SHT/M/X

VCC1_05_PCH

VCC1_05_PCH

3

VCC3

R349
100/4/1

Q24
MMBT2222A/SOT23/600mA/40

BC143
1u/4/X5R/6.3V/K

5VDUAL

BC150
1u/4/X5R/6.3V/K

NL3 0/6/SHT/M/X
NL4 0/6/SHT/M/X

CLOSE北橋(

V5REF_SUS

3VDUAL

VCC3

VCC3_ME

VCC3

VCC3_DAC

VCCA_DPLLA
VCCA_DPLLB

VCC

V5REF

BC189

0.1u/4/X7R/16V/K

BC153
1u/4/X5R/6.3V/K
BC125
1u/4/X5R/6.3V/K

C108

0.1u/4/X7R/16V/K

SOT23

132

注意震盪水波紋

D

R173

GS

8.2K/4

2

Q23

2N7002/SOT23/25pF/5

3

1

+12V

(3.3V/70mA+360uA)

R283
100/4/1

BT25
AV28

AU20
AV20
AU22

AN52

VCC3_DAC3VDUAL

BF1

AT1

AB1
AC2

PCHJ

V5REF
V5REF_SUS
VCCSUSHDA

VCC3_3
VCC3_3
VCC3_3

VCCSPI

VCCADAC

VCCADPLLA
VCCADPLLB

10 OF 11

)

VCC3_DAC

NBC75
10u/8/X5R/6.3V/K

VCCVRM_1
VCCVRM_4
VCCVRM_3
VCCVRM_2

VCCPNAND
VCCPNAND

VCCSUS3_3
VCCSUS3_3

VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3

VCCSUS3_3
VCCSUS3_3

VCCSUS3_3

VCCDSW3_3

V_PROC_IO

V_PROC_IO_NCTF

DCPSUS_03
DCPSUS_01

DCPRTC_NCTF

DCPSUS_02

DCPSUSBYP

BD82H77/S

NBC5
1u/4/X5R/6.3V/K

VCC3_3
VCC3_3

VCC3_3
VCC3_3
VCC3_3

VCC3_3
VCC3_3

VCCRTC
DCPRTC

DCPSST

2

BC138 1u/4/X5R/6.3V/K
R299 0/4/SHT/M/X
BC131

R284 0/4/SHT/M/X

AJ1
R2
R54
R56

NV_PCH

T55
T57

AL38
AN38

BC17
BD17
BD20

A12
AF57

BT35
AV30

AV32
AY31
AY33
BJ36
BK36
BM36

AT40
AU38

U31

AV40

BC191

0.1u/4/X7R/16V/K

D55
B56

A39
AA32

BU42
BR54
BT56

AT41
AV41

BA46

0.1u/4/X7R/16V/K/X

V_1P5_RTC_INT

1u/4/X5R/6.3V/K

BC181 1u/4/X5R/6.3V/K

R406 0/4/SHT/M/X

R405 0/4/SHT/M/X

BC180 1u/4/X5R/6.3V/K

BC132

BC183

10u/8/X5R/6.3V/K/X

3VDUAL

Need isolation

C109

0.1u/4/X7R/16V/K

3VDUAL_PCH

CPU_VTT

BC176
1u/4/X5R/6.3V/K

V_1P1_USB

V_1P5_RTC_INT

V_1P5_INT

SC1

BC184

0.1u/4/X7R/16V/K

V_1P5_INT

VCC1_8_PCH

VCC1_8_PCH

VCC1_8_PCH

VCC3

1u/4/X5R/6.3V/K

BC187

1u/4/X5R/6.3V/K

BC185
1u/4/X5R/6.3V/K

BC238

0.1u/4/X7R/16V/K

VCC1_8_PCH

3VDUAL_PCH

BC163
1u/4/X5R/6.3V/K

0.1u/4/X7R/16V/K

4

V_1P1_USB

VCC3_ME

BC161

Q84
L1117LG/N/SOT223/1A

3
2
1

RTCVDD [12,28]

BC162

0.1u/4/X7R/16V/K

BC160
1u/4/X5R/6.3V/K

R617
301/4/1

R609
510/4/1

1

VCC3

VCC1_05_PCHVCC1_05_ME

3VDUAL_PCH

BC229
22u/8/X5R/6.3V/M

5VSB

BC228
1u/4/X5R/6.3V/K

A26

A29

A42

A49A9AA20

AA22

AA24

AA26

AA28

AA30

AA38

AB11

AB15

AB40

AB41

AB43

AB47

AB52

AB57

AB6

AC22

AC34

AC36

AC38

AC4

AC54

AE14

AE18

AE22

AE26

AE38

AE4

AE47

AE8

AE9

AF52

AF6

AG11

AG14

AG20

AG22

AG30

AG36

AG43

AG44

AG46

AG5

AG50

AG53

AH52

AH6

AJ22

AJ30

AJ57

AK52

AK6

AL11

AL18

AL20

AL22

AL26

AL30

AL36

AL41

AL46

AL47

AM52

AM3

AM57

AN11

AN12

AN15

AN17

AN18

AN20

AN30

AN36

AN4

AN43

AN47

AN54

AN9

AR20

AR22

AR52

AR6

AT15

AT18

AT43

AT47

AT52

AT6

AT8

AU24

AU26

AU28

AU5

AV12

BA49

BB1

BB3

BB52

BB6

BC14

M33

M36

M46

M52

M57M6M8M9N4

N54

R11

R15

R17

R22R4R41

R43

R46

R49

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

A A

BC15

BC20

BC27

BC31

BC36

BC38

BC47

BC9

BD25

BD33

BF12

BF20

BF25

BF33

BF41

BF43

BF46

BF52

BF6

BG22

BG25

BG27

BG31

BG33

BG36

BG38

BH52

BH6

BJ1

BJ15

BK20

BK41

BK52

BK6

BM10

BM12

BM16

BM22

BM23

BM26

BM28

BM32

BM40

BM42

BM48

BM5

BN31

BN47

BN6

BP3

BP33

BP35

BR22

BR52

BU19

BU26

BU29

BU36

BU39

C19

C32

C39C4D15

D23D3D35

D43

D45

E19

E39

E54E6E9

F10

F12

F16

F22

PCHK BD82H77/S

5

4

F26

F32

F33

F35

F36

F40

F42

F46

F48

F50F8AV18

AV22

AV34

AV38

AV47

AV6

AW57

AY38

AY6

B23

BA11

BA12

BA31

BA41

BA44

G54

H15

H20

H22

H25

H27

H33H6J1

J33

J46

3

J48J5J53

K52K6K9

VSS

L12

L17

L38

2

P22

BA36

AY36

Y14

Y12

AE49

L33

TP3

VSS

TP17

TP18

TP13

VSS

VSS

VSS

VSS

VSS

VSS

L41

L43

M20

M22

M25

M27

L31

L36

AL44

AL43

M38

P25

R25

1
TP

TP4

VSS

TP19

TP20

VSS

VSS

VSS

VSS

VSS

M31

T52

T6

U15

U11

AE41

P36

R36

AE43

BA27

TP2

TP5

VSS

VSS

VSS

VSS

VSS

TP14

TP15

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

U25

U22

U20

U17

U27

U33

U36

U38

U41

Gigabyte Technology

Title

Size Document Number Rev

Custom

Date: Sheet

U47

BM46

AG12

AG18

AG17

TP11

TP10

L_BKLTEN

L_VDD_EN

L_BKLTCTL

VSS_NCTF

VSS_NCTF

VSS_NCTF

VSS_NCTF

VSS_NCTF

VSS_NCTF

VSS_NCTF

A4A6B2

BM1

BM57

BP1

BP57

BT2

PCH PWR ,GND

GA-H77-DS3H

U53

V20

VSS

VSS

VSS

VSS_NCTF

VSS_NCTF

VSS_NCTF

BU4

BU52

V38V6W1

VSS

VSS_NCTF

BU54

BU6D1AY22

1

W55

W57

Y11

Y15

Y38

Y40

Y43

Y46

Y47

Y49

Y52

Y6

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

VSS

11 OF 11

VSS_NCTF

VSS_NCTF

VSS

VSS

VSS

VSS

VSS_ADAC

TS_VSS1

TS_VSS2

TS_VSS3

VSS_NCTF

C12

F1

TS_VSS4

AE56

BR36

AU2

A54

A52

F57

D57

13 35Tuesday, February 21, 2012

1.0

of

Gigabyte Confidential

Do not Copy

8

+12V

1

+

EC8
270u/FP/D/16V/8C/A/10m

D D

X16_+12V

BC30

0.1u/4/X7R/16V/K

+12 protect
short-wire
test

PCIEX16:16/5/5/5/16

EXP_RXP[0..15]
EXP_RXN[0..15]
EXP_TXP[0..15]
EXP_TXN[0..15]

C C

B B

EXP_TXP0
EXP_TXN0
EXP_TXP1
EXP_TXN1
EXP_TXP2
EXP_TXN2
EXP_TXP3
EXP_TXN3
EXP_TXP4
EXP_TXN4
EXP_TXP5
EXP_TXN5
EXP_TXP6
EXP_TXN6
EXP_TXP7
EXP_TXN7

EXP_TXN8
EXP_TXP9
EXP_TXN9
EXP_TXP10
EXP_TXN10
EXP_TXP11
EXP_TXN11
EXP_TXP12
EXP_TXN12
EXP_TXP13
EXP_TXN13
EXP_TXP14
EXP_TXN14
EXP_TXP15
EXP_TXN15

EXP_RXP[0..15] [4]
EXP_RXN[0..15] [4]
EXP_TXP[0..15] [4]
EXP_TXN[0..15] [4]

C43 0.22u/4/X5R/6.3V/K
C36 0.22u/4/X5R/6.3V/K
C47 0.22u/4/X5R/6.3V/K
C49 0.22u/4/X5R/6.3V/K
C52 0.22u/4/X5R/6.3V/K
C54 0.22u/4/X5R/6.3V/K
C57 0.22u/4/X5R/6.3V/K
C59 0.22u/4/X5R/6.3V/K
C62 0.22u/4/X5R/6.3V/K
C64 0.22u/4/X5R/6.3V/K
C65 0.22u/4/X5R/6.3V/K
C67 0.22u/4/X5R/6.3V/K
C69 0.22u/4/X5R/6.3V/K
C71 0.22u/4/X5R/6.3V/K
C76 0.22u/4/X5R/6.3V/K
C75 0.22u/4/X5R/6.3V/K
C79 0.22u/4/X5R/6.3V/K
C80 0.22u/4/X5R/6.3V/K
C81 0.22u/4/X5R/6.3V/K
C82 0.22u/4/X5R/6.3V/K
C86 0.22u/4/X5R/6.3V/K
C87 0.22u/4/X5R/6.3V/K
C90 0.22u/4/X5R/6.3V/K
C91 0.22u/4/X5R/6.3V/K
C92 0.22u/4/X5R/6.3V/K
C93 0.22u/4/X5R/6.3V/K
C95 0.22u/4/X5R/6.3V/K
C96 0.22u/4/X5R/6.3V/K
C97 0.22u/4/X5R/6.3V/K
C98 0.22u/4/X5R/6.3V/K
C99 0.22u/4/X5R/6.3V/K
C100 0.22u/4/X5R/6.3V/K

PCI-E REV:1.1--> 2.5GHZ
PCE-E X1(

單向

) BANDWITH=2.5GHz*(8b/10b)=2Gb/s=250MB/s

PCE-E X1(雙向) BANDWITH=2.5GHz*(8b/10b)X2=4Gb/s=500MB/s

單向

PCE-E X16(
PCE-E X16(

) BANDWITH=2.5GHz*(8b/10b)X16=32Gb/s=4GB/s

雙向

) BANDWITH=2.5GHz*(8b/10b)X16X2=64Gb/s=8GB/s

7

+12V X16_+12V

1 2
3 4
5 6
7 8

RN3 0/8P4R/4/X

1

2
3 4
5 6
7 8

RN2 0/8P4R/0402/SHT/X

EXP_TXP0C
EXP_TXN0C
EXP_TXP1C
EXP_TXN1C
EXP_TXP2C
EXP_TXN2C
EXP_TXP3C
EXP_TXN3C
EXP_TXP4C
EXP_TXN4C
EXP_TXP5C
EXP_TXN5C
EXP_TXP6C
EXP_TXN6C
EXP_TXP7C
EXP_TXN7C
EXP_TXP8CEXP_TXP8
EXP_TXN8C
EXP_TXP9C
EXP_TXN9C
EXP_TXP10C
EXP_TXN10C
EXP_TXP11C
EXP_TXN11C
EXP_TXP12C
EXP_TXN12C
EXP_TXP13C
EXP_TXN13C
EXP_TXP14C
EXP_TXN14C
EXP_TXP15C
EXP_TXN15C

6

X16_+12V X16_+12V

3VDUAL

SMBCLK
SMBDATA

VCC3

EXP_TXP0C
EXP_TXN0C

EXP_TXP1C
EXP_TXN1C

EXP_TXP2C
EXP_TXN2C

EXP_TXP3C
EXP_TXN3C

EXP_TXP4C
EXP_TXN4C

EXP_TXP5C
EXP_TXN5C

EXP_TXP6C
EXP_TXN6C

EXP_TXP7C
EXP_TXN7C

EXP_TXP8C
EXP_TXN8C

EXP_TXP9C
EXP_TXN9C

EXP_TXP10C
EXP_TXN10C

EXP_TXP11C
EXP_TXN11C

EXP_TXP12C
EXP_TXN12C

EXP_TXP13C
EXP_TXN13C

XP14C

EXP_T
EXP_TXN14C

EXP_TXP15C
EXP_TXN15C

SMBCLK[7,8,12,15,16,25,29]

SMBDATA[7,8,12,15,16,25,29]

-PCIE_WAKE[12,15,16,31]

PCIESLOT-164DN-3

PCIEX16

B1

12V

B2

12V

B3

RSVD

B4

GND

B5

SMCLK

B6

SMDAT

B7

GND

B8

3.3V

B9

JTAG1

B10

3.3VAUX

B11

WAKE*

B12

RSVD

B13

GND

B14

HSOP0

B15

HSON0

B16

GND

B17

PRSNT2*

B18

GND

B19

HSOP1

B20

HSON1

B21

GND

B22

GND

B23

HSOP2

B24

HSON2

B25

GND

B26

GND

B27

HSOP3

B28

HSON3

B29

GND

B30

RSVD

B31

PRSNT2*

B32

GND

B33

HSOP4

B34

HSON4

B35

GND

B36

GND

B37

HSOP5

B38

HSON5

B39

GND

B40

GND

B41

HSOP6

B42

HSON6

B43

GND

B44

GND

B45

HSOP7

B46

HSON7

B47

GND

B48

PRSNT2*

B49

GND

B50

HSOP8

B51

HSON8

B52

GND

B53

GND

B54

HSOP9

B55

HSON9

B56

GND

B57

GND

B58

HSOP10

B59

HSON10

B60

GND

B61

GND

B62

HSOP11

B63

HSON11

B64

GND

B65

GND

B66

HSOP12

B67

HSON12

B68

GND

B69

GND

B70

HSOP13

B71

HSON13

B72

GND

B73

GND

B74

HSOP14

B75

HSON14

B76

GND

B77

GND

B78

HSOP15

B79

HSON15

B80

GND

B81

PRSNT2*

B82

RSVD

PCI-E/16X-164P/BU-297C/RIGHT PUSH

5

3GIO_*16

KEY

PRSNT1*

JTAG2
JTAG3
JTAG4
JTAG5

PWRGD

REFCLK+

REFCLK-

HSIP0
HSIN0

RSVD

HSIP1
HSIN1

HSIP2
HSIN2

HSIP3
HSIN3

RSVD
RSVD

HSIP4
HSIN4

HSIP5
HSIN5

HSIP6
HSIN6

HSIP7
HSIN7

RSVD

HSIP8
HSIN8

HSIP9
HSIN9

HSIP10
HSIN10

HSIP11
HSIN11

HSIP12
HSIN12

HSIP13
HSIN13

HSIP14
HSIN14

HSIP15
HSIN15

GND

GND

GND

GND

GND

GND
GND

GND
GND

GND

GND

GND
GND

GND
GND

GND
GND

GND

GND

GND
GND

GND
GND

GND
GND

GND
GND

GND
GND

GND
GND

GND
GND

GND

4

A1
A2

12V

A3

12V

A4
A5
A6
A7
A8
A9

3.3V

A10

3.3V

A11

A12
A13
A14
A15
A16
A17
A18

A19
A20
A21
A22
A23
A24
A25
A26
A27
A28
A29
A30
A31
A32

A33
A34
A35
A36
A37
A38
A39
A40
A41
A42
A43
A44
A45
A46
A47
A48
A49

A50
A51
A52
A53
A54
A55
A56
A57
A58
A59
A60
A61
A62
A63
A64
A65
A66
A67
A68
A69
A70
A71
A72
A73
A74
A75
A76
A77
A78
A79
A80
A81
A82

VCC3

-PCIE_RST

EXP_RXP0
EXP_RXN0

EXP_RXP1
EXP_RXN1

EXP_RXP2
EXP_RXN2

EXP_RXP3
EXP_RXN3

EXP_RXP4
EXP_RXN4

EXP_RXP5
EXP_RXN5

EXP_RXP6
EXP_RXN6

EXP_RXP7
EXP_RXN7

EXP_RXP8
EXP_RXN8

EXP_RXP9
EXP_RXN9

EXP_RXP10
EXP_RXN10

EXP_RXP11
EXP_RXN11

EXP_RXP12
EXP_RXN12

EXP_RXP13
EXP_RXN13

EXP_RXP14
EXP_RXN14

EXP_RXP15
EXP_RXN15

-PCIE_RST [15,17]

3

-PCIE_RST

SRCCLK_3GIO [10]

-SRCCLK_3GIO [10]

C27
33p/4/NPO/50V/J/X

2

VCC3

BC34

0.1u/4/X7R/16V/K/X

BC39

0.1u/4/X7R/16V/K/X

0.1u/4/X7R/16V/K/X

1

BC41

PCI-E REV:2.0--> 5GHZ

A A

Gigabyte Technology

8

7

6

5

Title

Size Document Number Rev
Custom

4

3

Date: Sheet

2

PCI EXPRESS * 16

GA-H77-DS3H

1.0

of

14 35Tuesday, February 21, 2012

1

Gigabyte Confidential

Do not Copy

8

PCIE*4 PCIE*1

+12V

SMBCLK[7,8,12,14,16,25,29]

D D

C C

B B

SMBDATA[7,8,12,14,16,25,29]

-PCIE_WAKE[12,14,16,31] -PCIE_RST [14,17]

SMBCLK
SMBDATA

3VDUAL

VCC3

-PCIE_WAKE

PCIE_TP5[9]

PCIE_TN5[9]

PCIE_TP6[9]

PCIE_TN6[9]

PCIE_TP7[9]

PCIE_TN7[9]

PCIE_TP8[9]

PCIE_TN8[9]

7

PCIEX4

B1

12V

B2

12V

B3

RSVD

B4

GND

B5

SMCLK

B6

SMDAT

B7

GND

B8

3.3V

B9

JTAG1

B10

3.3VAUX

B11

WAKE*

B12

RSVD

B13

GND

B14

HSOP0

B15

HSON0

B16

GND

B17

PRSNT2*

B18

GND

B19

HSOP1

B20

HSON1

B21

GND

B22

GND

B23

HSOP2

B24

HSON2

B25

GND

B26

GND

B27

HSOP3

B28

HSON3

B29

GND

B30

RSVD

B31

PRSNT2*

B32

GND

3GIO_*4

KEY

6

PRSNT1*

GND
JTAG2
JTAG3
JTAG4
JTAG5

PWRGD

GND

REFCLK+

REFCLK-

GND

HSIP0

HSIN0

GND

RSVD

GND

HSIP1

HSIN1

GND

GND

HSIP2

HSIN2

GND

GND

HSIP3

HSIN3

GND

RSVD

5

+12V

A1
A2

12V

A3

12V

A4
A5
A6
A7
A8
A9

3.3V

A10

3.3V

A11

A12
A13
A14
A15
A16
A17
A18

A19
A20
A21
A22
A23
A24
A25
A26
A27
A28
A29
A30
A31
A32

VCC3

3VDUAL

BC37

1u/4/X5R/6.3V/K/X

+12V

BC29

0.1u/4/X7R/16V/K/X

VCC3

BC33

0.1u/4/X7R/16V/K

-PCIE_RST

BC28

0.1u/4/X7R/16V/K

BC40

0.1u/4/X7R/16V/K

-PCIE_RST

22p/4/NPO/50V/J/X

SRCCLK_3GIO1 [10]

-SRCCLK_3GIO1 [10]
PCIE_IP5 [9]

PCIE_IN5 [9]

PCIE_IP6 [9]
PCIE_IN6 [9]

PCIE_IP7 [9]
PCIE_IN7 [9]

PCIE_IP8 [9]
PCIE_IN8 [9]

C24

+12V

BC265

0.1u/4/X7R/16V/K

+12V

PBC57

0.1u/4/X7R/16V/K

VCC3

PBC47

0.1u/4/X7R/16V/K

+12V

PBC58

0.1u/4/X7R/16V/K

4

3VDUAL

PBC56

0.1u/4/X7R/16V/K/X

PBC48

0.1u/4/X7R/16V/K

3VDUAL

PBC55

0.1u/4/X7R/16V/K/X

3

PCIEX1_1

B1

+12V

SMBCLK

SMBCLK[7,8,12,14,16,25,29]

SMBDATA

SMBDATA[7,8,12,14,16,25,29]

VCC3

-PCIE_WAKE[12,14,16,31]

-PCIE_WAKE[12,14,16,31]

3VDUAL

PCIE_TP1

PCIE_TP1[9]

PCIE_TN1

PCIE_TN1[9]

+12V

SMBCLK

SMBCLK[7,8,12,14,16,25,29]

SMBDATA

SMBDATA[7,8,12,14,16,25,29]

VCC3

3VDUAL

PCIE_TP2

PCIE_TP2[9]

PCIE_TN2

PCIE_TN2[9]

12V

B2 A2

12V 12V

B4

GND

B5

SMCLK

B6

SMDAT

B7

GND

B8

3.3V

B9

JTAG1

B10

3.3VAUX

B11

WAKE*

B12

RVSD

B13

GND

B14

HSOP0

B15

HSON0

B16

GND

B17

PRSNT2*

B18

GND

PCI-E/1X-36P/WH/OL

PCIEX1_2

B1

12V

B2 A2

12V 12V

B4

GND

B5

SMCLK

B6

SMDAT

B7

GND

B8

3.3V

B9

JTAG1

B10

3.3VAUX

B11

WAKE*

B12

RVSD

B13

GND

B14

HSOP0

B15

HSON0

B16

GND

B17

PRSNT2*

B18

GND

PCI-E/1X-36P/WH/OL

3GIO_X1

KEY

3GIO_X1

KEY

2

PRSNT1*

JTAG2
JTAG3
JTAG4
JYAG5

PWRGD

REFCLK+

REFCLK-

HSIP0

HSIN0

PRSNT1*

JTAG2
JTAG3
JTAG4
JYAG5

PWRGD

REFCLK+

REFCLK-

HSIP0

HSIN0

1

A1

+12V

A3B3

12VRSVD

A4

GND

A5
A6
A7
A8
A9

3.3V

3.3V

GND

GND

GND

12VRSVD

GND

3.3V

3.3V

GND

GND

GND

VCC3

A10
A11

A12
A13

PCIE_CLK1 [10]

A14

-PCIE_CLK1 [10]

A15

PCIE_IP1

A16

PCIE_IN1

A17
A18

A1

+12V
A3B3
A4
A5
A6
A7
A8
A9

VCC3

A10
A11

A12
A13

PCIE_CLK2 [10]

A14

-PCIE_CLK2 [10]

A15

PCIE_IP2

A16

PCIE_IN2

A17
A18

PCIE_IP1 [9]
PCIE_IN1 [9]

PCIE_IP2 [9]
PCIE_IN2 [9]

-PCIE_RST [14,17]

C206
22p/4/NPO/50V/J/X

-PCIE_RST [14,17]

C207
22p/4/NPO/50V/J/X

VCC3

B81

PRSNT2*

PCI-E/16X-65P/BU/RIGHT PUSH

A A

PBC60

0.1u/4/X7R/16V/K

8

7

6

5

4

PBC61

0.1u/4/X7R/16V/K/X

Title

Size Document Number Rev
Custom

3

Date: Sheet

2

Gigabyte Technology

PCI EXPRESS X 4 PORT

GA-H77-DS3H

15 35Tuesday, February 21, 2012

of

1

1.0

Gigabyte Confidential

Do not Copy

5

PCI SLOT 1

D D

G_-PIRQB[35]

G_-PIRQD[35]

C C

G_-DEVSEL[35]

B B

1K/8P4R/4

A A

1 2
3 4
5 6
7 8

VCC

G_PTCK

G_-PIRQB
G_-PIRQD

G_PCLK0

G_PCLK0[35]

G_-REQ0

G_-REQ0[35]

G_A_D31
G_A_D29

G_A_D25
G_-C_BE3

G_-C_BE3[35]

G_A_D23

G_A_D19

G_-C_BE2

G_-C_BE2[35]

G_-IRDY

G_-IRDY[35]

G_-DEVSEL
G_-PLOCK

G_-PLOCK[35]

G_-PERR G_PCI_A40

G_-PERR[35]

-BSERR

G_-SERR[35]

G_-C_BE1

G_-C_BE1[35]

G_A_D14
G_A_D12

G_A_D10

G_A_D8
G_A_D7

G_A_D5
G_A_D3

GBRN1

8.2K/8P4R/4

G_-PTRST

1 2

G_PTCK

3 4

G_PTMS

5 6
7 8

GBRN2

G_-ACK64
GA_-REQ64
GB_-REQ64

-12V +12VVCC3

PCI1

B1
B2
B3
B4
B5
B6
B7
B8
B9

B10
B11
B12
B13
B14
B15
B16
B17
B18
B19
B20
B21
B22
B23
B24
B25
B26
B27
B28
B29
B30
B31
B32
B33
B34
B35
B36
B37
B38
B39
B40
B41
B42
B43
B44
B45
B46
B47
B48
B49

B52
B53
B54
B55
B56
B57
B58
B59
B60
B61
B62

PCI/120/P/IV/VA

-REQ0/-GNT0/A_D16

VCC

3VDUAL

0.1u/4/X7R/16V/K/X

5

VCC -12V +12VVCC3

A1

-12V
TCK
GND
TDO
+5V
+5V
INTB
INTD
PRSNT1
RESERVED
PRSNT2
GND
GND
RESERVED
GND
CLK
GND
REQ
+5V
AD31
AD29
GND
AD27
AD25
+3.3V
C/BE3
AD23
GND
AD21
AD19
+3.3V
AD17
C/BE2
GND
IRDY
+3.3V
DEVSEL
GND
LOCK
PERR
+3.3V
SERR
+3.3V
C/BE1
AD14
GND
AD12
AD10
GND

AD8
AD7
+3.3V
AD5
AD3
GND
AD1
+5V
ACK64
+5V
+5V

GABC4

TRST

+12V

TMS

TDI

+5V
INTA
INTC

+5V

RESERVED

+5V

RESERVED

GND
GND

3.3V_AUX
RST

+5V

GNT

GND

PME
AD30
+3.3V
AD28
AD26

GND
AD24

IDSEL

+3.3V
AD22
AD20

GND
AD18
AD16
+3.3V

FRAME

GND

TRDY

GND

STOP

+3.3V

SDONE

SBO

GND

PAR
AD15
+3.3V
AD13
AD11

GND

AD9

C/BE0

+3.3V

AD6

AD4

GND

AD2

AD0

+5V

REQ64

+5V
+5V

GBBC4

0.1u/4/X7R/16V/K/X

A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
A13
A14
A15
A16
A17
A18
A19
A20
A21
A22
A23
A24
A25
A26
A27
A28
A29
A30
A31
A32
A33
A34
A35
A36
A37
A38
A39
A40
A41
A42
A43
A44
A45
A46
A47
A48
A49

A52
A53
A54
A55
A56
A57
A58
A59
A60
A61
A62

VCC

0.1u/4/X7R/16V/K/X

G_-PTRST
G_PTMS

G_-PIRQA
G_-PIRQC

G_-PCIRST

GAR1 100/4/1

N_-PCIE_WAKE
G_A_D30

G_A_D28
G_A_D26G_A_D27

G_A_D24

G_A_D22
G_A_D20G_A_D21

G_A_D18
G_A_D16G_A_D17

G_-FRAME
G_-TRDY
G_-STOP

G_PCI_A41
G_PAR

G_A_D15
G_A_D13

G_A_D11
G_A_D9

G_-C_BE0
G_A_D6

G_A_D4
G_A_D2

G_A_D0G_A_D1

GA_-REQ64G_-ACK64

GABC3

G_A_D[0..31][35]

G_-PIRQA [35]
G_-PIRQC [35]

3VDUAL

GBBC3

0.1u/4/X7R/16V/K/X

4

GABC5
33p/4/NPO/50V/J/X

G_PCLK0

GABC7 10p/4/NPO/50V/J/X

G_PCLK1

GABC6 10p/4/NPO/50V/J/X

G_-GNT0 [35]

-PCIE_WAKE [12,14,15,31]

G_A_D16

G_-FRAME [35]
G_-TRDY [35]
G_-STOP [35]

G_PAR [35]

G_-C_BE0 [35]

VCC3 +12V

4

G_A_D[0..31]

G_-PCIRST

GABC9

1u/4/X5R/6.3V/K/X

PCI SLOT 2

G_-PCIRST [35]

GBBC6

1u/4/X5R/6.3V/K/X

3

VCC

PCI2

B1

G_PTCK

G_-PIRQC[35]

G_-PIRQA[35]

G_-C_BE3[35]

G_-DEVSEL[35]

G_-PIRQC
G_-PIRQA

G_PCLK1

G_PCLK1[35]

G_-REQ1

G_-REQ1[35]

G_A_D31
G_A_D29

G_A_D25
G_-C_BE3

G_A_D23

G_A_D19

G_-C_BE2

G_-C_BE2[35]

G_-IRDY

G_-IRDY[35]

G_-DEVSEL
G_-PLOCK

G_-PLOCK[35]

G_-PERR G_PCI_A40

G_-PERR[35]

G_-SERR

G_-SERR[35]

G_-C_BE1

G_-C_BE1[35]

G_A_D14
G_A_D12

G_A_D10

G_A_D8
G_A_D7

G_A_D5 G_A_D4
G_A_D3

B2
B3
B4
B5
B6
B7
B8

B9
B10
B11
B12
B13
B14
B15
B16
B17
B18
B19
B20
B21
B22
B23
B24
B25
B26
B27
B28
B29
B30
B31
B32
B33
B34
B35
B36
B37
B38
B39
B40
B41
B42
B43
B44
B45
B46
B47
B48
B49

B52
B53
B54
B55
B56
B57
B58
B59
B60
B61
B62

PCI/120/P/IV/VA

-12V
TCK
GND
TDO
+5V
+5V
INTB
INTD
PRSNT1
RESERVED
PRSNT2
GND
GND
RESERVED
GND
CLK
GND
REQ
+5V
AD31
AD29
GND
AD27
AD25
+3.3V
C/BE3
AD23
GND
AD21
AD19
+3.3V
AD17
C/BE2
GND
IRDY
+3.3V
DEVSEL
GND
LOCK
PERR
+3.3V
SERR
+3.3V
C/BE1
AD14
GND
AD12
AD10
GND

AD8
AD7
+3.3V
AD5
AD3
GND
AD1
+5V
ACK64
+5V
+5V

TRST

RESERVED
RESERVED

3.3V_AUX

+3.3V

IDSEL
+3.3V

+3.3V

FRAME

TRDY
STOP

+3.3V

SDONE

+3.3V

C/BE0
+3.3V

REQ64

+12V

INTA
INTC

GND
GND

GND
PME
AD30

AD28
AD26
GND
AD24

AD22
AD20
GND
AD18
AD16

GND
GND

GND
AD15
AD13

AD11
GND

GND

A1
A2
A3

TMS

A4

TDI

A5

+5V

A6
A7
A8

+5V

A9
A10

+5V

A11
A12
A13
A14
A15

RST

A16

+5V

A17

GNT

A18
A19
A20
A21
A22
A23
A24
A25
A26
A27
A28
A29
A30
A31
A32
A33
A34
A35
A36
A37
A38
A39
A40
A41

SBO

A42
A43

PAR

A44
A45
A46
A47
A48
A49

AD9

A52
A53
A54

AD6

A55

AD4

A56
A57

AD2

A58

AD0

A59

+5V

A60
A61

+5V

A62

+5V

-REQ1/-GNT1/A_D17

GBBC2

GABC2

0.1u/4/X7R/16V/K/X

0.1u/4/X7R/16V/K/X

3

VCC VCC3

GABC11
22u/8/X5R/6.3V/M

G_-PTRST
G_PTMS

G_-PIRQB

G_-PIRQB [35]

G_-PIRQD

G_-PIRQD [35]

G_-PCIRST

GBR1 100/4/1

N_-PCIE_WAKE
G_A_D30

G_A_D28
G_A_D26G_A_D27

G_A_D24

GBR2 100/4/1GAR2 100/4/1

G_A_D22
G_A_D20G_A_D21

G_A_D18
G_A_D16G_A_D17

G_-FRAME
G_-TRDY
G_-STOP

G_PCI_A41
G_PAR

G_A_D15
G_A_D13

G_A_D11
G_A_D9

G_-C_BE0
G_A_D6

G_A_D2
G_A_D0G_A_D1

GB_-REQ64G_-ACK64

GABC12
22u/8/X5R/6.3V/M

3VDUAL

G_-GNT1 [35]

-PCIE_WAKE [12,14,15,31]

G_A_D17

G_-FRAME [35]
G_-TRDY [35]
G_-STOP [35]

G_PAR [35]

G_-C_BE0 [35]

SMBCLK[7,8,12,14,15,25,29]

SMBDATA[7,8,12,14,15,25,29]

GBR3 0/6/SHT/X
GBR4 0/6/SHT/X

G_-PCIRST

G_PCI_A40
G_PCI_A41

2

GBBC5
33p/4/NPO/50V/J/X

VCC3

1

+

PEC2
560u/FP/D/6.3V/69/A/11m

2

G_-PCIRST [35]

1

Title

PCI SLOT 1&2

Size Document Number Rev

Custom

Date: Sheet

GA-H77-DS3H

1

16 35Tuesday, February 21, 2012

of

1.0

Gigabyte Confidential

Do not Copy

8

R40 8.2K/4

VCC3

R41 8.2K/4/X

HI FOR PCH ERP
LO FOR IO ERP

3VDUAL_PCH

VCC3

D D

C C

22p/4/NPO/50V/J/X

B B

VCC3

-PFMRST[12]

MB_ID2

R26 8.2K/4
R7 8.2K/4

FANPWM5[30]

R52 1K/4/1

PWROK1[11,12,29]

BC20

TEMP_ALART-[11]

TPM_GP14[18]

-PFMRST2[18,31,35]

-PFMRST1[4]

FANIO1[30]
FANIO2[30]
FANIO3[30]

FANIO4[30]

-PFMRST

SERIRQ[11,18]

-LFRAME[12,18]
LAD0[12,18]

LAD1[12,18]
LAD2[12,18]
LAD3[12,18]

-KBRST[11]

A20GATE[11]

LPC33[10]

LPCCLK48[10]

R43 8.2K/4/X

VCC3

R44 8.2K/4

-5VSB_CTRL

-THERM

-THERM

IT_VCCH

BEEP-[28]

IT_VCCH

-LDRQ0[12]

CTS1-[18]

FANPWM1[30]
FANPWM2[30]
FANPWM3[30]

IO_PWOK
MB_ID2

R8 0/4/SHT/M/X

-5VSB_CTRL

-RST_BTN

R55 22/4
R64 22/4
R68 22/4

IT8721

FAN_CTL4/VID_TURBO

PIN121

PIN120

PIN19

PIN31

PIN53

PIN55

PIN66

PIN70

PIN95

PIN96

PIN97

A A

PIN98

VDDA_EN

GP30

GP14

SST/AMDTSI_D/PECI_AVA/MTRB#/PCH_D

PECI/AMDTSI_C/DRVB#/PCH_C

GP47

SYS_3VSB

VIN3/ATXPG

VIN2

VIN1(VCC5)

VIN0(VCC12)

8

7

MB_ID3

For IT8275

-THERM [24]

32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59

JP5

60
61
62
63
64
65
66
67
68
69

ISOLATEB[31]

-LDRQ0

-SPI_HOLD0

-SPI_HOLD1

ITE_PWROK2

For IT8728

ITE_PWROK
PRST1-

SIO_18V

IT8728

VCORE_EN/PCH_C0

VLDT_EN/PCH_D0

ATXPG

PCH_C1

SST/AMDTSI_D/MTRB#/PCH_D1

PECI/AMDTSI_C/DRVB#

SYS_3VSB

GP47

VIN2(VCC5)

VIN1(VCC12)

VIN1/VDIMM_STR(1.5V)

VIN0/VCORE(1.1V)

7

FANPWM4[30]

CTS1#/GP31
BEEP_GB/FAN_CTL5
PCIRSTIN#/CIRTX2/GP15
3VSB
HOLD_M#/GP64
HOLD_B#/GP63
FAN_TAC1
FAN_CTL1
FAN_TAC2/GP52
FAN_CTL2/GP51
FAN_TAC3/GP37
FAN_CTL3/GP36
RSTCONOUT/GP35
RSTCONIN/GP34
GNDD
5VSB_CTRL#
5VAUX_SW
PWRGD2_50ms
ATXPG/GP30
GP27/SIN2
GP26/SOUT2
FAN_TAC4/GP25/DSR2#
FAN_TAC5/GP24/RTS2#
GP23/CPU_PG
GP22
GP21/DCD2#
GP20/CTS2#
GP17/RI2#
DTR2#
CIRTX1/CE_N
PCH_C1/GP14
PWRGD1_30ms
PCIRST1#/GP12
PCIRST2#/GP11
3VSB
VCORE
LRESET#
LDRQ#

JP2

RTS1-[18]

DSR1-[18]

JP3

TXD1[18]

RXD1[18]

JP4

DTR1-[18]
DCD1-[18]

RI1-[18]

DUAL BIOS OPT STRAP

CEB_N

-SPI_HOLD0[19]

-SPI_HOLD1[19]

6

31

GP67

GP66

RI1#/GP32

DCD1#/GP33

SIN1/GP41

DTR1#/JP4

SOUT1#/JP3

DSR1#/GP45

GNDD

RTS1#/JP2

VLDT_EN/PCH_D0/GP65

VCORE_EN/PCH_C0/FAN_CTRL4

IT8728F(GB)

LAD2

LAD1

LAD0

LAD3

SERIRQ

LFRAME#

KRST#/GP62

GA20/JP5

PCICLK

CE_IN/GP50

CLKIN

GNDD

747372

75

70

71

76777879808182838485868788899091929394

LAD1

LAD2

LAD3

LAD0

C14

10p/4/NPO/50V/J/X

R90 1K/4/1/X
R85 680/4/1/X

R91 1K/4/1

6

PD1/GP71

PD2/GP72/BUSSI0

PD3/GP73/BUSSI1

PD4/GP74/BUSSI2

PD5/GP75/BUSSO0

PD6/GP76/BUSSO1

PD7/GP77/BUSSO2

DENSEL#

MTRA#

SST/AMDTSI_D/PCH_D1/MTRB#

DRVA#

PECI/AMDTSI_C/DRVB#

WDATA#

SMBC_R2/DIR#

VCC

VCC3

-SPI_HOLD0

-SPI_HOLD1

5

MB_ID3

6789101112131415161718192021222324252627282930

ERR#

PD0/GP70

ACK#/GP83

VIN1/VDIMM_STR(1.5V)

INIT#/GP85/SMBD_M1

AFD#/GP86/SMBC_R1

STB#/GP87/SMBC_M1

SLIN#/GP84/SMBD_R1

RSMRST#/CIRRX1/GP55

SMBC_M2/STEP#

SMBD_R2/HDSEL#

SMBD_M2/WGATE#

RDATA#

TRK0#

INDEX#

WPT#

IT8728F/EX (GB)/QFP128

95

-LDRQ0

ITE_PWROK2

ITE_PWROK

-PCIE_RST

-PFMRST1

-PFMRST2

A20GATE

Hi :Disable WDT
Lo :Enable WDT to rest PWROK

5

ERP [24]

U1

5

BUSY/GP82

4

PE/GP81

3

SLCT/GP80

2

AVCC3

VIN2(+12V)

VIN3(+5V)

VIN5
VIN6

VREF
TMPIN1
TMPIN2
TMPIN3

TS_D­GNDA

MCLK/GP56
KCLK/GP60

KDAT/GP61

GNDD

PME#/GP54

SUSB#

VBAT

COPEN#

3VSB

SYS_3VSB

DSKCHG#

1
128
127
126
125
124
123
122
121
120
119
118
117
116
115
114
113
112
111
110
109
108
107
106
105
104
103
102
101
100
99
98

28_3VSB

97
96

BC21

0.1u/4/X7R/16V/K

For IT8728

PECI [4,11]
SSTCTL [11]

VIN0/VCORE(1.1V)

VIN4/VLDT_12

PCIRST3#/GP10

MDAT/GP57

3VSBSW#/GP40

PWRGD3_150ms

SUSC#/GP53
PSON#/GP42

PANSWH#/GP43

PWRON#GP44

CE2_N/GP47

Only For Push-Pull Mode

R75 1K/4/1

R32 1K/4/1

R56 1K/4/1

R66 1K/4/1

R67 1K/4/1/X
R63 1K/4/1/X

R76 680/4/1/X

4

R54 0/4/X

R87 8.2K/4
R61 8.2K/4

IO_GP43

CEB_N

VCC3

VCC3

VCC3

VCC3

VCC3
VCC3

4

3

For 8728 EUP function

3VDUAL_PCH

IT_AVCC

R53 22/4
R62 22/4

1u/4/X5R/6.3V/K

VIN0 [30]
VIN1 [30]
VIN2 [30]
VIN3 [30]
VIN4 [30]
VIN5 [30]
VIN6 [30]
VREF [30]
SYS_TEMP [30]
CPU_TEMP [30]
PWM_TEMP [30]

-RSMRST

KCLK [30]
KDAT [30]

-S4_S5 [12,33]

IT_VCCH

BC22

BC255
1u/4/X5R/6.3V/K

internal power pin, max 22nF cap---->2uf for

低溫相容性

8728

1u/4/X5R/6.3V/K/X

EUP control detect

3VDUAL

JP4

JP3
JP50101

-RSMRST [12,24]

-PCIE_RST [14,15]

3VDUAL

VBAT [12]

-CASEOPEN [28]

0.01u/4/X7R/25V/K

SIO_18V

BC18

R83 100/4/1
BC3

1u/4/X5R/6.3V/K

1

k8 power sequency function is Disable

0

k8 power sequency function is Enable

1 The default value of EC Index 63h/6Bh/73h is 80h.

1

The default value of EC Index 63h/6Bh/73h is FFh.

The default value of EC Index 63h/6Bh/73h is 00h.

0

0

The default value of EC Index 63h/6Bh/73h is 40h.

3

R21 0/6/SHT/M/X

VCC3

R18 0/6/SHT/M/X

VIN2/3:UNUSE:PULL HI

C13

BC19

0.1u/4/X7R/16V/K

28_3VSB

2

3VDUAL_PCH

-PSON

10mil

BC4

0.1u/4/X7R/16V/K

IT_AVCC

3

D

GS

2

Q1
2N7002/SOT23/25pF/5

SOT23

1

R1
220/6

BC23

10u/8/X5R/6.3V/K

1u/4/X5R/6.3V/K

BC2
10u/8/X5R/6.3V/K

BC6

BC1

0.1u/4/X7R/16V/K

0.1u/4/X7R/16V/K

IT_AVCC

IT_VCCH

BC17

For IT8721 Power leakage

-PSON [29,33]

-PWRBTSW [28]

-LPCPME [12]
PWRBTSW [12]

-SLP_S3 [12,24,33]

R73

8.2K/4/X

3VDUAL_PCH

EUP FROM PCH

VCC

R36

8.2K/4/X

PWOK[29]

R31 0/4/SHT/M/X

JP2

R12 8.2K/4

JP3

JP4
JP5

R11 8.2K/4

R9 8.2K/4
R50 8.2K/4/X

R718 8.2K/4

R10 1K/4/1/X

JP3--- High SPI-Flash Disable
Low SPI-Flash Enable

JP6:N\A FOR 8728 DX
JP6:PULL DOWN FOR 8728 EX

anti-surge enable

Gigabyte Technology

Title

Size Document Number Rev

Custom

Date: Sheet

2

ITE 8728 LPC IO

GA-H77-DS3H

1

IO_PWOK

C9
1n/4/X7R/50V/K

17 35Tuesday, February 21, 2012

of

1

VCC3
VCC3

VCC3
VCC3

1.0

Gigabyte Confidential

Do not Copy

8

COMA COM RI

D D

RI1-[17]

CTS1-[17]

DSR1-[17]

RTS1-[17]

DTR1-[17]

RXD1[17]

TXD1[17]

DCD1-[17]

-12V

ABC2

0.1u/4/X7R/16V/K/X

7

AU1

19

RY1

18

RY2

17

RY3

16

DA1

15

DA2

14

RY4

13

DA3

12

RY5

11

GND

10

-12V

GD75232/TSSOP20

RA1
RA2
RA3
DY1
DY2
RA4
DY3
RA5

12V

5V

2
3
4
5
6
7
8
9

20
1

ABC1

0.1u/4/X7R/16V/K/X

NRIA­NCTSA­NDSRA­NRTSA­NDTRA­NSINA
NSOUTA
NDCDA-

6

VCC

+12V

ABC3

0.1u/4/X7R/16V/K/X

5

NRIA-

D6

R93 75K/4/1

CD4148WP/1206/300mA

4

Q5
MMBT2222A/SOT23/600mA/40

-RI

-RI [12]

SOT23

132

R92

8.2K/4

3

NRIA­NCTSA­NDSRA­NRTSA-

NDTRA­NSINA
NSOUTA
NDCDA-

ACN1

180P/8P4C/6/NPO/50V/K

ACN2

180P/8P4C/6/NPO/50V/K

2

87
65
43
21

87
65
43
21

NDCDA­NSOUTA

NRTSA­NRIA-

COMA

12
34
56
78
910

BH/2*5K10/IV/2.54/VA/COM

11NH3-000205-Y1R/Y2R

1

NSINA
NDTRA­NDSRA­NCTSA-

LPT PORT

C C

B B

TPM

VCC3

3VDUAL_PCH

TPMCLK[10]

-LFRAME[12,17]

-PFMRST2[17,31,35]

LAD0[12,17]

BC70

A A

0.1u/4/X7R/16V/K/X

-LFRAME

-PFMRST2

R234 8.2K/4/X

BC71

0.1u/4/X7R/16V/K/X

1 2
3
5 6

LAD3

7 8
9 10

LAD0

11 12
13
15
17
19

TPM
BH/2*10K4/BK/2.54/VA/HA

LCLK GND
LFRAME#
LRESET#
LAD3
VCC3
LAD0
RSV0
SB3V
GND
LPCPD#

R264 0/4/SHT/X

SUSCLK[12]

VCC5
LAD2
LAD1
GND
RSV1
SERIRQ
CLKRUN#
RSV2

VCC3

LAD2
LAD1

14
16
18
20

SERIRQ

LAD2 [12,17]LAD3[12,17]
LAD1 [12,17]

SERIRQ [11,17]

R263

8.2K/4

TPM_GP14 [17]

Gigabyte Technology

Title

Size Document Number Rev

Custom

8

7

6

5

4

3

Date: Sheet

2

COM & Print

GA-H77-DS3H

18 35Tuesday, February 21, 2012

1

1.0

of

Gigabyte Confidential

Do not Copy

8

VCC3

BC208

0.1u/4/X7R/16V/K

D D

7

C168

10p/4/NPO/50V/J/X

6

-ICH_SPI_CS

5

M_BIOS
R603 22/4

SPI_MISO -SPI_HOLD0

-SPI_WP0

64M/SPI/SO8/200mil/S/[10HP4-112564-20R]

1

CS#

2

SO

3

WP#

4

VSS

VDD

HOLD#

SCK

8
7
6
5

SI

MAIN BIOS

VCC3

R558
0/4/SHT/X

MBIOS_VCC

ICH_SPI_CLK
ICH_SPI_MOSI

4

BC211
1u/4/X5R/6.3V/K

-SPI_HOLD0 [17]

C180
10p/4/NPO/50V/J/X

3

MOSI For DMI RX Termination Voltage

ICH_SPI_MOSI[12]

-ICH_SPI_CS[12]

ICH_SPI_MISO[12]

2

ICH_SPI_MOSI

-ICH_SPI_CS

-SPI_HOLD0

-SPI_HOLD1

-SPI_WP1[12]

-SPI_WP0[12]

-SPI_WP1

-SPI_WP0

ICH_SPI_MISO

-GNT0[11]

-GNT1[11]

R619 8.2K/4/X
R590 8.2K/4/X
R613 1K/4/1
R602 1K/4/1

R683 8.2K/4/X
R684 8.2K/4/X
R685 8.2K/4

R290 1K/4/1/X
R289 1K/4/1/X

1

VCC3

VCC3

Default int pull up

SPI_MISO

C C

R615 22/4

BOOT
DEVICE

LPC
PCI
NAND

ICH_SPI_MISO [12]

GNT0

0
0
1

GNT1

0
1
0

11SPI

1 means floating
0 means PD 1K

B B

A A

Gigabyte Technology

8

7

6

5

Title

Size Document Number Rev
Custom

4

3

Date: Sheet

2

BIOS

GA-H77-DS3H

19 35Tuesday, February 21, 2012

1

1.0

of

Gigabyte Confidential

Do not Copy

5

AZALIA CODEC

ALC887-VD2/ALC889/VT1708S/VT1708SCE/VT2021 Colay

ALC887-VD2ALC662

CR65
CBC35

CR44/CBC26

D D

CR31
CR30

CBC1/CBC2

CR20
CR34

CBC40/CBC41

X
O

47ohm+1nF

XO
O

X
O

47ohm+1nF

O
X

10uF/X5R10uF/X5R

5.11K/4/1
20K/4/1

X

5.11K/4/1
20K/4/1

X

4

ALC889

O
X

47ohm+1nF

O
X

22uF/X5R

5.11K/4/1
20K/4/1

X

VT1708S-CD

O
X

22ohm+100P

O
X

10uF/X5R

5.1K/4/1

5.1K/4/1
100P/4

3

VT1708S-CE

VT2021

OX

O

22ohm+100P

X

47ohm+1nF
O
X

X

10uF/X5R 10uF/X5R

5.1K/4/1
20K/4/1

100P/4

5.1K/4/1

5.1K/4/1
X

2

1

CR6/CR7/CR58/CR54

22K/4

22K/4

22K/4

10K/4/1

10K/4/1

10K/4/1

CR5/CR8/CR1/CR14/
CR17/CR22/CR13/CR11/
CR57/CR53

CR51/CD1/CBC7

CD2/CD3/CQ5/CQ5

C C

B B

62 ohm

O
X

62 ohm

O
X

co-layout

SPDIFO2_HDMI[21]
SPDIFO3_HDMI[21]

50歐姆:4/5

CR14/CBC4 close to SouthBridge

62 ohm

X

VCC3

ACZ_SDOUT[12]
ACZ_BITCLK[12]

ACZ_SDIN2[12]

VCC3

ACZ_SYNC[12]

-ACZ_RST[12]

22p/4/NPO/50V/J/X

75 ohm

X
O

CR63 0/6/SHT/M/X

CR60 22/4

CBC32

O
XO

CBC34
10u/8/X5R/6.3V/K

CBC39 10u/8/X5R/6.3V/K/X

CBC35 10u/8/X5R/6.3V/K

CR61 22/4

CBC33

0.1u/4/X7R/16V/K

SPDIF[21]

CR65 0/4/X

75 ohm75 ohm

1

DVDD1

2

GPIO0/XTALI

3

GPIO1/XTALO

4

DVS1

5

SDATA_OUT

6

BIT_CLK

7

DVSS2

8

SDATA-IN

9

DVDD2

10

SYNC

11

RESET#

12

PC_BEEP

O
X

Digital Area Analog Area

CBC41

100p/4/NPO/50V/J/X

FRONT_JD[21]

LINE1_JD[21]

MIC1_JD[21]

CR20 5.11K/4/1
CR23 10K/4/1
CR18 20K/4/1

CR26: 20K/4/0.1% @ALC889A
CR26: 20K/4/1% @others

CR34 20K/4/1
CBC40 100p/4/NPO/50V/J/X

For ALC888-VD/ALC892

4847464544434241403938

LFE

SPDIFO

SPDIF/EAPD

SURBACK-R/XTALSEL

SURBACK-L/JD0 GPIO0

SENSE A(JD1)/PHONE JD5

LINE2-L/AUX-L

LINE2-R/AUX-R

MIC2-L/JD2

MIC2-R/JD1 GPIO1

1314151617181920212223

CEN

AVSS2

CD_L

CD_GND

SURR-R

JDREF (NC)/JD3

CD_R

MIC1-L/MIC1

SURR-L

MIC1-R/MIC2

37

AVDD2

SENSE B (JD2)/FMIC1
MIC1-VREFO-R/FMIC2

LINE1-VREFOR/VREFO3

LINE1-VREFO-L/AFILT1

MIC1-VREFO-L/VREFOUT

LINE1-L

LINE1-R

24

LINE1_R
LINE1_L
MIC1_RR
MIC1_LL

VT1708S :5.1K + 100PF

0.1u/4/X7R/16V/K

CU1

ALC889A+

FRONT-R

FRONT-L

DCVOL/VREFVOUT2

LINE2-VREFO/JD4

MIC2-VREFO/AFILT2

VREF
AVSS1
AVDD1

ALC887-VD2-CG/LQFP48/S

CBC1 10u/8/X5R/6.3V/K
CBC2 10u/8/X5R/6.3V/K
CBC9 10u/8/X5R/6.3V/K
CBC11 10u/8/X5R/6.3V/K

CBC12

AVDD

36
35
34
33
32
31
30
29
28
27
26
25

VT1708S :22 OHM + 100PF

CR44 47/4/1

JD resistors close to pin34 of CODEC

VODR

VOBR

AVDD

CBC10

0.1u/4/X7R/16V/K

LINE_O_R [21]
LINE_O_L [21]

CR16 8.2K/4

VT1708S :3.3K

CR19 8.2K/4

VT1708S :3.3K

CBC8
10u/8/X5R/6.3V/K

FAUDIO_JD [21]

CBC26
1n/4/X7R/50V/K

Can Support Amp Out

MIC1_VREFO_R [21]
LINE2_VREFO [21]
MIC2_VREFO [21]

MIC1_VREFO_L [21]

CBC7

10u/8/X5R/6.3V/K

For ALC888-VD/ALC892

LINE_IN_R [21]
LINE_IN_L [21]
MIC1_R [21]
MIC1_L [21]

50

歐姆

:4/10

CR51 0/6

1

AZ2225-01L/SOD323

5VDUAL

CD1

JD resistors close to pin13 of CODEC

CESD1

LINE2_R

MIC2_L

1
2
3 4

AZC009-04S/SOT23-6L

4

A A

5

LINE2_L

6
5

5VDUAL

MIC2_R

LINE2_L[21]

LINE2_R[21]

MIC2_L[21]

MIC2_R[21]

Can Support Amp Out

Gigabyte Technology

Title

Size Document Number Rev
Custom

3

2

Date: Sheet

HD AUDIO VT2021

GA-H77-DS3H

20 35Tuesday, February 21, 2012

1

1.0

of

Gigabyte Confidential

Do not Copy

5

CODEC POWER/EMI PAD

+12V

EUP

5VDUAL

CD4148WP/1206/300mA/X

D D

22u/8/X5R/6.3V/M

上

ALC892時,

CQ5

CBC13

AVDD

此顆電容要保留

4

123

1

CD2
AZ2225-01L/SOD323/X

CQ3
78L05/SOT89/0.1A/X

0.1u/4/X7R/16V/K/X

CD3
CD4148WP/1206/300mA/X

CR24 0/4/SHT/M/X

ADD CD2 For ESD PROTECT DIODE

4

CR49 0/6/X

CR21 2.2/6

3

LINE-OUT

LINE-IN

Verify MIC function
in LINE-in

2

CEC1

100u/OS/D/6.3V/66/A/35m

LINE_O_R[20]

LINE_O_L[20]

1

+

1

+

CEC2

100u/OS/D/6.3V/66/A/35m

Only reserved for ALC888

LINE_IN_R[20]

LINE_IN_L[20]

CR1 62/4

CR14 62/4

CR5 62/4

CR8 62/4

CBC19

180p/4/NPO/50V/J

CBC20

180p/4/NPO/50V/J

CR7 22K/4
CR6 22K/4

1

VT2021

AJ_B5

AJ_B2

CBC24
180p/4/NPO/50V/J

AJ_A5

AJ_A2

CBC23
180p/4/NPO/50V/J

MIC-IN

C C

MIC1_R[20]

MIC1_L[20]

CR17 62/4

CR22 62/4

MIC1_VREFO_L[20]
MIC1_VREFO_R[20]

CBC3

180p/4/NPO/50V/J

AJ_C5

AJ_C2

CBC4
180p/4/NPO/50V/J

SPDIF_OUT

SPDIF[20]
SPDIFO2_HDMI[20]
SPDIFO3_HDMI[20]

CR30 0/4/X
CR31 0/4/SHT/M/X
CR66 0/4/X

CBC17

100p/4/NPO/50V/J

PIN

SPDIF_O

PH/1*2/BK/2.54/VA/D

For HDMI SPDIF

B B

AUDIO

C4

LINE1_JD[20]

FRONT_JD[20]

MIC1_JD[20]

A A

5

LINE1_JD
AJ_A5

AJ_A2

FRONT_JD
AJ_B5

AJ_B2

MIC1_JD
AJ_C5

AJ_C2

C4

C3

C3

C5

C5

C2

C2

GND

B4

B4

B3

B3

B5

B5

B2

B2

GND

A4

A4

A3

A3

A5

A5

A2

A2

GND

A1

A1

MH4

MH4

MH5

MH5

A3RP/13P/BL,LI,PK/RA/D/1/B

MH1
MH2
MH3

BLUE

LINE-IN

GREEN

LINE-OUT

PINK

MIC-IN

MH1
MH2
MH3

4

AZALIA FRONT PANEL

FAUDIO_JD[20]

3

MIC2_L[20]

LINE2_R[20]
LINE2_L[20]

CQ4

BAT54A/SOT23/200mA

LINE2_VREFO[20]

CQ2

BAT54A/SOT23/200mA

MIC2_VREFO[20]

CBC6 10u/8/X5R/6.3V/K
CBC5 10u/8/X5R/6.3V/K

100u/OS/D/6.3V/66/A/35m

1

+

CEC9

1

+

CEC6

100u/OS/D/6.3V/66/A/35m

CR13 62/4
CR11 62/4

L2_R

CR57 62/4

L2_L

CR53 62/4

L2_R
L2_L

SOT23

CR52 8.2K/4
CR56 8.2K/4

SOT23

CR10 8.2K/4
CR9 8.2K/4

M2_L
M2_R

L2-R
L2-L

180p/4/NPO/50V/J

2

VT2021

CR12 0/4/X

CBC30

2
4

CR55 20K/4/1

6

CR59 39.2K/4/1

10

CBC36

180p/4/NPO/50V/J

Digital Area

3VDUAL

CR62

8.2K/4/X

CR58 22K/4
CR54 22K/4

CBC29

180p/4/NPO/50V/J

VT2021

F_AUDIO

1
3
5
7
9

BH/2*5K8/GED/2.54/VA/AUDIO/PRT/TUR180

CBC37

180p/4/NPO/50V/J

Gigabyte Technology

Title

Size Document Number Rev
Custom

Date: Sheet

AUDIO JACK

GA-H77-DS3H

1

21 35Tuesday, February 21, 2012

-ACZ_DET [12]MIC2_R[20]

1.0

of

Gigabyte Confidential

Do not Copy

5

4

3

2

1

VSENG

DBC93 0.01u/4/X7R/25V/K

DBC95 0.01u/4/X7R/25V/K

RTNG

DR450 10/4

DBC66

0.1u/4/X7R/16V/K

DR79
100/4/1

DR445 8.2K/4
DR482 1K/4/1

DBC67

0.22u/4/X5R/6.3V/K

0.22u/6/X7R/16V/K/X

disable PWM2G

0/4/SHT/M/X

Disable NTCG
function

DR456 27K/4/1

DR85 51/4/1

DRT1 100K/1/4/S/X

DR59 27K/4/1

ISEN3
ISEN2
ISEN1

DR475
100/4/1

DR162 487/4/1

Iocp --> 50A

DBC96

DR454

DR156
0/4

CPU_VAXG

DR45

DBC113

DBC69

0.1u/4/X7R/16V/K

VIDSLCK_VR[4]

-VIDALRT_VR[4]
VIDSOUT_VR[4]

DR82 10/4/X

VTT_PWRGD[24,27]

0/4/SHT/M/X

VSUMN[23]

DRT4
10K/1/4/S

DR157

7.5K/4/1

VAXG_ADJ[25]

D D

VSUMNG[23]

0.1u/4/X7R/16V/K

Close DL6

VSUMPG[23]

C C

VR_HOT[24]

B B

VAXG_SENSE[4]

FBG_OV

VAXG_VSS[4]

DR159
11K/4/1

DBC64

0.047u/4/X7R/16V/K/X

CPU_VTTP

DR76

DR84

DR81
100/4/1/X

100/4/1

100/4/1

DBC100 0.22u/6/X7R/16V/K
DBC101 0.22u/6/X7R/16V/K
DBC102 0.22u/6/X7R/16V/K

FBG_OV

ISUMPG

VCC

ISEN2G

PVIDSLCK_F

DR446
845/4/1

DBC114
330p/4/NPO/50V/J

DU1

1
2
3
4
5
6
7
8
9

10

41

ISEN3[23]
ISEN2[23]
ISEN1[23]

DR447

2.37K/4/1

ISUMNG

ISUMPG
ISEN1G
ISEN2G
NTCG
SCLK
ALERT#
SDA
VR_HOT#
VR_ON
NTC

PAD

ISEN3
ISEN2
ISEN1

DBC91
1n/4/X7R/50V/K

RTNG

40

39

RTNG

ISUMNG

ISEN2

ISEN3/FB2

12

11

DR444
2K/4/1

DBC94

680p/4/X7R/50V/K

FBG

VAXG_RDY

COMPG

38

37

FBG

COMPG

INTERSIL

ISL95836HRTZ

ISEN1

ISUMP

13

14

DBC90
330p/4/NPO/50V/J

DBC92 47p/4/NPO/50V/J

DR448
270K/4

DR452 8.2K/4

33

36

PGOODG

32

35

34

PWM2G

LGATE1G

PHASE1G

UGATE1G

PWM

COMP

PGOOD

FB

ISUMN

RTN

18

16

19

17

15

RTN

FB

COMP

DR449 169K/4/1

S.W frequncy-->300Khz
Imax-->45A

BOOT2

LGATE2

VCCP

VDD

PWM3

LGATE1

VR_RDY

DR453 0/4/X

30
29
28
27
26
25
24
23
22
21

VCC3

31

BOOT1G

UGATE2
PHASE2

PHASE1
UGATE1

BOOT1

ISL95836HRTZ/TQFN40/[10TA1-695836-01R]

20

PWM2G

LGS
PHS
UGS
BTS

DAL1

DR80
1K/4/1

VCC3

0.1u/4/X7R/16V/K/X

VR_RDY

1uH/30A/IMD0814/R/D

1

+

DEC6

270u/FP/D/16V/8C/A/10m

UGS
PHS
LGS

UG1
PH1
LG1
ISEN1

UG2
PH2
LG2
ISEN2

PWM3
ISEN3

3VDUAL

DR106

8.2K/4

DC1

DR87

8.2K/4
MMBT2222A/SOT23/600mA/40

UGS [23]
PHS [23]
LGS [23]

UG1 [23]
PH1 [23]
LG1 [23]
ISEN1 [23]

UG2 [23]
PH2 [23]
LG2 [23]
ISEN2 [23]

PWM3 [23]
ISEN3 [23]

DQ17
MMBT2222A/SOT23/600mA/40

SOT23

132

DQ16

V12

DBC1

VCC

BTS [23]

BT2

BT2 [23]

UG2
PH2
LG2

LG1
PH1
UG1

BT1

DBC98 1u/4/X5R/6.3V/K

DR457 0/4/SHT/M/X
DR458 1/6

DBC99 1u/4/X5R/6.3V/K

PWM3 [23]

BT1 [23]

1u/6/X7R/16V/K

VCC

VIN

1

+

DEC1
270u/FP/D/16V/8C/A/10m

VCC3

DR108
100K/4/1

SOT23

132

DR107
1K/4/1

N_PCH_VRMPWRGD [12]

DC17

0.1u/4/X7R/16V/K

VSUMP

VSUMP[23]

DBC104

Close
CHOKE

偵測溫度改成一邊各放一顆

PWM + OP MOSFET

A A

各放一邊

Rseries

DR42

2.61K/4/1

DRT3

10K/1/4/S

VSUMN

VSUMN[23]

DBC29

0.1u/4/X7R/16V/K

0.22u/4/X5R/6.3V/K

DR46
11K/4/1

RparallelRntc=(Rseries+DRT3)//Rparellel

DBC25

DBC23

0.22u/4/X5R/6.3V/K

DBC117

0.22u/4/X5R/6.3V/K

Ri

Iocp --> 150A

DR47
620/4/1

DBC20
330p/4/NPO/50V/J

DR49
100/4/1

DR462

3.24K/4/1/X
DBC107

1n/4/X7R/50V/K/X

VCORE_ADJ[25]

5

4

DR58 0/4/SHT/M/X

1n/4/X7R/50V/K

DBC108

0.01u/4/X7R/25V/K

DBC109

0.01u/4/X7R/25V/K

load-line --> 1.7mohm

DR463 3K/4/1

FB_OV

FB_OV

3

DR461
845/4/1

DR468 100/4/1

DR464 270K/4

x100

DR466 8.2K/4

DR472 1K/4/1

A_VSS_SENSE

DBC105
47p/4/NPO/50V/J

倍

VCORE

A_VCC_SENSE

A_VSS_SENSE [4]

DBC106
680p/4/X7R/50V/K

A_VCC_SENSE [4]

BOTTOM PAD
CONNECT TO
GND
THROUGH 10
VIA

ISEN3 [23]

DBC103

10p/4/NPO/50V/J/X

VBOOT

DR465

3.24K/4/1

VBOOT-->0V
Imax-->99A

2

FOR RMA

CPU_VTT

DR126 1K/4/1/X

VCC3

DR473

8.2K/4/X

DQ18
MMBT2222A/SOT23/600mA/40/X

SOT23

132

TDI[4]

DR474 510/4/1

改用此電阻

Set BT=PD 10K for Vboot=1.1V

Title

Size Document Number Rev
Custom

Date: Sheet

Gigabyte Technology

3

D

GS

2

,DQ19

CPU CORE VR-1

GA-H77-DS3H

1

VBOOT

DQ19
MMBT2222A/SOT23/600mA/40

SOT23

1

要換成

BJT

22 35Tuesday, February 21, 2012

of

1.0

Gigabyte Confidential

Do not Copy

5

DC2

0.22u/6/X7R/16V/K
DR6

0/6/SHT/M/X

BOOT
PVCC

6609_VCC

PWM3

DBC2

BOOT
PVCC

6609_VCC

PWM3

UG1

UG1 [22]

PH1

PH1 [22]

LG1

LG1 [22]

ISEN1

ISEN1 [22]

Pop ISL6625CB for PSI
[ISL6625CBZ/SO8]

PH3

DU2

2

BOOT

UGATE

7

PVCC

PHASE

6

VCC

3

PWM

LGATEGND

9

GND

ISL6208BCRZ/DFN8

DU3

2

BOOT

UGATE

7

PVCC

PHASE

6

VCC

3

PWM

LGATEGND

ISL6609ACBZ/SO8/X

1
8

54

1
8

54

D D

PWM3

PWM3 [22]

ISEN3

ISEN3 [22]

VCC +12V

DR3
1/6/X

DR90
0/6/SHT/M/X

DR4
0/6/SHT/M/X

C C

DBC4

1u/6/X7R/16V/K

0.1u/4/X7R/16V/K/X

6609 colay with 6208

UG2

UG2 [22]

PH2

PH2 [22]

LG2

LG2 [22]

ISEN2

ISEN2 [22]

B B

VAXG

DR480
0/6

DBC115

DR476

0/6/SHT/M/X

DR28 0/6/SHT/M/X

UGS_1

LGS_1

G

DR479

8.2K/4

DR25

2.2/6

G

DBC5
1n/4/X7R/50V/K

DQ15
RJK0393DPA-0G/N/4.3m/PPAKSO-8/[10IF9-040393-01R_10IF9-050840-01R]
DQ14
RJK0393DPA-0G/N/4.3m/PPAKSO-8/[10IF9-040393-01R_10IF9-050840-01R]

UGS

UGS[22]

PHS

PHS[22]

0.22u/6/X7R/16V/K

BTS[22]

LGS

A A

LGS[22]

4

DR9 0/6

UG1 UG1_1

PH1

BT1[22]

[1]

UG3

PH3

UG3

LG3

UG3
PH3

[3]

LG3

UG2 UG2_1

PH2
LG2 LG2_1

BT2[22]

[2]

560u/FP/D/6.3V/69/A/11m

VIN

D2D3D4

D5

DQ13
RJK0397DPA-0G/N/10.1m/PPAKSO-8[10IF9-100397-01R_10IF9-070428-01R]

S1D1S3

S2

D2D3D4

D5

G

S1D1S3

S2

VSUMPG[22]

DBC7
1u/6/X7R/16V/K

D2D3D4

S1D1S3

S2

DR484 3.6K/4/1

+

D5

1

DEC12
270u/FP/D/16V/8C/A/10m

DL6

0.6uH/42A/IMD0814/R/D

DR26
0/4/SHT/M/X

DR7

DR11 0/6

DR8

DR21 0/6

DR29

1

+

DEC7

560u/FP/D/6.3V/69/A/11m

R50

LG1_1LG1

0/6/SHT/M/X

0.22u/6/X7R/16V/K

0/6/SHT/M/X

LG3_1LG3

0/6/SHT/M/X

0/6/SHT/M/X

0.22u/6/X7R/16V/K

0/6/SHT/M/X

1

+

DEC9

560u/FP/D/6.3V/69/A/11m

CPU_VAXG

0.1u/4/X7R/16V/K
DR27
0/4/SHT/M/X

DBC111

DR470

UG3_1

DBC112

DR471

DBC118

1

+

DEC11

3

DR14

8.2K/4

11LC3-30500C-R1~R3

DR15

2.2/6

DC3
1n/4/X7R/50V/K

DR12

8.2K/4

11LC3-30500C-R1~R3

DR16

2.2/6
DC4

1n/4/X7R/50V/K

DR23

8.2K/4

11LC3-30500C-R1~R3

DR24

2.2/6
DC7

1n/4/X7R/50V/K

VCOREVCORE VCOREVCORE

1

1

+

+

DEC8

560u/FP/D/6.3V/69/A/11m

560u/FP/D/6.3V/69/A/11m

CPU_VAXG

+

DBC119
1u/4/X5R/6.3V/K

VCOREVCORE

DEC16

560u/FP/D/6.3V/69/A/11m

1

DEC14
560u/FP/D/6.3V/69/A/11m
DEC15
560u/FP/D/6.3V/69/A/11m

2

VIN

DBC11

D2D3D4

D5

1u/6/X7R/16V/K

UG1_1

PH1

LG1_1

UG3_1

PH3

LG3_1

UG2_1

PH2

1

+

LG2_1

DEC17

G

DQ1
RJK0397DPA-0G/N/10.1m/PPAKSO-8[10IF9-100397-01R_10IF9-070428-01R]

S1D1S3

S2

D2D3D4

G

DBC14
1u/6/X7R/16V/K

D2D3D4

G

DBC8
1u/6/X7R/16V/K

D2D3D4

G

D5

DQ5

VSUMP[22]

S1D1S3

S2

ISEN1[22]

VSUMN[22]

D5

DQ7

VSUMP[22]

S1D1S3

S2

ISEN3[22]

VSUMN[22]

D5

DQ11

VSUMP[22]

S1D1S3

S2

ISEN2[22]

VSUMN[22]

D2D3D4

D5

DQ4

G

S1D1S3

S2

RJK0393DPA-0G/N/4.3m/PPAKSO-8/[10IF9-040393-01R_10IF9-050840-01R]
RJK0393DPA-0G/N/4.3m/PPAKSO-8/[10IF9-040393-01R_10IF9-050840-01R]

VIN

D2D3D4

D5

G

DQ2
RJK0397DPA-0G/N/10.1m/PPAKSO-8[10IF9-100397-01R_10IF9-070428-01R]

S1D1S3

S2

D2D3D4

D5

DQ6

G

S1D1S3

S2

RJK0393DPA-0G/N/4.3m/PPAKSO-8/[10IF9-040393-01R_10IF9-050840-01R]
RJK0393DPA-0G/N/4.3m/PPAKSO-8/[10IF9-040393-01R_10IF9-050840-01R]

VIN

D2D3D4

D5

G

DQ10
RJK0397DPA-0G/N/10.1m/PPAKSO-8[10IF9-100397-01R_10IF9-070428-01R]

S1D1S3

S2

D2D3D4

D5

DQ12

G

S1D1S3

S2

RJK0393DPA-0G/N/4.3m/PPAKSO-8/[10IF9-040393-01R_10IF9-050840-01R]
RJK0393DPA-0G/N/4.3m/PPAKSO-8/[10IF9-040393-01R_10IF9-050840-01R]

VSUMP

ISEN1

VSUMN

Close to PWM

VSUMP

ISEN3

VSUMN

Close to PWM

VSUMP

ISEN2

VSUMN

0/4/SHT/M/X

DR171

3.6K/4/1

DR172
10K/4/1

DR173
10/4

0/4/SHT/M/X

DR176

3.6K/4/1

DR177
10K/4/1

DR178
10/4

0/4/SHT/M/X

DR181

3.6K/4/1

DR182
10K/4/1

DR183
10/4

1

DL2

0.6uH/42A/IMD0814/R/D

DR169

DL3

0.6uH/42A/IMD0814/R/D

DR174

DL5

0.6uH/42A/IMD0814/R/D

DR179

VCORE

DR170
0/4/SHT/M/X

DR438
10K/4/1

DR439
10K/4/1

VCORE

DR175
0/4/SHT/M/X

DR440
10K/4/1

DR441
10K/4/1

VCORE

DR180
0/4/SHT/M/X

DR442
10K/4/1

DR443
10K/4/1

112A Max

ISEN2

ISEN3

ISEN1

ISEN2

ISEN1

ISEN3

R50

R50

R50

Close to PWM

1

+

VSUMNG[22]

DR483 10/4

5

4

3

2

Title

Size Document Number Rev
Custom

Date: Sheet

Gigabyte Technology

CPU CORE VR-3

GA-H77-DS3H

23Tuesday, February 21, 2012

1

1.0

of

Gigabyte Confidential

Do not Copy

5

R622

8.2K/4

132

SOT23

5VSB

84

3

+

2

-

5VSB

84

5

+

6

-

5VDUAL_GATE

3

D

GS

2

1

C181
1n/4/X7R/50V/K/X

U17A

1

KA393D/SO8

U17B

7

KA393D/SO8

Q94
2N7002/SOT23/25pF/5

SOT23

5VDUAL

VCC=4.2V

R620 8.2K/4

VCC

R621

12K/4/1

C187
1u/4/X5R/6.3V/K

R612 10K/4/1

D D

5VSB

R618
10K/4/1

+12V=10V

R556 8.2K/4

+12V

R557

2.74K/4/1

MMBT2222A/SOT23/600mA/40

-SLP_S3

-SLP_S3[12,17,33]

R624

8.2K/4

Q93

C185
1u/4/X5R/6.3V/K

C158

0.1u/4/X7R/16V/K

5VSB

+12V

R555

RJK0397DPA-0G/N/10.1m/PPAKSO-8[10IF9-100397-01R_10IF9-070428-01R]

8.2K/4

5V_DRV

R554
1K/4/1

VCC

P_EN

5VSB

R553

8.2K/4/X

560u/FP/D/6.3V/69/A/11m

I/O ErP Control

C C

From I/O ErP
Control

PCH ErP Control

B B

From PCH ErP
Control

A A

-DEPSLP[12]

R667
270K/4

1u/4/X5R/6.3V/K

-DEPSLP[12]

5VL_EN

R650 0/4/SHT/X

ERP[17]

5VSB

R666

GS

22K/4

132

MMBT2222A/SOT23/600mA/40

C197

R520 270K/4

R682 8.2K/4

5VSB

R665

8.2K/4

3

D

Q104
2N7002/SOT23/25pF/5

SOT23

2

1

Q105

SOT23

C193
1u/4/X5R/6.3V/K

C198
1u/6/X7R/16V/K

3

D

GS

2

1

C199

0.1u/4/X7R/16V/K

5

D14

BAT54C/SOT23/200mA

5VSB

R477
150K/4

R476

C129

270K/4

0.1u/6/X7R/25V/K

FOR PCH ERP

5VL_EN

Q76
MMBT2222A/SOT23/600mA/40

SOT23

132

FOR PCH ERP

R681
1K/4/1

Q106

2N7002/SOT23/25pF/5

SOT23

5VSB

R573

8.2K/4

R574
1K/4/1

Q46
MMBT2222A/SOT23/600mA/40

SOT23

132

R576 0/4/SHT/M/X

P_EN

5VDUAL SHORT PROTECT

D13

SOT23

BAT54A/SOT23/200mA

P_EN

Q72
MMBT2907A/SOT23/-600mA/50

SOT23

132

5VSB

5VDUAL

-DEPSLP[12]

Q95

S3
S2
S1

Q96
P2003ED/P/TO252/30m

1
3

1

+

EC36

FOR PCH ERP

R577 8.2K/4

4

5VDUAL

G

D1
D2
D3
D4
D5

2

1

+

EC34

100u/OS/D/6.3V/66/A/35m

GS

5VL_EN

C163

0.1u/4/X7R/16V/K

4

FOR PCH ERP

5VSB

R578
22K/4

3

D

Q73
2N7002/SOT23/25pF/5

SOT23

2

1

3VDUAL

2

Q92

L1085DG/TO252/5A

-DEPSLP[12]

1u/4/X5R/6.3V/K

1u/4/X5R/6.3V/K

R579 220/6

R580 220/6

5VDUAL

BC231

0.1u/4/X7R/16V/K

3
1

3VDUAL

D21

BAT54A/SOT23/200mA

SOT23

DDRVTT

BC199

C137

5VDUAL

Q74
PMBT2907A/SOT23/-600mA/50

SOT23

132

5VSB

BC212
22u/8/X5R/6.3V/M/X

5VDUAL

132

5VSB

3VDUAL

R623
100/4/1

R626
169/4/1

R639 75K/4/1
R640 27K/4/1
C192 1u/4/X5R/6.3V/K

Q75
PMBT2907A/SOT23/-600mA/50

DDR_15V

5VSB

C

SOT23

BC225

0.1u/4/X7R/16V/K

5VSB

R508
1K/4/1

DDR_VTT_REF

R505
1K/4/1

FOR ERP

5VDUAL

R651

R581

220/6

220/6/X

R

Q79

A

AP431N/SOT23/150mA

3

R373 47K/4/1

1

+

EC32
560u/FP/D/6.3V/69/A/11m

-RSMRST

3

D

Q99
R638
22K/4

132

BC259
22u/8/X5R/6.3V/M

2N7002/SOT23/25pF/5

GS

SOT23

2

1

Q100
MMBT2222A/SOT23/600mA/40

SOT23

At least 10ms delay after
3VDUAL stabel

U13

1

VIN

2

GND

3
4 5

2_5LEVEL

ENABLE
VREF1
VOUT BOOT_SEL

GND

9

RT9173DPSP/3A/SO8/S

3

VREF2

VCNTL

DDRVTT

R519
0/6/X

8
7
6

-RSMRST

-RSMRST [12,17]

C115
1n/4/X7R/50V/K

Meet the rise time

VCC5VDUAL

R518
0/6/SHT/X

BC196

10u/8/X5R/6.3V/K

1A max

VCC1_8_PCH

BC207

1u/6/X7R/16V/K

OTP PROTECT

-PROHOT

VCC3

0.1u/4/X7R/16V/K

2

BC204

0.1u/4/X7R/16V/K/X

-PROCHOT[4]

+12V

CLOSE PWM HOT MOSFET

MMBT2222A/SOT23/600mA/40

-SLP_S3[12,17,33]

R484

8.2K/4

R483

BC194

8.2K/4

2

2_5LEVEL

0.1u/4/X7R/16V/K

R538

3.6K/4/1

VCC18_EN

R546
10K/4/1

VCC1_8_PCH_OV[25]

-PROCHOT

R418

R604

1.4K/4/1

10K/4/1

RS_VRM2

R425

100K/1/4/S

1K/4/1

5VSB

R569

8.2K/4

-SLP_S3

R570 22K/4

Q45

SOT23

132

MMBT2222A/SOT23/600mA/40

+12V

BC239

RJK0397DPA-0G/N/10.1m/PPAKSO-8[10IF9-100397-01R_10IF9-070428-01R]

U15A

411

LM324DR/SO14

3

+

1

2

-

C159
1n/4/X7R/50V/K

R561

40.2K/4/1

BC209

0.01u/4/X7R/25V/K/X

Q36

SOT23

BAT54A/SOT23/200mA/X

R458
0/4/SHT/M/X

RS2 CLOSE CPU VR MOSFET

R441 45.3K/4/1

+12V

TSM_52_5LEVEL
TSM_6

132

PWR_EN

R482
0/4/X

411

10

+

8

9

-

U15C
LM324DR/SO14

C175

0.1u/4/X7R/16V/K/X

VCC18_EN

3

D

Q60
2N7002/SOT23/25pF/5

GS

SOT23

2

1

C162
1n/4/X7R/50V/K/X

Q70

SOT23

VTT_PWRGD

3

D

Q56
2N7002/SOT23/25pF/5

GS

SOT23

2

1

3

D

Q41
2N7002/SOT23/25pF/5

GS

SOT23

2

1

C155
1n/4/X7R/50V/K/X

3

D

Q61
2N7002/SOT23/25pF/5

GS

PWR_EN

SOT23

2

1

Title

Size Document Number Rev

C

Date: Sheet

1

VCC3

Q20

D2D3D4

D5

R269 100/4/1

VR_HOT [22]

-CPU_HOT [11]

PCH GPIO7

TSM_7

VCC1_05_EN [25]

CPUPWROK [4,12]

C102

8.2K/4

R552
2K/4/1

110~126 degree

-PROCHOT

3

D

GS

2

1

3

D

GS

2

1

VTT_PWRGD [22,27]

G

S1D1S3

S2

1.6A max

VCC1_8_PCH

560u/FP/D/6.3V/69/A/11m

-PROCHOT [4]

Q34
2N7002/SOT23/25pF/5

SOT23

-THERM [17]

Q37
2N7002/SOT23/25pF/5/X

SOT23

Gigabyte Technology

DISCRETE POWER

GA-H77-DS3H

1

1

+

EC18

1.0

of

24 35Tuesday, February 21, 2012

Gigabyte Confidential

Do not Copy

VCC1_05_PCH

5

4

DDR_15V

3

2

1

BC151

+12V2_5LEVEL

U15B

411

LM324DR/SO14

5

+

6

-

7

R416 100/4/1

C114
1n/4/X7R/50V/K

R511

40.2K/4/1

R498 2K/4/1

R521

8.2K/4

10u/8/X5R/6.3V/K

0X200X2AADDRESS

R1(K)

OPEN
R2(K) 3.9
%VCC

U9

1

VDD

2

B_SEL

3

GND

4 5

SDA SCL

NCT3931U-2/SOT23-8/X

042

VREF1
VREF2
VREF3

8
7
6

VCCSA_ADJ [27]
VCC1_8_PCH_OV [24]
VTTD_ADJ [26]

SMBCLK [7,8,12,14,15,16,29]

BC144
100p/4/NPO/50V/J/X

D2D3D4

G

S1D1S3

S2

BC205

BC260
10u/8/X5R/6.3V/K/X

0X22

10

1.3
OPEN
100 75

D5

D2D3D4

D5

Q30
RJK0397DPA-0G/N/10.1m/PPAKSO-8[10IF9-100397-01R_10IF9-070428-01R]

G

Q33
RJK0397DPA-0G/N/10.1m/PPAKSO-8[10IF9-100397-01R_10IF9-070428-01R]

S1D1S3

S2

VCC1_05_PCH

8.5A max

1

+

EC24
560u/FP/D/6.3V/69/A/11m

0X26

3

2.210

D D

R535

13.7K/4/1

VCC1_05_EN[24]

BC195

1u/4/X5R/6.3V/K

C C

VCC1_05_EN

R524
10K/4/1

VCC1_05_PCH_OV

Voltage console

0X2A = 0%xVCC

R329 0/6/X

5VDUAL

R328 0/6/SHT/X

B B

3VDUAL

BC142

0.1u/4/X7R/16V/K/X

NCT_POWER

R344 1.3K/4/1/X
R345 10K/4/1/X

SMBDATA[7,8,12,14,15,16,29]

100p/4/NPO/50V/J/X

0X20 =
100%xVCC

SMBDATA[7,8,12,14,15,16,29] SMBCLK [7,8,12,14,15,16,29]

A A

BC158

0.1u/4/X7R/16V/K

NCT_POWER

R354 10K/4/1
R355 2.2K/4/1/X

up6262 0X20
VREF1 VCC1_05_PCH
VREF2 VCCSAVCC1_8_PCH

5

VREF3

FOR B75:3931

U11

1

VDD

2

B_SEL

3

GND

4 5

SDA SCL

NCT3931U-2/SOT23-8

VREF1
VREF2
VREF3

8
7
6

VCORE_ADJ [22]
VAXG_ADJ [22]
0_8LEVEL_DDR [33]

0X2A

VCORE

CPU_VTT DDR

4

Gigabyte Technology

Title

PCH CORE / VOLTAGE CONSOLE

Size Document Number Rev

B

3

2

Date: Sheet

GA-H77-DS3H

1

of

25 35Tuesday, February 21, 2012

1.0

Gigabyte Confidential

Do not Copy

5

4

3

2

1

CPU_VTT

G

TR32

8.2K/4

G

TQ4

VIN

VIN

TBC34

D2D3D4

D2D3D4

1u/6/X7R/16V/K

D5

TQ3
RJK0397DPA-0G/N/10.1m/PPAKSO-8[10IF9-100397-01R_10IF9-070428-01R]

S1D1S3

S2

D5

TR35

2.2/6

TBC37
1n/4/X7R/50V/K

S1D1S3

S2

VCC

TR27

2.2/6

D D

TR18

20K/4/1/X

TR19
27K/4/1

C C

VTT_EN

TBC35

3.3n/4/X7R/50V/K

TBC36
22p/4/NPO/50V/J

TR20
0/4/X

TR21
0/4/SHT/M/X

TBC30

1u/4/X5R/6.3V/K

TU1

7

COMP

5

UGATE

VCC

GND

PGND

RT8120DGS/SOP8

3

9

0/4/SHT/M/X

BOOT

PHASE

LG/OCFB

TQ10
BAT54C/SOT23/200mA/X

TBC33 0.1u/6/X7R/25V/K

1
2
8

46

TR45

VTT_VSS [4]

VTT_PHASE

VTT_LG1

TR34

OCP:46A for Rds=5.9m

27K/4/1

OCP:64A for Rds=4.2m

TR30 2.2/6

RJK0393DPA-0G/N/4.3m/PPAKSO-8/[10IF9-040393-01R_10IF9-050840-01R]

VTTD_ADJ[25]

VTT_UG1VTT_UGATE1

VTTD_ADJ

OCP:46A=Roset*Iocset / Rds(on)

=27K*10uA / 5.9m

B B

VCC1_05_PCH

CPU_VTT PWR SEQ

VCC3

TR43

8.2K/4

TR44

8.2K/4

TBC44

0.1u/4/X7R/16V/K

VCC3

TR42

8.2K/4/X

VTT_EN

3

D

GS

2

1

TQ9
MMBT2222A/SOT23/600mA/40

SOT23

132

TQ8
2N7002/SOT23/25pF/5

VIN

1

+

TEC5
270u/FP/D/16V/8C/A/10m

TL1

0.6uH/42A/IMD0814/R/D

R60

0.8V

HI
LO

VTT_SEL

1.05V

1.0V

17A MAX

TBC41

1u/4/X5R/6.3V/K

TR25
487/4/1

TC29

3.3n/4/X7R/50V/K

CPU_VTT

TR22
100/4/1

VTT_SENSE [4]

TR23
1K/4/1

TR24
3K/4/1

According intel
CDI/IBP#476733,

1.067V

CPU_VTT

1

+

TEC6
560u/FP/D/6.3V/69/A/11m

固定

1.05V

1

+

TEC7
560u/FP/D/6.3V/69/A/11m

A A

Title

RT8120_CPU_VTT

Size Document Number Rev

5

4

Custom

3

2

Date: Sheet

GA-H77-DS3H 1.0

of

26 35Tuesday, February 21, 2012

1

Gigabyte Confidential

Do not Copy

5

4

3

2

1

電容限高

VCC_SA

CPU_VTT

D D

0.1u/4/X7R/16V/K

VSA_SENSE[4]

C C

B B

VCCSA_ADJ[25]

PDG 1.01

HI
LO

VSA_SEL

0.85V

0.925V

2_5LEVEL

R528
10K/4/1

0.94V

BC201

R543 2K/4/1

R544 0/4/SHT/X

VSA_REF

R537

6.04K/4/1

BC203

0.01u/4/X7R/25V/K/X

According intel
CDI/IBP#476733, 0.925V

12
13

+12V

411

+

-

固定

U15D
LM324DR/SO14

14

R155 100/4/1

C157
1n/4/X7R/50V/K

R560

40.2K/4/1

C46

8.2K/4

R551
2K/4/1

10u/8/X5R/6.3V/K

D2D3D4

D5

G

Q12
RJK0397DPA-0G/N/10.1m/PPAKSO-8[10IF9-100397-01R_10IF9-070428-01R]

S1D1S3

S2

VCCSA

BC54

+

Check

8.8A@0.85/0.925

1

EC12
560u/FP/D/6.3V/69/A/11m

Check

電容限高

10mm

10mm

VCCSA PWR SEQ

VCC

CPU_VTT

R481

V

VCCSA

1K/4/1

R192 1K/4/1

0.1u/4/X7R/16V/K

C128

0.1u/4/X7R/16V/K/X

5VDUAL

R191

8.2K/4

132

C72

R564
22K/4

SOT23

132

Q44
MMBT2222A/SOT23/600mA/40

CPU_VTT

R193

8.2K/4

3

D

Q17
2N7002/SOT23/25pF/5

GS

SOT23

2

1

Q16
MMBT2222A/SOT23/600mA/40

SOT23

VSA_REF

3

D

Q68
2N7002/SOT23/25pF/5

GS

SOT23

2

1

C161

0.1u/4/X7R/16V/K/X

VTT_PWRGD [22,24]

A A

5

4

3

2

Gigabyte Technology

Title

VCCSA POWER

Size Document Number Rev

Custom

Date: Sheet

GA-H77-DS3H

1

of

27 35Tuesday, February 21, 2012

1.0

Gigabyte Confidential

Do not Copy

8

7

6

5

4

3

2

1

FRONT USB1

FUSEVCC_F1 FUSEVCC_F2

BC122

0.1u/4/X7R/16V/K

PCH_USB3_RXN1[9]

D D

C C

PCH_USB3_RXP1[9]

PCH_USB3_TXN1[9]
PCH_USB3_TXP1[9]

USB3_TXP1
USB3_TXN1

9

10

RUE3

USB3_TXN1 PCH_USB3_RXP2
USB3_TXP1

NC

NC

D1+

D1-

1

2

USB3_TXN1

C2150.1u/4/X7R/16V/K

USB3_TXP1

C2160.1u/4/X7R/16V/K

-USBP0[9]

+USBP0[9]

7

8

NC

GND

11

GND

D2+

3

4

F_USB30

REV=1

1

VBUS

10

ID

2

SSRX1-

3

SSRX1+

5

SSTX1-

6

SSTX1+

8

D1-

9

D1+

7

GND

4

GND

BH/2*10K20/BU/ON/2.0/VA/D/GF/[11NH3-020210-21R]

USB3_TXN2
USB3_TXP2

6

NC

D2-

AZ1045-04F/MSOP10

5

USB3_TXP2
USB3_TXN2

19

VBUS

15

SSTX2-

14

SSTX2+

18

SSRX2-

17

SSRX2+

12

D2-

11

D2+

16

GND

13

GND

PCH_USB3_RXP1
PCH_USB3_RXN1

RUE4

PCH_USB3_RXN1
PCH_USB3_RXP1

USB3_TXN2
USB3_TXP2

10

1

NC

D1+

BC124

0.1u/4/X7R/16V/K

C2130.1u/4/X7R/16V/K
C2140.1u/4/X7R/16V/K

-USBP1 [9]
+USBP1 [9]

8

9

NC

GND

11

D1-

GND

2

3

PCH_USB3_TXN2 [9]
PCH_USB3_TXP2 [9]

PCH_USB3_RXN2 [9]
PCH_USB3_RXP2 [9]

PCH_USB3_RXN2

PCH_USB3_RXP2

6

7

NC

NC

D2-

D2+

5

4

PCH_USB3_RXN2

AZ1045-04F/MSOP10

5VDUAL

GPIO11[12]

ESD12

-USBP1

1
2

+USBP0

3 4

AZC009-04S/SOT23-6L

F17 SMD1812P350SLR/S/[10FP1-06350B-20R]

1

F18 SMD1812P350SLR/S/[10FP1-06350B-20R]

+

EC23
100u/OS/D/6.3V/66/A/35m

6
5

1 2

1 2

F_USB POWER PROTECT

D11

3

BAT54A/SOT23/200mA

+USBP1

5VDUAL

-USBP0

FUSEVCC_F1

FUSEVCC_F2

SOT23

-USBOC_F

1

-USBOC_R

2

SATA LED

-USBOC_R [9,31]

-MSATALED[32]

-SATALED[11]

FPD3

2

3

1

BAT54A/SOT23/200mA

SOT23

VCC3

VCC3

R490

R491

1K/4/1

8.2K/4

MMBT2222A/SOT23/600mA/40

Q53

R489
1K/4/1

SOT23

132

Q39
MMBT2222A/SOT23/600mA/40

R530 1M/4

-HDLED

C124
180p/4/NPO/50V/J/X

SOT23

132

CASE OPEN

-CASEOPEN

BC198

0.01u/4/X7R/25V/K

-CASEOPEN [17]RTCVDD[12,13]

ESD Close to connector ESD Close to connector

VCC

FRONT USB1

0.1u/4/X7R/16V/K

BH/2*5K9/BU/ON/2.54/VA/D/GF/[11NH3-001205-41R_11NH3-001205-42R]

B B

FUSEVCC_F4

BC267

-USBP4[9]
+USBP4[9] +USBP5 [9]

ESD11

-USBP4 +USBP4

1
2

-USBP5 +USBP5

3 4

AZC009-04S/SOT23-6L

F_USB1

132
5 6

FUSEVCC_F5

4
87

10

6
5

BC269

0.1u/4/X7R/16V/K

-USBP5 [9]

FUSEVCC_F4

FRONT USB2

0.1u/4/X7R/16V/K

BH/2*5K9/BU/ON/2.54/VA/D/GF/[11NH3-001205-41R_11NH3-001205-42R]

ESD Close to connector ESD Close to connector

5VDUAL

F15 SMD1812P160/8V

1 2

F20 SMD1812P160/8V

1 2

F21 SMD1812P160/8V

A A

1 2

F22 SMD1812P160/8V

1 2

1

+

EC19
100u/OS/D/6.3V/66/A/35m

8

FUSEVCC_F4

FUSEVCC_F5

FUSEVCC_F8

FUSEVCC_F9

5VDUAL

7

FUSEVCC_F8

BC250

-USBP8[9] -USBP9 [9]
+USBP8[9]

-USBP8

-USBP9

R274

8.2K/4

ESD13

1
2
3 4

AZC009-04S/SOT23-6L

-USBOC_F

R276
15K/4/1

F_USB2

132
5 6

3

3

3

6

FUSEVCC_F9

4
87

10

+USBP8

6
5

+USBP9

SOT23

1
2

BAT54A/SOT23/200mAD23

SOT23

1
2

BAT54A/SOT23/200mAD25

SOT23

1
2

BAT54A/SOT23/200mAD26

-USBOC_F [9]

BC270

0.1u/4/X7R/16V/K

+USBP9 [9]

FUSEVCC_F8

FUSEVCC_F1

FUSEVCC_F2

FUSEVCC_F4

FUSEVCC_F5

FUSEVCC_F8

FUSEVCC_F9

-RST

-PWRBT_1 -PWRBT_1

AZC009-04S/SOT23-6L

5

INTEL FRONT PANEL

5VSB

-SYS_RST[12,29]

0.01u/4/X7R/25V/K

ESD10

1
2
3 4

6
5

Rev 0.2 modefy

R495 8.2K/4/X
R497 100/4/1

BC197

-RST

4

5VSB

BEEP-[17]

for ITE8728
rstconin isuue

VCC

R419
330/6

-HDLED

-RST

-CASEOPEN

MPD+

VCC

R591
1K/4/1

3

D

R583

8.2K/4

GS

BEEP-

2

1

Q88
2N7002/SOT23/25pF/5

BC206

0.01u/4/X7R/25V/K/X
F_PANEL

1

MSG/PD+

HD+

3

MSG/PD-

HD-

5

GND

7

RESET

9

CI-

11

CI+

15

PWR+

17

PWR-

19

PWR-

BH/2*10K10,12,13/WH/2.54/VA/PA

3

PW+

PW-

SP+

R610
75/6/1

SPK-

SOT23

2
4
6
8

14
16

NC

18

NC

20

SP-

SOT23

132

Q77
MMBT2222A/SOT23/600mA/40

3VDUAL_PCH

MPD+HD+

-PWRBT_1

VCC

SPK-

R611
75/6/1

R472

8.2K/4
R469 33/4

C127

0.01u/4/X7R/25V/K/X

Title

Size Document Number Rev
Custom

Date: Sheet

2

D16
CD4148WP/1206/300mA

VCC3

SPKR

GPIO28 [12]

Q78
MMBT2222A/SOT23/600mA/40

132

R584 8.2K/4

R:0.2

VCC

R438
330/6

MPD+

132

R470 8.2K/4

-PWRBTSW [17]

BC190

0.01u/4/X7R/25V/K

To disable TCO
timer

SPKR

SPKR [12]

修正

Q38
MMBT2222A/SOT23/600mA/40

SOT23

Gigabyte Technology

FP,F_USB,USB PWR,FDD,BZ

GA-H77-DS3H

28 35Tuesday, February 21, 2012

of

1

R585
1K/4/1

R:0.2

修正

1.0

Gigabyte Confidential

Do not Copy

8

D D

C C

-PSON[17,33]

BC216

0.1u/4/X7R/16V/K

-5V
VCC
VCC

BC218

1u/6/X7R/16V/K

MH1

654

3

7

2

8

19

HOLE_3/X

101112

MH4

654

3

7

2

8

19

HOLE_3/X

101112

7

BC219

0.1u/4/X7R/16V/K/X

MH2

654

7
8

101112

MH5

654

7
8

101112

6

ATX POWER CONNECTOR

VCC3

-12V

BC230

0.1u/4/X7R/16V/K/X

APW/2*12/IV/VA/SN/2SHK/PA66

MH3

3
2
19

HOLE_3/X

MH6

3
2
19

HOLE_3/X

ATX

13

3.3V

14

-12V

15

GND

GND

16

PSON

17

GND

GND

18

GND

19

GND

GND

20

-5V

POK

21

5V

5VSB

22

5V

23

5V

24

GND

654

3

7

2

8

19

HOLE_3/X

101112

AGND1

654

3

7

2

8

19

HOLE_3/X

101112

3.3V

3.3V

3.3V

5

VCC3

1
2
3
4

5V

5
6

5V

7
8
9
10

12V

11

12V

12

MH8

7
8

654

101112

BC217
510/6/X

To prevent the 5VSB
under loading when
boot

3
2
19

HOLE_3/X

BC221
510/6/X

BC222
1u/6/X7R/16V/K

1

1

4

BC214
10u/8/X5R/6.3V/K

BC223

0.1u/4/X7R/16V/K

K3

K1_ICT/X

K5

K1_ICT/X

BC215
1u/4/X5R/6.3V/K

BC220

0.1u/4/X7R/16V/K

K6

K1_ICT/X

1

K1

K1_ICT/X

1

VCC3VCC3VCC3

BC227
1u/4/X5R/6.3V/K

PWOK [17]

BC224

0.1u/4/X7R/16V/K

1

1

VCC

VCC

+12V

K2

K1_ICT/X

K4

K1_ICT/X

3

1

AD1
AZ2225-01L/SOD323

I1

4MMH/X

I3

4MMH/X

I5

4MMH/X

5VSB

I2

4MMH/X

I4

4MMH/X

2

V12

4

APW/2*2/IV/P/4.2/SN/PA66

BC25

0.1u/4/X7R/16V/K

ATX_12V

+12V

GND
GND+12V

1

1
23

3VDUAL

CLK GEN CK505

BC74

FB1
30/6/4A/S

BC79
1u/4/X5R/6.3V/K

U5

31

DOC_0

32

DOC_1

B B

SRCCLK_SATA[11]

-SRCCLK_SATA[11]
SRCCLK_PCH[9]

-SRCCLK_PCH[9]
DOTCLK[9]

-DOTCLK[9]

LPC_48

VCC3

R230 33/4
R644 10/4

R261 8.2K/4/X

R240 1K/4/1/X
R232 8.2K/4

PCHCLK14[10]

-SYS_RST[12,28]

CKVDD

PWROK1[11,12,17]

A A

FS_133M

CPU_STP

5

CPUT_LR

6

CPUC_LR

24

SATACLKT_LR

23

SATACLKC_LR

9

PCIEXT_LR

10

PCIEXC_LR

13

DOT96T_LR

14

DOT96C_LR

16

48M/FSLB

15

24_12M

29

25M

19

REF/FSLA

30

RLATCH/RESET_IN#/RESET#

17

VTTPWRGD/WOL_STOP#

9LRS4105BKLFT/MLF32

BC73

0.1u/4/X7R/16V/K/X

VCC3

R229 8.2K/4/X
R239 8.2K/4

FS_133M

VDD96

VDDSATA

VDDPCIEX

VDDCPU
VDDREF

VDD25

SDATA

SCLK

GNDPAD
GNDCPU

GNDPCIEX

GND96

GNDREF

GNDSATA

GND25

11
25
7
3
22
28

20

X1

21

X2

2
1

33
4
8
12
18
26
27

R255 8.2K/4

PCHCLK14

1u/4/X5R/6.3V/K

C89 27p/4/NPO/50V/J

C88 27p/4/NPO/50V/J
R238 10/4
R237 10/4

LPC_48

C85 10p/4/NPO/50V/J/X

BC75

1u/4/X5R/6.3V/K

X1

14.318M/16p/20ppm/49US/40/D

CKVDD

BC80

C83

100p/4/NPO/50V/J/X
C84
100p/4/NPO/50V/J/X

BC72

1u/4/X5R/6.3V/K

SMBDATA [7,8,12,14,15,16,25]
SMBCLK [7,8,12,14,15,16,25]

BC78

0.1u/4/X7R/16V/K

1u/4/X5R/6.3V/K

CPU Frequency Selection

CPU

FS
0

100M <Default>

1 133M

8

7

6

5

4

3

BC68
1u/4/X5R/6.3V/K

Gigabyte Technology

Title

ATX POWER CONNECTOR

Size Document Number Rev
Custom

Date: Sheet

GA-H77-DS3H

2

29 35Tuesday, February 21, 2012

of

1

1.0

Gigabyte Confidential

Do not Copy

8

TEMP H/W MONITOR

VREF[17]

SYS_TEMP[17]

D D

CPU_TEMP[17]

PWM_TEMP[17]

C11

1u/4/X5R/6.3V/K

C12
1u/4/X5R/6.3V/K

VOLTAGE-- H/W MONITOR

**

VCC3

R23

6.49K/4/1

C C

VIN1[17]
VIN2[17]
VIN3[17]

R22

C4

10K/4/1

1u/4/X5R/6.3V/K

The division voltage of VIN2 &
VIN3 must be around 2.9V FOR DX,

2.0V FOR EX

KB/USB

B B

0.1u/4/X7R/16V/K

-USBP10[9]
+USBP10[9]

KBDATA
KBCLK

A A

-USBP10 +USBP10

ESD Close to connector

KDAT[17]
KCLK[17]

BC13

U5
U6
U7
U8

ESD6

1
2
3 4

AZC009-04S/SOT23-6L

8

+12V VCC

R25

75K/4/1

0.1u/4/X7R/16V/K/X

IT8728 EX IT8728 EX

C5

R27
15K/4/1

1u/4/X5R/6.3V/K

KCLK

KB_MS_USB

1
2
5
6

U1
U2

13 57

U3
U4

24 68

USB

4

3

KB

G1G2G3

G4

KB/USB/A/PC99(DUAL)/GF/2/RA/D

6
5

-USBP11+USBP11

BC249

1u/4/X5R/6.3V/K

FUSEVCC_R11FUSEVCC_R10

7

R42
10K/4/1

RS_SYS
10K/1/4/S

Close SIO

*

R34
15K/4/1

2.0V2.0V

R30

C6

10K/4/1

82/4R38
82/4R46

BC268

0.1u/4/X7R/16V/K

-USBP11 [9]
+USBP11 [9]

FUSEVCC_R11

FUSEVCC_R10

7

6

Rev 0.2 modefy

R756

8.2K/4

R758

8.2K/4

VCORE

VIN5[17]
VIN6[17]
VIN0[17]
VIN4[17]

1u/4/X5R/6.3V/K

KBDATAKDAT
KBCLK

FUSEVCC_R11

R757

8.2K/4

RS_PWM

8.2K/4

CLOSE CPU
VCORE MOS

DDR_15V

R35

R39

8.2K/4

8.2K/4

C8

1u/4/X5R/6.3V/K

C232
1u/4/X5R/6.3V/K/X

CPU_VTT

R24

8.2K/4

IT8728 EX

C1

C10

1u/4/X5R/6.3V/K

1u/4/X5R/6.3V/K

BC11

180p/4/NPO/50V/J

8.2K/4R45

8.2K/4R37

180p/4/NPO/50V/J

KCLK
KDAT

CPU_VAXG

BC8

OR76

8.2K/4

OC10

FANPWM1[17]

FANPWM4[17]

SYS FAN

FANPWM2[17]

FOR EMI ONLY

R20 0/6/SHT/M/X

6

5

R753
1K/4/1

VCC

R733

8.2K/4

SHORT PROTECT
R0402-2

1u/6/X7R/16V/K

VCC3

C210

VCC

R754 22K/4

1u/4/X5R/6.3V/K

R734
100/4/1

R630
0/4

SYS_FAN2
FAN/1*4/WH/A3/PA66

CPUFAN_VCC

R752
1K/4/1/X

BC273

+12V

213

4

GVS

C

4

Linear SYS_FAN

VCC VCC3 +12V

R357

8.2K/4

R356
22K/4

4

5

R384

1K/4/1/X

+12V

C21
1n/4/X7R/50V/K

R375
1K/4/1

R372 22K/4

BC164

1u/4/X5R/6.3V/K

+12V

R750
22K/4

R755

8.2K/4

5
6

R628

3.3K/4/1
R627

15K/4/1

+12V

84

3

+

2

-

84

U12B

+

-

LM358DR/SO8

CPU SMART FAN

BC272

0.1u/4/X7R/16V/K

U12A

1

LM358DR/SO8

R625

6.2K/4/1

R171

8.2K/4

7

3

+12V+12V

R751

8.2K/4

P2003ED/P/TO252/30m

100u/OS/D/16V/69/A/35m

C189

0.047u/4/X7R/16V/K

3

100u/OS/D/16V/69/A/35m

Q114

EC39

FANPWM5[17]

FANIO3 [17]

1

Q11
P2003ED/P/TO252/30m

2

3

R749

8.2K/4

FANPWM3[17]

1

3

2

CPUFAN_VCC

1

+

R717

8.2K/4

SHORT PROTECT
R0402-2

1u/6/X7R/16V/K

1

+

EC33

VCC

VCC

100/4/1

VCC

C211

C212

1u/6/X7R/16V/K

2

132

R288

+12V

CPU_FAN
FAN/1*4/WH/A3/PA66

R114
100/4/1

OQ1
BAV99/SOT23/300mA/X

R348
0/4/X

213

4

GVS

C

+12V

R97
0/4

213

4

GVS

SYS_FAN3
FAN/1*4/WH/A3/PA66

R98
0/4/X

FAN/1*4/WH/A3/PA66

C

Anti Spike

+12V

R279

3.3K/4/1
R280

15K/4/1

+12V

R96

3.3K/4/1
R95

15K/4/1

R735

8.2K/4

213

GVS

SYS_FAN1

C105

R281

0.047u/4/X7R/16V/K

6.2K/4/1

R94

6.2K/4/1

+12V+12V VCC

R101

3.3K/4/1

R103
15K/4/1

4

C

1

FANIO1 [17]

C19

0.047u/4/X7R/16V/K

R107

0.047u/4/X7R/16V/K

6.2K/4/1

Gigabyte Technology

Title

Size Document Number Rev

Custom

Date: Sheet

HWM,KB/MS, FAN CTRL

GA-H77-DS3H

2

30 35Tuesday, February 21, 2012

1

C20

of

FANIO4 [17]

FANIO2 [17]

1.0

Gigabyte Confidential

Do not Copy

PCIE-1G LAN

D D

3VDUAL

AR8161-->N/A
(LABC12)

LAX1

C C

25M/20p/30ppm/49US/20/D

LAC31
27p/4/NPO/50V/J

SCH BOM OPT:(

-->(LAC30):M/B

-->(LAX1,LAC31,LAC32):M/B

USB30_LAN CONNECTOR

-USBP13

1
2

+USBP12 -USBP12

B B

LA_LED_LINK100

LA_LED_LINK1000

A A

USB3_TXN4
USB3_TXP4

RUE2

USB3_TXP4
USB3_TXN4

3 4

AZC009-04S/SOT23-6L

1
2
3 4

AZC009-04S/SOT23-6L

10

NC

D1+

1

5

離IC近越好

LA_-SRCCLK_LAN[10]

LA_SRCCLK_LAN[10]

LA_ML_OP[9]

LA_ML_ON[9]

3VDUAL

LABC9
10u/8/X5R/6.3V/K

LAC33

LAR6

8.2K/4

LA_XTALI

LA_XTALO

二擇一使用

有

CLK GEN 25M

ESD7

LAESD1

9

NC

D1-

2

100p/4/NPO/50V/J/X

-PFMRST2[17,18,35] LA_ML_IN [9]

-PCIE_WAKE[12,14,15,16]

LABC12
1u/4/X5R/6.3V/K

LABC15
1u/4/X5R/6.3V/K

LABC16

0.1u/4/X7R/16V/K

LAC32
27p/4/NPO/50V/J

)

無

CLK GEN 25M

+USBP13

6
5

6
5

8

11

354

5

LA_LED_ACT_TXRX
LAN_3VDUAL_LED

LA_LED_D2

7

NC

GND

GND

D2+

FUSEVCC_R13

PCH_USB3_TXN3[9]
PCH_USB3_TXP3[9]

LABC10
1u/4/X5R/6.3V/K

LABC18
1u/4/X5R/6.3V/K

LABC19

0.1u/4/X7R/16V/K

USB3_TXP3

6

NC

D2-

AZ1045-04F/MSOP10

USB3_TXN3
USB3_TXP3

LABC11

0.1u/4/X7R/16V/K

LA_-CLKREQ
LA_VDDCT
LA_AVDDL
LA_XTALO
LA_XTALI
LA_AVDDH

歐姆

100

FUSEVCC_R3

0.1u/4/X7R/16V/K

PCH_USB3_RXN3[9]
PCH_USB3_RXP3[9]

UC3 0.1u/4/X7R/16V/K
UC4 0.1u/4/X7R/16V/K

0.1u/4/X7R/16V/K
LAC1
LAC2

0.1u/4/X7R/16V/K

LABC4
1u/4/X5R/6.3V/K

LABC3

0.1u/4/X7R/16V/K

LAU1

41

1

VDD3V

2

PERST#

3

WAKE#

4

CLKREQ#

5

VDDCT/ISOLAT

6

AVDDL_REG

7

XTLO

8

XTLI

9

AVDDH_REG

10

RBIAS

LA_RBIAS

LAR10

2.37K/4/1

LABC20

0.1u/4/X7R/16V/K

AR8161-->N/A
(LABC20)

:[20/4/8/4/20]

LABC23 0.1u/4/X7R/16V/K

LA_MDI0+
LA_MDI0­LA_MDI1+
LA_MDI1­LA_MDI2+
LA_MDI2­LA_MDI3+
LA_MDI3-

LABC25
0/4/SHT/M/X

BC5

USB3_TXN3
USB3_TXP3

PCH_USB3_RXP4
PCH_USB3_RXN4

10

RUE1

1

PCH_USB3_RXN4
PCH_USB3_RXP4

LA_ML_OP_C
LA_ML_ON_C

LA_LX

40

EGND

111213141516171819

LA_MDI0+

LA_AVDD_CEN

GND_L10

-USBP2
+USBP2

9

NC

D1+

2

4

LA_AVDDVCO

LA_DVDDL

LA_LED_ACT_TXRX

LA_LED_LINK100

LX

LED0

LED1

RX_P

RX_N

AVDDL

REFCLKP

REFCLKN

DVDDL_REG

Atheros

AR8151/AR8161

TRXP0

TRXN0

AVDDL/NC

TRXP1

TRXN1

AVDDH/AVDD33

TRXP2

TRXN2

AVDDL

LA_MDI2+

LA_MDI1+

LA_AVDDL

LA_MDI1-

LA_AVDDL

LA_MDI2-

LA_MDI0-

LA_AVDD33

LAR19 0/4/X

LAR20 0/4/SHT/M/X

LABC22
1u/4/X5R/6.3V/K

USB_LAN
USB+LAN/1G/GO,Y/OS/RA/D/1

L1
L2
L3
L4
L5
L6
L7
L8
L9

L10

R_USB30
USB/18P/BU/OS/RA/D/2/1U/SB

U1

VBUS

U2

D-

U3

D+

U4

GND

U5

SSRX-

U6

SSRX+

U7

GND

U8

SSTX-

U9

SSTX+

8

NC

GND

11

D1-

GND

354

4

LA_ ML-->80歐姆:[15/5/5/5/15]

歐姆

VBUS

GND

GND

30
29
28
27
26
25
24
23
22
21

D­D+

:[18/4/10/4/18]

0.1u/4/X7R/16V/K/X

LA_ ML-->80

LA_ML_IP_C
LA_ML_IN_C

0/4/SHT/M/X

LA_PPS
LA_LED_LINK1000
LA_AVDDH
LA_MDI3-

LA_LED_ACT_TXRX

D1

LA_LED_D2

D2

LA_LED_LINK100

D3

LA_LED_LINK1000

D4
U1

U2
U3
U4
U5
U6
U7
U8

-USBP12 [9]
+USBP12 [9]

-USBP13 [9]
+USBP13 [9]

90歐姆:[15/4.5/7.5/4.5/15]

U10

-USBP3

U11

+USBP3

U12
U13
U14
U15
U16

USB3_TXN4

U17

USB3_TXP4

U18

SRCCLK-->50

LABC5

0.1u/4/X7R/16V/K

LABC6

0.1u/4/X7R/16V/K

AR8161-->N/A
(LABC6)

LA_AVDDL

313233343536373839

AVDDL/NC

TX_P
TX_N

NC

TESTMODE

SMDATA

SMCLK

DVDDL/PPS

LED2

AVDDH

TRXN3

TRXP3

AR8151-BL1A-R/S/[10HP2-408151-20R]

20

LA_MDI3+

LABC21

0.1u/4/X7R/16V/K

3VDUAL
LA_AVDDH

AR8151:LA_AVDDH(LAR20)
AR8161:3VDUAL(LAR19)

UP

DOWN

USB3.0/2.0

SSRX-

SSRX+

SSTX-

SSTX+

AGND

AGND

AGND

AGND

G1G2G3

G4

PCH_USB3_RXN3
PCH_USB3_RXP3USB3_TXN3

6

7

NC

NC

D2-

D2+

AZ1045-04F/MSOP10

PCH_USB3_RXP3
PCH_USB3_RXN3

3

LA_AVDDVCO

LABC7

LABC8

4.7u/6/X5R/6.3V/K/X

AR8161-->(O)

歐姆

:[15/5/5/5/15]

離IC近越好

LAC12 0.1u/4/X7R/16V/K
LAC13 0.1u/4/X7R/16V/K

LABC14

LAR9

0.1u/4/X7R/16V/K

LA_DVDDL

LABC17

0.1u/4/X7R/16V/K

LAR21 150/6

LAR22 150/6
LAR23 150/6

PCH_USB3_RXN4 [9]
PCH_USB3_RXP4 [9]

UC2 0.1u/4/X7R/16V/K
UC1 0.1u/4/X7R/16V/K

Close to R_USB30Close to R_USB30

LA_ML_IP [9]

LAN_3VDUAL_LED

FUSEVCC_R13

LBC27

0.1u/4/X7R/16V/K

FUSEVCC_R4

BC9

0.1u/4/X7R/16V/K

AR8161-->N/A
(LAR9,LAC18)

3VDUAL

LAFB1
0/6/SHT/M/X

LABC24

0.1u/4/X7R/16V/K/X

FUSEVCC_R12

PCH_USB3_TXN4 [9]
PCH_USB3_TXP4 [9]

90歐姆:[20/4.5/7.5/4.5/20]90歐姆:[20/4.5/7.5/4.5/20]

-USBP2[9]
+USBP2[9]

-USBP3[9]
+USBP3[9]

+USBP3

-USBP2

ESD3

1
2
3 4

AZC009-04S/SOT23-6L

-USBP2
+USBP2

-USBP3
+USBP3

-USBP3

6
5

+USBP2

Close to connector

3

LBC6

0.1u/4/X7R/16V/K

FUSEVCC_R4

LAN POWER

MDI : AR8161-->N/A

5VDUAL

100u/OS/D/6.3V/66/A/35m

5VDUAL

2

NEW DESIGN ONLY FOR INTERNAL SWR
AR8151:LAR3(O),LAR5(X)
AR8161:LAR5(O),LAR3/LAR4(X)

LAL1

4.7uH/1A/[10LC4-5A470B-01R]

LA_LX_OUT

LABC1
10u/8/X5R/6.3V/K

AR8161-->(O)

LA_AVDDH

AR8161-->(O)

LA_VDDCT

LAR11

49.9/4/1

LABC2

0.1u/4/X7R/16V/K

LAR3 0/4/SHT/M/X

LAR4 0/4/SHT/M/X

LAR5 0/6/X

LAR7 8.2K/4/X

LAR8 8.2K/4/X

LAR2
0/4/X

LAR12

49.9/4/1

LA_MDI_RC0 LA_MDI_RC3

LAC26

0.1u/4/X7R/16V/K

LA_LX

CLOSE
LA_LX 200mil

LA_VDDCT

LA_AVDD_CEN

LA_DVDDL

LA_LED_ACT_TXRX

LA_LED_LINK100

VCC3

LAR1
30K/4/X

LA_MDI0+
LA_MDI0-

LAR13

49.9/4/1

AR8161-->N/A
(LAR3,LAR4)

LAFB2 0/6/X

AR8161-->BEADAR8161-->(O)
AR8151-->N/A

ISOLATEB [17]

LA_MDI1+
LA_MDI1-

LAR14

49.9/4/1

LA_MDI_RC1

LAC27

0.1u/4/X7R/16V/K

CLOSE LAN CHIP

5VDUAL

F23 SMD1812P160/8V

1 2

1

F24 SMD1812P160/8V

EC38

+

1 2

F5 SMD1812P160/8V

1 2

F19 SMD1812P160/8V

1 2

1 2

F1 SMD1812P350SLR/S/[10FP1-06350B-20R]

1 2

F16 SMD1812P350SLR/S/[10FP1-06350B-20R]

1

+

EC3
100u/OS/D/6.3V/66/A/35m

FUSEVCC_R3

FUSEVCC_R4

Close to connector

2

1

AR8151 POWER

LA_AVDDL

LAFB3 0/6/SHT/M/X

LA_AVDDVCO

AR8161-->BEAD
AR8151-->0/6

AR8161 POWER

Power domain chart

LA_MDI3+
LA_MDI3-

LAR18

49.9/4/1

LAC29

0.1u/4/X7R/16V/K

FUSEVCC_R10

BAT54A/SOT23/200mAD27

FUSEVCC_R13

BAT54A/SOT23/200mAD24

FUSEVCC_R4

BAT54A/SOT23/200mAD1

LR15 0/6/SHT/M/X

AR8161

3.3V

3.3V

2.7V

1.1V

FUSEVCC_R11

FUSEVCC_R12

FUSEVCC_R3

31 35Tuesday, February 21, 2012

of

AR8151

AVDD33
VDD33
AVDDH

AVDDL/DVDDL

VDDCT

LA_MDI2+

LAR15

49.9/4/1

R60 8.2K/4

FUSEVCC_R10

FUSEVCC_R11

FUSEVCC_R12

FUSEVCC_R13

Title

Size Document Number Rev
Custom

Date: Sheet

LA_MDI2-

LAR16

49.9/4/1

LA_MDI_RC2

LAC28

0.1u/4/X7R/16V/K

N/A

3.3V

2.7V

1.1V

1.7V

LAR17

49.9/4/1

SOT23

1

3

2

SOT23

1

3

2

SOT23

1

3

2

-USBOC_R-USBOC_R-USBOC_R-USBOC_R

-USBOC_R-USBOC_R-USBOC_R-USBOC_R

-USBOC_R [9,28]

R72
15K/4/1

CR50 0/6/X

LR3 0/6/SHT/M/X

Gigabyte Technology

ARTHEROS AR8161/AR8151

GA-H77-DS3H

1

1.0

Gigabyte Confidential

Do not Copy

5

4

3

2

1

MSATA

VCC3

D D

SATA5TXP[11]
SATA5TXN[11]

SATA5RXN[11]
SATA5RXP[11]

C C

SATA5TXP
SATA5TXN

SATA5RXN
SATA5RXP

NC43 0.01u/4/X7R/25V/K
NC42 0.01u/4/X7R/25V/K

NC41 0.01u/4/X7R/25V/K
NC40 0.01u/4/X7R/25V/K

-MSATALED[28]

VCC3

R142 0/4/SHT/X

1u/4/X5R/6.3V/K

R143 8.2K/4

SATA5TXPC
SATA5TXNC

SATA5RXNC
SATA5RXPC

BC61

51
49
47
45
43
41
39
37
35
33
31
29
27
25
23
21
19
17
15
13
11

9
7

BC263

1u/4/X5R/6.3V/K

MINI PCIE/52/IV/RA/S/H6.8mm

5
3
1

MSATA

Presence Detection
DA/DSS
N/A
N/A
GND
+3.3V
+3.3V
GND
GND
SATA_TX+
SATA_TX­GND
GND
SATA_RX­SATA_RX+
GND
N/A
N/A
GND
N/A
N/A
GND
N/A
N/A
N/A
N/A

54

53

54

53

G1

G1

+3.3V

GND

+1.5V

N/A
N/A
N/A

GND

N/A
N/A

GND

N/A
N/A

+1.5V

GND

+3.3V

N/A
N/A

GND

N/A
N/A
N/A
N/A
N/A

+1.5V

GND

+3.3V

G2

G2

52
50
48
46
44
42
40
38
36
34
32
30
28
26
24
22
20
18
16
14
12
10
8
6
4
2

VCC3

VCC1_5

BC51
1u/4/X5R/6.3V/K

BC52

0.1u/4/X7R/16V/K

BC50
1u/4/X5R/6.3V/K

BC53
1u/4/X5R/6.3V/K

MSATA_L

B B

LATCH/52/SI/RA/S/H6.8mm

A A

56

56

55

55

VCC1_5

0.1u/4/X7R/16V/K

Q113
L1117LG/N/SOT223/1A

3

4

2
1

BC60

R140
100/4/1

R141

22.6/4/1

BC58

10u/8/X5R/6.3V/K

BC59
1u/4/X5R/6.3V/K

Title

VCC3

VCC1_5

BC57
1u/4/X5R/6.3V/K

MSATA

Size Document Number Rev

A

5

4

3

Date: Sheet

2

GA-H77-DS3H 1.0

32 35Tuesday, February 21, 2012

of

1

Gigabyte Confidential

Do not Copy

5

4

3

2

1

DDR18V

D17

D D

R531

20K/4/1/X

R532
27K/4/1

C C

+12V

5VDUAL

DDR_EN

C154

3.3n/4/X7R/50V/K

SDM20E40C/0.4A/SOT23

RT8120DGS/SOP8

C153
22p/4/NPO/50V/J

R736

0/4/X
R738
0/4/SHT/M/X

R582 2.2/6

Q91

U16

7

COMP

GND

3

BAT54C/SOT23/200mA/X

5

BOOT

UGATE

VCC

PHASE

LG/OCFB

PGND

9

放靠近

注意

: Rocset

一般Ipeak

PWR SEQ

B B

-PSON[17,29]

-SLP_S3[12,17,24]

POWER ISSUE

R496

22K/4

DDR_EN

3

D

GS

2

1

132

C131

1u/6/X7R/16V/K

Q65
2N7002/SOT23/25pF/5

Q51

MMBT2222A/SOT23/600mA/40

SOT23

C126

0.1u/4/X7R/16V/K

C218

1u/6/X7R/16V/K

1
2
8

46

R614
11K/4/1

IC pin4

的阻值要依據

5VDUAL

L6
1uH/30A/IMD0814/R/D

IN_D

D2D3D4

D5

C165

G

R526

2.2/6
R542

8.2K/4

L

RJK0393DPA-0G/N/4.3m/PPAKSO-8/[10IF9-040393-01R_10IF9-050840-01R]
RJK0393DPA-0G/N/4.3m/PPAKSO-8/[10IF9-040393-01R_10IF9-050840-01R]

設定在

S1D1S3

S2

D2D3D4

G

S1D1S3

S2

Lo side Rdson

50~60A

-S4_S5[12,17]

0.1u/6/X7R/25V/K

Q55
RJK0397DPA-0G/N/10.1m/PPAKSO-8[10IF9-100397-01R_10IF9-070428-01R]

PH

D2D3D4

D5

Q82

G

S1D1S3

S2

改變

即可

5VSB

R571
22K/4

R572

8.2K/4

132

C125
1u/6/X7R/16V/K

L5

R559

CLOSE

2.2/6

low-side

C142

MOS

1n/4/X7R/50V/K

1uH/30A/IMD0814/R/D

D5

Q83

LOOK 0.8V

0_8LEVEL_DDR[25]

DDR_EN

3

D

Q64
2N7002/SOT23/25pF/5

GS

2

1

Q71
MMBT2222A/SOT23/600mA/40

SOT23

1

+

EC37
560u/FP/D/6.3V/69/A/11m

BC192

0.1u/4/X7R/16V/K
R737

487/4/1

R739

3.3n/4/X7R/50V/K

0_8LEVEL_DDR

1

+

EC28
560u/FP/D/6.3V/69/A/11m

DDR_15V

25A max

R527
2K/4/1

RS

Remote sense

RO

R534

2.15K/4/1

0.8*[(RS+RO)/RO] = Vout = 1.54V

VIN=5V,VOUT=1.5V,IOUT=25A,PHASE=1
IRMS=11.45A

560u/FP/D/6.3V/68/8m RIPPLE CURRENT=4.7A
Coefficient=1.7(85 ),1(105 )

℃℃

VIN Ripple current=4.7X1.7=7.99A(85 )

-->

故固態電容須

2X7.99=15.98>11.45A

OCP : Ipeak=(2xIocsetxRocset)/Rdson

OCP:38.31A for Rds=6.7m for vishay@4.5V
OCP:78.78A for Rds=3.3m for renesas@10V
OCP:57A=Roset*Iocset / Rds(on)

=11K*10uA / [5//5]

請從最重的負載端點拉回

℃

A A

Title

Size Document Number Rev

Custom

5

4

3

2

Date: Sheet

RT8120

GA-H77-DS3H 1.0

33 35Tuesday, February 21, 2012

1

of

Gigabyte Confidential

Do not Copy

5

4

3

2

1

DVI LEVEL SHIFT

HU2

HR19 1K/4/1

HC9 0.1u/4/X7R/16V/K
HC10 0.1u/4/X7R/16V/K

HC11 0.1u/4/X7R/16V/K
HC12 0.1u/4/X7R/16V/K

HC13 0.1u/4/X7R/16V/K
HC14 0.1u/4/X7R/16V/K

HC15 0.1u/4/X7R/16V/K
HC16 0.1u/4/X7R/16V/K

HR25
10/4/X

HR31

HR30

3.3K/4/1

10/4/X

VCC3

VCC3

HR32
10/4/X

HR34

4.7K/4/X

HR36
10/4

DVI_HDP_F[10]

HR24

8.2K/4/X

HR29
10/4/X

VCC3

DVI_TXC[10]

DVI_TXC-[10]

DVI_TX0[10]

DVI_TX0-[10]

DVI_TX1[10]

DVI_TX1-[10]

DVI_TX2[10]

DVI_TX2-[10]

D D

RESERVE
FOR NXP

C C

DVI_CLK_P
DVI_CLK_N

DVI_DAT_N0

DVI_DAT_P1 DVITX2­DVI_DAT_N1

DVI_DAT_P2
DVI_DAT_N2

DVI_HP
DVI_HDP_F

DDPB_CTRLCLK
DDPB_CTRLDATA

DVI_SCL
DVI_SDA

HR26 8.2K/4

HR35

4.7K/4/X

HR37
10/4

VCC3VCC3

DVI_EN

25

OE*

39

IN_D1+

38

IN_D1-

42

IN_D2+

41

IN_D2-

45

IN_D3+

44

IN_D3-

48

IN_D4+

47

IN_D4-

30

HPD_SINK

7

HPD_SOURCE

9

SCL_SOURCE

8

SDA_SOURCE

28

SCL_SINK

29

SDA_SINK

32

DDC_EN

3

OC_0

4

OC_1

6

OC_2(REXT)

10

OC_3

34

EQ_0

35

EQ_1

ASM1442/QFN48/[10TA1-051442-20R]

OUT_D1+

OUT_D1-

OUT_D2+

OUT_D2-

OUT_D3+

OUT_D3-

OUT_D4+

OUT_D4-

THERMAL_PAD

HDP NONE-REVERSE

VCC3V
VCC3V
VCC3V
VCC3V
VCC3V
VCC3V
VCC3V
VCC3V

GND
GND
GND
GND
GND
GND
GND
GND
GND
GND

DVITXC+

22

DVITXC-

23

DVITX0+

19

DVITX0-

20

DVITX1+DVI_DAT_P0

16

DVITX1-

17

DVITX2+

13
14

2
11
15
21
26
33
40
46

1
5
12
18
24
27
31
36
37
43
49

HBC7

0.1u/4/X7R/16V/K

DDPB_CTRLCLK[10]

DDPB_CTRLDATA[10]

DVI_SDA
DVI_SCL

HBC8

0.1u/4/X7R/16V/K

0/0/0/0:Vswing 500mV

0 0:3dB

VCC

HR21

HR20

28K/4/1

HR22 2.2K/4/1
HR23 2.2K/4/1

28K/4/1

HBC9

0.1u/4/X7R/16V/K

VCC3

HBC10

10u/8/X5R/6.3V/K

VCC3

HBC12

0.1u/4/X7R/16V/K/X

FUSEVCC_R10

HBC11

0.1u/4/Y5V/16V/Z/X

HR27

20K/4/1

DVITX0­DVITX0+
DVITX1­DVITX1+
DVITX2­DVITX2+

DVI_SCL
DVI_SDA

DVITXC­DVITXC+

DVI_HP

M1M2

17
18

9

10

1
2

3
11
19
12
13

4

5
20
21

6

7
14
15
22
24
23

8
16

DVI

17

1619824

DVI-D/24P/SC/RA/D/SH

M5
M6
M7
M8

HDMI LEVEL SHIFT

HR1 1K/4/1

HC1 0.1u/4/X7R/16V/K
HC2 0.1u/4/X7R/16V/K

HC3 0.1u/4/X7R/16V/K
HC4 0.1u/4/X7R/16V/K

HC5 0.1u/4/X7R/16V/K
HC6 0.1u/4/X7R/16V/K

HC7 0.1u/4/X7R/16V/K
HC8 0.1u/4/X7R/16V/K

HDMI_HDP_F[10]

DDPD_CTRLDATA[10]

VCC3

HR8

4.7K/4/X

HR11
10/4/X

HR12

3.3K/4/1

HR13
10/4/X

HR14

4.7K/4/X

VCC3 VCC3

HR16
10/4

5

0 1:7.2dB

HR5

4.7K/4/X

HR10
10/4/X

VCC3

HDMI_TXC[10]

HDMI_TXC-[10]

HDMI_TX0[10]

HDMI_TX0-[10]

HDMI_TX1[10]

HDMI_TX1-[10]

HDMI_TX2[10]

HDMI_TX2-[10]

B B

A A

0/0/0/0:Vswing 500mV

VCC3

HDMI_CLK_P
HDMI_CLK_N

HDMI_DAT_P0
HDMI_DAT_N0

HDMI_DAT_P1
HDMI_DAT_N1

HDMI_DAT_P2
HDMI_DAT_N2

HDMI_PLUG

HDMI_HDP_F
DDPD_CTRLCLK
DDPD_CTRLDATA

HDMI_SCLDDC
HDMI_SDADDC

HR9 8.2K/4

HR15

4.7K/4/X

HR17
10/4

HDMI:20/4/6/4/20
Impedance=85 +- 17.5%

HU1

25

OE*

39

IN_D1+

38

IN_D1-

42

IN_D2+

41

IN_D2-

45

IN_D3+

44

IN_D3-

48

IN_D4+

47

IN_D4-

30

HPD_SINK

7

HPD_SOURCE

9

SCL_SOURCE

8

SDA_SOURCE

28

SCL_SINK

29

SDA_SINK

32

DDC_EN

3

OC_0

4

OC_1

6

OC_2(REXT)

10

OC_3

34

EQ_0

35

EQ_1

ASM1442/QFN48/[10TA1-051442-20R]

4

OUT_D1+

OUT_D1-

OUT_D2+

OUT_D2-

OUT_D3+

OUT_D3-

OUT_D4+

OUT_D4-

THERMAL_PAD

VCC3V
VCC3V
VCC3V
VCC3V
VCC3V
VCC3V
VCC3V
VCC3V

GND
GND
GND
GND
GND
GND
GND
GND
GND
GND

HDMI

HDMI_TXP2

HDMI_TXCP

22

HDMI_TXCN

23

HDMI_TXP0

19

HDMI_TXN0

20

HDMI_TXP1

16

HDMI_TXN1

17

HDMI_TXP2

13

HDMI_TXN2

14

2
11
15
21
26
33
40
46

1
5
12
18
24
27
31
36
37
43
49

HBC1

0.1u/4/X7R/16V/K

HBC2

0.1u/4/X7R/16V/K

DDPD_CTRLCLK[10]DDPD_CTRLCLK[10]

DDPD_CTRLDATA[10]

3

HBC3

0.1u/4/X7R/16V/K

DDPD_CTRLCLK
DDPD_CTRLDATA

HBC4
10u/8/X5R/6.3V/K

VCC3

HR38 2.2K/4/1
HR39 2.2K/4/1

HDMI_SDADDC

VCC

HR2

28K/4/1

HBC13

0.1u/4/X7R/16V/K

VCC3

2

HR3
28K/4/1

FUSEVCC_R10

HBC5

0.1u/4/X7R/16V/K/X

Title

Size Document Number Rev
Custom

Date: Sheet

HDMI_TXN2
HDMI_TXP1

HDMI_TXN1
HDMI_TXP0

HDMI_TXN0
HDMI_TXCP

HDMI_TXCNHDMI_SCLDDC

HDMI_SCLDDC

HDMI_SDADDC

HDMI_PLUG

HR4

HDMI/[11NR6-H01019-91R_11NR6-H01019-92R]

20K/4/1

Gigabyte Technology

DVI

GA-H77-DS3H

1

D2+

2

D2 Shield

3

D2-

4

D1+

5

D1 Shield

6

D1-

7

D0+

8

D0 Shield

9

D0-

10

CK+

11

CK Shield

12

CK-

13

CE Remote

14

NC

15

DDC CLK

16

DDC DATA

17

GND

18

+5V

19

HP DET

34 35Tuesday, February 21, 2012

1

of

SHL20
SHL22
SHL25

SHL24
SHL23
SHL21

20
22
25

24
23
21

1.0

Gigabyte Confidential

Do not Copy

8

7

6

5

4

3

2

1

VCC3

VCC3

GBC6

10u/8/X5R/6.3V/K

D D

C C

G_PCIEBOP[9]
G_PCIEBON[9]

G_PCIEBIN[9]
G_PCIEBIP[9]

B B

A A

GBC12

1u/4/X5R/6.3V/K

-PFMRST2

G_-PBCLK[10]

G_PBCLK[10]

GC2 0.1u/4/X7R/16V/K
GC1 0.1u/4/X7R/16V/K

GBC9 0.1u/4/X7R/16V/K
GBC8 0.1u/4/X7R/16V/K

8

0.1u/4/X7R/16V/K

GBC28 100p/4/NPO/50V/J/X

1u/4/X5R/6.3V/K

G_PCIEWAKE
G_-BPCIPME

VCCP

LDOAUX_18V

1.8V_AUX

GTP4

1.8VA

1.8VA

G_RREF
G_PCIEBOP_C
G_PCIEBON_C

1.8V_AUXA

G_PCIEBIN_C
G_PCIEBIP_C

1.8VD

GTP3
GTP2

G_A_D0
G_A_D1

GTP1

0.1u/4/X7R/16V/K

GBC25

GBC20

GBC5

0.1u/4/X7R/16V/K

1

WAKE#

2

PME#

3

GNDP_AUX

4

VCCP_AUX

5

LDOAUX_18V

6

VSS_AUX

7

VCCK_AUX

8

NC

9

CLKN

10

CLKP

11

VCC18A

12

VCC18A

13

GNDA

14

GNDA

15

GNDA

16

RREF

17

DIP

18

DIN

19

VCC18A_AUX

20

DON

21

DOP

22

VSS

23

VCCK

24

SEG_EN1/GP3

25

SEG_EN2/GP4

26

EECS#

27

EECLK

28

EEWRDATA

29

EERDDATA

30

AD0

31

AD1

32

SEG_G

7

GBC23

GU1

VCC3

GBC4

0.01u/4/X7R/25V/K

1.8VD

1u/4/X5R/6.3V/K

GTP8

GTP10

1.8VD

G_PCICLK_SEL

125

126

127

128

VCCK

SEG_F/GP1

SEG_E/GP0

PCICLK_SEL

GBC22

GND

124

GNDP

123

G_M66EN

122

VCCP

GTP6

121

M66EN

SEG_D

GTP9

120

SEG_C

GTP5

119

SEG_B

GTP7

118

GBC10

0.1u/4/X7R/16V/K

G_-PCIRST

-PFMRST2

G_-PIRQD

114

115

116

117

NC

INTD#

SEG_A

PERST#

PCIRST#

0.01u/4/X7R/25V/K

1.8VD

110

111

112

113

VSS

VCCK

GNDP

VCCP

IT8892E/BX LQFP128

AD2

AD3

VCCP

GNDP

AD4

AD5

AD6

AD7

VCCK

VSS

AD8

AD9

AD10

CBE0#

VCCP

GNDP

CBE1#

AD11

33343536373839404142434445464748495051525354555657585960616263

G_A_D2

G_A_D3

1.8VD

G_A_D4

G_A_D5

G_A_D6

G_A_D7

G_A_D9

G_A_D8

VCC3

AD12

VCC3

G_A_D10

G_-C_BE0

G_-C_BE1

G_A_D12

G_A_D11

6

GBC7

G_-REQ2

109

G_A_D13

G_-GNT0

108

TP2

AD13

G_A_D14

1.8VD

1.8VD

GBC2

10u/8/X5R/6.3V/K

1.8VA

1.8VA

GBC16

10u/8/X5R/6.3V/K/X

G_-REQ3

G_A_D29

G_A_D28

G_A_D30

G_A_D31

G_-REQ1

G_-GNT1

G_-REQ0

G_CLKOUT0

979899

100

101

102

103

104

105

106

107

NC

TP1

GNT0#

REQ0#

PCICLK0

AD14

AD15

PERR#

SERR#

VCCP

VCC3

G_A_D15

G_-PERR

G_-SERR

GNT1#

GNDP

LDO_18V

REQ1#

LDO_18V

AD31

VSS

G_PAR

AD30

PAR

AD29

LOCK#

G_-PLOCK

VSS

AD28

INTB#

INTC#

64

G_-PIRQB

G_-PIRQC

VCCK

GNDP

VCCP

NC

EXT_ARB

RST_SEL

TEST_EN

AD27
AD26

CBE3#

AD25
AD24

VCCP

AD23
AD22
AD21
AD20

VSS

VCCK

AD19
AD18
AD17
AD16

GNDP

VCCP

FRAME#

IRDY#
CBE2#
TRDY#
STOP#

DEVSEL#

INTA#

IT8892E/EX/S

96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
80
79
78
77
76
75
74
73
72
71
70
69
68
67
66
65

GBC26

1u/4/X5R/6.3V/K

GBC15

1u/4/X5R/6.3V/K

1.8VD

G_CLKOUT1
G_EXT_ARB
G_RST_SEL
G_TEST_EN
G_A_D27
G_A_D26
G_-C_BE3
G_A_D25
G_A_D24

G_A_D23
G_A_D22
G_A_D21
G_A_D20

1.8VD

G_A_D19
G_A_D18
G_A_D17
G_A_D16

G_-FRAME
G_-IRDY
G_-C_BE2
G_-TRDY
G_-STOP
G_-DEVSEL
G_-PIRQA

5

GBC24

0.1u/4/X7R/16V/K

GBC14

0.1u/4/X7R/16V/K

3VDUAL 1.8V_AUX 1.8V_AUXA

GBC27

0.1u/4/X7R/16V/K/X

G_A_D[0..31]

G_-C_BE0
G_-C_BE1
G_-C_BE2
G_-C_BE3

G_-PERR
G_-SERR

G_PAR
G_-PLOCK
G_-DEVSEL
G_-STOP
G_-TRDY
G_-IRDY
G_-FRAME

-PFMRST2
G_-PCIRST
G_-REQ0

G_-REQ1
G_-GNT0

G_-GNT1

G_-PIRQA
G_-PIRQB
G_-PIRQC

VCC3

VCC3

VCC3

G_-PIRQD

G_CLKOUT0
G_CLKOUT1

G_-PIRQB
G_-PIRQC
G_-PIRQD
G_-PIRQA

G_-REQ2
G_-REQ0 G_-STOP
G_-REQ3
G_-REQ1

G_PAR

G_PCIEWAKE
G_-BPCIPME
VCCP

GBC17

0.1u/4/X7R/16V/K

G_A_D[0..31] [16]

G_-C_BE0 [16]
G_-C_BE1 [16]
G_-C_BE2 [16]
G_-C_BE3 [16]

G_-PERR [16]
G_-SERR [16]

G_PAR [16]

G_-PLOCK [16]
G_-DEVSEL [16]
G_-STOP [16]
G_-TRDY [16]

G_-IRDY [16]

G_-FRAME [16]

-PFMRST2 [17,18,31]

G_-PCIRST [16]
G_-REQ0 [16]

G_-REQ1 [16]

G_-GNT0 [16]

G_-GNT1 [16]

G_-PIRQA [16]

G_-PIRQB [16]

G_-PIRQC [16]

G_-PIRQD [16]

GR12 47/4/1
GR11 47/4/1

GRN1

2.7K/8P4R/4

1 2
3 4
5 6
7 8

GRN4

2.7K/8P4R/4

1 2
3 4
5 6
7 8

GR1 2.7K/4/1/X

GR9 10K/4/1
GR8 10K/4/1
GR7 0/4/SHT/X

4

GBC11

0.1u/4/X7R/16V/K

G_PCLK0 [16]
G_PCLK1 [16]

VCC VCC

3VDUAL

G_-DEVSEL
G_-TRDY
G_-IRDY
G_-FRAME

G_-SERR
G_-PERR

G_-PLOCK

G_RREF

G_TEST_EN

G_EXT_ARB

G_RST_SEL

LDO_18V

LDOAUX_18V

LDOAUX_18V

LDO_18V

3

10u/8/X5R/6.3V/K

10u/8/X5R/6.3V/K

G_M66EN

G_PCICLK_SEL

GRN2

2.7K/8P4R/4

1 2
3 4
5 6
7 8

GRN3

2.7K/8P4R/4

1 2
3 4
5 6
7 8

GR2 12K/4/1

GR3 10K/4/1

GR5 10K/4/1

GR4 10K/4/1

GFB3 0/6/SHT/M/X

GFB1 0/6/SHT/M/X

GFB4 0/6/SHT/M/X

GFB2 0/6/SHT/M/X

GBC21

PCB layout note:

Close to chip

GBC1

VCC3

GR14

8.2K/4/X

GR13
10/4

VCC3

GR15

8.2K/4/X

GR10
10K/4/1

1.8VA

1.8VD

1.8V_AUX

1.8V_AUXA

GBC19

1u/4/X5R/6.3V/K

GBC3

1u/4/X5R/6.3V/K

GBC18

0.01u/4/X7R/25V/K

GBC13

0.01u/4/X7R/25V/K

High: Enable PCI CLK 66MHz
Low: Disable PCI CLK 66MHz

High: PCICLK INTPUT form CLK Gen
Low: PCICLK OUTPUT form IT8893 chip

Title

Size Document Number Rev
Custom

Date: Sheet

2

Gigabyte Technology

GA-H77-DS3H

IT8892E

35 35Tuesday, February 21, 2012

1

1.0

of
