Getac Technology 046, 047 User Manual

Download

V200

USER’S MANUAL

Rugged Mobile Computing Solutions

Aug. 2012

TRADEMARKS

TRADEMARKSTRADEMARKS

The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. All brand and product names are trademarks or registered trademarks of their respective companies.

NOTE

NOTENOTE

The information in this manual is subject to change without notice. Most screens and operating instructions in this manual are based on Windows 7. If you’re using a different version of Windows, the screens and related operations

may not be the same. For the latest version of the manual, please visit the Getac website at www.getac.com.

ENERGY STAR® is a government program that offers businesses and consumers energy-efficient solutions, making it easy to save money while protecting the environment for future generations.

Please reference ENERGY STAR® related information from www.energystar.gov.

As an ENERGY STAR® Partner, Getac Technology Corporation has determined that this product meets the ENERGY STAR® guidelines for energy efficiency.

An ENERGY STAR® qualified computer uses 70 % less electricity than computers without enabled power management features.

Earning the

Earning the E

Earning the Earning the

 When every home office is powered by equipment that has earned the ENERGY

STAR®, the change will keep over 289 billion pounds of greenhouse gases out of the air.

 If left inactive, ENERGY STAR

and may use 15 watts or less. New chip technologies make power management features more reliable, dependable, and user-friendly than even just a few years ago.

 Spending a large portion of time in low-power mode not only saves energy,

but helps equipment run cooler and last longer.

ENERGY

NERGY S

NERGY NERGY

STAR

TAR

TARTAR

®®®®

qualified computers enter a low-power mode

 Businesses that use ENERGY STAR

enabled office equipment may realize

additional savings on air conditioning and maintenance.

 Over its lifetime, ENERGY STAR

qualified equipment in a single home office (e.g., computer, monitor, printer, and fax) can save enough electricity to light an entire home for more than 4 years.

 Power management (“sleep settings”) on computers and monitors can result

in much savings annually.

Remember, saving energy prevents pollution

Remember, saving energy prevents pollutionRemember, saving energy prevents pollution

Because most computer equipment is left on 24 hours a day, power management features are important for saving energy and are an easy way to reduce air pollution. By using less energy, these products help lower consumers’ utility bills, and prevent greenhouse gas emissions.

Table of Contents

Table of ContentsTable of Contents

Chapter 1

Chapter 1 GGGGetting Started

Chapter 1Chapter 1

etting Started ................................

etting Startedetting Started

Getting the Computer Running ......................................... 1-2

Unpacking ................................................................ 1-2

Connecting to AC Power ............................................ 1-3

Opening and Closing the Cover ................................... 1-4

Operating in Tablet Mode ........................................... 1-5

Turning On and Off the Computer ............................... 1-7

Taking a Look at the Computer ...................................... 1-8

Front Components ..................................................... 1-8

Rear Components ..................................................... 1-10

Right-Side Components ............................................. 1-11

Left-Side Components ............................................... 1-12

Top-open Components .............................................. 1-13

Bottom Components .................................................. 1-15

Using the Accessories .................................................. 1-17

Using the Tether ..................................................... 1-17

Attaching the Handgrip Strap ...................................... 1-18

Attaching the Shoulder Strap ...................................... 1-18

..............................................

................................................................

.............. 1111----1111

............................

Chapter

Chapter 2222 OOOOperating Your Computer

Chapter Chapter

perating Your Computer .............................

perating Your Computerperating Your Computer

Using the Internal Keyboard ............................................2-2

Typewriter Keys ........................................................2-2

Cursor-Control Keys ..................................................2-2

............................. 2222----1111

..........................................................

Numeric Keypad .......................................................2-3

Function Keys ..........................................................2-4

Fn Key ...................................................................2-4

Hot Keys ................................................................2-4

Using the Touchpad ......................................................2-7

Configuring the Touchpad ............................................2-9

Navigating on the Screen ............................................. 2-10

Using the Touchscreen ............................................. 2-10

Using Multi-touch Gestures ........................................ 2-11

Using the Dual Mode Display (Optional) .................... 2-13

Using Landscape or Portrait View ............................... 2-15

Using the Input Panel ................................................. 2-17

Using the Network Features ........................................... 2-18

Using the Modem ................................................... 2-18

Using the LAN ....................................................... 2-19

Using the Wireless LAN ........................................... 2-19

Using the Bluetooth Feature ......................................... 2-21

Turning Off/On the Bluetooth Radio ........................... 2-21

Connecting to another Bluetooth Device ....................... 2-21

Using the WWAN Feature (Optional) ............................ 2-23

Installing a SIM Card .............................................. 2-23

Turning Off/On the WWAN Radio .............................. 2-24

Connecting to WWAN Network ................................... 2-25

Using the Fingerprint Scanner (Optional)........................ 2-27

Chapter

Chapter 3333 MMMManaging

Chapter Chapter

anaging Power

anaging anaging

AC Adapter .................................................................3-2

Battery Pack ................................................................3-3

Charging the Battery Pack ..........................................3-3

Initializing the Battery Pack .........................................3-4

Power ................................

PowerPower

.............................................

................................................................

............. 3333----1111

..........................

Checking the Battery Level .........................................3-4

Replacing the Battery Pack .........................................3-5

Battery Low Signals and Actions ..................................3-6

Power Management .......................................................3-8

Hibernation ...............................................................3-9

Power-Saving Tips ..................................................... 3-10

Chapter

Chapter 4444 EEEExpanding Your Computer

Chapter Chapter

Chapter

Chapter 5555 UUUUsing BIOS Setup and System Recovery

Chapter Chapter

xpanding Your Computer ............................

xpanding Your Computerxpanding Your Computer

Connecting an External Monitor .......................................4-2

Connecting a Serial Device.............................................4-3

Connecting a USB Device ..............................................4-4

Connecting an IEEE 1394 Device ....................................4-5

Connecting Audio Devices ..............................................4-6

Using ExpressCards ......................................................4-7

Using PC Cards...........................................................4-9

Using Smart Cards (Optional) ...................................... 4-11

Using Storage Cards ................................................... 4-12

System Memory Upgrade.............................................. 4-13

sing BIOS Setup and System Recovery ......

sing BIOS Setup and System Recoverysing BIOS Setup and System Recovery

BIOS Setup .................................................................5-2

When and How to Use .............................................5-2

Information Menu ......................................................5-3

Main Menu ..............................................................5-4

Advanced Menu ........................................................5-5

Security Menu ........................................................ 5-12

Boot Menu ............................................................ 5-14

Exit Menu ............................................................. 5-15

System Recovery ........................................................ 5-17

............................ 4444----1111

........................................................

...... 5555----1111

............

iii

Chapter

Chapter 6666 UUUUsing Getac Software

Chapter Chapter

sing Getac Software ................................

sing Getac Softwaresing Getac Software

Using the OSD Control Panel .........................................6-2

Quick Button Setup ...................................................6-6

Using Button Manager ...................................................6-8

Using G-Manager ....................................................... 6-10

Starting G-Manager ................................................. 6-10

System Tab ............................................................ 6-11

Battery Tab ........................................................... 6-12

ECO Tab .............................................................. 6-14

Light Sensor Tab .................................................... 6-16

Ignition Tab ........................................................... 6-18

Monitoring Tab ....................................................... 6-19

GPS Status Tab ..................................................... 6-20

Using Getac Camera ................................................... 6-22

Taking Pictures ....................................................... 6-24

Shooting Videos ...................................................... 6-26

Using View Mode ................................................... 6-27

Camera Settings ..................................................... 6-31

....................................

................................................................

.... 6666----1111

........

Chapter

Chapter 7777 CCCCaring for the Computer

Chapter Chapter

aring for the Computer ...............................

aring for the Computeraring for the Computer

Protecting the Computer .................................................7-2

Using an Anti-Virus Strategy .......................................7-2

Using Action Center (for Windows 7) .........................7-2

Using the Cable Lock ................................................7-3

Taking Care of the Computer .........................................7-4

Location Guidelines ....................................................7-4

General Guidelines ....................................................7-5

Cleaning Guidelines ...................................................7-5

Battery Pack Guidelines ..............................................7-6

Touchscreen Guidelines...............................................7-7

............................... 7777----1111

..............................................................

When Traveling ............................................................7-9

Chapter

Chapter 8888 ................................

Chapter Chapter

8888----1111

.................................................

................................................................

Preliminary Checklist ......................................................8-2

Solving Common Problems .............................................8-3

Battery Problems .......................................................8-3

Bluetooth Problems ....................................................8-3

Display Problems ......................................................8-4

Hardware Device Problems ..........................................8-5

Hard Disk Drive Problems ..........................................8-5

Keyboard, Mouse, and Touchpad Problems ....................8-6

LAN Problems ..........................................................8-6

Modem Problems ......................................................8-7

Power Management Problems ......................................8-7

Software Problems .....................................................8-8

Sound Problems .......................................................8-8

Startup Problems .......................................................8-9

WLAN Problems .......................................................8-9

Other Problems ....................................................... 8-11

Resetting the Computer ................................................ 8-12

................. TTTTroubleshooting

..................................

roubleshooting

roubleshootingroubleshooting

Appendix A S

Appendix A Specifications

Appendix A SAppendix A S

Appendix

Appendix B R

Appendix Appendix

pecifications ................................

pecificationspecifications

B Regulatory Information

egulatory Information ............................

B RB R

egulatory Informationegulatory Information

On the Use of the System ........................................... B-2

Class B Regulations ................................................. B-2

UL1604 Installation Instructions .................................... B-3

Safety Notices ......................................................... B-4

On the Use of the RF Device ...................................... B-7

USA and Canada Safety Requirements and Notices ........ B-7

European Union CE Marking and Compliance Notices ..... B-10

............................................

................................................................

............................ BBBB----1111

........................................................

............ AAAA----1111

........................

Chapter 1

Chapter 1Chapter 1

Getting Started

Getting StartedGetting Started

Congratulations on purchasing this rugged computer.

This chapter first tells you step by step how to get the computer up and running. Then, you will find a section briefly introducing the external components of the computer.

Getting Started 1-1

Getting the Computer Running

Getting the Computer RunningGetting the Computer Running

This section guides you through the procedures for getting the computer ready for operation.

Unpacking

UnpackingUnpacking

After unpacking the shipping carton, you should find these standard items:

 Notebook computer

 Accessories:

− AC adapter

− AC power cord

− Shoulder strap

− Handgrip strap

− Stylus and tether

− Digitizer pen (option)

− Driver disc

− Documents

Inspect all the items. If any item is damaged or missing, notify your dealer immediately.

Keep the shipping carton and packing materials in case you need to ship or store the computer in the future.

1-2 Getting Started

Connecting to AC Power

Connecting to AC PowerConnecting to AC Power

The computer operates either on the external AC power or internal battery power. It is suggested that you use AC power when you start up the computer for the very first time.

CAUTION: Use only the AC adapter included with your computer. Using other AC adapters may damage the computer.

1. Plug the DC cord of the AC adapter to the power connector of the computer ().

2. Plug the female end of the AC power cord to the AC adapter and the male end to an electrical outlet ().

3. When the AC adapter is connected, power is being supplied from the electrical outlet to the AC adapter and onto your computer. Now, you are ready to turn on the computer.

CAUTION:

hen you disconnect the AC adapter, disconnect from the electrical outlet first

 W

and then from the computer. A reverse procedure may damage the AC adapter or the computer.

Getting Started 1-3

 When unplugging the connector, always hold the plug head. Never pull on the

cord.

NOTE: When the AC adapter is connected, it also charges the battery pack. For information on using battery power, see Chapter 3.

Opening and Closing the Cover

Opening and Closing the CoverOpening and Closing the Cover

To open the top cover:

1. Pull loose the cover latch () and release the clamp ().

2. Lift up the cover (). You can tilt the cover forward or backward for optimal viewing clarity.

To close the top cover:

1. Close the display.

1-4 Getting Started

2. Lift the cover latch and engage the clamp on the display. Then, push in the cover latch to click it into place.

Operating in Tablet Mode

Operating in Tablet ModeOperating in Tablet Mode

In addition to being used as a regular notebook computer (Laptop mode), your computer can also be operated in Tablet mode. In Tablet mode, you operate the computer with a stylus or digitizer pen, or a fingertip, instead of a keyboard or mouse.

1. Open the top cover so that it is almost perpendicular with the keyboard of the computer.

2. Turn the display counter-clockwise by 165o.

CAUTION: Do not rotate the display more than 165o, or attempt to rotate the display clockwise.

. Close the computer with the display facing up.

Getting Started 1-5

4. Lift the cover latch and engage the clamp on the display. Then, push in the cover latch to click it into place.

In Tablet mode, the computer can be operated while holding it as shown. A handgrip strap is supplied to help you hold the computer. (See “Attaching the Handgrip Strap” in this chapter for installation instructions.)

1-6 Getting Started

Use the Windows Start menu to put the computer in Hibernation

Turning On and Off the Computer

Turning On and Off the ComputerTurning On and Off the Computer

Turning On

Turning OnTurning On

Press the power button ( a Power-On Self Test (POST), and the operating system such as Windows should start.

Turning O

Turning Off

Turning OTurning O

When you finish a working session, you can stop the system by turning off the power or leaving it in Sleep or Hibernation mode:

Power off (Shutdown)

ffff

To...

To... Do this...

To...To...

Use the Windows Start menu in the lower left and follow the shutdown procedure.

). Each time the computer is turned on, it performs

Do this...

Do this...Do this...

Sleep Press the power button*.

–or– Use the Windows Start menu to put the computer in Sleep mode.

Hibernate

mode. (See “Hibernation” in Chapter 3 for more information.)

* “Sleep” is the default setting of the power button. You may change what the power button does in Windows Control Panel.

Getting Started 1-7

Opens or closes the OSD (On Screen Display)

readable mode, the display brightness

Taking a Look at the Computer

Taking a Look at the ComputerTaking a Look at the Computer

NOTE:

 Depending on the model you purchased, the appearance of your computer

may not be exactly the same as those shown in this manual.

 You need to open the protective covers to access the connectors. When not

using a connector, make sure to close the cover completely for water- and dust-proof integrity. (Engage the locking mechanism if existing.)

Front Components

Front ComponentsFront Components

Ref

Component

Component Description

RefRef

ComponentComponent

Description See Also

DescriptionDescription

See Also

See AlsoSee Also

Strap Holder

Strap HolderStrap Holder



Stereo

Stereo Stereo



Speaker

SpeakerSpeaker

OSD Control

OSD Control OSD Control



Button

Button Button

P1 Button

P1 ButtonP1 Button

Sunlight

Sunlight----

SunlightSunlight



rea

readable

dable

rearea

dable dable

Button

ButtonButton

1-8 Getting Started

Two buckles hold the shoulder strap. P. 1-18

Sends out sound and voice from your computer.

control panel.

Can be re-defined using the Button Manager utility. P. 6-8

Toggles the sunlight-readable mode on or off. In sunlight-

is increased to the highest level.

P. 6-2

Opens or closes the software keyboard on your

Ref

Component

Component Description

RefRef

ComponentComponent

Description See Also

DescriptionDescription

See Also

See AlsoSee Also











P2 Button

Button

P2P2

ButtonButton

RF Button

RF Button RF Button

P3 Button

Button

P3P3

ButtonButton

Reset Button

Reset Button Reset Button

P4 Button

Button

P4P4

ButtonButton

Software

Software Software Keyboard

Keyboard

Keyboard Keyboard Button

Button

Button Button

P5 Button

Button

P5P5

ButtonButton

Top Cover

Top Cover Top Cover Latch

Latch

LatchLatch

Button

ButtonButton

Power

Power Power

CAUTION: To prevent burns to your fingers if using the computer (especially in Tablet Mode) with sunlight-readable mode turned on, do wear gloves when touching the top portion of the LCD display as it may be hot to the touch.

Can be re-defined using the Button Manager utility. P. 6-8

Serves as the master on/off control of the RF radio.

Can be re-defined using the Button Manager utility. P. 6-8

Serves as the Ctrl

Can be re-defined using the Button Manager utility. P. 6-8

screen.

Can be re-defined using the Button Manager utility. P. 6-8

Locks the top cover. P. 1-4

Turns the power on or off (Sleep mode by default).

Ctrl+Alt

Alt+Del

CtrlCtrl

AltAlt

Del keyboard keys. P. 8-12

DelDel

P. 2-17

P. 1-7

Getting Started 1-9

an audio recording

flash disk,

Locks the computer to a stationary object for

(Depending on your model, this port could be

Connects a serial mouse or serial communication

Rear Components

Rear ComponentsRear Components

Ref

RefRef





Component

Component Description

ComponentComponent

Audio Output

Audio Output Audio Output Connector

Connector

ConnectorConnector

Mini IEEE 1394

Mini IEEE 1394 Mini IEEE 1394 Port

Port

PortPort

Connects a set of headphones, external speakers with amplifier, or device.

Connects an IEEE 1394 device such as a scanner, printer, DVCAM, and VCR.

Description See Also

DescriptionDescription

See Also

See AlsoSee Also

P. 4-6

P. 4-5

Microphone

Microphone Microphone



Connector

ConnectorConnector

USB 2.0 Port

USB 2.0 PortUSB 2.0 Port



Kensington Lock

Kensington LockKensington Lock



VGA Connector

VGA ConnectorVGA Connector



Serial Connector

Serial ConnectorSerial Connector



1-10 Getting Started

Connects an external microphone. P. 4-6

Connects a USB device, such as a printer, digital camera, joystick, and more.

security.

Connects an external display monitor.

a serial connector.)

device.

P. 4-4

P. 7-3

P. 4-2

P. 4-3

Serves as the input device by tapping on the

Inside is the battery pack that supplies power to

Right

Right----Side Components

RightRight

Ref

RefRef



Side Components

Side ComponentsSide Components

Component

Component Description

ComponentComponent

Stylus

StylusStylus

touchscreen to make selections and enter information.

NOTE: Some models do not have the stylus slot on this side, so you can only use the slot on the left side for storing the stylus.

Description See Also

DescriptionDescription

See Also

See AlsoSee Also

P. 2-10

Tether Hole

Tether HoleTether Hole



Battery Pack

Battery Pack Battery Pack



Compartment

Compartment Compartment

Hard Disk Drive

Hard Disk Drive Hard Disk Drive



Compartment

Compartment Compartment

Stylus can be tethered to this hole.

NOTE: Depending on your model, this is on both sides of the computer or on the left side only.

your computer when external power is not connected.

Inside is the hard disk drive.

P. 1-17

P. 3-3

Getting Started 1-11

ice, such as a flash disk,

Depending on your model, the two slots could be a different combination (as

Left

Left----Side Components

LeftLeft

Side Components

Side ComponentsSide Components

Ref

RefRef

 

Component

Component Description

ComponentComponent

Tether Hole

Tether HoleTether Hole

Stylus Slot

Stylus SlotStylus Slot

Stylus can be tethered to this hole. P. 1-17

Stylus can be stored in this slot.

Description See Also

DescriptionDescription

See Also

See AlsoSee Also

Power Connector

Power ConnectorPower Connector



USB

USB 3.0

3.0 Port

USB USB



RJ----11

RJRJ



RJ----45

RJRJ



ExpressCard Slot

ExpressCard Slot ExpressCard Slot



(upper)

PC Card

PCPC

(lower)

below).

1-12 Getting Started

Port

3.03.0

PortPort

11 Connector

Connector

1111

ConnectorConnector

45 Connector

Connector

4545

ConnectorConnector

Card Slot

Slot

Card Card

SlotSlot

Connects the AC adapter. P. 1-3

Connects a USB dev printer, digital camera, joystick, and more.

Connects the telephone line. P. 2-18

Connects the LAN cable. P. 2-19

Accepts an ExpressCard for additional functions. P. 4-7

Accepts a PC card for additional functions. P. 4-9

P. 4-4

card for removable

The lens supports 2 MP (mega pixel).

Smart Card

Smart Card Smart Card Reader

Reader (upper)

Reader Reader

Ref

RefRef



Top

Top----open Components

TopTop

Component

Component Description

ComponentComponent

ExpressCard Slot

ExpressCard Slot ExpressCard Slot (lower)

SD Card Reader

SD Card ReaderSD Card Reader

open Components

open Componentsopen Components

Accepts a smart card for additional security feature.

Accepts an ExpressCard for additional functions. P. 4-7

Accepts a SD/SDHC/SDXC storage media.

P. 4-11

Description See Also

DescriptionDescription

See Also

See AlsoSee Also

P. 4-12

Ref

RefRef



Com

Component

ponent Description

ComCom

ponentponent

Camera Lens

Camera LensCamera Lens

Allows you to use your computer’s camera function.

Description See Also

DescriptionDescription

Getting Started 1-13

See Also

See AlsoSee Also

P. 6-22

automatic adjustment of the LCD brightness and

Blinks yellow when the battery’s capacity is below

Lights green when the computer is accessing the

Ref

RefRef





Com

Component

ponent Description

ComCom

ponentponent

Touchscreen

TouchscreenTouchscreen

Light Sensor

Light SensorLight Sensor

Description See Also

DescriptionDescription

It can be rotated.

Displays and receives information for the computer.

Detects the surrounding lighting condition for

See Also

See AlsoSee Also

P. 2-10



  

Fingerprint

Fingerprint Fingerprint Scanner

Scanner

Scanner Scanner (optional)

Keyboard

KeyboardKeyboard

Touchpad

TouchpadTouchpad

Indicators

IndicatorsIndicators

Power

PowerPower

Battery

Battery Battery

Charge

ChargeCharge

optional keyboard backlight.

Uses fingerprint verification to protect your computer against unauthorized access.

Serves as the data input device. P. 2-2

Serves as the pointing device. P. 2-7

Show the current status of the computer’s devices.

Lights green when the computer is turned on. P. 1-7

Lights yellow when the computer is in Sleep mode.

Lights green when the battery is fully charged. P. 3-3

Lights yellow when the battery is being charged.

10%.

Blinks green and yellow by turns to indicate charging is suspended because the battery’s temperature is either too high or too low.

P. 2-27

P. 3-6

Hard Disk

Hard Disk Hard Disk

Drive In

Drive In----Use

Drive InDrive In

1-14 Getting Started

Use

UseUse

hard disk drive.

hen the optional hard disk drive heater

Inside is the docking connector for connecting an

Ref

RefRef

Com

Component

ponent Description

ComCom

ponentponent

Description See Also

DescriptionDescription

See Also

See AlsoSee Also

Blinks red w is on for low temperature operation.

RFRF

Num Lock

Num LockNum Lock

Caps Lock

Caps LockCaps Lock

Bottom Components

Bottom ComponentsBottom Components

Lights when the radio frequency is on.

Lights when Num Lock is on. P. 2-3

Lights when Caps Lock is on. P. 2-2

P. 8-9

Ref

RefRef

 

Component

Component Description

ComponentComponent

Strap Holder

Strap HolderStrap Holder

Docking

Docking Docking Connector

Connector

ConnectorConnector

Four bottom hooks hold the handgrip strap. P. 1-18

office dock or vehicle dock (purchased separately).

Description See Also

DescriptionDescription

Getting Started 1-15

See Also

See AlsoSee Also

Inside are the memory slots for expanding the



Memory Slots

Memory SlotsMemory Slots

SIM Card Slot

SIM Card Slot SIM Card Slot

(optional)

P. 4-13

memory size of your computer.

Inside is the SIM card slot. P. 2-23

1-16 Getting Started

Using the Accessories

Using the AccessoriesUsing the Accessories

Using the Tether

Using the TetherUsing the Tether

A tether is provided for attaching the stylus to your computer.

1. Insert one of the tether’s loop ends through the hole of the stylus (as indicated by  below). Then, insert the other end through the first loop (as indicated by  below) and pull it tight.

2. Insert the other loop end to the tether hole on the computer (as indicated by

 below). Then, insert the stylus end through the loop (as indicated by 

below) and pull it tight.

Getting Started 1-17

Attaching the Handgrip Strap

ttaching the Handgrip StrapAttaching the Handgrip Strap

To use the handgrip strap, attach its four loops to the four bottom hooks on your computer. Make sure the loops are securely hooked.

When you need to operate and hold your computer at the same time, insert your hand through the strap for a firm grip.

Attaching the Shoulder Strap

ttaching the Shoulder StrapAttaching the Shoulder Strap

To use the shoulder strap, secure the snap hooks to (Select models have four buckles for different positioning of the strap.)

1-18 Getting Started

the two buckles on your computer.

CAUTION:

he strap has been designed to carry only the weight of the computer.

 T

Therefore, be sure that the strap does not carry a weight that exceeds the weight of the computer. The strap may accidentally come loose from the computer.

 Do not use a strap that is damaged or about to tear.

Getting Started 1-19

Chapter 2

Chapter 2Chapter 2

Operating Your Computer

Operating Your ComputerOperating Your Computer

This chapter provides information about the use of the computer.

If you are new to computers, reading this chapter will help you learn the operating basics. If you are already a computer user, you may choose to read only the parts containing information unique to your computer.

CAUTION:

o not expose your skin to the computer when operating it in a very hot or cold

 D

environment.

 The computer can get uncomfortably warm when you use it in high

temperatures. As a safety precaution in such a circumstance, do not place the computer on your lap or touch it with your bare hands for extended periods of time. Prolonged body contact can cause discomfort and potentially a burn.

Operating Your Computer 2-1

Using the Internal Keyboard

Using the Internal KeyboardUsing the Internal Keyboard

Your keyboard has all the standard functions of a full-sized computer keyboard plus an Fn

Fn key added for specific functions.

FnFn

The standard functions of the keyboard can be further divided into four major categories:

 Typewriter keys

 Cursor-control keys

 Numeric keys

 Function keys

Typewriter Keys

ypewriter KeysTypewriter Keys

Typewriter keys are similar to the keys on a typewriter. Several keys are added such as the Ctrl (Caps Lock

aps Lock and Num Lk

aps Lockaps Lock

Ctrl, Alt

Alt, Esc

CtrlCtrl

Esc, and lock keys for special purposes. When the lock keys

AltAlt

EscEsc

Num Lk) are pressed, their corresponding indicators light up.

Num LkNum Lk

The Control (Ctrl keys for program-specific functions. The Escape (Esc stopping a process. Examples are exiting a program and canceling a command. The function depends on the program you are using.

Cursor

Cursor----Control Keys

CursorCursor

Cursor-control keys are generally used for moving and editing purposes.

NOTE: The word “cursor” refers to the indicator on the screen that lets you know exactly where on your screen anything you type will appear. It can take the form of a vertical or horizontal line, a block, or one of many other shapes.

2-2 Operating Your Computer

Ctrl) / Alternate (Alt

CtrlCtrl

Control Keys

Control KeysControl Keys

Alt) key is normally used in combination with other

AltAlt

Esc) key is usually used for

EscEsc

Numeric Keypad

umeric KeypadNumeric Keypad

A 15-key numeric keypad is embedded in the typewriter keys as shown next:

Numeric keys facilitate entering of numbers and calculations. When Num Lock is on, the numeric keys are activated; meaning you can use these keys to enter numerals.

NOTE:

 When the numeric keypad is activated and you need to type the English letter

in the keypad area, you can turn Num Lock off or you can press Fn the letter without turning Num Lock off.

 Some software may not be able to use the numeric keypad on the computer. If

so, use the numeric keypad on an external keyboard instead.

Operating Your Computer 2-3

Fn and then

FnFn

Function Keys

Function KeysFunction Keys

On the top row of the keys are the function keys: F1 to F12. Function keys are multi-purpose keys that perform functions defined by individual programs.

Fn Key

Fn KeyFn Key

The Fn key, at the lower left corner of the keyboard, is used with another key to perform the alternative function of a key. The letter “Fn” and the alternative functions are identified by the color of blue on the keytop. To perform a desired function, first press and hold Fn, then press the other key.

Hot Keys

ot KeysHot Keys

Hot keys refer to a combination of keys that can be pressed any time to activate special functions of the computer. Most hot keys operate in a cyclic way. Each time a hot key combination is pressed, it shifts the corresponding function to the other or next choice.

You can easily identify the hot keys with the icons imprinted on the keytop. The hot keys are described next.

Key

Key Description

KeyKey

2-4 Operating Your Computer

Description

DescriptionDescription

Switches the keyboard backlight on and off (optional).

Switches the wireless radio on and off.

Decreases the sound volume.

that you can define with Windows’

Key

Key Description

KeyKey

Increases the sound volume.

Switches the display output when external devices are connected.

Decreases the LCD brightness (20 levels).

Increases the LCD brightness (20 levels).

Switches the touchscreen on and off (option).

Switches the touchpad on and off.

Description

DescriptionDescription

Switches the system sound output off (mute) and on.

Switches LCD backlight on and off.

Serves as the sleep button

Power Options

Power Options. (See the “Power Management” in Chapter 3.)

Power OptionsPower Options

Windows Keys

Windows KeysWindows Keys

The keyboard has two keys that perform Windows-specific functions: Logo key and

Application key.

Windows

Operating Your Computer 2-5

The Windows Logo key opens the Start functions when used in combination with other keys. The Application key usually has the same effect as a right mouse click. (See your Windows manual for more information.)

Start menu and performs software-specific

StartStart

2-6 Operating Your Computer

Using the Touchpad

Using the TouchpadUsing the Touchpad

CAUTION: Do not use a sharp object such as a pen on the touchpad. Doing so may damage the touchpad surface.

NOTE: For optimal performance of the touchpad, keep your fingers and the pads clean and dry. When tapping on the pad, tap lightly. Do not use excessive force.

The touchpad is a pointing device that allows you to communicate with the computer by controlling the location of the pointer on the screen and making selection with the buttons.

The touchpad consists of a rectangular pad (work surface) and a left and right buttons. To use the touchpad, place your forefinger or thumb on the pad. The rectangular pad acts like a miniature duplicate of your display. As you slide your fingertip across the pad, the pointer (also called cursor) on the screen moves accordingly. When your finger reaches

the edge of the pad, simply relocate yourself by lifting the finger and placing it on the other side of the pad.

Here are some common terms that you should know when using the touchpad:

Operating Your Computer 2-7

Term

Term Action

TermTerm

Action

ActionAction

Point Move your finger on the pad until the cursor points to the selection

on the screen.

Click Press and release the left button.

–or– Tap gently anywhere on the pad.

Double-click Press and release the left button twice in quick succession.

–or– Tap twice on the pad rapidly.

Drag and drop Press and hold the left button, then move your finger until you

reach your destination (drag). Finally, release the button (drop) when you finish dragging your selection to the destination. The object will drop into the new location.

–or– Gently tap twice on the pad and on the second tap, keep your

finger in contact with the pad. Then, move your finger across the pad to drag the selected object to your destination. When you lift your finger from the pad, the selected object will drop into place.

Scroll To scroll is to move up and down or left and right in the working

TABLE NOTE:

TABLE NOTE: If you swap the left and right buttons, “tapping” on the touchpad as

TABLE NOTE:TABLE NOTE:

an alternative method of pressing the left button will no longer be valid.

2-8 Operating Your Computer

area on the screen. To move vertically, place your finger on the right or left edge

of the pad and slide your finger up and down along the edge. To move horizontally, place your finger on the top or bottom edge of the pad and slide your finger left and right.

This function works only after you install the touchpad driver supplied with the computer and it may not work for all applications.

Configuring the Touchpad

Configuring the TouchpadConfiguring the Touchpad

You may want to configure the touchpad to suit your needs. For example, if you are a left-handed user, you can swap the two buttons so that you can use the right button as the left button and vice versa. You can also change the size of the on-screen pointer, the speed of the pointer, and so on.

To configure the touchpad, go to Control Panel

Control Panel  Mouse Properties

Control PanelControl Panel

Mouse Properties.

Mouse PropertiesMouse Properties

Operating Your Computer 2-9

Navigating on the Screen

Navigating on the ScreenNavigating on the Screen

The screen of your computer is touch-sensitive. You can control the location of the cursor/pointer on the screen using your finger or the included stylus or digitizer pen to communicate with the computer.

CAUTION: Do not use sharp objects on the LCD display. Doing so may damage the display surface. Use your finger or the included stylus or digitizer pen.

Using the Touchscreen

Using the TouchscreenUsing the Touchscreen

If your computer is equipped with the touchscreen fe or the included stylus to navigate and select objects on the screen.

The following table shows how you use the touchscreen to obtain equivalent mouse functions.

Term/Action

Term/ActionTerm/Action

Tap: Touch the screen once. Click/Point

Double-tap: Touch the screen twice rapidly. Double-click

ature, you can use your finger

Equivalent Mouse

Equivalent Mouse Equivalent Mouse

Function

FunctionFunction

2-10 Operating Your Computer

Use zooming to make an

Equivalent Mouse

Term/Action

Term/ActionTerm/Action

Tap and hold: Tap and hold until a popup menu appears. Right-click

Equivalent Mouse Equivalent Mouse

Function

FunctionFunction

Drag: Hold the stylus (or finger) on the screen and drag

across the screen until reaching your destination.

Using Multi

Using Multi----touch Gestures

Using MultiUsing Multi

If your computer model comes with multi-touch-capable screen and Windows 7, you can interact with your computer by placing two fingers on the screen. The movement of the fingers across the screen creates “gestures,” which send commands to the computer.

Here are the multi-touch gestures that you can use:

Gestures

GesturesGestures

Pan (Scroll)

touch Gestures

touch Gesturestouch Gestures

Actions

ActionsActions

( = finger down; = finger up)

( = finger down; = finger up)( = finger down; = finger up)

Drag 1 or 2 fingers up or down.

Drag

Descriptions

DescriptionsDescriptions

Use panning to see another part of a page that has scroll bars.

Zoom (Pinch)

Move two fingers apart/toward each other.

item (a photo for example) on the screen larger or smaller. The gesture works in applications that support mouse wheel zooming.

Operating Your Computer 2-11

works in applications that

Press on target and tap using a second

Gestures

GesturesGestures

Actions

ActionsActions

( = finger down; = finger up)

( = finger down; = finger up)( = finger down; = finger up)

Descriptions

DescriptionsDescriptions

Rotate

Press and Tap

Twofinger Tap

Move two fingers in opposing directions.

-orUse one finger to pivot around another.

finger.

Use rotating to move a picture or other item on the screen in a circular direction (clockwise or counterclockwise). The gesture

support the specific gesture.

Use press and tap to access the shortcut menu.

The function is defined by applications that support the specific gesture.

Tap two fingers at the same time (where the target is in the midpoint between the fingers).

2-12 Operating Your Computer

Gestures

GesturesGestures

Actions

ActionsActions

( = finger down; = finger up)

( = finger down; = finger up)( = finger down; = finger up)

Descriptions

DescriptionsDescriptions

Flicks

Make quick drag gestures in the desired direction.

Using the Dual Mode Display (Optional)

sing the Dual Mode Display (Optional)Using the Dual Mode Display (Optional)

Dual mode display incorporates both touchscreen and digitizer functions.

The display is set to Touchscreen mode by default. Touchscreen mode provides all the functionalities that an ordinary touchscreen has. When the computer receives signals from the digitizer pen, the display automatically switches to Digitizer mode.

Flick left or right to navigate back and forward in a browser and other applications. The gesture works in most applications that support back and forward.

Here are some common terms that you should know when using the digitizer feature:

Operating Your Computer 2-13

Term

Term Action

TermTerm

Action

ActionAction

Move

Click/Point

Double-click

Drag and drop

Right-click

Move the cursor pointed by the digitizer pen.

Tap gently on the display.

Tap twice on the display rapidly.

Tap lightly on the display and move your digitizer pen until you reach your destination (drag). Finally, release your digitizer pen (drop) when you finish dragging your selection to the destination. The object will drop into the new location.

Press and hold down the digitizer pen button (A), then tap gently the object.

CAUTION:

 When the LCD display is used alone or with an external display

simultaneously, the digitizer function cannot be used when the area of either display is set larger than the default setting of the display resolution.

 Even when only an external display is in use, the cursor will move on the

external display if you touch the surface of the LCD display with the pen or bring the pen close to the surface of the LCD display when the digitizer driver is active. Therefore, do not touch the LCD display when only an external display is in use.

 The active digitizer feature cannot be used in the BIOS Setup program or

when using the full screen in DOS mode.

2-14 Operating Your Computer

NOTE:

 You can move the cursor by bringing the digitizer pen close to the screen,

without actually touching the screen’s surface.

 Do not move the digitizer pen too quickly. If the pen moves too quickly, the

cursor may be unable to follow its movement.

 If you cannot click on the edge of the screen, hold the digitizer pen

perpendicular to the display and try clicking again.

Using Landscape or Portrait View

Using Landscape or Portrait ViewUsing Landscape or Portrait View

To rotate the display, press the button

located on the front of your computer

to open the OSD Control Panel and click . Each time this Rotate button is clicked, the screen display rotates counter-clockwise by 90O.

For a Model without WWAN Module

For a Model without WWAN ModuleFor a Model without WWAN Module

Primary

Primary Primary

Landscape

LandscapeLandscape

Display

For a Model with WWAN Module

For a Model with WWAN ModuleFor a Model with WWAN Module

Primary

Primary Primary

Landscape

ndscape

LaLa

ndscapendscape

Display

Primary

Primary Primary

Portrait

PortraitPortrait

Display

Secondary

Secondary Secondary Landscape

Landscape

LandscapeLandscape

Display

Secondary

Secondary Secondary Landscape

Landscape

LandscapeLandscape

Display

Primary Landscape

Primary LandscapePrimary Landscape

Secondary

Secondary Secondary

Display

Portrait

PortraitPortrait

Display

Primary

Primary Primary

Landscape

LandscapeLandscape

Display

Operating Your Computer 2-15

NOTE:

 If the screen display resolution has been set to 800×600 pixels, you can rotate

the display to Primary Landscape and Secondary Landscape only.

 While the display is rotated:

– Do not set the display resolution larger than the resolution of the LCD display. – If you exit Windows, the next time Windows is started up, the operation of the touchpad will not match the display angle for a few seconds. – The computer’s performance will decrease slightly. – If a video is played, the picture may not be displayed properly or the sound may be broken up. This problem can be corrected by rotating the display to Primary Landscape. – The touchpad’s scroll function does not work.

 The display cannot be rotated when DOS mode is set to “Full Screen.”

2-16 Operating Your Computer

Using the Input Panel

Using the Input PanelUsing the Input Panel

Use the Input Panel to enter text and perform various keyboard functions. There are two types of Input Panels for you to use in Windows 7:

 Touch Keyboard

Touch Keyboard allows you to enter text by tapping the keys with your stylus,

Touch KeyboardTouch Keyboard

like pressing the keys on a standard keyboard.

 Writing Pad

Writing Pad allows you to write on the writing pad, like writing on a piece of

Writing PadWriting Pad

paper. Your handwriting will be converted into typed text.

To open the Input Panel, tap the Input Panel tab, which appears by default on the left edge of the screen. (You can also press the button on the front of the computer to open or close the Input Panel.) To switch between the two types, tap

or at the upper left corner of the Input Panel.

NOTE: For more information on using the Input Panel, see Windows’ online help.

Operating Your Computer 2-17

Using the Network Features

Using the Network FeaturesUsing the Network Features

Using the Modem

Using the ModemUsing the Modem

The internal 56 K fax/data modem allows you to use the telephone line to communicate with others by fax, email, or connect to an online service or bulletin board.

To connect the telephone line to the modem, connect one end of the modem cable to the RJ-11 connector on the computer and the other end to the phone line.

NOTE:

 When using the communication software, you may have to disable power

management. Do not enter the Sleep mode when using the communication software.

 Set parameters such as modem speed (baud rate) and line type (pulse dialing

or tone dialing).

2-18 Operating Your Computer

Using the LAN

Using the LANUsing the LAN

The internal 10/100/1000Base-T LAN (Local Area Network) module allows you to connect your computer to a network. It supports data transfer rate up to 1000 Mbps.

To connect the network cable to the LAN module, connect one end of the LAN cable to the RJ-45 connector on the computer and the other end to the network hub.

Using the Wireless LAN

Using the Wireless LANUsing the Wireless LAN

The WLAN module of your computer supports IEEE 802.11a/g/n.

Turning On/Off the WLAN Radio

Turning On/Off the WLAN Radio Turning On/Off the WLAN Radio

NOTE: The FAA (Federal Aviation Agency) has deemed it unsafe to operate wireless devices in aircraft as this may interfere with flight safety. Remember to turn off wireless LAN when using your computer in the airplane.

FOR WIFI 5G BAND STATEMENT

The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems.

To turn on or off the wireless radio (including the WLAN radio), press the button

located on the front of your computer or spress Fn+F1

up on the screen to indicate the status.

Fn+F1. A small window pops

Fn+F1Fn+F1

Operating Your Computer 2-19

Connecting to a Wireless Network

Connecting to a Wireless NetworkConnecting to a Wireless Network

To connect to a wireless network:

1. Make sure that the WLAN function is enabled (as described above). The Wireless Network icon on the taskbar should appear without a red X.

2. Tap the Wireless Network icon on the taskbar. (An orange light in the icon

indicates connections are available.)

3. In the list of available wireless networks, tap a network, and then tap Connect

4. Some networks require a network security key or passphrase. To connect to one of those networks, ask your network administrator or Internet service provider (ISP) for the security key or passphrase.

For more information on setting a wireless network connection, refer to Windows online help.

Connect.

ConnectConnect

NOTE: Y capabilities of your computer. See the Help of the utility for instructions.

2-20 Operating Your Computer

ou can use Intel® PROSet Wireless to take full advantage of the WiFi

Using the Blue

Using the Bluetooth Feature

Using the BlueUsing the Blue

Your computer incorporates the Bluetooth 4.0 capability for short-range (about 50 meters) wireless communications between devices without requiring a cable connection. With Bluetooth, data can be transmitted through walls, pockets and briefcases as long as two devices are within range.

Turning Off/On the Bluetooth Radio

Turning Off/On the Bluetooth RadioTurning Off/On the Bluetooth Radio

To turn on or off the wireless radio (including the Bluetooth radio), press the button

located on the front of your computer or spress Fn+F1

up on the screen to indicate the status.

When the Bluetooth radio is on, the Bluetooth icon appears on the Windows taskbar.

Connecting to another Bluetooth Device

Connecting to another Bluetooth DeviceConnecting to another Bluetooth Device

tooth Feature

tooth Featuretooth Feature

Fn+F1. A small window pops

Fn+F1Fn+F1

1. Make sure that the Bluetooth function is enabled (as described above).

2. Make sure that the target Bluetooth device is turned on, discoverable and within close range. (See the documentation that came with the Bluetooth device.)

3. To search for Bluetooth devices, right click the Bluetooth icon and select Add a Device.

4. Select the device you want to connect from the search results.

Operating Your Computer 2-21

5. Depending on the type of Bluetooth device that you want to connect to, you will need to enter the pertinent information.

For detailed information on using the Bluetooth feature, see Windows’ online Help.

2-22 Operating Your Computer

Using the WWAN Feature (Option

Using the WWAN Feature (Optional)

Using the WWAN Feature (OptionUsing the WWAN Feature (Option

A WWAN (Wireless Wide Area Network) uses mobile telecommunication cellular network technologies to transfer data. The WWAN module of your computer supports 3G or 4G LTE depending on your model.

NOTE: Your computer only supports data transmission; voice transmission is not supported.

Installing a SIM Card

Installing a SIM CardInstalling a SIM Card

al)

al)al)

To use the WWAN feature to connect to the Internet, service and acquire a SIM card from a mobile phone network service provider.

To install the SIM card, follow these steps:

1. Turn off the computer and disconnect the AC adapter.

2. Carefully place the computer upside down.

3. Remove the four screws to open the compartment cover.

you need to subscribe to the

Operating Your Computer 2-23

Locking tab

4. Locate the SIM card slot.

Slide the locking tab of the SIM card slot inward to unlock. Lift the slot up and, noting the orientation, insert the SIM card into the slot. Close the slot and slide the locking tab outward to secure the card in place.

5. Slide the locking tab outward to secure the SIM card in place.

6. Close the compartment cover and secure with four screws.

Turning Off/On the WWAN Radio

Turning Off/On the WWAN RadioTurning Off/On the WWAN Radio

CAUTION:

For SAR STATEMENT FCC RF Radiation Exposure Statement For body worn operation, this device has been tested and meets FCC RF

exposure guidelines that positions the EUT a minimum of 0 cm from the body SAR information:

1.WWAN transmitter : 0.142W/kg (1g)

2.WLAN transmitter: 0.376 W/kg (1g)

2-24 Operating Your Computer

To turn on or off the wireless radio (including the WWAN radio), press the button

located on the front of your computer. A small window pops up on the screen

to indicate the status.

Connecting to WWAN Network

Connecting to WWAN NetworkConnecting to WWAN Network

1. Make sure that the SIM card is inserted and WWAN function is enabled (as described above).

2. On Windows desktop, double-click the AirCard Watcher below appears.

3. If the radio is currently off, click Turn Radio On

4. Use AirCard Watcher to manage your broadband wireless network connections such as:

 Connect to the Internet

 Configure user options

AirCard Watcher shortcut. The screen as

AirCard WatcherAirCard Watcher

Turn Radio On to turn on the radio.

Turn Radio OnTurn Radio On

 Send and receive SMS messages

Operating Your Computer 2-25

 Manage profiles

 Use GPS to track your position (for models having the GPS module)

NOTE: For detailed information on using AirCard Watcher, see the program’s online help.

2-26 Operating Your Computer

Using the Fingerpri

Using the Fingerprint Scanner

Using the FingerpriUsing the Fingerpri (Optional)

(Optional)

(Optional)(Optional)

CAUTION:

 We shall not be liable for any loss or damage whatsoever resulting from your

use of the fingerprint scanner or neglect of fingerprint scanner use, or any data loss resulting from such developments as fingerprint authentication malfunctioning.

 It is not recommended that you use the fingerprint scanner in a below-freezing

temperature. The moisture on your finger can freeze to the scanner’s metal surface when you touch it, resulting in a failed operation.

he fingerprint scanner provides a strong authentication mechanism based on fingerprint

T recognition. It features:

 Website Log On

Logon to your web accounts like banks, webmail, and more with a simple swipe of your finger.

nt Scanner

nt Scanner nt Scanner

 Windows Log On

Logon to Microsoft® Windows® with a simple swipe of your finger every time you turn on your computer or log onto your desktop.

 QuickLaunch

Quickly launch all your favorite websites, open files and folders, and log in to your accounts with a simple swipe of your finger.

 KeepSafe

Protect your pictures, personal files, and folders using your fingerprint so only you can access them.

NOTE: Y Windows user account.

ou can register a fingerprint only after creating a password for the

Operating Your Computer 2-27

App Store

Settings

Options

Help

To register your fingerprint, click Start

AuthenTec TrueSuite

AuthenTec TrueSuite. Click the finger you want to register and follow the onscreen

AuthenTec TrueSuiteAuthenTec TrueSuite

Start  All Programs

StartStart

Programs  AuthenTe

ProgramsPrograms

AuthenTec TrueSuite

AuthenTeAuthenTe

c TrueSuite 

c TrueSuitec TrueSuite

instructions to complete.

You can then use the Fingerprint Software to set up how the fingerprint authentication works.

2-28 Operating Your Computer

For detailed information, click the Help button of the software.

Operating Your Computer 2-29

Chapter 3

Chapter 3Chapter 3

Managing Power

Managing PowerManaging Power

Your computer operates either on external AC power or on internal battery power.

This chapter tells you how you can effectively manage power. To maintain optimal battery performance, it is important that you use the battery in the proper way.

Managing Power 3-1

AC Adapter

AC AdapterAC Adapter

CAUTION:

 The AC adapter is designed for use with your computer only. Connecting the

AC adapter to another device can damage the adapter.

 The AC power cord supplied with your computer is for use in the country where

you purchased your computer. If you plan to go overseas with the computer, consult your dealer for the appropriate power cord.

 When you disconnect the AC adapter, disconnect from the electrical outlet first

and then from the computer. A reverse procedure may damage the AC adapter or computer.

 When unplugging the connector, always hold the plug head. Never pull on the

cord.

he AC adapter serves as a converter from AC (Alternating Current) to DC (Direct

T Current) power because your computer runs on DC power, but an electrical outlet usually provides AC power. It also charges the battery pack when connected to AC power.

The adapter operates on any voltage in the range of 100~240 V AC.

3-2 Managing Power

Battery Pack

Battery PackBattery Pack

The battery pack is the internal power source for the computer. It is rechargeable using the AC adapter.

The operating time of a fully charged battery pack depends on how you are using the computer. When your applications often access peripherals, you will experience a shorter operating time.

NOTE: Care and maintenance information for the battery is provided in the “Battery Pack” section in Chapter 7.

Charging the Battery Pack

Charging

hargingCharging

NOTE:

 Charging will not start if the battery’s temperature is below 0 °C (32 °F) or

above 40 °C (104 °F); the charging process will stop if the battery’s temperature gets above 60 °C (140 °F). To avoid damaging the battery under this situation, disconnect the AC adapter and wait for the battery to return to room temperature before charging again.

 During charging, do not disconnect the AC adapter before the battery has

been fully charged; otherwise you will get a prematurely charged battery.

To charge the battery pack, connect the AC adapter to the computer and an electrical outlet. The Battery Charge Indicator ( that charging is in progress. You are advised to keep the computer power off while the battery is being charged. When the battery is fully charged, the Battery Charge Indicator lights green.

It takes approximately 3 hours to fully charge the Li-Ion battery pack when the computer is off, and approximately 6 hours to fully charge the Li-Ion battery pack when the computer is on.

the Battery Pack

the Battery Packthe Battery Pack

) on the computer glows yellow to indicate

Managing Power 3-3

CAUTION: After the computer has been fully recharged, do not immediately disconnect and reconnect the AC adapter to charge it again. Doing so may damage the battery.

NOTE: The battery level may automatically lessen due to the self-discharge process (0.21 % per day), even when the battery pack is fully charged (100 %). This happens no matter if the battery pack is installed in the computer.

Initializing the Battery Pack

Initializing the Battery PackInitializing the Battery Pack

You need to initialize a new battery pack before using it for the first time or when the actual operating time of a battery pack is much less than expected. Initializing is the process of fully charging, discharging, and then charging. It can take several hours.

A tool called “Gauge Reset” is provided for the purpose. See “Gauge Reset” in Chapter 6 for information on using the tool.

Checking the Battery Level

hecking the Battery Level Checking the Battery Level

NOTE: Any battery level indication is an estimated result. The actual operating time can be different from the estimated time, depending on how you are using the computer.

By Operating System

By Operating SystemBy Operating System

You can check the approximate battery level using the battery meter function of the operating system. To read the battery level in Windows, click the battery icon on the taskbar.

By Gas Gauge

By Gas GaugeBy Gas Gauge

On the exterior side of the battery pack is a gas gauge for displaying the estimated battery charge. When the battery pack is not installed in the computer and you want

3-4 Managing Power

to know the battery charge, you can press the switch with a pointed device to see the corresponding value of indicator segment that light green.

Switch

The value of the corresponding green segment indicates the relative percentage of the battery charge. The battery pack is fully discharged when you see no segment glowing green.

Replacing the Battery Pack

eplacing the Battery PackReplacing the Battery Pack

CAUTION:

 There is danger of explosion if the battery is incorrectly replaced. Replace the

battery only with the computer manufacturer’s optional battery packs. Discard used batteries according to the dealer’s instructions.

 Do not attempt to disassemble the battery pack.

If you often rely on battery power for a long period of time while traveling, you may consider the purchase of an additional battery pack from your dealer and keep it with you in a fully charged state as a backup.

To replace the battery pack, follow these steps:

1. Make sure that the computer is not turned on or connected to AC power.

2. Locate the battery compartment on the right side of the computer.

3. Slide the door lock toward the left to unlock (). Then slide the door latch downward to open the door ().

Managing Power 3-5

percent

battery

battery level

The battery charge has reached the critical battery

4. Pull the ribbon strip to remove the battery pack.

5. With the ribbon strip facing outward, slide the new battery pack all the way into the slot.

6. Close the door. Make sure the door latch clicks into place. Then, slide the door lock toward the right.

Battery Low Signa

Battery Low

attery Low Battery Low

The battery icon changes appearance to display the current state of the battery.

Battery

Battery Battery

Icon

IconIcon

3-6 Managing Power

Battery Level Description

Battery LevelBattery Level

Discharging The icon shows the charge remaining in 10-

Low The battery charge has reached the low-

Critically low

Signals and Action

SignaSigna

Battery Level

ls and Actionssss

ls and Actionls and Action

increments until the charge reaches the lowlevel.

(10% by default).

level (5% by default). By default, Windows will display a notification and put your computer into Hibernation.

Description

DescriptionDescription

When the battery is low, the computer’s Battery Charge Indicator (

) also

blinks red to alert you to take actions.

Always respond to low-battery by connecting the AC adapter, placing your computer in Hibernation mode, or turning off the computer.

Managing Power 3-7

When the hard disk has been idle for a set

When the display has been idle for a set

mode.

The hard disk and display are turned

off and the entire system consumes

When the entire system has been idle for

mode. (See the next subsection for

When the entire system has been idle for

Power Management

Power ManagementPower Management

Your computer supports ACPI (Advanced Configuration and Power Interface) for power management. The power management feature allows you to reduce the power consumption for energy saving.

With an ACPI-compliant operating system such as Windows, power supply to different computer components is controlled on an as-needed basis. This allows maximum power conservation and performance at the same time.

In general, Windows’ power management works in this way:

What...

What... When...

What...What...

Power to the hard disk is turned off

Power to the display is turned off

period.

When...

When...When...

The computer enters the Sleep

less power.

The computer enters the Hibernation

more information.)

For detailed information on power management, see Windows’ Help.

3-8 Managing Power

a set period.

When you manually activate the mode.

a set period.

When you manually activate the mode.

Hibernation

HibernationHibernation

Hibernation is a very useful feature. People frequently open many applications when they use computers. It takes some time to get all these applications open and running, and normally they all have to be closed before the computer can be turned off.

When you use the hibernation feature, you do not have to close the applications. The computer stores the state of your computer to a file on the hard disk and then shuts down. The next time you turn on your computer, you return to exactly where you left off.

Managing Power 3-9

Power

Power----Saving Tips

PowerPower

Aside from enabling your computer’s power saving mode (see previous section), you can do your part to maximize the battery’s operating time by following these suggestions.

 Enter power saving mode when using battery power.

 Do not disable automatic power management features.

 Decrease the LCD brightness to the lowest comfortable level.

 Shorten the length of time before Windows turn off the display.

 Many USB devices use power just by being connected. If you use a USB mouse,

you can save power by disconnecting the mouse and using the touchpad. If you use a USB flash drive, unplug it when you are not using it.

 Remove the card (such as PC card, ExpressCard, and Smart Card) if not using

it.

Saving Tips

Saving TipsSaving Tips

 Turn off the wireless radio if you are not using the wireless module (such as

WLAN, Bluetooth, or WWAN).

 Turn off the computer when you are not using it.

3-10 Managing Power

Chapter 4

Chapter 4Chapter 4

Expanding Your

Expanding Your Expanding Your Computer

Computer

ComputerComputer

You can expand the capabilities of your computer by devices.

When using a device, be sure to read the instructions accompanying the device together with the relevant section in this chapter.

connecting other peripheral

Expanding Your Computer 4-1

Connecting an External Monitor

Connecting an External MonitorConnecting an External Monitor

If you want the benefits of a larger display screen with higher resolution, you can connect an external display monitor to your computer. Follow this procedure to connect an external monitor:

1. Make sure that the computer is not turned on.

2. Plug the monitor’s D-type signal connector to the computer’s VGA connector.

3. Plug one end of the monitor’s power cord into the power socket on the monitor and the other end to an electrical outlet.

4. To use the monitor, turn on the monitor before turning on the computer.

5. The monitor should respond by default. If not, you can switch the display to the monitor or to both (simultaneous display), or to multi-display by pressing the Fn

Fn+F5

F5 hot key. In Windows, you can also change the display through the

FnFn

F5F5

settings in Display

6. You can change display settings through your operating system. See your operating system documentation or online help for specific information.

CAUTION: Do not disconnect the external monitor while the computer is in the Sleep mode or Hibernation mode. If no external monitor is connected when the computer resumes, the LCD might not display properly.

4-2 Expanding Your Computer

Display Properties.

DisplayDisplay

Connecting a Serial Device

Connecting a Serial DeviceConnecting a Serial Device

Your computer has one or two serial port (depending on model) for connecting a serial device such as a serial mouse or serial communication device (modem).

Follow this procedure to connect a serial device:

1. Make sure the computer is not turned on

2. Plug the device cable to the serial port on the rear of the computer.

3. Turn on the computer.

NOTE: Portable modems that derive power through the serial port cannot be used with the computer. Instead, use a modem that is powered by its own internal battery or external AC power.

Expanding Your Computer 4-3

Connecting a USB Device

Connecting a USB DeviceConnecting a USB Device

Your computer has three USB ports (two USB 3.0 ports at the left side and one USB 2.0 port at the back) for connecting USB devices, such as a digital camera, scanner, printer, modem, and mouse.

USB 3.0 supports a transfer rate up to 5 Gbit/s and USB 2.0 a transfer rate up to 12 MB/s.

To connect a USB device, plug the device cable to a matching USB port.

4-4 Expanding Your Computer

Connecting an IEEE 1394 Device

Connecting an IEEE 1394 DeviceConnecting an IEEE 1394 Device

Your computer has a mini IEEE 1394a port for connecting IEEE 1394 devices that include not only computer peripheral devices such as scanner, printer and high-quality CCD, but also consumer electronic equipment such as DVCAM and VCR.

To connect an IEEE 1394 device, prepare an IEEE 1394 cable. Plug the appropriate end of the cable to the computer’s mini IEEE 1394 connector and the other end to the device’s corresponding connector.

Expanding Your Computer 4-5

Connecting Audio Devices

Connecting Audio DevicesConnecting Audio Devices

For higher audio quality, you can send or receive sound through external audio devices.

 Audio Output Connector

Audio Output Connector (

Audio Output Connector Audio Output Connector

or earphone set.

)

can be connected to speakers, headphones,

 Microphone Connector

Microphone Connector (

Microphone Connector Microphone Connector

for recording voice or sound.

NOTE:

 After connecting an external audio device, make sure that you specify the use

of the correct audio device in Windows.

 When using the external speakers/headphones or microphone, you cannot

use the internal one.

4-6 Expanding Your Computer

) can be connected to an external microphone

Using ExpressCards

Using ExpressCardsUsing ExpressCards

Your computer has an ExpressCard slot.

The ExpressCard slot can accommodate a 54 mm (ExpressCard/54) or 34 mm (ExpressCard/34) wide ExpressCard. Typical ExpressCards support a very extensive range of applications including memory, wired and wireless communication cards, and security devices.

Shown next are the appearances of ExpressCards for your reference.

ExpressCard/54 ExpressCard/34

To insert an ExpressCard:

1. Locate the ExpressCard slot on the left side of the computer. It can be the upper slot (standard configuration) or lower slot depending on your model.

2. Slide the ExpressCard, with its label facing up, all the way into the slot until the rear connectors click into place.

Eject button

Expanding Your Computer 4-7

3. When a new card is seated, the computer will detect it and try to install the appropriate driver. Follow the on-screen instructions to complete the process.

To remove an ExpressCard:

1. Double-click on the Safely Remove Hardware Windows taskbar and the Safely Remove Hardware

2. Select (highlight) the ExpressCard from the list to disable the card.

3. Push the eject button and the card will slide out slightly.

4. Pull the card out of the slot.

Safely Remove Hardware icon ( ) found on the

Safely Remove Hardware Safely Remove Hardware

Safely Remove Hardware window appears on screen.

Safely Remove HardwareSafely Remove Hardware

4-8 Expanding Your Computer

Using PC Cards

Using PC CardsUsing PC Cards

NOTE:

 Some PC cards require additional system resources. Before using such PC

card, you may have to free other system resources for the PC card.

 Although some PC cards can be inserted and removed without turning off the

computer, you cannot remove or install PC cards during Sleep mode.

Your computer (standard configuration) has one PC card slot that support CardBus specifications. The slots can accommodate a type II card. Typical type II cards are flash memory, SRAM, modem, LAN, and SCSI cards.

To insert a PC card:

1. Locate the PC card slot (the lower slot) on the left side of the computer.

2. Slide the PC card, with its label facing up, into the slot until the eject button pops out.

Eject button

3. When a new card is seated, the computer will detect it and try to install the appropriate driver. Follow the on-screen instructions to complete the process.

To remove a PC card:

1. Double-click the Safely Remove Hardware and the Safely Remove Hardware

2. Select (highlight) the PC card from the list to disable the card.

Safely Remove Hardware window appears on screen.

Safely Remove HardwareSafely Remove Hardware

Safely Remove Hardware

Safely Remove Hardware Safely Remove Hardware

icon found on the Windows taskbar

Expanding Your Computer 4-9

3. Push the eject button and the card will slide out slightly.

4. Pull the card out of the slot.

4-10 Expanding Your Computer

Using Smart Cards (Optional)

Using Smart Cards (Optional)Using Smart Cards (Optional)

Your computer may have a smart card reader.

With an embedded microcontroller, smart cards have the unique ability to store large amounts of data, carry out their own on-card functions (e.g., encryption and mutual authentication), and interact intelligently with a smart card reader.

To insert a smart card:

1. Locate the smart card slot.

2. Slide the smart card, with its label and embedded computer chip facing up into the slot.

3. When a new card is seated, use the third-party smart card software to allow your computer to read it.

To remove a smart card:

1. Make sure that the third-party smart card software is not accessing the smart card.

2. Pull the card out of the slot.

Expanding Your Computer 4-11

Using Storage Cards

Using Storage CardsUsing Storage Cards

NOTE: You can use only storage cards. Your SD card reader does not support cards with I/O (input/output) functions such as a wireless network card or Bluetooth card.

Your computer has an SD card reader. The card reader is a small drive for reading from and writing to removable storage cards (or called memory cards). The card reader supports SD (Secure Digital), SDHC (Secure Digital High Capacity), and SDXC (Secure Digital eXtended Capacity) cards.

To insert a storage card:

1. Locate the SD card reader on the left side of the computer.

2. Align the card with its connector pointing to the slot and its label facing up. Slide the card into the slot until it reaches the end.

3. Windows will detect the card and assign it a drive name.

To remove a storage card:

1. Double-click My Computer

2. Right-click the drive with the card and select Eject

3. Push the card to release and then pull the card out of the slot.

4-12 Expanding Your Computer

My Computer.

My ComputerMy Computer

Eject.

EjectEject

System Memory Upgrade

System Memory UpgradeSystem Memory Upgrade

You can upgrade your computer by expanding system memory.

CAUTION:

 It is not recommended that you buy and install RAM modules by yourself. If

you want to expand system memory, please ask Getac service center to install DRAM modules for you so that full compatibility can be guaranteed.

 RAM modules are extremely sensitive to static electricity. There are cases

where static electricity generated by the human body has adversely affected such modules. When inserting or removing a RAM module, do not touch the terminals or internal components, insert objects other than the module, or allow foreign particles to enter. Doing so has been known to cause damage, fire, or electrical shock.

o install the RAM module:

1. Remove the battery pack (see chapter 3) and make sure that the computer is not connected to AC power.

2. Carefully place the computer upside down.

3. Remove the four screws to open the compartment cover.

Expanding Your Computer 4-13

4. To install the RAM module, match the module's notched part with the socket's projected part and firmly insert the module into the socket at a 20-degree angle. Then push down until the retaining clips lock the module into position.

CAUTION: If the RAM module is difficult to insert or difficult to push down, do not force it. Check once more to ensure that the module is positioned correctly.

5. Close the compartment cover and secure with four screws.

4-14 Expanding Your Computer

Chapter 5

Chapter 5Chapter 5

Using BIOS Setup and

Using BIOS Setup and Using BIOS Setup and System Recovery

System Recovery

System RecoverySystem Recovery

BIOS Setup Utility is a program for configuring the System) settings of the computer. BIOS is a layer of software, called firmware, that translates instructions from other layers of software into instructions that the computer hardware can understand. The BIOS settings are needed by your computer to identify the types of installed devices and establish special features.

System Recovery reinstalls Windows to your computer and restores it to the factory default status.

This chapter tells you how to use the BIOS Setup and System Recovery.

BIOS (Basic Input/ Output

Using BIOS Setup and System Recovery 5-1

V200

BIOS Setup

BIOS SetupBIOS Setup

When and How to Us

When and How to Useeee

When and How to UsWhen and How to Us

You need to run BIOS Setup Utility when:

 You see an error message on the screen requesting you to run BIOS Setup

Utility.

 You want to restore the factory default BIOS settings.

 You want to modify some specific settings according to the hardware.

 You want to modify some specific settings to optimize the system performance.

To run BIOS Setup Utility, press the F2

F2 key when the prompt appears on the screen

F2F2

during the system startup. The prompt shows up on the screen for only a few seconds. You must press the F2

F2 key quickly. The BIOS Setup Utility main screen appears

F2F2

as shown next.

Information Main Advanced Security Boot Exit

Model NO: Serial NO: Asset Tag: Processor Info: Installed System Memory:

SATA HDD:

BIOS Revision: EC Revision: LAN MAC Address:

IEEE 1394 GUID:

Operating Time:

F1 Help ↑↓ Esc Exit ←→

↑↓ Select Item +/- Change Values F9 Setup Defaults

↑↓↑↓ ←→ Select Menu Enter Select  Sub-Menu F10 Save and Exit

←→←→

-G2

RC6XXV0026

Intel(R) Core(TM) i5-3320M CPU @2.60GHz 4096 MB

TOSHIBA MQ01ABD032 – 320.0 GB

R1.50.070520G R0.50P.070520 00-22-20-0D-98-C0

00-40-D0-01-00-49-00-D6

184 Hours

5-2 Using BIOS Setup and System Recovery

V100

In general, you can use the arrow keys to move around and + / – keys to change the setup values. Keyboard information can be found at the bottom of the screen.

NOTE:

 The BIOS Setup Utility screens shown in this chapter are for your reference

only. The actual items or settings on your computer may differ.

 The BIOS Setup Utility program may have been updated after the publication

of this manual.

 The settings you select in your operating system might override similar

settings in BIOS Setup Utility.

Information Menu

nformation MenuInformation Menu

The Information menu contains the basic configuration information of the system. There are no user-definable items in this menu.

Information Main Advanced Security Boot Exit

Model NO: Serial NO: Asset Tag: Processor Info: Installed System Memory:

SATA HDD:

BIOS Revision: EC Revision: LAN MAC Address:

IEEE 1394 GUID:

Operating Time:

F1 Help ↑↓ Esc Exit ←→

↑↓ Select Item +/- Change Values F9 Setup Defaults

↑↓↑↓ ←→ Select Menu Enter Select  Sub-Menu F10 Save and Exit

←→←→

-G4

RC5XXV0043

Intel(R) Core(TM) i5-3320M CPU @2.60GHz 8192 MB

LITEONIT LAT-128M3S – 128 GB

R1.01.070520U R0.50M.070520 00-22-20-0D-A8-A7

00-40-D0-01-00-49-00-2D

80 Hours

NOTE:

The “Asset Tag” information appears when you have entered the asset

number for this computer using the asset management program. The program is provided in the Asset tag folder of the Driver disc.

Using BIOS Setup and System Recovery 5-3

Main Menu

Main MenuMain Menu

The Main menu contains various system settings.

Information Main Advanced Security Boot Exit

System Date:

System Time:

Legacy USB Support:

F1 Help ↑↓ Esc Exit ←→

↑↓ Select Item +/- Change Values F9 Setup Defaults

↑↓↑↓ ←→ Select Menu Enter Select  Sub-Menu F10 Save and Exit

←→←→

[05/28/2012] [11:33:08]

[Enabled]

Item Specific Help

View or set system date.

System Time

System Time sets the system time.

System TimeSystem Time

System Date

System Date sets the system date.

System DateSystem Date

Legacy USB Support

Legacy USB Support enables or disables the system’s support for Legacy USB device

Legacy USB SupportLegacy USB Support

in DOS mode.

5-4 Using BIOS Setup and System Recovery

Disabled

Advanced Menu

Advanced MenuAdvanced Menu

The Advanced menu contains the advanced settings as shown next.

Information Main Advanced Security Boot Exit

 Intel (R) Rapid Start Technology

 Wake Up Capability

System Policy AC Initiation: SATA Mode:

 AMT Configuration  Virtualization Technology Setup  Graphic Setup  Device Configuration  Serial COM Port Configuration

F1 Help ↑↓ Esc Exit ←→

↑↓ Select Item +/- Change Values F9 Setup Defaults

↑↓↑↓ ←→ Select Menu Enter Select  Sub-Menu F10 Save and Exit

←→←→

[Performance] [Disabled] [AHCI]

Item Specific Help

iRST – Intel (R) Rapid Start Technology Configuration

Intel (R) Rapid Start Technology

Intel (R) Rapid Start Technology configures iRST. Press Enter

Intel (R) Rapid Start Technology Intel (R) Rapid Start Technology

Enter to access the submenu

Enter Enter

as shown below.

Advanced

Intel (R) Rapid Start Technology Item Specific Help

iRST Support:

F1 Help ↑↓ Esc Exit ←→

↑↓ Select Item +/- Change Values F9 Setup Defaults

↑↓↑↓ ←→ Select Menu Enter Select  Sub-Menu F10 Save and Exit

←→←→

[Disabled ]

Using BIOS Setup and System Recovery 5-5

Enable iRST.

Disabled

iRST Support enables of disables iRST, which gets your system up and running faster.

Wake Up Capability

Wake Up Capability specifies events for waking up the system. Press Enter

Wake Up CapabilityWake Up Capability

Enter to access

Enter Enter

the submenu as shown below.

Advanced

Wake Up Capability Item Specific Help

Ring Wake Up From S3:

USB Wake Up From S3: Wake on PCH LAN:

F1 Help ↑↓ Esc Exit ←→

↑↓ Select Item +/- Change Values F9 Setup Defaults

↑↓↑↓ ←→ Select Menu Enter Select  Sub-Menu F10 Save and Exit

←→←→

[Disabled] [Disabled] [Disabled]

Allow a modem activity to wake up the system from S3(Sleep) state.

Ring Wake Up From S3 allows a modem device activity to wake up the system from S3 (Sleep) state.

USB Wake Up From S3 allows a USB device activity to wake up the system from S3 (Sleep) state.

Wake on PCH LAN allows a LAN activity to wake up the system from S3 (Sleep) state.

System Policy

System Policy sets if the system always runs at full speed (

System Policy System Policy

down when its temperature is too high (

AC Initiation

AC Initiation sets if connecting AC power will automatically start or resume your

AC Initiation AC Initiation

computer.

AHCI

SATA Mode

SATA Mode set to

SATA ModeSATA Mode

if your hard disk supports AHCI. AHCI allows you to take

advantage of Advanced Host Controller Interface features. The options are

AHCI

CAUTION: Incorrect SATA mode settings can result in hard disk drive boot failure.

5-6 Using BIOS Setup and System Recovery

Balance

Performance

) or lowers

IDE

and

Enabled

AMT Configuration

AMT Configuration configures Active Management Technology parameters. Press

AMT ConfigurationAMT Configuration Enter

Enter to access the submenu as shown below.

Enter Enter

Advanced

AMT Configuration Item Specific Help

Intel AMT:

Intel AMT Setup Prompt:

F1 Help ↑↓ Esc Exit ←→

↑↓ Select Item +/- Change Values F9 Setup Defaults

↑↓↑↓ ←→ Select Menu Enter Select  Sub-Menu F10 Save and Exit

←→←→

[Disable ] [Disabled]

Enable/Disable Intel (R) Active Management Technology BIOS Extension. Note: iAMT H/W is always enabled. This option just controls the BIOS extension execution. If enabled this requires additional firmware in the SPI device

Intel AMT enables or disables Intel® Active Management Technology BIOS extension execution. AMT allows the system administrator to access an AMT featured computer remotely.

Intel AMT Setup Prompt

Intel AMT Setup Prompt determines whether the prompt for entering Intel AMT

Intel AMT Setup PromptIntel AMT Setup Prompt

Setup appears or not during POST. If disabled, users cannot enter Intel AMT Setup.

Virtualization Technology Setup

Virtualization Technology Setup sets Virtualization Technology parameters. Press Enter

Virtualization Technology SetupVirtualization Technology Setup

Enter

Enter Enter

to access the submenu as shown below.

Using BIOS Setup and System Recovery 5-7

Disabled

Advanced

Virtualization Technology Setup Item Specific Help

Intel(R) Virtualization Technology

Intel(R) VT for Directed I/O (VT-d)

F1 Help ↑↓ Esc Exit ←→

↑↓ Select Item +/- Change Values F9 Setup Defaults

↑↓↑↓ ←→ Select Menu Enter Select  Sub-Menu F10 Save and Exit

←→←→

[Disabled] [Disabled]

When enabled, a VMM can utilize the additional hardware capabilities.

Intel(R) Virtualization Technology

Intel(R) Virtualization Technology enables or disables Intel® VT (Intel

Intel(R) Virtualization TechnologyIntel(R) Virtualization Technology

Virtualization Technology) feature which provides hardware support for processor virtualization. When enabled, a VMM (Virtual Machine Monitor) can utilize the additional hardware virtualization capabilities provided by this technology.

Intel(R) VT for Directed I/O (VT

Intel(R) VT for Directed I/O (VT----d)

Intel(R) VT for Directed I/O (VTIntel(R) VT for Directed I/O (VT

Technology for Directed I/O). When enabled, VT-d helps enhance Intel platforms for efficient virtualization of I/O devices.

Graphics Setup

Graphics Setup sets graphics related options. Press Enter

Graphics SetupGraphics Setup

as shown below.

5-8 Using BIOS Setup and System Recovery

d) enables or disables VT-d (Intel® Virtualization

d)d)

Enter to access the submenu

Enter Enter

64MB

Advanced

Graphic Setup Item Specific Help

DVMT Pre-Allocated:

Total Graphics Memory:

F1 Help ↑↓ Esc Exit ←→

↑↓ Select Item +/- Change Values F9 Setup Defaults

↑↓↑↓ ←→ Select Menu Enter Select  Sub-Menu F10 Save and Exit

←→←→

[ ] [256MB]

Select Pre-Allocated Graphics Memory size used by the Internal Graphics Device. This has no effect if external graphics are present.

NOTE: Graphic Setup parameters apply to the internal graphics device only.

DVMT Pre

DVMT Pre----Allocated

DVMT PreDVMT Pre

Allocated sets the amount of pre-allocated (fixed) graphics memory

Allocated Allocated

for use by the internal graphics device.

Total Graphics Memory

Total Graphics Memory sets the amount of total graphics memory (pre-allocated

Total Graphics Memory Total Graphics Memory

+ fixed + DVMT) for use by the internal graphics device.

Using BIOS Setup and System Recovery 5-9

Enabled

Device Configuration enables or disables several hardware components. Press Enter to access the submenu as shown below.

Advanced

Device Configuration Item Specific Help

Wireless LAN:

WWAN: Bluetooth: Media Card Reader: Smart Card Reader: HD Audio: Modem:

Fingerprint Scanner: 1394 Port: Touch Screen: GPS:

F1 Help ↑↓ Esc Exit ←→

↑↓ Select Item +/- Change Values F9 Setup Defaults

↑↓↑↓ ←→ Select Menu Enter Select  Sub-Menu F10 Save and Exit

←→←→

[ ] [Enabled] [Enabled] [Enabled] [Enabled] [Enabled] [Enabled] [Enabled] [Enabled] [Enabled] [Enabled]

Set WLAN device to enable/disable.

You can enable or disable the following items:

 Wireless LAN

 WWAN

 Bluetooth

 Media Card Reader (SD)

 Smart Card Reader

 HD Audio (High Definition Audio)

 Modem

 Fingerprint Scanner

 1394 Port

 Touch Screen

 GPS

5-10 Using BIOS Setup and System Recovery

Enabled

Serial COM Port Configuration enables or disables the serial port. Press Enter to access the submenu as shown below.

Advanced

COM PORT Configuration Item Specific Help

Serial COM PORT1

Serial COM PORT2

Serial COM PORT3

F1 Help ↑↓ Esc Exit ←→

↑↓ Select Item +/- Change Values F9 Setup Defaults

↑↓↑↓ ←→ Select Menu Enter Select  Sub-Menu F10 Save and Exit

←→←→

[ ] [Enabled] [Enabled]

This option controls the Onboard COM1 Address. When enabled, COM1 uses address 0x3F8h and IRQ4.

Using BIOS Setup and System Recovery 5-11

Enter

Security Menu

Security MenuSecurity Menu

The Security menu contains the security settings, which safeguard your system against unauthorized use.

Information Main Advanced Security Boot Exit

Supervisor Password Is: User Password Is:

Set Supervisor Password:

Set User Password Password on Boot:

Set HDD 0 Password: HDD 0 Password:

 TPM Setup Menu

Intel Trusted Execution Technology

F1 Help ↑↓ Esc Exit ←→

↑↓ Select Item +/- Change Values F9 Setup Defaults

↑↓↑↓ ←→ Select Menu Enter Select  Sub-Menu F10 Save and Exit

←→←→

Cleared Cleared [Enter] [Enter] [Disabled]

[Enter] Cleared

[Disabled]

Item Specific Help

Set or clear the Supervisor account’s password.

NOTE:

 You can set the user password only when the supervisor password has been

set.

 If both the administrator and user passwords are set, you can enter any of

them for starting up the system and/or entering BIOS Setup. However, the user password only allows you to view/change the settings of certain items.

 A password setting is applied right after it is confirmed. To cancel a password,

leave the password empty by pressing the Enter key.

Supervisor/User Password Is

Supervisor/User Password Is shows whether you have set the supervisor/user

Supervisor/User Password Is Supervisor/User Password Is

password or not for the system.

Set Supervisor/User Password

Set Supervisor/User Password sets the supervisor/user password. When typing the

Set Supervisor/User PasswordSet Supervisor/User Password

password, first make sure that Num Lock is off, and then type the password in the entry fields and press Enter

Enter. Confirm your password by typing it again and pressing

EnterEnter

5-12 Using BIOS Setup and System Recovery

Enabled

Enter

Enter. You can set the supervisor/user password to be required for starting up the

EnterEnter

system and/or entering BIOS Setup.

Password on Boot

Password on Boot allows you to enable or disable the entering of password for booting

Password on BootPassword on Boot

up your system. Once the password is successfully set and this item is enabled, it is required for booting up the system.

Set HDD

Set HDD 0 Password

Set HDD Set HDD

0 Password sets the password for locking the Primary Master hard disk

0 Password0 Password

drive. After setting a password, the hard disk drive can only be unlocked by the password no matter where it is installed.

HDD 0 Password Is

HDD 0 Password Is shows whether you have set the hard disk password or not.

HDD 0 Password Is HDD 0 Password Is

TPM Setup Menu

TPM Setup Menu sets various TPM parameters. Press Enter

TPM Setup MenuTPM Setup Menu

Enter to access the submenu

Enter Enter

as shown below.

Security

TPM Setup Menu Item Specific Help

TPM Support:

Current TPM State:

Change TPM Status:

F1 Help ↑↓ Esc Exit ←→

↑↓ Select Item +/- Change Values F9 Setup Defaults

↑↓↑↓ ←→ Select Menu Enter Select  Sub-Menu F10 Save and Exit

←→←→

[ ]

[Enabled and Activated]

[No Change]

This is used to decide whether TPM support should be enabled or disabled.

TTTTPM Support

PM Support enables or disables TPM (Trusted Platform Module) support. TPM

PM Support PM Support

(Trusted Platform Module) is a component on your computer’s mainboard that is specifically designed to enhance platform security by providing a protected space for key operations and other security critical tasks.

Using BIOS Setup and System Recovery 5-13

Current TPM State

Current TPM State shows the current TPM state.

Current TPM StateCurrent TPM State

Change TPM State

Change TPM State allows you to select between

Change TPM State Change TPM State

& Disable

, and

Enable & Activate

No Change, Clear, Deactivate

Intel Trusted Execution Technology enables utilization of additional hardware capabilities provided by Intel® Trusted Execution Technology.

Boot Menu

Boot MenuBoot Menu

The Boot menu sets the sequence of the devices to be searched for the operating system.

Information Main Advanced Security Boot Exit

Boot priority order:

1. SATA ODD:

2. SATA HDD1: TOSHIBA MQ01ABD032

3. USB HDD:

4. USB FDD:

5. PCI LAN: IBA GE Slot 00C8 v1365

6. USB ODD:

7. Other HDD:

8. ESATA HDD:

F1 Help ↑↓ Esc Exit ←→

↑↓ Select Item +/- Change Values F9 Setup Defaults

↑↓↑↓ ←→ Select Menu Enter Select  Sub-Menu F10 Save and Exit

←→←→

Item Specific Help

Keys used to view or configure devices:  and 

 arrows Select a



device. ’+’ and ’-’ moves the device up or down. ’Shift + 1’ enables or disables a device. ’Del’ deletes an unprotected device.





The bootable devices will be automatically detected during POST and shown here, allowing you to set the sequence that the BIOS uses to look for a device from which to load the OS.

Below is a brief description of keyboard usage:

5-14 Using BIOS Setup and System Recovery

highlighted boot device from the “Boot priority order” list to

xclamation)

symbol appears beside the item and system will bypass it when detecting

Key

Key Function

KeyKey

Function

FunctionFunction

↑ , ↓ Selects (highlight) a boot device.

+, – Changes the boot sequence.

1111 to 4444 Loads the default boot sequence.

Key

Key Function

KeyKey

Function

FunctionFunction

ffff or rrrr Specifies if the boot device is fixed (ffff) or removable (rrrr).

XXXX

Moves the the “Excluded from boot order” list, and vice versa.

Shift

Shift+1111

ShiftShift

Deactivates/activates the highlighted boot device on the “Boot priority order” list. When a device has been deactivated, an “!” (e

boot device during POST.

Exit Menu

Exit MenuExit Menu

The Exit menu provides ways of exiting BIOS Setup. After finishing with your settings, you must save and exit so that the changes can take effect.

Information Main Advanced Security Boot Exit

Exit Saving Changes

Exit Discarding Changes

Load Setup Defaults

Discard Changes

Save Changes

F1 Help ↑↓ Esc Exit ←→

↑↓ Select Item +/- Change Values F9 Setup Defaults

↑↓↑↓ ←→ Select Menu Enter Select  Sub-Menu F10 Save and Exit

←→←→

Item Specific Help

Equal to F10, save all changes of all menus, then exit setup configure driver. Finally resets the system automatically.

Using BIOS Setup and System Recovery 5-15

Exit Saving Changes

Exit Saving Changes saves the changes you have made and exits BIOS Setup Utility.

Exit Saving Changes Exit Saving Changes

Exit Discarding Changes

Exit Discarding Changes exits BIOS Setup Utility without saving the changes you have

Exit Discarding Changes Exit Discarding Changes

made.

Load Setup Defaults

Load Setup Defaults loads the factory default values for all the items.

Load Setup DefaultsLoad Setup Defaults

Discard Changes

Discard Changes restores the previous values for all the items.

Discard Changes Discard Changes

Saves Changes

Saves Changes saves the changes you have made.

Saves Changes Saves Changes

5-16 Using BIOS Setup and System Recovery

Getac Technology 046, 047 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
