Page 1
Caution : You must read this before you proceed
Armchair
Page 1 OF 8
Page 2
Label Picture Description QTY
A Frame 1
B Back 1
C Seat 1
Label Picture Description QTY
① Bolt (M8*60MM) 3
② Screw (M4*40mm) 5
③ Spring Washer 3
④ Washer 3
⑤ Allen Key 1
⑥ Screwdriver 1
Page 2 OF 8
Page 3
Before
Beginning
Assembly:
Overview
Front Facing
Back(B)
Frame(A)
Seat(C)
Page 3 OF 8
Page 4
Step 1
Step 2
This Armchair has multiple parts and may require up to 30 minutes to
assemble. To give you an overview of the Armchair parts, the above
picture is to help you put the various parts into perspective. Please
read through the instructions below to familiarise yourself with the
parts and steps before assembly.
Place the Frame(A), Back(B) and Seat(C) on a clean, non-marring
surface.
Carefully peel away the Dust Cover from the edge of the Seat(C).
A
B
C
⑤
Back(B)
Seat(C)
2. 1
2. 2
Back(B) Seat(C)
①
③
④
Table
Table
Page 4 OF 8
Page 5
Put the Back(B) onto a Table.
2.1) Align the mounting positions of the Back(B) with Seat(C) and
attach them using Bolts(①), Spring Washers(③) and Washers(④) with
Allen Key(⑤).
Note: If the mounting positions cannot be aligned well and hinder
installation, then sway the Seat(C) lightly when locking the Bolts,
this action could help prevent the Bolts from getting stuck and
ensure smooth assembly.
Tighten the Bolts fully in a sequential manner
2.2) Smooth down the Dust Cover with your hands at all four edges of
the Seat(C) bottom.
Step 3
3. 1
Seat(C)
Table
Assembled Seat(C) and Back(B) stuck in the middle of the Frame(A)
Frame(A)
⑥
②
3. 2
Back(B)
Seat(C)
Frame(A)
Table
Page 5 OF 8
Page 6
Step 4
Place the assembled Seat(C) and Back(B) on the side of the Table,
with the backrest facing down and perpendicular to the Table Top.
3.1)Place the Frame(A) onto the assembled Seat(C) and Back(B) and
align the mounting positions as pictured.
3.2) Attach Frame(A) to Seat(C) using Screws(②) with
Screwdriver(⑥).
Note: If there are gaps between the Frame(A) and Seat(C) which
hinder installation, then pull the Seat(C) upwards into the
Frame(A), this action helps to ensure there are no gaps between
them.
Do not fully tighten the Screws.
Finally, stand the Armchair up, and place on a LEVEL SURFACE.
Inspect it and make sure all parts are adequately connected.
Gently and gracefully, sit into the Armchair.
This would help to align all parts at all joints.
Then get off the Armchair, and place it facedown.
Tighten all Screws at all joints. Do not overtighten the Screws.
Overtightening could lead to damage to the product.
Tighten only until secure and stable.
If there are still wobbles, loosen the screws and execute this
same process.
Test for Stability
Back(B)
Frame(A)
Seat(C)
Page 6 OF 8
Page 7
Step 5
Your Armchair is ready for use.
This Armchair can only be used on a flat, level surface.
Page 7 OF 8
Page 8
Page 8 OF 8
