Gfive Internet GS62 User Manual

Attention

Warranty

8.

well the warranty card and purchase invoice as proofs for after-sales uses. For non-human damages and bugs,

Keep
service provided in accordance with the following terms:

· 1 year warranty for the scooter excluding batteries and consumables.

· 6-month warranty for batteries; the tyres belong to consumables thus with 1-month warranty.

Attention

the following items are not covered by the warranty:

· problems caused by non-compliance to the <User Manual>.

· damages caused from self-modification and non-comply with the instructions.

· damages caused from improper maintenance by users or unpredictable incidents.

· no warranty card, invoice, or inconformity of the vehicle, warranty card and invoce .

· after using, the damage of the appearance are not covered by the warranty.

· self-demolition of damaged pieces out of the range specified in the instructions.

· damage caused by long in the rain and soak in the water.

1 14

0

Protect Function

During operation, if any system errors or violaton operations occur, the wheel will warn to stop in
different ways, the indicator lights up and beeps, the wheel won't stay in self-balanced mode.

· well drived under a proper speed, if over-speed, the wheel will up-warp to control the speed to
a safe range.

· when standing on the pads, the tilting angle is over 10°.

· over-low battery voltage.

· under charging process.

· the board up-wraps to prevent operation during riding.

· the scooter sways back and forth over 30s.

· the system steps into protection mode, the indicator light is long stay, and high frequency
beeps during riding.

· the scooter will switch off automatically if the board tilts over 35°.

· the scooter will switch off in 2s automatically if the tyres locked-rotor.

· the scooter will switch off in 15s if the battery is lower than the protection level.

· the long-time heavy load discharging (eg. Climbing a long and steep slope in the long time),
the scooter will switch off in 15s.

7. Maintenance

7.1 Storage

Do no store the device in wet condition, charge the battery at least once a month to protect the
battery activity if it is not used for a long time.

7.2 Change tyres

Power off the scooter beore changing tyres, use a screwdriver to take off the bolts, open the
shell, be careful with the connection lines in the shell.

Attention

· After the maintenance, instant ignition might occur when connecting the power terminals, this

is a normal phenomenon, do not be panic.

· Please comply with all the items in the <User Manual>, and if anything beyond control occur,

turn to G'five after-sales service.

13 02

1.Self-balanced Scooter

Self-balanced vehicle is a new high-tech outdoor sport product, which uses aerospace attitude
control theory, fuzzy algorithms and gyroscope system, to achive self-balancing forward and
backward directions. Through tilting the body slightly forward and backward, to achive progress,
acceleration, deceleration, braking balance and other traffic operations, left and right directions
are similar to the bicycle, realizing the balance by twisting the body. Self-balanced vehicle is a
green, environmental and carry-on device, is a good helper for recreation.

· Save Space

With its unique appearance design, it is available to take and move at any time, and save space.

· Save Time

The max speed is 10-15km among models, and it can be continuously running for 10-25 miles
when fully charged.

6. Learn to Drive a Balance Wheel

Pay attention to the relevant safety issues, and fully understand all precautions of <User Manual> mentioned prior before
driving.
Step1: Start the vehicle, press the switch button.
Step2: Get ready for driving, stand onto the pad with one of the feet, the sensor will consequently work, the indicator turns
green, and the system will be in a balance condition, then stand onto the pad with the other foot to operate.
Step3: Keep the balance when standing on, try to move by slightly tilting your body forward and backward.
Step4: Control the left and right direction of the wheel.
Step5: Get off, stop and balance the wheel before getting off, one foot get off first, then the other foot get off quickly.

Attention:

If the wheel is not in horizontality when step onto the pads, the alarm buzzer will beep and the indicator light will turn red,
the system then fail in keeping its balance, then it is not allowed to operate.

03 12
