Gerber D510457TC Specifications

AERATOR KIT 1.75 GPM AERATOR KIT 1.75 GPM

SPECIFICATIONS

AERATOR KIT 1.75 GPM

AERATOR KIT 1.75 GPM

Description

• Flow rate at 1.75 gallon per minute

• Female or male thread available

• Insert provided by Neoperl (see the number in
brackets below)

• Rolling printed "A112.18.1M, 1.75 GPM / 6.6 LPM Max"

• Pressure compensating between 20 psi and 80 psi

Standards

• ASME A112.18.1M

Flow Rate

2

1.5

1

GPM

0.5

0

20 40 60

PSI

80

Warranty

Danze products are covered by a manufacturer’s
limited "lifetime" warranty for manufacturing defects.

Model Numbers:

DA500184N (42.3061.0.000) 1.75 GPM, junior, male, bubble, no wrench included
DA500186N (40.2061.0.0001) 1.75 GPM, standard, female, bubble, no wrench included
DA500210N (40.2061.0.0001) 1.75 GPM, standard, male, bubble, no wrench included
DA500188N (40.2061.0.0001) 1.75 GPM, standard, female, bubble, no wrench included
DA613086N (40.2061.0.0001) 1.75 GPM, standard, male, bubble
DA613085N (42.3061.0.000) 1.75 GPM, junior, male, bubble
DA613087N (31.2013.1) 1.75 GPM, standard, female, bubble
DA613089N (31.2013.1) 1.75 GPM, junior, male, bubble
DA613088N (31.2013.1) 1.75 GPM, standard, male, bubble

DA613086N Shown

Finishes Available

• Chrome

• Other: Refer to Price List for
additional finish

Ø13/16"

(Ø21mm)

Ø15/16"

(Ø24mm)

1/2"

9/16"

(13mm)

(14mm)

3/16"

(5mm)

15/16"-27UNS-2A

Submittal Information:

Job Name: Location:

Contractor: Contact #:

Danze, Inc., 2500 Internationale Parkway, Woodridge, IL 60517, USA danze.com

SDAK1.75/09-11.01
