Fact Sheet
Find a contact near you by visiting www.gewater.com and clicking on “Contact Us” .
* Trademark of General Electric Company; may be registered in one or more countries.
©2013, General Electric Company. All rights reserved.
AM-FSpwSESeries_EN.doc Nov-13
Membrane
S-Series, Thin-Film Membrane (TFM*)
Model
Average
permeate flow
gpd (m3/day)
1,2
Average NaCl
rejection
1,2
Minimum
NaCl
rejection
1,2
SE2540F30
550 (2.1)
98.5%
97.5%
SE2540F50
370 (1.4)
98.5%
97.5%
SE8040C30
8,300 (31.4)
98.5%
97.5%
Model
Spacer
mil (mm)
Active area
ft2 (m2)
Outer wrap
Part
number
SE2540F30
30 (0.76)
25 (2.3)
Fiberglass
1207431
SE2540F50
50 (1.27)
17 (1.6)
Fiberglass
1207427
SE8040C30
30 (0.76)
378 (35.1)
Cage
1207488
Model1
Dimensions, inches (cm)
Boxed
A
B2
C3
Weight
lbs (kg)
SE2540F30
40.0
(101.6)
0.75
(1.9) OD
2.4
(6.1)
4
(1.8)
SE2540F50
40.0
(101.6)
0.75
(1.9) OD
2.4
(6.1)
4
(1.8)
SE8040C30
40.0
(101.6)
1.125
(2.86)
7.9
(20.1)
29
(13.2)
Typical Operating Flux
5-20 GFD (8-34 LMH)
Maximum Operating Pressure
600psi (4,137kPa) if T < 95°F (35°C)
435psi (3,000kPa) if T > 95°F (35°C)
Maximum Temperature
Continuous Operation: 122°F (50°C)
Clean-In-Place (CIP): 122°F (50°C)
pH Range
Optimum rejection Range 5.5-7.0
Continuous Operation: 2.0-10.0
Clean-In-Place (CIP): 1.0-10.5
Maxime Pressure Drop
Over an element: 15psi (103kPa)
Per housing: 60psi (414kPa)
Chlorine Tolerance
500+ ppm-hours,
dechlorination recommended
Feedwater
NTU < 1
SDI < 5
SE Series
Industrial High Rejection Brackish Water RO Elements
The S-Series family of proprietary thin-film reverse
osmosis membrane elements is characterized by
high sodium chloride rejection and a smooth, fouling-resistant membrane surface.
SE High Rejection Brackish Water Elements are
used for brackish water desalination and process
stream concentration.
The SE elements feature either a fiberglass or a patented Durasan* cage outer wrap, 30mil or 50mil
spacer and polysulfone or Noryl plastic parts.
Table 1: Element Specification
Figure 2: Element Dimensions Diagram (Male)
Table 2: Dimensions and Weight
1
Average salt rejection after 24 hours operation. Individual flow rate may vary
±25%.
2
Testing conditions: 2,000ppm NaCl solution at 425psi (2,930kPa) operating pres-
sure, 77°F (25°C), pH6.5 and 15% recovery.
1
These elements are dried then bagged before shipping.
2
Internal diameter unless specified OD (outside diameter).
3
The element diameter (dimension C) is designed for optimum performance in GE
pressure vessels. Other pressure vessel dimension and tolerance may result in
excessive bypass and loss of capacity.
Table 3: Operating and CIP Parameters
Figure 1: Element Dimensions Diagram (Female)
