Wonderful Communication, Mobile Life.
HUAWEI Mobile Partner
User Manual
Copyright © 2007 Huawei Technologies Co., Ltd.
All Rights Reserved
No part of this manual may be reproduced or transmitted in any form or by any
means without prior written consent of Huawei Technologies Co., Ltd.
Trademarks
and HUAWEI are trademarks of Huawei Technologies Co., Ltd. All other
trademarks mentioned in this manual are the property of their respective holders.
Notice
The information in this manual is subject to change without notice. Every effort
has been made in the preparation of this manual to ensure accuracy of the contents,
but all statements, information, and recommendations in this manual do not
constitute the warranty of any kind, expressed or implied.
Contents
1 Descriptions of the Mobile Partner GUI ............................................................................... 1
Launch the Mobile Partner ............................................................................................ 1
Interface Overview ........................................................................................................ 1
2 Internet Services .................................................................................................................... 3
Accessing the Internet ................................................................................................... 3
Statistics Information ..................................................................................................... 3
3 T ext Message ......................................................................................................................... 5
Creating and Sending a Message .................................................................................. 5
Inbox .............................................................................................................................. 6
Outbox ........................................................................................................................... 7
Important, Draft, Deleted and Report ............................................................................ 7
Viewing a Message in the SIM/USIM Card ................................................................. 8
Text Message Settings ................................................................................................... 9
4 Phonebook ........................................................................................................................... 10
Phonebook Management in Local ............................................................................... 10
Phonebook Management in the SIM/USIM Card ....................................................... 12
Import/Export .............................................................................................................. 13
5 Settings and Information Query .......................................................................................... 15
Switching a Language ................................................................................................. 15
PIN Operations ............................................................................................................ 15
Choosing a Device ....................................................................................................... 16
Viewing Diagnostic Information ................................................................................. 16
Startup Settings ............................................................................................................ 17
Network Settings ......................................................................................................... 17
Connection Profile Settings ......................................................................................... 18
6 FAQs .................................................................................................................................... 21
7 Acronyms and Abbreviations .............................................................................................. 22
i
1 Descriptions of the Mobile Partner
GUI
Launch the Mobile Partner
To launch the Mobile Partner, double-click the shortcut icon of the Mobile Partner
on the desktop.
Note:
If you are required to enter the Personal Identification Number (PIN) code, enter
the correct one and click OK. If you fail to enter the correct PIN or PIN
Unblocking Key (PUK) code, the network-related functions are unavailable.
Contact your service provider for whether a Subscriber Identity Module (SIM)/
UMTS Service Identity Module (USIM) card is needed.
The SIM/USIM card is supplied by the service provider. For details, contact
your service provider.
Interface Overview
Shortcut Icons
The following table lists the shortcut icons provided by the Mobile Partner.
Click… To…
Display the Connect interface.
Query the statistics of the transferred data.
Display the Text interface.
1
Click… To…
Display the Phonebook interface.
Status Information
The following table lists all the possible status information.
Status Information Description
Network signal Indicate the signal strength of the network by the following
icons:
Network information Display the profile of the current network.
New message
Unread message When there is an unread message:
Network connection The information of the network connection:
Tr ansferred data
If the Text message handling is enabled, when there is a new
message:
In the status bar, the icon
On the lower right corner of the PC screen, the Prompt
dialog box is displayed.
In the status bar, the icon
When you move the cursor to the icon, the number of the
unread message(s) is displayed.
: The network is connected.
: The network is disconnected.
: Data download is in progress.
flashes.
flashes.
: Data upload is in progress.
2
2 Internet Services
Accessing the Internet
After setting the network and connection profiles, you can access the network through the
Mobile Partner.
You can do as follows to connect the network.
1. Click
2. Select the network type and a correct profile.
3. Click Connect to launch the browser on the PC to access the network.
Note:
When the connection is established, the statistics interface displays the details of
When the connection is established, click Disconnect to disconnect from the
to display the Connect interface.
the current network, including connected duration, data statistics, transferred
rate and so on.
network.
Statistics Information
You can use the Statistics function to check the traffic of the network.
Viewing the Statistics Informati on
You can do as follows to view the statistics information:
1. Click
2. In the navigation tree, click the following tabs to display the corresponding diagram.
Transfer: View the uploaded/downloaded speed and data of the current connection.
Statistics: View the current connected duration, last reset time, and
daily/monthly/yearly uploaded and downloade d dat a.
to display the statistics interface.
3
Resetting the Statistics Information
You can operate as follows to reset the statistics information:
1. In the navigation tree, right-click a tab.
2. Choose Reset Statistics.
3. In the Confirm dialog box, click Yes.
4
