Micro Switch
Free P osi tion
SWH-0 40
Mate rial: Sta inless st eel
Mome ntary (N. O. /N.C. ) Do uble Po le Double Thr ow
Max. R ating : 5A/ 12 5/250 VAC
Cont act resis tance: 50 m Ω Ma x.(in it ial)
Oper ating lif e(Mecha nical) : Ov er 100,00 0 times
Oper ating tra vel: 2.7 mm
Cabl es includ ed
SWH-0 50
Mate rial: Sta inless st eel
Max. R ating : 5A 125/ 250 VAC
Mome ntary (N. O. /N.C. ) Do uble Po le Double Thr ow
Cont act resis tance: 50 m Ω Ma x.(in it ial)
Oper ating lif e(Mecha nical) : Ov er 100,00 0 times
Oper ating tra vel: 2.7 mm
Cabl es includ ed
/
Oper ati on Posi tion
2.7mm
Free P osi tion
Oper ati on Posi tion
2.7mm
Free P osi tion
35.8
M30 x P1.5mm
27.9
28.3
30.3
SWH-0 60
Mate rial(Bu tton): Zi nc alloy
Max. R ating : 5A 125/ 250 VA
/ C
Mome ntary (N. O. /N.C. ) Do uble Po le Double Thr ow
Cont act resis tance: 50 m Ω Ma x.(in it ial)
Oper ating lif e(Mecha nical) : Ov er 100,00 0 times
Oper ating tra vel: 2.7 mm
Cabl es includ ed
SWH-0 70
Mate rial: Sta inless st eel
Mome ntary (N. O. /N.C. ) Do uble Po le Double Thr ow
Max. R ating : 5A/ 12 5/250 VAC
Cont act resis tance: 50 m Ω Ma x.(in it ial)
Oper ating lif e(Mecha nical) : Ov er 100,00 0 times
Oper ating tra vel: 2.7 mm
Free P osi tion
Oper ati on Posi tion
2.7mm
Oper ati on Posi tion
2.7mm
Oper ati ng trav el:
2.7m m
Oper ati ng trav el:
2.7m m
35.8
35.8
M30 x P1.0mm
27.9
23.0
2.0
38.0
M30 x P1.0mm
13.0
25.3
Copyr ig ht © 2010 G ia nni Ind us tries , In c. All rig ht s reser ve d.
DM-CA -P BT-Swi tc h Ver. E Publ is hed on 20 11.05. 10
GIANN I INDUSTR IES, INC.
No. 13, Zhongxing Rd., Tucheng Dist., New Taip ei
City 236,Taiwan (R.O.C.)
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: inquiry@gianni.com.tw
Web si te : gi an ni .t w
Micro Switch
M19 x P1.0 mm
0.5mm thickness
MSW-19 01 -EXIT
MSW-25 01 -EXIT
Mate rial: Sta inless st eel
Mome ntary (N. O. ) Singl e Pole Sing le Thr ow
Max. R ating : 5mA /1 2VDC
Cont act resis tance: 1k Ω Ma x.(in it ial)
Oper ating lif e(5mA/5 VDC) : Over 1 00,000 ti mes
Oper ating tra vel: 1.75 mm
MSW-19 02 -EXIT
MSW-25 02 -EXIT
S-SI -PBT-4-GE M
Mate rial: Sta inless st eel
Mome ntary (N. O. /N.C. ) Do uble Po le Double Thr ow
Max. R ating : 5A/ 12 5/250 VAC
Cont act resis tance: 50 m Ω Ma x.(in it ial)
Oper ating lif e(Mecha nical) : Ov er 100,00 0 times
Oper ating tra vel: 2.7 mm
Cabl es includ ed
22
14.0
16.0
MSW-19 01 -EXIT
MSW-25 01 -EXIT
Free P osi tion
Oper ati on Posi tion
2.7mm
1.0
8.0
14.0
17.5
MSW-19 02 -EXIT
MSW-25 02 -EXIT
34mm
2mm
22mm
2.0
M19 x P1.0mm
SWH- CN0 20
Mate rial : Copp er alloy
Max. R ating :
Mome ntary(N .O.) Sing le Pole Sin gle Throw
Cont act resis tance: 50 m Ω Ma x.(in it ial)
Oper ating lif e(Mecha nical) : Ov er 100,00 0 times
Oper ating tra vel: 2.0 mm
SWH- 1922
Mate rials: St ainless s teel
Mome ntary(N .O./N.C .) D ouble P ole Doubl e Th ro w
Max. R ating : 5A/ 12 5/250 VAC
Cont act resis tance: 50 m Ω Ma x.(in it ial)
Oper ating lif e(Mecha nical) : Ov er 100,00 0 times
Oper ating tra vel: 2.7 mm
Cabl es includ ed
3A/1 25V AC, 6A/2 4V DC
SWH- 1925
Free P osi tion
Oper ati on Posi tion
2mm
Free P osi tion
Oper ati on Posi tion
2.7mm
Oper ating tra vel: 2.7m m
22mm
(25mm)
22mm
27mm
3mm
2.0
M19 x P0.75mm
32mm
28mm
M19 x P1.0mm
2.0
Copyr ig ht © 2010 G ia nni Ind us tries , In c. All rig ht s reser ve d.
DM-CA -P BT-Swi tc h Ver. E Publ is hed on 20 11.05. 10
GIANN I INDUSTR IES, INC.
No. 13, Zhongxing Rd., Tucheng Dist., New Taip ei
City 236,Taiwan (R.O.C.)
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: inquiry@gianni.com.tw
Web si te : gi an ni .t w
SWH- 160 -RESWH- 160 -GE
Mate rial: Zin c alloy
Max. R atings : 5A @125/25 0 Vac
Mome ntary (N/ O, N/C) Do uble Pole D ouble Throw
Cont act resis tance: 50 mΩ Max.(i ni tial)
Oper ating lif e(Mecha nical) : Ov er 100,00 0 times
Oper ating tra vel: 2.7m m
Micro Switch
Free P osition
Oper ation Pos ition
Oper ating tra vel:
2.7m m
35.0
45.0
M22 x P1.5mm
5
23.0
thickness
(SWH -16 0-GE)
2.0
29.9
0.6mm
SWH- 190 -RESWH- 190 -GE
Mate rial: PVC
Max. R ating : 5A 125/ 250 V
Mome ntary (N/ O, N/C) Do uble Pole D ouble Throw
Cont act resis tance: 50 mΩ Max.(i ni tial)
Oper ating lif e(Mecha nical) : Ov er 100,00 0 times
Oper ating tra vel: 2.7m m
/ AC
Free P os ition
Oper ation Pos ition
Oper ating tra vel:
2.7m m
20.5
36
M22 x P1.5mm
23
29.9
5
0.6mm
thickness
Copyr ig ht © 2010 G ia nni Ind us tries , In c. All rig ht s reser ve d.
DM-CA -P BT-Swi tc h Ver. E Publ is hed on 20 11.05. 10
GIANN I INDUSTR IES, INC.
No. 13, Zhongxing Rd., Tucheng Dist., New Taip ei
City 236,Taiwan (R.O.C.)
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: inquiry@gianni.com.tw
Web si te : gi an ni .t w
Micro Switch
SW H- 104 00 SW H- 105 00
Materials:ABS
Switch Ratings : 1.5A, 250V
or 1A, 125~250VAC
S
ingle pole double throw (SPDT)
(COM,N/C,N/O)
Cable Length : 4 Meters
Rectangular faceplate
Faceplate Dimensions:
42(H)x23(W)x3(D)mm
Materials:ABS
Switch Ratings : 1.5A, 250V
or 1A, 125~250VAC
S
ingle pole double throw (SPDT)
(COM,N/C,N/O)
Cable Length : 4 Meters
Oval-shaped faceplate
Faceplate Dimensions:
42(H)x23(W)x3(D)mm
SW H- 104 05
Swit ch Materi al: Coppe r alloys
Mome ntary (N. O. /N.C. /C om) Sin gl e Pole Do uble Throw
Max. R ating : 3A 125/ 250 V
/ AC
Oper ating lif e(Mecha nical) : Ov er 100,00 0 times
Oper ating tra vel: 2.7m m
22.5
Ø 20.0
Un it : mm
Ф M18XP1.0mm
Copper
34
25
2.5
5.0
22.5
Ø 8.5
42.0
3
35
55
3
Ø 4.5
Ø 15.0
26
Ф10.5
Ф 5.1
Ф M18
Stainless
Unit:mm
SW H- 104 05 CB
Position bolt
Switch Ratings : 5A/250VAC
S
ingle pole double throw (SPDT)
(COM,N/C,N/O)
Dimension: M18XP1.0mm
Cable Length : 4 Meters
Rectangular stainless
steel faceplate
Faceplate Dimensions:
55(H)x26(W)x3(D)mm
SW H- 104 05 CB -42
Position bolt
Switch Ratings : 5A/250VAC
S
ingle pole double throw (SPDT)
(COM,N/C,N/O)
Dimension: M18XP1.0mm
Cable Length : 4 Meters
Rectangular stainless
steel faceplate
Faceplate Dimensions:
42(H)x23(W)x3(D)mm
Narrow Faceplate
Copyr ig ht © 2010 G ia nni Ind us tries , In c. All rig ht s reser ve d.
DM-CA -P BT-Swi tc h Ver. E Publ is hed on 20 11.05. 10
SW H- 105 05 CB
Position bolt
Switch Ratings : 5A/250VAC
S
ingle pole double throw (SPDT)
(COM,N/C,N/O)
Dimension: M18XP1.0mm
Cable Length : 4 Meters
Oval-shaped stainless
steel faceplate
Faceplate Dimensions:
55(H)x26(W)x3(D)mm
SW H- 105 05 CB -42
Position bolt
Switch Ratings : 5A/250VAC
S
ingle pole double throw (SPDT)
(COM,N/C,N/O)
Dimension: M18XP1.0mm
Cable Length : 4 Meters
Oval-shaped stainless
steel faceplate
Faceplate Dimensions:
42(H)x23(W)x3(D)mm
Narrow Faceplate
34
25
Ф M18XP1.0mm
34
25
Ф M18XP1.0mm
3
55
3
3
32
42
3
26
35
23
GIANN I INDUSTR IES, INC.
No. 13, Zhongxing Rd., Tucheng Dist., New Taip ei
City 236,Taiwan (R.O.C.)
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: inquiry@gianni.com.tw
Web si te : gi an ni .t w
Ф10.5
Ф5.1
ФM18
Unit:mm
M18x1 .0 P
23
32
42
Micro Switch
SWH- 250 -GE
(ø 50 mm )
SWH- 260 -GE
(ø 60 mm )
SWH- 251 -GE
(ø 50 mm )
SWH- 261 -GE
(ø 60 mm )
SWH- 250 -BL
(ø 50 mm )
SWH- 260 -BL
(ø 60 mm )
Free P osition
Oper ation Pos ition
You can use th e push butt on
at any an gle.
Oper ating tra vel:
2.7m m
Mate rials: Zi nc alloy
Swit ch Rating :
Mome ntary Dou ble Pole Do uble Throw
Cont act resis tance: 50 mΩ Max.(i ni tial)
Oper ating lif e(Mecha nical) : Ov er 100,00 0 times
Oper ating tra vel: 2.7m m
5A/1 25 VAC
SWH- 251 -BL
(ø 50 mm )
SWH- 261 -BL
(ø 60 mm )
SWH- 250 -RE
(ø 50 mm )
SWH- 260 -RE
(ø 60 mm )
SWH- 251 -RE
(ø 50 mm )
SWH- 261 -RE
(ø 60 mm )
50.0
60.0
10.5
10.5
40.0
40.0
M22 x P1.5mm
5
23.0
(SWH -25 0)
M22 x P1.5mm
5
23.0
(SWH -26 0)
2.0
24.5
0.6mm
thickness
2.0
24.5
0.6mm
thickness
Copyr ig ht © 2010 G ia nni Ind us tries , In c. All rig ht s reser ve d.
DM-CA -P BT-Swi tc h Ver. E Publ is hed on 20 11.05. 10
GIANN I INDUSTR IES, INC.
No. 13, Zhongxing Rd., Tucheng Dist., New Taip ei
City 236,Taiwan (R.O.C.)
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: inquiry@gianni.com.tw
Web si te : gi an ni .t w
