GE Profile™ 7.4 cu. ft. Capacity aluminized alloy drum Gas Dryer
with Sanitize Cycle and Sensor Dry
DIMENSIONS AND INSTALLATION INFORMATION (IN INCHES)
EXHAUST OPTION: When viewed from the front
of the unit, exhaust 3-way via rear, left and bottom.
Dryer is shipped exhausted to the rear. Alternate
exhausting knockouts are supplied.
GAS: An individual, properly-grounded branch circuit,
with a three-prong grounding-type receptacle, protected
by a 15 or 20 amp circuit breaker or a time-delay fuse is
required.
GAS DRYER ELECTRIC RATING: 120V, 60Hz, 6A
GAS (BTU/HR): 22,000. Factory-equipped for
natural gas. Tested for LP gas. LP gas supply requires
a conversion kit. Check installation instructions for
correct kit and have a qualified gas technician install a
conversion kit. See dryer ducting information for proper
installation.
NOTE: Dryer wall outlet must be located within 36" of
service cord entry and accessible when dryer is mounted
in position.
INSTA L L ATION IN FO R MATION : For complete
information, see installation instructions packed with
your dryer.
SPECIAL INSTALLATION REQUIREMENTS
ALCOVE OR CLOSET INSTALLATION:
- If your dryer is approved for installation in an alcove or closet, it will be stated on a
label on the dryer back.
- The dryer MUST be exhausted to the outside.
- Minimum clearances between dryer cabinet and adjacent walls or other surfaces
are: 0" either side; 1" front, top and rear
- Closet doors must be louvered or otherwise ventilated and must contain a
minimum of 60 sq. in. of open area equally distributed. If this closet contains
both a washer and a dryer, doors must contain a minimum of 120 sq. in. of
open area equally distributed.
- No other fuel-burning appliance shall be installed in the same closet with a
ga s dr yer.
BATHROOM OR BEDROOM INSTALLATION:
- The dryer MUST be exhausted to the outdoors.
- The installation must conform with the local codes, or in the absence of local
codes, with the National Electric Code and National Fuel Gas Code, ANSI
Z223 for gas dryers.
MINIMUM CLEARANCES OTHER THAN ALCOVE OR CLOSET
INSTA L L ATION :
- Minimum clearances to combustible surfaces are: 0" both sides; 1" rear
DRYER EXHAUSTING INFORMATION :
- Use metal duct only, vertical and horizontal ducting.
For answers to your Monogram, GE Café™, GE Profile™ or GE Appliances
product questions, visit our website at geappliances.com or call
GE Answer Center® Service, 800.626.2000.
Specification Revised 12/21
Page 2
PTD60GBSR/BPR
27˝
11-3/4˝
Power Cord 5-1/2˝
3-1/4˝
1-3/4˝
5˝
3-7/8˝
8˝
38-1/2˝
43-7/8˝
30-1/2˝ to front panel
31-1/8˝ to door
28-7/8˝ to door
28-1/4˝ to front panel
23-1/4˝
Side ViewRear View
5
Power
Cord Hole
4-1/2
GE Profile™ 7.4 cu. ft. Capacity aluminized alloy drum Gas Dryer
with Sanitize Cycle and Sensor Dry
DIMENSIONS AND INSTALLATION INFORMATION (IN INCHES)
POWER CORD LOCATIONS
BACK VIEW
For answers to your Monogram, GE Café™, GE Profile™ or GE Appliances
product questions, visit our website at geappliances.com or call
GE Answer Center® Service, 800.626.2000.
Specification Revised 12/21
Page 3
PTD60GBSR/BPR
GE Dryer Vent
2-1/2
GE Profile™ 7.4 cu. ft. Capacity aluminized alloy drum Gas Dryer
with Sanitize Cycle and Sensor Dry
FOR COMPLETE INFORMATION, SEE INSTALLATION INSTRUCTIONS PACKED
WITH YOUR DRYER.
DUCTING MATERIALS:
For best performance, this dryer should be vented with 4" diameter all rigid metal exhaust
duct. If rigid metal duct cannot be used, then UL-listed flexible metal (semi-rigid) ducting can
be used (Kit WX08X10077). In special installations, it may be necessary to connect the dryer
to the house vent using a flexible metal (foil-type) duct. A UL-listed f lexible metal (foil-type)
duct may be used ONLY in installations where rigid metal or flexible metal (semi-rigid) ducting
cannot be used AND where a 4" diameter can be maintained throughout the entire length of
the transition duct. Please see installation instruction packed with your dryer for complete
instructions when using flexible metal (foil type) ducting.
EXHAUST LENGTH CALCULATION:
1. Determine the number of 90° turns needed for your installation. If you exhaust to the side or
bottom of dryer, add one turn.
2. The maximum length of 4" rigid (aluminum or galvanized) duct which can be tolerated is
shown in the table. A turn of 45° or less may be ignored. Two 45° turns within the duct length
should be treated as a 90° elbow. A turn over 45° should be treated as a 90° elbow.
Dryers must be exhausted to the outside.
CAUTION: For personal safety do not terminate exhaust into a chimney, under any enclosed
house floor (crawl space), or into an attic, since the accumulated lint could create a fire hazard
or moisture could cause damage. Never terminate the exhaust into a common duct or plenum
with a kitchen exhaust, since the combination of lint and grease could create a fire hazard.
Exhaust ducts should be terminated in a dampered wall cap to prevent back drafts, bird
nesting, etc. The wall cap must also be located at least 12" above the ground or any other
obstruction with the opening pointed down.
FOR MORE INFORMATION ON VENTING KITS AND ACCESSORIES,
PLEASE CALL 1-800-GE-CARES.
DRYER EXHAUSTING INFORMATION—
USE METAL DUCT ONLY VERTICAL AND
HORIZONTAL DUCTING
BEST PERFORMANCE
Maximum length
of 4" dia rigid
A
4
Domestic dryer models
Long Vent 6.1-7.4 cu. ft.capacity electric & gas(GTD33, GTD42, GTD45,GTD65, GTX22, GTX33, GTX42and GTX65)
For every extra 90° elbow, reduce the allowable vent system
length by 10 ft.
Two 45° elbows will be treated like one 90° elbow.
For the side exhaust installations, add one 90° elbow to the chart.
When calculating the total vent system length, you must add all
the straight portions and elbows of the system (including the
transition duct.
B
Number
of 90°
metal duct
Exhaust hood type
A
turns
0120 ft.90 ft.
1100 f t.75 f t.
285 ft.65 ft.
370 ft.55 f t.
460 f t.45 ft.
555 ft.35 ft.
4"
opening
opening
B
2-1/2"
Specification Revised 12/21
Page 4
PTD60GBSR/BPR
GE Profile™ 7.4 cu. ft. Capacity aluminized alloy drum Gas Dryer
with Sanitize Cycle and Sensor Dry
FEATURES AND BENEFITS
Washer Link – Wirelessly connects the washer to the dryer, enabling the dryer to automatically set
the optimal settings based on the load that was just washed.
Wrinkle Care – Prevent wrinkles by extending the tumble without heat.
Sensor Dry – Innovative dual thermistor technology continually monitors temperature and moisture
to prevent over-drying and protect your laundry.
Sanitize Cycle – Reduces 99.8% of bacteria found in laundry.
Check Vent Notification – Receive a notification when the dryer vent needs to be cleaned, ensuring
safe operation and optimal drying performance.
120 ft. Venting – Innovative 120 ft. venting enables optimal airflow, enhanced drying ability and
flexible installation.
Built-In WiFi Powered by SmartHQ™ – Start, stop and monitor your laundry from anywhere while
receiving real-time notifications and updates.
Download Additional Cycles – Leverage the power of SmartHQ™ technology to download additional
cycles, such as Warm Up, Active Wear and Casual.
My Cycle – Streamline your laundry process by saving your favorite dryer settings for future use.
Quick Dry – Quickly dries a variety of loads for families on the go.
Damp Notification – Receive a notification when your laundry has reached the ideal dampness
to remove from the dryer, so you get wrinkle-free results.
Eco Dry – This dryer uses less energy and still offers reliable performance, giving you the same
high-quality results.
ENERGY STAR® qualified – Meets or exceeds federal guidelines for energy efficiency for
year-round energy and money savings.
Model PTD60GBSRWS – White with silver backsplash
Model PTD60GBPRDG – Diamond Gray
Specification Revised 12/21
