24395951 01022019
17L Halogen Cooker
1
Model Ref:
Instruction Manual
GC-CK-A15 Cat No.: 24395951
INTRODUCTION
Thank you for choosing this 17L Halogen Oven. This
product is manufactured to the highest standards of
performance and safety.
Before use, please read this manual carefully. It gives
important instructions about safety, use and maintenance of
your device.
Remove all packaging material. You may wish to keep
the packaging for future use or storage of your device.
Alternatively, dispose of accordingly.
CONTENTS
Introduction
Important Safety Information
....................................................... 01
.......................... 02
General Guidelines and Warning .................... 03
Product Overview
............................................. 04
Features............................................................. 05
Recommended Cooking Times ....................... 09
Specification ..................................................... 10
01
IMPORTANT SAFETY INFORMATION
These basic safety precautions should always be followed:
- Always switch the power off before removing power cable
from the wall outlet.
- Remove the power cable by the plug. DO NOT PULL THE
CORD.
- To protect against electrical shock, do not immerse cord,
plugs or motor assembly in water or other liquids.
- Unplug from wall outlet when not in use and before
cleaning.
- Allow the appliance to cool before putting on or taking o
parts.
- Do not use outdoors. This appliance is not designed for
outdoor use.
- Do not place the appliance on or near electrical equipment,
hot gas flame or in a heated oven.
- Do not let the cord hang over the edge of a table or counter
or to touch hot surfaces. Always use on a stable flat surface.
- Extreme caution must be used when moving an appliance
containing hot oil or other hot liquids.
- Do not use appliance for anything other than the intended
purpose.
- Do not move or lift the halogen cooker while the power cord
is still connected to the wall outlet. Remove the plug from the
wall outlet, then remove the top by using both hands, move
carefully.
- Before removing the lid: Disconnect the power cable, lift the
top using the carrying handle, place the top, preferably
resting the stainless steel edge rim a on a flat surface.
02
- Do not place the hot underside of the lid directly onto
laminated, wood, paper, plastic or other flammable surfaces.
Put the lid on a heat resistant surface.
- Always place the top unit onto the bowl before plugging in
the power cord and switching on.
- Do not clean with metal scouring pads.
- Do not operate if the appliance has a damaged or broken
cable or plug, return the oven to authorized service centre or
qualified persons.
- The appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given superivision or instruction concerning
use of the appliance by a person responsible for their safety.
GENERAL GUIDELINES AND WARNING
- Remember to distribute food evenly in the halogen cooker
to ensure an even flow of air all around the food.
- The first time you try a recipe, check the cooking process
through the tempered glass bowl as the cooking time of the
halogen cooker is shorter.
- Since it is practical to place food directly onto the wire rack,
you may want to spray it with a non-stick spray to avoid food
sticking to the rack.
- The halogen cooker is self-cleaning. Simply put 2” of water
in the bottom and set temperature dial to 'wash' (100) for
10-12 minutes.
- For a very dirty oven, add some detergent to the water and
wipe the stains if needed.
03
PRODUCT OVERVIEW
Accessories
Extender Ring
Low Cooking Rack
High Cooking Rack
Cooking Tongs
04
FEATURES
Multifunction:
Using a hot air circle and 65-250°C temperature
range, the convection oven has a lot of functions:
a. cook food in different ways, including baking, roasting,
grilling, toasting, broiling and BBQ .
b. defrost frozen foods quickly
c. drying and sterilizing
Lowering cholesterol:
Modern medical science has proved that high cholesterol
accounts for heart disease and blood vessel trouble. The hot
moving air circle in the convection oven will breakdown the fat
tissue and lower the cholesterol content.
Saving time and energy
Due to the efficiency of the hot moving air in the oven, the
cooking time and the consumed energy are reduced. Our
experiment shows that the convection oven saves electricity
up to 20% compared to ordinary ovens.
Preserving the food’s nutrition and the natural flavor. High
temperature and prolonged cooking time can destroy the
food’s nutrition and change its natural flavor. The temperature
and time control in the convection oven retains more of the
nutrients and flavours in the food.
05
IMPORTANT
1. When the halogen cooker is in use, the support base holding
the glass bowl will expanded with the heat and appear loose
around the bowl, this is normal, it will be restored when it has
cooled down.
2. Do not put the cooker lid directly onto the work surface after
cooking. Place it on a dish, bowl or heat-resistant base to avoid
heat damage to your work area.
3. The controls on the cooker lid should not be washed or
submerged in the water. Clean the lid with a clean soft damp
cloth.
4. The glass bowl can be washed once it is completely cooled
down. Do not add water or submerge in water whilst hot to
avoid the glass bowl breaking.
Using the cooker
1. Place the steel rack into the glass bowl, then add the food.
Note: there should be some space between the food and the
cooker lid to ensure the hot air can circulate around the food
efficiently. Note: Overloading the glass bowl with food can also
affect cooking times.
2. Plug in the cooker according to the power specification. Note:
the cooker should not be used plugged into an extension lead or
multi adapter.
3. Turn the timer clockwise to your required time, the red lamp
will illuminate.
06
4. Turn the temperature controller clockwise to the required
temperature, the green light will then illuminate. The convection
will now start cooking.
5. The green light indicates that the cooker is heating up to the
required temperature. Once it has reached its set temperature
the green light will go out. If the temperature drops the cooker
will turn the heat back on and the green light will illuminate
again.
Note: The handle on top of the cooker when lifted will cut the
power to the unit and stop cooking. Push the handle back
down to resume power. If placing the cooker lid on a surface,
ensure the power is disconnected until it is returned to the top of
the bowl.
Note: If you wish to increase the capacity of your cooker from
12 L to 17L use the collar sleeve provided.
How to Broil
- Place the food directly on the wire rack (low or high rack)
- For very thick cuts of meat , turn the food at the halfway point
- Like roasting, broiling time may vary depending on cut, size,
amount of fat, etc.
How to Steam
- You can steam vegetables at the same time you cook your
Main dish by placing the vegetables in an aluminum foil pouch:
add a few drops of water and seal the pouch.
- You can also add a cup of water in the bottom pot, with savory
herbs and spices to steam sh or vegetables.
07
How to Fry
- You can get the effect of deep-fat fried French Fries without all
the oil by dipping potato strips in polyunsaturated cooking oil,
allow excess oil to drain away and cook according to cooking
guide.
- To make delicious fried chicken , dip chicken pieces in batter
and then in cooking oil, drain excess oil and cook according to
chart provided.
How to Toast
- You can toast bread and snacks with the convection oven
without preheating. Simply put the food directly onto the wire
rack and watch it toast. It will be crisp on the outside and stay
soft on the inside.
How to Defrost
-You can use the convection oven to defrost frozen food more
evenly than microwave ovens, simply set the temperature
controller to 'thaw' (100°C
) and check the food every 5-10
minutes.
08
RECOMMENDED COOKING TIMES
Food Time Temperature
Chicken 25-30 mins 230-250C
Fish 10-15 mins 200-220C
Cake 8-10 mins 200-230C
Lobster 12-15 mins 180-200C
Shrimp 10-12 mins 150-180C
Sausage 10-13 mins 120-150C
Peanut 10-15 mins 140-160C
Roasted Bread 8-10 mins 120-140C
Potato 12-15 mins 180-200C
Chicken Wings 15-20 mins 150-180C
Crab 10-13 mins 140-160C
Hot Dogs 5-8 mins 190-210C
BBQ Spareribs 18-20 mins 220-240C
NOTE: The times above are only a guideline. The quantity
of food, cooking temperature and personal preference will
effect the overall cooking times.
09
SPECIFICATION
Voltage
Rated power 1200-1400W
Thermostat 65 – 250 °C
Timer 0-60 minutes
Container capacity
Gross weight
Net weight 4.90kg
220-240 V / 50Hz
Ø 305 x 225 mm
6.62kg
14
DISPOSAL INFORMATION
IMPORTANT INFORMATION FOR CORRECT DISPOSAL
OF THE APPLIANCE IN ACCORDANCE WITH EC
DIRECTIVE 2002/96/EC
At the end of its working life, the Halogen Oven must NOT
be disposed of as urban waste.
It must be taken to a special local authority dierentiated
waste collection centre or to a dealer providing this service.
Disposing of a household appliance separately avoids
possible negative consequences for the environment and
health deriving from inappropriate disposal and enables the
constituent materials to be recovered to obtain signicant
savings in energy and resources. As a reminder of the need
to dispose of household appliances separately, the product is
marked with a crossed-out wheeled dustbin.
15
JA1731XQ
