GIANNI INDUSTRIES, INC.
Operating Features
Specifications
Opera ting Vo ltage : 12/2 4 VDC
Curre nt Dra w: 500 mA/12 VDC;250 mA/24 VDC
(at 20 degre e cent igrad e)
Opera ting Temp eratu re : -10~ 55ºC (1 4~131 ºF )
Humid ity: 0~ 95% non -cond ensing.
Holdi ng Forc e: Up to 60 0 lbs (27 2 Kg)
Dimen sions :
Magne t:(L) 2 50, (W) 4 2.5, (D ) 25 mm
Armatu re Plat e:(L) 1 85, (W) 3 8, (D) 12 m m
Mount ing Pla te:(L ) 250, (W ) 25, (D) 5 m m
Finis hes for m agnet a nd arma ture plat e: Zinc P lated
Epoxy P ottin g Compo und: E8 7252 (S), UL94V-0
Net Wei ght: 2. 0 Kg
EM-600/EM-600TD
Mini Electromagnet Lock
Cop yrigh t © Giann i Indus tries , Inc. All r ights r eserv ed.
DM- CA-EM -600 Ver. A Pub lishe d on 2010 .02.0 9
Features
High reliability
Fail- safe ( Power to Lock).
Aluminum anodized casing.
MOV provides spike and surge protection.
Dual voltage 12 or 24 VDC (selectable).
Anti-Residual magnetism function
Statement
The E M-600 ar e hig h q ualit y and sa fety range of stan dard fai lsafe elect romag net lock s t hat is simp ly, wo rks well in orde r t o
effec tivel y secur e wi th door s. The EM -600 are su rface m ou nted fa ce
to fac e l ocks o ffe ring u p to 600 po unds h oldin g fo rce wh ich th is l ock
is re comme nded for ap plica tions whic h r equir e high er le vels of
acces s a nd egres s c ontro l a nd is suita ble for fir e d oors and
emerg ency exit doors. The EM-600 Series are design ed for sing le
doors a nd are su itabl e for out -swing ap plica tions .
Optional Brackets
With LZ -brac ket for i n-swi ng doors
LZ-EM-600
Regular Installation
The p roduc t is warr anted agains t defec ts in m ateri al and
workm anshi p wh ile used in no rmal serv ice for a pe riod of 5
years from the dat e of sal e to the orig inal clien t. The GEM
polic y is o ne of conti nual de velop ment an d im prove ment;
there fore G EM reser ves th e righ t to change speci ficat ions
witho ut noti ce.
Warranty
EM-600TD: Relock time delay
N.O.
COM.
N.C.
Powe r
Inpu t
SPDT re lay
1A/2 4VDC
Timer Ad just
Shor ten
Trigg er
Mag net
Arm ature
(On P ower)
Mag net
Arm ature
(Po wer Off)
Anti-r esidu al stat ement
Our elect romag net locks fea ture Anti- Resid ual Magne tism
(ARM) w hich ensur es the door ca n be op ened witho ut any
resis tance fr om left over magn etism im parte d t o the arm ature
plate
Ensur es the automatic l ock mode
after t he d oor is clos ed prop erly and it
can be ad juste d from 1 to 8 0 secon ds.
No. 13, Z hon gxi ng Rd ., Tuc heng Dist. , New Taipei
City 23 6,Tai wan ( R.O .C. )
Te l: 88 6-2 2 267 7 986 / F ax: 8 86 -2 22 67 98 76
E-Mai l: in qui ry@ gia nni.com. tw
Web site: gian ni. tw
