Gericom A360 Notebook Specification
A
Notebook Specification
This appendix provides the technical specification of the A360 notebook:
A.1 System Specification
MICRO PROCESSOR
CPU Type Pentium-III / Celeron Processor
Clock Speed and Voltage • Pentium-III CPU at 933 MHz, 1/1.1GHz
• Celeron CPU at 766/800/850/900/950 MHz
External L2 Cache 256 KB (Pentium-III) / 128KB (Celeron)
CPU Package FC-PGA
SYSTEM LOGIC CHIPSET
Chipset Type • VIA Twister - North Bridge
• VI82C686A - South Bridge
Thermal controller Integrated in South Bridge
Appendix
SYSTEM CLOCK
System Clock
Package SSOP
Clock Summary • CPUCLK = 66/100 /133 MHz
Supply Current Icc Max = 90mA (CPU = 66.6 MHz, PCI = 33 MHz)
Package SDRAM PC100/133 – 32 / 64 / 128 / 256 M B SO-DIMM
Operation Mode Synchronous Dynamic Mode
Refresh Auto and Self Refresh
Slow Refresh 4096 refresh cycle / 64ms
Supply Voltage 3.3V
Configuration • Standard SODIMM DRAM Module – 2 pieces
Parity Support No parity bit for all memory
SMC FDC37869
• PCICLK = 30/33 MHz
• South Bridge / VGA = 14.318 MHz
• North Bridge = 48 MHz
MEMORY MODULE
• 640KB Conventional RAM
• 128KB BIOS Shadow
• 256KB reserved for Power Management usage
• 7168KB Extended RAM
• Upgradable to max. 512MB using 256 MB SODIMM x 2
FIC A360 Service Manual A-1
Notebook Specification
BIOS ROM
ROM Type 512K x 8 CMOS Flash Memory –28SF040A-90/120 (SST)
ROM Size 4M-bit
Boot Code Sector Top Sector
Package PLCC 32-lead
Erase / Program • 8 second typical chip erase
• 3.6 second chip program
• 10,000 erase/program cycles minimum
Program Voltage 5V
Supply Current • Icc Typ. = 20mA (active read)
• Icc Typ. = 30mA (active program)
• Iccsb Max = 50uA (standby)
VIDEO SUBSYSTEM
Video Chipset S3 Savage 4 (Integrated in Twister) with AGP 4 x SMA
Video RAM 16MB SDRAM
(Using system memory, SMA) (Twister spec is 2/32 MB)
Bus Interface 32-bit PCI Local Bus
Addressing Linear Addressing
Simul Scan Yes
Maximum Resolution at CRT 1280 x 1024 at 32-bit color (16 million colors)
Maximum Color at CRT 32-bit color (16 million colors)
External CRT connector 15-pin D-Sub female
I/O SUBSYSTEM
I/O Controller Chip Integrated in South Bridge
Parallel / Printer Port (LPT1) 25-pin D-sub female connector (with EPP/ECP support)
Serial / COM Port (COM1) • Type: 9-pin D-sub male RS-232 connector
• Baud Rate: 300 – 38400 bps (UART 16C550)
• Drivers / Receiver: Maxim MAX3243 (SSOP, 28-pin)
KEYBOARD SUBSYSTEM
Keyboard Controller Mitsubishi M38867
Package QFP 80-Pin
Host Interface 8042-style host interface
Keyboard Scan Local 16 x 8 keyboard switch matrix
External PS/2 Keyboard Mini-DIN PS/2 connector
A-2 FIC A360 Service Manual
Notebook Specification
SOUND SUBSYSTEM
Audio Chip Integrated in VT82C686B (PCI audio)
Bus Interface 32-bit PCI Bus
Compatibility Sound Blaster 16 (Pro) & 3D Surround Sound
Wavetable Function Software
Connection Full-Duplex
Volume Analog H/W Volume
Built-in Speaker 2-way (left and right) mini speakers
Built-in Microphone Mono
Line-In Jack 1 x line-in jack
Line-Out Jack 1 x line-out jack
Microphone Jack 1 x 3.5p microphone jack
POINTING DEVICE SUBSYSTEM
Chipset Controller Mitsubishi M38867
Package QFP 80-Pin
Touchpad Type Synaptics TM41PDG351-1 Glide Point
Interface PS/2
External PS/2 Mouse Mini-DIN PS/2 connector (share with PS/2 keyboard)
PCMCIA SUBSYSTEM
Chipset Controller O2Micro 026933 PCI -cardbus bridge
PCMCIA Slot Configuration 2 Type I or Type II at the same time, or
1 Type III
Bus Type 32-bit PCI CardBus
Compatibility Register Compatible with Intel 82365SL
POWER MANAGEMENT UNIT (PMU)
PMU Modes Video Timeout, Hard Disk Timeout, Suspend to RAM (STR)
Others LCD Cover-Switch STR, ACPI, DMI 2.0, Thermal Control
mode, Suspend to Disk (STD) mode
STATUS LED INDICATORS
Number of LEDs 5 LEDs
Power Status LED
Green color when powering on
Green color blinking when in STR or STD
Amber color in Battery Low.
Battery Charge LED
Green color in charging status
Lights off when the battery is fully charged or no battery
installed
Internet / Mail LED
HDD LED Green color when accessing the HDD
FDD LED Green color when accessing the FDD
Num Lock LED Green color for Num Lock activate on keyboard
Caps Lock LED Green color for Caps Lock activate on keyboard
Scroll Lock LED Green color for Scroll Lock activate on keyboard
Green color when a new mail is arriving
FIC A360 Service Manual A-3
Notebook Specification
HOT-KEY DEFINITION
Number of hot-keys 8 <Fn> key combinations
LCD/CRT Simul Fn + F3 (toggle) (LCD/ CRT/ TV/ LCD&CRT)
Display Stretch / Normal Fn + F5 (toggle)
PC Speaker On / Off (Mute) Fn + F6 (toggle)
Brightness Up Fn + F8
Brightness Down Fn + F9
Save to Disk Fn + Power Button
Internet Function Key Internet Button
Mail Function Key Mail Button
A.2 Display Specification
12.1” SVGA TFT LCD (HANNSTAR)
LCD Model HannStar HSD121PS11
LCD Type 12.1” SVGA TFT
Display Area H246 x V184.5 [mm]
Display Pixels H800 x V600 pixels
Pixel Pitch H 0.3075 x V 0.3075
Pixel Arrangement RGB vertical stripe
Display colors 262144 Colors
Module Size W275 x H199 x D6.0 MAX [mm]
Weight Approx. 410g
Contrast Ratio 250:1 (typ.)
Power Supply 3.3 V
Power Consumption 2.6 W
Response Time 50ms (max)
Operating Temperature 0 to 50 degrees Celsius
Storage Temperature -20 to 60 degrees Celsius
12.1” SVGA TFT LCD (ADI)
LCD Model ADI AA121SJ23
LCD Type 12.1” SVGA TFT
Display Area H246 x V184.5 [mm]
Display Pixels H800 x V600 pixels
Pixel Pitch H 0.3075mm x V 0.3075mm
Pixel Arrangement RGB stripe arrangement
Display colors 260K Colors
Module Size H275 x V199 x T6.0 MAX [mm]
Weight Approx. 440g
Contrast Ratio 150:1 (Typ.)
Power Supply 3.3 V
Power Consumption 3.8 W
A-4 FIC A360 Service Manual
