2018.April

DUAL SUSPENSION

USER’S MANUAL

2

TABLE OF CONTENTS

INTRODUCTION 3

BASIC TERMS & SHOCK SETUP OVERVIEW 3

TERMS 3

SETUP 3

SAG 4

REBOUND DAMPING 4

PEDAL PLATFORM 4

GENERAL MAINTENANCE 4

FRONT SUSPENSION TRAVEL & SAG GUIDE 5

COIL SPRING FORKS 5

AIR SPRING FORKS 5

SUSPENSION SAG RECOMMENDATION CHART 5

REAR SHOCK SETUP GUIDE 6

COIL SHOCK SETUP 6

AIR SHOCK SETUP 7

COIL & AIR SHOCKS SETTING & ADJUSTING REBOUND DAMPING 8

SUGGESTED REAR SUSPENSION SAG GUIDE 9

MY19 bike models 9

MY18 bike models 10

MY17 bike models 10

3

INTRODUCTION

This booklet is intended as a quick-start reference guide to help familiarize you with your
new GIANT full-suspension mountain bike. It is not meant to replace the general bicycle
owner’s manual or the shock and suspension fork manufacturer’s technical manuals that also
came with your bicycle. If you did not receive these manuals, please contact your Authorized
GIANT dealer. We encourage you to read all manuals relating to your bicycle and its
suspension components before your first ride. All manuals contain important information
regarding the safety and operation of your bicycle.

Please refer to the manufacturer’s technical information that came with your bicycle
for specific details regarding shock function and setup prior to riding your GIANT
bicycle. If you did not receive these technical booklets, contact your Authorized
GIANT dealer. If you do not understand the quick-start instructions or have difficulty
with setup, please see your Authorized GIANT dealer before riding your GIANT
bicycle.

Only GIANT Glory model bicycles are engineered for use with dual crown suspension
forks. Use of dual crown suspension forks on any GIANT bicycle other than these
models will void the warranty and may result in frame failure, which can cause injury
or death. GIANT Bicycle Inc. is not responsible for damages to the bike and rider
resulting from the use of dual crown forks.

BASIC TERMS & SHOCK SETUP OVERVIEW

TERMS

• Bottomed Out: When a rear shock or suspension fork (herein after referred to

as“shock”) is compressed completely and all the suspension travel has been used
Compression Stroke: The motion of the shock in response to an impact.

• Damping: Internal mechanism to control the speed of compression or rebound.

• PSI: Pounds per square inch.

• Rebound: The extension or return stroke of the shock.

• Sag: Compression of the shock caused by the rider’s static weight.

• Spring Rate: The amount of force required to compress the spring.

• Topped Out: When the shock or fork rebounds quickly enough to cause a “clunk”

at the very top of its upstroke.

SETUP

Please refer to the individual shock manufacturer’s technical manuals for specific information

4

on how to adjust the shock on your GIANT dual suspension bicycle.
The shock on your GIANT dual suspension bicycle can be adjusted to meet your riding style
and weight. This booklet is intended as a quick-start guide to help you get started. It may
take a few rides to find your preferred settings.

SAG

All GIANT dual suspension bikes rely on sag for its suspension to work efficiently. Please take
a few moments to read through this guide to understand sag as it applies to your bicycle (pgs.
6, 7). Setting your bike’s sag will greatly enhance your riding experience and the performance
of your bicycle.

REBOUND DAMPING

Rebound damping controls the rate of speed at which the shock returns to its original
position after responding to a bump force. Rebound damping prevents the shock from
springing back too quickly. This is desirable because it improves the rear suspension’s
sensitivity to small bumps and the tire’s ability to stay in contact with the ground. It also
helps reduce the “pogo stick” motion from the rear suspension when the bike encounters a
bump while the rider is seated. Typically, the heavier the rider (and higher the necessary
spring rate), the more rebound damping is required. Please refer to this guide for details on
how to set rebound damping rate. You should also refer to the individual shock
manufacturer’s technical manual for specific information.

PEDAL PLATFORM

A pedal platform system is part of the compression damping circuit in the rear shock on your
Maestro bike. The system helps to control pedal induced "bob" on the suspension. Please
refer to the shock manufacturer’s technical manual for specific adjustment information.

NOTE - The linkage design of the Maestro Suspension system is inherently efficient, therefore
very little or no pedal platform is required to get the best from your bike.

GENERAL MAINTENANCE

• Inspect all suspension bolts and tighten if necessary to required torque settings. If

unsure, take your bicycle to your Authorized GIANT dealer immediately for inspection.

• Do not use high-pressure water sources to wash or rinse your bicycle. Doing so can

displace any lubricants that are present, as well as possibly forcing water and/or
contaminants into the bearings that can harm the pivot and bearing, reduce
performance, and cause premature wear. Use only low pressure water, or a bucket of
water with a sponge and a soft nylon bristle brush and mild soap to clean the frame and
components. We would recommend that you do not use dish washing liquid due to its
high salt content that can cause corrosion. If using bicycle specific cleaners/degreasers
please check the manufacturer’s recommended amount of time to leave the cleaner on
your bike. Prolonged exposure to some such cleaners can damage the surface finish of
your frame and or components.

5

FRONT SUSPENSION TRAVEL & SAG GUIDE

• To determine your bike’s specific front suspension travel adjustments and

recommended settings, please refer to the fork manufacturer’s technical manual.

• A suspension fork is effective at both absorbing bump forces and helping the tire to

track the ground for improved traction and braking control.

• When in active mode, a fork will rely on sag to keep the front tire in better contact with

the ground during braking. The chart on page 5 should be used as a general guideline.

COIL SPRING FORKS

• Springs on these types of forks are set at the factory. Most have a simple preload

adjuster that allows the rider to make the fork firmer or softer depending on rider’s
weight. The heavier the rider, the firmer the spring setting should be.

• If with no preload you are not achieving the recommended sag then a softer spring is

needed and if with maximum preload you are achieving too much sag then a harder
spring is needed.

• To check rebound, turn the rebound damping knob (if applicable) counter-clockwise

until it stops. With full body weight, push down on the fork forcefully with the front
brake on and watch (and feel) how the fork rebounds. Turn the rebound damping knob
clockwise until the fork rebounds slightly slower than with no damping (the heavier the
rider, the more damping will be required).

AIR SPRING FORKS

• As a general guide, pump the main chamber (main spring) to a psi equal to 60% of your

rider weight in pounds (2.2lb = 1kg).

• Adjust the fork's sag by using the same procedure used for accurately adjusting, the sag

on your rear shock as described on “SUGGESTED REAR SUSPENSION SAG GUIDE”.

SUSPENSION SAG RECOMMENDATION CHART

FORK TRAVEL (mm)

SAG (mm)

80

12-16

100

20-25

120

24-30

140

35-42

160

48-56

180 54-63

200

60-70

6

REAR SHOCK SETUP GUIDE

COIL SHOCK SETUP

GIANT’s Maestro rear suspension design precisely positions the pivots and linkages to give
you efficient pedaling and small bump compliance. Maestro’s pivot placement allows the
rear suspension to be completely active under pedaling and braking, allowing the rear wheel
to react constantly to the terrain.

• All coil shock-equipped GIANT bicycles use the same formula to determine “sag” and

“rebound damping” (see Basic Terms & Shock setup Overview for definition of sag and
rebound damping).

Please refer to the manufacturer’s technical information for specific details regarding
shock function and setup prior to riding your GIANT bicycle. If you have difficulty with
setup, please see your Authorized GIANT Dealer.

• Maestro-equipped mountain bikes rely on rear suspension “sag.” Sag (see Basic Terms &

Shock Setup Overview) is a critical performance component and is relative to the
individual rider’s weight. See the following sag setting instructions for details.

• GIANT’s Glory DH and Glory frame designs and travel are intended for aggressive

freeriding and recreational/competitive downhill riding. The sag range can
accommodate a wide variety of riding styles and terrain.

• The GIANT Reign is an all-mountain bicycle designed to handle both aggressive trail

riding and light freeriding duties. The multi-tunable shock can be almost infinitely
adjusted for all types of terrain and riding styles.

COIL SHOCKS SETTING & ADJUSTING SAG

1. Turn the spring tension collar counter clockwise

until there is minimal tension on the spring (Fig.1).

2. With a felt-tip marker, place a dot on the edge of

the collar and the shock body so you can measure
full rotations of the shock collar.

3. Position your bicycle next to a wall so that you can

sit on the bike with both feet on the pedals while steadying yourself with one arm.
Gently sit on the saddle without bouncing. Have a partner measure the eye-to-eye
distance while you are seated on the bike (Fig.1).

4. Dismount and subtract the weighted eye-to-eye distance from the un-weighted
eye-to-eye distance to determine sag. See Sag Recommendations charts for sag
distances.

Spring tension collar

Eye to eye

Fig.1

7

5. For general purpose riding, the shock should compress approximately one quarter of its
travel (please refer to the Sag Recommendations charts for specific recommendations
for your frame). Turn the shock’s tension collar clockwise to increase spring
tension/decrease shock sag.

6. If you sit on the bike with minimal tension on the spring and there is less than one
quarter of the shock travel, a lighter weight spring is needed. If you turn the shock
tension collar three complete turns and the shock compresses more than a quarter of
the shock’s travel, a heavier spring is needed. Consult your Authorized Giant Retailer for
replacement springs.

Never tighten the spring tension collar past three turns from minimum tension as
doing so will cause the spring to "coil bind" which can cause damage to the spring
and internal workings of the shock.

AIR SHOCK SETUP

GIANT cross-country, trail and all mountain bikes feature an air shock equipped Maestro
suspension design. Maestro-equipped mountain bikes rely on rear suspension “sag.” Sag (see
Basic Terms & Shock Setup Overview) is a critical performance component and is relative to
the individual rider’s weight.

USING A SHOCK PUMP

These simple steps will help you get the most accurate use of your shock pump and improve
the life of your shock pump.

1. When screwing the pump onto the shock do not screw it on all the way until it stops.
This will damage the seal on the pump and also allow too much air to escape when you
remove the pump.

2. Watch the pressure gauge on the pump when you screw the pump onto the shock.
Screw the pump on until the gauge registers a pressure and then another 1⁄4 - 1⁄2 turn.
At this point you now have a strong air seal.

3. When you remove the pump a small amount of air will always be lost. If you follow our
recommendation above the pressure loss will only be approximately 5% rather than up
to 50% if the pump is screwed all the way onto the valve. Because of this pressure loss
when you have found a pressure that gives you the best performance from your frame
you will need to add 5% extra pressure according to the gauge to leave the required
pressure in the shock once the pump is removed.

E.g. Required pressure is 160psi, 5% = 8psi. Pump the shock until the gauge reads 168psi,
remove the pump, 160psi will be left in the shock.

8

AIR SHOCKS SETTING AND ADJUSTING SAG

1. Pump the main air chamber to a psi equal to 100% of rider
weight in pounds (2.2lb = 1kg).

2. Push the rubber O-ring that is around the shock shaft all the
way against the base of shaft (closest to shock body).

3. Position your bicycle next to a wall so that you can sit on the
bike with both feet on the pedals while steadying yourself with
one arm. Gently sit on the saddle without bouncing. Dismount
gently without bouncing and take note of how far the O-ring
has moved down the shaft. Measure distance O-ring has
moved (Fig. 2).

4. Add or remove air until desired shock movement is obtained.
To achieve a high level of accuracy it’s best to carry out this procedure while wearing
normal riding kit including shoes, hydration pack, any tools, etc. The shock pump must
be removed every time you check the sag.

• Please refer to the shock manufacturer’s technical manual for minimum and

maximum working pressures for your shock. Refer to the Sag Recommendation
Guide on the next page for proper sag measurement.

• If there is no O-ring on the shock body or you cannot clearly see the shock shaft

then please use the method for coil spring bikes using the eye to eye
measurement as described on page 6.

COIL & AIR SHOCKS SETTING & ADJUSTING REBOUND DAMPING

(See Basic Terms and Shock Setup Overview for definition of rebound damping).

1. If you are unfamiliar with rebound damping, perform this procedure: With full body
weight, push down on the saddle forcefully to compress the shock. Watch (and feel) how
the shock rebounds from compression.

2. Next, turn the rebound damping knob clockwise until it stops and compress the shock
under full body weight. Note that the shock rebounds very slowly. Next, turn the
damping knob counterclockwise a few complete turns and re-perform your compression
testing until the shock rebounds more slowly than with no damping.

3. To check the rebound damping rate while riding, ride off a curb while seated. The rear
suspension should bounce only once upon rebound (the heavier the rider, the more
damping will be required). Adjust accordingly to accomplish this motion. If the
suspension bounces more than once, turn the damping knob clockwise until one bounce
is achieved.

Fig. 2

O-ring

9

SUGGESTED REAR SUSPENSION SAG GUIDE

MY19 bike models

Bicycle

Model

Rear Wheel

Travel

Eye To Eye

Shock Length

Shock
Travel

Shock

Mounting

Type

Hardware

Recommend

Sag %

Sag Measured

By Travel

Anthem 29

Series

90.mm 165 mm 42.5mm

Trunnion

/Metric

54x10/No

Bushing

20-25% 8.5-10.6 mm

Anthem

Series

110.mm 165 mm 42.5mm

Trunnion

/Metric

54x10/No

Bushing

20-30 % 8.5-12.8 mm

Stance

Series

120.mm 184.15 mm 44.5mm

Standard/In

ch

22.2x6/No
Bushing

25% 11 mm

Embolden

Series

120.mm 184.15 mm 44.45mm

Standard/In

ch

22.2x6/No
Bushing

25% 11 mm

Pique
Series

120.mm 165 mm 42.5mm

Trunnion

/Metric

54x10/No

Bushing

25-30 % 10.6-12.8 mm

Trance 29

Series

115.mm 165 mm 42.5mm

Trunnion

/Metric

54x10/No

Bushing

25% 10.6 mm

Trance Jr

Series

120.mm 165 mm 42.5mm

Trunnion

/Metric

54x10/No

Bushing

25% 10.6-12.8 mm

Trance

Series

140.mm 185 mm 52.5mm

Trunnion

/Metric

54x10/No

Bushing

30% 15.8 mm

Intrigue

Series

140.mm 185 mm 52.5mm

Trunnion

/Metric

54x10/No

Bushing

30% 15.8 mm

Reign

Series

160.mm 205 mm 62.5mm

Trunnion

/Metric

54x10/No

Bushing

30-35% 18.8-21.9 mm

Hail Series 160.mm 205mm 62.5mm

Trunnion

/Metric

54x10/No

Bushing

30-35% 18.8-21.9 mm

Glory

Series

200.mm 240 mm 76.mm

Standard/In

ch

40x8/No

Bushing

30-35% 22.8-26.6 mm

10

MY18 bike models

Bicycle
Model

Rear Wheel

Travel

Eye To Eye

Shock Length

Shock

Travel

Shock

Mounting

Type

Hardware

Recommend

Sag %

Sag Measured

By Travel

Anthem 29

series

90.mm 165 mm 42.5mm

Trunnion

/Metric

54x10/No

Bushing

20-25% 8.5-10.6 mm

Anthem

series

110.mm 165 mm 42.5mm

Trunnion

/Metric

54x10/No

Bushing

20-30 % 8.5-12.8 mm

Stance

series

120.mm 184.15 mm 44.5mm

Standard/In

ch

22.2x6/No
Bushing

25% 11 mm

Embolden

series

120.mm 184.15 mm 44.45mm

Standard/In

ch

22.2x6/No
Bushing

25% 11 mm

Pique
series

120.mm 165 mm 42.5mm

Trunnion

/Metric

54x10/No

Bushing

25-30 % 10.6-12.8 mm

Trance Jr

series

120.mm 165 mm 42.5mm

Trunnion

/Metric

54x10/No

Bushing

25% 10.6-12.8 mm

Trance

series

140.mm 185 mm 52.5mm

Trunnion

/Metric

54x10/No

Bushing

30% 15.8 mm

Reign
series

160.mm 205 mm 62.5mm

Trunnion

/Metric

54x10/No

Bushing

30-35% 18.8-21.9 mm

Hail series 160.mm 205mm 62.5mm

Trunnion

/Metric

54x10/No

Bushing

30-35% 18.8-21.9 mm

Glory

series

200.mm 240 mm 76.mm

Standard/In

ch

40x8/No

Bushing

30-35% 22.8-26.6 mm

MY17 bike models

Bicycle

Model

Rear Wheel

Travel

Eye To Eye

Shock Length

Shock
Travel

Shock

Mounting

Type

Hardware

Recommend

Sag %

Sag Measured

By Travel

Anthem 29

series

100 mm 165 mm 38 mm Standard

22.2x6/No

Bushing

20-25% 7.6-9.5 mm

Anthem

series

110 mm 165 mm

42.5

mm

Trunnion

/Metric

54x10/No

Bushing

20-30% 8.5-12.8 mm

Stance

series

120 mm 184.15 mm

44.45

mm

Standard

22.2x6/No

Bushing

25% 11 mm

Embolden

series

120 mm 184.15 mm

44.45

mm

Standard

22.2x6/No

Bushing

25% 11 mm

Pique

series

120 mm 165 mm

42.5

mm

Trunnion

/Metric

54x10/No

Bushing

25-30% 10.6-12.8 mm

Trance

series

140 mm 185 mm 52.5 mm

Trunnion

/Metric

54x10/No

Bushing

30% 15.8 mm

Reign

series

160 mm 200 mm

57.15

mm

Standard

40x8/No

Bushing

30-35% 17.1- 20 mm

Hail series 160 mm 205 mm 62.5 mm

Trunnion

/Metric

54x10/No

Bushing

30-35% 18.8-21.9 mm

Glory

series

200 mm 240 mm 76 mm Standard

40x8/No

Bushing

30-35% 22.8-26.6 mm
