GETT TKG-104-MB-IP68-VESA-GREY, TKG-104-MB-IP68-VESA-BLACK User Manual

TKG-104-MB-IP68-VESA-GREY

TKG-104-MB-IP68-VESA-BLACK

FEATURES

• Integrated mousebutton

• VESA-M5-boreholes (distance 75 x 75 mm)

• IP68 sealing, can be submerged into liquids

• Can be cleaned and desinfected thoroughly

INDUPROOF SILICONE KEYBOARDS

• Special coating for excellent mechanical and chemical resistance

• Robust, durable silicone material

TECHNICAL DATA

Number of keys: 104 Housing type: dekstop housing Material (keypad): silicone Material (bottom panel): plastic Colour: grey, black Keyswitch technology: carbon contacts Switching cycles: 2 mill. (per key) Operating force: 1.5 N / 1.1 N (Num) Switch travel: 1.4 mm Protection level: IP68 Interface: USB USB compatibility: USB V1.1/2.0 compliance Operating temperature: -20 °C to +60 °C Storage temperature: -25 °C to +70 °C Dimensions: 340 x 165 x 18.4 mm Weight: 735 g

Certication:  CE,FCC

Warranty: 4 years on the electrical function

TECHNICAL DATA MOUSEBUTTON

Operating princwiple: Hall-sensor Resolution: 800 cpi

TECHNICAL DATA VESA INSERT NUTS

Thread: M5 Material: 1.5 mm steel Recommended screw tightening torque: 3.60 Nm Resistance to distortion: 8.47 Nm Axial force: 3110 N

Cat.No. Product description Colour Layout

KG17203 TKG-104-MB-IP68-VESA-GREY-USB-DE Grey German KG17204 TKG-104-MB-IP68-VESA-GREY-USB-US Grey US KG19259 TKG-104-MB-IP68-VESA-BLACK-USB-DE Black German KG21212 TKG-104-MB-IP68-VESA-BLACK-USB-US Black US

Otherlanguageversions/interfaces/congurationsavaibleonrequest.

GETT Gerätetechnik GmbH

Mittlerer Ring 1 | 08233 Treuen | Germany Tel: +49 37468 660-0 Fax: +49 37468 660-66

E-Mail: info@gett.de

Rev.0-06 2019

Internet: www.gett.de

Gett North America LLC

E-Mail: info@gett-na.com Internet: www.gett-na.com

Gett Asia Ltd.

E-Mail: info@gett-asia.com Internet: www.gett-asia.com

Subject to modications and errors

gett.de

gett-group.com

TECHNICAL DRAWING (in mm)
