90
OFF-road | PERFORMANCE | Competition
OFF-road | PERFORMANCE | All Mountain
Reign *
Specifications
SIZES
COLOUR
frame
FRAME
FORK
SHOCK
HANDLEBAR
STEM
SEATPOST
SADDLE
componentS
PEDALS
SHIFTERS
FRONT DERAILLEUR
REAR DERAILLEUR
BRAKES
DriVetrain
BRAKE LEVERS
CASSETTE
CHAIN
CRANKSET
BOTTOM BRACKET
RIMS
HUBS
SPOKES
WHeeLS
TIRES
EXTRAS
Specific ations and availab ility subject to c hange without noti ce.
XS,S,M,L,XL
Black / Bright Green
ALUXX SL-grade aluminum,
6.0” Maestro suspension
FOX 32 TALAS 150 FIT RL, tapered,
15QR, 120-150mm travel
FOX RP23 BV, XV sleeve
Giant Contact SL/R low-rise 31.8mm
Giant Contact
Crank Brothers Joplin-4 30.9x398mm,
remote
Fi'zi:k Gobi XM w/ K:ium rails
Not included
Shimano Deore XT
Shimano Deore XT
Shimano Deore XT Shadow long cage
Avid Elixir CR F:185mm / R:160mm
hydraulic disc
Avid Elixir CR
Shimano Deore XT 11-36T 10SPD
Shimano HG74
Shimano Deore XT 24/32/42T
Shimano internal press fit
DT Swiss TRICON M 1700
DT Swiss TRICON, F:15QR
DT Swiss TRICON
Kenda Nevegal 26x2.35”
$
*available in limited quanti ties
Spec Features
— FOX 32 TALAS 150 FIT RL tapered 15QR fork w/ 120-150mm travel, FOX RP23 shock
— Shimano Deore XT 10-speed component group, Avid Elixir CR disc brakes
— Giant Contact SL/R composite handlebar, Contact stem & Crank Brothers Joplin-4 seatpost
— Wheelset: DT Swiss TRICON M 1700 tubeless-compatible disc
frame geometry
A B C D E F G H
Actual
Frame Size
inche s degre es degre es inch es inche s in ches inche s inches
XS 14.5 2112200 67.5 73.5 21.7 4.6 17.2 42.9 31.4
S 15 2112201 67.5 73.5 22.2 4.6 17.2 43.5 31.6
M 17 2112202 67.5 73.5 23.2 5.0 17.2 44.5 31.9
L 19 2112203 67.5 73.5 24.2 5.9 17.2 45.4 32.0
XL 20 2112204 67.5 72.0 25.2 7.5 17.2 46.4 32.6
*Seat ang le is actual
**Toptube is m easured from the c enter of the headtu be horizontally ba ck to the top of the effec tive extension of th e seattube
***Sta ndover height is ba sed on the largest s ize tire that will fit the b ike, not necessar ily the included si ze tire
Part
Number
Head
Angle
Seat
Toptube** Headtube Chainstay Wheelbase
Angle*
Standover
Height***
