SHOWER ACCESSORIES
SHOWER ACCESSORIES
Finishes Available
• Chrome
•
Other: Refer to the Price List for additional finishes
Standards
SP ECI FIC ATI ONS
• UPC/ cUPC
Warranty
Danze products are cove red by a manufac turerʼ s
limited "l ifetime" warranty for manufacturing defects.
Ø1 9/16"
(Ø39mm)
1/2-14NPT
2 1/2"
(63mm)
1/2-14NPSM
3 3/8"
(85mm)
D469100
3 13/16"
1/2-14NPT
(97mm)
1 1/8"
(28mm)
(65mm)
2 9/16"
D469100 - Show er arm Mou nt
Description
• With bras s ball joint & i ntegral
chec k valve
D469058 - R1 Supply Elb ow
Description
• Attache s to handshower hos e
• ½" brass water supply c onnection
Includes
•
back flow preventi on
integral check valve for
D469060 - Supp ly Mount*
Description
• Adjus table handshower holde r
• Solid brass ½" supply fitt ing with
integral c heck valve
• Metal housing
D469050 - Two Positio n Wall
Mount Brac ket
Description
• 2 pos ition hands howe r holder
* Additional supply outlet for handshower is
not required when using this supply mount.
2 5/16"
(58mm)
7/16"
(11mm)
1 1/4"
(31mm)
1/2-14NPSM
D469060
7/8"
(23mm)
3/8"
(10mm)
1 3/4"
(43mm)
1/4"
(7mm)
1/2-14NPT
1/2-14NPSM
Ø2 1/4"
(Ø55mm)
2 7/16"
(62mm)
2-Ø5/16ʼʼ
(2-Ø8mm)
2-Ø/16ʼʼ
(2-Ø5mm)
1 5/8ʼʼ
(41.4mm)
1/8’’
(3 mm)
D469058
Submittal Information:
Jo b Name: Lo ca tion :
Cont ra ct or : Cont ac t #:
Danze, Inc., 2500 Internationa le Parkway, Woodridge, IL 60517, USA danze.com
3/8’’
(10mm)
(46mm)
1 13/16’’
7/8’’
(22.3mm)
7/16’’
(10.5mm)
D469050
。
17.3
1 7/8’’
(47mm)
。
3.9
7/8’’
(22.8mm)
1 7/16’’
(37mm)
SDSA2/07-15
R1/16’’
(R2mm)
11/16’’
(17.2mm)
