GEZE Slimdrive SL-RD Additional Installation Instructions

Slimdrive SL-RD

GB Additional installation instructions

150819-03

These additional installation instructions contain supplementary information to the mounting instructions for Slim­drive SL and can only be used in conjunction with these.

Chapter 2.1

2 Overview

2.1 Diagrams

Drawing no. Typ e Name
70484-0-025 Overview diagram Slimdrive SL RD 2-leaf
70484-ep39 Overview diagram Slimdrive SL RD attachment variants
70715-9-9833 p.1 Installation diagram ESG pane in ISO glass leaf, right-hand side
70715-9-9833 p.2 Installation diagram ESG pane in ISO glass leaf, left-hand side
70717-9-9800 Installation diagram Support eld for Slimdrive SL RD left
70717-9-9801 Installation diagram Support eld for Slimdrive SL RD right
70511-9-0968 Wiring diagram DCU1 Slimdrive SL
70484-9-9864 Wiring diagram Supplement Slimdrive SL-RD
70484-9-0955 Cable plan Slimdrive SL Standard
70484-9-9875 Fault table Troubleshooting and fault elimination

Slimdrive SL-RD

The diagrams are subject to change. Use only the most recent version.

2

Slimdrive SL-RD



Chapter 4.2







1 Clamping ledge 70484-2-0211 from accessory pack 70715-1-0196
2 Light barrier prole or xed side screen of the side part

à The recommended tolerance value ± 1.5 mm of the opening width ÖW must be maintained over the whole

area.

à In addition to the standard clamping ledges, a further four clamping ledges (1) are installed in the passage

clearance. Two of these are installed on the outside in the passage clearance and the other two in the centre of
the passage clearance (see sketch above).
They are used to x the support ledges for the upper seal in place. The additional clamping ledges do not
have any setscrews.

3



Slimdrive SL-RD

Chapter 3.10



 





1 Rubber cord
2 Outer roller carriage
3 Cord xture mounted on the left leaf
4 Cord deection
5 Running rail buer
6 Inner roller carriage
7 Cord xture in the running rail
8 Knot
L Length of the relaxed rubber cord













X

Place the rubber cord (1) around the cord deection (4) and t the cord deection in the runner rail.

X

Fit the inner roller carriage (6) in such a way that both ends of the rubber cord run past it.

X

Make sure that the rubber cords do not twist.

X

Fit the outer roller carriage (2) in such a way only the rear rubber cord runs past it.

The front rubber cord hangs out between the two roller carriages of a leaf.

X

Install running rail buer (5).

X

Knot the rubber cord at the cord xture (7) and install the cord xture (7) in the running rail.

X

Make sure enough rubber cord is left protruding.

X

Knot the rubber cord tightly on the cord attachment bracket of the cord xture (7) and trim as close to the
knot as possible.

X

Install leaf.

X

Make sure that the rubber cord which is protruding between the roller carriages hangs down in front of the
leaf.

X

Insert the cord xture (3) in the running rail and screw tightly to the plate provided on the leaf.

X

Pre-tension the rubber cord on the cord attachment and knot it.
The rubber cord has been pre-tensioned correctly when the relaxed protruding part (length L) is in accordance
with the following lengths:

à for light doors (< ca. 60 kg): Opening width ÖW / 2
à for heavy doors: 0.7 × opening width ÖW

X

When mounting the leaves, check again that the cord is routed as illustrated above.

4

Slimdrive SL-RD

Chapter 5.2 (display of 4th menu)

Display of 4th
menu

sC

*) Higher value than with Standard SL

Explanatory notes Possible settings Factory setting

Speed of the closing system

00 … 14* 00

(in cm/s)

5

Chapter 7.2 (electrical faults)

Fault messages

Fault message Meaning

08

Other

X

Attach type plate SL-RD (70484-2-0529) to the system in a clearly visible position.

Smoke alarm

Slimdrive SL-RD

Tür DIN 18095-RS 2
Schiebetüranlage GEZE Slimdrive SL-RD
Hersteller: GEZE GmbH
Prüfzeugnis Nr. P-13-002190-PR01-ift vom 02. April 2019

Herstellungsjahr: ____________

X

After commissioning, enter the year of manufacture (1) by hand.

X

Stick the Ü symbol for SL-RD smoke-proofness onto the outside of the hood from below.

X

Complete and sign factory certicate and hand it over to the client.

6
