TABLE
Caution: This Table is NOT a TOY
Keep your child/ children at bay during the assembly process.
Whenever moving/lifting the Table and to prevent damage to the Table, two
adults are needed to execute these actions.
Page 1 OF 6
Parts List
Label Picture
A
B
Description
Table Top
Legs
QTY
1
4
Hardware
Label Picture
1
2
3
Description
Bolt (M8x )65 mm
Spring Washer
Washer
(19x2mm)
(13x2mm)
QTY
9
9
9
4
Allen Key
1
Page 2 OF 6
Assembly Preparation
Before Beginning Assembly:
Assembly Steps
OVERVIEW
Table Top (A )
Legs (B)
FRONT FACING
This Table has multiple parts and may require up to 30 minutes to
assemble. To give you an overview of the Table parts, the above picture is
to help you put the various parts into perspective. Please read through the
instructions below to familiarise yourself with the parts and steps before
assembly.
Page 3 OF 6
Step 1
Unpack and place all parts on a clean, non-marring surface.
Step 2
B
A
B
A
4
3
2
1
Attach Leg (B) to the Table Top (A) by using 2 Bolts ( ), 2 Spring Washers ①
( ) and 2 Washers ( ) with Allen Key ( ).② ③ ④
Do not fully tighten the Bolts.
Repeat the same process with the remaining three Legs (B).
Page 4 OF 6
Step 3
Stand the Table up, with assistance from your adult partner.
Exert pressure floorwards, onto the Table with both your hands.
This pressure will help the Legs and Table Top reach full alignment status.
Check for wobbles on a LEVEL surface.
If no wobbles are found proceed to tighten the Bolts in a sequential
manner, until evenly secured.
When tightening the Bolts tighten sequentially.
Do not tighten any Bolt fully and then move on towards the next one.
If there are still wobbles, loosen the Bolts and excute the same above
process.
If the Table is not Stable it could lead to damage to the product.
Your Table is ready for use.
This Table can only be used on a flat, level surface.
Page 5 OF 6
