F110
USER MANUAL
Rugged Mobile Computing Solution
Oct. 2013
TRADEMARKS
All brand and product names are trademarks or registered trademarks of their
respective companies.
NOTE
The information in this manual is subject to change without notice.
For the latest version of the manual, please visit the Getac website at www.getac.com.
Table of Contents
Chapter 1 Getting Started ..................................................................... 1-1
Getting the Tablet PC Running ...................................... 1-2
Unpacking .............................................................. 1-2
Installing the SIM Card (Optional) and Battery Packs .... 1-3
Connecting to AC Power ........................................... 1-5
Using the Tether ..................................................... 1-6
Turning On and Off the Tablet PC ............................. 1-7
Taking a Look at the Tablet PC .................................... 1-9
Front Components .................................................... 1-9
Rear Components ................................................... 1-12
Left-Side Components .............................................. 1-13
Top Components..................................................... 1-14
Bottom Components ................................................. 1-15
Chapter 2 Operating Your Tablet PC ...................................................... 2-1
Navigating on the Screen .............................................. 2-2
Using the Touchscreen .............................................. 2-2
Using the Dual Mode Display (Optional) ..................... 2-5
Using the Network Features ........................................... 2-6
Using the LAN (Optional) ........................................ 2-6
Using the Wireless LAN ............................................ 2-6
Using the BT Feature .................................................. 2-8
Turning On/Off the BT Radio .................................... 2-8
Connecting to another BT Device ................................ 2-9
Using the WWAN Feature (Optional) ........................... 2-10
i
Turning On/Off the WWAN Radio ............................. 2-10
Setting up a WWAN Connection ................................ 2-11
Chapter 3 Managing Power ................................................................... 3-1
AC Adapter ................................................................ 3-2
Battery Pack .............................................................. 3-3
Charging the Battery Pack ......................................... 3-3
Initializing the Battery Pack ........................................ 3-4
Checking the Battery Level ........................................ 3-4
Battery Low Signals and Actions ................................. 3-5
Replacing the Battery Pack ........................................ 3-6
Power-Saving Tips ...................................................... 3-8
Chapter 4 Expanding Your Tablet PC ..................................................... 4-1
Connecting a USB Device ............................................. 4-2
Connecting an Audio Device .......................................... 4-3
Connecting an HDMI Display Monitor ............................... 4-4
Connecting a Serial Device (Optional) ............................ 4-5
Using Smart Cards (Optional) ...................................... 4-6
Using MicroSD Cards (Optional) ................................... 4-8
Chapter 5 Using BIOS Setup .................................................................. 5-1
When and How to Use ................................................ 5-2
Menu Descriptions ....................................................... 5-3
Information Menu ..................................................... 5-3
Main Menu ............................................................. 5-3
Advanced Menu ....................................................... 5-4
Security Menu ......................................................... 5-5
Boot Menu ............................................................. 5-6
Exit Menu .............................................................. 5-6
Chapter 6 Using Getac Software ............................................................ 6-1
OSD Control Panel ...................................................... 6-2
G-Manager ................................................................ 6-3
Getac Camera (Optional) ............................................ 6-5
Getac Smart Tag (Optional) ......................................... 6-6
Using the Barcode Reader (Optional) ............................. 6-7
ii
Chapter 7 Caring for the Tablet PC ....................................................... 7-1
Protecting the Tablet PC .............................................. 7-2
Using an Anti-Virus Strategy ...................................... 7-2
Using the Cable Lock ............................................... 7-2
Taking Care of the Tablet PC ....................................... 7-3
Location Guidelines ................................................... 7-3
General Guidelines ................................................... 7-4
Cleaning Guidelines .................................................. 7-4
Battery Pack Guidelines ............................................. 7-5
Touchscreen Guidelines ............................................. 7-6
When Traveling ........................................................... 7-8
Chapter 8 Troubleshooting ................................................................... 8-1
Preliminary Checklist ..................................................... 8-2
Solving Common Problems ............................................ 8-3
Battery Problems ..................................................... 8-3
BT Wireless Transmission Problems ............................. 8-3
Display Problems ..................................................... 8-4
Hardware Device Problems ......................................... 8-4
Power Management Problems ..................................... 8-5
Sensor Problems (for Windows 8 Models Only)............ 8-6
Software Problems ................................................... 8-7
Sound Problems ...................................................... 8-7
Startup Problems ..................................................... 8-7
Wireless LAN Problems ............................................. 8-8
Other Problems ....................................................... 8-9
Resetting the Tablet PC ............................................. 8-10
System Recovery ........................................................ 8-11
System Restore, Refresh, or Reset (for Windows 8
Models) ............................................................... 8-11
System Recovery (a Tool for Windows 7 Models) ...... 8-12
Appendix A Specifications ....................................................................... A-1
Appendix B Regulatory Information ......................................................... B-1
On the Use of the System .......................................... B-2
iii
Class B Regulations ................................................ B-2
ANSI Warning ........................................................ B-3
Safety Notices ........................................................ B-4
On the Use of the RF Device ..................................... B-7
USA and Canada Safety Requirements and Notices ....... B-7
European Union CE Marking and Compliance Notices ..... B-9
iv
Chapter 1
Getting Started
Congratulations on purchasing this rugged Tablet PC.
This chapter first tells you step by step how to get the Tablet PC up and running.
Then, you will find a section briefly introducing the external components of the Tablet
PC.
Getting Started 1-1
Getting the Tablet PC Running
Unpacking
After unpacking the shipping carton, you should find these standard items:
Tablet PC
Accessories:
AC adapter
AC power cord
Stylus or digitizer pen
Tether
AG/AR (anti-glare/anti-reflection) film, which is already attached to
the screen
Screen cleaning cloth
Driver disc
Document(s)
Inspect all the items. If any item is damaged or missing, notify your dealer
immediately.
1-2
Getting Started
tPac
Lpb
S
Wth
E
h
a
v
h
C
d
c
p
w
s
t
a
k
t
h
n
t
r
k
t
Ins
1.
ocate the b
osition (
attery cover.
alling t
ks
e SIM
ttery cover.
) an
) (
ard (O
Slide the t
then relea
tional)
o small loc
e the latch
nd Batt
s outward
( ) (
ery
o the unloc
) to open
ed
he
2.
elect models
NOT
and
ith the SIM
e slot, inse
: To remo
remove t
only:
card’s chip
rt the card
e the SIM
e card.
side facing
all the way
ard, jus
up and the
into the slo
push in t
beveled co
.
he SIM car
Getti
ner pointing
d to pop-o
g Started
to
t
1-3
NinTb
P
H
(
(
t
n
c
e
e
a
e
k
P
o
b
y
e
s
o
a
r
n
m
a
e
t
t
o
3.
ote the orie
hen, lift the
attery conne
sert its sma
tation of the
ll tabs to th
yellow prote
tor.
battery pac
correspond
ction sheet i
. Hold the
ing notches
n the batter
attery pack
in the batte
compartme
Battery 1
Battery 2
t an angle
y compartm
t and plug
nd
nt.
he
4.
5.
1-4
roceed with
old the batt
c
orresponding
s
mall dots (
) ()
).
Getting S
the other b
ry cover at
notches on
) so that
and slide th
arted
ttery pack.
an angle a
the Tablet
the cover cl
two small l
nd insert th
C; then clo
icks into pla
cks inward t
cover’s s
e the cover.
ce. Engage
o the locked
all tabs to
Press the f
the cover la
position (
he
ur
ch
)
n
P
(
P
e
P
g
h
a
e
n
P
A
h
t
r
o
w
r
c
g
e
t
n
b
f
d
P
t
Co
It is
very
nectin
suggested t
first time.
to AC P
at you use
ower
AC power
hen startin
up the Ta
let PC for
he
1.
2.
3.
y
lug the DC
).
lug the fem
nd to an el
ower is bei
our Tablet
cord of the
le end of t
ctrical outle
g supplied f
C. Now, y
C adapter t
e AC powe
().
om the ele
u are ready
o the power
cord to th
trical outlet
to turn on
connector o
AC adapte
o the AC a
the Tablet
Getti
the Tablet
r and the m
apter and o
C.
g Started
PC
ale
to
1-5
CAUTION: Use only the AC adapter included with your Tablet PC.
Using other AC adapters may damage the Tablet PC.
NOTE: When the AC adapter is connected, it also charges the
battery pack. For information on using battery power, see
Chapter 3.
Using the Tether
A tether is provided for attaching the stylus to your Tablet PC.
1. Insert one of the tether’s loop ends through the hole of the stylus (as indicated
by below). Then, insert the other end through the first loop (as indicated
by below) and pull it tight.
2. Insert the other loop end to the tether hole on the Tablet PC (as indicated
by
below). Then, insert the stylus end through the loop (as indicated by
below) and pull it tight.
1-6
Getting Started
Turning On and Off the Tablet PC
Turning On
Press the power button ( ). The Windows operating system should start.
Turning Off
When you finish a working session, you can stop the system by turning off the
power or leaving it in Sleep or Hibernation mode:
To...
Power off
(Shutdown)
Windows 8 Windows 7
1. Open the Charms Bar of Windows
8 by swiping in from the right side
of the screen.
2. Tap Settings and then tap
(Power).
3. Tap Shut down in the Power menu
Do this...
Use the Windows Start menu
in the lower left and follow the
shutdown procedure.
Getting Started 1-7
To...
Do this...
Windows 8 Windows 7
that pops up.
Sleep Press the power button* or use the
Power menu to put the Tablet PC
in Sleep mode.
Press the power button* or
use the Windows Start menu
to put the Tablet PC in Sleep
mode.
Hibernate By default, this option is not shown
in the Power menu. If you want to
use the feature, set up according in
Use the Windows Start menu
to put the Tablet PC in
Hibernation mode.
Windows Control Panel.
* “Sleep” is the default setting of the power button. You may change what the
power button does in Windows Control Panel.
1-8
Getting Started
Taking a Look at the Tablet PC
NOTE: Depending on the model you purchased, the appearance of
your Tablet PC may not be exactly the same as those shown in
this manual.
CAUTION: You need to open the protective covers to access the
connectors. When not using a connector, make sure to close the
cover completely for water- and dust-proof integrity. (Engage
the locking mechanism if existing.)
Front Components
Ref Component Description See Also
Touchscreen
Camera Lens
(optional)
Light Sensor
Displays and receives information for the Tablet
PC.
Allows you to use the camera function. When the
camera lens is in use, the indicator beside it lights
up.
Senses the ambient light for automatic adjustments
Getting Started 1-9
P. 2-2
P. 6-5
A
Ref Component Description See Also
of the display backlight.
Indicators
Power
Lights blue when the power is on.
Blinks blue when the system is in Sleep mode.
Charge
Frequency)
Power Button
Extra Button
Battery
RF (Radio
Lights green when the battery is fully charged. P. 3-3
Lights amber when the battery is being charged.
Blinks red (once per second) when the battery’s
capacity is below 10%.
Blinks red rapidly (once per 0.5 second) when
there is a thermal protection problem.
service in case this happens.
Blinks amber when the battery charging is in an
abnormal state. Replace the battery in case this
happens.
Lights blue when the RF radio of any RF feature
(WLAN/BT/WWAN) is on.
Turns the power on or off. (The default “off” state
is “Sleep mode.”)
Starts the Getac Camera program and serves as
the shutter release button.
– or –
Serves as the trigger button for the barcode reader
if your model has the barcode reader module.
sk for repair
P. 3-5
P. 1-7
P. 6-5
– or –
P. 6-7
1-10
When Function Lock is on:
Enables or disables the touchscreen feature.
Provides a keyboard key function for specific
occasions.
Getting Started
P. A-2
Ref Component Description See Also
P1 Button
Up/Down Button
Microphone
Windows Logo
Button
Switches on or off Function Lock (FL), which
changes the Extra, Up, and Down buttons to an
alternative function. When FL is on, the icon
appears on Windows taskbar.
When pressed longer:
Serves as the Ctrl+Alt+Del keyboard keys.
Provides a keyboard key function for specific
occasions.
increases the sound volume.
decreases the sound volume.
When Function Lock is on:
increases the LCD brightness.
decreases the LCD brightness.
Provides a keyboard key function for specific
occasions.
Receives sound and voice to record voice.
For Windows 8:
Goes to the Start screen. Or if you're already on
Start, pressing this button brings you to the last
application you were in.
P. 8-10
P. A-2
P. A-2
For Windows 7:
Opens or closes the OSD Control Panel.
Provides a keyboard key function for specific
occasions.
Getting Started 1-11
P. 6-2
P. A-2
Rear Components
Ref Component Description See Also
Tether Hole
Stylus/
Digitizer pen
Battery Pack Cover
Camera Indicator
(optional)
Flash (optional) Provides extra light when taking pictures.
Camera Lens
(optional)
Speaker
1-12
Getting Started
Stylus can be tethered to this hole. P. 1-6
Serves as the input device by tapping on the
touchscreen to make selections and enter
information.
Inside are two battery packs. P. 3-3
Inside is the SIM card slot (optional). P. 1-3
Lights up when the camera lens beside it is
in use.
Allows you to use the camera function. P. 6-5
Sends out sound and voice from your Tablet
P. 2-2
PC.
Ref Component Description See Also
Select models have one of the below components.
Smart Card Reader
RFID Reader
Accepts a smart card for additional security
feature.
Scans and reads RFID (Radio-frequency
identification) tags.
P. 4-6
P. 6-6
Left-Side Components
Ref Component Description See Also
Combo Audio
Connector
HDMI Connector
Connects a set of headphones or external
speakers with amplifier
Supports a headset microphone with 4-pole
TRRS 3.5mm jack.
Connects a HDMI (High-Definition Multimedia Interface) monitor or TV set.
P. 4-3
P. 4-4
USB 3.0 Port
Connects a USB device, such as a USB flash
disk, printer, digital camera, joystick, and more.
Getting Started 1-13
P. 4-2
Top Components
Ref Component Description See Also
None
Or can be one of the below components depending on your model:
Serial Port
MicroSD Card Slot
(inside the cover)
RJ-45 Connector
(inside the cover)
USB 2.0 Port (inside
the cover)
Barcode Reader
Lens
1-14
Getting Started
Connects a serial device. P. 4-5
Accepts a microSD card for removable storage
media.
Connects the LAN cable. P. 2-6
Connects a USB device, such as a USB flash
disk, printer, digital camera, joystick, and more.
Scans and reads barcodes. P. 6-7
P. 4-8
P. 4-2
Bottom Components
Ref Component Description See Also
Power Connector
Antenna Pass-
through (optional)
Docking Connector
Kensington Lock
Connects the AC adapter. P. 1-5
Connects to the docking station for using
external WWAN/GPS/WLAN antenna.
Connects to the docking station (available as
an option).
Locks the Tablet PC to a stationary object for
security.
P. 7-2
Getting Started 1-15
Chapter 2
Operating Your Tablet PC
This chapter provides information about the use of the Tablet PC.
If you are new to Tablet PCs, reading this chapter will help you learn the operating
basics. If you are already a computer user, you may choose to read only the parts
containing information unique to your Tablet PC.
CAUTION:
Do not expose your skin to the Tablet PC when operating it
in a very hot or cold environment.
The Tablet PC can get uncomfortably warm when you use it in
high temperatures. As a safety precaution in such a
circumstance, do not place the Tablet PC on your lap or touch
it with your bare hands for extended periods of time.
Prolonged body contact can cause discomfort and potentially
a burn.
Operating Your Tablet PC 2-1
Navigating on the Screen
The screen of your Tablet PC is touch-sensitive. You can control the location of
the cursor/pointer on the screen using the included stylus or your finger to
communicate with the Tablet PC.
CAUTION: Do not use a sharp object such as a ballpoint pen or
pencil on the touchscreen. Doing so may damage the touchscreen
surface. Use the included stylus or your finger.
NOTE: An AG/AR film has been attached to the screen before
shipment. The film is a consumable, which will be worn out by
possible scratches. You can purchase a new one when replacement
is required.
Using the Touchscreen
NOTE: Instead of a hard tip, your stylus has a soft tip so that
it does not scratch the AG/AR film. It is normal for the soft
tip to wear out after a long period of use. You can purchase
a new one when needed.
The following table shows how you use the touchscreen to obtain equivalent mouse
functions.
2-2
Operating Your Tablet PC
Term/Action
Tap: Touch the screen once. Click/Point
Double-tap: Touch the screen twice rapidly. Double-click
Tap and hold: Tap and hold until a popup menu appears. Right-click
Drag: Hold the stylus (or finger) on the screen and drag across
the screen until reaching your destination.
Equivalent Mouse
Function
Drag
Using Multi-touch Gestures
You can interact with your Tablet PC by placing two fingers on the screen. The
movement of the fingers across the screen creates “gestures,” which send commands
to the Tablet PC.
Here are the multi-touch gestures that you can use:
Gestures
Pan
(Scroll)
( = finger down; = finger up)
Actions
Descriptions
Use panning to see
another part of a page that
has scroll bars.
Zoom
(Pinch)
or
Drag 1 or 2 fingers up or down.
Move two fingers apart/toward each
other.
Use zooming to make an
item (a photo for
example) on the screen
larger or smaller. The
gesture works in
applications that support
mouse wheel zooming.
Operating Your Tablet PC 2-3
Gestures
Rotate
Press and
Tap
Twofinger Tap
Actions
( = finger down; = finger up)
or
Move two fingers in opposing directions.
-orUse one finger to pivot around another.
Press on target and tap using a second
finger.
Descriptions
Use rotating to move a
picture or other item on
the screen in a circular
direction (clockwise or
counterclockwise). The gesture
works in applications that
support the specific
gesture.
Use press and tap to
access the shortcut
menu.
The function is defined by
applications that support
the specific gesture.
2-4
Tap two fingers at the same time (where
the target is in the midpoint between the
fingers).
Operating Your Tablet PC
Gestures
Flicks
( = finger down; = finger up)
Make quick drag gestures in the desired
direction.
Actions
Descriptions
Flick left or right to
navigate back and forward
in a browser and other
applications. The gesture
works in most applications
that support back and
forward.
Using the Dual Mode Display (Optional)
Dual mode display (if your model has the feature) incorporates both touchscreen
and digitizer functions.
The display is set to Touchscreen mode by default. Touchscreen mode provides
all the functionalities that an ordinary touchscreen has. When the Tablet PC receives
signals from the digitizer pen, the display automatically switches to Digitizer mode.
You can move the cursor by bringing the digitizer pen close to the screen, without
actually touching the screen’s surface.
Operating Your Tablet PC 2-5
Using the Network Features
Using the LAN (Optional)
To connect the network cable to the LAN module (if your model has the feature),
connect one end of the LAN cable to the RJ-45 connector on the Tablet PC and
the other end to the network hub.
Using the Wireless LAN
The WLAN module of your Tablet PC supports IEEE 802.11a/b/g/n/ac.
Turning On/Off the WLAN Radio
To turn on the WLAN radio:
1. Make sure that the Airplane mode is switched off. You can control the Airplane
mode using one of the below methods.
Use the Airplane Mode button in the OSD Control Panel.
For Windows 8: Open the Charms Bar, tap Settings Change PC Settings
Wireless. Slide the Airplane mode switch to the Off position.
2. If you have previously turned off the WLAN radio, use one of the below methods
to turn it on.
For Windows 8: Open the Charms Bar of Windows. Tap Settings Change
PC Settings Wireless. Slide the Wi-Fi switch to the On position.
2-6
Operating Your Tablet PC
Loading...
