1-House Audio Door Entry System CAS 88306 (2-Wire Installation)
In this Set (Fig. 1)
1. Power Adapter
2. Handset
3. Outdoor Panel
4. Rain Cover
Components/ operating controls
Handset (Fig. 2a)
1. Loudspeaker
2. Microphone
3. Ring tone volume adjustment
4. Intercom button
5. Strike control (Door/Gate opener)
6. Terminal block
Outdoor panel (Fig. 2b)
1. Loudspeaker
2. Name plate/bell
3. Screws
4. Microphone
5. Cable duct channel
6. Holes for attaching the unit to the wall
7. Terminal block
8. Switch for setting the sound level for
the speaker of the outdoor panel
9. Switch for setting the sound level for
the speaker of the handset
Introdcution
This audio door phone system consist of a
handset and an outdoor unit. With these you
can establish an audio connection between
the caller and yourself. Furthermore you
have the option to add a door/gate strike
(not included) into the system.
This audio door phone set uses a BUS-type
protocol; i. e. just two wires are needed for
all functions (ringing, speaking, listening,
controlling the door/ gate strike)
Safety instructions
All warranty claims will be null and void in
the event of any damage or loss caused by
failure to observe these operating instructions. We accept no liability for any consequential losses or damage. We accept
no liability for any personal injury or mate-
rial damage caused by improper use or
by failure to observe
these cases the guarantee
invalidated. For safety and authorization
purposes it is not permitted to carry out any
adaptation or conversion of the device.
1. Do not disassemble the unit.
2. Do not spray water on the indoor unit.
Do not keep the outdoor unit where it
will be exposed to extreme moisture.
3. Do not drop or shock the unit.
4. Remove the power cord from the wall
socket when unit is not used for long
periods.
5. This apparatus is designed for moderate
climates. Do not use in high humidity,
dusty or dirty areas.
Installing
Attention: if you like to test the units before
final installation then don’t do this with both
units inside The same room-this could lead
to a Larsen-eect (an annoying acoustic
feedback of the indoor panel).
Installation of the outdoor panel (Fig. 3)
The outdoor panel is determined for wallmounting.
Remove the front panel of the outdoor unit
by loosening the two screws on the bottom (Fig. 3/1). Run the cables coming from
the indoor unit (handset) through the cable
opening (Fig. 3/2). Likewise, if required, the
cables coming from the electric door/gate
opener, too. Screw the rain cover housing
with two
(Fig. 3/3).
according to the wiring diagram (depending
on the number of indoor units see Figure 5
or 6) to the appropriate terminals (Fig. 3/4).
Before closing the front plate again, you can
do still volume settings on the fixed back
plate (Fig. 2b/8 and 9). Use a small, suitable screwdriver and turn the screw without
much force (Fig 2b/8 volume control of the
outdoor
indoor unit).
8
screws at the location you provided.
Now you can connect the wires
unit. Fig 2b/9 volume control of the
the safety advice. In
and warranty are
Tip: Seal the joints between the outdoor unit
and the wall from three sides with silicone.
Let the joint on the bottom open to decrease
the likelihood of condensation.
Mounting the indoor unit (Fig. 4a and 4b)
First, open the indoor unit for this purpose,
go with a suitable screw driver on the right
bottom in the recess and pry through slight
leverage the top of the lower shell. Mount
the lower shell with four screws at the designated place on the wall. Now connect the
wires as shown in figure 5. or 6-depending
on your desired level of expansion.
Installation of the handset/
installation of outdoor panel/
caption of the badge
Connecting the handset.
See figures 5 or 6-depending on your desired
level of expansion. To avoid problems highand low-voltage cables should never be in
the same cable conduit. Connect the cables
as shown in the figures described.
Connecting the handset to the outdoor
panel: Connect the power supply with the
inside socket. Connect „L +“ and „L -“ of the
handset with the terminals „L +“ and „L -“ of
the outdoor panel.
It is essential that you use a door opener
which has a memory function. Regarding
the connection instructions see connection
diagram 5 or 6. As a suitable electric door
opener, we
007680 (110mm)
recommend such as item no.
or 007697 (250mm) from
our GEV product range.
For connecting an electric gate opener connect
the terminals „GATE“ „GATE“ of the
outdoor panel and the two corresponding
terminals (varies- depending on the manufacturer. Consult the manual of your gate
drive engine) to your gate engine (terminals „GATE“ „GATE“ are dry contacts).
In case you have connected an external gate
drive, enable this by a three-second push on
the
button on the phone.
Important: The functions can be
executed only at the active unit and
after lifting the handset.
Abb./Fig. 7
Connecting an electric door/or gate strike.
You can optionally include an electric door
and/or gate opener in this system. For the
connection diagram see Figure 5 or 6.
Alternatively, the system can be powered via
a cap rail transformator (order no. 8830602)
Caption of the name plate: Remove the
cover of the bell in which you lever it by
using a thin tool and carefully push it inside
the notches (Fig. 7/A).
Set Up/Operation
Pressing on the push button of the outdoor
panel, raises a signal on the handset (max. 6
times within 30 sec.). You can now pick up
the phone and speak with the guest for a
maximum of approx. 90 sec. To operate the
electric door opener, briefly press (1 sec.)
button on the indoor unit. Important:
the
A
Additional information
You have the option to connect up to three
additional interior handsets in parallel (fig. 6/
order no. 8830601). When connecting multiple
handsets, it is sucient if you are using a
single
power supply for all stations. However,
this power supply has to be the one which is
9
the closest to the outdoor panel. In order to
communicate internally, press the button.
This will trigger a collective call and establish
a connection to the remote handset which is
being picked up first (for approx. 30 sec.).
As long as there’s an internal connection, the
voice contact to the outdoor panel is locked.
Receycling instructions
This device may not be disposed
of with unsorted household waste.
Owners of old devices are required by
law to dispose this device correctly.
Contact your twon council for further information.
The intercom function is interrupted in case
there is an external call coming in.
Technical and design features may be subject to change without notice.
Specifications
Handset (8830601) Specifications
Dimensions 70[W] x 230[H] x 40 [D]mm
Power Supply DC18V / 1,5A
Power Consumption Max. 2W
Connection System 2-wires
Sounds 1
Max. Distance/ wire to be used Min. diameter of cable between last
handset and outdoor panel
up to 25m: ø 0,6mm-1,0mm
up to 100m: ø 1,0mm-1.5mm
IP 20
Mains adapter Specifications
Power Supply 230 V~, DC 18V, 1,5A
Outdoor panel (8830603) Specifcations
Dimensions 95[W] x120[H] x 30 [D]mm
Current DC12V (via indoor unit / handset)
Installation type Outdoor- / Indoor unit : 2-wires
Door strike Current 12V DC / max. 1.0A
Gate motor Dry contact / closing time ca. 3 sec.
Type of installation Wall mount
Protection type IP 54
Operating temperature -10˚C ~ 45˚C
10
11
