GIGABYTE G1345 User Manual

G1345

All mobile products b y GIGA-BYTE COMMUNICATIONS INC. mentioned in this document, including the device, accessories, software, text, music, and pictures, are owned by, or authorized by original manufacturers to GIGA-BYTE COMMUNICATIONS INC. Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of GIGA-BYTE COMMUNICATIONS INC. is prohibited.

GIGA-BYTE Group, GIGA-BYTE COMMUNICATIONS INC.

G1345│

0-1

Safety Information

This section contains important information on safe and efficient operation. Please read this information before

using the device.

• Use only the batteries and power adapter provided by the manufacturer. Use of unauthorized accessories may void your warranty.

• Do not remove the battery while the phone is charging.

• Avoid using the phone near electromagnetic sources such as TVs, radios, and microwave ovens.

• Unplug the power adapter from the wall outlet during lightning storms to avoid electric shock or fire.

• Do not expose the phone or the battery to direct sunlight.

• Do not store your phone in temperatures higher than 60ºC or 140ºF.

• Do not use harsh chemicals or detergents to clean your phone.

• Do not handle the phone with wet hands while it is being charged. This may cause an electric shock or serious damage to the phone.

SAFETY PRECAUTIONS FOR BATTERY USE

• Use only approved battery.

• Keep the battery dry and away from any liquid since this may cause a short circuit.

• Keep the battery away from metal objects since this may cause a short circuit.

• Do not use damaged or deformed batteries.

• If the battery emits a foul odor, discontinue use.

• Keep the battery away from babies and small children.

• If the battery leaks:

• Do not allow the leaking fluid to come in contact with your skin, eyes or clothing. If already in contact, rinse with clean water immediately and seek medical advice.

• Keep the battery away from fire since this may cause the battery to explode.

• Do not attempt to open or service the battery yourself.

• Do not dispose battery in fire or water.

• Recycle or dispose used batteries according to the local regulations.

• Prevent to place the battery in extreme temperature condition, it maybe influence the battery efficiency.

ROAD AND ENVIRONMENTAL SAFETY

• Turn off the phone in areas with a potentially explosive atmosphere or where flammable objects exist such as gas stations, fuel depots, and chemical plants among others. Sparks from these areas could cause explosion or fire and result in injury or even death.

• Do not use hand-held phones while driving a vehicle. Use hands-free devices as an alternative.

SAFETY IN AIRCRAFT Do not use the phone on board an aircraft. The phone’s network signals may cause interference to the

G1345│

0-2

navigation system. As a safety measurement, it is against the law in most countries to use the phone on board an aircraft.

Android is a trademark of Google Inc. Use of this trademark is subject to Google Permissions. Bluetooth and the Bluetooth logo are trademarks owned by Bluetooth SIG, Inc. Java, JME and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and other countries.

SAR Information

THIS MOBILE DEVICE MEETS GUIDELINES FOR EXPOSURE TO RADIO W AVES. Your mobile device is a radi o transm itte r and rec eiver . It is des igned not to exc eed th e lim its for exposu re to radio wave s recommended by international guidelines. These guidelines were developed by the independent scientific organization ICNIRP and include safety margins designed to assure the protection of all persons, regardless of age and health. The exposure guidelines for mobile devices employ a unit of measurement known as the Specific Absorption Rate or SAR. The SAR lim it stated in the ICNIRP guideli nes is 2 W/kg averaged over 10 grams of tiss ue. Tests for SAR are conducted using standard operating positions with the device transmitting at its highest certified power level in all tested frequency bands. The actual SAR level of an operating device ca n be b el ow t he m a xi m um va l ue bec aus e th e de vic e is d es i gn ed t o u se o nl y th e po w er required to reach the network. That amount changes depending on a number of factors such as how close you are to a network base station. The highest SAR value under the ICNIRP guidelines for use of the device at the ear is 0.788 W/Kg. Use of device accessories and enhancements may result in different SAR values. SAR values may vary depending on national reporting and testing requirements and the network band. Additional SAR information can be found on the Cellular Telecommunications Industry Association (CTIA) website at www.wow-com.com.

 The standard value of SAR is 2.0W/Kg; the maximum SAR of the device is 0.788 W/Kg.  For decreasing the influence of the electromagnetic wave, please use the device carefully.

WEEE Notice

The WEEE logo on the product or on its box indicates that this product must not be disposed of or dumped with your other household waste. You are liable to dispose of all your electronic or electrical waste equipment by relocating over to the specified collection point for recycling of such hazardous waste. Isolated collection and proper recovery of your electronic and electrical waste equipment at the time of disposal will allow us to help conserve natural resources. Moreover, proper recycling of the electronic and electrical waste equipment will ensure safety of human health and environment. For more information about electronic and electrical waste equipment disposal, recovery, and collection points, please contact your local city center, household waste disposal service, shop from where you purchased the equipment, or manufacturer of the equipment.

RoHS Compliance

This product is in compliance with Directive 2002/95/EC of the European Parliament and of the Council of 27 January 2003, on the restriction of the use of certain hazardous substances in electrical and electronic

G1345│

0-3

equipment (RoHS) and its amendments.

European Union Regulatory Conformance

The equipm ent complies with the RF Exposure Requirement 1999/519/EC, Council Recommendation of 12 July 1999 on the limitation of exposure of the general public to electromagnetic fields (0–300 GHz). This equipment meets the following conformance standards: EN 300 328, EN 301489-1, EN 301489-3, EN 301489-7, EN 301489-17, EN 301489-24, EN 301 511, EN 301 908-1/2, EN 50360, EN62311, EN 300440 and EN 60950. Changes or modifications to this product not authorized by the m anufacturer could void the EMC compliance and negate your authority to operate the product. This product has demonstrated EMC compliance under condi tions that included the use of compliant peripheral devices and shielded cables between system components. It is important that you use compliant peripheral devices and shielded cables betw een system components to reduce the possibility of causing interference to radios, televisions, and other electronic devices. We, hereby, declare that this cellular, Wi-Fi, & Bluetooth radio is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.

Intellectual Property Right Information

Right to all technologies and products that comprise this device are the property of their respective owners: This product has an Android platform based on Linux, which can be expanded by a variety of Java-Script-based application SW. Google, the Google logo, Android, the Android logo, Gmail, and YouTube are trademarks of Google Inc. Bluetooth and the Bluetooth logo are trademarks owned by Bluetooth SIG, Inc. Wi-Fi, the Wi-Fi CERTIFIED log, and the Wi-Fi logo are registered trademarks of the Wireless Fidelity Alliance. Java, JME and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and other countries. microSD is a trademark of SD Card Association.

G1345│

0-4

General Information

This section contains important information on safe and efficient operation. Please read this information before

using the device. Ignorance of the following notices may lead to violations of the law.

• Before using the device, please make sure you have fully charged the battery.

• Do NOT remove the battery from the device during charging.

• Before inserting SIM card into the device, make sure that the device is switched off.

• Do NOT attempt to dissemble the device on your own. This should be done by an authorized person.

• Use the device in accordance to instructions when in public facilities.

• In some countries, it is a violation against the law to record phone conversations. Always ask permission of

the other party when you are going to record a conversation.

• To protect your ears, turn down the volume before you use stereo headsets or other audio devices.

• To avoid damagi ng the touch screen and the device, do NOT apply excessive pressure on them, and

remove the device from your pants’ pocket before you sit down. It is also recommended that you only use the stylus or your finger to interact with the touch screen. It is not covered by the warranty that you crack the touch screen because of the improper usage.

• When you use the device for a long time, such as talking on the phone, browsing online, or charging the

battery, the device may become warm. In most cases, this condition is normal.

• Refer servicing to the provider, or an authorized technician under the following conditions: 1. The device

has been damaged. 2. When you follow the instructions to use your device, it does not operate normally. 3. The device has been exposed to water. 4. Liquid has been spilled or an object has fallen onto the device.

• Do Not push unauthorized objects into slots and openings in your device.

• The de vice should be placed away from heat sources such as stoves, radiators, heat registers, or other

products that produce heat.

• Condensation may form on or within your device, when you move your de vice between environments with

very different temperature and/or humidity ranges. To avoid dam aging your device, m ake the m oisture to evaporate before you use the device.

• To avoid damaging your device, do Not put your device on an unstable table, stand, bracket, or other

places.

• Before you clean your device, unplug it, please. Use a damp cloth for cleaning, but do Not use water, liquid

cleaners, or aerosol cleaners to clean the touch screen.

G1345│

0-5

Table of Contents

Copyright .................................................................................................................................................... 0-1

Safety Information ................................................................................................ ...................................... 0-2

General Information .................................................................................................................................... 0-5

Chapter 1 Getting Started ........................................................................................................................ 1-1

1.1 Your Phone .......................................................................................................................................... 1-1

1.2 Installing or uninstalling the SIM Card, Battery, and Memory Card ...................................................... 1-3

1.3 Charging the Battery............................................................................................................................. 1-6

1.4 Turning the Phone On or Off ................................................................................................................ 1-6

1.5 Lock / Unlock ........................................................................................................................................ 1-7

1.6 Notification LED .................................................................................................................................... 1-7

1.7 Initial Settings ....................................................................................................................................... 1-7

1.8 Using Headset ................................................................................................ ...................................... 1-8

1.9 Adjusting the Volume............................................................................................................................ 1-8

1.10 Contacts ............................................................................................................................................. 1-8

1.11The Home Screen ............................................................................................................................... 1-10

Chapter 2 Phone Functions & Input........................................................................................................ 2-1

2.1 Voice Calls ........................................................................................................................................... 2-1

2.2 Using On-Screen Keyboard .................................................................................................................. 2-2

Chapter 3 Email & Messaging ................................................................................................................. 3-1

3.1 Creating and sending a text message .................................................................................................. 3-1

3.2 Multimedia Message............................................................................................................................. 3-2

3.3 Voice Message ..................................................................................................................................... 3-2

3.4 E-mail Accounts.................................................................................................................................... 3-3

3.5 Using E-mail ......................................................................................................................................... 3-3

Chapter 4 Using the Internet ................................................................................................................... 4-1

4.1 Connecting to the Internet .................................................................................................................... 4-1

4.2 Bluetooth modes................................................................................................................................... 4-3

Chapter 5 Multimedia Applications ......................................................................................................... 5-1

5.1 Photos and Videos ............................................................................................................................... 5-1

5.2 Viewing Photos and Videos .................................................................................................................. 5-4

5.3 Music .................................................................................................................................................... 5-4

Chapter 6 Programs ................................................................................................................................. 6-1

6.1 Browser ................................................................................................................................................ 6-2

6.2 Calculator ............................................................................................................................................. 6-5

G1345│

0-6

6.3 Calendar ............................................................................................................................................... 6-5

6.4 Gmail…………………………………………………………………………………………………………… .6-6

6.5 Maps..................................................................................................................................................... 6-6

6.6 Latitude................................................................................................................................................. 6-6

6.7 Places................................................................................................................................................... 6-7

6.8 Navigation ................................................................................................ ........................................... 6-7

6.9 Google Search .................................................................................................................................... 6-7

6.10 Voice Search ...................................................................................................................................... 6-7

6.11 Talk..................................................................................................................................................... 6-8

6.12 YouTube ............................................................................................................................................. 6-8

6.13 Market ................................................................................................................................................ 6-8

6.14 Weather .............................................................................................................................................. 6-9

6.15 News and Weather ............................................................................................................................. 6-9

6.16 People ................................................................................................................................................ 6-10

6.17 Best Choice ........................................................................................................................................ 6-10

6.18 FM Radio ............................................................................................................................................ 6-10

6.19 Sound Recorder ................................................................................................................................. 6-11

6.20 File Manager....................................................................................................................................... 6-11

6.21 Android Manager ................................................................................................................................ 6-11

6.22 USB Manager ..................................................................................................................................... 6-12

6.23 Install USB Driver ............................................................................................................................... 6-12

6.24 Downloads .......................................................................................................................................... 6-13

Chapter 7 Managing Your Phone ............................................................................................................ 7-1

7.1 Phone Settings ..................................................................................................................................... 7-1

7.2 Managing Basic Settings ...................................................................................................................... 7-4

7.3 Protecting Your Phone ......................................................................................................................... 7-5

7.4 Resetting Your Phone .......................................................................................................................... 7-6

7.5 Specifications ....................................................................................................................................... 7-6

G1345│

0-7

1. Getting Started

1.1 Your Phone

This section introduces you to the hardware of the device.

No. Items Functions

1 Earphone jack

2 Power

Use a headset for hands-free conversation or listening to music.

• Press and hold for several seconds to turn the phone on or off.

• To set your phone to the

3 Earpiece

4 Touch screen

LED

6 P-sensor

7 Light sensor

8 Home

9 Menu

10 Search

11 Return

MIC

13 Micro USB port

sleep mode, press the power button briefly. Press

again to turn on the display. The source of music and voice. Display screen.

• Power status notification.

• Other notification. (New

message / Missed call). The screen will turn off automatically when taking the device close to face on call. Adjust the brightness of the screen according to the environment.

• Go back to Home Screen.

• Press and hold to bring up

recent activities. Press to view the options of the menu. Connect to the website or find features in the phone.

Return to the previous page.

Sound Receiver.

• Connect USB cable to PC,

share your phone's mobile

network with PC / USB

mass storage.

• Connect USB cable and

the AC adapter to charge

the battery.

1-1

G1345│

No. Items Functions

No. Items Fu

nctions

5Megapixels

Press upwards or

Volume

15 Micro SD Slot

16 Camera key

17 Speaker

downwards to increase or decrease the volume. Slide down the key fully to enter vibrate mode. You can insert your Micro SD card.

• Tap to activate the camera.

• In Camera/Camcorder mode, press to take a photo or video.

The source of music and voice.

Flash LED

Camera

20 Back cover

NOTE: The battery can also be charged while connecting to a computer.

G1345│ 1-2

Help photo shooting. The camera on the back of

the device supports 5-mega-pixel photo and high-quality video. You need to open the cover to install or uninstall the battery and the SIM card.

1.2 Installing or uninstalling the SIM Card, Battery, and Memory Card

To remove the back cover

1. Please turn over your phone with the back cover facing up.

2. Please move your fingertip into the slot .

3. Stay your palm close to the back cover. Then pull the back cover with your fingertip to remove

G1345│

1-3

it.

SIM card

The SIM card contains your phone number, memory storage, and the details of the network service.

To install the SIM card

Insert the SIM card. Make sure the gold contacts are facing down and the cut-off corner is facing towards the battery slot. There are two slots for two SIM cards. Upper slot is for SIM2, and SIM1slot is on the underside.

To install the battery

Insert the battery. Make sure the contacts of the battery are aligned with the connectors on the battery slot.

To remove the battery

Use your fingertip to lift the battery, and then, remove it.

To remove the SIM card

1. Remove battery.

2. Use your finger to slide the SIM card from the

card slot.

Battery

Your phone comes with a rechargeable battery. Battery life varies depending on the network, used applications, and the type of connections attached to your phone.

NOTE: To ensure battery performance and avoid the risk of fire:

• Use only the original battery designated for

the phone.

• Do not store the battery in temperatures

below -10ºC or higher than 45ºC

G1345│ 1-4

To replace the back cover

1. Please insert the hook on the top of the back cover into the slot of the phone.

2. Then, press the bottom of the back cover until click into place.

Memory card

You will need a microSD card to store photos, music, videos, and other data.

To install the memory card

1. Insert the memory card with the gold contacts facing down.

2. Push the memory card until it clicks into place.

1-5

G1345│

To remove the memory card

1. For safe removal, tap Application Drawer > Settings > Storage > Unmount SD card.

2. Push the memory card down to eject it from the

slot.

1.3 Charging the Battery

When you take your phone out from the box for the first time, the battery is only partially charge. Please charge the battery fully before use.

1. Connect the USB cable to the AC adapter, and then, connect to the device via the USB cable.

2. Plug the AC adapter to an outlet to start charging.

NOTE:

• The battery can also be charged when you

connect your phone to the computer.

• To ensure safety, do not remove the battery

from the phone while the AC adapter is connected or while it is being charged.

1.4 Turning the Phone On or Off

After installing the SIM card and charging the battery, you are now ready to turn on your phone.

To turn on your phone

Press and hold the power button until the phone vibrates.

To turn off your phone

1. Press and hold the power button for several seconds.

2. A pop-up window appears, and then, tap Power off.

3. Select OK to confirm.

To set your phone to the sleep mode

To set your phone to the sleep mode, press the power button briefly. It will turn the display off. To turn the display on, press the power button briefly again.

G1345│ 1-6

1.5 Lock / Unlock

Types Descriptions

When you turn on your phone or the display, you need to unlock the device. Slide the Lock Icon on screen to unlock the device. Slide the Sound Icon on screen to turn on / off the sound.

1.6 Notification LED

Solid red light

Solid green light

Flashing red light

Flashing green light

Battery is charging.

Battery is full.

Battery is low. Notification ( New

message / Missed call / New email)

1.7 Initial Settings

Please insert your SIM card first. When you turn on your phone for the first time or you reset your phone, you need to follow the step below:

1. In the screen of Mobile Network, you can enable / disable the network of your device. If you enable it, you may be charged. You can tap “Change language” to change the default language,” or tap “Done” to finish the setting.

2. Tap the Android Robot icon to begin. In this

step, you can tap “Emergency dial” to make an emergency call, or tap “Change language” to change the default language.

3. In the screen of Set up your Google Account, you can tap “Create” to create an account, tap “Sign in” to sign in the Google account, or tap “Skip” to set up the account later.

4. In the screen of Use Google location, you can

allow or disallow Google’s location service to collect anonymous location data. You can also allow or disallow Google to use My Location for Google search results and other Google

services. Then, tap “Next” to finish the whole initial settings.

NOTE: Some applications and functions that need to connect to the Internet such as location-based services and the automatic synchronization of your online accounts may incur the fees of the connection from your service provider. You may enable or disable the Internet later.

G1345│

1-7

1.8 Using Headset

Types Descriptions

press the button to play, and

For hands-free conversation or listening to music, plug a headset to the headset jack.

NOTE:

• When using a headset, your ability to hear outside sounds may be limited. Do not use the headset if it will endanger you.

• Do not set the volume to its maximum with a headset as it may damage your hearing.

• The following instructions are only provided with the original headset of the original manufacturer:

Press the button on the headset

Press and hold the button on the headset

• When you receive an incoming call, press the button to answer the call. If you are having a call conversation, press the button to hold, and press again to un-hold the call.

• In music / video mode,

press again to stop or resume music / video.

• When you are listening to music, press twice quickly to next music.

• If you are having a call

conversation, press and hold the button to end the call.

• When you receive an incoming call, press and hold the button to end the call.

• When you are listening to music, press and hold the button back to Playlist.

• When you use other

functions, press and hold the button to launch the music player.

1.9 Adjusting the Volume

To adjust the volume of ringtone, media, and alarm

1. Tap Application Drawer > Settings > Sound > volume.

2. Slide the volume bar to adjust the volume. Do

either of the following: a. Drag the slider towards the left to decrease the vol ume, or drag the slider towards to the right to increase the vol ume. Tap OK to save your

settings.

b. Tap Application Drawer > Settings > Sound > Silent mode to set the phone to the silent

mode.

NOTE: When the phone is set to the silent mode, all sounds are turned off except media and alarm.

1.10 Contacts

“Contacts” is your phonebook that lets you store names, phone numbers, e-mail addresses and other information. Contacts are stored in the phone memory.

Adding a Contact

1. Tap Application Drawer > Contacts.

2. Tap Menu > New contact, and then, the new

contact window appears.

3. Tap each field to enter the contact information

with the on-screen keyboard.

NOTE: To add picture, tap Picture field, and then, select a picture file.

4. Tap Done to save.

G1345│ 1-8

Searching for Contacts

On Contacts tab, do any of the following to easily search for contacts:

• Tap Menu > Search. Type the first few letters of the contact to search. The list is filtered as you type.

• Tap a letter in the Letter Index to view the contacts whose initial letter is the letter you select in the Letter Index. For example, if you want to view the contacts whose initial letter is M,

tap M in the letter Inde x. Tap to go back to the list of contacts.

• If you want to categorize the contacts, tap Menu > Display options to set up the category.

Manage Accounts

1. Tap Application Drawer > Contacts.

2. Tap Menu > Accounts.

3. You can mark Background data. If so,

applications can sync, send, and receive data any time.

4. You can mark Auto-sync. If so, applications

sync data automatically.

Importing / Export Contacts

Export Contacts to phone

1. Tap Application Drawer > Contacts.

2. On Contacts tab, tap Menu > Import/Export >

SIM Manager > Select [SIM1] / [SIM2].

3. Tap Menu > Export to phone. Select the

contacts you want, or tap Select All to select all

1-9

G1345│

contacts. Then tap Export.

Icons

Descriptions

Import Contacts to SIM card.

1. Tap Application Drawer > Contacts.

2. On Contacts tab, tap Menu > Import/Export > SIM Manager.

3. Tap Menu > Import to SIM. You can select SIM1 or SIM2 (If SIM2 inserted.) Then tap OK.

4. Select the contacts you want, or tap Select All to select all contacts. Then tap Import.

Import Contacts from SD card

1. Tap Application Drawer > Contacts.

2. On Contacts tab, tap Menu > Import/Export > Import from SD card.

Back up Contacts

Export Contacts to SD card

1. Tap Application Drawer > Contacts.

2. On Contacts tab, tap Menu > Import/Export > Export to SD card.

3. Tap OK to confirm.

Favorite Contacts

You can add the most frequently called contacts to the favorite contact list which helps you to access the contacts quickly and easily.

Add to Favorites

1. Tap Application Drawer > Contacts.

2. On Contacts tab, tap and hold the desired

contact.

3. The submenu appears, and then, tap Add to favorites.

4. When you tap the contact, you will find a golden

star appears next to the contact’s name. It

means the contact is in the favorites list.

Remove from Favorites

1. Tap Application Drawer > Contacts.

2. Tap Favorites tab, the favorites list is displayed.

3. Tap and hold the desired contact to display the submenu.

4. Tap Remove from favorites. The contact will be removed from the favorites list.

SIM Manager

SIM Manager is an SIM card management tool. If you don't have any contacts stored on your phone, you can export SIM contacts to your device.

1. Tap Application Drawer > SIM Manager.

2. Tap and hold the desired contact, the submenu appears. Select what you want in the submenu.

1.11 The Home Screen

On Home screen, you can quickly access common features and view notifications of missed calls, received messages, battery, and the status of the connection.

You can slide the home screen from the left side to the right side or from the right side to the left side to switch it. The icons located at the bottom of the home page have different functions:

Tap to launch Application Drawer

Tap and hold it to review the five home screens at the same time.

Tap to launch Phone.

Tap to launch Call log.

G1345│ 1-10

+ 41 hidden pages
