Digital Cordless Phone
User Manual
Model BL300-1/BL300-2
2
TABLE OF CONTENTS
Important Safety Instructions..................................................................................................... 3
Safety Instructions for Handset Battery Pack ............................................................................ 4
LCD Display .............................................................................................................................. 6
Getting Started............................................................................................................................ 7
Install and Charge the Battery Pack ........................................................................................... 7
Basic Operation ........................................................................................................................ 10
Making Internal Calls............................................................................................................... 10
Making External Calls.............................................................................................................. 10
Receiving External Calls.......................................................................................................... 11
Receiving Internal Call............................................................................................................. 11
Redialing .................................................................................................................................. 11
Dialing from the Phone Book................................................................................................... 13
Muting the Microphone............................................................................................................ 13
Muting the Ringer volume ....................................................................................................... 13
Call Transfer / Forwarding....................................................................................................... 13
Three Party Conference............................................................................................................ 14
Changing the Earpiece Volume ................................................................................................ 14
Paging the Handset...................................................................................................................14
Handset Speaker Phone............................................................................................................ 14
Key Lock .................................................................................................................................. 14
Short Key Definition ................................................................................................................ 14
Phone Book .............................................................................................................................. 15
Date & Time............................................................................................................................. 17
Call List.................................................................................................................................... 17
Display Setup ...........................................................................................................................18
Base Setup ................................................................................................................................ 19
Ringer ....................................................................................................................................... 19
Dial Mode................................................................................................................................. 20
MW Indication .........................................................................................................................20
Reset Base ................................................................................................................................ 20
HS Settings............................................................................................................................... 20
Ringer Setup............................................................................................................................. 21
Set Alarm................................................................................................................................. 22
Auto Talk .................................................................................................................................. 23
Registration .............................................................................................................................. 23
Select Base ............................................................................................................................... 24
Tones On/Off............................................................................................................................ 24
Reset Handset........................................................................................................................... 24
GFM Guarantee........................................................................................................................ 27
3
Important Safety Instructions
BEFORE USING YOUR TELEPHONE EQUIPMENT, BASIC SAFETY PRECAUTIONS SHOULD
ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND INJURY
TO PERSON, INCLUDING THE FOLLOWING:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleanser or aerosol cleanser.
Use a damp cloth for cleaning.
4. Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink, laundry tub,
in a wet basement, or near a swimming pool.
5. Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious
damage to the product.
6. Slots and openings in the cabinet and the back or bottom are provided for ventilation. To protect it
from overheating, these openings must not be blocked or covered. The openings should never be
blocked by placing the product on the bed, sofa, rug, or other similar surface. This product should
never be placed near or over a radiator or heat re gister. This produc t should not be placed in a built-in
installation unless proper ventilation is provided.
7. This product should be operated only from the type of power source indicated on the label. If you are
not sure of the type of power supply to your home, consult your dealer or local power company.
8. Do not allow anything to rest on the power cord. Do not lo cate this product where the cord will be
damaged by persons walking on it.
9. Do not overload wall outlet extension cords, as this can result in the risk of fire or electric shock.
10. Never push objects of any kind into this product through cabinet slots as they may touch dangerous
voltage points or short out parts that could result in a risk of fire or electric shock. Never spill liquid of
any kind on this product.
11. To reduce the risk of electric shock, do not disassemble this product. Instead, when repair work is
required, take the unit to a qualified technician. Opening or removi n g covers may expose you to
dangerous voltages or other risks. Incorrect reassembly can cause electric shock when the appliance is
subsequently used.
12. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire.
They may explode.
13. Unplug this product from the wall outlet and refer servicing to a qualified service personnel under the
following conditions:
a. When the power supply cord or plug is damaged or frayed.
b. If liquid has been spilled into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following the operating instructions. Adjust only those
controls that are covered by the operating instructions because improper adjustment of other controls
may result in damage and will often require extensive work by a qualified technician to restore the
product to normal operation.
4
e. If the product has been dropped or cabinet has been damaged.
f. If the product exhibits a distinct change in performance.
14. Avoid using a telephone (other than a cordless type) d uring an electrical storm. There may be a re mote
risk of electrical shock from lightning.
15. Do not use the telephone to report a gas leak in the vicinity of the leak.
16. This power unit is intended to be correctly oriented in a vertical or floor mount position.
17.
Use only with Class (Class 2) power source 7.5VDC 320mA .
SAVE THESE INSTRUCTIONS
Safety Instructions for Handset Battery Pack
CAUTION:
There is danger of explosion if the battery is incorrectly replaced. Use only an approved
battery pack in the handset of your Cordless Telephone System. To reduce the risk of fire or
injury, always do the following when replacing, discarding, or charging battery. When
handling the batteries, be careful not to short the battery with conducting materials such as
rings, bracelets, and keys. The Battery or conducting material may overheat and cause
burns. Risk of explosion if battery is replaced by an Incorrect type. Dispose of used batteries
according to the instructions. Use only with (GPI GP60AAAH2BMJZR; (2.4V,600mAH)
NiMH rechargeable battery) / LEXEL LH065-3A43C2BRJS1P (2.4V,600mAH) NiMH
rechargeable battery)
CONTAINS NICKEL-METAL HYDRIDE BATTERY. BATTERY MUST
BE RECYCLED OR DISPOSED OF PROPERLY
18. Do not dispose of the battery in a fire. The cell may explode. Check with local codes for possible special
disposal instructions.
19. Do not open or mutilate the battery. Released electrolyte is corrosive and may cause damage to the
eyes or skin. It may be toxic if swallowed.
20. Exercise care in handling batteries in order not to short the battery with conductin g materials such as
rings, bracelets and keys. The battery or conductor may overheat and cause burns.
21. Charge the batteries provided with, or id entified for use, with this product only in accordance with the
instructions and limitations specified in this manual.
22. Observe proper polarity orientation between the battery(ies) and the battery charger.
23. Do not mix old and new batteries in this product.
24. Do not mix batteries of different sizes or from different manufacturers in this product.
SAVE THESE INSTRUCTIONS
5
Handset Layouts
Redial / Up key
CID key / down key
Left soft key ( SKL ) /Menu OK key
Right soft key ( SKR ) / Intercom
key
Right key
Phonebook key
Left key/Mute key
External Call key/Flash key
Speaker phone key
End call key
Asterisk / Ringer off key
Pause / Space key
Hash key / Lock key
6
Base layouts
Charger suitable for Model BL300-2
Paging
CID
7
LCD Display
Main Menu idle
Icon Icon Name
Small Icon
Battery icon
Key lock icon
Line in use icon
Speak phone icon
Mic mute icon
No ring icon
Signal icon
Alarm icon
Large Icon
Date & Time icon
Calls List icon
Display Setup icon
Base Setup icon
Phone Book icon
HS Settings icon
Getting Started
Install and Charge the Battery Pack
1 Open the battery compartment by sliding the cover down.
2 Plug the Battery Pack connector into the Handset socket, then place the battery pack and wires in the
compartment.
3 Slide the battery cover back into place.
8
Place the handset in the base station to charge for 16 hours prior for first use. If you don’t
properly charge the phone, battery performance will be compromised.
Connecting the Base Station and Power Plug
Connecting the plugs to the corresponding sockets in the base station (they can not be
connected incorrectly because the sockets and plugs are designed prevent reverse poling). Lay
the cable under the telephone to the rear. Plug the telephone line in the telephone connection
socket. Insert the power plug at the other end in the power outlet. The base station is now ready
to operate.
Only use the connection cable supplied.
AC power outlet Phone jack
CAUTION:
Plug the adapter to the socket outlet that near the equipment and shall be easily
accessible. Use only the power supply that came with this unit. Using other power supplies
may damage the unit.
9
Features
We are very pleased that you have purchased this highly sophisticated, cordless telephone
which is equipped with the following features:
1. Digital cordless telephone complying to DECT standards
2. Operation instruction in 3 languages
3. Teleconference
4. Call transfer/forwarding
5. Internal, free communication between handsets
6. Automatic call answering on/off
7. Phone book group function (6 groups)
8. Color display with icon driven menu
9. Phone book for 50 entries
10. Extended redialing for 10 call numbers
11. Caller ID* function with 30 name/number call list
12. Microphone and ringer muting function
13. Low battery and out of range indicators
14. Key lock
15. Key tone on/off
16. 14 incoming call ringing melodies
17. Ringing volume control (5 levels)
18. Internal/External call separate ring tone
19. DTMF/Pulse dialing
20. Operation of up to 4 handsets
21. Paging function from base station to handset
22. Up to100 hours standby
23. Up to 10 hours continuous call time.
24. Operation with 2 standard AAA batteries (NiMH)
25. Adjustable flash time
*DECT Digital Enhanced Cordless Telecommunication = Standard for Cordless Telephones.
